Osburn 7000 User manual

READ AND KEEP THIS MANUAL FOR REFERENCE
45723A
Printed in Canada 12-06-2014
INSTALLATION AND OPERATION MANUAL
7000
Safety tested according to ULC S627,
UL1482 and ASTM E1509 by Intertek
Testing Services.
CONTACT LOCAL BUILDING OR FIRE OFFICIALS
ABOUT RESTRICTIONS AND INSTALLATION
INSPECTION REQUIREMENTS IN YOUR AREA.
PLEASE READ THIS ENTIRE MANUAL BEFORE INSTALLATION AND USE OF THIS PELLET FUEL-
BURNING ROOM HEATER. FAILURE TO FOLLOW THESE INSTRUCTIONS COULD RESULT IN
PROPERTY DAMAGE, BODILY INJURY OR EVEN DEATH.
Stove Builder International Inc.
www.osburn-mfg.com
250, rue de Copenhague, St-Augustin-de-Desmaures (Quebec) Canada G3A 2H3
Tel: [phone] Fax: [phone]
INSTALLATION BY A PROFESSIONAL IS STRONGLY RECOMMENDED
This manual is available for free download on the manufacturer’s web site. It is a copyrighted
document. Re-sale is strictly prohibited. The manufacturer may updatethis manual from time to
time and cannot be responsible for problems, injuries, or damages arising out of the use of
information contained in any manual obtained from unauthorized sources.

7000 Pellet Stove Installation and Operation Manual
2 _________________________________________________________________________________________________
THANK YOU FOR CHOOSING THIS OSBURN PELLET STOVE
As one of North America’s largest and most respected pellet stove, wood stove and fireplace
manufacturers, Stove Builder International takes pride in the quality and performance of all its
products. We want to help you get maximum satisfaction as you use this product.
In the pages that follow you will find general advice on pellet heating, detailed instructions for safe
and effective installation, and guidance on how to get the best performance from this stove as you
build and maintain your pellet heating system.
We highly recommend that our pellet burning hearth products be installed and serviced by
professionals who are certified in the United States by NFI (National Fireplace Institute®) or in Canada
by WETT (Wood Energy Technology Transfer) or in Quebec by APC (Association des Professionnels du
Chauffage).
Congratulations on making a wise purchase.
To receive full warranty coverage, you will need to show evidence of
the date you purchased your stove. Keep your sales invoice. We also
recommend that you register your warranty online at:
REGISTER YOUR WARRANTY ONLINE
http://www.osburn-mfg.com/warranty-registration.aspx
Registering your warranty online will help us to quickly track the
information we need about your stove.

7000 Pellet Stove Installation and Operation Manual
_________________________________________________________________________________________________ 3
Table of contents
1INTRODUCTION.......................................................................................................................................6
1.1 About Pellet Heating..............................................................................................................................6
1.1.1 Top 10 Reasons for Buying a Pellet Stove...................................................................................6
1.2 7000 Specifications...............................................................................................................................7
1.3 Overall Exterior Dimensions..................................................................................................................8
PART A – INSTALLATION................................................................................................................................9
2Installation Safety Information...............................................................................................................9
2.1 Installation Warnings, Cautions and Recommendations ......................................................................9
2.2 Regulations Covering Pellet Stove Installation ...................................................................................11
2.3 Before Operating Your Stove..............................................................................................................11
3Clearances to Combustible Material....................................................................................................12
3.1 Certification Label Location.................................................................................................................12
3.2 Minimum Clearances to Combustibles................................................................................................13
3.3 Back Wall Installation..........................................................................................................................13
3.4 Corner Installation...............................................................................................................................14
3.5 Ceiling Clearances..............................................................................................................................14
3.6 Floor Protection...................................................................................................................................14
4Venting system......................................................................................................................................15
4.1 General................................................................................................................................................15
4.2 Recommendations ..............................................................................................................................15
4.3 Equivalent Vent Length (EVL).............................................................................................................15
4.4 Termination Location...........................................................................................................................17
4.4.1 Permitted Termination Location..................................................................................................17
4.5 Installation Configurations...................................................................................................................19
4.5.1 Installation Warnings, Cautions and Recommendations Reminder...........................................19
4.5.2 Through Wall Installation (Main Floor or Basement)..................................................................20
4.5.3 Through Roof Installation ...........................................................................................................21
4.5.4 Through a Factory Built Chimney...............................................................................................22
4.5.5 Through an Existing Masonry Fireplace.....................................................................................23
4.5.6 Through an Existing Masonry Chimney .....................................................................................24
PART B - OPERATION ...................................................................................................................................25
5General information...............................................................................................................................25
5.1 Operation Warnings, Cautions and Recommendations......................................................................25
5.1.1 Zone Heating and How to Make It Work for You........................................................................27
5.2 Combustible ........................................................................................................................................28
5.2.1 Proper Fuel.................................................................................................................................28
5.2.2 Where to Store Bags of Pellets ..................................................................................................28
6Stove controls........................................................................................................................................29
6.1 General Information.............................................................................................................................29
6.1.1 LCD Touch Screen Controls, Operation and Configuration.......................................................29
6.1.2 Configuration and Operation Diagram........................................................................................31
6.1.3 Selecting the Language and Temperature Unit (
⁰ F or ⁰ C).........................................................31
6.1.4 Viewing Statistics........................................................................................................................31
6.1.5 Adjusting the Combustion Level (Heat Output)..........................................................................32
6.1.6 Combustion Settings and Pilot Settings depending on Fuel Quality..........................................33
6.1.7 Convection Fan Speed Adjustment............................................................................................34
6.1.8 Selecting Manual or Thermostat Mode ......................................................................................35
6.1.9 Selecting the Pilot Cycle.............................................................................................................36
6.1.10 Filling or Purging Auger Housing................................................................................................37
6.1.11 Demo Mode................................................................................................................................38

7000 Pellet Stove Installation and Operation Manual
4 _________________________________________________________________________________________________
7Stove operation......................................................................................................................................39
7.1 First Startup.........................................................................................................................................39
7.2 Everyday Startup.................................................................................................................................39
7.3 Running Out of Pellets ........................................................................................................................39
7.4 Refueling.............................................................................................................................................39
7.5 Shutting Down Procedure...................................................................................................................40
7.6 Signs of an Overheating Stove ...........................................................................................................40
8MAINTENANCE......................................................................................................................................41
8.1 Stove Maintenance..............................................................................................................................41
8.1.1 Recommended Maintenance Schedule .....................................................................................41
8.1.2 Cleaning the Baffle, the Heat Exchanger and the Combustion Chamber..................................41
8.1.3 Exhaust Channel and Exhaust Blower Maintenance.................................................................44
8.1.4 Cleaning the Burn Pot ................................................................................................................46
8.1.5 Ash Removal ..............................................................................................................................48
8.1.6 Cleaning the Air Wash System...................................................................................................49
8.1.7 Glass Care..................................................................................................................................49
8.1.8 Replacement of Broken Door Glass...........................................................................................49
8.1.9 Door Gasket Maintenance..........................................................................................................50
8.1.10 Door Adjustment.........................................................................................................................50
8.2 Venting System Maintenance .............................................................................................................50
8.2.1 Dealing With a Chimney Fire......................................................................................................50
8.2.2 Soot and Fly Ash ........................................................................................................................51
9Troubleshooting ....................................................................................................................................52
9.1 Validating Status .................................................................................................................................52
9.2 Testing Components...........................................................................................................................54
9.3 Main Error Codes, Possible Causes and Solutions............................................................................54
9.3.1 Blocked Flue...............................................................................................................................55
9.3.2 No Fuel.......................................................................................................................................56
9.3.3 Failed Ignition .............................................................................................................................58
9.3.4 Defective Igniter Fuse.................................................................................................................59
9.3.5 Auger Fuse.................................................................................................................................59
9.3.6 Unit Overheat..............................................................................................................................60
9.3.7 Hopper Lid Open ........................................................................................................................61
9.3.8 Power Loss.................................................................................................................................62
9.3.9 Smoke Smell...............................................................................................................................62
9.3.10 Combustion Air Starvation..........................................................................................................63
9.3.11 The LCD Touch Screen Does Not Lightup.................................................................................63
10 Wiring Diagram......................................................................................................................................64
11 Access to Fuses ....................................................................................................................................65
12 Components location............................................................................................................................67
13 Blower Replacement .............................................................................................................................68
14 L-250 and F-160 Thermal Switch Replacement..................................................................................74
15 Exploded View and Replacement Parts ..............................................................................................76
APPENDIX A: HORIZONTAL AND VERTICAL VENT CHART.....................................................................86
APPENDIX B: LCD SLIDING BRACKET .......................................................................................................88
APPENDIX C: FLAME CARACTERISTICS....................................................................................................90
APPENDIX D: INSTALLING A THERMOSTAT (AC05558)...........................................................................91

7000 Pellet Stove Installation and Operation Manual
_________________________________________________________________________________________________ 5
APPENDIX E: MOBILE HOME INSTALLATION............................................................................................94
APPENDIX F: COMBUSTION AIR SUPPLY..................................................................................................96
APPENDIX G: INSTALLING THE DOOR OVERLAY.....................................................................................99
APPENDIX H: OPTIONAL HOT AIR DISTRIBUTION KIT (AC01343) ........................................................100
OSBURN LIMITED LIFETIME WARRANTY.................................................................................................101

7000 Pellet Stove Installation and Operation Manual
6 _________________________________________________________________________________________________
1INTRODUCTION
1.1 ABOUT PELLET HEATING
Pellet stoves offer a dramatic improvement in the convenience of heating with solid fuel. Wood
pellets are handled in bags and are therefore easily and cleanly stored. A single loading of a pellet
stove can provide long hours of warmth. Pellet stoves also provide a special comfort associated with
wood burning. The combination of fans delivering warm air currents and the direct comfort of radiant
heat provides special satisfaction on a cold winter day. The heat provided is even and constant, due
to the auto fuel feed responding to owner settings. Pellet stoves also offer strong environmental
benefits; pellets not only reduce dependence on finite supplies of fossil fuels like oil and gas, but they
also put to good use materials that would otherwise unnecessarily and expensively add to our waste
disposal problems.
In addition, pellet stoves burn very cleanly and offer the lowest emissions of unwanted pollutants of
all solid fuel burning appliances.
1.1.1 TOP 10 REASONS FOR BUYING A PELLET STOVE
•Fuel is relatively cheap, easy tohandle and store
•Installation is relatively inexpensive and flexible
•Can be thermostatically controlled
•Can run for long hours without the need to refuel
•Heat output is steady because fuel feed is regulated
•Provides powerful convection heat
•Has the lowest emissions of all solid fuels
•Reduces our dependence on fossil fuels
•Pellets are a renewable fuel
•Wood pellets are made of 100% residual matter (saw dust). This creates added-value from
waste that would otherwise end up in a landfill.

7000 Pellet Stove Installation and Operation Manual
_________________________________________________________________________________________________ 7
1.2 7000 SPECIFICATIONS
Fuel Type Wood pellets
Test Standards (safety) ULC S627, ASTM E1509 and UL 1482
Heating capacity range* 1000 to 2800 sq. ft. (93 to 260 m2)
Input BTU range** From 10 500 BTU to 70 000 BTU
Hopper capacity** 125 lb (57 Kg)
EPA Status <2.5 g/h
Optimum efficiency 79.9 %
Maximum Burn Time* 92h
Shipping Weight 454 lb (206 kg)
Vent system size 4'' (see Section 4.3 Equivalent Vent Length (EVL))
Baffle material Stainless Steel
Burn rate** 1.2 lb to 8.2 lb per hour
Energy consumption 3.7A for ignition cycle
2.15A Min./2.9A Max. for continuous operation
Electrical requirements 120VAC 15A
Control board fuses Main: 7.5A-250V fast-blow fuse
Convection blower: 5A-250V fast-blow fuse
Combustion blower: 3A-250V fast-blow fuse
Exhaust blower: 3A-250V fast-blow fuse
Auger motor #1: 3A-250V fast-blow fuse
Auger motor #2: 3A-250V fast-blow fuse
Igniter: 5A-250V fast-blow fuse
* Burn time and heating capacity may vary subject to location in home, chimney draft, chimney
diameter, locality, heat loss factors, climate, selected fuel level, fuel types and other variables.
** This can vary depending on pellet density, length, and diameter.

7000 Pellet Stove Installation and Operation Manual
8 _________________________________________________________________________________________________
1.3 OVERALL EXTERIOR DIMENSIONS
A
FRESH AIR INLET
B
EXHAUST

7000 Pellet Stove Installation and Operation Manual
_________________________________________________________________________________________________ 9
PART A – INSTALLATION
2INSTALLATION SAFETY INFORMATION
2.1 INSTALLATION WARNINGS, CAUTIONS AND RECOMMENDATIONS
•PROFESSIONNAL INSTALLATION IS HIGHLY RECOMMENDED.
•YOU MAY NEED TO OBTAIN A BUILDING PERMIT FOR THE INSTALLATION OF THIS STOVE AND
ITS VENTING SYSTEM. CONSULT YOUR MUNICIPAL BUILDING DEPARTMENT OR FIRE
DEPARTMENT BEFORE INSTALLATION TO DETERMINE THE NEED TO OBTAIN ONE. WE
RECOMMEND THAT YOU ALSO INFORM YOUR HOME INSURANCE COMPANY TO FIND OUT IF
THE INSTALLATION WILL AFFECT YOUR POLICY.
•THIS STOVE MUST BE CONNECTED TO A STANDARD 120V. 60 HZ GROUNDED ELECTRICAL
OUTLET. DO NOT USE AN ADAPTER PLUG OR SEVER THE GROUNDING PLUG. DO NOT ROUTE
THE ELECTRICAL CORD UNDERNEATH, IN FRONT OR OVER THE STOVE.
•IF THIS STOVE IS NOT PROPERLY INSTALLED, A HOUSE FIRE MAY RESULT. TO REDUCE THE RISK
OF FIRE, FOLLOW THE INSTALLATION INSTRUCTIONS.
•BURNING ANY SOLID FUELS GENERATES CARBON MONOXIDE IN LOW CONCENTRATION. THIS
GAS IS EVACUATED BY THE VENTING SYSTEM. IN HIGHER CONCENTRATIONS, CARBON
MONOXIDE IS TOXIC AND MAY CAUSE DEATH. TO PREVENT THIS, ENSURE THAT YOUR VENTING
SYSTEM IS AIRTIGHT.
•THIS STOVE IS MOBILE HOME APPROVED AND REQUIRES INSTALLATION OF A FRESH AIR KIT,
SOLD SEPARATELY. THE STOVE MUST BE ATTACHED TO THE STRUCTURE OF THE MOBILE HOME
AND THE STRUCTURAL INTEGRITY OF THE MOBILE HOME FLOOR, WALL, AND CEILING/ROOF
MUST BE MAINTAINED. DO NOT INSTALL IN A SLEEPING ROOM.
•THIS STOVE IS NOT RECOMMENDED TO BE INSTALLED IN A BEDROOM.
•THIS STOVE HAS BEEN DEVELOPED AND BUILT FOR RESIDENTIAL SUPPLEMENTARY HEAT
SOURCE. COMMERCIAL AND INDUSTRIAL USE IS PROHIBITED AND WILL VOID THE WARRANTY.
•THE INFORMATION GIVEN ON THE CERTIFICATION LABEL AFFIXED TO THE STOVE ALWAYS
OVERRIDES THE INFORMATION PUBLISHED IN ANY OTHER MEDIA (OWNER’S MANUAL,
CATALOGUES, FLYERS, MAGAZINES AND/OR WEB SITES).
•CONNECT THIS STOVE ONLY TO A LISTED PELLET VENT FOR USE WITH SOLID FUEL OR TO A
LINED CHIMNEY CONFORMING TO NATIONAL AND LOCAL BUILDING CODES.
•DO NOT INSTALL A FLUE DAMPER IN THE EXHAUST VENTING SYSTEM OF THIS UNIT.

7000 Pellet Stove Installation and Operation Manual
10________________________________________________________________________________________________
•DO NOT CONNECT THIS STOVE TO ANY OTHER EXISTING VENTING SYSTEM SERVING ANOTHER
APPLIANCE.
•DO NOT CONNECT TO OR USE IN CONJUNCTION WITH ANY AIR DISTRIBUTION DUCTWORK.
•THE VENTING SYSTEM MUST BE COMPLETELY AIRTIGHT AND PROPERLY INSTALLED. ALL VENT
CONNECTOR JOINTS MUST BE SEALED AND FASTENED IN ACCORDANCE WITH THE PELLET VENT
MANUFACTURER'S INSTRUCTIONS TO ENSURE CONSISTENT PERFORMANCE AND AVOID SMOKE
AND ASH SPILLAGE.
•THE VENTING SYSTEM SHOULD BE CHECKED, AT LEAST TWICE A YEAR FOR ANY BUILDUP OF
SOOT OR CREOSOTE.
•NEVER BLOCK ANY LOUVERS OF THE STOVE.
•IF REQUIRED, A FRESH AIR KIT CAN BE INSTALLED TO SUPPLY COMBUSTION AIR TO THE ROOM
OR SPACE (SEE APPENDIX F: COMBUSTION AIR SUPPLY).
•MIXING OF APPLIANCE COMPONENTS FROM DIFFERENT SOURCES OR MODIFYING
COMPONENTS IS PROHIBITED AND WILL VOID THE WARRANTY.
•ANY MODIFICATION OF THE STOVE THAT HAS NOT BEEN APPROVED IN WRITING BY THE
TESTING AUTHORITY IS PROHIBITED AND VIOLATES CSA B365 (CANADA), AND ANSI NFPA 211
(USA).
•STOVE BUILDER INTERNATIONAL INC. (SBI) GRANTS NO WARRANTY, IMPLIED OR STATED, FOR
THE POOR INSTALLATION OR LACK OF MAINTENANCE OF YOUR STOVE AND ASSUMES NO
RESPONSIBILITY OF ANY CONSEQUENTIAL DAMAGES.

7000 Pellet Stove Installation and Operation Manual
________________________________________________________________________________________________ 11
2.2 REGULATIONS COVERING PELLET STOVE INSTALLATION
When installed and operated as described in these instructions, this pellet stove is suitable for use as
a freestanding heater in residential installations.
In Canada, the CSA B365 Installation Code for Solid Fuel Burning Appliances and Equipment and the
CSA C22.1 Canadian National Electrical Code are to be followed in the absence of local code
requirements. In the USA, the ANSI NFPA 211 Standard for Chimneys, Fireplaces, Vents and Solid
Fuel-Burning Appliances and the ANSI NFPA 70 National Electrical Code are to be followed in the
absence of local code requirements.
This stove must be connected to a pellet vent system complying with the requirements for Pellet
Vent in the standards UL 103, UL 641, ULC S629M, CAN/ULC S609 and ULC/ORD C441 or to a code-
approved masonry chimney with a stainless steel flue liner.
2.3 BEFORE OPERATING YOUR STOVE
Some minor installation and adjustment are required prior to use:
•If desired, LCD sliding support can be installed on the left at the back of the stove; (see Appendix
B: Repositioning the LCD Sliding Bracket).
•The handle and door must be adjusted; (see section 8.1.10 Door Adjustment)
•The stove must be leveled using threaded legs;
•The door overlay must be installed on the door frame as shown (see Appendix G: Installing the
Door Overlay).
•Make sure the fresh air intake back draft shutter works freely.
•Make sure to remove all tools or accessories that have been inserted in the stove for
transportation purposes (see following illustration.)

7000 Pellet Stove Installation and Operation Manual
12________________________________________________________________________________________________
A LCD AND SUPPORT
B POWER CORD
C OWNER’S MANUAL
D THERMOSTAT
E SCRAPER
F DESICCANT (drying
agent)
G SWEEPING BRUSH (the
tie wrap must be cut)
3CLEARANCES TO COMBUSTIBLE MATERIAL
The clearances shown in this section have been determined by tests according to procedures set out
in safety standards ULC S627 (Canada), ASTM E1509 (U.S.A). When the pellet stove is installed so that
its surfaces are at, or beyond, the minimum clearances specified, combustible surfaces will not
overheat under normal and even abnormal operating conditions.
WARNING: NO PART OF THE STOVE MAY BE LOCATED CLOSER TO COMBUSTIBLES THAN THE
MINIMUM CLEARANCES SPECIFIED ON THE CERTIFICATION LABEL.
CAUTION: NO PART OF THE PELLET VENT SYSTEM MAY BE LOCATED CLOSER TO COMBUSTIBLES
THAN THE MINIMUM CLEARANCES SPECIFIED BY THE VENT MANUFACTURER.
CAUTION
3.1 CERTIFICATION LABEL LOCATION
: DO NOT USE MAKESHIFT MATERIALS OR MAKE ANY COMPROMISES WHEN INSTALLING
THIS STOVE.
Since the information given on the certification label affixed to the stove always overrides the
information published in any other media (owner’s manual, catalogues, flyers, magazines and/or web
sites), it is important to refer to it in order to have a safe and compliant installation. In addition, you

7000 Pellet Stove Installation and Operation Manual
________________________________________________________________________________________________ 13
will find important information about your stove (model, serial number, etc.). You will find the
certification label on the inner side of the hopper lid of the stove.
3.2 MINIMUM CLEARANCES TO COMBUSTIBLES
LETTER CLEARANCES TOCOMBUSTIBLES
CANADA USA
A* 3″(76 mm) 3″(76 mm)
B 6″(152 mm) 6″(152 mm)
C 3″ (76 mm) 3″(76 mm)
D Refer to vent manufacturer’s
clearances
Refer to vent
manufacturer’s
clearances
I 72″ (1 829 mm) 72″ (1 829 mm)
Note
* From the fresh air intake
: We recommend leaving 24″ on each side of the stove and 12″ at the back of the stove in
order to facilitate access for maintenance.
3.3 BACK WALL INSTALLATION
For a back wall installation, in order to allow
the LCD sliding support to move freely and fully
extend, you should allow a minimum of 6″(152
mm) clearance from the side wall (B) and 3″(80
mm) clearance at the back of the stove, from
the fresh air intake (A). However, if you wish to
install the stove with minimum clearances (see
table in Section 3.2 Minimum Clearances to
Combustibles), it is possible to locate the LCD
touch screen elsewhere but within the
maximum length of the Telco wire provided.
You could also want to install the LCD sliding
support on the left side of the stove (see
Appendix B:
Repositioning the LCD Sliding
Bracket).

7000 Pellet Stove Installation and Operation Manual
14________________________________________________________________________________________________
3.4 CORNER INSTALLATION
For a corner installation, in order to allow the LCD sliding support to
move freely and fully extend, you should allow a minimum of 6¼''
(160 mm) clearance to the adjacent walls (C). However, if you wish to
install the stove with minimum clearances (see table in Section 3.2
Minimum Clearances to Combustibles), it is possible to locate the
LCD touch screen elsewhere but within the maximum length of the
Telco wire provided. You could also want to install the LCD sliding
support on the left side of the stove (see Appendix B: Repositioning
the LCD Sliding Bracket).
3.5 CEILING CLEARANCES
For ceiling clearances refer to the table in Section 3.2 Minimum
Clearances to Combustibles.
3.6 FLOOR PROTECTION
For floor protection clearances refer to the following table.
FLOOR PROTECTION
LE
TT
ER
CANADA USA
E 18″(460 mm) 6″(155 mm)
F N/A (USA only) 6″(155 mm)
G 8″(205 mm) N/A (Canada only)
H 8″(205 mm) N/A (Canada only)
CAUTION
*Any type of tile will require a continuous non combustible sheet beneath to prevent the possibility of
embers falling through to the combustible floor if cracks or separation should occur in the finished
surface, this would include floor protection for built-in raised hearths. Check local codes for approved
alternatives.
: THE STOVE MUST BE PLACED ON A CONTINUOUS (GROUTED JOINTS) NONCOMBUSTIBLE
MATERIAL SUCH AS CERAMIC TILE*, CEMENT BOARD, BRICK, MILLBOARD OR EQUIVALENT, OR ANY
OTHER APPROVED OR LISTED MATERIAL SUITED FOR FLOOR PROTECTION.

7000 Pellet Stove Installation and Operation Manual
________________________________________________________________________________________________ 15
4VENTING SYSTEM
4.1 GENERAL
Even though the chimney draft is mechanical, a suitable venting system will ensure a natural draft
which will prevent smoke spillage in your home if a power outage occurs. Moreover, a suitable
venting system configuration will help getting the best efficiency out of your stove when installed in
accordance with the required EVL (see Section 4.3 Equivalent Vent Length (EVL)).
Even the best stove will not function safely and efficiently as intended if it is not connected to a
suitable venting system.
4.2 RECOMMENDATIONS
In Canada, we recommend that you use a listed pellet vent that meets the CAN/ULC S609 or ULC/ORD
C441 Standard. A pellet vent listed to ULC S629M is also suitable for installation with this stove.
For the United States, we recommend that you use a listed pellet vent that meets the UL 641
Standard. A pellet vent listed to UL 103 is also suitable for installation with this stove.
This stove can be vented in an existing factory-built or masonry chimney with the addition of a
stainless steel liner, provided the chimney is more than 4” in diameter. The liner should be listed and
should meet the ULC S635 CAN/ULC S640 standard in Canada and the UL 1777 standard in the USA.
Refer to the instructions provided by the vent manufacturer, especially when passing through a wall,
ceiling or roof.
4.3 EQUIVALENT VENT LENGTH (EVL)
Recommended venting system inner pipe diameter is 4”.
To calculate the EVL of your installation, use the following conversions:
Qty Type of pipe EVL equivalent(ft)
1 90° elbow or “T” 5
1 45° elbow 3
1 ft Horizontal pipe run 1
1 ft Vertical pipe run 0.5

7000 Pellet Stove Installation and Operation Manual
16________________________________________________________________________________________________
NOTE: Horizontal runs shall not exceed 9 feet.
NOTE: Never exceed 30 feet of EVL.
Here is an example to help you calculate Equivalent Vent Length. On the following figure the EVL can
be calculated like this:
•2 horizontal run of 1’ = (2 X 1’) X 1’ = 2’ of EVL
•1 elbow 90° or "Tee" = 5’ of EVL
•3 vertical length of 4’ = (3 X 4’) X 0.5’ = 6’ of EVL
•Total EVL = (2’ + 5’ + 6’) = 13’.
NOTE: Do not include the exterior wall termination in the EVL calculation (45° elbow and
termination).
For example, let’s imagine an installation consisting of a horizontal
vent coming out at the back of the stove on a total distance of 8 feet.
This horizontal run is followed by a tee and a 6-foot vertical rise. This
type of installation is not acceptable. As you can see, the vent
termination is clearly outside the allowed configuration zone on the
chart because the venting system proposed does not have at least
one foot of vertical rise for each foot of horizontal run.

7000 Pellet Stove Installation and Operation Manual
________________________________________________________________________________________________ 17
Instead, if the installation consisted of a horizontal vent coming out
at the back of the stove on a total distance of 4 feet, followed by a
tee and a 6-foot vertical rise, it would be acceptable. The installation
end should be within the allowable configuration zone on the chart
since it would have at least one foot of vertical rise for each foot of
horizontal run. Furthermore, the total vertical rise would be at least
3-foot high.
WARNING: To reduce the risk of smoke spillage there should always
be at least one foot of vertical rise for each foot of horizontal run. In
all cases, at least 3 feet of vertical rise is needed.
4.4 TERMINATION LOCATION
Termination should not be located so that hot
exhaust gases can be a hazard. They can reach
temperatures of 500°F (260°C) and cause serious
burns.
CAUTION: TERMINATION COLLAR (SPARK
ARRESTER) IS MANDATORY.
4.4.1 PERMITTED TERMINATION LOCATION
Refer to NFPA 211 (USA) or CSA B365 (Canada) for rules for the distance of exit terminal from
windows and openings. The exit terminal of a mechanical draft system, other than a direct vent
appliance shall be located in accordance with the following.
O.K.

7000 Pellet Stove Installation and Operation Manual
18________________________________________________________________________________________________
Canada:
Letter Min. clearances Description
A 12’’ (30 cm) Clearances above grade level or any adjacent surface that might support
snow, ice, or debris
B 39’’ (100 cm) Clearance to window or door that may be opened
F 39’’ (100 cm) Clearance to corner or adjacent wall
H 39’’ (100 cm) Not to be installed above a meter/regulator assembly within 39" (100 cm) horizontally from the vertical center-line of the regulator and for 15’
vertically
I 72’’ (183 cm) Clearance to gas service regulator vent outlet or within 39’’ (100 cm) of an oil
tank vent or an oil tank fill inlet
J 39’’ (100 cm) Clearance to the combustion air inlet to any other appliance
K 72’’ (183 cm) Clearance to a mechanical air supply inlet
L 84’’ (213 cm) Clearance above paved side-walk or a paved driveway located on public
property
39’’ (100 cm) Clearance to property boundary
A vent shall not terminate underneath a veranda, porch, or deck

7000 Pellet Stove Installation and Operation Manual
________________________________________________________________________________________________ 19
United States:
•Not Less than 36’’ (91 cm) above any forced air inlet located within 10 feet (305 cm);
•Not Less than 48’’ (122 cm) below and horizontally from, or one foot (30 cm) above, any door,
window or gravity air inlet into any building;
•Not Less than 24’’ (61 cm) from an adjacent building and not less than 84’’ (213 cm) above grade
when located adjacent to a public walkway.
•Cannot be located less than 12 inches (300mm) above grade.
•Cannot be located above a gas meter/regulator within 3 feet (900mm) horizontally of the vertical
center line of the regulator.
•Not within 6 feet (1.8 meters) of a gas service regulator vent outlet.
•Other restrictions may apply. See NFPA 211 for further information.
4.5 INSTALLATION CONFIGURATIONS
4.5.1 INSTALLATION WARNINGS, CAUTIONS AND RECOMMENDATIONS REMINDER
•PROFESSIONNAL INSTALLATION IS HIGHLY RECOMMENDED
•THIS STOVE USES A PRESSURIZED VENTING SYSTEM. ALL VENT CONNECTOR JOINTS MUST BE
SEALED AND FASTENED. CONSULT THE PELLET VENT MANUFACTURER’S INSTRUCTION TO
ENSURE PROPER INSTALLATION, CONSISTENT PERFORMANCE, AND TO AVOID SMOKE AND ASH
SPILLAGE.
•USE RTV SILICONE (Room Temperature Vulcanisation), METALLIC TAPE, AND A MINIMUM OF
THREE SELF-TAPING SCREWS AT ALL JOINT CONNECTIONS TO ENSURE A TIGHT SEAL.
•THE CHIMNEY CONNECTOR SHALL NOT PASS THROUGH AN ATTIC OR ROOF SPACE, CLOSET OR
SIMILAR CONCEALED SPACE OR FLOORS OR CEILING.
•INSTALL VENTING SYSTEM AT CLEARANCES SPECIFIED BY THE VENT MANUFACTURER.
•THE USE OF A SPARK ARRESTER AT THE END OF THE TERMINATION IS MANDATORY.

7000 Pellet Stove Installation and Operation Manual
20________________________________________________________________________________________________
4.5.2 THROUGH WALL INSTALLATION (MAIN FLOOR OR BASEMENT)
1. Position stove following clearances given in Section 3, Clearances to Combustible Material and
following vent manufacturer’s instructions. Then locate the position of the exhaust pipe in the
wall.
2. Install wall thimble as per vent manufacturer’s instructions.
3. Attach enough piping length to go through the wall thimble and extend at least 6 inches beyond
the exterior wall.
4. Attach cap and seal outside wall thimbles with high temperature waterproof silicone sealant.
CAUTION: TO REDUCE THE RISK OF SMOKE SPILLAGE THERE SHOULD ALWAYS BE AT LEAST 12” (30
CM) OF VERTICAL RISE FOR EACH FOOT OF HORIZONTAL RUN. IN ALL CASES, AT LEAST 36” (91 CM)
OF VERTICAL RISE IS NEEDED BEFORE THE TERMINATION.
WARNING: TERMINATION SHOULD NOT BE LOCATED SO THAT HOT EXHAUST GASES CAN BE A
HAZARD. EXHAUST GASES CAN REACH TEMPERATURES OF 500°F (260°C) AND CAUSE SERIOUS
BURNS. SEE SECTION 4.4.1 PERMITTED TERMINATION LOCATION.
