Osburn 50 Series Technical specifications

29-10-2013
! !

Maintenance(50(Serie(
2
CAUTION
Before resetting your electronic
card that displays an error code.
OVERHEAT MESSAGE
•Service the stove COMPLETELY as described in this
manual.
•Check the chimney pipe.
BLOCKED FLUE MESSAGE
•Service the stove COMPLETELY as described in this
manual.
•Check the chimney pipe.
Check that the Pressure switch pipe is not blocked.
THIS STOVE IS EQUIPPED WITH MULTIPLE DEVICES TO ENSURE YOUR SAFETY. HOWEVER
IF A WARNING ERROR CODE STOPS YOUR STOVE ON SEVERAL OCCASIONS, THERE ARE
GREAT CHANCES THAT THE STOVE DOES NOT EXHAUST PROPERLY. YOU HAVE THE
RESPONSIBILITY TO MAKE SURE THAT THE MAINTENANCE OF THE STOVE IS DONE AS
DESCRIBED IN THIS DOCUMENT.

Maintenance(50(Serie(
3
MINIMUM RECOMMENDED MAINTENANCE SCHEDULE
Components
Weekly
Or after
+/- 250 pounds
Twice a year
Or after
+/- 1 tons
Annually
Or
Per 2 tons of pellets
Baffle
Vacuum
Bottom air-wash inlet
Vacuum
Burn Pot
Brush and Vacuum
Glass
Clean
Ash Drawer
Empty and Vacuum
Combustion Chamber
Vacuum
Vacuum and Brush
Heat Exchanger Tubes
Brush
Scrape and Vacuum
Exhaust Channels
(through access traps)
Vacuum
Exhaust Blower
Vacuum
Pressure switch tube
Clean
Combustion Blower
Inspect
Convection Blower
Vacuum
Venting System
Inspect and Sweep
Inspect and Sweep
Gaskets
Inspect
Hopper
Empty and Vacuum
THE MAINTENANCE SCHEDULE VARIES WITH THE
QUANTITY AND QUALITY OF PELLETS USED.
The user must be able to judge the frequency of maintenance depending on the dirtiness level
on the burn pot. A burn pot that is dirty will reduce the efficiency of the stove and may cause
problems.
!
!

Maintenance(50(Serie(
4
REMOVE THE BAFFLES.
Using the 4 tabs, remove and clean
the three compartments of the baffles
which are located inside the
combustion chamber. Use an ash
vacuum to clean between the heat
exchangers.
Remove the panels in the order
indicated in the pictures.
1. Center panel
2. Right side panel
3. Left side panel
1
3
2

Maintenance(50(Serie(
5
CLEANING THE BURN POT.
Using a scraper and a wire brush, thoroughly
clean the surface of the burn pot. It is very
important to leave no residue on the surface of
the burn pot.
Note: The sand and dirt contained in the wood
pellets does not burn and solidifies to form a
stone on the surface of the burn pot. This stone
is commonly called (clinker) in the pellet stove
industry.
If the (clinker) is not removed the combustion air
holes are blocked or reduced and this will also
reduce the efficiency of the stove and increases
the formation of (clinker) until the combustion
becomes almost impossible.
Release the clips on both sides of the burn pot,
and then remove the burn pot by lifting it. Make
sure the burn pot is clean and that the holes are
not blocked. Once the burn pot is removed,
clean inside the burn pot receptacle with an ash
vacuum to remove accumulated ash.
If necessary, clean the air inlet pipe. To achieve this, you must open the access door of the
ash drawer and remove the ash drawer. Then, loosen the wing nut to open the hatch. Vacuum
combustion residues. (Check that the seal of the access door is in good condition, otherwise
replace it.)
RECOMMENDED MAINTENANCE
WEEKLY

Maintenance(50(Serie(
6
CLEANING THE GLASS RETAINERS.
!
To keep the glass as clean
as possible.
It is important to vacuum the
glass retainers to keep the
airwash free of ash
accumulation.
CLEANING THE ASH DRAWER
!
!
To empty the ash drawer of
its contents, open the
access door by lifting the
latch using the removable
handle included.
(A support for hanging the
handle is located at the rear
of the stove, on the right
side).
!
!
Empty the ash drawer,
vacuum around the drawer
and the bottom of the
combustion chamber.
RECOMMENDED
MAINTENANCE
WEEKLY
WARNING: ASH DRAWER MUST BE IN PLACE AND ACCESS DOOR MUST BE KEPT
CLOSED WHEN THE UNIT IS ON.

Maintenance(50(Serie(
7
MAINTENANCE OF THE INNER
DUCTING.
The inner ducting and the exhaust fan are
located on the left side of the stove.
Here's how to perform the inspection and
cleaning.
REMOVE THE DUCTING ACCESS
COVER.
!!!!!!!!!! !
To access inner ducting, open the decorative
panels that are located on the left side of the
stove facing the stove. It is also possible to
remove the panels if necessary.
!
!!!!!! !
To remove the access covers, simply push and
turn the screw in the middle of the panel
counterclockwise with a Phillips or Robertson
screwdriver.

Maintenance(50(Serie(
8
VACUUM THE INNER DUCTING AND
BLOWER.
Clean and vacuum any ash buildup in the
inner ducting using the scraper provided
with the stove.
Also clean and vacuum the exhaust fan
housing outlet being careful not to
damage the fan blades.
It is very important to ensure that the
cover gasket is in good condition.
If the gasket is damaged it must be
replaced before using the stove.

Maintenance(50(Serie(
9
CLEANING THE PRESSURE SWITCH
TUBE.
!!!!!!!!!!!!!!!!!!!!!!! !
!
To access the pressure switch.
Open the right side decorative panel of
the stove.
The pressure switch is fixed to the back
grill.
!
!!!!!!!!!!!! !
!
The pressure switch is connected to the
exhaust fan with a rubber tube.
!
!!!!!!!!!!!!! !
Here is a view of the pressure switch
from behind the stove to easily
understand how it is installed.

Maintenance(50(Serie(
10
CLEANING THE PRESSURE SWITCH TUBE.
1. Remove the tube from the
pressure switch.
2. Blow into the tube and
ensure that the air passes
freely.
3. Reinstall the tube on the
pressure switch taking care
to connect the tube to the
WHITE side of the sensor.
RECOMMENDED
MAINTENANCE
2 TIMES PER SEASON
OR AFTER
1 TON OF PELLETS
!
1
2
3

Maintenance(50(Serie(
11
THIS PELLET STOVE IS EQUIPED WITH MULTIPLE DEVICES TO ENSURE YOUR SAFETY. HOWEVER
IF A WARNING ERROR CODE STOPS YOUR STOVE ON SEVERAL OCCASIONS, IT IS VERY LIKELY TO
BE THAT THE STOVE DOES NOT EXHAUST PROPERLY. YOU HAVE THE RESPONSIBILITY TO MAKE
SURE THAT THE MAINTENANCE OF THE STOVE IS DONE AS DESCRIBED IN THIS DOCUMENT.
Before resetting the PC-board that displays an error code.
Do FULL stove maintenance as described in this manual.
TO RESET AN OVERHEAT MESSAGE
OVERHEAT
MESSAGE
PRESS ON RESET
After 3 attempts, this reset is no longer possible
CAUTION
Overheat message after 3 reset
AFTER 3 OVERHEAT MESSAGES.
THERE ARE GREAT CHANCES THAT
THE STOVE DOES NOT EXHAUST
PROPERLY. TO REDUCE THE RISK
OF FIRE OR SMOKE DAMAGE IT IS
VERY IMPORTANT TO PERFORM
MAINTENANCE ON YOUR STOVE.
CAUTION
ONCE THE MAINTENANCE IS DONE FOLLOW THESE INSTRUCTIONS After 3
attempts press restart and then enter the following codes.
PRESS RESET ENTER 999-333-555 PRESS ACCEPT

Maintenance(50(Serie(
12
TO RESET ALL OTHER MESSAGES
After giving an error code message, your stove will
shut down by itself and begin a cooling cycle.
To RESTART your stove.
1. Press the RESET button.
2. Press the on/off button "ON / OFF” .
Note:
Your stove will restart when
the cooling cycle is completed.
SMOKE SMELL OR SOOT BUILD:
Because it is a solid fuel appliance, your pellet stove may emit odors of burnt wood. If these odors
reach an abnormal level or if soot accumulates on the walls and furniture, check your exhaust to
detect leakage. All joints should be in good condition and sealed. Clean your stove following the
instructions in this manual. Contact your dealer if the problem persists.
RESET
