OSD Audio AP525 User manual

Patio Speaker Manual
AP SERIES
Thank you for giving OSD AUDIO the chance to earn your business! We are condent you will nd that OSD oers an outstanding combination of performance
and value in everything we make. To ensure you get the most out of your new patio speakers, please take a moment to read this manual before you get started.
Installing Speakers
These weather resistant patio speakers are manufactured to resist a variety of weather condition. The most ideal place to install these speakers is the undersides
of most eaves and overhangs as they provide the best protection. Like all speakers, they sound the best when placed no more than seven feet apart from each
other, and slightly higher than ear level. If the speakers are more than seven feet apart, toe them in toward the center of the listening area.
These speakers are not waterproof and cannot be submerged under water.
Placing Speakers
If your application requires the speaker to be mounted, please follow these directions. Using the hardware supplied, mount the bracket rst. Attach the
speakers to the brackets using the large plastic knobs supplied.
Never mount a speaker on a wall made of unreinforced drywall or plasterboard.
If you are unsure,consult a professional contractor. (See Diagram 1)
Painting the grilles
The metal grilles may also be painted. Use very thin paint (5:1). It will be easier to paint the grilles while it is o the speaker. Avoid plugging up the holes with
excess paint. First remove the grille fom the speaker using spray paint lightly go over the front of the grille and then go over the back of the grille. Two coats
may be nessesary for desired look. The binding post speaker terminals on the speakers will accommodate up to 12-guage wire. When using 70V amplier
output, please select a power setting through the knob switch. When connecting the speakers, it is very important to observe the correct polarity. This means
that the wire attached to the (+), red, or positive terminals on one component must be attached to the (+), red, or positive terminal on the corresponding
component speaker output terminals. Similarly, the (-), Black, Negative or ground terminals must connect to the respective (-), Black, Negative, or ground
terminals. This is easy to do by locating the color stripes that appears on most wire.
Mounting
To install the bracket on the speaker. Screw the bracket knobs into the cabinet. Point the speaker toward the listening area. Once the direction of the
speaker has been determined tighten the bracket knobs securely. (See Diagram 2)
WIRING
Connect the speaker cable to the speaker cable terminals, matching the proper polarity with your amplier, + to + (red) and - to - (black). Make sure to
connect the right channel to the right speaker and the left channel to the left speaker . Either channel may be attached to either terminals set, however, be
sure that polarity ( + and - ) is correct on each channel or the performance of the speaker will be seriously aected as one channel will cancel out the other.
L/R Pair Speaker
70 Volts consideration
(Applicable to only 70V tap speakers)
The 70V transformer oers you the ability to
daisy chain multiple number of speakers in
series. In doing so, you would simply connect 1
pair of outputs to each speaker and daisy chain
to subsequential speaker/s. If you don’t intend
to daisy chain the speakers, set the default
setting to 8 ohms. (See Diagram 3)
Single - Stereo
AP850 / AP840 / AP670 / AP650 /
AP650T ( 70 ) /AP650TT /
AP640 / AP640T ( 70V )
AP525 / AP520T ( 70V )
AP490 / AP450
AP650TT
AP650TT
AP525

Warranty & Repair
All OSD AUDIO speaker products have (1) year LimitedWarranty against defects in materials and workmanship. Proof of purchase must accompany all claims.
During the warranty period OSD AUDIO will replace any defective part and correct any defect in workmanship without charge for either parts or labor.
OSD AUDIO may replace returned speakers with a product of equal value and performance. In such case, some modications to the mounting
may be necessary and are not OSD AUDIO’s responsibility.
For this warranty to apply, the unit must be installed and used according to its written instructions. If necessary, repairs must be performed by OSD AUDIO.
The unit must be returned to OSD AUDIO at the owner’s expense and with prior written permission. Accidental damage and shipping damage
are not considered defects, noris damaged resulting from abuse or from servicing performed by an agency or person not specically
authorized in writing by OSD AUDIO.
OSD AUDIO sells products only through authorized dealers and distributors to ensure that customers obtain proper support and service.
Any OSD AUDIO product purchased from an unauthorized dealer or other source, including retailers, mail over dealers and online sellers will not be
honored or serviced under existing OSDAUDIO warranty policy. Any sale of product by an unauthorized source or other manner not authorized by
OSD AUDIO shall void the warranty on the applicable product.
Damage to or destruction of components due to application of excessive power voids the warranty on those parts. In these cases, repairs will be made on the
basis of the retail value of the parts and labor. To return for repairs, you must email customer service at [email protected]om for a Returned Merchandise
Authorization (RMA) number # then the unit must be shipped to OSD AUDIO at the owner’s expense, along with a note explaining the nature of service
required. Be sure to pack the speaker(s) in a corrugated container with at least 3 inches of resilient material to protect the unit from damage in transit.
This Warranty Does Not Cover:
Damage caused by abuse, accident, misuse, negligence, or improper operation (installation) • Any products that have been altered or modied • Any product
whose identifying number of decal, serial #, etc. has been altered, defaced or removed • Normal wear and maintenance.
Specications
Patio Speakers
Patio Speakers
Patio Speakers
AP850 AP650AP670
AP520T (70V)
AP840
AP640 AP640T (70V)
AP450
AP490
AP650TT
AP525
Speaker Type:
Tweeter:
Woofer:
Impedance:
Sensitivity:
70V Tap: (optional)
Bass port:
Frequency Response:
Power Handing:
Dimensions: (H x W x D)
Unit of Measure:
Speaker Type:
Tweeter:
Woofer:
Impedance:
Sensitivity:
70V Tap: (optional)
Frequency Response:
Power Handing:
Dimensions: (H x W x D)
Unit of Measure:
Speaker Type:
Tweeter:
Woofer:
Impedance:
Sensitivity:
70V Tap: (optional)
Frequency Response:
Power Handing:
Dimensions: (H x W x D)
Unit of Measure:
8” Ultra Patio Speaker
2” Silk Dome
8” Polypropylene
8 
90dB
40W,30W,25W,20W
Yes
37Hz-22kHz
200 Watts
15” ⁄ x 11” x 10”
Pair
6 ⁄” Ultra Patio Speaker
1” Silk Dome
6 ⁄” Polypropylene
8 
90dB
N/A
Yes
37Hz-22kHz
150 Watts
11 ⁄ ” x 8 ⁄” x 7 ⁄”
Pair
6 ⁄” Ultra Patio Speaker
1” Silk Dome
6 ⁄”Waterproof Paper Cone
8 
90dB
N/A
Yes
44Hz-22kHz
120 Watts
14 ⁄ ” x 8 ⁄” x 7 ⁄”
Pair
5 ⁄”High Performance
Ultra Patio Speaker
¾” Silk Dome
5 ⁄” Polypropylene
8 
88dB
4W, 8W, 16W, 30W
50Hz-22kHz
120 Watts
9” ⁄ x 11⁄”x 6 ⁄”
Pair
8” High Performance
1” Silk Dome
8” Polypropylene
8 
90dB
N/A
Yes
30Hz-22kHz
200 Watts
14 ¾” x 11” x 9 ⁄”
Pair
6 ⁄” High Performance
Patio Speaker
1” Silk Dome
6 ⁄”Polypropylene
8 
89dB
4W, 8W, 16W, 30W
38Hz-20kHz
150 Watts
11 ” ⁄ x 8 ⁄” x 7 ⁄”
Pair
6 ⁄” High Performance
Patio Speaker
1” Silk Dome
6 ⁄”Polypropylene
8 
89dB
4W, 8W, 16W, 30W
38Hz-20kHz
150 Watts
11 ” ⁄ x 8 ⁄” x 7 ⁄”
Pair
4” Ultra Patio Speaker
⁄” Mylar Dome
4” Polypropylene
8 
90dB
N/A
58Hz-22kHz
100 Watts
7 ¾” x 5 ⁄” x 4 ⁄”
Pair
4” Ultra Patio Speaker
1” Silk Dome
4” Polypropylene
8 
88dB
N/A
60Hz-22kHz
100 Watts
9 ⁄ ” x 5 ⁄” x 5 ⁄”
Pair
6 ⁄” Single Stero Patio
Speaker
1” Silk Dome × 2
6 ⁄”Waterproof Paper Cone
8  x 2 (stereo) 16  (mono)
90dB
N/A
44Hz-22kHz
120 Watts
14 ” x 8” x 8”
Each
5 ⁄”High Performance
Patio Speaker
1” Silk Dome
5 ⁄” Polypropylene
8  x 2 (stereo) 16  (mono)
90dB
2.5W,5W,10W,15W, 20W
45Hz-22kHz
120 Watts
9 ⁄ ”x 7 ⁄” x 6 ⁄”
Pair
AP650T (70V)
6 ⁄” Ultra Patio Speaker
1” Silk Dome
6 ⁄” Polypropylene
8 
89dB
2.5W,5W,10W,15W
Yes
37Hz-22kHz
175 Watts
11 ⁄ ” x 8 ⁄” x 7 ⁄”
Pair
OSD AUDIO • 775 Columbia St • Brea • CA • 92821 • www.osdaudio.com • Tel [phone]
