Oster TSSTVDG01 Series User manual

User Manual Digital Countertop
Oven
Notice d’emploi Four posable
numérique
P.N. 171321 Rev. A
Visit us at www.oster.ca
Visitez au www.oster.ca
MODELS TSSTVDG01 Series/
MODÈLES de la série TSSTVDG01

English-2
IMPORTANT SAFEGUARDS
When using electrical appliances, basic safety precautions should always
be followed, including the following:
READ AND SAVE THESE
INSTRUCTIONS
• READ ALL INSTRUCTIONS, PRODUCT LABELS AND WARNINGS
BEFORE USING THE COUNTERTOP OVEN.
• Do not touch hot surfaces. Always use oven mitts when handling hot
materials and allow metal parts to cool before cleaning. Allow the unit to cool
thoroughly before putting in or taking off parts. Always use the oven handles
when moving the unit.
• When the unit is not in use and before cleaning, press the “Start/Cancel”
button and remove the countertop oven from the power outlet.
• To protect against risk of electrical shock, do not immerse the appliance in
water or any other liquids.
• Close supervision is always necessary when this or any appliance is used near
children. This appliance is not for use by children.
• Do not operate this or any appliance with a frayed or damaged cord or plug
or after the appliance malfunctions or is dropped or has been damaged in
any manner. Return the countertop oven to the nearest Authorized Sunbeam
Appliance Service Center for examination, repair or electrical or mechanical
adjustment.
• Do not use attachments not recommended by the manufacturer; they may
cause fire, electric shock or personal injury.
• Do not use outdoors or for commercial purposes.
• Do not use this appliance for other than its intended use.
• Do not let the cord dangle over the edge of a tabletop or countertop or touch
hot surfaces.
• Do not place the appliance near a hot gas or electric burner or in a heated
oven.
• Extreme caution should be used when using containers constructed of material
other than metal or glass.
• A fire may occur if the countertop oven is covered or touching flammable
materials, including curtains, draperies, walls, etc., when in operation. Do not
store any items on top of the appliance when in operation.
• When using countertop oven, pull the unit out a minimum of 6 inches away
from the wall or other cords.

English-3
• Do not store any materials, other than manufacturer’s recommended
accessories, in this unit when not in use.
• Do not place any flammable materials in oven, such as paper, cardboard,
plastic or any materials that may catch fire or melt.
• Do not cover the oven tray or rack with metal foil. This will cause overheating
of the appliance.
• Oversized foods or metal utensils must not be inserted in the appliance as they
may create a fire or risk of electrical shock.
• Do not clean with metal scouring pads. Pieces can break off the pad and touch
electrical parts involving a risk of electrical shock.
• Use extreme caution when removing pan or disposing of hot grease or other
hot liquids.
• To turn this appliance off, press the “Start/Cancel” button and remove cord
from outlet. The LCD will turn off after 30 seconds.
• This appliance has a polarized plug (one blade is wider than the other). To
reduce the risk of electric shock, this plug is intended to fit into a polarized
outlet only one way. If the plug does not fit fully into the outlet, reverse the
plug. If it still does not fit, contact a qualified electrician. Do not attempt to
modify the plug in any way.”
• Use extreme caution when removing tray or disposing of hot grease.
This Unit Is for Household Use Only
Short Power Supply Cord Instructions
A short power-supply cord is provided to reduce the risk resulting from
becoming entangled in or tripping over a longer cord. An extension cord
may be used if care is exercised in its use. If an extension cord is used, the
electrical rating of the cord must be at least as great as the electrical rating
of the appliance. The extension cord should be arranged so that it will not
drape over the countertop or tabletop where it can be pulled on by children
or tripped over unintentionally.
For Products Purchased in the United States and Canada Only
To reduce the risk of electrical shock, this appliance has a polarized plug (one
blade is wider than the other). This plug fits a polarized outlet only one way;
if the plug does not fit fully into the outlet, reverse the plug. If it still does not
fit, contact a qualified electrician. Do not attempt to defeat this safety feature.
SAVE THESE INSTRUCTIONS

English-4
PRODUCT DIAGRAM
1. LCD Display
2. Turbo Convection Heat Button – Use to activate or cancel
turbo convection heat.
3. Start/Cancel Button –Press this button to turn the appliance off.
4. Function Selector Knob – Select cooking function by turning knob
to desired setting.
5. Time/Temperature Control Knob – Adjust the dial thermostat to
the desired temperature/ Adjust the dial to the desired time
6. Removable Wire Rack – See “Positioning Rack” section.
7. Tempered Glass Door – For front viewing of food.
8. Two Rack Positions
9. Removable Crumb Tray – For crumb or fallen food particles collection.
Pulls out for easy cleaning.
10. Baking Pan/Cookie Sheet in One and Broil Rack – Use for all your baking
needs, broiling and grilling needs.
11. Easy Clean Interior Walls – Allows fast clean up.
1
8
10
4
5
2
3
9
67
11

English-5
ac
f
bd
e
LCD Display
a. Functions Indicator – Toast ( ), Bagel ( ), Pizza ( ), Bake ( ),
Broil ( ), Cookies ( ), Roast ( ), Warm ( ), Defrost ( ),
Reheat ( )
b. Function Indicator Arrow
c. 1-7 color shade setting indicator
d. Time Indicator
e. Turbo Convection Heat Icon
f. Temperature Indicator
Preparing Your Toaster Oven
If you are using your toaster oven for the first time, please:
• Remove any stickers from the surface of the oven.
• Open oven door and remove all printed documents and paper from
inside the toaster oven.
• Clean the rack and pan with hot water, a small amount of dishwashing
liquid and a nonabrasive sponge or cleaning pad.
DO NOT IMMERSE THE BODY OF THE UNIT IN WATER.
• Dry the unit thoroughly before using.
• Select a location for the toaster oven. The location should be in an open
area on a flat counter where the plug will reach an outlet.
• Plug the toaster oven into an electrical outlet.

English-6
USING YOUR TOASTER OVEN (SEE FIG. 1)
Plug the unit in. The unit will emit two long
“beeps” and the LCD screen will illuminate. The
function option will appear with an indicator on
the preset TOAST ( ) function. The LCD and the
Start/Cancel button light will be illuminated for
30 seconds and then go out if no other buttons or
knobs are pressed or moved.
PLEASE NOTE: once the blue LCD display goes
out – you can press or move any button or knob to
“wake up” the display and operate as normal.
Step 1. Select Function
Turn the Function Knob to choose one of
the following 10 options from the menu:
Toast ( ), Bagel ( ), Pizza ( ), Bake ( ),
Broil ( ), Cookies ( ), Roast ( ), Warm
( ), Defrost ( ) and Reheat ( ). The
indicator arrow will move from function to
function as the knob is turned.
NOTE: If the cooking process is not started or no
further button is pressed or knob is turned
within 30 seconds the blue backlight and
the Start/Cancel Button Light will turn off.
Step 2. Temperature:
Turn the temperature/time knob to increase
or decrease the temperature setting.
Step 3. Time:
Turn the temperature/time knob to
increase or decrease the cooking time. The
maximum time setting is 60 minutes.
NOTE: Press the temperature / time knob to toggle
between the tempertaure and time selction.
Figure 1

English-7
USING THE TOAST FUNCTION (SEE FIG. 2)
Step 1. Turn the Function Knob to the Toast ( )
function. When you select the Toast function,
the 1-7 color shade setting indicator will
become visible on the LCD. Both upper and
lower heating elements will heat.
Default Color Shade Setting is 4. This will
be the default every time the Toaster Oven
is unplugged and plugged back in. If the
Toaster Oven remains plugged in since
the last time you have selected a different
shade for the Toast function (even if not
activated), the unit will remember the last
shade setting you selected.
NOTE: The bottom rack position is recommended
for toasting.
The temperature or time is not adjustable
for the Toast function.
Step 2. To adjust the shade color:
Turn the Temperature/Time Knob to adjust
the shade color. The color shade-setting
indicator will show your selection as you turn
the knob. The frame around the shade setting
indicator on the LCD display will be blinking.
Step 3. To Start:
Press the Start/Cancel Button to start the
toasting process. The red Start/Cancel
Button light will illuminate. The LCD
Display will show the Toast Function, the
shade color selection and the countdown
time. The unit will begin to operate and the
timer will start counting down. (Step 3)
When the Toasting is complete, the unit
will emit 3 beeps. The LCD and the Start/
Cancel Button Light will turn off after 30
seconds.
NOTE: You can cancel the toasting cycle at any
time by pressing the Start/Cancel Button
once.
Figure 2

English-8
USING THE BAGEL FUNCTION (SEE FIG. 3)
Step 1. Turn the Function Knob to the Bagel ( )
function. When you select the Bagel function,
the 1-7 color shade setting indicator will
become visible on the LCD. Only upper
heating element will heat. Default Color
Shade Setting is 4. This will be the default
every time the Toaster Oven is unplugged
and plugged back on. If the Toaster Oven
remains plugged-in since the last time you
have selected a different shade for the Bagel
function (even if not activated), the unit
will remember the last shade setting you
selected.
NOTE: The bottom track position is recommended
for bagel toasting. For best results toast bagel
with cut side up.
The temperature or time is not adjustable
for the Bagel function once it has started.
Step 2. To adjust the shade color:
Turn the Temperature/Time Knob to adjust
the shade color. The color shade-setting
indicator will show your selection as you turn
the knob. The frame around the shade-setting
indicator on the LCD display will be blinking.
Step 3. To Start:
Press the Start/Cancel Button to start the
bagel toasting process. The red Start/Cancel
Button light will illuminate. The LCD
Display will show the Bagel Function, the
shade color selection and the countdown
time. The unit will begin to work and the
timer will start counting down.
When the Bagel toasting is complete, the
unit will emit 3 beeps. The LCD and the
Start/Cancel Button Light will turn off after
30 seconds.
NOTE: You can cancel the bagel toasting cycle
at any time by pressing the Start/Cancel
Button once.
Figure 3

English-9
USING THE PIZZA/ TURBO CONVECTION HEAT
FUNCTION (SEE FIG. 4)
Step 1. Turn the Function Knob to the Pizza
( ) function. When you select the Pizza
function, the Turbo Convection Heat will
automatically activate.
Step 2. If you wish to switch to the regular Pizza
function, press the Turbo button once to
turn off the Turbo Convection Heat default
selection. The blue light of the Turbo
Convection Heat button will turn off.
The Turbo Convection Heat Function turns
on a built-in fan that circulates hot air in
the oven chamber, cooking your food faster
and more evenly.
Default Temperature: 200ºC.
Default Time: 16 minutes.
Step 3. To set the temperature:
Turn the Temperature/Time Knob if
you wish to increase or decrease the
temperature setting. The frame around the
temperature setting on the LCD display
will be blinking. For the Pizza Function, the
temperature can be set from 170 to 230ºC
in 15-degree increments. Once you have
selected the desired temperature, press the
knob once to set that selection. The frame
of the temperature will disappear and the
frame of the time setting will start blinking.
Step 4. To set the time:
Turn the Temperature/Time Knob if you
wish to increase or decrease the cooking
time. The maximum time setting for Pizza
is 60 minutes (1 hour). Once you have
selected the desired cooking time, press the
Start button to initiate the cooking process.
The frame of the time will disappear.
Figure 4

English-10
Step 5. To Start:
Press the Start/Cancel Button to start the
cooking process. The red Start/Cancel
Button light will illuminate. The LCD
Display will show the Pizza Function,
the countdown time and the selected
temperature. The unit will begin to work
and the timer will start counting down.
When the Pizza function cycle is complete,
the unit will emit 3 beeps. The LCD and the
Start/Cancel Button Light will turn off after
30 seconds.
NOTE: You can cancel the cooking cycle at any
time by pressing the Start/Cancel Button
once.
USING THE BAKE/ TURBO CONVECTION HEAT
FUNCTION (SEE FIG. 5)
Step 1. Turn the Function Knob to the Bake
( ) function. When you select the Bake
function, the Turbo Convection Heat will
automatically activate.
Step 2. If you wish to switch to the regular Bake
function, press the Turbo button once to
turn off the Turbo Convection Heat. The
blue light of the Turbo Convection Heat
button will turn off.
The Turbo Convection Heat Function turns
on a built-in fan that circulates hot air in
the oven chamber, cooking your food faster
and more evenly.
Default Temperature: 165ºC.
Default Time: 30 minutes.
