OUKITEL B2000E User manual

Smart Battery Expansion
B2000E
User Manual • Uživatelský manuál •
Užívateľský manuál • Használati utasítás •
Benutzerhandbuch

2
English
3 –15
Čeština
16 –28
Slovenčina
29 –41
Magyar
42 –54
Deutsch
55 –68

3
Dear customer,
Thank you for purchasing our product. Please read the following instructions carefully
before first use and keep this user manual for future reference. Pay particular attention
to the safety instructions. If you have any questions or comments about the device,
please contact the customer line.
󹘯󹘰󹘱󹘲󹘳www.alza.co.uk/kontakt
✆[phone]
Importer Alza.cz a.s., Jankovcova 1522/53, Holešovice, 170 00 Praha 7, www.alza.cz

4
Specifications
Model
B2000E
Battery Type
LiFePO4
Capacity
2048Wh, 3.2V, 640000mAh (51.2V,
40000mAh)
Input
AC (XT60)
Adapter (200W)
Solar charging
(XT60)
12V –48V / 10A,
200W Max
Car charging
12V –8
24V –8.3A
Recharging with BP2000E / BP4000
Output
USB-A
5V –2.4A, 12W
USB-C
5V –3A / 9V –3A /
12V –3A / 15V –3A
/ 20V –5A
100W PD
Cigarette lighter
socket
12V –10A, 120W
XT90
48V –15A, 720W
MPPT Control System
Maximum power point tracking
Battery Life Cycles
3500
Discharging Temperature
-10°C –40°C (20°C - 30°C recommended)
Charging Temperature
0°C –40°C (20°C - 30°C recommended)
Dimensions
47.5 × 29.6 × 24.15 cm
Weight
18.6 kg

5
Packaging
1× Smart battery expansion
B200E
1× XT60 –Car charging
cable
1× XT60 –MC4 Solar
charging cable
1× Cable for parallel
connection
1× User’s manual

6
Diagram
1. LCD Display
2. 12V –10A, Cigarette lighter socker
3. 48V –15A, XT90 Output
4. 5V –2.4A, USB-A Output
5. PD100W, USB-C Output
6. DC Switch
7. Main power switch
8. 12V –48V, 10A max, 200W max, XT60 Input
9. First battery expansion port
10. Second battery expansion port
Power Functions and Charging Instructions
Main Power Switch
To operate the device, press the power button for 3 seconds to turn it on, and press it
again for 3 seconds to turn it off. Additionally, a short press on the switch controls the
activation or deactivation of the LCD display. If there's no activity for 30 minutes, the LCD
display will automatically turn off, and subsequently, the power will be switched off as
well.

7
DC Switch
1. Activation: Press and hold the main power switch for 3 seconds to power up the
station. Use a short press on the DC button to toggle the DC / USB output ports
on or off.
2. Battery Check: Regularly check the remaining battery power. If the battery level
drops below 10%, it's advised to recharge the battery promptly.
3. Power Output: Connect the device to the DC cigarette lighter socket with a 48V
XT90 Output. Notably, it's recommended to turn off the DC output switch when
the port is not in use to conserve power.
XT60 Input Port Recharging
AC Wall Outlet Charging
1. Plug the adapter into a wall outlet and connect the other side to the XT60 input
port for automatic charging, even when the main power is off. During charging,
the LCD screen will display the remaining power percentage, and the battery
indicator will blink. It will also provide details on XT60 input, input power, and the
estimated time for a full charge.
Solar Panel Charging
1. Place a compatible Solar Panel (not included) in direct sunlight and connect it (in
series or parallel) with an open circuit voltage range of 12V - 48V for charging. The
maximum input current for solar charging is 10A, with a max input power of
200W. If the input power exceeds 200W, it will cap at 200W. However, charging is
only possible within the 12V - 48V range. Ensure proper connection using an MC4
plug to the solar panel and XT60 to the input port for automatic charging, even
when the power is off. Similar to AC charging, the LCD screen will provide
charging details such as remaining power, input power, and estimated full charge
time.

8
Car Charging
1. Use the provided XT60-Car Charging Cable to connect the B2000E device to the
car's cigarette lighter port. During charging, the LCD screen will display details
regarding power input and the estimated time for a full charge.
BP2000E / BP4000+B2000E Smart Expansion Battery
1. For expanded charging options, connect the B2000E expansion battery with
BP2000E / BP4000, then connect them to a wall outlet. The maximum input
power for charging the B2000E / BP4000 and B2000E battery is 1800W. Use the
parallel cable to connect the Battery Expansion Port of BP2000E / BP4000 to the
Battery Expansion Port 1 of B2000E, then connect the Battery Expansion Port 2 of
B2000E to the Battery Expansion Port 1 of another B2000E. The LCD display will
showcase the remaining power and charging status during this process.

9
LCD Display
1. Remaining time for charge / discharge
2. High temperature warning
3. Low temperature warning
4. Power percentage indicator
5. XT60 input status
6. Cumulative input power
7. Total output power consumption
8. 48V XT90 output status
9. Cigarette lighter (12V) output indicator
10. Battery expansion symbol
11. Silent mode activation
12. Overload safeguard
13. USB-A output status
14. USB-C output status
15. Voltage protection mechanism
16. Current protection feature
17. Short circuit safety
18. Battery pack protection status
Discharging
Remaining
Input
Output
Mins
Hours
Overload

10
1. When the LCD screen displays it indicates correct connection between
BP2000E and B2000E.
2. If the B2000E is linked with the BP2000E and the LCD screen shows , it confirms
a proper BP2000E + B2000E connection, allowing for mutual recharging and
discharging capabilities.
Note:
•If the remaining power is below 5% when connecting the BP2000E with B2000E,
paralleling is not feasible due to significant battery voltage differences. However,
activating the input power source allows successful activation and recharging of
both the BP2000E and B2000E.
•Typically, after connecting the BP2000E and B2000E, the higher battery device will
autonomously charge the lower battery. Yet, if one device is below 5%, the
system identifies a substantial voltage gap, impeding a successful connection.
•In such cases, activating the input power source enables successful activation
and recharging of both the BP2000E and B2000E.
Enhancing Power Expansion with BP2000E / BP4000E
1. Multi-Battery Expansion: The BP2000E / BP4000 accommodates connection with
up to 7 expansion batteries, amplifying the total capacity to 16384Wh.
2. Unified Power Activation: Upon connecting the BP2000E / BP4000 with the
B2000E, a long press on either unit's main power button will simultaneously
power ON both devices.
3. Quick Power Toggle: A short press of the main power button turns off the LCD
screen and prompts the indicator to blink.
Guidelines for Connection
1. Prior to connecting the B2000E expansion battery, ensure both the BP2000E /
BP4000 and B2000E are powered off.
2. Verify the display of the parallel power icon on both the BP2000E/BP4000E and
B2000E screens after connecting the B2000E expansion battery before use.
3. Before connecting or disconnecting the B2000E expansion battery, first turn off
the B2000E.
4. Avoid direct contact between hands and the wire's metal terminal; use a dry cloth
for handling.
5. Ensure secure connections between the parallel wires and ports to prevent
terminal heat, potential device functionality issues, or fire hazards.

11
6. When charging the BP2000E / BP4000 + B2000E, connect the BP2000E / BP4000
to the wall outlet/solar panel for charging. Disconnect the B2000E before
rejoining it to the BP2000E / BP4000 if it was separately linked to the AC
adapter/solar/car charger.
BP2000E / BP4000+B2000E Expansion Battery
Pack
•Input Limitation: When utilized in this
configuration, the B2000E expansion battery
solely expands capacity and ceases charging
even when connected to the AC adapter or
solar/car charging board.
•Output Restriction: The 12V / 48V / USB
output ports on the B2000E expansion
battery remain inactive in this setup.
BP2000E / BP4000 Expansion Battery Pack
•The B2000E expansion battery A functions
normally for both input and output.
However, input and output for B2000E
expansion batteries B and C are halted in this
configuration, serving solely for capacity
expansion.

12
Troubleshooting
Error
Problem
Solution
The internal temperature
of the device is high.
Let the device sit and cool
before restarting.
Recommended
temperature 20°C - 30°C
The internal temperature
of the device is low.
Use the device in a normal
temperature environment.
Recommended
temperature 20°C - 30°C
Voltage protection.
Overvoltage has occurred
at the internal battery or
PV input.
Disconnect the input
terminal, check that the
voltage on the input
terminal is within the
allowable range, and then
reconnect.
Current protection. A BMS
charge/discharge
overcurrent has occurred.
Disconnect the input
terminal and turn off the
power, then reconnect it.
Disconnect the output
terminal, and turn on the
power, then reconnect it.
Short circuit protection. A
BMS failure has occurred.
Please contact customer
service at
[e-mail]
Battery pack protection. A
battery pack failure or
BMS communication error
has Occurred
Please contact customer
service at
[e-mail]
An error has occurred in
the output
Check the load of the
connected device. Check
the connection with the
output terminal.

13
Frequently Asked Questions
1. What causes the noise when in use? The noise may emanate from the fan or relay
during startup or operation.
2. Is it normal for the charging cable to heat up during use? Yes, it's normal. Our
charging cable adheres to national safety standards and has undergone certification.
3. How can I check the remaining discharge time? Refer to the LCD screen for the
remaining discharge time, displayed upon turning on the device.
4. How can I confirm if the product is charging? During charging, the product screen
will indicate the input wattage, accompanied by a blinking power percentage
indicator.
5. How should I clean the product? Gently wipe the product using a dry, soft, clean
cloth, or tissue.
6. What's the recommended storage method? Switch off the product and store it in
a dry environment, avoiding proximity to water. For long-term storage, it's advisable
to use the product every three months. Use up the remaining power, recharge to
your desired percentage (e.g., 50%), and store it accordingly.
Maintenance Guidelines
1. It is advised to use or store this product within an environment ranging from
20°C to 30°C. Keep it away from water, heat sources, and metallic objects.
2. For safety precautions, avoid storing this product in environments exceeding
45°C or dropping below -10°C for extended periods.
3. When not in use for an extended duration, charge the product to 60%. Prolonged
storage with a significantly depleted battery may cause irreparable damage and
reduce the product's lifespan.

14
Warranty Conditions
A new product purchased in the Alza.cz sales network is guaranteed for 2 years. If you
need repair or other services during the warranty period, contact the product seller
directly, you must provide the original proof of purchase with the date of purchase.
The following are considered to be a conflict with the warranty conditions, for
which the claimed claim may not be recognized:
•Using the product for any purpose other than that for which the product is intended
or failing to follow the instructions for maintenance, operation, and service of the
product.
•Damage to the product by a natural disaster, the intervention of an unauthorized
person or mechanically through the fault of the buyer (e.g., during transport,
cleaning by inappropriate means, etc.).
•Natural wear and aging of consumables or components during use (such as
batteries, etc.).
•Exposure to adverse external influences, such as sunlight and other radiation or
electromagnetic fields, fluid intrusion, object intrusion, mains overvoltage,
electrostatic discharge voltage (including lightning), faulty supply or input voltage and
inappropriate polarity of this voltage, chemical processes such as used power
supplies, etc.
•If anyone has made modifications, modifications, alterations to the design or
adaptation to change or extend the functions of the product compared to the
purchased design or use of non-original components.

15
EU Declaration of Conformity
This equipment is in compliance with the essential requirements and other relevant
provisions of Directive 2014/35/EU, 2014/30/EU and Directive 2011/65/EU amended (EU)
2015/863.
WEEE
This product must not be disposed of as normal household waste in accordance with
the EU Directive on Waste Electrical and Electronic Equipment (WEEE - 2012/19 / EU).
Instead, it shall be returned to the place of purchase or handed over to a public
collection point for the recyclable waste. By ensuring this product is disposed of
correctly, you will help prevent potential negative consequences for the environment
and human health, which could otherwise be caused by inappropriate waste handling of
this product. Contact your local authority or the nearest collection point for further
details. Improper disposal of this type of waste may result in fines in accordance with
national regulations.

16
Vážený zákazníku,
Děkujeme vám za zakoupení našeho produktu. Před prvním použitím si prosím pečlivě
přečtěte následující pokyny a uschovejte si tento návod k použití pro budoucí použití.
Zvláštní pozornost věnujte bezpečnostním pokynům. Pokud máte k přístroji jakékoli
dotazy nebo připomínky, obraťte se na zákaznickou linku.
󹘯󹘰󹘱󹘲󹘳www.alza.cz/kontakt
✆[phone]
Dovozce Alza.cz a.s., Jankovcova 1522/53, Holešovice, 170 00 Praha 7, www.alza.cz

17
Specifikace
Model
B2000E
Typ baterie
LiFePO4
Kapacita
2048 Wh, 3,2 V, 640000 mAh (51,2 V,
40000 mAh)
Vstup
STŘÍDAVÝ PROUD
(XT60)
Adaptér (200 W)
Solární nabíjení
(XT60)
12 V –48 V / 10 A,
max. 200 W
Nabíjení
automobilu
12 V - 8
24 V - 8,3 A
Dobíjení pomocí BP2000E / BP4000
Výstup
USB-A
5 V - 2,4 A, 12 W
USB-C
5 V –3 A / 9 V –3 A
/ 12 V –3 A / 15 V –
3 A / 20 V –5 A
100 W PD
Zásuvka zapalovače
cigaret
12 V –10 A, 120 W
XT90
48 V –15 A, 720 W
Řídicí systém MPPT
Sledování bodu maximálního výkonu
Cykly životnosti baterie
3500
Teplota vybíjení
-10 °C –40 °C (doporučeno 20 °C – 30 °C)
Teplota nabíjení
0 °C –40 °C (doporučeno 20 °C – 30 °C)
Rozměry
47,5 × 29,6 × 24,15 cm
Hmotnost
18,6 kg

18
Balení
1× rozšíření chytré baterie
B200E
1× XT60 - nabíjecí kabel
do auta
1× XT60 - MC4 Solární
nabíjecí kabel
1× kabel pro paralelní
připojení
1× uživatelská příručka

19
Schéma
1. LCD displej
2. 12 V –10 A, zásuvka zapalovače cigaret
3. 48 V –15 A, výstup XT90
4. 5 V - 2,4 A, výstup USB-A
5. PD100W, výstup USB-C
6. Spínač stejnosměrného proudu
7. Hlavní vypínač
8. 12 V –48 V, max. 10 A, max. 200 W, vstup XT60
9. První rozšiřující port baterie
10. Druhý rozšiřující port pro baterii
Funkce napájení a pokyny k nabíjení
Hlavní vypínač
Chcete-li zařízení ovládat, zapněte jej stisknutím tlačítka napájení na 3 sekundy a vypněte
jej opětovným stisknutím na 3 sekundy. Kromě toho krátkým stisknutím vypínače
ovládáte aktivaci nebo deaktivaci displeje LCD. Pokud po dobu 30 minut neprovedete
žádnou aktivitu, displej LCD se automaticky vypne a následně se vypne i napájení.

20
Spínač stejnosměrného proudu
1. Aktivace: Stiskněte a podržte hlavní vypínač po dobu 3 sekund, aby se stanice
zapnula. Krátkým stisknutím tlačítka DC zapnete nebo vypnete výstupní porty DC /
USB.
2. Kontrola baterie: Pravidelně kontrolujte zbývající energii baterie. Pokud úroveň
nabití baterie klesne pod 10 %, doporučujeme baterii neprodleně dobít.
3. Výstupní výkon: Připojte zařízení do stejnosměrné zásuvky zapalovače cigaret
s výstupem 48 V XT90. Zejména se doporučuje vypnout vypínač stejnosměrného
výstupu, když se port nepoužívá, aby se šetřila energie.
Dobíjení vstupního portu XT60
Nabíjení ze zásuvky střídavého proudu
1. Zapojte adaptér do zásuvky a druhou stranu připojte ke vstupnímu portu zařízení
XT60, aby se automaticky nabíjel, i když je hlavní napájení vypnuté. Během nabíjení
se na displeji LCD zobrazí zbývající procento energie a indikátor baterie bude blikat.
Rovněž bude poskytovat podrobné informace o vstupu XT60, vstupním výkonu a
odhadované době plného nabití.
