Induction plate IP1215R
User manual

Congratulations on your purchase induction plate OURSSON!

INTRODUCTION
3
The induction cooker works on the basis of an electromagnet that creates a powerful, high-frequency
electromagnetic field. When cookware consisting of magnetic material (e.g. iron) is placed on the
induction cooker, the electromagnetic field transfers energy to the bottom of the cookware, which
causes the cookware and the food inside it to become hot. The amount of heat generated in the
cookware is controlled by varying the strength of the electromagnetic field. When the strength of the
electromagnetic field is changed, the temperature of the cookware changes instantly.
Read this user manual carefully before you use the appliance and save it for future reference.
• Safe: the induction cooker does not make use of an open flame or fire. It also has a number of
safety features, which allow you to enjoy cooking with your family whenever you want.
• Fast: in induction cooker, the cookware serves as the heat source. This results is much faster
and more even heat transfer, shortening the cooking time by more than 1/3 compared to
conventional cooking.
• Versatile: the induction cooker has 2 preset cooking modes, each with its own optimal heating
pattern. These modes allow you to prepare a great variety of nutritious meals.
• Very user friendly: the simple and interactive control panel and display allow you to easily adjust
the settings at the touch of a button.
• Comfortable: the induction cooking process is smoke-free and produces less grease.
Moreover, the cooker and the surrounding area stay cool. This allows you to cook in a cool and
comfortable environment.
• Portable: the induction cooker has a compact design and the cooking plate stays cool. This
means the appliance is always safe to use and allows you to cook anywhere in your home.
• Never immerse the appliance in water or rinse
it under the tap.
• Do not cover any part of the cooking plate with
aluminium foil to prevent the risk of electric
shock, short circuiting or fire.
ADVANTAGES OF THE INDUCTION COOKER
DANGER
IMPORTANT

INTRODUCTION
4
• Check if the voltage indicated on the appliance
corresponds to the local mains voltage before you
connect the appliance.
• The temperature of accessible surfaces may be high
when the appliance operates.
• Only connect the appliance to an earthed wall socket.
Always make sure the plug is inserted firmly into the
socket.
• Do not use the appliance if the plug, the mains cord or
the appliance itself is damaged.
• If the mains cord is damaged, you must have it replaced
by Oursson, a service centre authorised by Oursson or
similarly qualified persons in order to avoid a hazard.
• If the surface of the cooking plate is cracked, switch off
the appliance and do not use it anymore to prevent the
risk of electric shock.
• This appliance is not intended for use by persons
(including children) with reduced physical, sensory or
mental capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction
concerning use of the appliance by a person responsible
for their safety.
• Children should be supervised to ensure that they do not
play with the appliance.
• Keep the mains cord out of the reach of children. Do not
let the mains cord hang over the edge of the table or
worktop on which the appliance stands.
• Make sure the cooking plate is clean and dry before you
switch on the appliance.
• Do not cover the air outlet while the induction cooker is
operating.
• Do not plug in the appliance or operate the control panel
with wet hands.
• Do not touch the cooking plate after cooking, as it retains
heat from the cookware.
• Metallic objects such as knives, forks, spoons and lids
should not be placed on the cooking plate since they can
get hot.
10A
220 В
WARNING

INTRODUCTION
5
• Never use any accessories or parts from other
manufacturers or that Oursson does not specifically
recommend. If you use such accessories or parts,
your guarantee becomes invalid.
• Do not expose the induction cooker to high
temperatures, hot gas, steam or damp heat. Do not
place the induction cooker on or near an operating or
still hot stove or cooker.
• Always switch off the appliance before you unplug it.
• Always unplug the appliance and let it cool down
before you clean it.
• This appliance is intended for indoor household
use only. If the appliance is used improperly or for
professional or semi-professional purposes or if it
is not used according to the instructions in the user
manual, the guarantee becomes invalid and Oursson
will not accept liability for any damage caused.
• Place the induction cooker on a stable, horizontal and
level surface and make sure there is at least 10cm
free space around it to prevent overheating.
• Do not operate the appliance on a plastic tablecloth.
• Do not place anything between the cookware and the
cooking plate.
• The maximum weight that can be put on the induction
cooker is 7kg.
• Beware of hot steam that comes out of the cookware
during cooking or when you remove the lid.
• Do not lift and move the induction cooker while it is
operating.
• Never put empty cookware on the switched-on
induction cooker, as this could cause the cookware
to become distorted or the heating coil to become
damaged.
• Do not store flammable materials and liquids near or
on the induction cooker.
• Avoid hard contact between the cookware or other
objects and the cooktop.
• Always place the cookware on the cooking zone
10A
10A
CAUTION
10A

INTRODUCTION
6
during cooking.
• Never connect this appliance to an external timer switch or remote control system in order to
avoid a hazardous situation.
• Do not use cookware with a bottom diameter of more than 16cm to deep-fry food, as this
causes the appliance to malfunction.
The appliance is equipped with automatic shut-off. It switches off automatically:
If there is no cookware or unsuitable cookware on the cooking plate when you press the start button
or if you remove cookware from the cooking plate during cooking, the cooker beeps continuously, the
display shows ‘----’. The cooker automatically switches off after 1 minute unless you put the cookware
back onto the cooking plate within this minute.
This Oursson appliance complies with all standards regarding electromagnetic fields (EMF). If
handled properly and according to the instructions in this user manual, the appliance is safe to use
based on scientific evidence available today.
Remove all packaging material from the induction cooker.
1. Place the appliance on a dry, stable and flat surface.
2. Make sure there is at least 10cm free space around the appliance to prevent overheating.
3. Always place the cookware on the cooking zone during cooking.
4. Make sure you use cookware of the correct type and size (see the tables below).
AUTOMATIC SHUT-OFF
ELECTROMAGNETIC FIELDS (EMF)
BEFORE FIRST USE
PREPARING FOR USE

INTRODUCTION
7
Tip: When you cook in the manual mode, you can use cookware with a bottom diameter of 12-20cm.
Tip: To deep-fry food, we advise you to use cookware with a bottom diameter of 12-16cm.
RECOMMENDED TYPES AND SIZES OF COOKWARE
ATTENTION! Use only the cookware suitable for induction plates.
Suitable cookware for the induction plates Cookware NOT suitable for the induction cooker
Cookware with a bottom made of iron or magnetic
stainless steel
Cookware with a bottom made of non-iron metal,
glass, aluminium and copper
Cookware with a flat bottom Cookware with a concave or convex bottom
Cookware with a bottom diameter of 12-20cm,
depending on the cooking mode(see tips below)
Cookware with a bottom diameter of less than 12cm
Cookware with a weight of up to 7kg (including
contents)
Cookware with a weight over 7kg (including
contents)

INTRODUCTION
8
Cooking zone
Cooktop
Air outlet
Main cord
Control panel
Rotate button
Air inlet
6
7
5
GENERAL DESCRIPTION
Pr
6
1
2
3
7
5
4

GENERAL DESCRIPTION
9
Power ON light
Mains switch ON/OFF
MODE button
CHILD LOCK light
and buttons
COOKING TIMER mode button
BOOST mode button
1
6
2
7
3
8
4
5
BOOST mode light
Timer mode light
Display
Power mode light
Temperature mode light
Preheating mode light
11
12
13
9
10
CONTROL PANEL
10 12 13 11
1
9
8
2 7 6 3 4 5

GENERAL DESCRIPTION
10
Only use cookware that is suitable for induction cooker (see chapter ‘Preparing for use’).
USING THE APPLIANCE
Compliance with the values of the levels of heating power and temperature
Temperature Heating power level
60°C 100 Watt
80°C 200 Watt
100°C 300 Watt
120°C 400 Watt
140°C 500 Watt
160°C 600 Watt
170°C 700 Watt
180°C 800 Watt
190°C 1000 Watt
200°C 1300 Watt
220°C 1600 Watt
240°C 2000 Watt
Note: Always place and use the appliance on a dry, stable and level surface.
Use this button to switch ON/OFF the main power of the induction plate.
Use this and buttons to adjust the heating power level or temperature, or to set the cooking
time.
Use this rotation button to adjust the heating power level or temperature, or to set the cooking time.
Use the power adjustment to set the heating power level or temperature.
Use BOOST button to cook with maximum heating power in any time.
Use this button to use COOKING TIMER mode.
Use this button to switch the induction plate between three modes:
• Power mode
• Temperature mode
• Preheating .

GENERAL DESCRIPTION
11
You can simply operate the appliance manually
You can simply operate the appliance manually
• Put the mains plug in the wall socket, the unit beeps during 2 second. «L» shows and blink
on the display. The induction plate goes to the stand-by mode.
• Touch the button to switch ON the induction plate, display shows «– – – –».
Tip: The induction plate automatically switch to the stand-by mode if you don’t press any buttons
during 1 minute. The unit will beep during 2-second.
• Place the cookware on the cooking zone
• Press the and buttons to set the heating power level.
• After setting heating power level the induction plate start to heat automatically.
• Touch the button to switch OFF the induction plate after you finish cooking. The induction
plate switch to the stand-by mode, display shows «L». After 1 minute the cooling fan will
switch off.
Tip: If no any cookware on the induction plate in a cooking mode, the induction plate don’t heating and
beep during 1 second. After 1 minute the induction plate automatically switch in to stand-by mode.
• Touch the and buttons to set the power level. During you touch buttons, the heating power
light goes on and the power level shows on display.
• Push on the rotation button. Rotate this button to left or to right to adjust the heating power level.
The heating power level shows on display. Push on the rotation button again to set the heating
power level.
USING THE DIFFERENT MODES
THE HEATING POWER LEVEL ADJUSTMENT
Any time you touch the buttons the induction plate beeps 1 second.
Note: Always place and use the appliance on a dry, stable and level surface.
You may use two ways to set and adjust the heating temperature:
THE TEMPERATURE ADJUSTMENT
• After switch ON the induction plate and setting the heating power level, touch the button
two times, to choose temperature mode. The induction plate beep 1 second and the display
shows the temperature and the temperature mode light goes on.
• Touch the and buttons to set the temperature. During you touch buttons, the display
shows temperature from 60°C to 240°C. Choose the temperature and the induction plate
automatically starts heating
• Use the rotate button by totation to left or to right to set and adjust temperature heating. The
display shows temperature from 60°C to 240°C. Choose the temperature and the induction
plate automatically starts heating

GENERAL DESCRIPTION
12
• Touch the button one time during the cooking mode, the cooking time light goes on. The
induction plate is in stand-by mode to set the cooking time. Set the cooking time by using the
and buttons or by using the rotation button. When you press the and buttons, the
time increases or decreases by 1 minute. When you press the buttons longer, the time increases or
decreases by 10 minutes. You may set the cooking time from 0 to 180 minutes. After you stop to set
the cooking time, the display shows preset cooking time. The countdown starts automatically.
• If you set preheat mode with cooking timer mode together, the display shows the settings of each
modes by rotation.
• After the cooking time finish countdown the induction plate stops heating and switch on to stand-by
mode.
• The default cooking time is 2 hours.
COOKING TIME SET MODE
• Preheat mode. After switch on the induction plate you should touch button 3 times to choose
the preheat mode. The preheat mode light goes on. The display shows temperature 60°C, heating
power level 100 Watt. These are default settings. Your induction plate is in preheat mode. You may stop
PREHEAT mode also by touch button.
THE SETTING AND USING PREHEAT MODE
Note: You may use BOOST mode during cooking after setting the heating power level.
• If you need the maximum level in any time during cooking, please touch the BOOST button one
time. The induction plate automatically switch to the maximum heating power level 2100 Watt, the
boost mode light goes on.
• To stop the BOOST mode, touch the BOOST button again one time, the boost mode light goes
OFF and the induction plate back to the preset heating power level.
• You may stop BOOST mode also by touch button.
BOOST MODE

GENERAL DESCRIPTION
13
Note: Unplug the appliance after use.
• Use this function to lock the control panel operation. Press the and buttons together for 2-3
seconds. Child lock indicator goes on. You may operate only by button, all other buttons are locked.
• To unlock the control panel press and buttons together for 2-3 seconds. Child lock indicator
goes off.
CHILD LOCK FUNCTION
CLEANING AND MAINTENANCE
STORAGE
Cleaning
Never immerse the appliance in water nor rinse it under the tap.
Never use scouring pads, abrasive cleaning agents or aggressive liquids such as petrol or acetone to
clean the appliance.
Do not put vinegar on the cooktop.
1. Unplug the appliance and let it cool down.
2. Clean the appliance with a damp cloth and if necessary, with some mild cleaning agent.
Do not place heavy objects on the cooktop as it is breakable.
Do not store the appliance in a hot place, for example near a cooker.
If you are not going to use the appliance for a longer period of time, we advise you to store the appliance
in a dry and safe place.
Maintenance
Improper use can lead to scratches on the cooking plate.
To avoid discolouring and scratches, use the appliance
according to the instructions in this user manual and always
clean the appliance and cookware properly after use.
10A

TROUBLESHOOTING
14
Problem/
Codes on the
display
Message Solution/What you should do
The power-on light does
not go on.
There is a connection problem.
• Check if the induction cooker is connected to the
mains and if the plug is inserted firmly into the wall
socket.
• Check if the power cord have no damaged.
The power on lights on
the panel goes on, but
the induction plate don’t
heating.
• Check if the using cookware are suitable for induction
plates.
• Check if the bottom size no less then 12cm.
• Take the appliance to your Oursson dealer or a
service centre authorised by Oursson.
The induction plate stops
heating during cooking
mode.
• Check if the air outlet do not cover while the induction
cooker is operating.
• Check if the cooking timer is finished countdown.
• Automatic protection system of induction plate switch
on. Disconnect the power cord from the wall socket.
Wait a few minutes, connect the power cord into the
wall socket, touch button.
• Take the appliance to your Oursson dealer or a
service centre authorised by Oursson.
If your induction cooker does not function properly or if the cooking quality is insufficient, consult the
table below. If you are unable to solve the problem, contact a Oursson service centre or the Customer
Care Centre in your country.

TROUBLESHOOTING
15
Problem/
Codes on the
display
Message Solution/What you should do
Е3; Е6 The induction plate inside
parts are over heated.
• Automatic protection system of induction plate switch
on. Disconnect the power cord from the wall socket.
Wait a few minutes, connect the power cord into the
wall socket, touch button.
• Check if the air outlet do not cover while the
induction cooker is operating.
• Take the appliance to your Oursson dealer or a
service centre authorised by Oursson.
E7; E8 Unstable voltage in power
supply network
• Check if the voltage in your home is suitable for the
induction cooker
Е1; Е2; Е4; Е5;
Еb; EC
• Take the appliance to your Oursson dealer or a
service centre authorised by Oursson.

OTHER
16
Technical specification
Model name IP1215R
Power consumption, Watt 2000
Voltage ~ 220 V; 50 Hz
Protection class I
The storage and delivering temperature from –25°C till +35°C
Operation temperature from +5°C till +35°C
Air humidity 15-75%
Net weight 2,8 kg
Dimensions, mm 370х300х62

www.oursson.com
