Outback Jupiter RS4491H User manual

Assembly and Operating Instructions for
Outback® Jupiter 4 Gas/Charcoal Hybrid
Photographs are not to scale.
Specifications subject to change
without prior notice.
WARNING
FOR YOUR SAFETY
If you smell gas:
1. Shut off gas to the appliance.
2. Extinguish any open flame.
3. Open barbecue lid or hood.
4. If odour continues, discontinue use and contact
your local dealer.
FOR YOUR SAFETY
1. Do not store or use petrol or other flammable
vapours or liquids in the vicinity of this or any
other appliance.
2. A gas bottle not connected for use shall not be
stored in the vicinity of this or any other
appliance.
RS4491H
 For outdoor use only. Not for commercial use.
 Read instructions before using the appliance. Failure to follow instructions could
result in death, serious bodily injury, and/or property loss.
 Warning: accessible parts may be very hot. Keep young children and pets away.
 Do not move the appliance during use.
 Turn off the gas supply at the gas bottle after use.
 Any modification of the appliance, misuse, or failure to follow the instructions
may be dangerous and will invalidate your warranty. This does not affect your
statutory rights.
 Retain these instructions for future reference.
 Leak test annually, and whenever the gas bottle is removed or replaced. Check
that the hose connections are tight and leak test each time you reconnect the
gas bottle.
 For Flare-up control please refer to the 'OPERATION' section of this manual.
2575 0359

2
CODE PART QTY Jupiter 4 Gas/
Charcoal Hybrid
HOOD
A1 Hood (Pre-Assembled to Body)1
A2 Hood Handle 1
A3 Heat Indicator 1
A4 Warming Rack 1
BODY
B1 Barbecue Body 1
B2 Burner 4
B3 Control Panel 1
B4 Knob 4
B5 Side Burner Valve, Hose and Regulator Assembly 1
B6 Flame Tamer 4
B7 Round Grill 1
B8 Cooking Grill 2
B9 Drip Tray 1
B10 Charcoal Basket 1
TROLLEY
C1 Side Burner Shelf 1
C2 Side Burner Shelf Panel 1
C3 Side Shelf 1
C4 Side Shelf Panel 1
C5 Tool Hook 3
C6 Side Burner Grid 1
C7 Knob Bezel 1
C8 Side Burner Knob 1
C9 Side Burner 1
C10 Left Cabinet Panel 1
C11 Right Cabinet Panel 1
C12 Upper Support 1
C13 Door Handle 2
C14 Left Door 1
C15 Right Door 1
C16 Rear Panel 2
C17 Bottom Panel 1
C18 Front Wheel Skirt 1
C19 Clapboard 1
C20 Caster 2
C21 Lockable Caster 2
C22 Hook Rail 1
C23 Chopping Board 1
HARDWARE
D1 M6x35 Bolt 8
D2 ST4.0x10 Screw 21 
D3 M6x15 Bolt 23 
D4 M6 Nut 12 
D5 M4x10 Bolt 3
D6 M5x10 Bolt 2
 Pre-Assembled Component
Parts List
Quantity varies according to model purchased. Specifications subject to change without prior notice. For
more details on hardware, please see the corresponding ‗Hardware Reference Diagram‘.

3
Parts Diagram
Quantity varies according to model purchased. Specifications subject to change without prior notice. For
more details on hardware, please see the corresponding ‗Hardware Reference Diagram‘.
A2
B2
B4
B9
C16
C13
C14 C15
B3
A1
C3
B5
C20
C21
C12
C4
C11
C10
C1
C6
C2
C8
C7
A3
C5
C17
C18
A4
B1
B6
B8
B7
C9
C19
B10
C23
C22

4
Hardware Reference Diagram
Specifications subject to change without prior notice.
D1
D2
D5
D3
D6
D4
M6X35 BOLT 8PCS
ST4.0X10 SCREW 21PCS
M6X15 BOLT 23PCS
M6 NUT 12PCS
M4X10 BOLT 3PCS
M5X10 BOLT 2PCS

5
Assembly
IMPORTANT!
 TOOLS NEEDED FOR ASSEMBLY: Medium size flat blade or Phillips/Crosspoint screwdriver,
adjustable spanner or metric spanner set.
 Remove any internal component or packaging from the barbecue body.
 Whilst every care is taken in the manufacture of this product, care must be taken during assembly in
case sharp edges are present.
 Please read the Important Information section carefully before assembly and use of your
barbecue.
1
2
Attach the Left Cabinet Panel (C10) and Right Cabinet Panel (C11) to the Bottom Panel (C17)
using M6x35 Bolts (D1x8pcs) and M6 Nuts (D4x8pcs), ST4.0x10 Screws (D2x6pcs) as shown.
Attach the Front Wheel Skirt (C18) onto the bottom panel using M6x15 Bolts (D3x3pcs)
as shown.
C18
D3
C17
D2
C10 C11
D1 D4
C17

6
Attach the Rear Panels (C16x2pcs) to the cabinet assembly using ST4.0x10 Screws
(D2x11pcs) as shown.
3
4
C16
Attach the Upper Support (C12) to the left/right cabinet panel using M6x15 Bolts (D3x4pcs).
D2
C16
C12
D3
D3

7
6
Remove the retaining bolts from one Door Handle (C13), and then attach the door
handle onto the Left Door (C14) using the retaining bolts as shown. Repeat above
process to install the other door handle onto the Right Door (C15).
Carefully turn the cabinet upside-down.
Attach the Casters (C20x2pcs) and Lockable Casters (C21x2pcs) onto the left/right
cabinet panels as shown. Ensure the lockable casters are installed on the rear side.
C21
C21
C20
C20
5
C13
C14

8
7
8
Carefully place the Barbecue Body (B1) onto the cabinet assembly and fix it using
M6x15 Bolts (D3x4pcs) as shown.
Fit the doors to the cabinet by depressing the spring pins and placing into the cabinet.
B1
D3
D3

9
Attach the side shelf assembly to the barbecue body using ST4.0x10 Screws (D2x2pcs) and
M6x15 Bolts (D3x4pcs) as shown.
9
10
Attach Side Shelf Panel (C4) onto Side Shelf (C3) using M6x15 Bolts (D3x2pcs) and M6 Nuts
(D4x2pcs) as shown.
D3
D2
step1
step2
step4
step3
C3
C4
D3
D4
D3
D4

10
11
12
Attach Side Burner Shelf Panel (C2) onto Side Burner Shelf (C1) using M6x15 Bolts (D3x2pcs)
and M6 Nuts (D4x2pcs) as shown.
Attach the side burner shelf assembly to the barbecue body using ST4.0x10 Screws (D2x2pcs)
and M6x15 Bolts (D3x4pcs) as shown.
C1
C2
D3
D4
D3
D4
step4
D3
step3
D2
step1
step2
