Ovente MFW85 Series User manual

Before use, please read this manual thoroughly and save for future reference.
ovente.com
MFW85 series
Wall Mount
MIRROR
with DIFFUSED LED RING Light
-
Available in three elegant finishes:
BRUSHED, ANTIQUE BRONZE and CHROME

ovente.com
MFW85 series
Wall Mount
MIRROR
with DIFFUSED LED RING Light
-

ovente.com
TABLE OF CONTENTS
4
5
6
9
Important safeguards
Parts & features
Using your mirror
Care & maintenance
..........
..........
..........
..........
Wall-Mount Mirror with Diffused led Ring Light
mfw85 series

4ovente.com
IMPORTANT SAFEGUARDS
Whenusingyourmirror,basicsafetyprecautionsshouldalwaysbefollowed,including
：
Provide close supervision when the mirror is being used near
children.
Never operate mirror if it is not working properly,has been
dropped,damaged,or submerged in water.
Do not use outdoors.
Do not disassemble the mirror.Do not attempt to remove,alter
or replace the permanent LED light.
Never operate where aerosol (spray)products are being used,
or where oxygen is administered.
Be sure the mirror is not in a position where it can reflect
sunlight.Reflected sunlight can cause a fire.
Always switch the mirror off after use and unplug before storing.
NOTE:When you are farther from the mirror,the image
is inverted.As you get closer,the image flips to the
actual virtual image in magnification standard.This is
due to the concavity of the mirror.
MAGNIFICATION EFFECT
Higher Magnification 1x

5ovente.com
PARTS & FEATURES
DISTORTION-FREE MIRROR
No reflection warps or bends
BATTERY COMPARTMENT
Battery operated
NATURAL WHITE LED LIGHTS
Long-lasting and energy-efficient lightbulbs
360° ROTATION MECHANISM
Allows you to adjust the mirror at any angle you want
EXTENDING ARM
Smoothly extends and folds
8.5-INCH ROUND MIRROR
Ideal size for your daily grooming routines
DIFFUSED RING LIGHT
Illuminates light that's close to natural light

6ovente.com
USING your mirror
INSTALLATION
Remove the wall-mount bracket from the mirror base.Screws
for the front of the base are pre-fastened for your conve�
nience.
Use the wall-mount bracket and a level to mark two dots on
the wall directly across from each other (you can also use
other parts of the bracket to secure to wall.Scan QR code for
video on how to make sure your mirror is properly secured).
Remove the wall-mount bracket and drill two holes into the
wall where you marked in Step 2(13/64 drill bit recommended).
Hammer gently with the back of the screwdriver the two wall
anchors (plastic pieces)into the now-drilled holes.
Secure wall-mount bracket to the wall by finding the wall
anchors behind the wall-mount bracket and drilling two
screws into the wall anchors.
Place mirror mount onto the pre-fastened screws and hold in
place.To secure,place plastic washers on bolts before
fastening lug nuts.
1
2
3
4
5
6

7ovente.com
USING your mirror
BATTERY REPLACEMENT
Before attempting to replace the batteries,turn off the switch.
Turn mirror to its higher magnification.
Hold mirror facing you,then twist counterclockwise.
Pull the mirror frame out.
Open the battery compartment and put in four batteries.All four batteries must be present
and properly positioned for the mirror to operate.Refer to Images 1and 2.
Close the battery compartment.
Put the mirror frame back and make sure the 3side dimples are aligned on the groove.
Press the mirror frame down.
Turn right (clockwise)to close.
1
2
3
4
5
6
7
8
9

8ovente.com
USING your mirror
NOTE:Batteries are not included in the package.
NOTE: It is recommended to always use high-quality lithium batteries to maintain
the mirror's maximum performance.
CAre or disposal of LITHIUM batteries
Use only fresh batteries of the required type and size.
Do not mix old and new batteries,different types of batteries,or rechargeable
batteries of different capacities.
Depleted batteries are to be removed from the item.
Dispose of the old batteries properly and according to your local regulations.

9ovente.com
care & maintenance
TECHNICAL SPECIFICATIONS
Make sure that LED lights are off before cleaning.
Use a soft,wet cloth to remove dirt and stains.Wipe with a dry cloth afterward.
To protect the mirror from dust simply store it in its original box.Store out of
reach of children in a safe,dry location.
Model:MFW85
Battery Operated

ovente.com
MFW85 series
Wall Mount
MIRROR
with DIFFUSED LED RING Light
-
