OVER-EAR Joe OE500L User manual

WWW.OVER-EAR.COM
What’s in the box
Headphones
Joe
Professional Wireless
Headphones
Falcon Donkey Parakeet
BobHarry
WWW.OVER-EAR.COM
Make the most of
your Joe...
Joe is compatible with a wide range of OVER-EAR
products including transmitters and different
receivers. Mix the products you need to create your
perfect system.
Compatible with:
Ned
234CHANGE CHANNELS
Slide channel switch to
your desired Channel.
1CHARGE UP
Ensure Joe is fully
charged (plug in to
USB socket, charge
for up to 2.5 hours).
Joe setup...
START AUDIO
Set up transmitter
with music playing
(see separate product
instructions).
SWITCH ON
Slide the switch on
to turn headphone
on, LED light will
illuminate.

MEET JOE TECHNICAL
SPECIFICATION
SAFETY
INSTRUCTIONS
DO DON’T
TROUBLE
SHOOTING
NO AUDIO / MUSIC?
Check your music playing device is
working, connected correctly, playing
music with volume turned up full.
Try a different device and audio cable.
Ensure receivers/ headphones are
switched on, connected to correct
channel and have volume up.
SIGNAL CUTS OUT, INTERFERENCE
OR REDUCED RANGE?
Ensure there is no interference caused
by other wireless equipment in the vicinity.
If using 2 or more transmitters
simultaneously make sure each is on
different channels (frequencies). You
cannot use 2 transmitters on the same
channel in the same place ever. They will
cancel each other out, resulting in little
or no signal.
NO POWER?
Check the headphones are fully charged
and switched on.
1. Channel selection
Slide the channel switch to select/ change
channels.
Toggle between 1-3
2. Power Switch
Slide the power switch to turn
headphone on/off.
3. Power socket
Insert charge cable to recharge.
4. LED Indicator
IN USE
LED illuminates when headphone is on
(colour depends on channel selected).
CHARGING
[Power off] - LED illuminates red
while charging, LED goes turns green
when fully charged.
[Power on] - LED illuminates red . LED turns
green when fully charged.
5. Folding hinge
Use to fold headphones when they are not
in use.
6. Volume
Use + or - to adjust audio input volume.
• Switch off and disconnect equipment from
mains before cleaning.
• Do not repair or replace parts for any products.
• Do not use equipment if damaged by water,
heat, physical impact etc.
• Do not use or store equipment in or near water,
moist or hot environments.
• Keep away from radiators and heat generating
electrical equipment such as screens and amps.
• Use only the supplied power cable and
accessories with your product.
• Disconnect from power after charging and
especially when not being used for long periods
of time. Overcharging headphones can cause
damage to the battery.
• Ensure that power connection is plugged in
properly - not damaged, working within a
comfortable temperature & not exposed to direct
sunlight.
• Do not overload wall sockets.
• Failure to comply with safety guidelines can
result in electrical shock, fire, damage to
equipment and invalidate your warranty.
• If in doubt please contact dealer or
manufacturer.
Do use headphones and
systems at comfortable
and safe listening levels.
Do gently clean
equipment between
uses and users. Hygienic
wipes and ear pad covers
are available from your
supplier.
Do feel free to expand
your system. Mix and
match with a variety of
OVER-EAR transmitters,
headphones and
receivers.
Do call, email or visit us
for help and advice.
HOW TO FOLD
Fold headphone
cup in towards
the band.
Fold back out
when you want
to use.
Don’t use 2 or more
transmitters on the same
channel - they won’t
work.
Don’t use equipment
near other wireless
apparatus including radio
mics, transmitters etc.
Frequencies can interfere
and result in distorted or
no signal.
Don’t attempt to repair
or modify equipment
yourself. This
could seriously harm
somebody.
Don’t use headphones
for extended periods of
time.
Model Number OE500L
Dimensions: 19cm (21.5cm extended)
Weight: 220g
Sound: Stereo
Frequency
Response 30-20,000Hz
Channel
Separation: >40dB
System: UHF/ RF
Modulation: FM
S/N Ratio: >75db
Connections: 5v (NK01)
Power Source: 420mAh
3.7v Lithium Battery
Charge Voltage: 5v
Charge Current: 200mA
Charge Time: 3 hours
Battery Life: 17 hours
Noise Reduction: Yes
Speaker: Advanced 40mm
Impedance: 32 ohm
Power Saving: N/A
Operational
Distance:
>300m (optimum)
Frequencies: Custom i.e. 433MHz/
863MHz/ 915MHz etc
LED Colour Typical Frequency
UK, EU & ROW USA
Red 863.7MHz 924.5MHz
Green 864.9MHz 925.6MHz
Blue 863.1MHz 923.8MHz
Please note frequencies and other specifications
may be changed without notice.
If in doubt please confirm with supplier.
2.
1.
3.
4.
5.
6.
7.
NEED HELP?
Feel free to drop us a line at:
[e-mail]
