Over Ometer User manual

Version: 1.1

OMETER

METER AND CONTROLLER

16 DRY CONTACT INPUTS

8 POWER OUTPUTS

SINGLE-PHASE POWER LINES 230VAC 50HZ

EDS BUS COMMUNICATION

STANDARD 9-WAY DIN-RAIL MOUNT

Device for measuring energy consumption (active and reactive), for single-phase lines (230Vac 50Hz) able to

control the electrical power status of connected loads such as lights, sockets, shutters, timed lights, etc. The

device has 16 programmable digital inputs to which buttons, switches, sensors or alarms are possible to

connect. These inputs can be useful for controlling the on/off status of the power outputs of the same

OMeter or any other device connected to the same BUS.

Manual version 1.1

2Version: 1.1

MODEL OMeter

PRODUCT CODE OMB

CERTIFICATIONS RoHS, CE

SIZE 159x90x58mm - 9 DIN modules

WEIGHT 490g

POWER SUPPLY 13,8÷15Vdc from EDS Bus

CURRENT DRAW max 350mA, average 100mA

BUS COMMUNICATION EDS (supply voltage 13,8÷15Vdc)

N° OUTPUT 8 power output

MEASURE ACCURACY ±1%

SINGLE OUTPUT BLOCK MAX CURRENT 300A*40 ms

DISSIPATED POWER FOR SINGLE POWER OUTPUT 5W at 16A

SINGLE BLOCK MAXIMUM LOAD POWER 3,5kW (cosφ=1)

TOTAL BOARD POWER 12kW (cosφ=1)

ELECTRIC POWER DISTRIBUTION ALLOWED 230Vac with neutral

N° INPUT 16 dry inputs

MAXIMUM CONTACT LENGTH 100m (wire size = 1,5mm)

OPERATING TEMPERATURE min -10°C

max +60°C

WAREHOUSING TEMPERATURE min -40°C

max +80°C

DATA SHEET

EDS BUS SPECIFICATIONS

MAXIMUM BUS

LENGTH

1200m linear

over the whole system

BUS TOPOLOGY Star, series or

promiscuous

BUS LENGTH <10m <30m <100m >100m

RECOMMENDED

MINIMUM SECTION

0,50

mm²

0,75

mm²

1,5

mm²

2,5

mm²

1,5mm² is recommended for implants, a value which however depends on the location of the modules

Version: 1.1

ELECTRICAL DIAGRAM

INSTALLATION INSTRUCTIONS

SAFETY

In order to maintain these conditions and ensure safe use, the user must follow the indications and markings contained in the following instructions.

Warning: Failure to follow the instructions below can result in death.

• Upon receipt of the instrument, before proceeding with the installation, check that it is intact and has not been damaged during

transport.

• Check that the operating voltage and the mains voltage coincide and then proceed with the installation.

• The instrument power supply must not be grounded.

• The instrument does not have a fuse to protect the power supply, so it must be protected by the installer.

• Maintenance and/or repair operations must be carried out only by qualied and authorized personnel.

• If you suspect that the tool is no longer secure, take it out of service and make sure it is not used inadvertently.

• Dangerous voltages can be present on voltage and current transformers. Follow standard safety precautions before performing

any installation or service activity.

• The instrument and its connections must be properly protected.

• The instrument must be installed following all local regulations.

Precautions: Failure to follow the instructions below can cause persistent damage to the instrument.

• The digital outputs and inputs are low voltage and cannot be connected to external power sources.

4Version: 1.1

EXAMPLE OF CONNECTION

BASIC INSTRUCTIONS

• You can control the power outputs by assigning

them to designated inputs programmed by the

software embedded in the OBox device.

• When the OMeter starts, the relays are closed.

However, the outputs can be programmed so that

they revert to their last state when restarted. Note

that in any case, when the control unit is restarted,

all the relays remain temporarily closed (for about

3 seconds). When the OMeter is not powered, the

relays will remain closed.

WARRANTY

This product is guaranteed against any material and manufacturing defects according to the period established by law from the date of purchase, even if

the product has not been installed. The warranty period starts from the moment of purchase. The buyer must report any defects in the delivered products

in writing to Over S.p.A.: the communication must contain a description of the reasons for defects and/or discrepancies, also indicating the serial

number, the delivery date, the delivery number and date of the transport document or invoice.

The Supplier’s warranty does not extend to products that are defective and/or damaged due to natural attrition or breakdown caused by improper use

or an operating procedure not contemplated in this manual, of negligence, or are tampered with or repaired by third parties or accidentally damaged

caused by atmospheric agents, or rmware updates.

The warranty intervention by the Supplier remains subject to the Buyer’s compliance with the payment conditions as well as the technical evaluation of

the existence of the warranty conditions veried by Over S.p.A. During the warranty period, Over S.p.A. undertakes to repair or replace, free of charge,

those products that have manufacturing defects or bad quality at its headquarters.

RETURN AND REPAIR PROCEDURE

All returned products must be returned in the same condition in which they were supplied at the Buyer’s expense, to the headquarters of Over S.p.A. in

Viale Piemonte 37 - 20093 Cologno Monzese (MI) and packed by the Buyer in order to avoid damages for which the Buyer himself would be responsible.

No return of goods will be accepted in the absence of authorization by Over S.p.A. to the Buyer.

No refund, even if authorized, will be accepted if the information regarding quantity, type of device returned and reason for return is not included in the

transport document or the accompanying letter.

Products not covered by the warranty will be returned to the Buyer at his own expense and charged to him for the costs incurred, after quantication and

communication, for the control and further testing and calibration of the same.

The replaced parts remain the property of Over S.p.A.

DECLARATION OF CONFORMITY
