OWI AMPLV602B Quick start guide

OWI Inc. * 17141 Kingsview Ave. Carson, CA 90746 USA * Tel. [phone] * [email protected] * www.owi-inc.com
INSTALLATION INSTRUCTIONS
AMPLV602B & AMPLV602W
1) When mounting speakers, use the mounting bracket as a template for marking and drilling three holes.
2) Assemble mounting screws, spring washers, flat washers and nuts to attach mounting brackets to mounting
surface. Note that:- Screws, washers and nuts provided are for mounting the cabinet from both sides of the
mounting location. For any other type of mounting, please consult your local hardware store for appropriate
mounting screws.
3) Follow installation directions included with your amplifier (or receiver). Strip 1/2" (12mm) of insulation
from each of the two conductors of the wire to expose the bare metal and twist each into a single strand.
[Connect the speaker wire to the terminals using the (+) as RED and the (-) as the BLACK].
4) Adjust position of the speaker to obtain the desired sound dispersion.
PARTS INCLUDED:
Mounting bracket 2 each
Bracket knob 4 each
Mounting screw 4 each
Flat washer 4 each
Speakers 2 each

OWI Incorporated * 17141 Kingsview Ave. Carson, CA 90746-1207 USA * Tel [phone] * Fax [phone]
www.owi-inc.com * [e-mail]
Speaker wire
Amplified Speaker Non-amplified Speaker
* 6.5” Mica Cone Rubber Edge Woofer
* 0.79” (20mm) PEI Dome Tweeter
* RMS Output Power : 2x15 Watts
* Frequency Response : 80 Hz - 20 kHz
AMPLV602B
AMPLV602W
2-way, Plastic Vented Box Design
with built-in amplifier
LINE OUT
AMPLV602 P602
Model - AMPLV602
POWERED SPEAKER
VOLUME
TREBLE
MIDRANGE
BASS
POWER
INPUT
MONO STEREO
AUDIO
INPUT
AUDIO
OUTPUT
L R
PAGE MUTE
UNMUTE
DELAY
30 SEC 300 SEC
POWER
SWITCH
WIRING INSTRUCTION
SPECIFICATIONS
PUBLIC ADDRESS RADIO, AUDIO, DVD, VCD, LD
IN
OUT
Model AMPLV602B & AMPLV602W
LOW VOLTAGE SURFACE MOUNT AMPLIFIED SPEAKER COMBINATION
