Owlet Home J1 User manual

1. Speakers
3. LED indicator
1. Power by DC5V adapter
2. Power by PC’s USB Port
2. Reset button
4. USB power port
The chime can be powered by an USB compatible phone
charger (DC5V 1A). You can also plug the chime to the USB
port on your PC/notebook to supply power.
1. Meet the chime
2. Power up device
1
2
3
4
Back
Front
(Not included)
(Not included)
2
2

3. Pair with Doorbell
Preparations
1. Configure Wi-Fi for the doorbell and add it to APP device list.
2. Supply power to the Chime.
3. Place the doorbell close to the Chime before pairing.
Pairing steps
1. Tap on “ ··· ” and enter into Settings , select Wireless Chime . Tap
on the icon to go to the pairing page.
Picture.1 Picture.2 Picture.3
Picture.6
Picture.5
Picture.4
Chime Pairing
Please ring the chime for your doorbell
1. Press bell button, status blue
light blinking and start
configuration
2.Press button Start configuration
3.Blue light solid on, configuration
succeeded
Pair
Unbind
HD
Wireless Chime
Chime Reminder
song1
song2
song3
song4
Ring Volume
Set up the indoor Wireless bell type,ring
options and the volumes to remind the
people who is indoor.
High
Settings
ppsldbbf91ebd5fd4a11
SN
Receive Notifications
Share
Host Leaves Message
Cloud Storage Service
Network Information
SD Card
Alarm Setting
Speaker Volume
Night Vision
Wireless Chime
Power management
Version
2.4.2.20190422
Automatic
70
2.Short click on the reset
button behind the chime,
and the LED indicator
falshes blue, indicating the
device is in pairing mode.
3. Tap “Pair” in the APP,
and the doorbell will send a
pairing signal to the chime.
Pairing succeeds and the
indicator on the Chime will
be in solid blue. Then you
can push the doorbell
button to test the result.
3
3

3. Specification
Note: The doorbells and indoor chimes support “one-to-many” and
“many-to-one” wireless connection.
1. Press and hold reset button on the chime for about 5 seconds till
the indicator flashes blue twice. It will restore to factory default.
2. You can also tap on “unbond” (See to picture 6) in the APP to
release the connection between doorbells and wireless chimes.
Unbond
Technical Specification
Power Input
Power port
Ringtones
Volume
Volume control
Consumption
Frequency
Connection type
Place of use
Working temp.
DC5V 1A
USB
4 ringtons
Max. 100dB
Low(mute), Middle, High
0.2W
866 MHz
indoor only
-30°C ~ 70°C
Radio frequency
Humidity
Size
Weight
＜90% （No condensation ）
�60 × 24mm
33g
LED indicator Flashing blue: pairing mode
Solid blue: power on/ pairing succeed
Flashes blue twice: reset to factory done
4
4
