OXE 125 User manual

USER MANUAL
OXE 125/150/175/200 HP

“THE OXE POWER HEAD IS A WELL PROVEN DIESEL
ENGINE INHERENTLY MORE EFFICIENT THAN GASOLINE
ENGINES CONTRIBUTING TO LOW FUEL CONSUMPTION”
INTRODUCTION

Overview
3
INTRODUCTION
Publication No: ODM1005/B
Maintenance Operating
Technical data

55
CONTENT
Overview___________________ 1
About this manual ___________ 1
Safety information ___________ 2
Symbols and signs _________ 2
Rotating parts_____________ 2
Hot parts_________________ 2
Electric parts _____________ 2
Engine shut-off switch
and cord _________________ 2
Engine exhaust emissions ___ 3
Modifications________________ 3
Accessories ______________ 3
Safe boating ________________ 3
Boater’s responsibilities_____ 3
Boat horse power capacity __ 3
Boat performance capacity __ 3
Warning and information labels_ 4
Main components ____________ 6
Instrumentation _____________ 8
control head ________________ 8
Control head operation________ 9
Control lamp______________ 9
Indicator dimming feature ___ 9
Neutral indicator lamp ______ 9
Control head range________ 10
Neutral Throttle Warmup___ 10
Low Speed Control ________ 11
Trolling Mode ____________ 11
Adjustable lever feel ______ 12
Outboard Installation ________ 13
Mounting the outboard _______ 14
Mounting height __________ 14
Engine connector _________ 15
Connecting the battery_____ 15
Engine kill-cord __________ 16
Breaking in the engine _______ 16
Break in procedure _______ 16
Operating _________________ 18
Before start-up _____________ 18
Checking the fuel level _____ 18
Filling fuel_______________ 18
Controls ________________ 18
Outboard________________ 18
Check engine oil, hydraulic oil
and belt oils _____________ 19
Check fluid level in power trim
and tilt unit ______________ 21
Starting the outboard ________ 22
Prestart checks __________ 22
Warming up the engine ____ 23
Shiing _________________ 24
Stopping the engine _______ 24
Power trim operation ________ 25
Adjusting the trim angle____ 25
Adjusting the boat trim ____ 26
Bow up _________________ 26
Bow down_______________ 27
Technical data Maintenance Operating Overview
Overview
Operating
Maintenance
Technical data

Power tilt operation _________ 27
Procedure for tilting up ____ 28
Procedure for tilting down __ 28
Power trim and tilt switch on
engine cowling ___________ 28
Maintenance_______________ 29
Outboard care ______________ 29
Owners responsibility________ 29
Transporting the outboard ____ 29
Cleaning the outboard _______ 30
Flushing the power unit ____ 31
Storing the outboard_________ 32
Winterization of the outboard 32
Checking and other
maintenance _______________ 34
Check air intake system____ 34
Check air filter ___________ 34
Check engine for oil leakage 34
Check drive belts _________ 34
Check battery ____________ 34
Check electric system _____ 34
Check fuel system ________ 35
Evacuating air from
fuel system______________ 35
Check cooling system _____ 36
Check water intake________ 37
Check coolant level and
mixture _________________ 37
Check power trim and tilt
system _________________ 38
Check propeller __________ 39
Check the top cowling _____ 40
Check cowling sealing _____ 40
Check painted surfaces ____ 40
Inspect anodes ___________ 41
Change fluids and filters ______43
Prevention of environmental
damage_________________ 43
Drain the fuel filter ________ 44
Replace fuel filter element __ 44
Replace hydraulic oil and filter45
Refill hydraulic oil _________ 45
Clean seawater strainer____ 46
Replace air filter __________ 46
Change engine oil_________ 47
Replace engine oil filter ____ 47
Filling up engine oil _______ 48
Change lower belt oil ______ 48
Change coolant___________ 49
Replace thermostat _______ 51
Replace propeller ___________ 52
Lubricating and greasing _____ 54
Power trim and tilt unit ____ 54
Maintenance schedule_______ 55
OXE Engine Fault codes ______ 63
OXE Controls Fault Code list ___ 68
Trouble shooting ___________ 69
Technical data _____________ 70
OXE125/150/175/200 hp ______ 70
Recommended fluids
and grease ________________ 71
Diesel fuel _________________ 72
Engine Oil viscosity__________ 73

1
OVERVIEW
ABOUT THIS MANUAL
This manual provides you with the
information you need to know about
starting, operating and maintaining
your OXE Diesel engine.
Read this manual carefully and
learn how to operate your outboard
properly. Always contact your dealer
if you have any questions.
Using and attending the engine
properly will preserve its qualities
for a long operating life. Follow
the instructions in this manual on
operating this engine and carry
out inspections as described on a
regular basis.
Cimco Marine AB
Metallgatan 17B
SE-262 72 Ängelholm, Sweden
[phone]
[email protected]
Technical data Maintenance Operating Overview

2
OVERVIEW
SAFETY INFORMATION
Do note remove or replace the top
cover with the engine running.
Hot parts
!DANGER
During and aer operation, engine
parts could be hot enough to
cause burns. Do not touch any
parts under the top cover until the
engine has cooled off.
Electric parts
!DANGER
Do not touch any electrical parts
while starting the engine. They
can cause shock or electrocution.
Engine shut-off switch and cord
!DANGER
The purpose of a lanyard stop
switch is to stop the engine when
the operator moves far enough
away from the operator’s position
to activate the switch.
Attach the engine shut-off cord
so that the engine stops if the
operator falls overboard or leaves
the helm.
When activating the engine
shut-off switch the engine will
stop immediately, but the boat
will continue to coast for some
distance depending on velocity
and degree of any turn at shut
down.
Safety and operating information
that is practiced, along with good
common sense, can help prevent
personal injury and product damage.
Symbols and signs
!DANGER
This indicates a hazardous
situation which, if not avoided,
will result in death or serious
injury.
!WARNING
This indicates a hazardous
situation which, if not avoided,
could result in death or serious
injury.
!CAUTION
This indicates a hazardous
situation which, if not avoided,
could result in minor or moderate
injury.
NOTE! Important information
Rotating parts
!DANGER
Rotating parts can cause cuts,
mutilation or strangulation.
Hands, feet, hair, jewelry,
clothing, PFD-straps, etc. can
become entangled with internal
rotating parts of the engine or
exposed moving parts.

3
Engine exhaust emissions
!WARNING
Inhaling engine exhaust gases
can result in carbon monoxide
poisoning, which can lead to
unconsciousness, brain damages,
or death. Avoid exposure to
carbon monoxide gas.
Stay clear from exhaust areas
when the engine is running. Keep
the boat well ventilated.
MODIFICATIONS
!WARNING
Do not attempt to modify the
outboard. Modifications may
reduce safety and reliability, and
render the outboard unsafe or
illegal to use.
Accessories
Genuine Cimco Marine parts and
accessories have been specifically
designed and tested for OXE
outboards.
Some accessories, not
manufactured or sold by Cimco
Marine, may not be designed to be
safely used with OXE outboards or
OXE outboard operating system.
Acquire and read the Installation,
Operation, Maintenance and
Accessories manuals for all selected
accessories.
SAFE BOATING
Boater’s responsibilities
It is always the operator (driver) that
is responsible for the correct and
safe operation of the boat and the
safety of its occupants and general
public. We strongly recommended
that each operator reads and
understands the entire manual
before operating the outboard.
Be sure that at least one additional
person onboard is instructed in the
basics of starting and operating the
outboard and boat handling in case
the driver is unable to operate the
boat.
Boat horse power capacity
Exceeding the boat’s maximum
power rating can cause serious
injury or death. Any overpowering of
the boat can affect boat control and
flotation characteristics or break the
transom.
Do not install an outboard that
exceeds the boat’s maximum power
and weight rating.
Boat performance capacity
Do not overpower or overload
your boat. Most boats will carry a
required capacity plate indicating
the maximum acceptable power
and load as determined by
the manufacturer. If in doubt,
contact your dealer or the boat
manufacturer.
Technical data Maintenance Operating Overview

4
OVERVIEW
Label Information Location
Heat warning label
30-0300-003
Warning for hot
surfaces, which could
result in burns.
1. Placed on the turbo
pressure pipe.
2. Placed on the lower part
of the intercooler, near
the primary belt housing.
Rotation warning label
WARNING
Keep hands, hair, and clothing away from
rotating parts while the engine is running.
30-0300-004CIMCO MARINE AB
Warning for rotating
parts.
1. Placed on the lower
timing belt cover, on
engine front.
2. Placed next to the upper
belt housing.
Electrical warning label
WARNING
Do not touch or remove electrical parts when
starting the engine or during operation.
30-0300-005CIMCO MARINE AB
Warning for electrical
hazards. Placed on the ECU-bracket.
Read manual label 1
30-0300-009CIMCO MARINE AB
A reminder of the
importance to read
manuals prior to the
initial use of equipment
or machinery. The
manual contains
information needed
for proper operation,
maintenance and care.
Placed on the upper
cowling, next to the trim and
tilt button.
Read manual label 2
WARNING
Do not touch or remove electrical parts when
starting the engine or during operation.
30-0300-005CIMCO MARINE AB
Placed on top of the timing
belt cover.
WARNING AND INFORMATION LABELS

5
Label Information Location
Read manual label 3
WARNING!
Locate and read operator’s
guide, follow all instructions
and warnings.
AVERTISSEMENT!
Localiser et lire le guide de
l’opèrateur. Suivre tous les
consignes et avertissements.
WARNUNG!
Betreibsanleitung ausfindig
machen und lesen. Alle
Anweisungen und
Warnhinweise befolgen.
¡ADVERTENCIA!
Ubicar y leer la guía del
operador. Atenerse a todas
las instrucciones y mensajes
de advertencia.
30-0300-007CIMCO MARINE AB
EN
FR
ES
DE
A reminder of the
importance to read
manuals prior to the
initial use of equipment
or machinery. The
manual contains
information needed
for proper operation,
maintenance and care.
Hanging underneath the
cowl, near the engine
connector.
Identification label
MODEL: OXE 200
MODEL NR: P3XL200
SERIAL NR:
BLOCK NR:
D.O.M:
MADE IN SWEDEN
CIMCO MARINE AB
30-0300-001
00001
17B68420
2016-08-25
1. Placed on the starboard
side of the engine,
just below the middle
cowling.
2. Placed on page 2 in the
Service Book.
Emission label
THIS OUTBOARD ENGINE COMPLIES WITH 2016 U.S EPA 40CFR PART 1042,
IMO 40CFR PART 43 EXHAUST REGULATIONS
• APPLICATION: COMMERCIAL
CATEGORY 1, PROPULSION WITH
FIXED-PITCH PROPELLERS
• REFER TO OWNER’S MANUAL FOR
MAINTENANCE SPECIFICATIONS AND
ADJUSTMENTS
• ULS DIESEL FUEL ONLY
MODEL: OXE 200
MODEL YEAR: 2016
FAMILY: GCABN02.0OXE
MAX POWER: 200HP / 149kW
MAX SPEED: 4300RPM
DISPLACEMENT: 1956 CC
STANDARD FELs: NO+HC 5,8 g/kWh
PM 0,15 g/kWh
EMISSION CONTROL INFORMATION
MADE IN SWEDEN CIMCO MARINE AB 30-0300-002
Placed on the timig belt
cover of the engine’s block.
Technical data Maintenance Operating Overview

6
OVERVIEW
MAIN COMPONENTS
ENGINE OIL
FILLER CAP
EXPANSION
TANK
INTERCOOLER
BELT HOUSING
HYDRAULIC
PUMP AND
FILTER
SEAWATER
STRAINER
AIR FILTER
GEARBOX
PROPELLER
SHAFT
ADAPTER
25 in.

7
TRANSOM
MOUNT WITH
TILT AND TRIM
CYLINDERS
SEAWATER
PUMP
ENGINE
CONNECTOR
ENGINE
OIL DIP
STICK
ENGINE
OIL FILTER
ENGINE
CONTROL
UNIT ECU FUEL FILTER
TURBO CHARGER
WATER INTAKE
ANTI CAVITATION
PLATE
Technical data Maintenance Operating Overview

8
OVERVIEW
CONTROL HEAD
The control head engages both gear
shiing and acceleration. Depending
on single installation or multi
installation of outboards, the boat
is equipped with a single or twin
shi control head. This description
comprises a single shi control head
only. Also refer to Single Control
Head Manual or Twin Control
Head Manual.
1. Engine trim control
2. Control lever
3. Lever position indicator
4. Control lamp
5. Neutral button
6. SEL button
7. Indicator lamp
INSTRUMENTATION
For instruments and gauges, refer
to corresponding Display manual.
1
3
6
7
4
2
5

9
CONTROL HEAD OPERATION
Neutral indicator lamp
The neutral indicator lamp (7) has
four states:
– Fast flashing in combination
with lamp (4) indicates
a critical fault which may
result in limited or no system
performance.
!DANGER
Call for assistance, use
another controlling device in
an emergency.
– Steady light: engine is in neutral
– Slow flashing (0.5 s on, 0.5 s
off): Neutral Throttle Warmup is
engaged.
– Very slow flashing (1 s on,
1 s off): Trolling mode is
engaged.
!WARNING
Be very cautious when first
engaging the gears to establish
that FORWARD is truly forward
and REVERSE is truly reverse. A
quick in-and-out of the gear test
is recommended. Ensure that
the boat is clear of all obstacles
around the boat before conducting
this test.
Control lamp
The control lamp (4) has a steady
light indicating that the control head
is active.
!WARNING
A fast flashing light indicates a
non-critical fault which may cause
the boat speed to be reduced. The
system will continue to operate.
Indicator dimming feature
When the control head is active,
pressing the SEL button (6)
repeatedly will cycle through the
available indicator brightness levels.
Technical data Maintenance Operating Overview

10
OVERVIEW
Control head range
Full speed
forward
Adjusng
screws
Full speed
reverse
Reverse
idle
Neutral
Forward
idle
Forward idle to 100% of max
engine rpm
Reverse idle to 50% of max
engine rpm
NTW idle to 50% of max
engine rpm
TM forward idle to 20% of max
engine speed
TM reverse idle to 20% of max
engine rpm
LSC forward idle rpm
LSC reverse idle rpm
Neutral Throttle Warmup
Neutral Throttle Warmup (NTW)
allows to control the engine throttle
without gear engagement, in order
to warm up the engine at a higher
rpm.
NOTE! Maximum rpm is limited to
2400 rpm.
A slow flashing neutral indicator
lamp (7) shows that NTW is
engaged.
Engaging NTW
Move the control lever (2) to
the Neutral position. The neutral
indicator lamp (7) will have a steady
light.
Press the Nbutton (5). The neutral
indicator lamp (7) flashes to indicate
that NTW is engaged.
It is now possible to increase throttle
and the engine will stay in neutral.
Disengaging Neutral Throttle
Warmup
Return the lever (2) to the Neutral
position.
Press the Nbutton (5). The lamp (7)
will have a steady light. The engine
and transmission will now respond
normally to lever commands.

11
Low Speed Control
Normal propeller
rpm range:
idle to max rpm
LSC propeller rpm range:
0 to idle rpm
Low Speed Control (LSC)
enables unprecedented control
while mooring and low speed
maneuvering. LSC incorporates
an electro-hydraulically operated
clutch that ensures smooth shiing
between neutral, forward and
reverse.
The sensor controlled propeller
speed allows for seamless control
from zero to maximum rpm. The
boat is fully operable even below
3-4 knots.
Trolling Mode
When engaging Trolling Mode (TM)
the full throttle range represents
20% of normal throttle range. This
enables a higher resolution of the
throttle maneuvering thus giving the
operator a more precise control in
demanding situations.
Trolling propeller rpm range:
Zero to idle rpm
Full engagement
propeller rpm range
idle to 20% of max rpm
A very slow flashing (one second
on, one second off) neutral indicator
lamp (7) indicates that TM is
engaged.
Engaging Trolling Mode
Move the control lever (2) to
forward idle or reverse idle
positions.
Press the Nbutton (5). The lamp (7)
will flash slowly to indicate that TM
is engaged.
Disengaging Trolling Mode
Move the control lever (2) to
forward idle or reverse idle position.
Press the Nbutton (5). The flashing
lamp (7) will go out to indicate that
TM is disengaged.
Technical data Maintenance Operating Overview

12
OVERVIEW
Adjustable lever feel
Throle fricon
Shi detent
The friction drag on the lever and
the force required to move in and
out of the shi detents can be set
according to operator preference.
Turn the throttle friction screw
clockwise to increase the friction
on the lever, counter-clockwise to
reduce the friction.
The shi detents are ment to prevent
accidental gear engagement.
Bear that in mind when you make
adjustments. Turn the shi detent
screw clockwise to increase,
counter-clockwise to decrease
force.

13
OUTBOARD INSTALLATION
!WARNING
Exceeding the boat’s maximum
power rating can cause serious
injury or death. Overpowering the
boat can affect boat control and
flotation characteristics or break
the transom. Do not install an
outboard that exceeds the boat’s
maximum power rating.
Improper mounting of the
outboard can result in hazardous
conditions such as poor handling
or loss of control. Your dealer
or other person experienced in
proper rigging should mount the
outboard.
Use mounting hardware to secure
only the outboard to the boat.
Do not use outboard mounting
hardware to attach accessories.
The information presented in this
section is intended as reference
only. For more detailed information,
refer to Installation Manual.
Safe and proper mounting depends
on experience and the specific
boat and outboard combination.
Therefore we strongly recommend
that your local dealer install the
outboard and related accessories to
ensure proper installation and good
performance.
Bolt pattern
Technical data Maintenance Operating Overview

14
OVERVIEW
MOUNTING THE OUTBOARD
The optimum mounting height is
determined by the boat/outboard
combination in addition to the
required use. Test runs at different
heights can be of assistance when
choosing the optimum mounting
height. For further information,
please contact the manufacturer.
!CAUTION
Check the carrying capacity of the
boat, at rest and with maximum
load, during water testing.
Check that the static water level
on the outboard rig is low enough
to prevent water from entering
the powerhead when water rising
due to waves when the outboard
is not running.
Incorrect engine height can create
air born water spray while the
boat is cruising. If the outboard
is operated continuously in the
presence of airborne water spray,
enough water could enter the
engine through the intake opening
on the cowling and cause severe
engine damage.
Eliminate the cause of airborne
water spray.
The outboard should be mounted
in such a way that the boat is well
balanced. Otherwise it could be
difficult to steer. Mount the outboard
on the centerline (keel line) of the
boat.
Mounting height
The mounting height of the outboard
affects its efficiency and reliability. A
mounting that is too high might lead
to propeller ventilation, which will
reduce propulsion due to excessive
propeller slip. There is also a risk of
overheating the outboard due to the
water intakes of the cooling system
may not get enough water supply.
If the outboard mounting is too low,
the water resistance will increase
and thereby reduce the efficiency
and performance of the outboard.
In general, the outboard should be
mounted so that the anti-cavitation
plate is in alignment with the bottom
of the boat.
