Safety Instructions
Notice: Ensure you read and fully understand instructions before use
While every attempt is made to ensure the highest degree of protection in all equipment, we cannot
guarantee freedom from injury. The user assumes all risk of injury due to use. All merchandise is sold
on this condition, which no representative of the company can waive or change.
•Ensure all nuts and bolts are tightened
and secure before use.
•Ensure that the plug, found on the side
of the lawn roller, is secure once you
have filled the tank with either water or
sand. Failure to do so could cause the
water or sand to leak.
•Leaving the product outside exposed to
the weather, especially direct sun, rain
and salt air, will speed up the weathering
process. This can be slowed by removing
the product from these conditions, or
covering it with a suitable cover.
•This product is not a toy, and is only to
be used for its intended purpose.
•Do not carry out alterations or
modifications to this product.
•This product is intended for outdoor use
only.
•Clean only with a damp cloth. Do not use
industrial or abrasive cleaning
substances, as these may damage the
product.
•If the product is damaged or defective,
•The drum will weigh approximately 30KG when filled with water, and
45KG when filled with sand.
•DRUM x1
•ROLLER HANDLE x1
•SCRAPER BAR x1
•ROLLER BEAM x2
•BOLT x6
•NUT x6
Page 3
Manual Version: v1.0
Model Code: 2459
Oypla.com LLP / www.oypla.com
Contents
1Front Cover
-
2Safety
Instructions
-
2Assembly
Instructions
-
4Back Cover
End
1. To start, push the bottom of the
roller beams (D) into the 30L tank (A),
ensuring that they go all the way in.
This will allow for the roller beams to
be secure when you attach the
scraper bar. Please see the image to
the right.
2. Align the holes in the Scraper Bar (C) with the hole in the roller beams (D). Once done, push
a screw (E) through each hole to hold the scraper bar in place. After this tighten a nut (F) onto
the screw (D). Do not overtighten the nut as this may damage the roller beams due to the curve
in the metal. Please see the images below.
3. Slide the roller handle on the inside of the roller beams, ensuring that the roller handle is
directly against the inside of the roller beams. Once done, push a bolt through each hole,
ensuring it goes through both parts. Once done, tighten a nut onto the bolt. Do not overtighten
as this may cause the bolt to bend. After this, repeat this step to fully attach the handle.
