Ozito BLL-036 User manual

CORDLESS
BLOWER
36V Lithium Ion
INSTRUCTION MANUAL
SPECIFICATIONS
Voltage: 36V
Battery: 3.0Ah Li-ion
Charge Time: 3 Hours
No Load Speed: 10,000-16,000/min
Max. Air Speed: 252km/hr
Weight with Battery: 4kg
BLL- 036
WHAT’S IN THE BOX
ozito.com.au
Blower
Blower Tube
Blower Nozzle
Battery Pack
Battery Charger

3
ONLINE MANUAL
Scan this QR Code with your
mobile device to take you to
the online manual.
Attaching the blow tube and direction nozzle
1. Unpack the blow tube and
direction nozzle.
2. Slide the larger end of the direction
nozzle onto the smaller end of the
blow tube.
3. Ensure that the button on the blow tube sits in
the hole in the direction nozzle.
4. Connect the blow tube to the blower
housing, ensuring that the blow tube
tab clicks into the hole in the blow
tube.
1 Direction Nozzle
2 Blow Tube
3 Blow Tube Release Tab
4 ON/OFF Switch/
Adjustable Speed Dial
5 Upper Handle
6 Battery
7 Battery Release Tab
8 Lower Handle
9 Battery
10 Charge Indicator Button
11 Battery Charger LED
12 Battery Charger
CORDLESS BLOWER
ACCESSORIES
KNOW YOUR PRODUCT
1. ASSEMBLY
SETUP & PREPARATION
9 1110
1
56 7
2 3
8
4
12
CAUTION! ENSURE THE TOOL IS OFF & THE BATTERY
REMOVED BEFORE PERFORMING ANY OF THE
FOLLOWING OPERATIONS.

Battery Charge Indicator
The blower battery is equipped with a
battery charge indicator to show the
state of the battery charge.
Press the charge indicator button and
look to see which LED lights illuminate.
1 GREEN LED
indicates that the battery requires immediate
charging.
2 GREEN LEDs indicate that the battery has only
a low charge and requires charging soon.
3 GREEN LEDs indicate that the battery is fully
charged.
Note: The battery should to be removed from the blower to check the
state of charge.
Battery protection system
The tool is equipped with the battery protection system, which helps to
ensure a long service life.
The output power automatically cuts off during operation when the tool
and/or battery are placed under the following situations:
• When the tool is overloaded:
If this occurs, release the trigger switch and remove causes of
overload, then pull the switch trigger again to restart.
• When the remaining battery capacity becomes low:
Recharge the battery pack.
Note: The battery protection system does not in any way damage the
tool.
Note: The indicated capacity may be lower than the actual level during
use or immediately after using the tool.
Inserting the battery pack
Align the raised ribs on the
battery with grooves on the
blower. Slide the battery into the
blower. Ensure the latch on the
bottom of the battery clicks in
place and that it is fully seated
and secure.
Removing the battery pack
1. Push in the battery release
button.
2. Lift the battery from its
position.
2. BATTERY & CHARGING
Charging your lithium ion battery
The hedge trimmer’s battery has been shipped in a low charge
condition, and requires charging prior to use. Allow several cycles of
charging and discharging (through use of the hedge trimmer) for the
battery to reach its optimum performance / runtime.
1. Connect the charger into a power outlet.
2. The charger LED will
illuminate red, showing
power is being supplied to
the charger.
3. With the charger sitting at on a bench/
table, align the raised ribs on the battery
with the recess in the charger and
slide onto the charger ensuring a rm
connection.
4. The charger LED will ash green signifying
that the battery is charging.
5. The charger LED will stop ashing and
illuminate green once the battery is fully
charged. A battery takes up to 3 hours to
become fully charged.
CAUTION! IF THE BATTERY IS TOO HOT OR TOO
COLD WHEN INSERTED INTO THE CHARGER, THE
CHARGING LED WILL FLASH RED. CHARGING WILL
AUTOMATICALLY BEGIN ONCE THE BATTERY REACHES
THE CORRECT CHARGING TEMPERATURE.
Charger LED Indicator
LED Indicator Situation
RED (illuminated) Stand by (no battery pack is inserted)
GREEN (Flashing) Battery is charging
GREEN (Illuminated) Battery is fully charged
RED (Flashing) Battery pack is too hot or too cold
(charging will begin automatically
when battery reaches correct charging
temperature).
CAUTION: THE POWER SUPPLY FOR THIS CHARGER
SHOULD BE PROTECTED BY A RESIDUAL CURRENT
DEVICE (RATED AT 30MA OR LESS).

Blowing
The blower is ideal for blowing
leaves, grass clippings and other
debris.
Hold the blower rmly, turn the
switch on, point the jet of air in
front of you and move forward
slowly. Move the blower from
side to side, with the tube several
inches above the ground.
Be careful where you point the
jet of air as it can move heavy
material and cause injury or
damage to bystanders.
Note: Be aware of other people
and animals in the area where you
are to be operating the blower.
Note: Avoid collisions with hard objects which could damage your
machine.
Turning ON
To turn the blower on, move the ON/OFF
switch/adjustable speed dial forward.
Turning OFF
To turn the blower off, move the ON/OFF
switch/adjustable speed dial back to the
OFF position.
Adjusting the speed
The ow of air can be regulated by turning
the adjustable speed dial.
To achieve the greatest ow of air, move
the switch forward to the “MAX” setting on
the dial.
The ow of air can be lessened by turning
the adjustable switch back in the direction
of the operator.
BLL - 036
3. ADJUSTABLE SPEED SWITCH 4. OPERATING THE BLOWER
OPERATION
WARNING! DO NOT USE THE BLOWER WITH ANY
TYPE OF ACCESSORY OR ATTACHMENT. SUCH USAGE
MIGHT BE HAZARDOUS.
WARNING! DO NOT PUT PART OF YOUR BODY SUCH
AS HANDS AND FINGERS IN THE VACUUM OPENING
OR EXHAUST OPENING.
WARNING! DO NOT SWITCH THE MACHINE ON IN
ENCLOSED OR POORLY VENTILATED SPACES OR IN
THE PRESENCE OF FLAMMABLE AND/OR EXPLOSIVE
LIQUIDS, GASES AND POWDERS.

DESCRIPTION OF SYMBOLS
CARING FOR THE ENVIRONMENT
Power tools that are no longer usable should not be disposed of
with household waste but in an environmentally friendly way. Please
recycle where facilities exist. Check with your local council authority
for recycling advice.
Recycling packaging reduces the need for landll and raw materials.
Reuse of recycled material decreases pollution in the environment.
Please recycle packaging where facilities exist. Check with your
local council authority for recycling advice.
Spare Part Part No.
Battery Pack ACCLB-136
Charger ACCLC-036
Spare parts can be ordered from the Special Orders Desk
at your local Bunnings Warehouse.
For further information, or any parts not listed here, visit
www.ozito.com.au or contact Ozito Customer Service:
Australia 1800 069 486
New Zealand 0508 069 486
E-mail: [email protected]
SPARE PARTS
Read instruction manual
Do not use in the rain or leave the blower outdoors while raining.
Be aware of people around you and do not direct towards them.
Regulator compliance mark
Keep bystanders away. Do not operate whilst people especially
children or pets are in the area.
Wear ear muffs.
5. GENERAL MAINTENANCE
MAINTENANCE
WARNING: BEFORE CLEANING YOUR BLOWER OR
CARRYING OUT ANY MAINTENANCE PROCEDURE,
MAKE SURE THAT THE MOTOR IS OFF AND THE BATTERY
REMOVED TO PREVENT ACCIDENTAL STARTING.
• Keep air intake clean and air vents free of debris to avoid overheating
the motor.
• Do not use cleaning agents to clean the plastic parts of the tool.
A mild detergent on a damp cloth is recommended. Water must never
come into contact with the tool.
• If the blower vibrates abnormally, stop motor immediately. Abnormal
vibration usually indicates a mechanical problem continued operation
could lead to injury or damage.
• No lubrication is necessary as the motor is equipped with lifetime-
lubricated bearings.
Note: Ozito Industries will not be responsible for any damage or injuries
caused by repair of the tool by an unauthorised person or mishandling
or mistreatment of the tool. This tool is designed for DIY use - use in
commercial or industrial environments will void the warranty.
THIS MANUAL CONTAINS IMPORTANT SAFETY AND OPERATING IN-
STRUCTIONS FOR YOUR
BATTERY CHARGER.
1. Before using the charger read all instructions and cautionary markings on the
charger, battery pack and the product using the battery pack.
2. This charger is not intended for any uses other than charging rechargeable batter-
ies. Any other use may result in risk of re, electric shock or electrocution.
3. Do not place any object on top of the charger or place the charger on a soft surface
that may result in excessive internal heat. Place the charger in a position away
from any heat source.
4. To reduce risk of damage to the electric plug and cord, pull by the plug rather than
the cord when disconnecting the charger.
5. Make sure the cord is located so that it will not be stepped on, tripped over, or
otherwise subjected to damage or stress.
6. An extension cord should not be used unless absolutely necessary. Use of an im-
proper extension cord could result in the risk of re, electric shock or electrocution.
7. Do not operate the charger if it has received a sharp blow, been dropped or other-
wise damaged in any way. Have it checked by an electrician or power tool repairer.
8. Do not disassemble charger. Take it to an electrician or power tool repairer when
service or repair is required. Incorrect reassembly may result in a risk of electric
shock, electrocution or re.
9. To reduce risk of electric shock, unplug the charger from the outlet before attempt-
ing any cleaning. Removing the battery pack will not reduce this risk.
10. Never attempt to connect 2 chargers together.
11. DO NOT store or use the tool and battery pack in locations where the temperature may
reach or exceed 40ºC (such as inside sheds or metal buildings in summer).
12. The charger is designed to operate on standard household electrical power (240
volts). Do not attempt to use it on any other voltage!
13. The battery pack is not fully charged out of the carton. First read the safety instruc-
tions and then follow the charging notes and procedures.
14. The longest life and best performance can be obtained if the battery pack is
charged when the air temperature is between 18 - 24ºC. Do not charge the battery
pack in an air temperature below 10ºC or above 40ºC. This is important and will
prevent damage to the battery pack.
15. Do not incinerate the battery pack even if it is seriously damaged or is completely
worn out. The battery can explode in a re.
16. Never attempt to open the battery pack for any reason. If the plastic housing of the bat-
tery pack breaks or cracks, immediately discontinue use and do not recharge.
17. During charging, the battery must be placed in a well ventilated area.
BATTERY AND CHARGER SAFETY WARNINGS

SPARE PARTS Tool:
Model No.
Item
No. Description Part No.
How To Order
Available spare parts can be ordered through the Special Orders Desk at any Bunnings Warehouse. If you have any
further questions, please contact Ozito Customer Service on:
Australia: 1800 069 486
New Zealand: 0508 069 486
[email protected]
The following is a list of spare parts carried by Ozito.
Please contact Customer Service for any parts not
listed.
Tool: 36V Blower Model No. BLL-036
Item
No. Description Part No.
- Battery Pack ACCLB-136
- Charger ACCLC-036

ADDITIONAL SAFETY INSTRUCTIONS FOR BLOWERS
• Always wear adequate protective clothing when operating the blower to avoid
injuries to face, eyes, hands, feet, head or hearing. Use safety glasses or a face
shield, high boots or sturdy shoes, long trousers, work gloves, a hard hat and ear
defenders.
• Do not start the tool when it is upside down or when it is not in the operating
position.
• Switch the motor off and remove the battery when the tool is not being used, left
unattended, being cleaned or being moved from one place to another.
• Do not operate the tool near people, especially children or pets. Turn it off if they
get too close. Maintain a safe distance of at least 5m from other people when
using the tool.
• Never direct the blower direction nozzle towards bystanders or pets. Never blow
debris in the direction of bystanders or pets. The operator is responsible for
accidents or hazards occurring to other people or their property.
• Do not handle the battery or the tool with wet hands and do not use the tool in
the rain.
• Keep all the air intakes and the blower tube free of dust, lint, hair and other
material that may cause a reduction in air ow.
• Keep a balanced and stable stance while using the tool. Do not switch on the tool
in enclosed or poorly ventilated spaces or in the presence of inammable and/or
explosive substances such as liquids, gasses and powders.
• Do not get distracted and always concentrate on what you are doing. Use
common sense. Never operate the tool when you are tired, sick or under the
inuence of alcohol or other drugs.
• Do not operate this appliance with long loose hair or loose tting jewellery. Tie
long loose hair back and remove loose tting jewellery.
• Only operate the tool during broad daylight or with adequate articial light.
• When the tool is not in use, store it in a dry place and out of reach of children.
• Only use the tool according to the instructions given in this manual.
• Check regularly that the screws are tight.
WARNING! When servicing, use only identical replacement parts. Use of
any other parts may create a hazard or cause product damage. To ensure
safety and reliability, all repairs should be performed by a qualied service
technician.
WARNING! This appliance is not intended for use by young or inrm persons
unless supervised by a responsible person to ensure that they can use the
appliance safely. Young children should be supervised to ensure that they do
not play with the appliance.
WARNING! When using mains-powered tools, basic safety precautions, including the
following, should always be followed to reduce risk of re, electric shock, personal injury
and material damage.
Read the whole manual carefully and make sure you know how to switch the tool off in an emergency, before
operating the tool.
Save these instructions and other documents supplied with this tool for future reference.
This tools charger is double insulated in accordance with AS/NZS 60745-1;
therefore no earth wire is required.
If the supply cord is damaged, it must be replaced by an electrician or a power tool repairer in order to avoid
a hazard.
Note: Double insulation does not take the place of normal safety precautions when operating this tool. The
insulation system is for added protection against injury resulting from a possible electrical insulation failure
within the tool.
To reduce the risk of electric shock, we recommend the use of a residual current device (rated 30mA or less).
GENERAL POWER TOOL SAFETY WARNINGS
ELECTRICAL SAFETY
WARNING! Read all safety warnings and all instructions. Failure to follow the warnings and
instructions may result in electric shock, re and/or serious injury.
Save all warnings and instructions for future reference. The term “power tool” in the
warnings refers to your mains-operated (corded) power tool or battery-operated (cordless) power
tool.
1. Work area safety
a. Keep work area clean and well lit. Cluttered or dark areas invite accidents.
b. Do not operate power tools in explosive atmospheres, such as in the presence of ammable
liquids, gases or dust. Power tools create sparks which may ignite the dust or fumes.
c. Keep children and bystanders away while operating a power tool. Distractions can cause you to
lose control.
2. Electrical safety
a. Power tool plugs must match the outlet. Never modify the plug in any way. Do not use any
adapter plugs with earthed (grounded) power tools. Unmodied plugs and matching outlets will
reduce risk of electric shock.
b. Avoid body contact with earthed or grounded surfaces, such as pipes, radiators, ranges and
refrigerators. There is an increased risk of electric shock if your body is earthed or grounded.
c. Do not expose power tools to rain or wet conditions. Water entering a power tool will increase the
risk of electric shock.
d. Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the power tool.
Keep cord away from heat, oil, sharp edges or moving parts. Damaged or entangled cords increase
the risk of electric shock.
e. When operating a power tool outdoors, use an extension cord suitable for outdoor use. Use of a
cord suitable for outdoor use reduces the risk of electric shock.
f. If operating a power tool in a damp location is unavoidable, use a residual current device (RCD)
protected supply. Use of an RCD reduces the risk of electric shock.
3. Personal safety
a. Stay alert, watch what you are doing and use common sense when operating a power tool. Do
not use a power tool while you are tired or under the inuence of drugs, alcohol or medication. A
moment of inattention while operating power tools may result in serious personal injury.
b. Use personal protective equipment. Always wear eye protection. Protective equipment such as dust
mask, non-skid safety shoes, hard hat, or hearing protection used for appropriate conditions will reduce
personal injuries.
c. Prevent unintentional starting. Ensure the switch is in the off-position before connecting to
power source and/or battery pack, picking up or carrying the tool. Carrying power tools with your
nger on the switch or energising power tools that have the switch on invites accidents.
d. Remove any adjusting key or wrench before turning the power tool on. A wrench or a key left
attached to a rotating part of the power tool may result in personal injury.
e. Do not overreach. Keep proper footing and balance at all times. This enables better control of the
power tool in unexpected situations.
f. Dress properly. Do not wear loose clothing or jewellery. Keep your hair, clothing and gloves
away from moving parts. Loose clothes, jewellery or long hair can be caught in moving parts.
g. If devices are provided for the connection of dust extraction and collection facilities, ensure
these are connected and properly used. Use of dust collection can reduce dust-related hazards.
4. Power tool use and care
a. Do not force the power tool. Use the correct power tool for your application. The correct power
tool will do the job better and safer at the rate for which it was designed.
b. Do not use the power tool if the switch does not turn it on and off. Any power tool that cannot be
controlled with the switch is dangerous and must be repaired.
c. Disconnect the plug from the power source and/or the battery pack from the power tool before
making any adjustments, changing accessories, or storing power tools. Such preventive safety
measures reduce the risk of starting the power tool accidentally.
d. Store idle power tools out of the reach of children and do not allow persons unfamiliar with the
power tool or these instructions to operate the power tool. Power tools are dangerous in the hands
of untrained users.
e. Maintain power tools. Check for misalignment or binding of moving parts, breakage of parts and
any other condition that may affect the power tool’s operation. If damaged, have the power tool
repaired before use. Many accidents are caused by poorly maintained power tools.
f. Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp cutting edges are
less likely to bind and are easier to control.
g. Use the power tool, accessories and tool bits etc. in accordance with these instructions, taking
into account the working conditions and the work to be performed. Use of the power tool for
operations different from those intended could result in a hazardous situation.
5. Battery tool use and care
a. Recharge only with the charger specied by the manufacturer. A charger that is suitable for one
type of battery pack may create a risk of re when used with another batery pack.
b. Use power tools only with specically designated battery packs. Use of any other battery packs
may create a risk of injury and re.
c. When battery pack is not in use, keep it away from other metal objects, like paper clips, coins,
keys, nails, screws or other small metal objects, that can make a connection from one terminal
to another. Shorting the battery terminals together may cause burns or a re.
d. Under abusive conditions, liquid may be ejected from the battery; avoid contact. If contact
accidentally occurs, ush with water. If liquid contacts eyes, additionally seek medical help.
Liquid ejected from the battery may cause irritation or burns.
6. Service
a. Have your power tool serviced by a qualied repair person using only identical replacement
parts. This will ensure that the safety of the power tool is maintained.

IN ORDER TO MAKE A CLAIM UNDER THIS
WARRANTY YOU MUST RETURN THE PRODUCT
TO YOUR NEAREST BUNNINGS WAREHOUSE WITH
YOUR BUNNINGS REGISTER RECEIPT. PRIOR TO
RETURNING YOUR PRODUCT FOR WARRANTY
PLEASE TELEPHONE OUR CUSTOMER SERVICE
HELPLINE:
Australia 1800 069 486
New Zealand 0508 069 486
WARRANTY
TO ENSURE A SPEEDY RESPONSE PLEASE
HAVE THE MODEL NUMBER AND DATE OF
PURCHASE AVAILABLE. A CUSTOMER SERVICE
REPRESENTATIVE WILL TAKE YOUR CALL
AND ANSWER ANY QUESTIONS YOU MAY
HAVE RELATING TO THE WARRANTY POLICY
OR PROCEDURE.
OZITO Australia/New Zealand (Head Office) 1-23 Letcon Drive, Bangholme, Victoria, Australia 3175.
The benefits provided under this warranty are in addition
to other rights and remedies which are available to you at law.
Our goods come with guarantees that cannot be excluded
at law. You are entitled to a replacement or refund for a major
failure and for compensation for any other reasonably foreseeable
loss or damage. You are also entitled to have the goods repaired
or replaced if the goods fail to be of acceptable quality and the
failure does not amount to a major failure.
Generally you will be responsible for all costs associated with
a claim under this warranty, however, where you have suffered
any additional direct loss as a result of a defective product you
may be able to claim such expenses by contacting our customer
service helpline above.
0414
3 YEAR REPLACEMENT WARRANTY
Your product is guaranteed for a period of 36 months from the
original date of purchase and is intended for DIY (Do It Yourself)
use only. If a product is defective it will be replaced in accordance
with the terms of this warranty. Lithium Ion batteries are covered
by a 12 month warranty. Warranty excludes consumable parts.
WARNING
The following actions will result in the warranty being void.
• If the tool has been operated on a supply voltage other
than that specified on the tool.
• If the tool shows signs of damage or defects caused
by or resulting from abuse, accidents or alterations.
• Failure to perform maintenance as set out within the
instruction manual.
• If the tool is disassembled or tampered with in any way.
