Ozito ECS-1935 User manual

Electric Chainsaw
356mm Bar356mm Bar
1900W
3/8” LP
52
3/8”LP
52
ElectricChainsaw
356mm Bar356mm Bar
1900W
3/8”LP
52
ElectricChainsaw
356mm Bar356mm Bar
1900W
3/8”LP
52
ElectricChainsaw
356mm Bar356mm Bar
1900W
ELECTRIC
CHAINSAW
1900W 356mm
INSTRUCTION MANUAL
SPECIFICATIONS
Motor: 1900W
Bar Length: 356mm (14”)
Cutting Length Max.: 325mm
Chain Speed: 15.5m/s
Oil Tank Capacity: 160ml
Noise Rating: 108dB
Weight: 4.8kg
ECS-1935
STANDARD EQUIPMENT
3 YEAR REPLACEMENT WARRANTY*
Your product is guaranteed for a period of 36 months from the original date of purchase. If
a product is defective it will be replaced in accordance with the terms of this warranty. Warranty
excludes consumable parts, for example: guide bar, chain and included accessories.
*This product is intended for DIY use only and replacement warranty covers domestic use.
WARNING
The following actions will result in the warranty being void.
• If the tool has been operated on a supply voltage other than that specified on the tool.
• If the tool shows signs of damage or defects caused by or resulting from abuse, accidents
or alterations.
• Failure to perform maintenance as set out within the instruction manual.
• If the tool is disassembled or tampered with in any way.
• Professional, industrial or high frequency use.
WARRANTY
Ozito Industries Pty Ltd 25 Fox Drive, Dandenong South, Victoria, Australia 3175.
ozito.com.au
Electric Chainsaw
Chain
0821
IN ORDER TO MAKE A CLAIM UNDER THIS WARRANTY
YOU MUST RETURN THE PRODUCT TO YOUR NEAREST
BUNNINGS WAREHOUSE WITH YOUR BUNNINGS
REGISTER RECEIPT. PRIOR TO RETURNING YOUR
PRODUCT FOR WARRANTY PLEASE TELEPHONE OUR
CUSTOMER SERVICE HELPLINE:
Australia: 1800 069 486
New Zealand: 0508 069 486
The benefits provided under this warranty are in addition to other rights and remedies which
are available to you at law.
Our goods come with guarantees that cannot be excluded at law. You are entitled to a
replacement or refund for a major failure and for compensation for any other reasonably
foreseeable loss or damage. You are also entitled to have the goods repaired or replaced if the
goods fail to be of acceptable quality and the failure does not amount to a major failure.
Generally you will be responsible for all costs associated with a claim under this warranty,
however, where you have suffered any additional direct loss as a result of a defective product
you may be able to claim such expenses by contacting our customer service helpline above.
TO ENSURE A SPEEDY RESPONSE PLEASE HAVE
THE MODEL NUMBER AND DATE OF PURCHASE
AVAILABLE. A CUSTOMER SERVICE REPRESENTATIVE
WILL TAKE YOUR CALL AND ANSWER ANY QUESTIONS
YOU MAY HAVE RELATING TO THE WARRANTY POLICY
OR PROCEDURE.
Guide Bar
Guide Bar Cover

ElectricChainsaw
356mm Bar356mm Bar
1900W
3/8”LP
52
Electric Chainsaw
356mm Bar356mm Bar
1900W
3/8” LP
52
Electric Chainsaw
356mm Bar356mm Bar
1900W
Electric Chainsaw
356mm Bar356mm Bar
1900W
3/8” LP
52
+
Electric Chainsaw
356mm Bar356mm Bar
1900W
3/8” LP
52
Electric Chainsaw
356mm Bar356mm Bar
1900W
Electric Chainsaw
356mm Bar356mm Bar
1900W
3/8” LP
52
+
3/8”LP
52
Electric Chainsaw
356mm Bar356mm Bar
1900W
3/8” LP
52
Electric Chainsaw
356mm Bar356mm Bar
1900W
Electric Chainsaw
356mm Bar356mm Bar
1900W
3/8” LP
52
+
Electric Chainsaw
356mm Bar356mm Bar
1900W
3/8” LP
52
Electric Chainsaw
356mm Bar356mm Bar
1900W
Electric Chainsaw
356mm Bar356mm Bar
1900W
3/8” LP
52
+
Electric Chainsaw
356mm Bar356mm Bar
1900W
3/8” LP
52
Electric Chainsaw
356mm Bar356mm Bar
1900W
Electric Chainsaw
356mm Bar356mm Bar
1900W
3/8” LP
52
+
3/8” LP
52
Electric Chainsaw
356mm Bar356mm Bar
1900W
Electric Chainsaw
356mm Bar356mm Bar
1900W
3/8” LP
52
Electric Chainsaw
356mm Bar356mm Bar
1900W
Electric Chainsaw
356mm Bar356mm Bar
1900W
3/8” LP
52
+
AB
Electric Chainsaw
356mm Bar356mm Bar
1900W
3/8” LP
52
Electric Chainsaw
356mm Bar356mm Bar
1900W
Electric Chainsaw
356mm Bar356mm Bar
1900W
3/8” LP
52
+
1. Power cord
2. Cord retainer
3. Oil level window
4. Oil tank cap
5. Side cover
6. Chain tensioning dial
7. Chain brake
8. Bucking spikes
9. Side cover lock
10. Guide bar
11. Chain
12. Lock-off switch
13. On/Off trigger
14 Rear handle
15. Sprocket
16. Front handle
17. Chain tensioning pin
ELECTRIC CHAINSAW
ACCESSORIES
KNOW YOUR PRODUCT
1. GUIDE BAR & CHAIN
ASSEMBLY
1 2 3 4 56 7 8
12
10 11
WARNING! ENSURE THE TOOL IS TURNED OFF AND
DISCONNECTED FROM THE POWER SUPPLY BEFORE
PERFORMING ANY OF THE FOLLOWING OPERATIONS.
ONLINE MANUAL
Scan this QR Code with your mobile
device to take you to the online manual.
Fitting the Chain & Bar
1. Fully unscrew the side cover lock
by turning it in an anti-clockwise
direction.
2. Remove the side cover.
3. Fit the chain over the guide bar,
making sure that the cutters are
facing in the direction of rotation.
4. Place the guide bar and chain
in position, ensuring that the
chain is around sprocket (A).
Also ensure that the chain
tensioning pin (B) fits into the
guide bar. If it does not fit, it
can be adjusted slightly with
the chain tensioning dial. The
chain must not slip off the bar
when you do this.
15 1613
18. Guide bar cover
WARNING! ALWAYS WEAR HEAVY GLOVES WHEN
HANDLING THE CHAIN AS IT IS VERY SHARP AND CAN
CUT YOU WHEN IT IS NOT MOVING.
5. Pull the guide bar forward until
the chain is closely seated.
Make sure that all the drive
links are in the groove of the guide bar.
6. Place the side cover at a slight angle at the
beginning of assembly, then secure with the
side cover lock, turning several times for the
thread to engage.
Note: Do not fully tighten the side cover lock
until after adjusting the chain tension.
14
18
9
17

3mm gap is
the ideal tension
Electric Chainsaw
356mm Bar356mm Bar
1900W
3/8” LP
52
Electric Chainsaw
356mm Bar356mm Bar
1900W
Electric Chainsaw
356mm Bar356mm Bar
1900W
3/8” LP
52
+
Electric Chainsaw
356mm Bar356mm Bar
1900W
3/8” LP
52
Electric Chainsaw
356mm Bar356mm Bar
1900W
Electric Chainsaw
356mm Bar356mm Bar
1900W
3/8” LP
52
+
Electric Chainsaw
356mm Bar356mm Bar
1900W
3/8” LP
52
Electric Chainsaw
356mm Bar356mm Bar
1900W
Electric Chainsaw
356mm Bar356mm Bar
1900W
3/8” LP
52
+
Electric Chainsaw
356mm Bar356mm Bar
1900W
3/8” LP
52
Electric Chainsaw
356mm Bar356mm Bar
1900W
Electric Chainsaw
356mm Bar356mm Bar
1900W
3/8” LP
52
+
3. Refit cap and clean any oil spillage.
4. Always fill the oil tank when the oil
level falls below the minimum mark
on the oil level window.
Note: Always check the oil level
window before and during the use of
the chainsaw.
1. Unscrew the side cover lock a few
turns to ensure it is loose.
2. Adjust the chain tension with the
chain tensioning dial. Rotating the dial
downwards increases the tension and
rotating the dial up decreases the chain
tension.
The tension is correct when the chain
can be pulled 3mm away from the
guide bar when using your finger and
thumb.
Do not over-tighten as this will
reduce the life of the chain and guide
bar.
Tensioning the Chain
SETUP & PREPARATION
2. CHAIN TENSION
WARNING! ENSURE THE TOOL IS TURNED OFF AND
DISCONNECTED FROM THE POWER SUPPLY BEFORE
PERFORMING ANY OF THE FOLLOWING OPERATIONS.
WARNING! ALL THE CHAIN LINKS MUST LIE
PROPERLY IN THE GROOVE OF THE GUIDE BAR.
3. Tighten the side cover lock.
WARNING!: THE CHAIN SHOULD BE ADJUSTED
BEFORE FIRST USE, AGAIN AFTER 2 - 3 MINUTES
OF OPERATION AND RECHECKED AND ADJUSTED IF
NECESSARY AFTER EACH 30 MINUTES OF USE. TAKE CARE
NOT TO OVER TENSION THE CHAIN.
3. LUBRICATION
WARNING! ONLY USE OIL THAT IS EXPRESSLY
LABELLED “CHAIN BAR OIL”
Filling with Oil
1. Place the chainsaw on a flat
surface and remove the oil
tank cap.
2. Slowly fill the tank with chain
bar oil, ensuring that no dirt
enters the tank. The capacity
of the chain oil tank is 160ml.
WARNING! NEVER OPERATE THE CHAINSAW UNLESS
THE CHAIN AND BAR ARE LUBRICATED.
5. To check the lubricating system,
switch on the chainsaw and hold it
with the guide bar and chain above
some light coloured paper such as
newspaper. A steadily increasing
stain caused by oil spray shows the
lubricating system is working.
Note: Chain bar oil may leak if the tool
is left for long periods. This is normal.
If the tool is to be left unused for an extended time, drain the oil from the
tool. Refill before use.
Use a funnel (not supplied) and fill the tank slowly to prevent spilling the
oil. Do not overfill the tank.

ElectricChainsaw
356mm Bar356mm Bar
1900W
3/8”LP
52
RUN
BRAKE IS OFF
BRAKE IS ON
Electric Chainsaw
356mm Bar356mm Bar
1900W
3/8” LP
52
ElectricChainsaw
356mm Bar356mm Bar
1900W
3/8”LP
52
The cord retainer is used to “anchor” an extension lead (not included)
when it is connected to the power cord of the tool. It prevents the
extension lead from being accidentally disconnected from the chainsaw’s
power cord or shaken loose during use. Only use Heavy Duty extension
lead suitable for outdoor use with electric garden tools, no longer than 25
meters.
1. Make a loop in the end of the
extension lead and pass the loop
though the hole in the handle.
2. Hook the loop over the cord
retainer. Pull the extension lead
to secure it in position over the
cord retainer.
3. Connect the extension lead to
the power cord of the tool.
Route the power cord and
extension lead away from the
work area to prevent contact
with the chainsaw.
Note: Always use an approved extension lead suitable for the power input
of the tool and outdoor use.
4. CORD RETAINER 5. CHAIN BRAKE
OPERATION
WARNING!: CHECK THE OPERATION OF THE CHAIN
BRAKE ON A REGULAR BASIS. NEVER USE THE
CHAINSAW IF THE CHAIN BRAKE IS NOT WORKING
PROPERLY.
The chain brake operates
automatically in the event of
kick back.
The chainsaw is fitted with a
hand guard/chain brake which,
when operated brings the
chain to a stop within a tenth
of a second.
The chain brake can be
operated manually by pushing
it forward or automatically as a
result of kickback.
Kick back occurs if the chain
catches on the wood being cut and the chainsaw pushes back suddenly.
In the event of kick back, your hand (which is on the front handle during
operation) jerks forward causing the back on your hand to push the guard
forward, engaging the chain brake and quickly stopping the chain.

ElectricChainsaw
356mm Bar356mm Bar
1900W
3/8”LP
52
RUN
BRAKE IS OFF
BRAKE IS ON
Electric Chainsaw
356mm Bar356mm Bar
1900W
3/8” LP
52
ElectricChainsaw
356mm Bar356mm Bar
1900W
3/8”LP
52
ElectricChainsaw
356mm Bar356mmBar
1900W
3/8”LP
52
Electric Chainsaw
356mm Bar356mm Bar
1900W
3/8” LP
52
ElectricChainsaw
356mmBar356mmBar
1900W
3/8”LP
52
ElectricChainsaw
356mmBar356mmBar
1900W
3/8”LP
52
ElectricChainsaw
356mmBar356mmBar
1900W
3/8”LP
52
Electric Chainsaw
356mm Bar356mm Bar
1900W
3/8” LP
52
Electric Chainsaw
356mm Bar356mm Bar
1900W
3/8” LP
52
ElectricChainsaw
356mm Bar356mm Bar
1900W
3/8”LP
52
ElectricChainsaw
356mm Bar356mm Bar
1900W
3/8”LP
52
ElectricChainsaw
356mm Bar356mm Bar
1900W
3/8”LP
52
ElectricChainsaw
356mm Bar356mm Bar
1900W
3/8”LP
52
ElectricChainsaw
356mm Bar356mm Bar
1900W
3/8”LP
52
ElectricChainsaw
356mm Bar356mm Bar
1900W
3/8”LP
52
6. SWITCHING ON/OFF 7. CUTTING
ECS-1935
WARNING!: ALWAYS CARRY THE CHAINSAW BY THE
FRONT HANDLE. IF THE CHAINSAW IS PLUGGED IN
AND YOU CARRY IT BY THE REAR HANDLE, THERE IS A RISK
THAT YOU COULD ACCIDENTALLY PRESS THE LOCK-OFF
SWITCH AND THE ON/OFF TRIGGER AT THE SAME TIME,
INADVERTENTLY STARTING THE CHAINSAW.
1. Pull the hand guard/chain brake
towards you. The brake may
be stiff and may require to be
moved with some force. If the
brake is engaged the chain will
not operate.
2. Hold the front handle with your
left hand and the rear handle
with your right hand.
Switching On
WARNING: TO REDUCE THE RISK OF ELECTRICAL SHOCK,
WE RECOMMEND THE USE OF A RESIDUAL CURRENT
DEVICE (RATED 30mA OR LESS).
Hints and Tips
•Do not force the saw into the cut. Apply only light pressure whilst
running the motor at full speed.
•If the chain gets caught in the cut, switch off and disconnect the
product from the power supply. Do not try to remove it by twisting the
guide bar or pulling forcibly. Use a lever or wedge to open up the cut so
that the chain is freed.
•While cutting, always:
– Run the chainsaw motor at full revs. This makes the job safer, as
there is less chance of pull-in or kick-back.
– Position your body to the left of the chainsaw so if it kicks back
uncontrollably, it goes over your right shoulder, never stand in the
cutting line of the saw.
– Keep a firm grip with your left hand on the front handle,
with your thumb securely below the handle.
3. Use the thumb of your right
hand to push the lock-off
switch in and squeeze the on/
off trigger to start the motor.
4. The chain will now be running,
ready to make a cut. Release
the lock-off switch.
Switching Off
1. Release the ON/OFF trigger. The
integrated brake will bring the
running chainsaw to a standstill
within a very short space of time.
WARNING! FIRST TIME USERS SHOULD, AS A
MINIMUM PRACTISE, CUT LOGS ON A SAW-HORSE OR
CRADLE.
WARNING! POSITION THE POWER LEAD SO THAT
IT WILL NOT BE CAUGHT IN BRANCHES DURING
CUTTING.
1. Press the bucking spikes against
the timber ensuring the chain is not
making contact with the material
being cut.
2. Start cutting by holding
the chainsaw by the front
handle and raising the rear
handle.
3. If you cannot cut the
timber in a single stroke,
apply light pressure to the
front handle and continue
sawing, draw the chainsaw
back a little then apply the
bucking spikes a little lower
and finish the cut by raising
the rear handle.
4. Withdraw the chainsaw
from the cut while the
chain is still running.

1
2
outward
stroke
30º
2
1
2
outward
stroke
30º
2
1
2
outward
stroke
30º
2
1
2
outward
stroke
30º
2
1
2
outward
stroke
30º
2
8. CUTTING APPLICATIONS
APPLICATIONS
WARNING! ALWAYS KEEP A BALANCED STANCE. DO
NOT STAND ON THE LOG. BE ALERT TO THE FACT THAT
THE LOG MAY ROLL OVER. WHEN WORKING ON A SLOPE,
ALWAYS STAND ON THE UP HILL SIDE OF THE LOG.
Felling a Tree
Decide the direction in which you
wish the tree to fall, taking into
account the direction of the wind,
the position of branches, lean of the
tree, ease of subsequent limbing
and bucking and other factors
prevalent at the time.
WARNING!: FELLING A TREE SHOULD ONLY BE DONE BY
TRAINED OPERATORS.
WARNING!: AVOID CUTTING INTO THE GROUND AS
THIS WILL VERY QUICKLY DULL THE CHAIN.
Limbing
Limbing is the process of removing
the branches from a fallen tree.
Check the direction in which a
branch will bend before cutting it.
Always cut on the opposite side
to the bending direction so that
the guide bar is not pinched in the
cut. For large limbs that cannot
be removed in one cut, make an initial cut from the bent side and finish
by sawing from the opposite direction. Do not remove limbs that are
supporting the fallen tree on the ground until the tree has been cut into
lengths.
Bucking
Bucking is cutting a log into lengths for
easier handling. To saw a log lying on
the ground, first saw halfway, then roll
the log over and cut from the opposite
side.
To saw the end of a log supported off
the ground, first saw up from the bottom
one-third through the log then finish by
sawing down from the top. To saw a log
in the middle of two supports holding it
off the ground, first saw down from the top one-third through the log then
finish by sawing up from the bottom.
Pruning
WARNING! DO NOT USE AN UNSTABLE FOOT-HOLD OR
LADDER. DO NOT OVERREACH. DO NOT SAW ABOVE
SHOULDER HEIGHT. ALWAYS USE BOTH HANDS TO HOLD
THE SAW. FIRST CUT UP FROM THE BOTTOM AND FINISH
DOWN FROM THE TOP.
Pruning is the removal of a limb or
branch from a standing tree.
Chain Tension
Check the chain tension frequently and adjust as often as necessary. (see Tensioning the chain)
Maintaining the Guide Bar
Most guide bar problems can be prevented by
keeping the chainsaw well maintained. Insufficient
guide bar lubrication and operating the saw with
a chain that is TOO TIGHT will contribute to rapid
bar wear.
To help minimize bar wear, the following guide bar
maintenance procedures are recommended.
• The bar should be reversed every 8 working
hours to ensure uniform wear. Keep the bar
groove and lubrication hole clean.
• Check the bar rails frequently for wear and, if necessary, remove the burs and square-up the
rails using the flat file.
• Oil passages on the bar should be cleaned to ensure proper lubrication of the bar and chain
during operation. Grease the nose sprocket at the tip of the guide bar.
Note: The condition of the oil passages can be easily checked. If the passages are clear, the
chain will automatically give off a spray of oil within seconds of starting the saw. Your saw is
equipped with an automatic oiler system.
Chain Sharpening
Chain File: 3.96mm (5/32”)
Chain Pitch: 9.53mm (3/8”)
Chain Gauge: 1.3mm (.050”)
Sharpen the chain regularly to maintain optimum
performance of the saw. Signs of a dull chain are:
• The sawdust becomes powder-like
• Extra force is required to execute a cut
• The cut does not track in a straight line
• Increased vibration
Sharpen each cutter using a chain file. Always use
outward strokes and maintain a 30° angle between the chain and file. After sharpening, the
cutters must all have the same width and length.
After every 3 – 4 uses get an authorised repair centre to professionally sharpen your chain.
They have the special tools necessary to ensure the correct cutting angles and depths.
WARNING! ENSURE THE TOOL IS TURNED OFF AND
DISCONNECTED FROM THE POWER SUPPLY BEFORE
PERFORMING ANY OF THE FOLLOWING OPERATIONS.
WARNING! ALWAYS WEAR HEAVY GLOVES WHEN
HANDLING THE CHAIN AS IT IS VERY SHARP AND CAN
CUT YOU WHEN IT IS NOT MOVING.
WARNING! WEAR HEAVY GLOVES WHEN HANDLING
THE CHAIN. HOLD THE GUIDE BAR SECURELY IN A
VICE.
MAINTENANCE
WARNING! KICKBACK MAY OCCUR WHEN THE NOSE
OR TIP OF THE GUIDE BAR TOUCHES AN OBJECT, OR
WHEN THE WOOD CLOSES IN AND PINCHES THE SAW CHAIN
IN THE CUT. TIP CONTACT IN SOME CASES MAY CAUSE A
LIGHTNING FAST REVERSE REACTION, KICKING THE GUIDE
BAR UP AND BACK TOWARDS THE OPERATOR.

Double insulated Wear hearing & eye protection
Diameter Wear non-slip heavy duty gloves
Warning
Regulatory Compliance Mark
(RCM)
Disconnect and discontinue use
should the power cord be
damaged.
VVolts Hz
W
Hertz
~
n0
/min
Alternating Current Watts
No load speed
Revolutions or reciprocations
per minute
Read Instruction Manual
Ø
108
Beware of kickback
Do not expose to rain
Always hold the chainsaw with
both hands
Sound power level
IMPORTANT! When placing the chain on the guide bar,
ensure the chain direction is the same as the image on the
guide bar
Chain drive links 52
52
DESCRIPTION OF SYMBOLS
Power tools that are no longer usable should not
be disposed of with household waste but in an
environmentally friendly way. Please recycle where
facilities exist. Check with your local council authority for
recycling advice.
Recycling packaging reduces the need for landfill and
raw materials. Reuse of recycled material decreases
pollution in the environment. Please recycle packaging
where facilities exist. Check with your local council
authority for recycling advice.
CARING FOR THE ENVIRONMENT
SPARE PARTS
Spare parts can be ordered from the Special Orders Desk at your
local Bunnings Warehouse.
For further information, or any parts not listed here, visit
www.ozito.com.au or contact Ozito Customer Service:
Australia 1800 069 486
New Zealand 0508 069 486
E-mail: [email protected]
Ozito Industries will not be responsible for any damage or injuries caused by
repair of the tool by an unauthorised person or mishandling or mistreatment
of the tool. This tool is designed for Domestic Home Use only. Use in
commercial or industrial environments will void the warranty.
• Keep the handles free of grease and oil so that you can maintain a firm
grip.
• Clean the device as required with a damp cloth and, if necessary, mild
washing up liquid.
• If the chainsaw is not to be used for an extended period of time then you
should remove the chain bar oil from the tank. Briefly immerse the chain
and the guide bar in an oil bath and then wrap them in oil paper and
store in guide bar cover.
Cleaning & Storing
The chain can be purchased through Ozito spare parts or from your local
Bunnings Warehouse. The correct chain can be purchased by matching
the pitch, gauge and number of links as shown below:
Chain Replacement
1
2
outward
stroke
30º
2
9.53mm (3/8”) 1.3mm (.050”) 52 Links
Gauge
TROUBLESHOOTING
PROBLEM CAUSE REMEDY
Chainsaw will not
work.
Chain brake
engaged
Disengage brake
No power supply Try alternative
source of electrical
power
Defective mains
outlet
Try alternative
source of electrical
power
Power extension
cord damaged
Check the cable and
replace if required
Chainsaw operates
intermittently
Power cable
damaged
Replace power cable
On/O󰀨 switch
defective
Replace switch
Dry chain No oil in oil tank Fill oil tank with
chain bar oil
Oil tank cap breather
blocked
Clean oil tank cap
Oil outlet blocked Clear oil outlet
Chain or guide rail
hot
No oil in oil tank Fill oil tank with
chain bar oil
Oil tank cap breather
blocked
Clean oil tank cap
Oil outlet blocked Clear oil outlet
Blunt chain Sharpen or replace
chain
Wont cut Blunt chain Sharpen or replace
chain
Chain on backwards
(chain teeth pointing
in the wrong
direction)
Remove chain and
reinstall with the
teeth facing in the
correct direction
Worn chain Replace the chain
Chainsaw vibrating
or not cutting
properly
Chain tension too
loose
Adjust chain to
correct tension
Blunt chain Sharpen or replace
chain
Worn chain Replace the chain
Chain on backwards
(chain teeth pointing
in the wrong
direction).
Remove chain and
reinstall with the
teeth facing in the
correct direction
MAINTENANCE (cont.)

GENERAL POWER TOOL SAFETY WARNINGS
ELECTRICAL SAFETY
WARNING! When using mains-powered tools, basic safety precautions, including the following,
should always be followed to reduce risk of fire, electric shock, personal injury and material damage.
Read the whole manual carefully and make sure you know how to switch the tool off in an emergency, before
operating the tool.
Save these instructions and other documents supplied with this tool for future reference.
The manufacturer cannot accept any liability for damage or accidents which arise due to a failure to follow these
instructions and the safety information.
This product has been designed for 230V and 240V only. Always check that the power supply corresponds to the voltage
on the rating plate.
If the supply cord is damaged, it must be replaced by an electrician or a power tool repairer in order to avoid a hazard.
Note: The supply of 230V and 240V is interchangeable for Australia and New Zealand. This tool is double
insulated in accordance with AS/NZS 62841-1; therefore no earth wire is required.
The power supply for this product should be protected by a residual current device (rated at 30mA or less). A residual
current device reduces the risk of electric shock.
If the supply cord is damaged, it must be replaced by an electrician or a power tool repairer in order to avoid a hazard.
This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use
of the appliance by a person responsible for their safety.
Note: Double insulation does not take the place of normal safety precautions when operating this tool. The insulation
system is for added protection against injury resulting from a possible electrical insulation failure within the tool.
Using an Extension Lead
Always use an approved extension lead suitable for the power input of this tool. Before use, inspect the extension lead
for signs of damage, wear and ageing. Replace the extension lead if damaged or defective. When using an extension
lead on a reel, always unwind the lead completely. Use of an extension lead not suitable for the power input of the tool or
which is damaged or defective may result in a risk of fire and electric shock.
WARNING! Read all safety warnings and all instructions. Failure to follow the warnings and
instructions may result in electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference.
The term “power tool” in the warnings refers to your mains-operated (corded) power tool or battery-operated (cordless)
power tool.
1. Work area safety
a. Keep work area clean and well lit. Cluttered or dark areas invite accidents.
b. Do not operate power tools in explosive atmospheres, such as in the presence of flammable liquids,
gases or dust. Power tools create sparks
which may ignite the dust or fumes.
c. Keep children and bystanders away while operating a power tool. Distractions can cause you to lose control.
2. Electrical safety
a. Power tool plugs must match the outlet. Never modify the plug in any way.
Do not use any adapter plugs with earthed (grounded) power tools. Unmodified plugs and matching outlets
will reduce risk of electric shock.
b. Avoid body contact with earthed or grounded surfaces, such as pipes, radiators, ranges and
refrigerators. There is an increased risk of electric shock
if your body is earthed or grounded.
c. Do not expose power tools to rain or wet conditions. Water entering a power tool will increase the risk of
electric shock.
d. Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the power tool. Keep cord
away from heat, oil, sharp edges or moving parts. Damaged or entangled cords increase the risk of electric
shock.
e. When operating a power tool outdoors, use an extension cord suitable
for outdoor use. Use of a cord suitable for outdoor use reduces the risk of electric shock.
f. If operating a power tool in a damp location is unavoidable, use a residual current device (RCD)
protected supply. Use of an RCD reduces the risk of electric shock.
3. Personal safety
a. Stay alert, watch what you are doing and use common sense when operating a power tool. Do not use
a power tool while you are tired or under the influence of drugs, alcohol or medication. A moment of
inattention while operating power tools may result in serious personal injury.
b. Use personal protective equipment. Always wear eye protection. Protective equipment such as dust mask,
non-skid safety shoes, hard hat, or hearing protection used for appropriate conditions will reduce personal injuries.
c. Prevent unintentional starting. Ensure the switch is in the off-position before connecting to power
source and/or battery pack, picking up or carrying the tool. Carrying power tools with your finger on the
switch or energising power tools that have the switch on invites accidents.
d. Remove any adjusting key or wrench before turning the power tool on. A wrench or a key left attached to a
rotating part of the power tool may result in personal injury.
e. Do not overreach. Keep proper footing and balance at all times. This enables better control of the power tool
in unexpected situations.
f. Dress properly. Do not wear loose clothing or jewellery. Keep your hair, clothing and gloves away from
moving parts. Loose clothes, jewellery or long hair can be caught in moving parts.
g. If devices are provided for the connection of dust extraction and collection facilities, ensure these are
connected and properly used. Use of dust collection can reduce dust-related hazards.
h. Do not let familiarity gained from frequent use of tools allow you to become complacent and ignore tool
safety principles. A careless action can cause severe injury within a fraction of a second.
4. Power tool use and care
a. Do not force the power tool. Use the correct power tool for your application. The correct power tool will do
the job better and safer at the rate for which it was designed.
b. Do not use the power tool if the switch does not turn it on and off. Any power tool that cannot be controlled
with the switch is dangerous and must be repaired.
c. Disconnect the plug from the power source and/or the battery pack from the power tool before making
any adjustments, changing accessories, or storing power tools. Such preventive safety measures reduce the
risk of starting the power tool accidentally.
d. Store idle power tools out of the reach of children and do not allow persons unfamiliar with the power
tool or these instructions to operate the power tool. Power tools are dangerous in the hands of untrained
users.
e. Maintain power tools. Check for misalignment or binding of moving parts, breakage of parts and any
other condition that may affect the power tool’s operation. If damaged, have the power tool repaired
before use. Many accidents are caused by poorly maintained power tools.
f. Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp cutting edges are less likely to
bind and are easier to control.
g. Use the power tool, accessories and tool bits etc. in accordance with these instructions, taking into
account the working conditions and the work to be performed. Use of the power tool for operations different
from those intended could result in a hazardous situation.
h. Keep handles and grasping surfaces dry, clean and free from oil and grease. Slippery handles and grasping
surfaces do not allow for safe handling and control of the tool in unexpected situations.
5. Service
a. Have your power tool serviced by a qualified repair person using only identical replacement parts. This
will ensure that the safety of the power tool
is maintained.
b. If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly
qualified persons in order to avoid a hazard.
• Keep all parts of the body away from the saw chain when the chain saw is operating. Before you
start the chain saw, make sure the saw chain is not contacting anything. A moment of inattention while
operating chain saws may cause entanglement of your clothing or body with the saw chain.
• Always hold the chain saw with your right hand on the rear handle and your left hand
on the front handle. Holding the chain saw with a reversed hand configuration increases the risk of personal
injury and should never be done.
• Hold the power tool by insulated gripping surfaces only, because the saw chain may contact hidden
wiring or its own cord. Saw chains contacting as a “live“ wire may make exposed metal parts of the tool “live”
and could give the operator an electric shock.
• Wear eye protection. Further protective equipment for hearing, head, hands, legs and feet is
recommended. Adequate protective equipment will reduce personal injury from flying debris or accidental
contact with the saw chain.
• Do not operate a chain saw in a tree, on a ladder, from a rooftop, or any unstable support. Operation of
a chain saw in this manner could result in serious personal injury.
• Always keep proper footing and operate the chain saw only when standing on fixed, secure and level
surface. Slippery or unstable surfaces such as ladders may cause a loss of balance or control of the chain saw.
• When cutting a limb that is under tension be alert for spring back. When the tension in
the wood fibres is released the spring loaded limb may strike the operator and/or throw the chain saw out of
control.
• Use extreme caution when cutting brush and saplings. The slender material may catch
the saw chain and be whipped toward you or pull you off balance.
• Carry the chain saw by the front handle with the chain saw switched off and away from your body.
When transporting or storing the chain saw always fit the guide bar cover. Proper handling of the chain
saw will reduce the likelihood of accidental contact with the moving saw chain.
• Follow instructions for lubricating, chain tensioning and changing the bar and chain. Improperly
tensioned or lubricated chain may either break or increase the chance for kickback.
• Cut wood only. Do not use chain saw for purposes not intended. For example: do not use chain saw
for cutting plastic, masonry or non-wood building materials. Use of the chain saw for operations different
than intended could result in a hazardous situation.
• Do not attempt to fell a tree until you have an understanding of the risks and how to avoid them.
Serious injury could occur to the operator or bystanders while felling a tree. Felling a tree will require a larger work
area. Ensure the work area is adequate while felling a tree.
Causes and operator prevention of kickback
Kickback may occur when the nose or tip of the guide bar touches an object, or when the wood closes in and
pinches the saw chain in the cut.
Tip contact in some cases may cause a sudden reverse reaction, kicking the guide bar up and back towards the
operator.
Pinching the saw chain along the top of the guide bar may push the guide bar rapidly back towards the operator.
Either of these reactions may cause you to lose control of the saw which could result in serious personal injury. Do
not rely exclusively upon the safety devices built into your saw. As a chain saw user, you should take several steps to
keep your cutting jobs free from accident or injury.
Kickback is the result of tool misuse and/or incorrect operating procedures or conditions and can be avoided by
taking proper precautions as given below:
• Maintain a firm grip, with thumbs and fingers encircling the chain saw handles, with both hands on
the saw and position your body and arm to allow you to resist kickback forces. Kickback forces can be
controlled by the operator, if proper precautions are taken. Do not let go of the chain saw.
• Do not overreach and do not cut above shoulder height. This helps prevent unintended tip contact and
enables better control of the chain saw in unexpected situations.
• Only use replacement bars and chains specified by the manufacturer. Incorrect replacement bars and
chains may cause chain breakage and/or kickback.
• Follow the manufacturer’s sharpening and maintenance instructions for the saw chain. Decreasing the
depth gauge height can lead to increased kickback.
ADDITIONAL SAFETY INSTRUCTIONS FOR CHAINSAWS
