Ozito IDL-018 User manual

Battery power: 18V
Charge time: 3 – 5 hours
No load speed: 0-2000/min
Impact speed: 0 - 3000bpm
Torque: 120Nm
Drive: 6.35mm (1/4”) hex shank
Battery: 18V - 1.3Ah Lithium Ion
Weight with 1 battery: 1.35kg
WARNING! The noise level of this machine can exceed 85dB(A).
Operators are recommended to use hearing protection devices.
1
6
810
3
9
SPECIFICATIONS – MODEL NO. IDL-018
1
KNOW YOUR PRODUCT
1. Driving bit retaining ring
2. Variable speed trigger switch
3. Forward/Reverse selector
4. LED light
5. Battery charge indicator
6. Battery
7. Battery release button
8. Charger adaptor
9. Charger jack
10. Charging cradle
7
2
!
!
4
5

2
TABLE OF CONTENTS
SPECIFICATIONS ………………………………………..
INTRODUCTION…………………………………………
ELECTRICAL SAFETY…………….………………………
GENERAL POWER TOOL SAFETY WARNINGS………
IMPACT DRIVER SAFETY WARNINGS……………………
LITHIUM ION BATTERY AND CHARGER
SAFETY FEATURES…………….…………………………
CHARGING YOUR LITHIUM ION BATTERY..…………
ASSEMBLY...….….….….….….….….….….….….………
IMPACT DRIVER OPERATION………………………….
MAINTENANCE…………….……………………………
SPARE PARTS …………….……………………………...
DESCRIPTION OF SYMBOLS ………………………….
PACK CONTENTS ………………………………………
WARRANTY………………………………………………
Page 1
Page 3
Page 3
Page 4
Page 7
Page 9
Page 10
Page 12
Page 13
Page 16
Page 17
Page 17
Page 18
Page 19

INTRODUCTION
3
Congratulations on purchasing an Ozito Lithium Ion Impact
Driver. We aim to provide quality tools at an affordable price.
We hope you will enjoy using this tool for many years. Your
Lithium Ion Cordless Impact Driver IDL-018 is designed to
drive and remove screws and to tighten and loosen nuts
and bolts quickly and efficiently.
It is designed to be used in a DIY (Do It Yourself) context or
for hobbyist purposes. It is not built for continuous daily use
in a trade or professional capacity.
Screwdriver and socket bit changes are “tool-free”. No tool
is required to fit either of them.
ELECTRICAL SAFETY
!
!WARNING! When using mains-powered tools, basic safety precautions,
including the following, should always be followed to reduce risk of fire,
electric shock, personal injury and material damage.
Read the whole manual carefully and make sure you know how to switch the tool
off, in an emergency, before operating the tool.
Save these instructions and other documents supplied with this machine for future
reference.
This tool is double insulated in accordance with AS/NZS 60335-1;
therefore no earth wire is required.
If the supply cord is damaged, it must be replaced by an electrician or a power
tool repairer in order to avoid a hazard.
Note: Double insulation does not take the place of normal safety precautions
when operating this tool. The insulation system is for added protection against
injury resulting from a possible electrical insulation failure within the tool.
Using an Extension Lead
Always use an approved extension lead suitable for the power input of this tool.
Before use, inspect the extension lead for signs of damage, wear and ageing.
Replace the extension lead if damaged or defective.
When using an extension lead on a reel, always unwind the lead completely. Use
of an extension lead not suitable for the power input of the tool or which is
damaged or defective may result in a risk of fire and electric shock.
It is recommended that the extension lead is a maximum of 25m in length. Do Not
use multiple extension leads.

4
GENERAL POWER TOOL SAFETY WARNINGS
WARNING! Read all safety warnings and all instructions. Failure to
follow the warnings and instructions may result in electric shock, fire and/or
serious injury.
Save all warnings and instructions for future reference.
The term “power tool" in all of the warnings refers to your mains-operated
(corded) power tool or battery-operated (cordless) power tool.
1) Work area safety
a) Keep work area clean and well lit. Cluttered or dark areas invite accidents.
b) Do not operate power tools in explosive atmospheres, such as in the
presence of flammable liquids, gases or dust. Power tools create sparks which
may ignite the dust or fumes.
c) Keep children and bystanders away while operating a power tool. Distractions
can cause you to lose control.
2) Electrical safety
a) Power tool plugs must match the outlet. Never modify the plug in any way.
Do not use any adapter plugs with earthed (grounded) power tools.
Unmodified plugs and matching outlets will reduce risk of electric shock.
b) Avoid body contact with earthed or grounded surfaces, such as pipes,
radiators, ranges and refrigerators. There is an increased risk of electric shock if
your body is earthed or grounded.
c) Do not expose power tools to rain or wet conditions. Water entering a power
tool will increase the risk of electric shock.
d) Do not abuse the cord. Never use the cord for carrying, pulling or unplugging
the power tool. Keep cord away from heat, oil, sharp edges or moving parts.
Damaged or entangled cords increase the risk of electric shock.
e) When operating a power tool outdoors, use an extension cord suitable for
outdoor use. Use of a cord suitable for outdoor use reduces the risk of
electric shock.
f) If operating a power tool in a damp location is unavoidable, use a residual
current device (RCD) protected supply. Use of an RCD reduces the risk of
electric shock.
3) Personal safety
a) Stay alert, watch what you are doing and use common sense when operating
a power tool. Do not use a power tool while you are tired or under the
influence of drugs, alcohol or medication. A moment of inattention while
operating power tools may result in serious personal injury.
b) Use personal protective equipment. Always wear eye protection. Protective
equipment such as dust mask, non-skid safety shoes, hard hat, or hearing
protection used for appropriate conditions will reduce personal injuries.
c) Prevent unintentional starting. Ensure the switch is in the off-position before
connecting to power source and/or battery pack, picking up or carrying the
tool. Carrying power tools with your finger on the switch or energising power
tools that have the switch on invites accidents.
!
!
!
!

5
GENERAL POWER TOOL SAFETY WARNINGS
!
!
d) Remove any adjusting key or wrench before turning the power tool on. A
wrench or a key left attached to a rotating part of the power tool may result in
personal injury.
e) Do not overreach. Keep proper footing and balance at all times. This
enables better control of the power tool in unexpected situations.
f) Dress properly. Do not wear loose clothing or jewellery. Keep your hair,
clothing and gloves away from moving parts. Loose clothes, jewellery or
long hair can be caught in moving parts.
g) If devices are provided for the connection of dust extraction and
collection facilities, ensure these are connected and properly used. Use of
dust collection can reduce dust-related hazards.
4) Power tool use and care
a) Do not force the power tool. Use the correct power tool for your
application. The correct power tool will do the job better and safer at the rate
for which it was designed.
b) Do not use the power tool if the switch does not turn it on and off. Any
power tool that cannot be controlled with the switch is dangerous and must
be repaired.
c) Disconnect the plug from the power source and/or the battery pack from
the power tool before making any adjustments, changing accessories, or
storing power tools. Such preventive safety measures reduce the risk of
starting the power tool accidentally.
d) Store idle power tools out of the reach of children and do not allow
persons unfamiliar with the power tool or these instructions to operate
the power tool. Power tools are dangerous in the hands of untrained users.
e) Maintain power tools. Check for misalignment or binding of moving parts,
breakage of parts and any other condition that may affect the power
tool's operation. If damaged, have the power tool repaired before use.
Many accidents are caused by poorly maintained power tools.
f) Keep cutting tools sharp and clean. Properly maintained cutting tools with
sharp cutting edges are less likely to bind and are easier to control.
g) Use the power tool, accessories and tool bits etc. in accordance with
these instructions, taking into account the working conditions and the
work to be performed. Use of the power tool for operations different from
those intended could result in a hazardous situation.
5) Service
a) Have your power tool serviced by a qualified repair person using only
identical replacement parts. This will ensure that the safety of the power tool
is maintained.
b) If the supply cord is damaged, it must be replaced by the manufacturer, its
service agent or similarly qualified persons in order to avoid a hazard.

6
BATTERY AND CHARGER SAFETY WARNINGS
!
!
THIS MANUAL CONTAINS IMPORTANT SAFETY AND OPERATING INSTRUCTIONS
FOR YOUR BATTERY CHARGER.
• Before using the charger read all instructions and cautionary markings on the
charger, battery pack and the product using the battery pack.
Danger! If the battery pack case is cracked or damaged, do not insert it
into charger. There is a danger of electric shock or electrocution.
WARNIING! Do not allow any liquid to get inside charger. Electric shock may
result. To facilitate cooling of the battery pack after use, avoid placing the
charger or battery pack in a warm environment such as in a metal shed, or an
uninsulated trailer.
• This charger is not intended for any uses other than charging rechargeable
batteries. Any other use may result in risk of fire, electric shock or electrocution.
• Do not place any object on top of the charger or place the charger on a soft
surface that may result in excessive internal heat. Place the charger in a position
away from any heat source.
• To reduce risk of damage to the electric plug and cord, pull by the plug rather than
the cord when disconnecting the charger.
• Make sure the cord is located so that it will not be stepped on, tripped over, or
otherwise subjected to damage or stress.
•An extension cord should not be used unless absolutely necessary. Use of an
improper extension cord could result in the risk of fire, electric shock or
electrocution.
• Do not operate the charger if it has received a sharp blow, been dropped or
otherwise damaged in any way. Have it checked by an electrician or power
tool repairer.
•Do not disassemble charger. Take it to an electrician or power tool repairer when
service or repair is required. Incorrect reassembly may result in a risk of electric
shock, electrocution or fire.
• To reduce risk of electric shock, unplug the charger from the outlet before
attempting any cleaning. Removing the battery pack will not reduce this risk.
•Never attempt to connect 2 chargers together.
• DO NOT store or use the tool and battery pack in locations where the temperature
may reach or exceed 40ºC (such as inside sheds or metal buildings in summer).
•The charger is designed to operate on standard household electrical power (240
volts). Do not attempt to use it on any other voltage!
•The battery pack is not fully charged out of the carton. First read the safety
instructions and then follow the charging notes and procedures.
!
!
!
!

7
BATTERY AND CHARGER SAFETY WARNINGS
!
!
• The longest life and best performance can be obtained if the battery pack is
charged when the air temperature is between 18 - 24ºC. Do not charge the
battery pack in an air temperature below 10ºC or above 40ºC. This is
important and will prevent damage to the battery pack.
• Do not incinerate the battery pack even if it is seriously damaged or is
completely worn out. The battery can explode in a fire.
• Never attempt to open the battery pack for any reason. If the plastic housing
of the battery pack breaks or cracks, immediately discontinue use and do
not recharge.
• During charging, the battery must be placed in a well ventilated area.
This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction concerning
use of the appliance by a person responsible for their safety.
Children should be supervised to ensure that they don't play with the appliance.
Recommendations for the use of a residual current device with a rated residual
current of 30mA or less.
Using an Extension Lead
Always use an approved extension lead suitable for the power input of this tool.
Before use, inspect the extension lead for signs of damage, wear and ageing.
Replace the extension lead if damaged or defective.
When using an extension lead on a reel, always unwind the lead completely. Use
of an extension lead not suitable for the power input of the tool or which is
damaged or defective may result in a risk of fire and electric shock.
It is recommended that the extension lead is a maximum of 25m in length. Do
Not use multiple extension leads.
•Hold power tool by insulated gripping surfaces, when performing an
operation where the cutting accessory may contact hidden wiring or its
own cord. Cutting accessory contacting a "live" wire may make exposed metal
parts of the power tool "live" and could give the operator an electric shock.•
Do not use the drill in wet or damp conditions.
• Wear ear protectors when impact drilling. Exposure to noise can cause
hearing loss.
• Wear a hard hat (safety helmet), safety glasses and/or face shield. It is also highly
recommended that you wear a dust mask, ear protection and padded gloves.
•Hold the power tool with a firm grip. High reaction torque can briefly occur while
driving and loosening screws.
IMPACT DRIVER SAFETY WARNINGS!
!
!

8
IMPACT DRIVER SAFETY WARNINGS! (cont.)
!
!
• Secure the work piece. A work piece clamped with clamping devices or in a vice, is
held more secure than by hand.
• One-handed operation is extremely dangerous. Hold the unit firmly with both hands
when operating the tool.
• After installing the driver bit, pull lightly on the bit to make sure that it does not come
loose. If the bit is not installed properly, it can come loose during use, which can be
dangerous.
• Use a bit that matches the screw.
• Tighten the screw with the impact driver lined straight with the screw to prevent the
screw head from being damaged and to ensure the proper force is delivered.
• Hold the power tool with a firm grip. High reaction torque can briefly occur while
tightening and loosening nuts and bolts.
• Check that any socket to be used is not cracked or broken. Broken or cracked sockets
are dangerous.
• If the ring securing the socket is damaged, the socket may come off during use
causing personal injury.
• Check the tightening torque. The appropriate torque for tightening a bolt depends
on the bolt material, its dimensions and grade and other factors.
• The torque delivered by the impact driver depends on how long it is applied, the
size of socket and other factors such as the sate of the battery (4) charge.
•Use a torque wrench to check that the bolt has been tightened to the appropriate
level of torque.
•Stop the impact driver before changing the direction of rotation. Always release
the trigger switch and wait for the impact wrench to stop before switching the
direction of rotation.
• Never touch the socket whilst it is turning. Do not let the turning socket get near
your hands or any other part of your body. You could be cut or caught up in the
socket.
• Do not touch the socket after it has been in use for an extended period. It could
be hot and burn you.

9
LITHIUM ION BATTERY AND CHARGER SAFETY
Over Charging Protection
This feature ensures that the battery (6) is never overcharged. When the battery (4)
has reached its full charge capacity the charger will shut off protecting the internal
components of the battery (6) from being damaged.
Over Discharge Protection
The battery (6) includes an over discharge protector. This feature stops the battery
(6) from discharging beyond the recommended lowest safety voltage.
Over Heat Protection
The battery (6) has an internal thermal cut-out device that stops the charging cycle
if the battery (6) becomes hot during the charging process. This thermal cut-out
device also stops the battery (6) from operating should the battery (6) become too
hot during the operation of the tool. This can happen when the tool is overloaded
or being used for extended periods of time.
Up to 30 minutes cooling time may be required depending on ambient
temperature and the operation being performed.
Over Current Protection
If the battery (6) is overloaded and the maximum current draw is exceeded the
battery will temporarily stop working to protect the internal components. The
battery (6) will resume normal operation once the current draw has returned to its
normal safe level. This may take a few seconds.
Short Circuit Protection
If the battery (6) short circuits, the short circuit protector immediately stops the
battery (6) from operating.
This ensures that no internal components of the battery (6) or tool are damaged.

CHARGING YOUR LITHIUM ION BATTERY
10
The batteries (6) have been shipped in a low charge condition, and requires charging
prior to use.
• Connect the charger jack (9) to the charging cradle (10)
(Fig. 1).
• Plug the charger adaptor (8) into a mains power outlet.
• The green light on the charging cradle (10) will
illuminate showing that power is being supplied to the
charging cradle (10).
• With the charging cradle (10) sitting flat on a
bench/table, insert the battery (6) into the recess of the
battery terminals ensuring a firm connection (Fig. 2).
• The battery (6) fits in one direction only. If you need to
force the connection it means the battery (6) is facing
the wrong way.
•When the battery (6) is properly seated, the red light on
the charging cradle (10) will illuminate if the battery (6) is
partially or fully discharged, signifying that the battery (6) is charging.
• When the battery (6) is fully charged, the red light will extinguish signifying that the
battery (6) is fully charged.
• A battery takes 3 - 5 hours to charge. Charging starts automatically when the
battery is connected to the charger. Remove the battery (6) from the charging
cradle (10) after 5 hours.
Initial Charge
• The battery (6) will not reach its full charge the first time it is charged.
• The green LED will remain illuminated until the charger is disconnected from the
mains power outlet.
• Allow several charging cycles of charging and then discharging (through use of the
tool) for the battery (6) to reach its maximum charge.
Caution: Disconnect the charger adaptor from the mains power when charger is not
in use.
Note: If the light on the charging cradle (10) fails to come on:
- Check the charger adaptor (8) is securely plugged into the mains power
outlet and switched on.
- Check the battery (6) is firmly seated onto the charging cradle (10).
- Check the charger jack (9) is securely connected into the charging cradle (10) socket.
Fig. 1
Fig. 2
Charger
jack

Subsequent Charges
• After normal usage, approximately 3-5 hours of charging time is required to
fully recharge the battery (6).
• If the battery (6) is completely discharged, 5 hours or longer of charging time
will be required to fully recharge it.
Important Charging Notes
• The charger adaptor (8) and battery (6) may become warm to touch while
charging. This is a normal condition, and does not indicate a problem.
• Use the charger at normal room temperature whenever possible. To prevent
overheating, do not cover the charger and do not charge the battery (6) in
direct sunlight or near heat sources.
• If the battery (6) does not charge properly:
- Check current at mains power outlet by plugging in a lamp or other appliance.
- If charging problems persist, have the complete tool checked by an electrician
or a power tool repairer.
•If the light on the charging cradle (10) fails to come on:
- Check the charging cradle (10) is securely plugged into the mains power outlet
and is switched on.
- Check that the battery (6) is firmly seated onto the charging cradle (10).
- Check that the charger jack (9) is securely connected into the charging
cradle socket.
Thermal Voltage Protection Indication
In the event that the thermal or voltage protection circuit has been activated the
battery (6) will cease to operate. This can happen when the tool has been used for
extended periods or worked hard with large drill bits or accessories.
If you place the battery (6) on the charging cradle (10) the LED Lights will give you
the appearance that the battery is fully charged. Leave the battery (6) in the
charging cradle (10) to charge for 3-5 hours.
The battery (6) may take the full 5 hours to charge, as the battery (6) may need to
cool down or the protection circuits to be reset. This will allow the charger to
begin charging the battery (6) and resume normal operation.
CHARGING YOUR LITHIUM ION BATTERY (cont.)
11

12
ASSEMBLY
Always ensure the forward/reverse selector (3) is in the lock position before
removing or inserting the battery (6). By pushing the forward/reverse lever (3)
into the middles of both forward and reverse the variable speed switch (2) will
be in the lock position.
Installing the Battery
• Holding the impact driver upright and picking up
the battery (6) in your opposite hand. Insert the
battery (6) until it clicks into place (Fig. 3).
• Do not use excessive force when inserting the battery (6).
If the battery (6) does not slide in easily, it is not being
inserted correctly and could cause damage to the
battery (6), battery (6) terminals or the impact driver.
• Do not operate the variable speed trigger switch (2) whilst
inserting the battery (6).
Removing the Battery
Depress the battery release button (7) and pull the battery (6) down away from the tool.
Getting the Best Performance from the Battery
The length of service from each charging cycle will depend on the type of
work undertaken.
To obtain the longest possible battery life, we suggest the following:
• Store and charge your batteries in a cool area. Temperatures above or below
normal room temperature will shorten battery life.
•Never store batteries in a discharged condition. Recharge them immediately after
they are discharged.
•All batteries gradually lose their charge. The higher the temperature the quicker
they lose their charge. If you store your drill for long periods of time without using
it, recharge the batteries every month or two. This practice will prolong battery life.
Fig. 3

13
IMPACT DRIVER OPERATION
!
!
!
!
WARNIING! Remove the battery (4) from the tool before inserting or
removing a bit or when making any adjustments to your tool.
Installing a driver bit
Pull the driving bit retaining ring (1) forward and insert
the hex shank of the appropriate driver bit into the
driving bit retaining ring (1) (Fig. 4).
Release the driving bit retaining ring (1) and slowly pull
the driving bit forward until you feel the ring engage
with the groove in the bit indicating that the bit is
locked in position. (Fig. 5).
Check if the bit is correctly fitted by pulling on the bit
to see if it can be removed. (Fig. 6). If it cannot be
extracted out of the driving bit retaining ring (1) , the
bit has been inserted correctly.
WARNIING! If the driving bit is not properly secured it may be ejected
unexpectedly during operation. This could potentially cause serious
personal injury or injury to others. Always ensure the driving bit is
secured properly before beginning operation.
Driving bit removal
Pull the driving bit retaining ring (1) forward and
remove the driving bit (Fig. 7). Release the driving bit
retaining ring (1).
Fig. 4
Fig. 5
Fig. 6
Fig. 7

14
IMPACT DRIVER OPERATION (cont.)
Installing a socket adaptor and socket (not included)
Pull the driving bit retaining ring (1) forward and insert the
hex shank of the socket adaptor into the retaining ring (1).
(Fig. 8).
Release the driving bit retaining ring (1) and slowly pull the
socket adaptor forward until you feel the ring engage with
the groove in the adaptor indicating that the adaptor is
locked in position. Check if the socket adaptor is correctly
fitted by pulling on the adaptor to see if it can be removed.
If it cannot be extracted, the adaptor has been inserted
correct (Fig. 9).
Select the correct socket for the nut or bolt you which to
tighten or loosen. A socket that is too large will result in
slippage or inaccurate and inconsistent torque, or damage
to the nut or head of the bolt.
Insert the square end of the socket bit into the socket
adaptor (Fig. 10).
Turning the tool on and off
To turn the tool on, slowly depress the variable speed
trigger switch (2). (Fig. 11). Release the variable speed
trigger switch (2) to stop the tool.
Variable speed
You can vary the speed of the impact driver by controlling
the amount of pressure applied to the variable speed
trigger switch (2). The tool reaches its top speed when the
trigger switch (2) is fully depressed. (Fig. 12).
Fig. 8
Fig. 9
Fig. 10
Fig. 11
Fig. 12

Changing the direction of rotation
• The direction of rotation can be changed with the
forward/reverse selector (3). This is located above
the variable speed trigger switch (2) (Fig. 13).
• To select the forward driving or tightening position,
push the forward/reverse selector (3) hard left.
• To select the reverse driving or loosening position
push the forward/reverse selector (3) hard right.
• The variable speed trigger switch (2) can be locked off by pushing the
forward/reverse selector (3) into the middle of both forward and reverse
positions.
WARNIING! Do not change direction of rotation unless the tool has
come to a complete stop.
Using the tool
Insert the correct driving bit or socket bit (with socket adaptor).
Before starting your job, always perform a test operation in a scrap piece of
material.
When fastening screws sized M8 or smaller, take particular care to use light
pressure on the variable speed trigger switch (2) for fear of damaging the fixture.
Hold the tool pointing straight in line with the fastener
and apply sufficient forward pressure to stop the bit
from slipping off the fastener (Fig. 14).
Apply slight pressure to the variable speed trigger
switch (2) to turn on the tool then increase the speed
according to the circumstances.
Do not apply torque for too long when tightening a
screw or nut or it will be damaged.
Note: The correct fastening or loosening torque will vary according to the size and
type of fastener, the material in which the fastener is inserted and the state of the
battery charge.
Note: The tool has a “sleep” mode that helps to extend the run time of the
battery (6). After a period of non-use, the tool will hesitate slightly before starting.
This indicates that the battery (6) is coming out of “sleep” mode and is normal.
IMPACT DRIVER OPERATION (cont.)
15
Fig. 14
Fig. 13
!
!

16
IMPACT DRIVER OPERATION (cont.)
MAINTENANCE
Battery Charge Indicator
• The impact driver is equipped with a battery charge
indicator (5) to show the state of the battery charge
(Fig. 15).
• Press the variable speed switch (2).
• Look to see which LED lights are illuminated (Fig. 15).
• When all three lights are illuminated, this indicates that
the battery (6) is fully charged and ready to use.
Note: The green LED light will slowly fade as it looses charge.
• The green LED light then goes off and only the orange and red LED lights are
illuminated. This indicates that the battery has only low charge and requires
charging soon.
• When ONLY the red LED light is illuminated, this indicates that the battery (6)
requires immediate charging.
LED Light
• The impact driver has 1 built-in LED light (4). The LED is
located above the battery charge indicator (5) (Fig. 16).
• The LED light (4) illuminates automatically when you
depress the variable speed switch (2).
• The LED light illuminate dark areas in tight corners to
assist with screw driving. This help you see the work
piece to achieve more accurate results.
• When not in use, the tool should be stored in a dry, frost free location, out of
reach of children.
• Keep ventilation slots of the tool clean at all times and prevent any foreign matter
from entering.
•If the housing of the tool requires cleaning, do not use solvents but a moist soft
cloth only.
• Blow out the ventilation slots with compressed air periodically.
Note: Ozito Industries will not be responsible for any damage or injuries caused by
repair of the tool by an unauthorised person or by mishandling of the tool.
Fig. 15
Fig. 16
Battery charge
indicator
LED light

SPARE PARTS
17
DESCRIPTION OF SYMBOLS
Warning Read instruction manual
ø Diameter
mA Milliamperes
Recycle battery Do not put in the rubbish
Polarity
Do not incinerate Donot get battery wet
Thermal cut-out protection
Transformer Energy
Rating (MEPS)
Double insulated
/min Revolutions or
reciprocation per minute
Ah Amp hour
Indoor use only
Lithium Ion battery Do not use or store battery in
temperatures exceeding 50ºC
Electrical Emissions
Conformity (EMC)
IPM Impacts per minute Nm Newton Meters
n o No load speed
VVolts Hz Hertz
ac/~ Alternating current WWatts
Direct current
dc/
Limited spare parts are available subject to availability. Please contact your local
Bunnings Special Orders Desk to order the required spare parts.
Most common spare parts listed below
Spare Part Part No.
18V Battery Pack SPCDL018-37
Charging Stand SPCDL018-38
Charging Adaptor SPCDL018-39

1 x 18V Li-Ion Impact Driver
1 x Socket Adaptor
1 x Slow Charger
1 x Instruction manual
* Accessories Included
AUSTRALIA (Head Office)
1 - 23 Letcon Drive, Bangholme, Victoria, Australia 3175
Telephone: [phone]
Facsimile: [phone]
Website: www.ozito.com.au
Email: [email protected]
Power tools that are no longer usable should not be
disposed of with household waste but in an environmentally
friendly way. Please recycle where facilities exist. Check with
your local council authority for recycling advice.
Recycling packaging reduces the need for landfill and raw
materials. Reuse of recycled material decreases pollution in the
environment. Please recycle packaging where facilities exist.
Check with your local council authority for recycling advice.
CARING FOR THE ENVIRONMENT
PACK CONTENTS
OZITO INDUSTRIES PTY LTD
18

WARRANTY
THIS WARRANTY FORM AND CONFIRMED BUNNINGS REGISTER RECEIPT SHOULD
BE RETAINED BY THE CUSTOMER AT ALL TIMES
The warranty is only made available by returning the product to your nearest
Bunnings Warehouse with a confirmed Bunnings register receipt.
PURCHASED FROM:________________________________________________
DATE PURCHASED: ________________________________________________
3 YEAR REPLACEMENT WARRANTY
Your Ozito tool is guaranteed for a period of 36 months from the original date of
purchase and is intended for DIY (Do it yourself) use only.
The Lithium Ion battery is covered by a 12 month warranty.
WARNING
The following actions will result in the warranty being void.
• Trade, professional, industrial or high frequency use.
• If the tool has been operated on a supply voltage other than that specified on
the tool.
•If the tool shows signs of damage or defects caused by or resulting from abuse,
accidents or alterations.
• If the tool is disassembled or tampered with in any way.
Note: Warranty excludes consumable parts such as carbon brushes, drill and driver
bits and chucks.
YOUR WARRANTY FORM SHOULD BE RETAINED
BY YOU AT ALL TIMES.
SHOULD YOU HAVE ANY QUESTIONS PRIOR TO
RETURNING YOUR PRODUCT FOR WARRANTY OR
REPAIR PLEASE TELEPHONE OUR CUSTOMER
SERVICE HELPLINE:
Australia 1800 069 486
New Zealand 0508 069 486
TO ENSURE A SPEEDY RESPONSE PLEASE HAVE THE MODEL NUMBER
AND DATE OF PURCHASE AVAILABLE. AN OZITO CUSTOMER SERVICE
REPRESENTATIVE WILL TAKE YOUR CALL AND ANSWER ANY QUESTIONS
YOU MAY HAVE RELATING TO THE WARRANTY POLICY OR PROCEDURE.
