Ozito XU1 XLMS-018 User manual

Ozito Industries Pty Ltd. 25 Fox Drive, Dandenong South, Victoria, Australia 3175
Telephone: [phone] (Aus), 0508 069 486 (NZ)
XU1 Power tools
XLMS-018 0822
Operating Instructions
XLMS-018
18V18V
Brushless LawnBrushless Lawn
MowerMower

SAFETY
INSTRUCTIONS
1
GENERAL
MACHINE
SAFETY
WARNINGS
ELECTRICAL
SAFETY
Description of symbols
CARING FOR THE
ENVIRONMENT
Power tools that are no longer usable
should not be disposed of with household
waste but in an environmentally friendly
way.
Please recycle where facilities exist.
Check with your local council authority for
recycling advice.
Check with your local council authority for recycling
advice.
Recycling packaging reduces the need
for landll and raw materials. Reuse of
recycled material decreases pollution in
the environment. Please recycle packaging
where facilities exist.
Read instruction manual
V Volts
Hz Hetz
a.c./~ Alternating current
WWatts
dc/ Direct current
Ø Diameter
mA Milliamperes
noNo load speed
/min Revolutions or reciprocation per minute
Nm Newton meters
IPX1 Ingress protection from water
Ah Amp hour
mm Millimetre
Double insulated
Regulator compliance mark
Always keep the lawn mower on the ground
when mowing. Tilting or lifting the lawn
mower may cause stones to be thrown out.
Keep bystanders away. Do not mow whilst
people especially children or pets are in the
mowing area.
Beware of severing toes or hands. Do not
put hands or feet near a rotating blade.
Wear hearing and eye protection.
Do not mow in the rain or leave the lawn
mower outdoors while raining.
Pull out Safety Key before carrying out any
repair work.
Sound power level 95 dB
Read the whole manual carefully and make sure
you know how to switch the tool or machine off in an
emergency, before operating the tool or machine.
Save these instructions and other documents
supplied with this tool or machine for future
reference.
Refer to the XU1 battery and charger instruction
manuals for information regarding charging, use and
storage.
-This equipment is battery-operated and the battery
must be charged outside the equipment.
WARNING! Read all safety
warnings, instructions, illustrations
and specications provided with
this machine. Failure to follow all instructions listed
below may result in electric shock, re and/or serious
injury.
Save all warnings and instructions for
future reference.
The term “machine” in the warnings refers to your
mains-operated (corded) machine or battery-operated
(cordless) machine.
1) Work area safety
a) Keep work area clean and well lit.
Cluttered or dark areas invite accidents.
b) Do not operate machines in explosive
atmospheres, such as in the presence
of ammable liquids, gases or dust.
Machines create sparks which may ignite the dust
or fumes.
c) Keep children and bystanders away
while operating a machine. Distractions can
cause you to lose control.
2) Electrical safety
a) Machine plugs must match the outlet.
Never modify the plug in any way. Do
not use any adapter plugs with earthed
(grounded) machines. Unmodied plugs and
matching outlets will reduce risk of electric shock.
b) Avoid body contact with earthed or
grounded surfaces, such as pipes,
radiators, ranges and refrigerators. There
is an increased risk of electric shock if your body is
earthed or grounded.
c) Do not expose machines to rain or
wet conditions. Water entering a machine will
increase the risk of electric shock.
d) Do not abuse the cord. Never use the
cord for carrying, pulling or unplugging
the machine. Keep cord away from
heat, oil, sharp edges or moving parts.
Damaged or entangled cords increase the risk of
electric shock.
e) When operating a machine outdoors,
use an extension cord suitable for
outdoor use. Use of a cord suitable for outdoor
use reduces the risk of electric shock.
3) Personal safety
a) Stay alert, watch what you are doing
and use common sense when operating
a machine. Do not use a machine while
you are tired or under the inuence of
drugs, alcohol or medication. A moment of
inattention while operating machines may result in
serious personal injury.
b) Use personal protective equipment.
Always wear eye protection. Protective
equipment such as a dust mask, non-skid safety
shoes, hard hat or hearing protection used for
appropriate conditions will reduce personal injuries.
c) Prevent unintentional starting. Ensure
the switch is in the o󰀨-position before
connecting to power source and/or
battery pack, picking up or carrying the
machine. Carrying machines with your nger on
the switch or energising machines that have the
switch on invites accidents.
d) Remove any adjusting key or wrench
before turning the machine on. A wrench
or a key left attached to a rotating part of the
machine may result in personal injury.
e) Do not overreach. Keep proper footing
and balance at all times. This enables better
control of the machine in unexpected situations.
f) Dress properly. Do not wear loose
clothing or jewellery. Keep your hair
and clothing away from moving parts.
Loose clothes, jewellery or long hair can be caught
in moving parts.
g) If devices are provided for the
connection of dust extraction and
collection facilities, ensure these are
connected and properly used. Use of dust
collection can reduce dust-related hazards.
h) Do not let familiarity gained from
frequent use of machines allow you
to become complacent and ignore
machine safety principles. A careless
action can cause severe injury within a fraction of
a second.
i) Avoid using power tools and machines
for long periods of time without breaks.
Vibration from tools and machines can be
transmitted into your hands and arms.
4) Machine use and care
a) Do not force the machine. Use the
correct machine for your application.
The correct machine will do the job better and safer
at the rate for which it was designed.
b) Do not use the machine if the switch
does not turn it on and o󰀨. Any machine
that cannot be controlled with the switch is
dangerous and must be repaired.
c) Disconnect the plug from the power
source and/or remove the battery pack,
if detachable, from the machine before
making any adjustments, changing
accessories, or storing machines. Such
preventive safety measures reduce the risk of
starting the machine accidentally.
d) Store idle machines out of the reach
of children and do not allow persons
unfamiliar with the machine or these
instructions to operate the machine.
Machines are dangerous in the hands of untrained
users.
e) Maintain machines and accessories.
Check for misalignment or binding of
moving parts, breakage of parts and
any other condition that may a󰀨ect
the machine’s operation. If damaged,
have the machine repaired before use.
Many accidents are caused by poorly maintained
machines.
95

2
ADDITIONAL
SAFETY
WARNINGS FOR
LAWN MOWERS
f) Keep cutting machines sharp and clean.
Properly maintained cutting machines with sharp
cutting edges are less likely to bind and are easier
to control.
g) Use the machine, accessories and
machine bits etc. in accordance with
these instructions, taking into account
the working conditions and the work
to be performed. Use of the machine for
operations different from those intended could result
in a hazardous situation.
h) Keep handles and grasping surfaces
dry, clean and free from oil and grease.
Slippery handles and grasping surfaces do not
allow for safe handling and control of the machine in
unexpected situations.
5) Battery machine use and care
a) Recharge only with the charger
specied by the manufacturer. A charger
that is suitable for one type of battery pack may
create a risk of re when used with another battery
pack.
b) Use machines only with specically
designated battery packs. Use of any other
battery packs may create a risk of injury and re.
c) When battery pack is not in use, keep
it away from other metal objects, like
paper clips, coins, keys, nails, screws
or other small metal objects, that can
make a connection from one terminal to
another. Shorting the battery terminals together
may cause burns or a re.
d) Under abusive conditions, liquid may
be ejected from the battery; avoid
contact. If contact accidentally occurs,
ush with water. If liquid contacts eyes,
additionally seek medical help. Liquid
ejected from the battery may cause irritation or
burns.
e) Do not use a battery pack or machine
that is damaged or modied. Damaged
or modied batteries may exhibit unpredictable
behaviour resulting in re, explosion or risk of injury.
f) Do not expose a battery pack
or machine to re or excessive
temperature. Exposure to re or temperature
above 130 °C may cause explosion.
g) Follow all charging instructions and
do not charge the battery pack or
machine outside the temperature range
specied in the instructions. Charging
improperly or at temperatures outside the specied
range may damage the battery and increase the
risk of re.
6) Service
a) Have your machine serviced by a
qualied repair person using only
identical replacement parts. This will
ensure that the safety of the machine is maintained.
b) Never service damaged battery packs.
Service of battery packs should only be performed
by the manufacturer or authorized service providers.
The appliance is not to be used
by persons (including children)
with reduced physical, sensory or
mental capabilities, or lack of experience
and knowledge, unless they have been
given supervision or instruction.
Young children should be supervised
to ensure that they do not play with the
appliance.
WARNING! If not used properly this
lawn mower can be dangerous!
This lawn mower can cause serious injury
to the operator and others, the warnings and safety
instructions must be followed to ensure reasonable
safety and efciency in using this lawn mower. The
operator is responsible for following the warning and
safety and instructions in this manual and on the lawn
mower. Never use the mower unless the catcher or
guards provided by the manufacturer are in the correct
position.
1) Training
• Read the instructions carefully. Be familiar with the
controls and the proper use of the appliance.
• Never allow children or people unfamiliar with these
instructions to use the appliance. Local regulations
may restrict the age of the operator.
• Never mow while people, especially children, or
pets are nearby.
• The operator or user is responsible for accidents or
hazards occurring to other people or their property.
• Know your controls. Read the manual carefully.
Learn how to stop the motor quickly in an
emergency.
2) Preparation
• While mowing, always wear substantial footwear
and long trousers.
• Do not operate the appliance when barefoot or
wearing open sandals.
• Thoroughly inspect the area where the appliance
is to be used and remove all stones, sticks, wires,
bones, and other foreign objects. They could be
thrown by the blade.
• Before using, always visually inspect to see that
the blades, blade bolts and cutter assembly are
not worn or damaged. Replace worn or damaged
blades and bolts in sets to preserve balance.
DAMAGED BLADES AND WORN
BOLTS ARE MAJOR HAZARDS.
• On multi-bladed appliances, take care as rotating
one blade can cause other blades to rotate.
3) Operation
• Avoid using power tools and machines for long
periods of time without breaks. Vibration from tools
and machines can be transmitted into your hands
and arms.
• Mow only in daylight or in good articial light.
• Avoid operating the appliance in wet grass, where
feasible.
• Always be sure of your footing on slopes.
• Walk, never run.
• For wheeled rotary mowers, mow across the face of
slopes, never up and down.
• Exercise extreme caution when changing direction
on slopes.
• Do not mow excessively steep slopes.
• Use extreme caution when reversing or pulling the
appliance towards you.
• Never cut grass while walking backwards.
• Stop the blade(s) if the appliance has to be tilted for
transportation when crossing surfaces other than
grass, and when transporting the appliance to and
from the area to be mowed such as gravel drives,
walks or roads.
• Never operate the appliance with defective guards
or shields, or without safety devices, for example
deectors and/or grass catchers, in place.
• Start the motor according to instructions and with
feet well away from the blade(s).
• Do not tilt the appliance when starting the motor,
except if the appliance has to be tilted for starting.
In this case, do not tilt it more than absolutely
necessary and lift only the part which is away
from the operator. Always ensure that both hands
are in the operating position before returning the
appliance to the ground.
• Do not put hands or feet near or under rotating
parts. For rotary mowers, keep clear of the
discharge opening at all times.
• Never pick up or carry an appliance while the motor
is running.
• Stop the motor and remove the battery from the
machine:
- when the equipment is left unattended;
- before clearing a blockage;
- when the equipment is being checked, cleaned, or
having maintenance work done;
- after striking a foreign object. Inspect the
appliance for damage and make repairs as
necessary;
- if the appliance starts to vibrate abnormally
(check immediately).
• Do not over-speed the mower or alter governor
settings. Excessive speed is dangerous and
shortens mower life.
4) Maintenance and storage
• Keep all nuts, bolts, and screws tight to be sure the
appliance is in safe working condition.
• Check the grass catcher frequently for wear or
deterioration.
• Replace worn or damaged parts for safety.
• For cylinder mowers, be careful during adjustment
of the appliance to prevent entrapment of the
ngers between moving blades and xed parts of
the appliance.
• Store the mower in a well-ventilated room away
from naked ames such that may be found in hot
water heaters.
• Remove batteries and safety key when changing
the blade.

Start Hear
Start Hear
Left
Right
Left
Right
A B CD
1. Front Wheel
2. Battery Cover
3. Carry Handle
4. Handle Securing Knob
5. Lower Handle-Right
6. Handle Securing Set
7. On/Off Switch
8. Upper Handle
9. Lower Handle-Left
10. Catcher Flap
11. Grass Indicator
12. Grass Catcher
13. Rear Wheel
14. Cutting Deck
15. Washers x 4
16. Safety Key
17. Cable Clips x 2
3
3
4
5
6
7
10
9
1
2
8
11
12
13
14
1 Press & Hold
2
1
2
3
1
2
3
TIMBER
A
B
1 Press & Hold
2
E F
65mm Highest
3
45mm
2
25mm Lowest
1
G
H I J K
5
6
4
15
17
16

Voltage: 18V
Cutting Diameter: 300mm
Cutting Heights: 25, 45 & 65mm
No Load Speed: 2,800/min
Grass Catcher: 30 litres
Noise Rating: 95 dB
Weight: 7.94kg
SPECIFICATIONS
4
OPERATION
Grass catcher assembly
1. To assemble the grass catcher align the two halves
and push them together, one side at a time. Ensure
the two halves click together around the entire
middle section. Starting at the underside of the rear
and slowly work forward, aligning each clip one at a
time so they click in place before moving to the next.
FIG. D.
2. Place the top half of the catcher onto the assembled
lower halve assembled in step 1. Ensure the two
halves click together. Starting at the rear slowly work
forward, aligning the clips one at a time so they click
in place before moving to the next.
3. Assemble the grass catcher handle onto the opening
on the top half of the assembled grass catcher. The
handle will click into position when aligned and tted
correctly.
Fitting & removing grass
catcher
The catcher must be attached to the two hooks on the
mower housing. FIG. E.
1. Lift up the catcher ap with one hand and guide the
catcher with your other hand over the two hooks on
the mower housing.
2. Lower the grass catcher and allow it to sit in place.
Lower the catcher ap.
Note: The grass catcher ap is held against the grass
catcher by a spring.
3. To empty the grass catcher, lift the catcher ap with
one hand then lift the grass catcher with the other
hand up off the two raised hooks.
Grass indicator
The grass catcher is tted with an indicator at the rear
of the catcher to help identify when to empty.
If the indicator drops down while operating then the
grass catcher is full and needs emptying.
Cutting height adjustment
To obtain the desired cutting height, the front and rear
axles are repositioned on the underside of the mower
housing.
1. Remove the grass catcher and place the mower on
its side.
2. Pull the wheel axle away from the front of the mower.
FIG. F.
3. Locate the wheel axle into the desired cutting height
adjustment position.
Note: Make sure that front, back, left & right wheels
are located in the same cutting height adjustment
position.
Fitting lower handles
1. Connect the left side lower handle to the threaded
end on the left side of the mower housing. FIG. A.
2. Fit and secure in place with washer and handle
securing knob.
3. Proceed in the same way on the right side with the
right side lower handle.
Fitting the upper handle
1. Place the upper handle over the upper ends of the
lower handles. FIG. B.
2. From the handle securing set, t the bolts through
the inner side of the lower handles and then through
the holes in the upper handle.
3. Fit and secure in place with washer and securing
knobs over the protruding ends of the bolts.
Fitting the cord clips
1. Ensure the power cord follows the handle smoothly
from the on/off switch to the body of the mower.
2. Secure the power cord from the on/off switch to the
body of the mower by using the two cord clips. FIG. C.
PROPER USE
This tool is intended for use in a DIY (Do It Yourself)
context or for hobbyist purposes. It is not built for
continuous daily use in a trade or professional capacity.
Before using the machine, carefully read these
instructions, especially the safety rules to help ensure
that your machine always operates properly.
Before attempting to operate the machine, familiarise
yourself with the controls and make sure you know how
to stop the machine quickly in an emergency.
Save these instructions and the other documents
supplied with this machine for future reference.
ASSEMBLY
WARNING! Do not touch rotating blade.
WARNING! Ensure the mower
is switched off and the battery is
disconnected before performing any of the
following tasks.
WARNING! Only t and remove the
grass catcher when the mower is switched
off and the motor has come to a stop.
WARNING! When assembling the
grass catcher back to the mower after
emptying, always ensure there is no build
up of grass in the grass chute. A build up
of grass in the grass chute may prevent
grass from moving into the grass catcher
effectively.
PREPARATION
WARNING! Ensure the mower
is switched off and the battery is
disconnected before performing any of the
following tasks.
4. Pull the rear axle away from the mowers catcher ap.
5. Locate the wheel axle into the desire cutting height
adjustment position.
Note: Make sure that both rear right and left wheel are
located in the same cutting height adjustment position.
Cutting height positions FIG. G.
1 - 25mm (lowest)
2 - 45mm
3 - 65mm (highest)
Inserting battery and safety
key into the mower
1. Open the battery cover, carefully lifting from the
front.
2. Slide a fully changed battery into the mower aligning
the ribs so that it clicks into place.
3. Insert the safety key. FIG. H. (If the mower is not
going to be used immediately, do not insert the
safety key.)
4. Carefully close the battery cover.
Removing battery from the
mower FIG. H.
1. Open the battery cover, Press and hold the battery
release tab (A) as you remove the battery (B).
2. Carefully close the battery cover.
WARNING! Always ensure the safety
key and the battery is removed when not
in use.
WARNING! Never leave the battery
inside the mower when not in use.
WARNING! Always wear sturdy, non-
slip footwear, long trousers, safety glasses
and hearing protection when using the
equipment . Never use the equipment
barefoot or in sandals.
Switching on and o󰀨
To prevent accidental start up, the mower is tted with a
dual action switch.
1. Press and hold the lock-off button. FIG. I.
2. Pull either of the start/stop levers towards the handle
to start the mower and then release the lock-off
button. FIG. J.
3. Release the start/stop lever to stop the mower.
Mowing tips
•Make sure the lawn is clear of sticks, stones, wire
and debris; they could be thrown by the blade.
WARNING! The blade will coast after
the switch has been released. Be aware
of the necessary time it takes for the blade
to stop rotating. Do not attempt to stop the
blade.

MAINTENANCE
Removing and tting the blade
Only replace the blade with a genuine XU1
replacement blade, as this will ensure top performance
and safety under all conditions.
1. To remove the blade bolt, hold the blade rmly and
with a 13mm spanner (not supplied) loosen the
blade bolt by turning it anti-clockwise. FIG. K.
Note: A piece of timber will assist in holding the blade
while removing and tightening the blade bolt.
2. Remove the blade bolt, and blade.
Renew the metal blade after 50 hours
mowing or 2 years whichever is sooner. If
the blade is cracked or damaged replace
it with a new one.
3. To t the blade, place the blade over the centre hole
aligning the lugs.
4. Then retighten the fastening screw with the
universal wrench. The tightening torque should be
approx. 25 Nm.
Cleaning, maintenance and storage
•Keep all nuts, bolts and screws tight to be sure the
lawn mower is in a safe working condition.
•Check the catcher frequently for wear or
deterioration.
WARRANTY
YOUR WARRANTY FORM SHOULD BE RETAINED BY YOU AT ALL TIMES. IN ORDER TO MAKE A
CLAIM UNDER THIS WARRANTY YOU MUST RETURN THE PRODUCT TO YOUR NEAREST BUNNINGS
WAREHOUSE WITH YOUR BUNNINGS REGISTER RECEIPT. PRIOR TO RETURNING YOUR PRODUCT FOR
WARRANTY. PLEASE TELEPHONE OUR CUSTOMER SERVICE HELPLINE:
Australia 1800 069 486
New Zealand 0508 069 486
TO ENSURE A SPEEDY RESPONSE PLEASE HAVE THE MODEL NUMBER AND DATE OF PURCHASE
AVAILABLE. A CUSTOMER SERVICE REPRESENTATIVE WILL TAKE YOUR CALL AND ANSWER ANY
QUESTIONS YOU MAY HAVE RELATING TO THE WARRANTY POLICY OR PROCEDURE.
The benets provided under this warranty are in addition to other rights and remedies which are available to you at
law.
Our goods come with guarantees that cannot be excluded at law. You are entitled to a replacement or refund for a
major failure and for compensation for any other reasonably foreseeable loss or damage. You are also entitled to
have the goods repaired or replaced if the goods fail to be of acceptable quality and the failure does not amount to
a major failure.
Generally you will be responsible for all costs associated with a claim under this warranty, however, where you have
suffered any additional direct loss as a result of a defective product you may be able to claim such expenses by
contacting our customer service helpline above.
1 YEAR REPLACEMENT WARRANTY
Your product is guaranteed for a period of 12 months from the original date of purchase and is intended for DIY
(Do It Yourself) use only. If a product is defective it will be replaced in accordance with the terms of this warranty.
Warranty excludes consumable parts, for example: blade.
Ozito Industries Pty. Ltd.
25 Fox Drive, Dandenong South, Victoria, Australia 3175
WARNING
The following actions will result in the warranty being void.
• Professional, Industrial or high frequency use.
• If the tool has been operated on a supply voltage other than that specied on the tool.
• If the tool shows signs of damage or defects caused by or resulting from abuse, accidents or alterations.
• Failure to perform maintenance as set out within the instruction manual.
• If the tool is disassembled or tampered with in any way.
5
•Before using the lawn mower and after any impact,
check for signs of wear or damage and repair as
necessary.
•Replace a worn or damaged blade together with the
blade bolt to preserve balance.
•Start mowing the edge of the lawn nearest to the
power point so the lead is laid out on the lawn you
have already cut.
•For best grass collection, always mow in a straight
line; do not swing the lawn mower from side to side.
•When mowing long grass be sure to not overload
the motor. First cut with the highest cutting height
and then to the desired height. This will help reduce
the load.
•Do not overload the mower. Mowing long thick grass
may cause the motor speed to drop; you will hear a
change in the motor sound. If the motor speed drops
you may overload your lawn mower, which may
cause damage. When mowing in long thick grass
rst cut with the cutting height set in the highest
position, this will help reduce the load.
WARNING! Do not mow with poor
visibility conditions, in the rain or when
grass is wet.
WARNING! Ensure the mower blade
has completely stopped, remove safety
key, battery and grass catcher prior to any
maintenance.
WARNING! Always use gloves when
handling the blade. Sharp edges could
cause injury.
•Replace worn or damaged parts for safety.
•Only use the replacement blade and blade bolt
specied for this product.
•Be careful during adjustments of the lawn mower to
prevent entrapment of the ngers between moving
blade and xed parts of the machine.
•If the housing of the machine requires cleaning, do
not use solvents. Use of a soft cloth and brush only
is recommended.
•Never allow any liquid to get inside the mower,
never immerse any part of the machine into liquid or
clean the mower with running water, particularly with
high-pressure water.
•When not in use, the mower should be stored in a
dry, frost-free location, out of reach of children. The
ideal storage temperature is between 5 and 30°C.
•Remove the battery and safety key from the mower
when in storage.
•Allow the motor to cool before you put the equipment
in an enclosed area.
Note: XU1 will not be responsible for any damage
or injuries caused by the repair of the lawn mower by
an unauthorised person or by mishandling of the lawn
mower.
