Box Contents
As you unpack your RailDriver, please check the enclosed items against
this packing list:
RailDriver Control Unit
RailDriver Power Supply (AC adapter)
RailDriver Label Sheets & Game Button Identification Strips
RailDriver Operating Manual
Installing Labels for the Controls and Function Keys
Reverser, Throttle, and Brake
decals are applied with the left end
of the label at the top of the control
lever.
To remove wiper and light switch
caps for labeling, insert a thin
bladed screwdriver into the slot on
either side of the switch and
carefully pry up until the switch cap
pops off.
To apply legends for the function keys,
pry up carefully, but with force, on the
panel cover, place the legend strips
above the keys. Insert the top of the
panel cover first, and snap the bottom
back into place.
Printable versions of these legend
strips can also be found on our website.

3
Use the drawing above to determine the location of the decals.
Connecting Sound and Vibration Features
The following steps are required to enable the RailDriver internal sub-
woofer. Power and audio connections are not required for operation of the
RailDriver controls, but they do enhance the driving experience.
A. RANGE
B. E-BRAKE
C. ALERT
D. SAND
E. P (PANTOGRAPH)
F. BELL
G. FORWARD - N - REVERSE
H. DYN BRAKE - THROTTLE
I. EMG - CS - SUP - REL
J. AUTO BRAKE - IND BRAKE
K. FULL - REL
L. WIPER
M. LIGHTS

4
1. Plug the RailDriver into the line out sound port on your computer.
2. Plug the speakers (which were in the sound port) into the RailDriver
pass through sound port.
3. Connect the 12 VDC Power Supply.
4. Set the Amplitude control to mid level (adjust setting when RailDriver is
running with your train simulation software).
NOTE: The RailDriver Desktop contains a speaker which has been
magnetically shielded to prevent color distortion on video displays.
Exposing magnetic media (floppy disk, memory stick, or digital tape) to
magnetic materials may cause data loss.
Installing Your RailDriver Train Cab Controller
The rapid evolution of train simulator software applications prohibits us
from keeping the most current and relevant instructions in a paper
manual or shipping software with the device. Please refer to our website
raildriver.com for the most current instructions and software.
How to Download RailDriver Software
Your new RailDriver requires software to make the connection to your
train simulation program. Go to raildriver.com/support and select your
program from the list. Follow the instructions on the page to download
and install the RailDriver software.
Supported Simulation Programs
Train Simulator (current version) by Dovetail Games
Trainz (up to Trainz 12) by N3V Games
Run8*
Open Rails*
World of Subways 2 & 3*
TrainMaster 4.3
*These programs have native RailDriver support and do not require our
software.
All downloads are free. If you cannot download the software, for any
reason, please contact us and we will provide the software by another
means.
Technical support for the installation of RailDriver is available via email:
[email protected]om or phone: [phone] Ext. 19

5
The Default Control Layout
While the RailDriver Desktop control levers and switches most closely
resemble the Dash 9 layout, they may be configured to operate any type
of engine in most train simulation programs. For details on selecting
alternate control layouts or creating your own custom layout, please refer
to the Help files in our software, or the Technical Support Page on our
web site (www.raildriver.com).
1. (1-28) Programmable game buttons
29. Zoom/Rocker button
30. Four way panning control
31. LED speedometer
32. Gear Shift
33. Emergency Brake
34. Alerter
35. Sander
36. Pantograph
37. Bell
38. Horn/whistle lever (operates forward or back)
39. Reverser (center detent, variable forward and reverse)
40. Combined throttle and dynamic brake (with "gate" center)
41. Automatic brake, (detent before e-brake)
42. Independent brake (w/right motion for bail-off)
43. Rotary wiper switch
44. Rotary headlight switch.
