PABX 208AC User manual

Evolio AC Series
Model:
208AC
308AC
416AC
432AC

1. Keep the unit away from heating appliances and electrical noise generating devices such as
motors and televisions. These noise sources can interfere with the performance of machine.
2. Keep away from AC power source when install the telephone cables.
3. Avoid using the same power supply outlet for computers and other office equipments,
otherwise, the system operation may be interrupted by the induction noise.
4. Unplug during install or remove the expansion boards, and the boards should be installed
or removed vertically to avoid short circuit.
5. After system is started, if it does not operate properly, please restart it. If it is still works
improperly, please contact with your dealer.
6. This unit should be kept free of dust, moisture, high temperature and vibration, and should
not be exposed to direct sunlight.
7. Never attempt to insert wires, pins, etc. Into the vents or other holes of this unit.
8. Do not use benzine, thinner, or the like, or any abrasive powder to clean the cabinet. Wipe
it with a soft cloth.
Precautions
WARNING
THIS UNIT MAY ONLY BE INSTALLED AND SERVED BY QUALIFIED
SERVICE PERSONNEL.
WHEN A FAILURE OCCURS, DISCONNECT THE POWER SUPPLY
CORD IMMEDIATELY AND ASK FOR HELP FROM YOUR DEALER.
MODEL HC,BC,VC AND DC ARE REQUIRED EQUIPPED WITH AN
EARTHING CONTACT PLUG. FOR SAFETY REASONS THIS PLUG
MUST ONLY BE CONNECTED TO AN EARTHING CONTACT SOCKET
WHICH HAS BEEN INSTALLED ACCORDING TO REGULATIONS.
THE POWER SUPPLY CORD IS USED AS THE MAIN DISCONNECT
DEVICE, ENSURE THAT THE SOCKET-OUTLET IS LOCATED NEAR
THE EQUIPMENT AND IS EASILY ACCESSIBLE.
TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS
PRODUCT TO RAIN OR MOISTURE.

Table of Contents
Chapter 1: Before Program
Brief Introduction -------------------------------------------------------------------------
Installation and Connection --------------------------------------------------------------
Technical Index ---------------------------------------------------------------------------
Chapter 2: System Operating
Intercom Calling --------------------------------------------------------------------------
Outside ( CO ) Line Access Mode Selection ------------------------------------------
Receiving Call ----------------------------------------------------------------------------
Call pickup -------------------------------------------------------------------------------
Call Transferred -------------------------------------------------------------------------
Operator Call ---------------------------------------------------------------------------
Automatic Callback Busy ---------------------------------------------------------------
Busy Transferred ------------------------------------------------------------------------
Unconditional Transferred -------------------------------------------------------------
Call Transferred to Secretary ------------------------------------------------------------
Do Not Disturb ( DND ) ----------------------------------------------------------------
Station Lock ( personal password) ----------------------------------------------------
Self-Extension Number Confirmation ------------------------------------------------
Executive Busy Override ---------------------------------------------------------------
Personal Account -------------------------------------------------------------------------
Call on Holding ---------------------------------------------------------------------------
Remote program ------------------------------------------------------------------------
Chapter 3: System Program
Unlock System Password ---------------------------------------------------------------
Change System Password ---------------------------------------------------------------
System Data Default Set ----------------------------------------------------------------
Outside ( CO ) Line Connection Assignment ------------------------------------------
Disable CO Lines ------------------------------------------ ---------------------------
Outside Call Answered Mode Management ------------------------------------------
Time ( Day / Night ) Service Changing Mode ----------------------------------------
Day Service Changing Mode -----------------------------------------------------------
Outside ( CO ) Line Ringing Selection -------------------------------------------------
Attendant Extension Assignment ------------------------------------------------------
1
2
3
6
7
9
10
10
11
11
12
12
13
13
14
4
6
4
9
15
16
16
16
18
19
20
20
17
14
15

Table of Contents
Outgoing Message ( OGM )-----------------------------------------------------------
Assign Outward Code (Least Cost Route) -------------------------------------------
Assign Outside Line Ring by Turns -------------------------------------------------
Enable or Disable Outside Call Reaches to Extension -----------------------------
by One-Touch Dialing ( at DISA mode)
Extension is Allowed Access Only Designated CO Line --------------------------
Exclusive CO Line of Designated Superior Extension -----------------------------
Assign Designated Extension is Belong to a Group --------------------------------
Head-Digits of Restricted Dial CO Line Number ----------------------------------
Head-Digits of Special (Allowed )Dial CO Line Number -------------------------
Certain Extension Outgoing Call Class ----------------------------------------------
Extension Number Management -----------------------------------------------------
Assign Outside ( CO ) Line Access Mode -------------------------------------------
Outside ( CO ) Line Duration Time Limit ------------------------------------------
Enable / Disable Extension User Use Speed Dialing Function --------------------
Fax Received Automatically --------------------------------------------------------
IP Code of CO Line ------------------------------------------------------------------
Cancel Call Transferred to Secretary -----------------------------------------------
Restore Personal Password ----------------------------------------------------------
Change System Time ------------------------------------------------------------------
Call Charge Mode ---------------------------------------------------------------------
Flash Time ----------------------------------------------------------------------------
Call Bill Memory Cleared -----------------------------------------------------------
Chapter 4: Appendix
Program Table ------------------------------------------------------------------------ 38
Operating Table ----------------------------------------------------------------------
PC Call Management Software -----------------------------------------------------
22
23
23
24
25
25
28
28
29
31
32
33
34
35
35
35
36
36
37
37
21
40
41
34

Brief Introduction
1
Chapter One Brief Introduction Chapter One
Thank you for choosing our products TC-2000AC series PABX, this system is
include following models:
No Model Structure CO line Extension
208AC
308AC
432AC
Not expandable
Not expandable
2 8
4
Not expandable 32
1
2
4
416AC 4
Not expandable
3
No Main Functions
1
2
3
4
Flexible coding - Extension Number Assignable
Extension ring by turns when has outside call is access ( programmable)
Enable/ disable outside caller reaches extension by one touch dialing
Auto adapt FSK and DTMF caller ID signal, caller ID transferred
5
6
7
Station lock ( personal password, allows lock your extension)
Multi-classes restricted of outgoing call
Outward code dialing ( least cost route, can save call fee)
Ringing extension assignable ( allows 8 extensions are ringing at that same time)
Twin route 3-OGM for auto-attendant ( OGM 1= 30s ; OGM 2= 15s ; OGM 3= 15s)
8
9
10
One touch dialing, allows call to operator by one key
11
12
13
14
15
Busy Transfer; Unconditional Transfer; Do Not Disturb(DND)
Extension or CO line groups assignable can realize call fee calculated separately
Party conference with caller ID transferred
PC management software can manage call fee and function programmed by PC, etc.
Support polarity reverse detection
16
High-capacity call bill memory can save call bill in any time
17
18
Remote program supply more convenient and easy after service
19
20
Make outside call by code ( speed dialing, increase your work efficiency)
Auto add IP code when dial long-distance call
Extension free notice ( when ever called ext. is becomes free, will send ring to inform you)
Allows user input his fond music as holding music
21
3
16
8

Chapter One Installation and Connection
1.1 Names
Model 208AC, 308AC back view
Model 416AC back view
Front view
Left view
Right view
2
Part Names:
LED
Power switch
CO line jack
Extension jack
Power socket
Rj11 for connect with PC COM port
External music inputted port

Chapter One Technical Index
1.2 Technical Index
No Names Specifications
1Capacity Extension: 8,16,32; CO lines: 2,3,4
2Exterior Jack * Standard jack: CO/ Extension jack, Rj11 for connect with PC
COM port, external music jack.
3Communicate
Channel * 7 channels
Transmission
Attributes:
* Extension to extension 1.5dB
* Extension to trunk line 2.0dB
4
Ringing
current
* Ac65v / 50Hz
Degree of
Unbalance
about earth
* 300Hz --- 600Hz 40dB
* 600Hz --- 3400Hz 46dB
Dial mode DTMF
Signal tone
* CO line: Tone from local telecom office;
* Internal dial tone: 450Hz, continuous sine wave;
* Internal ringback tone: 450Hz, sine wave, 1s on / 4s off;
* Internal busy tone: 450Hz, sine wave, 0.3s on / 0.3s off;
* Internal confirmation tone: 450Hz, sine wave, 1s on;
* Internal error tone: 450Hz, sine wave, 0.3s on / 0.3s off.
5
6
7
8
Caller ID * Receive: Auto adapt DTMF, FSK ( Bell .202) ;
* Send: FSK ( Bell. 202) ;
9
Power supply * AC220V ± 10% /12W;
10
3

Chapter Two Operating
4
2.2 Outside ( CO ) Line Access Mode Selection
2.2.2 Access Outside ( CO) Line by Second or Third Outward Code
( Least Cost Route )
Example: Non-direct outgoing mode extension 8008 make an outside call via VOIP line
that is correspond to outward code 3.
Operating: 1) Lifts extension 8008, hear internal dial tone;
2) Press 3 to access VOIP line;
3) Dial outside call number.
This function is applies to place where has several telecom providers, allows
user access designated CO line that can supply least call fee, please refer 3.20
Description: Allows an extension user to make a call to an external party by use one of
the following line access methods.
2.1 Intercom Calling
Description: Allows an extension user to make a call to another extension.
Format 1: ABCD ( When extension is at non-direct access CO line mode)
Format 2: * ABCD ( When extension is at direct access CO line mode)
ABCD = Extension number
Example 2: Direct outgoing mode extension 8011 calls extension 8083.
Operating: 1) Lifts extension 8011, hear external dial tone;
2) Input * first, then input 8083 after hear internal dial tone;
3) Ringback tone (1s:4s) is sent indicates call made successfully.
1. Intercom calling is not via telecom provider, it is free charge.
2. Internal dial tone sounds more reedy than external dial tone.
Example 1: Non-direct outgoing mode extension 8008 calls extension 8065.
Operating: 1) Lifts extension 8008, hear internal dial tone;
2) Input 8065;
3) Ringback tone (1s:4s) is sent indicates call made successfully.
2.2.1 Access Outside ( CO)Line by Press 0 or 9
Example: Non-direct outgoing mode extension 8008 make an outside call.
Operating: 1) Lifts extension 8008, hear internal dial tone;
2) Press 0 to get external dial tone;
3) Dial outside call number .
Refer page32 to learn related setting.

2.2.3 Access Outside ( CO)Line Directly
Example: Direct outgoing mode extension 8008 make an outside call.
Operating: 1) Lifts extension 8008;
2) Dial outside call number when hear external dial tone.
Extension will enter CO line when lifts handset if has idle CO line (refer 3.50).
2.2.4 Access Outside ( CO)Line by Preferred CO Line
Format : # MN
MN = CO line port number = 01 ~04
Example: Extension 8008 is wants to make an outside call via CO line 3.
Operating: 1) Lifts extension 8008;
2) Dial #3 when hear internal dial tone;
3) Dial outside call number when hear external dial tone.
1. When user need to use * or # key to program some functions that supplied
by telecom provider, in order to avoid conflict with some functions of
PABX that need to use same key at beginning , please access CO line by
this program (select CO line ) first, then program functions supplied by
telecom provider.
2. User can select CO line by use #M, example, select CO 3
by input # 3 can access CO line 3, it is as same as press #03;
3. Busy tone will be sent when selected CO line is busy.
2.2.5 Personal Speed Dialing
Format : # # MN
MN = Speed dialing number = 01 ~80
Description: Allows an extension user to store up to 80 speed dialing numbers (01
through 80) with a maximum of 24 digits per number. For example, 01 =
008675786692066, 02 = 008675786692033. Here 01, 02 are speed dialing
number, to make a call, dial # # MN ( MN is the speed dialing number),
Example: Extension 8008 wants to call CO number 008675786692066 that is correspond
to speed dialing number 12.
Operating: 1) Lifts extension 8008, hear internal dial tone;
2) Input ## 12, then will call 008675786692066 automatically.
1. Only allows authorized user to use this function.
2. Related program: Please refer 2.3 and 3.53.
Chapter Two Operating
5

2.3 Assign Speed Dialing Number for Outside ( CO) Line Number
Format : # ** MN abcdefgh #
MN = Speed dialing number = 01 ~80
abcdefgh = Outside (CO) line number ( maximum of 24 digits)
Description: Allows authorized extension add or change speed dialing number, the
assigned speed dialing numbers can be shared with all extension users.
Refer 3.53 to learn enable or disable extension use speed dialing function.
Example: Extension 8003 wants to assign outside number 008675786692066 is
correspond to speed dialing number 12.
Operating: 1) Lifts extension 8003, hear internal dial tone;
2) Dial # * * 1 2 008675786692066 # ;
Last number setting will replace previous assigned number.
2.4 Cancel Certain Speed Dialing Number
Format : # ** MN#
MN = Speed dialing number = 01 ~80
Description: This program will cancel certain speed dialing number and its CO line
number.
2.5 Receiving Outside Call by Ringing Extension
Description: When system is at operator attendant mode, the designated extension will
ring when has outside call is received, lifts ringing extension can answer
outside call. When at auto-attendant (DISA) mode, non of extension will
ring when has outside call is received, caller is hear outgoing message
( OGM), the called extension will ring after caller input extension number,
lifts ringing extension can answer outside call.
2.6 Receiving Outside Call by Non-Ringing Extension ( Call Pick Up)
Format : # 7
Description: Allows an extension user to answer a call ringing at another extension, if
the call is ringing within his extension group, he can pickup call by #7.
2.6.1 Group Call Pickup
Chapter Two Operating
6

Chapter Two Operating
7
Format : # 9
Description: Allows an extension user to answer a call ringing at any other extension. If
the call is ringing within his extension group, he can pickup call by #7.
If the call is ringing in different extension group, he must to pickup by #9.
Example, extension A and B are ringing at the same time, they are in different
group, at this time, extension C wants to pickup calls, if C and A are in same
group, C can pickup call ringing at A by #7; however, when C is input # 9, he
will pickup call ringing on extension that is connect with anterior extension
jack first, the extension in after jack will keep ringing.
2.6.2 Directed Call Pickup
Format : Tap hook-switch + ABCD
ABCD = Extension number
Description: Allows an extension user transfer an outside call to another extension.
When has outside call is received at extension A, user A is transfers this call
to extension B, music is sent to outside caller while being transferred, when B
is lifts handset, communicate between A and B is established, whoever A or B
is hangup, the remain party will get through to outside caller.
Example: Has outside call is received at 8002, user wants to transfer this call to 8015.
Operating: 1) Extension 8002 is talking with outside caller;
2) User 8002 taps hook-switch rapidly get internal dial tone, input 8015;
3) 8015 is ringing, music is sent to outside caller while being transferred;
4) 8015 lifts handset, communicate between 8015 and 8002 is established,
outside caller is keep holding with music;
5) 8002 hangup, 8015 will get through to outside call.
2.7 Transfer Outside Call to Extension
1. User must to tap hook-switch rapidly which time should not over assigned
hook-switch flash time(refer 3.61), otherwise, the line will be disconnected;
2. After user A has inputted extension number of B, when B is busy, three Beep
busy tone is sent to A, and A will reconnect with outside caller.
a) B is ringing, A is not hangup, if B answer within 25seconds can build internal
talk with A, whoever A or B hangup, the remain party will get through to
outside caller;
b) B is ringing, A is not hangup, if B does not answer within 25seconds, A will
get through to outside caller;
c) B is ringing, A hangup, if B answer within 25seconds he can get through to
outside caller;
d) B is ringing, A hangup, if B does not answer within 25seconds, B will stop
ringing, here A will ring if it is free( if A is busy, operator extension will ring),
if A (or operator) answer within 25seconds, it will get through to outside caller;
if nobody answer within 25 seconds, the line will be released.
When extension B is idle, have follow cases:

Chapter Two Operating
8
2.8 Conference ( 3-party, 1 CO and 2 Extensions)
Format : Tap hook-switch + * + ABCD
ABCD = Extension number
Description: During a 2-party conversation, an extension user can add a third party to
make a 3-party conference.
Example: Extension 8002 is answering an outside call, 8002 wants to add 8015 to build
a 3-party conference.
Operating: 1) Extension 8002 is answering an outside call;
2) 8002 taps hook-switch rapidly to get internal dial tone, input * 8015;
3) 8015 is ringing, music is sent to outside caller while being transferred;
5) 8015 lifts handset can get through to outside caller and 8002, here 3-party
conference is established.
1. When two extensions are making internal call, their conversation cannot
be heard by outside caller; when in 3-party conference, outside caller and
two extensions are involved.
2. No matter when it is ready to transfer or when at 3-party conference, user
will hear internal dial tone after he tap hook-switch, here user must to input
destination extension number within 10 seconds, otherwise, this extension
will be get through to outside caller again.
Format : Tap hook-switch + ABCD
ABCD = Extension number
Description: Allows an extension user transfer an internal call to another extension.
Example: Extension 8002 is making internal talk with extension 8032, 8002 wants to
transfer call to 8015.
Operating: 1) Extension 8002 is making internal talk with 8032;
2) 8002 taps hook-switch rapidly, then dial 8015;
3) 8015 is ringing, 8032 is listening ring tone;
4) 8015 lifts handset can build internal talk with 8002, 8032 is keep
listening ring tone;
5) 8002 hangup, 8015 will get through to 8032.
2.9 Internal Call Transfer ( Between Extensions)
1. User must to tap hook-switch rapidly which time should not over assigned
hook-switch flash time(refer 3.61), otherwise, the line will be disconnected;
2. After user A has inputted extension number of C, when C is busy, three Beep
busy tone is sent to A, and A will reconnect with extension B.
3. If extension C is idle, will have follow cases:
a). C is ringing, A does not hangup, when C lifts handset can get through
to A, whoever A or C is hangup, the remain party will connect with B;
b). C is ringing, A does not hangup, when C lifts handset can get through
to A, here if B hangup, A and C will hear busy tone;
c). C is ringing, A hangup, when C lifts handset can get through to B;
d). C is ringing, B hangup, A will hear busy tone, C will stop ringing.

Chapter Two Operating
9
2.11 Operator Call
Format : Dial 9 or 0
Description: Every extension user can reach operator by dial 9 directly.
Example: In hotel, guest whose extension number is 6013 can get through to hotel
restaurant with the help of operator when he does not know restaurant number.
Operating: 1) Guest (6013) lifts handset, hear internal dial tone, input 9 to call operator;
2) Operator lifts handset to answer 6013, and then transfer call to restaurant;
3) Guest (6013) can get through to restaurant.
1. System default setting is dial 9 for operator, but allows user change setting to
dial 0 for operator, please refer page35 for related setting.
2. This system supports two operators ( refer 3.15), when extension dial 9 ( or 0),
the call will go to No.1 operator when it is free, otherwise, call will be forwarded
to No.2 operator automatically.
When both of them are busy, the call will be failure.
3. The direct-outgoing mode extension must to dial * 9 ( or * 0) to call operator.
2.10 Conference ( Intercom 3-party )
Format : Tap hook-switch + * + ABCD
ABCD = Extension number
Description: During a 2-party internal conversation, an extension user can add third
extension party to build a 3-party conference.
Example: Extension 8002 is making internal talk with 8005, 8002 user wants to add 8015
to build internal 3-party conference.
Operating: 1) Extension 8002 is making internal talk with 8005;
2) 8002 taps hook-switch rapidly to get internal dial tone, then input * 8015;
3) 8015 is ringing, 8005 is listening ring tone;
4) 8015 lifts handset can get through to 8002 and 8005, here 3-party internal
conference is established
When extension A and B are making internal talk, if A is transfers this call to C,
no matter at any condition, as long as B is hangup will make transfer failure,
A and C will hear busy tone.
2.12 Make Your Telephone Ringback Automatically When an Extension Line
Becomes Free ( Automatic Callback Busy)
Format: Tap hook-swtich + # # 00
Description: Allows assign send callback ringing to notify an extension user automatically,
when the ever called extension becomes available.
Example: You called extension 8008, but it is busy.
Operating: 1) Lift your handset, dial 8008 when hear internal dial tone;
2) Busy tone is sent when 8008 is busy;
3) Tap hook-switch and input ##00, hangup when music tone is heard;
4) When 8008 is becomes free, your phone will ring with display number 8008;
5) Lift your handset, 8008 will ring automatically and with display of your
extension number, you can get through to 8008 when it is lifted.

Chapter Two Operating
10
Description: Allows an extension user assign automatic transfer any calls to another
designated extension unconditionally.
Example: Manager ( whose extension is 8016) can assign all outside calls to his extension
will be transferred to his secretary (whose extension is 8015) automatically when
he is in busy trip.
Operating: 1) Lifts 8016, hear internal dial tone;
2) Input # * 2 8015;
2.13 Busy Transferred
Format: # * 1 ABCD
ABCD = Destination extension number
Description: Allows an extension user assign automatic transfer outside calls to another
designated extension when the called extension is busy.
Example: Manager ( whose extension is 8016) can assign all outside calls to his extension
will be transferred to his secretary ( whose extension is 8015) automatically
when his extension is busy,
Operating: 1) Lifts 8016, hear internal dial tone;
2) Input # * 1 8015;
1. When extension A has been assigned busy transferred to extension B, outside
calls will be transferred to B automatically when A is busy; when B is busy,
if B has been assigned busy transferred to C, then, this outside call will be
transferred to C automatically, allows busy transferred ten times, otherwise,
outside caller will hear busy tone;
2. The last setting will replace previous one.
2.14 Cancel Busy Transferred
Format: # * 1 00
,
2.15 Unconditional Transferred
Format: # * 2 ABCD
ABCD = Destination extension number
The last setting will replace previous one.
2.16 Cancel Unconditional Transferred
Format: # * 2 00

Chapter Two Operating
11
2.17 Call Transferred to Secretary
Format: # * 6 ABCD
ABCD = Secretary extension number
Description: All calls (except secretary) to superior will be transferred to secretary first,
the call will be transferred to superior only after filtrated by secretary.
Example: Superior (whose extension is 8008) can assign all calls will be transferred to his
secretary (whose extension is 8012 ) first automatically.
Operating: 1) Lifts 8008, hear internal dial tone;
2) Input # * 6 8012;
1. The last setting will replace previous one.
2. Only allow secretary extension can call superior extension directly;
3. Support maximum of eight extensions use this function in same time.
2.18 Cancel Call Transferred to Secretary
Format: # * 6 00
1. Allows use extension 8001 to cancel by batch way ( refer 3.57)
2.19 Do Not Disturb ( DND )
Format: # * 71
Description: Allows an extension user to prevent other parties from disturbing them. The
extension will not receive intercom or outside calls, and it will not ring when
has calls and send busy tone to outside caller, but the assigned extension can
make calls as normal.
Example: A guest in hotel does not want to be disturbed in his rest time, he can use this
function to make his telephone will not ring when has calls.
1. After assigned DND function, any calls can not call that extension;
2. Do not disturb function will not invalid until it is cancelled.
Operating: 1) Guest lifts his extension, hear internal dial tone;
2) Input # * 71;
2.20 Cancel Do Not Disturb
Format: # * 70

Chapter Two Operating
12
2.21 Station Lock ( personal password)
Format: # * 3 ABCD
ABCD = Personal password
Description: Allows extension user to lock his station so that other users cannot make
outside calls until it is unlocked. Any 4-digits code can be used to lock and
unlock an extension.
Example: Manager extension 8008 can make any calls, he can lock his phone by
password (suppose password is 2589) when he leaves office, his phone will
disable to make outside calls after locked.
Operating: 1) Manager lifts his extension 8008, hear internal dial tone;
2) Input # * 3 2589;
1. Non of extension is locked at default mode;
2. Default personal password is 1234.
Format: # * 4 ABCD
ABCD = Personal password
Description: Allows user to unlock his extension by password.
2.22 Unlock Personal Password
Format: # * 5 abcd ABCD
abcd = current password
ABCD = new password
2.23 Change Personal Password
1. Default personal password is 1234;
2. Suggest user change password before using;
3. In the case of forget password, please contact with administrator
to restore your password to default password 1234, then re-set
password ( refer 3.58)
Format: # * 9
Description: User can confirm their extension jack and extension number by this way.
Example: User input "# * 9" on extension 8001, he will hear "Your port number is 01,
extension number is 8001".
2.24 Report Extension number

Chapter Two Operating
13
2.25 Executive Busy Override
Format : # *0 MN
MN = CO line port number = 01 ~16
Description: Enable or disables using this feature at each extension, if enabled, authorized
user can monitor or interrupt an established call ( refer 3.54).
Example: Extension 8003 is enabled to use executive busy override function, he wants to
interrupt CO line 4.
Operating: 1) Lifts 8003, hear internal dial tone, input # * 0 04;
2) 8003 user can interrupt CO line 4 after two seconds.
This function is supplied to superior for management purpose, we are
irresponsible for any result from use this function.
2.26.1 Personal Account Assignment
Format 1: * 86 MN A # ( For certain account)
Format 2: * 86 A # ( For all accounts)
MN = account = 01~99 (total 99 accounts)
A = 0 = Disable account
A = 1 = Enable account
Description: Enable or disable make outgoing call by any extension after enter an assigned
account to override restriction, but spend will be under individual account.
This function is suits occasion that call fee is independent accounting.
2.26 Personal Account
2.26.2 Change Password of Certain Account
Format: # * # MN abcd * ABCD
MN = account
abcd = original password
ABCD = new password
Description: Allows change password by any extension, in the case of forget password,
please contact with administrator to restore default password by follow
programming ( operate by extension 1):
Input format * 86 MN 0 # to disable account, then input * 86 MN 1 # to
enable same account can restore password to default 1234.
2.26.3 Make outgoing call by personal account
Format: # * # MN abcd #
MN = account
abcd = password of account (default is 1234)
Description: Allows use any extension to make outgoing call by input this format.

Chapter Two Operating
14
2.28 Remote Program
Format : Tap hookswitch + # * # *
Description: Allows an extension user to program a PABX system that is using in
different place, it can supply a convenient and high-efficiency service for
PABX end user.
Example: When you encountered puzzle on system programming, you can solve it with
the help of PABX dealer or manufacturer ( herein after named service center )
by their remote program operating.
Operating: 1) Lift your extension 8001, make a call to service center;
2) When your call is get through to service center, please tap hook-switch, here
service center technician is under holding music, you hear internal dial tone;
3) You should input # * # * on your phone can restore talk with technician;
4) You can ask technician to assign functions according your necessary by phone,
he can program your PABX by his telephone at the same time.
5) Please hangup your extension after complete setting.
1. You must to call service center by your extension 8001;
2. When your call is get through to service center, technician can start program
for your machine need not input system password;
3. Also allows technician call you if necessary (at any attendant mode), when
his call is received at your side, please transfer this call to extension 8001,
remote program can be performed when communicate is established.
Format: Tap hookswitch + # # #
Description: Allows extension user can put an external call is on holding.
Example: When an extension is talking with outside caller, he can tap hook-switch and
input # # # to put call is on holding, he can make other call or do other operating
at this time.
He can input # # # to retake call within 4minutes, otherwise, line will be released.
Allows other extension retake this call by input # # *.
2.27 Call on Holding

15
Chapter Three System Program
3.1 Before System Programming
This system has factory default settings ( refer 3.4). If any of programming needs to be
changed, you can change the setting by system programming.
Default setting shows you the factory default setting.
1. System programming can only be performed from extension 8001;
2. Required Telephone Set: DTMF dial mode;
3. Start with * key, and end with # key, allows use * key to re-program if any error
occur during programming, need not hangup;
4. "Your instructions are successful" informs you that setting is successfully, on contrary,
"You have entered an incorrect instruction, try again later " informs you that the entry
is invalid.
3.2 Unlock System Password
Format : * * 01 ABCD #
ABCD = System password
Description: Password is required for entering the system programming mode.
Example: Unlock system by password before system program.
Operating: 1) Lifts extension 8001;
2) Input ** 01 1234 #, hear "System unlocked is successful, you can start operating ".
Keep off-hook and start programming;
1. Password is 1234 at factory default mode;
2. Please keep extension 8001 is off-hook, you can continue programming
by entering program format.
3. If extension 8001 is hangup during programming, you need to input
password to unlock system before new programming;
4. Herein after, all programming is after unlock system by password.
3.3 Change System Password
Format : * 02 ABCD #
ABCD = System new password.
Example: Change password to 5678.
Operating: 1) Lifts extension 8001, unlock system by default password 1234;
2) Input * 02 5678 #;
1. Password is 1234 at factory default mode, suggest administrator change
system password first before using;
2. In the case of forget password, please contact with service center.

Chapter Three System Program
16
3.4 System Data Default Set
Format : * 6 000 #
Description: This system can initialize system-programmed data.
All data can be restored to default setting except data of the follow 3 parameters.
1. Outside line connection assignment ( CO parameters);
2. Extension number parameters;
3. Call bill memory.
Default Values
Outside (CO ) Line Caller ID signal Adapt with FSK, DTMF
Trunk group Not set
Extension, CO Line Group 0
Extension outside call class Not set
Head-digits assignment
Monitor voice record
Call duration time limit
Hookswitch flash time
Not set
Not set
Not set
760ms
Function Default value
Operator attendant
8001, 8002, 8003,8004;
No
Attendant Mode
Outside (CO) Line Ringing Extension
1
2
3
4
5
7
6
9
8
10
11
12
Operator Extension at DISA mode 8002,8003
Outside( CO ) Line Access Mode Dial 0 or select CO line
3.5 Outside ( CO ) Line Connection Assignment
Format : * 31 ABCDEF #
ABCDEF = CO line jack need to be connected
Example: Connect CO lines with jack 1,2,3,4 , namely, it is enable CO1,2,3,4.
Operating: 1) Lifts extension 8001 unlock system;
2) Input * 31 1234 #;
3.5.1 Assign CO Line Connection
Description: Assigns which CO line(s) is connected to the system or not.
3.6 Disable CO Lines
Format : * 31 #
