PABX TC-208 SP User manual

TC-208 SP
Model:

Table of Contents
-Page -
- Functions -
------------------------------------------------------------------ 3Chapter 2: Programming and Operating
2.1 Unlock System Password -------------------------------------------------------------------------------3
2.2 Change System Password -----------------------------------------------------------------------------3
2.3 Internal Call --------------------------------------------------------------------------------------------- 3
2.4 Outside ( CO ) Line Connection Assignment -------------------------------------------------------4
2.5 Access Outside ( CO ) Line Instruction -------------------------------------------------------------4
----------------------------------------------------4
----------------------------------------------------------------------------4
--------------------------------------------------------------------------4
----------------------------------------------- 4
2.6 Ringing Extensions of Certain CO Line ------------------------------------------------------------ 5
2.7 Answer Incoming Call ---------------------------------------------------------------------------------- 5
------------------------------------------------------------------------------- 5
------------------------------------------------------- 5
2.8 Answering Mode Assignment ------------------------------------------------------------------------- 5
------------------------------------------------------------------------- 5
----------------------------------------------------------------- 5
2.9 Attendant Extensions Assignment ------------------------------------------------------------------6
2.10 Outgoing Message ( OGM ) For Auto-Attendant Service --------------------------------------6
------------------------------------------------------------------------------------6
------------------------------------------------------------------------- 6
2.11 Call Permission Management ------------------------------------------------------------------------6
-------------------------------------------------------- 6
------------------------------------------------------------7
------------------------------------------------------------------------7
--------------------------------------------------------------------------7
-------------------------------------------- 7
---------------------------------------------------- 8
---------------------------------------------------------------- 8
-------------------------------------------------------------------- 8
2.12 Call Transferring Management -------------------------------------------------------------------- 8
---------------------------------------------------------------------------------- 8
----------------------------------------------------------------------- 9
-------------------------------------------------------------9
2.13 Party Conference ( 1 CO & 2 Extensions) ------------------------------------------------------- 10
2.14 Flash Time ---------------------------------------------------------------------------------------------10
2.15 External Call Waiting---------------------------------------------------------------------------------10
2.16 Verify Holding Music --------------------------------------------------------------------------------10
2.17 Extension Number Assignment ---------------------------------------------------------------------11
2.18 Extension Number Confirmation ------------------------------------------------------------------11
2.19 Restore All Extension Numbers -------------------------------------------------------------------- 11
2.20 Factory Settings (Default) --------------------------------------------------------------------------- 11
2.5.1 Access CO Line by Dial 0 or Tap Hookswitch
2.5.2 Access CO Line Directly
2.5.3 Access Preferred CO Line
2.5.4 Direct / Non-Direct Access CO Line Assignment
2.7.1 By Ringing Extension
2.7.2 By Non-Ringing Extension ( Call Pick Up)
2.8.1 Operator Answering Mode
2.8.2 Auto-Attendant Answering Mode
2.10.1 OGM Recording
2.10.2 Listen Recorded Message
2.11.1 Class Assignment for Certain Extension
2.11.2 Class Assignment for All Extensions
2.11.3 Forbidden Phone Number
2.11.4 Permitted Phone Number
2.11.5 Extension is Permitted Use Certain CO Line Only
2.11.6 Exclusive CO Line of Superior Extension
2.11.7 Executive Busy Override (EBO)
2.11.8 External Call is Time-limited
2.12.1 Busy Transferred
2.12.2 Unconditional Transferred
2.12.3 Transfer Incoming Call by Operator
Chapter 1: Brief Introduction -------------------------------------------------------------------------------- 1
1.1 Precautions ---------------------------------------------------------------------------------------------- 1
1.2 Technical Index -------------------------------------------------------------------------------------------1
1.3 Names -------------------------------------------------------------------------------------------------------2

1.1.1 Keep the unit away from heating appliances and electrical noise generating devices
such as motors and televisions, these noise sources can interfere with performance
of machine.
1.1.2 Keep away from AC power source when install the telephone cables.
1.1.3 Avoid using the same power supply outlet for computers and other office equipments,
otherwise, the system operation may be interrupted by the induction noise.
1.1.4 All connection ( power, CO line, extension )should be good, otherwise, noise or
discontinuity would happen.
1.1.5 After system is started, if it does not operate properly, please restart it, if it is still works
improperly, please contact with your dealer.
1.1.6 This unit should be kept free of dust, moisture, high temperature and vibration, and
should not be exposed to direct sunlight.
1.1.7 Never attempt to insert wires, pins, etc. Into the vents or other holes of this unit.
1.1.8 Do not use benzine, thinner, or the like, or any abrasive powder to clean the cabinet.
Wipe it with a soft cloth.
1.1 Precautions
- 1 -
Chapter 1: Brief Introduction
1.2 Technical Index
No Names Specifications
1
2
3
4
5
6
7
8
9
10
11
CO lines:1 to 2 Extension: 1 to 8
Capacity
7 channels
Communicate Channel
* Extension to extension 1.5dB
* Extension to trunk line 2.0dB
Degree of unbalance about Earth * 300Hz --- 600Hz 40dB
* 600Hz --- 3400Hz 46dB
Ringing current
Transmission Attributes
Ac65v / 50Hz.
Dial mode DTMF
* CO line: Tone from local telecom office;
* Internal dial tone: 450Hz, continuous sine wave;
* Internal ringback tone: 450Hz, sine wave, 1s on / 4s off;
* Internal busytone: 450Hz, sine wave, 0.3s on / 0.3s off;
* Internal error tone: 450Hz, sine wave, 0.3s on / 0.3s off;
* Internal confirmation tone: 450Hz, sine wave, 1s on;
Signal tone
* Receive / Send: DTMF, FSK ( Bell .202) ;
Caller ID
AC220V 10% /15W ¡À The actual voltage is according to
label data which upon power socket.
Feedback current
Power supply
Power Failure Transferred
DC32V/25mA
When the power failure extension 801 and CO line 1
still can work normally.

- 2 -
1.3 Names
Chapter 1: Brief Introduction
Power supply socket
CO line ports ( RJ 11) 01 and 02
Extension ports from 01 to 08
( The actual voltage is according to
label data which upon power socket.)
( Refer following profile chart )
1
3
2
31 2
( Back View)
This PABX machine support 2 CO lines which
share same jack ( refer above ).
RJ 11 jack has four pins inside which
can be divided into two groups as CO lines,
(refer A, B, C, D in left picture),
join pins B & C as CO line 1, join A & D as CO line 2.
RJ 11 Jack Explanation:
2
A
BCD
( CO line jack RJ 11 profile chart)

Chapter 2: Programming and Operating
2.1 Unlock System Password
Format:
Description:
Example:
Operating:
ABCD = System password ( Default is 1234 )
Password is required for entering the system programming mode.
Unlock system by password before system program:
Lifts extension 801 Input ** 01 1234 # Hear [System unlocked
is successful, you can start operating] Start programming.
* * 01 ABCD #
2.2 Change System Password
ABCD = System new password.
Change password to 5678.
Lifts extension 801 Input 1234 Input * 02 5678 #;
Format :
Example:
Operating:
* 02 ABCD #
Suggest administrator change system password before using, please
contact with service center of supplier in case forget password.
1.
2. Required Telephone Set: DTMF dial mode.
3. Start with * key, and end with # key, no need to hangup 801 while
programming, otherwise you need to unlock system again by password
to start next programming.
Allows use * key to re-program if any error occur during programming,
need not hangup.
4. System will inform user setting is whether successful or failured.
5.
System programming can only be performed by extension 801.
Herein after, all programming is after unlock system by password.
- 3 -
2.3 Internal Call
Format 1:
Format 2:
Example 1:
Operating:
Example 2:
Operating:
ABC
* ABC
( When extension is at non-direct access CO line mode)
( When extension is at direct access CO line mode)
ABC = Extension number
Extension 808 is at non-direct access mode, he calls extension 806.
Lifts 808 (hear internal dialing tone) Input 806
Extension 807 is at direct access mode, he calls extension 808.
Lifts 807 (hear external dialing tone) Input * 808.
Allows an extension user to make a call to another extension.
1. Ringback tone (1s:4s) is sent indicates call made successfully.
2. Internal call is free charge.
3. Internal dialing tone is more reedy than external dialing tone.

2.4 Outside ( CO ) Line Connection Assignment
AB = CO line ( 1 or 2 )
Assigns which CO line(s) is connected to the system or not.
Connect CO line 1 and CO line 2.
Input format can enable CO line 1,2.
Format 1:
Format 2:
Description;
Example:
* 3 AB #
* 3 # ( Use for intercom only )
* 3 12 #
When extension user make external call it will enter CO line according
to priority. e.g the first call will enter line1 priority, meanwhile, the
second call will enter line 2 in case it is free. We had better connect CO
lines used for receive incoming call frequently with after jacks because
anterior lines are occupied by outgoing calls often.
,
2.5 Access Outside ( CO ) Line Instruction
Allows make external call by any one of following methods 2.5.1~2.5.3.
2.5.1 Access CO Line by Dial 0 or Tap Hookswitch
Extension 808 is at non-direct access mode, he makes external call.
Lifts extension 808 Press 0(or tap hookswitch) Input number.
Example:
Operating:
Related setting please refer .2.5.4
2.5.2 Access CO Line Directly
Extension 808 is at direct access mode, he makes external call.
Lifts extension 808 Input number will enter free CO line.
Example:
Operating:
Related setting please refer 2.5.4.
2.5.4 Direct / Non-Direct Access CO Line Assignment
ABC = Extension number
N = 0 = Non-direct access CO line mode
N = 1 = Access CO line directly
, extension will be at intercom state as soon as off-hook,
user can input extension number directly to make internal call, but
he must dial 0 or tap hookswitch to get external dial tone before input
phone number when he needs to make external call.
Format 1:
Format 2:
Description:
* 8 ABC N #
* 8 000 # ( Disable access CO line directly for all extensions )
When N = 0
2.5.3 Access Preferred CO Line
( At non-direct access CO line mode)
At direct access CO line mode)
M= CO line ( 1 or 2 )
Extension 808 is at non-direct access mode, he wants to make external
call via CO line 1.
Lifts extension 808 Input #1 Input phone number.
Format 1:
Format 2:
Example:
Operating:
# M
* # M (
- 4 -
Chapter 2: Programming and Operating

When N = 1, extension will enter free CO line as soon as off-hook
and user can input phone number directly, but he must input * ABC
when he needs to make internal call.
1. Suggest assign N = 1 ( access CO line directly) for extensions which
make external calls frequently.
2. When N = 1, extension can redial by REDIAL button.
3. Related operating please refer 2.5.1 / 2.5.2.
2.6 Ringing Extensions of Certain CO Line ( For Operator Attendant Service)
M = CO line ( 1 or 2 )
ABCD = Extension port number ( 1 to 8 )
Assign which extensions will ring when has incoming call via
certain CO line.
Assign extensions 802 will ring when has incoming call on CO line 1,
extension 803 and 806 will ring when has incoming calls on CO line 2.
Input * 1 12 # * 1 2 36 #
Format :
Description:
Example:
Operating:
* 1 M ABCD #
Ringing extensions are 801 to 804 at factory default setting.
2.7 Answer Incoming Call
Description: Extension user can answer the phone by lifts ringing exension which
pre-assigned for operator attendant mode purpose, however, none of
extension will ring at auto-attendant mode until caller input extension
number or dial related number to access operator.
( At non-direct access CO line mode )
( At direct access CO line mode )
User can answer the phone which ringing at other extension.
Formate 1 :
Formate 2:
Description:
# 7
* # 7
2.7.1 By Ringing Extension
2.7.2 By Non-Ringing Extension ( Call Pick Up)
2.8 Answering Mode Assignment
2.8.1 Operator Answering Mode
Format 1 :
Description:
* 21 # ( All CO lines at Operator Answering mode )
Operator lifts ringing extension can answer incoming call.
2.8.2 Auto-Attendant Answering Mode
Format 1 :
Format 2 :
* 20 #
* 20 M #
( All CO lines at Auto-attendant Answering mode )
( Certain CO lines at Auto-attendant Answering mode)
M = CO line ( 1 or 2 )
- 5 -
Chapter 2: Programming and Operating
Description: External caller will hear outgoing message (OGM) when he enter
line which is at auto-attendant service mode, none of extension ring
until he input extension number or call operator.

When need to assign some CO lines at auto-attedant answering mode,
we can assign all CO lines at operator answering mode first by ,
then assign auto-attendant mode for certain CO lines by .
*21#
* 20 M #
2.9 Attendant Extensions Assignment
ABC = Extension number
Allows assign two attendant extensions for service at
, when caller dial 0 call will go to attendant 1, and it will be auto-
transferred to attendant 2 when attendant 1 is busy, however, system
will search free extension from extension 802 to 808 for answering
when both attendant extensions are busy.
Format 1:
Format 2:
Description:
* 25 ABC # ( Attendant1, default setting is extension 802)
* 26 ABC # ( Attendant2, default setting is extension 803)
auto-attendant
mode
2.10 Outgoing Message ( OGM ) For Auto-Attendant Service
Allows record up to 15 seconds OGM for auto-attendant service.
"This is A company, for the sales division, press 803; for the service
division, press 806; for fax, press 808; to call operator, press 0 ".
Format:
Description:
Example:
* 22 #
2.10.1 OGM Recording
Allows to play back recorded message to verify its performance.
Format :
Description:
* 23 #
2.10.2 Listen Recorded Message
Recording by high quality handset in quiet environment can get
better timbre, A beep tone indicates user can start recording and
the last recording will replace the old one.
- 6 -
Chapter 2: Programming and Operating
2.11 Call Permission Management
2.11.1 Class Assignment for Certain Extension
ABC = Extension number
M=0=Only call numbers with permitted front digits. (Refer 2.11.4)
M=1=No restriction.
M=2=International call is forbidden ( default setting).
M=3=Long distance call is forbidden.
M=4=Not allowed call numbers with front digits in group A. (Refer 2.11.3)
M=5=Not allowed call numbers with front digits in group B. (Refer 2.11.3)
M=6=Only permit to make internal call.
Assign extension 803 is not allowed make long distance call, extension
806 is not allowed call numbers with forbidden front digits in gourp A,
extension 807 is only permitted to make internal call.
Input * 51 803 3 # 806 4 # 807 6 #
Format 1:
Example 1:
Operating:
* 51 ABC M #

2.11.2 Class Assignment for All Extensions
M is the same as 2.11.1
Assign extension 804 and 805 are not allowed to make international
call ( M=2), others are not allowed to make long distance call (M=3).
Input * 51 3 # 804 2 # 805 2 #
Format :
Example :
Operating:
* 51 M #
We can use * 51 3 # do assignment for the most extensions first.
2.11.3 Forbidden Phone Number
ABCD = Front digits of forbidden phone number
Phone numbers with these front digits are forbidden.
Assign front digits 573/8 to group A.
Input * 52 573# 8#
Format 1:
Format 2:
Format 3:
Format 4:
Description:
Example:
Operating:
* 52 ABCD # ( Group A )
* 53 ABCD # ( Group B )
* 52 # ( Cancel Group A )
* 53 # ( Cancel Group B )
2.11.4 Permitted Phone Number
ABCD = Front digits of permitted phone number
Only permit call phone numbers with these front digits.
Assign 0757 / 010 as permitted front digits, and extension 803 is only
permitted to call numbers with front digits 0757 / 010.
Input * 54 0757 # 010 # *51 803 0#
Format 1:
Format 2:
Description:
Example:
Operating:
* 54 ABCD #
* 54 # ( Clear permitted front digits)
Allows assign up to ten pieces front digits and maximum of four digits
for each piece.
- 7 -
Chapter 2: Programming and Operating
M = CO line ( 1 or 2 )
ABC = Extension number
The assigned extension is permitted use only designated CO line
to make external call.
Input can assign extension 803 is permitted use only
CO line 1.
Format :
Description:
Example:
* 42 M ABC #
* 42 1 803 #
1. Any incoming call can be transferred to this assigned extension, and
this extension user can pick up any incoming call.
2. This extension can have only one CO line to make external call.
2.11.5 Extension is Permitted Use Certain CO Line Only

- 8 -
Chapter 2: Programming and Operating
2.11.6 Exclusive CO Line of Superior Extension
M = CO line ( 1 or 2 )
ABC = Superior's extension number
The superior has exclusive CO line which is forbid used by normal
extension users, moreover, this superior can also use other CO lines.
Each exclusive line can be shared by up to four superior extensions.
Input can assign CO line 1 as exclusive line for superior
whose extension is 808.
Format :
Description:
Example:
* 41 M ABC #
* 41 1 808 #
1. The last setting will replace the previous one
2. Use format * 3 AB # can cancel settings 2.11.5 and 2.11.6.(refer 2.4)
N = CO line ( 1 or 2 )
Authorized user (superior) can interpose a busy line.
Extension 801 wants to interpose CO line 2 even it is busy.
Lifts 801 Input # * 92 Access line 2 after two seconds.
Format :
Description:
Example:
Operating:
# 9 N
Only extension 801 is permitted use this function, we are
irresponsible for any result from use this function.
2.11.7 Executive Busy Override (EBO)
2.11.8 External Call is Time-limited
ABC = Extension number
MN = Limit time = 01 ~ 99 minutes
The line will disconnected automatically when time is up.
Assign time limit is 15 minutes for extension 805
Input * 9 805 15 #
Format 1:
Format 2:
Description:
Example:
Operating:
* 9 ABC MN # ( Assignment for certain extension)
* 9 ABC # ( Cancel time limited for certain extension)
Only effective for external call.
2.12 Call Transferring Management
Format 1:
Format 2:
Description:
# 0 ABC ( Assign busy transferred)
# 0 000 ( Cancel busy transferred)
# 0 ABC
ABC = Entrusted extension number
Extension user can input on his phone to assign calls are
transferred to entrusted extension automatically when his phone is
busy. Allows serial transferring up to five extensions,it is say, the
entrusted extension can entrust other extension to answer incoming
call when it is busy.
The new setting will replace the old one.
2.12.1 Busy Transferred

- 9 -
Chapter 2: Programming and Operating
,
2.12.2 Unconditional Transferred
Format:
Description:
ABC = Entrusted extension number
Extension user can input # * ABC on his phone to assign calls are
transferred to entrusted extension automatically at any time.
# * ABC
1. The extension cannot be used until setting is cancelled, just need to
lift that extension and then on-hook can cancel setting.
2. This function is ineffective for the attendant extensions at operator
attendant service mode when there is call from outside.
ABC = Extension number
Extension A wants to transfer an incoming call to extension B, he
should tap hookswitch and input extension number of B, they can
build internal communication as soon as B lifts handset.
However, if B is busy A will get back to external caller, unless B has
been assigned busy transfer function , so the call will be transferred to
entrusted extension automatically.
External caller is listening music while transferring, whoever A or B
is hangup the remain party will get through caller.
Different conditions would happen when extension B is free:
A doesn't hangup, B answer the phone within 25 seconds can build
internal call with A, whoever A or B is hangup the remain party will
get through to caller.
A doesn't hangup, B doesn't answer the phone within 25 seconds,
A will get back to caller.
A hangup, B answer the phone within 25 seconds can get through
to caller.
A hangup, B will stop ringing if he doesn't answer the phone within
25 seconds, then A start ringing if it is free;if A is busy or no answer
within 25 seconds the line will be disconnected.
Format :
Description:
Condition 1:
Condition 2:
Condition 3:
Condition 4:
Tap hook-switch + ABC
2.12.3 Transfer Incoming Call by Man

- 10 -
2.14 Flash Time
Format:
Description:
Example:
M = 1 = 750ms
M = 2 = 1000ms ( default setting)
M = 3 = 1200ms
M = 4 = 1500ms
M = 5 = 2000ms
Flash Time is duration between on-hook and re-off-hook, if user
doesn't off-hook when flash time is up will be regarded as hangup;
if user off-hook within flash time will be regarded user is ready to
transfer call
Flash Time is 1200ms, if user doesn't off-hook after 1200ms will be
regarded as hangup; if user off-hook after 1200ms will be regarded
ready to make call; if user off-hook within 1200ms will be regarded
ready to transfer call.
* 81M #
.
2.15 External Call Waiting
Format: Hookswitch + #99
Description: When extension user is on the phone with external caller, when has
Beep tone is heard may indicates has another call is incoming, if user
want to answer this call he can tap hookswitch and then input #99 to
place current call is on holding and answer new call, this user will get
back to the first caller as soon as the second caller is on-hook.
Should apply this service from local telecommunication carrier first.
,
2.16 Verify Holding Music
: User can verify holding music performance.
Format :
Description
* 24 #
Verifying just for reference, real timber should be verified in practise.
2.13 Party Conference ( 1 CO & 2 Extensions)
+ +
ABC = Extension number
When an extension user is on the phone with external party he can
add one more extension on the same line by tap hook-switch then
input * ABC ( ABC is additional extension number).
Format :
Description:
Tap hook-switch * ABC
Chapter 2: Programming and Operating

2.19 Restore All Extension Numbers
Restore all extension numbers to factory setting 801 ~808.
Format :
Description:
* 7 000 #
2.17 Extension Number Assignment
abc = Current extension number
ABC = New extension number
Allows change extension number for certain jack.
Change current extension number 803 to 333, 804 to 128.
Input * 7 803 333# 804 128#.
Format 1 :
Description:
Example:
Operating:
* 7 abc ABC #
1. Same extension number is unallowable .
2. Extension number can be assigned from 100 ~ 999 freely.
- 11 -
Some factory settings for your reference as following:
Caller ID signal Adapt with FSK, DTMF
Hookswitch flash time 1000ms (M=2)
Function Default Setting
Operator attendant
801 / 802 / 803 / 804
No
Service mode
Ringing extensions
1
2
3
4
5
6
Attendant extensions for auto-attendant 802 / 803
Access CO line mode Dial 0 or tap hookswitch
2.20 Factory Settings (Default)
All data can be restored to factory setting except followings:
1. Outside line connection assignment.
2. Extension number settings.
Format :
Description:
* 6 000 #
2.18 Extension Number Confirmation
Format:
Description: System will report extension number and its port number afer user
input this format on his extension.
# 81
Chapter 2: Programming and Operating
