Packard Bell M10905-32 User manual

USER GUIDE
M10905-32
TABLET/LAPTOP
2-IN-1 10.1”

10.1” tablet
Smart keyboard
User guide
In the box
USB Type-C
charging cable
Adapter
USER GUIDE
M10905-32
TABLET/LAPTOP
2-IN-1 10.1”
01

• During charging, keep your device and adapter near room temperature for efficient battery charging.
• New batteries are not fully charged.
• New batteries or batteries stored for a long time may take more time to charge.
• The included adapter is intended for indoor use only.
• Service should only be provided by an authorized service provider.
• Never attempt to disassemble, repair or modify the tablet yourself.
• Do not use the tablet in rain or other wet locations.
• Avoid spilling any liquid on the tablet.
• In case the tablet gets wet, unplug all cables and turn off the tablet.
• Do not attempt to dry the tablet with an external heat source.
• Unplug all cables and turn off the tablet before cleaning.
• Use a soft, lint-free cloth to clean the tablet and display.
• Avoid getting moisture in open ports.
• Do not use household cleaners, solvents, alcohol, or abrasives to clean the tablet.
• Routinely check the tablet for proper and safe conditions. If there is any damage, or broken parts, remove the tablet from use.
• If for any reason the screen (display) is fractured or cracked, immediately remove this product from use and contact Customer Support.
• It is rare but possible for seizures to be triggered by light flashes or patterns such as those on computer orTV screens. To reduce exposure to this
potential hazard, play/watch in a well-lit room, sit an appropriate distance from the screen and take 10- to 15-minute breaks every hour.
• Cords could be a strangulation hazard.
• Keep out of reach of children under 3 years of age.
• Children pulling on the cord could cause the computer monitor or other equipment to which the device is connected to fall with
possibility of property damage, serious injury, or death. Adult supervision required during use.
• Long-term exposure to loud sounds, at high volume, may result in permanent hearing loss.
• When using headphones or earbuds, it is recommended that the product is listened to at lower volumes for shorter periods of time.
Set the volume while in a quiet environment; turn the volume down if you cannot hear the people speaking near you.
• Limit the listening time to 90 minutes, followed by a quiet period. The louder the volume, the less time required before your hearing
may be affected.
• If you experience ringing in your ears or hear muffled speech, stop listening and have your hearing checked.
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRICAL SHOCK, DO NOT EXPOSE THIS PRODUCT TO
RAIN OR MOISTURE.
WARNING
RISK OF ELECTRIC SHOCK
DO NOT OPEN
WARNING: TO REDUCE THE RISK OF
ELECTRIC SHOCK, DO NOT REMOVE COVER
OR BACK.
NO USER SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE
PERSONNEL.
THE LIGHTNING FLASH WITH ARROWHEAD
SYMBOL, WITHIN AN EQUILATERAL TRIANGLE,
IS INTENDED TO ALERT THE USER TO THE
PRESENCE OF UNINSULATED “DANGEROUS
VOLTAGE” WITHIN THE PRODUCT’S ENCLOSURE
THAT MAY BE OF SUFFICIENT MAGNITUDE
TO CONSTITUTE A RISK OF ELECTRIC SHOCK
TO PERSONS.
THE EXCLAMATION POINT WITHIN THE
EQUILATERAL TRIANGLE IS INTENDED TO
ALERT THE USER TO THE PRESENCE OF
IMPORTANT OPERATING AND MAINTENANCE
SERVICING INSTRUCTIONS IN THE LITERATURE
ACCOMPANYING THE PRODUCT.
Care & safety precautions
02

Tablet
Reset button
2
�Power button
3
Volume button
4
Headphone jack
1
Front camera
5
Microphone
6
Speakers
7
Quick connector
8
Micro SD card slot
10
USB Type-c charging port
11
Rear camera
9
Buttons, ports & hardware
3
2
1
6 7 8 7
9
10
11
4
5
03

Smart keyboard
Quick connector pins
12
12
04

To install a Micro SD card into the tablet, carefully insert the card as shown below
into the card slot until it clicks and locks into place.
To remove the Micro SD card, gently press it inward to eject.
Inserting a Micro SD card
Tablet
(SIDE)
Expanding the storage
Micro SD
card
05

Tablet
(SIDE)
Battery Tips:
• Turn off Wi-Fi when it’s not in use.
• Lock the tablet (turning the display off) to shorten charging time.
• To optimize battery time and performance, adjust the "Brightness" and "Screen
timeout" options in the Settings panel.
• It is recommended to keep the brightness level at 50% or under if the tablet
is in use while charging.
Connect the tablet to a wall outlet using the included adapter as shown below.
Wall outlet
Adapter
When charging, the lightning
indicator will appear in the
battery icon.
08:10
Charging
USB Type-C cable
USB port
06

Turning on the tablet
Press & hold the �power button until the
startup screen appears.
Power off the tablet
Press & hold the �power button until the
“Power off” option appears.
Briefly press the �power button. (Lock
the tablet to conserve the battery).
Unlock the tablet
Briefly press the �power button, and
slide the ”Lock icon” up.
Lock screen
Tablet (TOP)
Tablet (TOP)
If the tablet malfunctions or freezes, you can
use the reset button.
To reset the tablet, take a metal pin (such as
the end of a paper clip) and gently push the
recessed reset button on the side of the tablet
as shown below.
The tablet will restart.
Press the �power button to start the tablet.
Power ON / OFF & Reset
Metal pin
Reset button
�power button
07

Press and hold the �Power
button to get started.
1
Startup screen
Turning on
08

Follow the initial setup
wizard prompts.
2
Setup wizard
09

If you use Gmail, you already have a Google Account — if not, you can
create an account now.
To use the Google Play, sign into or create a
Google Account.
3
Google Account
10

Google Play
Google Play is your entertainment unbound. It brings together all of the
entertainment you love and helps you explore it in new ways, anytime, anywhere.
We’ve brought the magic of Google to movies, TV, books, apps and games, so you
get more from your content every day.
11

Widgets
To add a widget, press and hold anywhere
on the home screen, and select the “Widgets”
option.
Home Screen
Home
Previous Multitasking
Home Screen
12

Press and hold a widget and place it on the home screen as shown below.
13

Google Duo Play Store
Search...
12:00 PM
Swipe up the home screen to access the Apps Screen.
Home Screen
Apps Screen
14

Home screen
Swipe down from the top edge of the screen to display the Notifications panel where
you can browse and reply to your emails, check software updates, reminders and
more.
Notifications panel
Swipe down once
Notifications and Quick Settings
15

Quick Settings
panel
Quick Settings panel
Swipe
down
twice
Swipe down twice from the top edge of the screen to expand and access the Quick
Settings panel, where you can easily enable/disable Wi-Fi, Bluetooth, Airplane mode
and other settings.
Quick Settings panel
16

Settings
Quick Settings panel
To enable/disable Wi-Fi or Bluetooth®, simply tap the icons on the Quick Settings
panel as shown below.
To access more settings options, select the icon.
Wi-Fi and Bluetooth®
Connecting
17
