PadBot P2 User manual

PadBot User Manual


PadBot P2
01
PadBot
Size
26.6*37.2*110cm
Screen Size 10 inches
Resolution HD1280*800
N.W. 6.5Kg
Battery Capacity 5000 mAh
Charging Input 12.6V/1.5A
Charging Interface 5.5*2.1
Charging Time 6Hours
Running Time 10 Hours
Standby Time 40 Hours
Charger X1 Charging Base X1
2. Accessories

Collision Prevention
& Anti Falling System
10’’ HD Screen
Battery Indicator
PadBot P2
NOTE: Long press Main Switch to start robot.
1. P2 Part Identifications
Foldable Body
Body Fixer
Main Switch
Sim Card Supported
USB Charging Port
Auto Charging System
DC Charging Port
Collision Prevention & Anti Falling System
PadBot P2

PadBot P2
02
PadBot

3. PadBot P2 InstallationBody Installation
1) Screw Body Fixer up to fix robot body, and follow correct direction to connect Body line with Base port.
  
 
2) Use screw key to fix M6 screw, and cover it with offered black plastic part.

Black bulge is
marked in red
Notch

PadBot P2
03
PadBot

4. PadBot P2 Tablet Installation, Connect Tablet with Body properly, and use M4 screw to fix Tablet.
5. How to StartLong press Main Switch until screen start.
6. Should connect with Internet, supporting WiFi & 4G:
WiFi: recommending bandwidth 8Mbps.
4G:Tablet supports Sim Card,Micro Sim Card Supported

Charging
04
PadBot
3.2 Way two: Connect charger into the port of Charging Base, use Charging Base to charge robot. After turn on “ auto
charge” function in App, robot will find Charging Base automatically if short of battery, and charge itself. After finish
charging, it will leave Charging Base automatically.
P2
PadBot P2 Charging
1. Robot equips with lithium battery, please charge robot fully in the first time to guarantee normal operation.
2. During charging, the charger’s light is red, when charge fully, the light turns green. And charger still shows green if connects no robot.
3. Two ways to charge robot:
3.1 Way one: Charging by DC charging port.

05
PadBot
Scan QR Code
Robot Side User Side
Robot Side (PadBot Telepresence Robot)
How to Use
Start robot after fixing Tablet, and open PadBot Telepresence Robot App; download PadBot Telepresence Admin
App as the User side.
1. Open the App
2. Check the QR Code
User Side (PadBot Telepresence Admin)
1. Download the App
2. Register
3. Scan the QR Code
to add robot
4. Manage robot
P2

06
PadBot
PadBot Telepresence Robot App--Main Interface
Click the App, enter into Main Interface. There shows the serial number and QR Code of robot, scan QR Code
with PadBot Telepresence Admin App firstly, to be the robot’s administrator.
Main Interface
P2

07
PadBot
In Main Interface, slide to left to switch to Robot Info page. There are the basic information of robot like: Icon,
nickname, serial number and current status, etc.
Robot Info Page
PadBot Telepresence Robot App--Robot Info
P2

08
PadBot
PadBot Telepresence Robot App--Robot Settings
1.In Robot Info page, click edit button to enter into Settings page.
2.Robot speed: there are 4 speed levels available, the higher level, the quicker speed.
3.Auto Charge: open auto charge function. When robot battery lower than 10%, robot will find nearby Charging
Base to charge itself automatically. Please close this function if no Charging Base available.
4.Collision Prevention: after open this function, robot will detect obstacles automatically during moving, and if
there are obstacles, robot will show obstacles’ place and stop.
Robot Info Page Robot Settings Page
P2

How to download App
lMode 11. iOS: Search “PadBot Telepresence Admin” in App Store
2. Android :Search “PadBot Telepresence Admin” in Google Play.
lMode 2Enter below link to download:
http://s.padbot.cn:9080/cloud/updatemgr/appDownloadLink.action?app=p
lMode 3Scan below QR Code to download
09
PadBot
Ways to download PadBot Telepresence Admin App in iOS or Android device:
P2

How to use PadBot Telepresence Admin App
Log in Page Main Interface
10
PadBot
1. Open PadBot Telepresence Admin App, log in with phone number.
2. After log in, click “+” icon in Main Interface, find “Scan” option to add robot or add a specific video
invitation into list. Scan QR Code in Main Interface to become the administrator of robot, or scan invitation
Code to accept video invitation.
Main Interface
P2

Invitation Share Page
PadBot Telepresence Admin--How to Set Up Video Invitation
As administrator, user can set up video invitation by clicking “Invite” button. In set-up page, user can edit all
details. After finish, share the invitation to relative people to join the video chat.
Main Interface Video Set-up Page
11
PadBot
P2

PadBot Telepresence Admin--Video Call
2. After video connecting successfully, user can control
robot to look up or down, move forward or backward,
turn right or left;click buttons in left bottom to switch
views, adjust volumes, etc.
Main Interface Video Connecting Interface Video Chat Interface
1. In main interface, click “ Video Call” button in robot
(as administrator) or “Video Call” button in meeting list
(as participant) to start video chat, and control robot to
move around after connecting successfully.
12
PadBot
P2

13
PadBot Telepresence Admin--Control
As administrator, user can control robot to move forward or backward, turn right or left by using “Control”
button. In Control page, user can also adjust robot speed and control robot to charge.
PadBot
   
Main Interface Control page
P2

14
PadBot
Technical Support
Q1Cannot do Auto Charging
A1. Check if robot opens auto charging function. Click “Settings” and check if “Robot Self Charging” opened.
2. Using charger to charge robot, if the indicator light is red means the robot can charge successfully.
3. Plug charger into charging base, and pull robot to charge through the charging base. If the indicator light is red, it
means the robot can charge successfully.
4. It’s normal when battery indicator flashes when charging; if indicator flashes when not charging, please check
robot’s hardware.
Q2Does it support 4G LTE card
AYes, it support 4G LTE card, and also support WiFi.
Q3How to set up video invitation?
ALog in PadBot Telepresence Admin App, and click “Invite” button in Main Interface to set up video invitation.
Share invitation with relative people, so they can join the meeting conveniently.
Q4Does it support setting up several invitations?
AYes, administrator can set up several invitations. Open PadBot Telepresence Admin App, choose the robot,
administrator can check already set video invitations. And click “+” in this page for adding new invitations.
Q5How to join the video chat?
AClick the invitation links received from Facebook to join, or use “Scan” function in PadBot Telepresence
Admin App to scan QR Code of the invitation to join.
P2

15
PadBot
Technical Support
Questions about Video Call
Q1Cannot Answer Video Call
A1. Check the camera of robot to see if it works successfully.
2. Check if giving authorization to camera and microphone, if not, please open these authorizations in Settings of
handhold device. For example, to open camera authorization in iOS device is “Settings→Privacy→Camera→PadBot
Telepresence Admin”; for Android device, please follow “Settings→Installed Apps→PadBot Telepresence Admin-
Permissions”.
3. Check if the Internet works fluently.
4. If still cannot do video call, please uninstall the APP and install again.
Q2Does it support group video call?
AFor now, it can only support one to one video call.
Q3How can my friends do video chat with me?
AYou can set up an video invitation, and share the link or invitation QR Code to your friends. By clicking the links or
scanning the QR Code, your friends will join the video call easily.
Q4There are noises in video call
AWhen the communicating parties are in the same place, the mutual voices will interfere with each other and make
noise. It won’t happen in distant call.
P2

Scan to follow PadBot’s Official Account in WeChat
We won’t do further notices for any changes in configurations, pictures, etc, caused by software update, customized requirements or other reasons, please follow the actual conditions. And we bear no responsibility for
any mistakes made by software update or misprinting.
About Us
Matters need Attention
1. Please do not cover anything on collision prevention sensor in robot bottom, to avoid any interference.
2. Please do not toss or throw robot or shake it mightily.
3. Please put the charger or charging base in a proper place for convenient use.
4. Please note that wrong type of battery may evoke explosion, please do follow instructions to dispose used battery.
Contact Us
Inbot Technology Ltd.
ADD: Room 1221-1222, No 140, West Zhongshan
Ave, Tianhe District, Guangzhou, Guangdong, China.
Email: [email protected]
WEB: www.padbot.com
TEL: [phone]
