PAJ ALLROUND User manual

USER MANUAL
ALLROUND FINDER
Comment:
Thank you for the purchase of our finder.
This guidance will show you the handling
and operation of the product. Please keep
this manual for future reference purposes.

ALLROUND Finder v.1.2ENG
© PAJ UG (haftungsbeschränkt)
2
Is this manual too small for you?
For this guidance, we have chosen a
particularlysmall printformat, so that you will
be able to put it in your pocket or in your car,
without requiring too much space.
If this manual is too small for you, it is
possible to find a current version of it as a
PDF here:
www.paj-gps.de/user-manual-englisch
You can display the file in any size and even
search for individual keywords.
Are you familiar with your ALLROUND
Finder?
We recommend using the PAJ Finder App to
easily create commands.

ALLROUND Finder v.1.2ENG
© PAJ UG (haftungsbeschränkt)
3
Still not satisfied?
Then contact us! We will take care of your
problem as soon as possible, sothat youcan
be satisfied!
Contact:
Phone: [phone]
E-Mail: [e-mail]
We would be pleased if you did not directly
open a case or leave a negative feedback,
but give us first the opportunity to find a
solution to your problem. This would be of
benefit to both parties. Contact us and we
will gladly help you! 

ALLROUND Finder v.1.2ENG
© PAJ UG (haftungsbeschränkt)
4
Satisfied?
If you are satisfied with our product, then we
would be very happy to get a positive
feedback or 5 stars from you!
Best regards and many thanks,
your PAJ-team
Artikel wie
beschrieben
Kommunikation
Versandzeit
Versand- und
Verpackungskosten
Kriterien Bewertungen

ALLROUND Finder v.1.2ENG
© PAJ UG (haftungsbeschränkt)
5
Quickstart –ALLROUND Finder of PAJ
Step 1: activation of the SIM Card
In order to use the ALLROUND finder, you
need a standard size SIM Card. This is not
included in the standard scope of delivery.
We recommend using a prepaid card, as
costs will be charged from the direct use
only. Activate your card and make sure that
it works.
Many SIM cards are now flexible. Initially,
you find them in standard frames, but then
you can break them down in other sizes
and reassemble them.
Nano
Standard
Mikro

ALLROUND Finder v.1.2ENG
© PAJ UG (haftungsbeschränkt)
6
Step 2: Disable PIN-Code and voice mail
of the SIM Card
Insert your SIM Card
in your mobile phone.
Disable the PIN Code
request of the SIM
Card over the
security setting on
your cell phone. For
most providers, it is
possible to disable
the voice mail by
calling ##002#.
For further details,
please refer to the
instructions of use of
your mobile operator
or network provider.

##002#
SIM-PIN
off

ALLROUND Finder v.1.2ENG
© PAJ UG (haftungsbeschränkt)
7
Step 3: Insert your SIM Card in the
ALLROUND finder
Insert the completely activated SIM Card
without PIN-Code in the ALLROUND
finder. Open the rubber gasket on the
outside and slide the SIM Card in the
SIM Card holder.

ALLROUND Finder v.1.2ENG
© PAJ UG (haftungsbeschränkt)
8
Please make sure that the bevelled edge of
your SIM Card (as shown) is located at the
top right and that the gold contacts face
downwardly.
In order to insert the SIM Card deeply
enough, please use a sharp object. Please
watch for a correct position of the SIM Card.
Introduce the SIM Card until it clicks.

ALLROUND Finder v.1.2ENG
© PAJ UG (haftungsbeschränkt)
9
Step 4: First start
Turn on the ALLROUND
Finder by pushing upward
the switch on the left side.
Then the LED lights turn on.
As soon as you get GPS
reception, the blue LED
flashes.
Meaning of LED lights:
GREEN
GPRS / GSM status
BLUE
GPS status
RED
Battery status/state of
charge

ALLROUND Finder v.1.2ENG
© PAJ UG (haftungsbeschränkt)
10
Step 5: Call and track your ALLROUND
Finder
Call the number of the SIM card that you
inserted in the GPS finder in order to request
a location.
After that, the finder will send you an SMS
with the coordinates and a link to Google
Maps directly to your mobile phone. As soon
as you use click on the link, the finder shows
the precise location. Please make sure that

ALLROUND Finder v.1.2ENG
© PAJ UG (haftungsbeschränkt)
11
your unit has sufficient reception power and
is not located on a covered space at the
beginning.
For more detailed information, please read
the user manual on the following pages.
The team of PAJ-GPS wishes you lots of
fun with your ALLROUND Finder!

ALLROUND Finder v.1.2ENG
© PAJ UG (haftungsbeschränkt)
12
Table of contents
1Scope of delivery ......................... 15
2Grounds........................................ 16
3Product graphics.......................... 19
4Technical Data.............................. 21
5Starting up.................................... 23
5.1 Activation of the SIM Card.............. 23
5.2 Deactivation of the PIN
Code/Mailbox................................. 25
5.3 Insertion of the SIM Card ............... 27
5.4 Loading.......................................... 29
5.5 Launching the product for the first
time, turning on and LED signal ..... 29
5.6 Authorization.................................. 34
5.7 Resetting to the factory defaults..... 39
Send an SMS with the following:.... 39

ALLROUND Finder v.1.2ENG
© PAJ UG (haftungsbeschränkt)
13
6Machine setup and commands ... 40
6.1 Password change........................... 41
6.2 Location request ............................ 43
6.3 Call monitoring (bug mode)............ 49
6.4 Radius alarm.................................. 51
6.5 Alarm for over speeding................. 54
This function allows you to send an
SMS to the authorized numbers when
exceeding a certain speed. ............ 54
6.6 Shock alarm................................... 57
6.7 Standby mode................................ 60
6.8 GPS-signal upon movement
(recommended setting) .................. 62
6.9 SOS button.................................... 64
6.10 Low battery power.......................... 66
6.11 Time adjustement........................... 67
6.12 The most important commands in the
overview......................................... 68

ALLROUND Finder v.1.2ENG
© PAJ UG (haftungsbeschränkt)
14
7Frequently asked questions in
overview ....................................... 71
8Safety............................................ 74
9Notes for the disposal of waste
batteries........................................ 76
9.1 Free withdrawal of used batteries... 76
9.2 Meaning of the battery icons .......... 77
10 PAJ location portal ...................... 79
10.1 Register portal access.................... 79
10.2 Connect the ALLROUND Finder with
the location portal........................... 86
10.3 Deregistration/Disconnect the internet
connection ..................................... 97
10.4 Test access and permanent use of the
portal access.................................. 98

ALLROUND Finder v.1.2ENG
© PAJ UG (haftungsbeschränkt)
15
1 SCOPE OF DELIVERY
The scope of delivery includes:
ALLROUND Finder by PAJ
USB charging cable
User Manual
We are constantly improving our products.
Therefore, the contents of the manual may
change. The latest version can be found on
our website at:
www.paj-gps.de/user-manual-englisch

ALLROUND Finder v.1.2ENG
© PAJ UG (haftungsbeschränkt)
16
2 GROUNDS
Based on the GSM mobile network and the
GPS satellites, this product can transmit its
location via SMS or GPRS. In addition, you
can use a microphone to hear the ambient
sounds of the finder.
The ALLROUND Finder offers you
numerous possibilities for position finding.
For more information about how to
implement them, please go to chapter 6.

ALLROUND Finder v.1.2ENG
© PAJ UG (haftungsbeschränkt)
17
SIM cards with contract term can also be
used. However, we recommend using a
prepaid SIM card for the GPS tracker.
Please do not use SIM cards that charge
automatically as soon as they reach a
specific account balance. This prevents you
from incurring increased costs due to an
incorrect setting.

ALLROUND Finder v.1.2ENG
© PAJ UG (haftungsbeschränkt)
18
Recommended for the first start of the
ALLROUND Finder are places that are not
covered, such as the garden or terrace (not
in the apartment, garage, cellar or similar).
Please note that the GSM signal is not
supplied in some locations by the respective
network provider.
Please enter the uppercase and lowercase
of the letters when entering the commands.
In addition, the plus characters (+) and the
quotation marks ("") are not to be sent. If
you receive an errormessage,the command
was not accepted. Please check the entries
carefully and then repeat the procedure.

ALLROUND Finder v.1.2ENG
© PAJ UG (haftungsbeschränkt)
19
3 PRODUCT GRAPHICS
Schalter
Notruftaste
up = on
down = off
Battery terminal
SOS-Emergency key
Turn on/off

ALLROUND Finder v.1.2ENG
© PAJ UG (haftungsbeschränkt)
20
SIM-Card
compartement
Microphone
LED-Signal
