Palax C700 COMBI User manual

1-2018
translation
OPERATING INSTRUCTIONS
PALAX C700
COMBI
powered by tractor
powered by electricity
powered by combustion engine
swinging conveyor of 4.3-metres with hydraulic
motor
SERIAL NUMBER _______________________
YEAR OF MANUFACTURE _______________________
PALAX
LAHDENTIE 9
FI-61400 YLISTARO, FINLAND
TEL. [phone]
WWW.PALAX.FI

1-2018
II
translation
CONTENTS
1 Basic specifications and responsibilities...................................................................1
1.1 Foreword...........................................................................................................1
1.2 EU Declaration of Conformity..........................................................................2
1.3 Intended use of the machine..............................................................................3
1.4 Warning signs ...................................................................................................3
1.5 Type markings...................................................................................................4
1.6 The main dimensions and models of the machine.............................................5
1.7 Safety instructions.............................................................................................5
1.8 Noise emission and vibration............................................................................6
1.9 Responsibilities of the operator ........................................................................6
1.10 Operating conditions.........................................................................................7
1.11 Terms of warranty.............................................................................................7
1.12 Operating instructions for the combustion engine and the winch ....................8
2 Taking delivery and assembly of the machine..........................................................9
2.1 State of delivery and acceptance control..........................................................9
2.2 Main parts of the machine.................................................................................9
2.3 Installation of the adjustment lever for the splitting wedge (Fig. 2).................9
2.4 Assembly of the log-stop, Figure 3..................................................................10
2.5 Topping up hydraulic oil.................................................................................10
2.6 Bringing the conveyor into the work position, Figures 4 and 5......................10
2.7 Bringing the conveyor into the transport position..........................................11
2.8 Lifting and transferring the machine, Figures 6A and 6B..............................12
3 DRIVING POWER.................................................................................................13
3.1 Powered by a tractor.......................................................................................13
3.2 Revolutions range of the PTO-shaft................................................................13
3.3 Stop switch of the tractor-powered machine (Figure 7).................................13
3.4 Automatic tightening of the V-belts (Figure 8) ...............................................14
3.5 Required measures in an emergency situation................................................14
3.6 Selecting the operating mode: powered by tractor or electricity (Figures 9 and
10) 14
3.7 Electric drive, start and emergency stop.........................................................15
3.8 Starting 15
3.9 Emergency stop of an electric-motor-powered machine ................................15
3.10 Starting the electric motor in frost..................................................................15
3.11 Honda petrol engine, start, stop and emergency stop.....................................16
4 Use of the firewood processor, crosscut operation .................................................17
4.1 Preparations before the use of the machine, all models.................................17
4.2 Operating the crosscut saw, before the operation..........................................17
4.3 During the operation.......................................................................................17
4.4 Placing the wood on the deck..........................................................................18
4.5 Crosscut operation..........................................................................................18

1-2018
II
I
translation
4.6
Disturbances during crosscut operation and their remedy.............................18
5 Use of the firewood processor, splitting operation .................................................19
5.1 Splitting cylinder.............................................................................................19
5.2 An automatic high-speed valve is available as an option...............................19
5.3 Splitting wedges ..............................................................................................19
5.4 Manual adjustment of the splitting wedge, Figure 15 ....................................20
5.5 Hydraulic height adjustment of the splitting wedge Fig. 16, optional...........20
5.6 Adjusting the speed of the splitting wedge adjustment cylinder, Figure 17....20
5.7 Disturbances during the splitting operation and their remedy.......................20
5.8 Re-splitting the logs safely..............................................................................21
5.9 How the safety devices affect the operation of the machine, Figure 18 .........21
6 Operation of the splitting mechanism.....................................................................22
6.1 Solitting sensor, Fig. 19..................................................................................22
6.2 Parts of the launch device (Figure 20) ...........................................................22
6.3 Operational principle of launching.................................................................22
6.4 Hand-start of the splitting motion, Figure 21.................................................23
6.5 Parts of the hydraulic valve (Figure 22).........................................................23
6.6 Operation of the valve.....................................................................................23
7 Maintenance of the machine ...................................................................................24
7.1 Crosscut saw-blade.........................................................................................24
7.1.1 Removing the crosscut saw-blade (Figures 23 and 24).....................24
7.1.2 Sharpening the chain..........................................................................24
7.1.3 Stressing the saw-blade......................................................................24
7.2 Guide for crosscut saw-blade (Figure 25)......................................................25
7.2.1 Adjustment of the saw-blade guide ...................................................25
7.3 Automatic tightening of the angular gear V-belts, Fig. 26.............................25
7.4 Changing the V-belts, angular gear................................................................25
7.5 Changing the oil in the angular gear..............................................................26
7.6 Lubricating the machine, Fig 28.....................................................................26
7.7 Clutch for hydraulic pump, Fig. 29................................................................27
7.8 Changing the oil..............................................................................................27
7.9 Maintenance of the valve ................................................................................27
7.10 Detent end of valve..........................................................................................28
7.11 Lubricating the spool shifter, Fig. 33 .............................................................28
7.12 Structure of the detent end and the correct order of the parts, Fig. 34..........28
7.13 Initial settings of the valve (Figures 35 and 36).............................................29
7.14 Adjustment of launch bar clearance ...............................................................30
7.15 Conveyor transmission, Fig. 37......................................................................30
7.16 Conveyor chains, Fig. 38................................................................................30
7.17 Cleaning the machine......................................................................................30
7.18 Washing the machine ......................................................................................31
7.19 Storing the machine.........................................................................................31

1-2018
I
V
translation
8
Maintenance schedule.............................................................................................32
9 Malfunctions and their remedy...............................................................................33
10 Electric diagrams ....................................................................................................34

1
translation
1 BASIC SPECIFICATIONS AND RESPONSIBILITIES
1.1 Foreword
This Instruction Manual is intended for a professional operator of the machine. The
operator must have usual general knowledge and skills. For example, the buyer of a
tractor-powered machine is expected to master the use of power take-off shaft
transmission.
Before the installation and operation, the operator of the machine must become
thoroughly familiar with the contents of the manual. The operator is also obliged to
gain familiarity with the operating controls of the machine and the emergency stop
mechanism. For more information about our products, please visit our website at
www.palax.fi.
NOTE! Keep this manual with the machine at all times.

2
translation
1.2 EU Declaration of Conformity
Directive 2006/42/EC
Manufacturer: Ylistaron Terästakomo Oy
www.palax.fi
Lahdentie 9
FI-61400 Ylistaro
Finland
[phone]
The person in charge of Technical Construction File: Kai Koskela,[email protected]
Product: PALAX C700 Combi
a firewood processor with 4,3-m discharge conveyor
Powered by: tractor PTO, electric motor or combustion engine
Models: TR Powered by tractor equipped with own hydraulic
system
TR/SM Powered by tractor / electric motor
PM Combustion engine
Serial number of the machine:
We hereby certify that the machine meets the requirements of the Government Decree
12.6.2008/400 on safety of machinery through which the Machine Directive
2006/42/EC has been put into effect, and that during the manufacturing process the
following harmonized standards have been applied.
SFS-HANDBOOK 93-series, SFS-EN 349-1+A1, SFS-EN 609-1+A1, SFS-EN 618, SFS-EN
847-1+A1, SFS-EN 847-2+A1, SFS-EN 847-3, SFS-EN 953+A1, SFS-EN 954-1, SFS-EN
982+A1, SFS-EN 1870-6, SFS-EN 4254-1, SFS-EN 11684, SFS-EN 12100-1+A1, SFS-EN
12100-2, SFS-EN 13850, SFS-EN 13857, SFS-EN 14121-1, ISO/TR 14121-2, SFS-EN 60204-
1+A1.
Notified body No.0504:
Luonnonvarakeskus ( Luke )
Mittaus ja standardisointi ( Vakola )
Vakolantie 55
03400 VIHTI
Ylistaron Terästakomo Oy
10.2.2016
Pekka Himanka
Managing Director

3
translation
1.3 Intended use of the machine
This Firewood Processor with Conveyor is intended for the purpose of producing
firewood primarily of round timber, but of logs as well.
Use of the machine for any other purposes is prohibited.
Note! Max. capacity of the machine
 For cutting, the maximum diameter of the tree is about 25 cm.
 The maximum length of the log to be processed is 4 metres. If the logs are longer
than this, they must be pre-cut to at most 4 metres.
1.4 Warning signs
Beware of the crosscut
saw-bar
Read the
instruction
manual Lifting points
Use eye guards
and hearing
protectors
Wear clothes,
which do not hang
loosely
Wear safety shoes
Use protective
gloves
Manual stop of
the splittig
cylinder
Direction of
rotation of tthe
blade
Revolutions
range for PTO-
shaft

4
translation
1.5 Type markings
Nameplate on the machine
 The name and address of the manufacturer
 Designation of the machine type
 Serial number and year of manufacture
 Total weight of the machine
 Diameter of the crosscut saw-blade 700mm
 Diameter of the saw-blade hole 35mm
 Max 2000 r.p.m.
 Nameplate at the rear of the crosscut saw housing
 Always mention the serial number and year of manufacture when ordering spare
parts.
Nameplates on the electric drive
3-phase motor
 Voltage 380 V
 Output 7.5 kW
Hydraulic height
adjustment of the
splitting wedge,
optional
Manual
start of the
splitting cylinder
Stay away from moving
partsof the machines
Beware of PTO
-
shaft
Disconnect the machine from the
electric supply before taking to any
service measures
The machine may
only be operated
by one person
Power switch for the
oil heater
Safe distance from the
conveyor
Stopping the machine
by slackening the V-
belts

5
translation
1.6 The main dimensions and models of the machine
Item
Powered by tractor
TR /operated
by electricity
Powered by
combustion engine
Output - 7.5 kW 13 hp
Fuse size - 16 A -
Weight 660 kg 720 kg 710 kg
Height/width/length 2400 mm x 2,830mm x 1,450mm
Crosscut deck
Length 950 mm, with extension table
1,950 mm
Height of crosscut deck 800 mm
Diameter of blade/hole 700/ 35 mm
Max. rotation speed of blade 2000 r.p.m.
Max. diameter of the log 25cm
Max. length of tree, splitting 600 mm
1.7 Safety instructions
General regulations and restrictions
 The maximum length of the log to be cut is 4 metres. Danger of turning over!
 The machine is exclusively intended for the production of firewood.
 The machine may only be operated by one person.
 The machine must be equipped with appropriate lights and reflectors for
transportation on public roads.
 The danger zone around the conveyor is 5 metres to the sides and to the rear
 Always lock the crosscut deck in the rear position for transportation.
 Always shift and lock the table extension into its rear position for transportation.
 The three-point linkage of the tractor is of size-category two. If using a tractor larger
in size, check that there is sufficiently space for the PTO-shaft and its protective
guard.
 Never use the machine indoors – risk of dust generation. The use of a machine
powered by combustion engine involves danger of exhaust gases.
 Never remove any safety-related devices from the machine.
 The width of the machine equipped with the 4,3-m conveyor is about 2.83 m. This
means that, depending on the size of the tractor, the transport width of the
conveyor may extend outside the rear wheel on the right-hand side.
The operator
 Every person operating the machine, must thoroughly study the entire user
manual.
 Always use eye guards and hearing protectors.
 Always wear protective shoes.
 Always wear work gloves.
 Do not wear loosely-fitting clothing.
Before use
 Make sure that all other people stay outside the operating range.
 Always hitch the tractor-driven machine to the three-point linkage. Also ensure that
sufficient space is provided for the PTO-shaft and its guard.

6
translation
 Release the crosscut chute from its transport position before launching the
crosscut operation.
 Only use a fault-free power take-off drive shaft and attach the chain for the shaft-
guard. Max. 450 r.p.m.
 Only operate the machine on a sufficiently firm and level surface.
 Only operate the machine in an adequately lit space.
 Keep the exhaust pipe of the combustion-engine-driven unit at a safe distance from
anything that might catch fire! Danger of fire!
 Always check that all the covers are intact and properly fastened.
 Always check that the crosscut saw-bar is intact.
 Always ensure that the electric conductors are intact.
 Always check that all the controls are operational.
 Always check the oil level and make sure that the hydraulic hoses and components
are free of damage.
 Before starting the work, make sure that the machine is firmly in position.
During operation
 Carelessness during the cut-off operation constitutes a major hazard!
 During the cut-off operation, make sure that the tree is always supported at the
support rollers of the crosscut deck. Danger of rolling over!
 Exercise particular caution when cutting knotty or crooked logs, because, as a
result of faulty cutting, the log might roll over or twist the saw-bar with enough force
to break it.
 Keep the working space clean and clear of foreign objects.
 Always stop the engine for refuelling.
 Always stop the machine before servicing.
 Only cut one log at a time.
 Danger! Stay away from moving parts.
 Beware of the hot exhaust pipe on the combustion-engine-driven unit!
1.8 Noise emission and vibration
 Equivalent continuous A-weighted sound-pressure level at the workstation is 85.4
dB (A) and the sound power level is 105.4 dB (A).
 The vibration emission values do not exceed the limit 2.5m/s2.
1.9 Responsibilities of the operator
 All the safety-related devices are necessary to ensure a sufficient level of safety.
 The machine operator is responsible for the flawless operation of the safety-related
devices and for ensuring that the machine is serviced in a due manner.
 Modifying the construction of the machine is prohibited.
 The machine must never be operated under the influence of alcohol or drugs.
 The machine may only be used to produce firewood.
 The operator is responsible for ensuring that no one else is subjected to any
danger.
 As the operator, remember that you are fully responsible for any injuries caused by
the removal of any safety-related devices from the machine, or by any modification
to its operation.

7
translation
 The C700 Combi is a very safe machine provided that it is operated carefully
following the instructions and that it is serviced regularly.
1.10Operating conditions
 Always place the machine on as level a surface as possible.
 Prevent risks, such as slipping in winter, by organising the work sit–e in a due
manner.
 Only operate the machine in an adequately lit space.
 It is recommended that a suitable stand be purchased or made that enables the
trees to be processed where the logs are ready at the level of the in-feed deck.
Hence, unnecessary lifting may be avoided and the work can proceed much faster.
 The suitable temperature range for operation is approximately -20 to +30 degrees
Centigrade.When starting the machine in severe frost, first allow it to idle at low
speed for about 5 to 10 minutes. This way, the oil warms up and flows better, so
risk of damage to the seals is reduced.
 No restrictions concerning the weather apply.
 Make sure that no other people, especially children, are present inside the
operating range.
 Never use the machine indoors – risk of dust generation. Use of the combustion
engine-powered machine may involve danger of exhaust gases.
1.11Terms of warranty
The warranty period runs for 12 months from the date of purchase.
The warranty covers
 Parts, damaged during normal operation of the machine due to defects in
material or workmanship.
 The reasonable repair cost in accordance with the agreement between the
seller and the manufacturer or the buyer and the manufacturer.
 A new part delivered as a replacement for the defective one.
The warranty does not cover
 Defects due to normal wear, faulty operation or negligent maintenance.
 The crosscut saw-blade, V-belts or oil.
 Defects in the machine due to any modifications which the buyer has made or
ordered from a third party and which have affected the machine in such a way
that it can no longer be considered to correspond to its original configuration.
 Other possible expenses or financial demands due to the above-mentioned
measures.
 Any indirect costs and/or travel expenses incurred from making repairs under
the guarantee.
 The combustion engine, whose obligations under warranty lie with the
manufacturer of the engine.
 For parts changed during the warranty period, the warranty expires at the same
time as the warranty period of the machine.
 Consult your dealer about matters related to the warranty.

8
translation
1.12Operating instructions for the combustion engine and the winch
Refer to the manuals on our website at www.palax.fi for detailed operating and
servicing instructions for the combustion engine and the winch. In matters related to
the combustion engine turn to the nearest Honda dealer.

9
translation
2 TAKING DELIVERY AND ASSEMBLY OF THE
MACHINE
2.1 State of delivery and acceptance control
 The machine is delivered almost ready-assembled and test driven.
 In order to prevent transport damage, the adjustment lever for splitting wedge 12,
the operating lever for log-stop 10 and the protective net for crosscut saw-blade 9
have been removed and packed separately. (Fig. 1)
 Check the delivered goods without delay.
 If the product shows transport damage, contact the transport company and your
dealer immediately.
2.2 Main parts of the machine
1. Table extension
2. Oil tank
3. Emergency stop lock
4. Emergency stop
5. Manual start of the splitting
cylinder
6. Disengaging clutch of the
angular gear
7. Crosscut deck
8. Saw-blade cover
9. Protective net for saw-
blade
10.Log-stop control lever
11.Protective net for splitting
chute
12.Adjustment lever 12 for the
splitting wedge
13.Conveyor
1
1 2 3 4
5
6 7 8 9
10 11 12 13
Fig. 1. Main parts of the machine
Install protective net 9 as shown in Fig. 1 so that its front edges and the front
edges of the protective net for splitting chute 11 come into line.
2.3 Installation of the adjustment lever for the splitting wedge (Fig.
2)
 Remove the splint, nut and cup springs.
 Position the adjustment lever so that the friction plate A comes between the frame
bar and the lever.
 Put the adjusting lever in place.
 Install the cup springs as instructed by the sticker.

10
translation
 Put the crown nut in place, adjust the lever to a suitable tightness and put the splint
in place.
NOTE! Do nut lubricate the friction plate A!
2.4 Assembly of the log-stop, Figure 3
1. Unscrew the attachment nut A for the log-stop.
2. Push the shaft B into the hole in the table and place the log-stop A on the shaft
B.
3. Push the shaft in place and fix the cotter.
4. Put the spring C in place.
5. Adjust the log-stop A as follows:
A. When the table is in the rear posistion,
the log-stop is in the limiting position.
B. When the deck is pushed forward, the log-stop folds completely away from
the log.
2.5 Topping up hydraulic oil
 Hydraulic oil volume 40 litres.
 Oil type Univis 32, SHELL Tellus 32, NESTE HYDRAULI 32 or equivalent.
 Only use fresh, clean oil.
 Observe particular cleanliness during the oil change, because smooth operation of
the machine is highly dependent on the purity of the oil.
2.6 Bringing the conveyor into the work position, Figures 4 and 5
1. Release the locks for the conveyor.
2. Uncoil the wire of the winch about twelve rounds.
3. Pull out the conveyor and leave it supported by the winch rope.
4. Lower the conveyor to the ground using the winch.
2
A
B
C
3
A
C
B
Fig.
2. Installing the adjustment lever
for the splittingwedge,
Fig. 3. Installingthe log-stop,

11
translation
5. Pull open lock A (Fig. 4).
6. Swing down the top of the conveyor.
7. Remove the support bar B for the conveyor chain (Fig. 5) and attach it to the
holes C at the edge of the conveyor.
8. Put the attachment chain and the splints back in place.
4
A
5
B
A
C
Fig. 5. Unfolding the conveyor 2/2
Fig. 4. Unfolding the comveyor 1/2
2.7 Bringing the conveyor into the transport position
1. Disconnect the attachment chain for the conveyor.
2. Lower the conveyor to the ground and connect the support bar B for the
conveyor chain, Fig. 5.
3. Pull lock A open and lift up the conveyor top.
4. Ensure that lock A is properly locked.
5. Raise the conveyor using the winch.
6. Tighten the winch wire lightly in order to prevent it uncoiling from the spool.
7. Lock the conveyor in the transport position.
NOTE! Always hold by the winch handle as you lower the conveyor.

12
translation
2.8 Lifting and transferring the machine, Figures 6A and 6B
Lifting the machine is allowed:
 Using the forks of a forklift truck
placed under the frame beams of
the machine in the front or rear,
observing the centre of gravity of
the machine..
 By lifting points A at the upper part
of the machine. Fig. 6A.
NOTE! The machine must be
equipped with appropriate lights
and reflectors for transportation on
public roads. Fig. 6B
9
A
A
Fig. 6A. Lifting points of the machine
6B
Fig. 6B. Example of additional lighting

13
translation
3 DRIVING POWER
The Palax C700 Combi firewood processor may be driven by a tractor, an electric
motor or a combustion engine.
3.1 Powered by a tractor
 Always connect the machine to the tractor’s three-point linkage and ensure that the
space reserved for the PTO-shaft and its guard is sufficient.
 A suitable size for power take-off drive shaft is, for example, a BONDIOLI 143 or
WALTERSCHEID W 2100.
 No safety clutch is required for the PTO-shaft.
 Only use fault-free PTO-shafts and always attach the chains for the shaft-guard to
the machine.
NOTE! When you disconnect the PTO-shaft from the tractor, hang it in the
hook on the machine.
 The machine comes with towing pins of 28 mm.
 If the power take-off of the tractor has a high-speed range, then it should be used,
because the horsepower requirement of the circular saw is small.
 Make sure that the speed of the power take-off shaft does not exceed 450 r.p.m.
3.2 Revolutions range of the PTO-shaft
 The suitable revolutions range is 400-450 r.p.m.
3.3 Stop switch of the tractor-
powered machine (Figure 7)
 The tractor-powered machine is equipped
with a special emergency stop device to
immediately disengage the transmission
between the angular gear and the saw-blade
shaft.
 In case of emergency, pull the lever A.
 When lever A is pulled, tightening wheel B
swings down and the V-belts slacken (Figure
8). Disengagement lever A locks up and the
belts remain slack.
7
A
Fig. 7. Stop switch of the TR
model

14
translation
3.4 Automatic tightening of the V-
belts (Figure 8)
As the switch is released, the tightening wheel,
affected by spring C, presses the V-belts on the
slack side and the V-belts of the angular gear
and the blade shaft automatically remain at
correct tightness.
8
B
C
Fig. 8. Tightening the V-belts
3.5 Required measures in an emergency situation
If the clutch has been used in an emergency situation, e.g. when a log has stuck in the
circular saw-blade as a result of a mistake during the sawing, then immediately
disconnect the power take-off transmission of the tractor as well, because the pulley of
the angular gear can wear down the V-belts unnecessarily.
NOTE! When the clutch is reset to the operating position, the power take-
off drive shaft must be disconnected from the tractor.
Only use the clutch in an emergency situation!
3.6 Selecting the operating mode: powered by tractor or electricity
(Figures 9 and 10)
 The machine is equipped with a system to prevent simultaneous operation in two
modes.
 When the cover plate is shifted to the left (Figure 9), it is possible to connect the
extension cable, and when it is shifted to the right (Figure 10), it is possible to
connect the power take-off shaft.
9
A
Fig. 9. Selecting the powered-by-
electricity mode
10
A
Fig. 10. Selecting the powered-by-tractor
mode

15
translation
3.7 Electric drive, start and emergency stop
 The power output of the motor is 7,5 kW at a speed of 1450 r.p.m.
 The machine is equipped with an automatic Y-D starter with an emergency stop
feature.
 All electric installations must be completed.
 In the 380 V-system the fuse size is 16 A slow.
 The cross-section of the required extension cord is 2,5 mm2.
 Before starting up the machine, check that it rotates in the direction shown by the
arrow at the end of the motor.
 Check the direction of rotation by allowing the motor to run for a short while and,
after that, stopping it immediately.
NOTE! Only skilful professionals are allowed to carry out the electric work
that changing the direction of rotation requires.
Make sure that the extension cord, that you use, is equipped with a switch that
enables changing the direction of rotation of the motor using a screwdriver.
3.8 Starting
 Press the start button. In the Y-position the motor starts rotating at slow speed with
low output. The start phase takes several tens of seconds.
 As the engine speed increases, the D-position is switched on and the motor quickly
reaches full speed. As the position D is switched on, the signal light between the
start and stop switches illuminates.
NOTE! The machine must not be operated until the motor has reached full
speed, because in the Y-position the output of the electric motor is very low.
3.9 Emergency stop of an electric-motor-powered machine
 The emergency stop is carried out by depressing the Emergency Stop button,
button B on the starter.
 The button is reset by pulling it up.
3.10Starting the electric motor in frost
 In severe frost, the hydraulic oil and the oil in the angular gear can become so cold
and viscous or the V-belts so rigid that the motor cannot be started.
 If operating the machine under cold conditions, we recommend that less viscous
hydraulic oils be used.
NOTE! A 300 W electric heater carpet with thermostat is available as an option
for the hydraulic oil tank. We recommend using the carpet whenever the
machine is operated under cold conditions. The starter is equipped as standard
with a lever switch for the heater. Keeping the heating switched on for about 1-2
hours is enough to make the oil sufficiently fluent.

16
translation
3.11Honda petrol engine, start, stop and emergency stop
 Refer to the engine’s instruction manual for detailed operating and servicing
instructions.
 Check the oil level in the engine and top it up if necessary.
NOTE: petrol is highly flammable!
 Use 95E petrol in the combustion engine.
 Always stop the machine for refuelling.
 Take care not to spill petrol on the hot engine.
Starting the motor Fig. 12
1. Check that the engine V-belts have
been slackened using the clutch.
2. Shift the gas lever to about half-way,
activate the choke and pull the starter
grip.
3. As soon as the motor starts, reduce
the setting of the choke gradually to
make the engine run smoothly.
4. Switch on the V-belt drive by shifting
the clutch lever B and increasing the
engine revolutions to maximum.
5. The pre-set engine revolutions are
equal to about 2000 revolutions on the
saw-blade shaft.
12
Fig. 12. Clutch lever for V-belts in a
combustion-engine-powered
machine
Stopping
1. Shift the gas lever to idling.
2. Turn off the engine with the switch.
3. Close the fuel valve.
 The V-belts must be kept tight during transportation, to prevent the engine from
“jumping”.
Emergency stop
 Turn off the engine with the switch.
