Palax C750.2 User manual

1
Palax C750.2 Translation 1-2020
INSTRUCTION MANUAL
C750.2
Powered by tractor
Powered by electric motor

2
Palax C750.2 Translation 1-2020
SERIAL NUMBER AND YEAR OF MANUFACTURING_______________________
Lahdentie 9
61400 Ylistaro, FINLAND
Tel. [phone]
palax.fi

3
Palax C750.2 Translation 1-2020
1BASIC SPECIFICATIONS AND RESPONSIBILITIES.................................................................................... 5
1.1 FOREWORD............................................................................................................................................................5
1.2 EU DECLARATION OF CONFORMITY ..................................................................................................................... 6
1.3 INTENDED USE OF THE MACHINE ...........................................................................................................................7
1.4 WARNING SIGNS....................................................................................................................................................7
1.5 NAMEPLATES ........................................................................................................................................................8
1.6 THE MAIN DIMENSIONS AND MODELS OF THE MACHINE......................................................................................... 9
1.7 SAFETY INSTRUCTIONS..........................................................................................................................................9
1.8 NOISE EMISSION AND VIBRATION ........................................................................................................................ 10
1.9 RESPONSIBILITIES OF THE OPERATOR .................................................................................................................. 10
1.10 OPERATING CONDITIONS ................................................................................................................................ 11
1.11 TERMS OF WARRANTY .................................................................................................................................... 11
1.12 OPERATING INSTRUCTIONS FOR THE WINCH ................................................................................................... 12
2TAKING DELIVERY AND SETTING UP THE MACHINE FOR OPERATION........................................ 12
2.1 LIFTING THE MACHINE ........................................................................................................................................ 12
2.2 THE TRANSPORT SET-UP AND UNPACKING........................................................................................................... 12
2.3 ACCEPTANCE INSPECTION ................................................................................................................................... 12
2.4 MAIN PARTS OF THE MACHINE,FIG 1 .................................................................................................................. 12
2.5 OPERATING CONTROLS OF THE MACHINE,FIG.2 ................................................................................................. 13
2.6 TABLE EXTENSION,FIG.3 ................................................................................................................................... 14
2.7 BRINGING THE CONVEYOR INTO THE WORK POSITION,FIGS.4, 5, 6AND 7 .......................................................... 14
2.8 BRINGING THE CONVEYOR INTO THE TRANSPORT POSITION,FIG.4, 5, 6AND 7 ................................................... 15
3OPERATION OF THE FIREWOOD PROCESSOR POWERED BY DIFFERENT POWER SOURCES 16
3.1 POWERED BY A TRACTOR .................................................................................................................................... 16
3.2 EMERGENCY STOP SWITCH OF THE TRACTOR POWERED MACHINE,FIG.9............................................................ 16
3.3 REQUIRED MEASURES IN AN EMERGENCY SITUATION.......................................................................................... 17
3.4 STARTING UNDER COLD CONDITIONS .................................................................................................................. 17
3.5 ELECTRIC DRIVE,START AND EMERGENCY STOP,FIG.10.................................................................................... 17
3.6 STARTING THE ELECTRIC MOTOR ........................................................................................................................ 18
3.7 EMERGENCY STOP OF A MACHINE POWERED BY ELECTRIC MOTOR,FIGURE 10 ................................................... 18
3.8 THE MACHINE IS EQUIPPED WITH A SYSTEM TO PREVENT SIMULTANEOUS OPERATION IN TWO MODES,FIG.11... 18
3.9 OPERATION UNDER COLD CONDITIONS................................................................................................................ 19
4FULLY HYDRAULIC CONTROL OF THE POWER 70 S FIREWOOD PROCESSOR, FIG 13.............. 20
4.1 MASTERING THE SAFETY DEVICES....................................................................................................................... 20
4.2 JOYSTICK-VALVE,NO.1, FIG.13......................................................................................................................... 20
4.3 OPERATING LEVER FOR THE SPLITTING WEDGE NO.2, FIG.13 ............................................................................ 20
4.4 ADJUSTMENT VALVE NO.3 FOR PROCEEDING SPEED OF CROSSCUT BLADE,FIG.12, ONLY IN S-MODEL ............... 21
4.5 JOYSTICK-VALVE,NO.4, FIG.13......................................................................................................................... 21
5MECHANICAL CONTROL OF THE POWER 70 FIREWOOD PROCESSOR USING THE MULTI-
FUNCTION LEVER ...................................................................................................................................................... 21
5.1 MASTERING THE SAFETY DEVICES....................................................................................................................... 21
5.2 CONTROL LEVERS FOR POWER 70, FIG.14A ....................................................................................................... 21
6USE OF THE FIREWOOD PROCESSOR, CROSSCUT OPERATION........................................................ 22
6.1 OPERATING THE CROSSCUT SAW,BEFORE THE OPERATION ................................................................................. 22
6.2 DURING THE OPERATION ..................................................................................................................................... 22
6.3 CUTTING TO EQUAL LENGTH AND FEEDING INTO THE SPLITTING CHUTE.............................................................. 23
6.4 FEEDING THE LAST LOG FOR SPLITTING............................................................................................................... 23
7DISTURBANCES DURING CROSSCUT OPERATION AND THEIR REMEDY....................................... 23
7.1 CROOKED TREES ................................................................................................................................................. 23
7.2 BIG TREES ........................................................................................................................................................... 23
7.3 CUTTING OF SMALL TREES WITHOUT SPLITTING.................................................................................................. 24
7.4 DISTURBANCES DURING THE SPLITTING OPERATION AND THEIR REMEDY ........................................................... 24
7.5 RE-SPLITTING THE LOGS SAFELY......................................................................................................................... 24
8ACCESSORIES FOR THE FIREWOOD PROCESSOR................................................................................. 24
8.1 SPLITTING CYLINDER .......................................................................................................................................... 24

4
Palax C750.2 Translation 1-2020
8.2 MANUALLY-OPERATED HIGH-SPEED VALVE,FIGURE 16 ............ VIRHE.KIRJANMERKKIÄ EI OLE MÄÄRITETTY.
8.3 AUTOMATIC HIGH-SPEED VALVE......................................................................................................................... 24
8.4 SPLITTING WEDGES ............................................................................................................................................. 25
9MAINTENANCE OF THE MACHINE.............................................................................................................. 25
9.1 REMOVAL AND CHANGE OF THE CROSSCUT BLADE,FIG 17 AND 18..................................................................... 25
9.2 TIGHTENING THE V-BELTS,CENTRE SHAFT/BLADE SHAFT,FIG.18...................................................................... 25
9.3 REPLACEMENT OF THE V-BELTS,CENTRE SHAFT /SAW-BLADE SHAFT ................................................................ 26
9.4 SHARPENING THE BLADE,HARD-METAL BLADE .................................................................................................. 26
9.5 SETTING THE SAW-BLADE,HARD-METAL BLADE................................................................................................. 26
9.6 SPARE BLADE ...................................................................................................................................................... 26
9.7 TIGHTENING THE V-BELTS,ANGULAR GEAR /CENTRE SHAFT .............................................................................. 26
9.8 REPLACEMENT OF V-BELTS,ANGULAR GEAR /CENTRE SHAFT............................................................................. 26
9.9 TIGHTENING THE ÍNFEED CONVEYOR BELT,FIG.19............................................................................................. 27
9.10 REPLACEMENT OF THE INFEED CONVEYOR BELT ............................................................................................ 27
9.11 DIRECTION OF ROTATION OF THE BELT........................................................................................................... 27
9.12 CHANGING THE OIL IN THE ANGULAR GEAR.................................................................................................... 27
9.13 CHANGING THE HYDRAULIC OIL,FIG.21........................................................................................................ 28
9.14 LUBRICATING THE MACHINE:REFER TO THE MAINTENANCE SCHEDULE ........................................................ 28
9.15 SERVICING THE MAIN VALVE,FIG.24............................................................................................................. 28
9.16 DETENT END OF THE VALVE,FIG.24 A........................................................................................................... 29
9.17 LUBRICATING THE SPOOL SHIFTER,FIG.24 B................................................................................................. 29
9.18 STRUCTURE OF THE DETENT END AND THE CORRECT ORDER OF THE PARTS,FIG.26....................................... 29
9.19 INITIAL SETTINGS OF THE VALVE .................................................................................................................... 30
9.20 TIGHTENING AND LUBRICATION OF THE CONVEYOR CHAIN,FIG.27............................................................... 30
9.21 CLEANING THE CONVEYOR............................................................................................................................. 30
9.22 WASHING THE MACHINE................................................................................................................................. 30
9.23 STORING THE MACHINE. ................................................................................................................................. 30
10 MAINTENANCE SCHEDULE ........................................................................................................................... 31
11 MALFUNCTIONS AND THEIR REMEDY...................................................................................................... 32
12 ELECTRIC DIAGRAMS..................................................................................................................................... 33

5
Palax C750.2 Translation 1-2020
1 Basic specifications and responsibilities
1.1 Foreword
This Instruction Manual is intended for a professional operator of the machine. The
operator must have usual general knowledge and skills. For example, the buyer of a
tractor-powered machine is expected to master the use of power take-off shaft
transmission.
Before the installation and operation, the operator of the machine must become thoroughly
familiar with the contents of the manual. The operator is also obliged to gain familiarity with
the operating controls of the machine and the emergency stop mechanism. For more
information about our products, please visit our website at www.palax.fi.
NOTE ! Keep this manual with the machine at all times.

6
Palax C750.2 Translation 1-2020
1.2 EU Declaration of Conformity
Directive 2006/42/EC
Manufacturer: TP Silva Oy
www.palax.fi
Lahdentie 9
FI-61400 Ylistaro
Finland
[phone]
The person in charge of Technical Construction File: Timo Jussila, [e-mail]
Product: Palax C750 Ergo, Palax C750 Pro, Palax C750 Pro+
a firewood processor with 4,3-m discharge conveyor
Powered by: Tractor P.T.O. or electric motor
Models: TR Powered by tractor equipped with own hydraulic system
TR/SM Powered by tractor or electric motor
Serial number of the machine:
We hereby certify that the machine meets the requirements of the Government Decree
12.6.2008/400 on safety of machinery through which the Machine Directive 2006/42/EC
has been put into effect, and that during the manufacturing process the following
harmonized standards have been applied.
SFS-HANDBOOK 93-series, SFS-EN 349-1+A1, SFS-EN 609-1+A1, SFS-EN 618,
SFS-EN 620, SFS-EN 847-1+A1, SFS-EN 847-2+A1, SFS-EN 847-3, SFS-EN
953+A1, SFS-EN 954-1, SFS-EN 982+A1, SFS-EN 1870-3+A1, SFS-EN 4254-1,
SFS-EN 11684, SFS-EN 12100-1+A1, SFS-EN 12100-2, SFS-EN 13850, SFS-EN
13857, SFS-EN 14121-1, ISO/TR 14121-2, SFS-EN 60204-1+A1.
TP Silva Oy
1.1.2023
Seppo Koiranen
Managing Director

7
Palax C750.2 Translation 1-2020
1.3 Intended use of the machine
This Firewood Processor with Conveyor is intended to be used for production of firewood
from round timber. Use of the machine for any other purposes is prohibited.
Maximum size of the wood
For cutting, the maximum diameter of the tree is about 30 cm.
The maximum length of the log is 4-5 m.
When handling long trees, we recommend using a specific log-lifting deck with rollers or
hydraulic feed.
1.4 Warning signs
Do not wear loosely
hanging clothes
Use eye guards and
hearing protectors
Wear safety shoes
Wear work gloves
Lifting point of the machine
The protective net for the splitting chute cannot be opened unless the
crosscut saw-blade is in its upper position
Lubrication point
Emergency stop (SM) Direction of rotation of the blade/PTO shaft
Interrupting the splitting
Launch of splitting.
Safe distance
from the
conveyor

8
Palax C750.2 Translation 1-2020
The explanations of the markings for the machine control functions are discussed in
chapter 4.
Revolutions range of the
PTO shaft
Lifting point of the
machine
Beware of PTO
shaft
Read the User
Manual for the
machine
Beware of rotating blade
Stay away from
moving parts of the
machine
Disconnect the
machine from
the electric
supply before
taking to any
service
measures
The machine may
only be operated
by one person
Stopping the
functions of the
machine by
slackening the V-
belts
Reversing the in-feed
conveyor
Sawing Feeding with the in-feed
conveyor
Take care that the log is not in an upright position when
being fed for splitting
Adjustment of cutting
length

9
Palax C750.2 Translation 1-2020
1.5 Nameplates
Nameplate on the machine
Name and address of the manufacturer.
Mark showing type of machine.
Total weight of the machine.
Diameter of the crosscut saw-blade 750 mm, the hole 35 mm.
The highest permitted rotational speed 1500 r.p.m
Max. hydraulic pressure 200 bar.
Serial number and year of manufacture.
Nameplate at the rear of the blade housing
Nameplates on the electric drive
3-phase motor.
Voltage 230/380 V or 380/600 V, may vary depending on the country.
Output 10,4 kW.
1.6 The main dimensions and models of the machine
Machine model
PALAX C750 Ergo
PALAX C750 Pro, Pro+
DRIVING POWER
TR
TR/SM
TR
TR/SM
Weight
810 kg
900 kg
840 kg
930kg
Powered by electricity
12,6 kW; fuse size: minimum 25A
Height/width/length
Transport position 2.45m / 1.3m / 2.8m
In-feed conveyor
Length 2.4m Height 0.9 m
Diameter of blade/hole
750mm/ 35mm
Max. rotation speed of blade
1500 r.p.m.
Max. diameter of the log
Max. cutting diameter of the log 30 cm
Max./min. length of the log
The maximum length of log that can be split is 55 cm.
The 4.3 m firewood conveyor is included in the weight.
1.7 Safety instructions
General regulations and restrictions
The maximum length of the log to be cut is 4 metres. Danger of turning over! If no log-
stand or log-deck is used.
The machine is exclusively intended for the production of firewood.
The machine may only be operated by one person.
The machine must be equipped with lights for transportation on public roads.
When transporting the machine on public roads hitched to the three-point linkage of a
tractor, the maximum allowed driving speed is 25 km/h.
The danger zone around the conveyor is 5 metres to the sides and to the rear.
Lift and lock the infeed deck and the discharge conveyor in the transport position for
transportation.
The three-point linkage of the tractor is of size-category two. If using a tractor larger in
size, check that there is sufficiently space for the PTO shaft and its protective guard.
Only persons over 18 years of age are allowed to operate this machine.
Never remove any safety-related devices from the machine.

10
Palax C750.2 Translation 1-2020
The width of the machine equipped with the 4,3-m conveyor is about 2.83 m. This
means that, depending on the size of the tractor, the transport width of the conveyor
may extend outside the rear wheel on the right-hand side.
The operator
Every person operating the machine, must thoroughly study the entire user manual.
Always use eye guards and hearing protectors.
Always wear protective shoes.
Always wear work gloves.
Do not wear loosely-fitting clothing.
Before use
Always carry out the required preparations on both the machine and the conveyor
before starting the operation.
Make sure that all other people stay outside the operating range.
Only use a fault-free PTO shaft and attach the chain for the shaft-guard. The
permissible revolutions range of the PTO shaft is 450-540 r.p.m.
Only operate the machine on a sufficiently firm and level surface.
Only operate the machine in an adequately lit space.
Keep the tractor-powered machine connected to the three-point linkage. Also ensure
that sufficient space is provided for the PTO shaft and its guard.
Always check that all the covers are intact and properly fastened.
Always check that the crosscut saw-bar is intact.
Always ensure that the electric conductors are intact.
Always check that all the controls are operational.
Always check the oil level and make sure that the hydraulic hoses and components are
free of damage.
Before starting the work, make sure that the machine is firmly in position.
During operation
Carelessness during the cut-off operation constitutes a major hazard!
During the cut-off operation, make sure that the tree at the cutting point always leans
against the support roller of the crosscut deck and the infeed roller: danger of rolling
over!
Exercise particular caution when cutting knotty or crooked logs, because, as a result of
faulty cutting, the log might roll over or twist the saw-bar with enough force to break it.
Keep the working space clean and clear of foreign objects.
Always stop the machine and disconnect the power supply cable or the power take-off
shaft before servicing.
Only cut one log at a time.
Danger! Stay away from moving parts.
1.8 Noise emission and vibration
Equivalent continuous A-weighted sound-pressure level at the workstation is 88.5 dB (A)
and the sound power level is 108.5 dB (A). The vibration emission values do not exceed
2.5 m/s2.
1.9 Responsibilities of the operator
The machine may only be used to produce firewood.

11
Palax C750.2 Translation 1-2020
All the safety-related devices are necessary to ensure a sufficient level of safety.
The PALAX C750 is a very safe machine provided that the instructions supplied are
properly followed, the regular maintenance routines are duly executed and the work is
carried out without haste.
It is the responsibility of the operator to ensure before the work is started that all the
safety-related devices are in perfect order and the machine has been serviced in a due
manner.
The operator is responsible for ensuring that no one else is subjected to any danger.
Modifying the construction of the machine is prohibited.
The machine must never be operated under the influence of alcohol or drugs.
Remember that as the operator you are responsible for any injuries caused if safety-
related devices have been removed from the machine.
1.10 Operating conditions
Always place the machine on as level a surface as possible.
Prevent risks, such as slipping in winter, by organising the work site in a due manner.
Otherwise the weather conditions do not set any restrictions on the operation. When
starting the machine in severe frost, allow it to idle at about 1/4 of the maximum speed
for about 5 to 10 minutes.
Only operate the machine in an adequately lit space.
It is recommended that a suitable stand be purchased or made that enables the trees
to be processed where the logs are ready at the level of the in-feed deck. Hence,
unnecessary lifting may be avoided and the work can proceed much faster. We
recommend using either the Palax Mega log-deck or the Palax Log log-stand.
The most suitable temperature range for operation is approximately - 20 to +30
degrees Centigrade. Otherwise, the weather conditions do not set any restrictions on
the operation.
Make sure that no other people, especially children, are present inside the operating
range.
Never use the machine indoors, owing to the risk of dust generation or the danger of
exhaust gases.
1.11 Terms of warranty
The warranty period runs for 12 months from the date of purchase.
The warranty covers
Parts which have been damaged during normal operation of the machine due to any
defects in material or workmanship.
The reasonable repair cost as set forth in the agreement between the buyer and the
manufacturer.
A new part is delivered as a replacement for the defective one.
The warranty does not cover
Defects due to normal wear, faulty operation or negligent maintenance.
The crosscut saw-blade, V-belts and oils.
Defects in the machine due to any modifications which the buyer has made or ordered
from a third party and which have affected the machine in such a way that it can no
longer be considered to correspond to its original configuration.
Other possible expenses or financial claims due to the above-mentioned
measures.

12
Palax C750.2 Translation 1-2020
any indirect costs and/or travel expenses incurred from making repairs under the
guarantee.
For parts changed during the warranty period, the warranty expires at the same time as
the warranty period of the machine.
Consult your dealer about matters related to the warranty.
1.12 Operating instructions for the winch
Please refer to the user manual of the winch or visit our website at www.palax.fi for more
detailed operating instructions for the winch.
2 TAKING DELIVERY AND SETTING UP THE MACHINE FOR
OPERATION
2.1 Lifting the machine
There are lifting lugs for lifting the machine with a crane at both ends of the machine, at
the rear edge of the splitting chute and at the rear edge of the infeed deck.
The machine can be lifted with a forklift truck from both sides. There are guide rails for
lifting forks under the chassis.
2.2 The transport set-up and unpacking
The machine is delivered almost ready assembled and with the conveyor attached.
In order to avoid damage during transportation, the machine is delivered partly
dismantled so that all the protruding levers and the hitching parts of a tractor-powered
machine have been removed and packed separately.
The extension table for the infeed conveyor and the loading conveyor are in the
transport position.
The angular gear is filled with transmission oil.
2.3 Acceptance inspection
Check the delivered goods without delay.
If the product shows transport damage, contact the transport company and your dealer
immediately.
2.4 Main parts of the machine, Fig 1
1. Infeed conveyor support
2. Infeed conveyor belt
3. In-feed conveyor
4. Conveyor support
5. Emergency stop lever, tractor-powered machine
6. Blade cover
7. Multi-function lever, crosscut and infeed operations
8. Protective net for splitting chute
9. Adjustment lever 12 for the splitting wedge
10.Conveyor

13
Palax C750.2 Translation 1-2020
2.5 Operating controls of the machine, Fig. 2
1. Optional hydraulics
2. Electric motor
3. Y/D starter
4. Manual start of the splitting cylinder
5. Adjustment of proceeding speed of the crosscut saw-blade
6. Log-clamp
1 2 3 4 5 6 7 8 9 10
1
1 2 3 4
5 6 7 8

14
Palax C750.2 Translation 1-2020
7. Hydraulic height adjustment of splitting wedge
8. Joystick valve for controlling the cutting, launching of splitting and infeed conveyor
operations
2.6 Table extension, Fig. 3
1. Disconnect the rubber strap A.
2. Pull open the locking lever B.
3. Swing the conveyor down and place the leg into the opening C in the frame. Re-
connect the rubber strap.
2.7 Bringing the conveyor into the work position, Figs. 4, 5, 6 and 7
Remove the locking pins A for the conveyor, Fig. 4 and 5.
Release the locks B, Figs. 4 and 5.
Unwind the winch wire a few rounds.
Pull out the conveyor and leave it supported by the winch rope.
Lower the conveyor to the ground using the winch.
4
B
A
5
A
B

15
Palax C750.2 Translation 1-2020
Pull open the lock A, Fig. 7
Swing down the top of the conveyor.
Remove the support bar B for the conveyor chain, Fig. 7, and attach it to the holes C at
the edge of the conveyor.
Put the splints back in place.
WARNING!
Always hold by the winch handle as you lower the conveyor.
2.8 Bringing the conveyor into the transport position, Fig. 4, 5, 6 and 7
Release the locks for the conveyor.
Lower the conveyor to the ground and connect the support bar B for the conveyor
chain, Fig. 7.
Pull lock A open and lift up the conveyor top.
Ensure that lock A is properly locked.
Raise the conveyor using the winch.
Tighten the winch wire lightly in order to prevent it uncoiling from the spool.
Lock the conveyor to the transport support using the lock, the chain and the pin.
6
7
B
A
C

16
Palax C750.2 Translation 1-2020
Adjusting the log-stop, Fig. 8
The log-stop A can be set to any position between 25 and 55 cm.
Set the desired cutting length using the scale, and tighten the log-stop screws with a
wrench.
As the crosscut blade lowers, the log-stop automatically turns away from the log,
allowing it to fall down freely.
The log-stop is equipped with two shear-pins B.
The shear-pins are intended for protecting the log-stop structure against damage that
may occur if a tree of excess length ends up in the splitting chute and the pusher
pushes it to a vertical position against the log-stop.
Bolt size M 8 x 100, partial thread, strength class 8.8, M8 Nyloc nut.
NOTE ! Always put the nut on the log-stop plate side.
3 OPERATION OF THE FIREWOOD PROCESSOR POWERED BY
DIFFERENT POWER SOURCES
3.1 Powered by a tractor
The PTO shaft must be able to transmit an output of about 26 kW: for example,
BONDIOLI 143, WALTERSCHEID W 2300 or EGT40.
No safety clutch is required for the PTO shaft.
Only use fault-free PTO shafts and always attach the chains for the shaft-guard to the
machine.
When you disconnect the PTO shaft from the tractor, hang it in the hook on the
machine.
If the power take-off of the tractor has a high-speed range, it is recommended to use it,
because the horsepower requirement of the Firewood Processor is small. The suitable
range of speeds for the PTO shaft is from min. 450 to max. 540 rpm.
3.2 Emergency stop switch of the tractor powered machine, Fig. 9
The tractor-powered machine is equipped with a special Rapid Stop Device which
disengages the transmission from the angular gear to the machine in a matter of
seconds and stops the operation of the machine completely.
In an emergency situation, push lever A upwards to the point where it locks. In this
8
B
A

17
Palax C750.2 Translation 1-2020
position, the drive belts are loose.
NOTE ! Only use the lever in an emergency, because the V-belts, which slightly
chafe the angle-drive pulley, may wear too quickly.
3.3 Required measures in an emergency situation
If the switch has been used in an emergency situation, e.g. when a log has stuck in the
circular saw-blade as a result of a mistake during the sawing, immediately also switch off
the power take-off transmission of the tractor, because the pulley of the angle drive can
wear down the V-belts unnecessarily.
NOTE ! Switch the Rapid Stop Device back to the operation position before
engaging the transmission of the tractor.
3.4 Starting under cold conditions
When starting the machine in severe frost, allow it first to idle at low speed for about 5
minutes; this warms up the oil. Warming up the oil reduces wear on the hydraulic
system significantly and prevents damage.
3.5 Electric drive, start and emergency stop, Fig. 10
The power output of the motor is 12,6 kW and the speed is 1,480 rpm.
The machine is equipped with an automatic Y-D starter with an emergency stop
feature.
All the electric installations have been made ready.
The cross-section of the extension cord required for a tension of 380 V must be at least
6 mm2.Fuse size: minimum 25A
When starting up the machine, check that the direction of rotation corresponds to the
arrow at the end of the motor.
To check the direction of rotation, run the motor for a short while and then stop it
suddenly.
The motor A and the starter B are located under the protective cover.

18
Palax C750.2 Translation 1-2020
NOTE ! Only a skilled craftsman is allowed to change the direction of rotation.
NOTE ! Only use an extension cord equipped with a changeover switch for
rotation direction of the motor that can be turned by screwdriver.
3.6 Starting the electric motor
Press the start button. In the Y-position the motor starts rotating at slow speed with low
output. The start phase takes several tens of seconds.
As the engine speed increases, the D-position is switched on and the motor quickly
reaches full speed. As the motor reaches full revolutions, the signal light on the starter
illuminates.
NOTE ! The machine must not be operated until the motor is running at full
speed.
3.7 Emergency stop of a machine powered by electric motor, Figure 10
Push down the emergency stop button B.
Turn the pushbutton clockwise to release it.
3.8 The machine is equipped with a system to prevent simultaneous operation
in two modes, Fig. 11
When the cover plate C is turned down, it is possible to connect the extension cord.
When the cover is turned up, it is possible to connect the PTO shaft.
Suspension hook A for the power take-off shaft.
A
10
C
B

19
Palax C750.2 Translation 1-2020
WARNING! Never remove from the machine the plate that prevents the
simultaneous operation in two modes. Always remove the power take-off shaft
before operating the machine by electricity.
3.9 Operation under cold conditions
When an electric motor-powered machine is operated in temperatures below -15 degrees
Centigrade, the use of a less viscous hydraulic oil is recommended, because a machine
with electric drive takes full revolutions right from the start of operation. Suitable oils are,
for example, ISO VG22S multigrade oil or synthetic hydraulic fluid.
Electric heater for oil tank, Fig.12
A 300 W electric heater carpet with adhesive tape attachment and thermostat is
available as an option for the hydraulic oil tank.
The starter comes as standard equipped with operating switch for the heater. Fig 10C.
Heating the oil for 1-2 hours is sufficient to enable smooth starting.
The size of the heater carpet is 200 x 300 mm.
Capacity 300 W.
Equipped with thermostat.
Strongly adherent glue for attachment of the carpet.
NOTE ! Only a skilled craftsman is allowed to carry out electrical work for the
heater.
11
A
B
C

20
Palax C750.2 Translation 1-2020
4 FULLY HYDRAULIC CONTROL OF THE PALAX C750 Pro and Pro+,
Fig 13
Cross-cutting, start of the splitting and operation of the in-feed conveyor are effortlessly
controlled using the fully hydraulic joystick-valve 1, Fig.13.
4.1 Mastering the safety devices
1. The crosscut blade does not come down - close the protective net for the splitting
chute. The machine does not operate, if the protective net is open.
2. The protective net for the splitting chute cannot be opened – lift the crosscut blade to
its upper position. The protective net cannot be opened if the crosscut blade is not in
the upper position.
3. The splitting operation cannot be launched with manual control – close the protective
net for the splitting chute. The machine does not operate, if the protective net is open.
4.2 Joystick-valve, No. 1, Fig. 13
Push the joystick forward and move it in direction B – D; the conveyor feeds the log
against the log-stop.
Push the joystick forward and move it in direction B – C; the conveyor reverses.
Pull the joystick back in direction A; the saw-blade comes down and cuts through the
wood.
Push the joystick forward in direction B; the crosscut blade comes up and, at the same
time, launches the splitting.
4.3 Operating lever for the splitting wedge No. 2, Fig. 13
Pull it back, the splitting wedge lowers.
Push it forward, the splitting wedge raises.
13
1
4
3
2
B
A
D
D
