PALAZZANI RAGNO TSJ 30.1 Use and care manual

PALIFT - DIVISION
RAGNO TSJ 30.1
OPERATIONS AND SAFETY MANUAL
RAGNO
SERIAL NUMBER
YEAR OF PRODUCTION
MANUAL N°
TSJ 30.1 / C
PT 4664
2021
NM 935
Palazzani Industrie SpA
Via del Pavione, 25050 Paderno Franciacorta (BS) - Italy
Tel. 0039 030 6857073 - Fax 0039 030657079
Original instructions
(TSJ 98 for US/Canada)

Warning for the users
The contents of this manual are based on know-how, designs, technology applications,
used on exclusive basis by Palazzani Industrie SpA, and therefore protected by national
and international intellectual property.
Any reference to names, dates and addresses of other Companies is not on purpose and,
unless otherwise indicated, it is only an example, to better understand the products made
by Palazzani Industrie SpA
The processing of text and images are evaluated with the utmost care, in any case Pa-
lazzani reserves the right to modify and / or update the information contained herein, to
correct typographical errors and / or inaccuracies, without notice or obligation on the
part thereof.
This manual contains all the information necessary for the operators for the normal and
planned use of Palazzani products.
The content of this manual is purely technical and owned by Palazzani Industrie SpA.
Any part of this manual may be translated into another language and/or adapted and/or
reproduced in another form and/or through any mechanical, electronic, photocopying,
recording, etc. tool, without the prior written consent of Palazzani.
The owner Company enforces its rights according to the law.
The documents are prepared in accordance with section 1.7.4 of the CE Directive
2006/42 / CE (Directive on the approximation of the laws of the member states relating
to machinery) and in compliance with point 7.1 of EN 280: 2015.
Any request of additional information about the machine, using the specific QR code
fixed on the machine.

Palazzani Industrie thanks you for purchasing its product and invites you to read this
manual and other attached manuals or documents.
In the manual you will find all needed information for the correct use and service of the
supplied machine.
Careful attention to follow the instructions and the reading of this manual in every part
is strictly necessary.
You are also invited to contact Palazzani Industrie or a local Dealer directly for spare
parts enquiry, suggestions on any special equipment choice or, simply, for any indica-
tion regarding the ordered machine.
The manual is identified by a unique code, divided into chapters and paragraphs num-
bered progressively.
Figures are numbered progressively for every chapter and are identified by the descrip-
tion.
The specific equipment instruction manuals are attached to this manual where present
The documents provided with the machine is composed of this Use and Maintenance
Manual, the equipment Manual and the Manuals of machines or semi-machines and
of the items listed in this documents which are an integral part of the Use and Mainte-
nance Manual and for which the same recommendations/indications of this Manual are
valid.
Conformity of the instructions
These warning and use instructions of the machine are conforming to the CE Directive
2006/42/CE, Annex I essential requirement of safety and health 1.7.4.
Pay attention to any different local regulations.
The following technical standards have been consulted:
EN ISO 12100 Safety of machinery. - General principles for design - Risk assessment
and risk reduction.
UNI 10653 Technical documentation - Quality of product technical documentation.
EN 280 : 2015 point 7.1
Organisation of the manual
The Machine Instruction and Warnings Manual is organized as follows:
A) General Manual consisting of the following sections:
CAP. 1 : GENERAL CHARACTERISTICS
CAP. 2: SAFETY DIRECTIONS
CAP. 3 : NORMAL WORKING CONDITIONS
CAP. 4 : EMERGENCY CONDITIONS

CAP. 5 : MAINTENANCE AND CHECK
CAP. 6 : ASSIGNMENT OR DEMOLITION OF THE MACHINE
B) Spare parts catalog
C) Instruction manuals drawn up by the respective Manufacturers for the main commer-
cial systems purchased by the Manufacturer and integrated on the machine.
Warranty
The guarantee of Palazzani Industrie S.p.A. covers defects in materials and
workmanship.
• DURATION OF THE WARRANTY: the warranty covers all repairs of Products car-
ried out within the time limits provided for in the sales contract.
• OBJECT OF THE GUARANTEE: the guarantee applies to Products or parts thereof
marked with serial numbers or other identification systems used by the Company.
• The guarantee is void if unauthorized persons intervene on the supply.
The guarantee described above is valid unless otherwise agreed between the Distributor
and the Customer.
Instruction Manual scope
The manual,as well as the CE certificate of conformity, is an integral part of machine
and must always accompany it even when it is moved or resold.It is owner’sresponsi-
bility to keep this documentation intact and available to the User, allow consultation,
throughout the life of the product itself.
In case of loss or destruction, a copy can be requested from the manufacturer specifying
the exact model, serial number and year of production.
The manual reflects the state of the art at the time of supply, the undersigned company
reserves the right to make any changes it deems useful to its products, without having to
update manuals and systems relating to previous production batches.
This Instruction manual provides all specific information needed for the correct use of
your Palazzani machine.
THE PURCHASER MUST HAVE THE CONTENTS OFTHE MANUALREAD,
MAKE SURE THE SAME UNDERSTANDING, TO ALL PERSONS IN CHAR-
GE OF THE USE AND MAINTENANCE OF THE MACHINE.

Language of the manual
The original manual is in English.
Any translations into additional languages must be made starting from the original in-
structions.
The Manufacturer is responsible for the information contained in the original Instruc-
tions; translations into different languages cannot be fully verified, so if an inconsi-
stency is found, it is necessary to follow the original text or contact Palazzani Industrie.
Some symbols are used in the manual to draw the reader’s attention and highlight some
particularly important aspects of the discussion. The following table describes the mea-
ning of the different symbols used that comply with the EN ISO 7010 standard.
SYMBOL MEANING NOTE
Danger Indicating danger with risk of accident, even mor-
tal, of the staff.
Keep the max attention to the texts showing this
symbol
!Warning Indicating warningof possible deterioration or
danger to the machine, equipments or other perso-
nal object of the customer/user.
Keep attention to the text showing this symbol
Important Obligation of a special behaviour or activity for a
safe machine managing or for information to the
staff
Additional
information.
Note
The texts including complementary information
show this symbol.
These information are not directly linked to the de-
scription of a function or with the procedure deve-
lopment.
They can refer to other complementary documents,
such as Instruction Manuals for attachments, tech-
nical documents or other sections of the present
manual.

Summary
1. GENERAL CHARACTERISTICS 1
1.1. INTRODUCTION AND INTENDED USE 1
1.2. DESCRIPTION 1
1.3. DIRECTIVE AND RULES 1
1.4. LIFE CYCLES 2
1.5. SPECIAL USE 2
1.6. DIMENSIONS AND PERFORMANCES 3
1.7. DIMENSIONS 6
1.8. WORKING AREA 8
1.9. MAIN GROUPS OF THE PLATFORM 11
2. SAFETY PRECAUTIONS 12
2.1. GENERAL SAFETY INFORMATION 12
2.2. OPERATOR TRAINING AND KNOWLEDGE 13
2.2.1. PRE OPERATION 13
2.2.2. MACHINE INSPECTION 14
2.3. INTENDED USE 16
2.4. SPECIAL INDICATIONS 16
2.4.1. ELECTROCUTION HAZARDS 18
2.4.2. TRIP AND FALL HAZARDS 20
2.4.3. CRUSHING AND COLLISION HAZARDS 22
2.4.4. TIPPING HAZARDS 24
2.5. IMPROPER USE 27
2.5.1. TOWING, LIFTING, AND HAULING 28
2.6. MAINTENANCE 28
2.6.1. MAINTENANCE HAZARDS 28
2.6.2. BATTERY HAZARDS 30
2.7. OTHER SAFETY PRECAUTIONS 31
2.7.1. HANDLING WITHOUT CAGE (FOR MODELS TSJ - XTJ - TZ) 32
2.7.2. HANDLING WITHOUT CAGE (FOR MODEL TZX) 32
2.8. ADDITIONAL RISKS, PRECAUTIONS, WARNINGS 33
2.8.1. Danger for the operator 33
2.8.2. Residual risks generated by the elements under pressure 33
2.8.3. Residual risks during maintenance 33
2.8.4. Explosive atmosphere 34
2.8.5. Slipping 34
2.8.6. Stumbling 34
2.8.7. Circuits failure 35
2.8.8. Lighting 35
2.8.9. Risk of heating / burning 35
2.8.10. Risks due to movement 35
2.8.11. Risks for the exposed persons 35
2.9. ADDITIONAL WARNINGS 36
2.10. OPERATOR’S PROTECTIVE EQUIPMENT 37
2.11. ENVIRONMENTAL CONDITIONS 39
2.11.1. Operating environment 39
2.11.2. Conditions of storage 40

2.12. TRANSPORT (MODELS XTJ, TSJ, TZ) 41
2.13. TRANSPORT (MODEL TZX) 44
3. NORMALWORK CONDITIONS 46
3.1. MAIN CONTROL PANEL 46
3.2. REMOTE / WIRED CONTROL 47
3.3. CAGE CONTROL PANEL 48
3.4. PLATFORM STARTING PROCEDURE 49
3.5. USE WITH DIESEL ENGINE 49
3.6. PLATFORM SELFPROPELLING 53
3.7. TRACKS ENLARGING (in models where this function is available) 55
3.8. STEERING 55
3.9. AUTOMATIC BRAKE 55
3.10. SPECIAL FUNCTION BUTTON FN 56
3.11. LEVELING THE MACHINE 58
3.12. AERIAL WORK 61
3.13. WORKING AREAAUTOMATIC LIMITING DEVICE 63
3.14. LOAD LIMITING DEVICE 64
3.15. CAGE ROTATION 64
3.16. AUTOMATIC CAGE ORIENTATION 64
3.17. ELECTRIC CURRENT GENERATOR (OPTIONAL) 65
3.18. INTERCOM (OPTIONAL) 65
3.19. MANEUVERS AND GROUND CONTROL PANEL 67
3.20. MANEUVERS AND CAGE CONTROL PANEL 67
3.21. SPECIAL DIRECTIONS 68
3.22. DISPLAY TOUCH SCREEN 69
4. EMERGENCY CONDITIONS 73
4.1. DEFINITION 73
4.2. EMERGENCY CONDITIONS 73
4.3. PERSONS RECOVERY FROM THE CAGE IN EMERGENCY 76
4.4. STABILIZERS RECOVERY 81
4.5. TRAVELLING 82
4.6. QUICK TROUBLESHOOTING FOR THE OPERATOR 82
5. MAINTENANCE AND CHECK-UP 84
5.1. ORDINARY MAINTENANCE - GENERAL INFORMATION 84
5.2. HYDRAULIC OIL FEATURES 85
5.3. DAILY CHECK 86
5.4. WEEKLY CHECK 89
5.5. QUARTERLY CHECK 90
5.6. SIX MONTH MAINTENANCE 93
5.7. ANNUAL MAINTENANCE 94
5.8. FOUR YEAR MAINTENANCE 95
5.9. EXTRAORDINARY MAINTENANCE 96
5.10. CHECK OF HYDRAULIC CIRCUIT 98
5.11. GENERAL ELECTRIC SYSTEM AND BATTERY RECHARGER CHECK 99
5.12. CHAIN CHECK 101
5.13. SAFETY DEVICES CHECK 104

6. PLATFORM ASSIGMENT AND DEMOLITION 114
6.1. ASSIGMENT 114
6.2. DEMOLITION 114
6.2.1. WASTE MATERIAL DISPOSAL 114
6.2.2. INDICATIONS FOR SPECIAL WASTE 115
6.2.3. DEMOLITION 116
6.3. CONTROL REGISTER 118
6.3.1. Storage instructions 118
6.3.2. Instructions for filling 118

Pag. 1OM1202_US
1. GENERAL CHARACTERISTICS
1.1. INTRODUCTION AND INTENDED USE
This equipment is built for lifting people intended as moving people to a working po-
sition where they have to do the work from the platform itself, with the intention that
people can only get off or on the platform at ground level.
1.2. DESCRIPTION
“Ragno” unit mainly consists of a chassis with 4 articulated stabilizing legs, hydraulically
controlled, a turntable slewing on a ball bearing ring.
Steel made multi-telescopic boom is hinged to the turntable and it supports the aerial cage,
with an hydraulically articulating jib.All movements are actuated by hydraulic cylinders, or
hydraulic motors.
The equipment is supported by rubber tracks or wheels fully integrated into the base chassis
It also has three energy sources: two electric motors and a soundproofed heat engine, alter-
native to each other and both suitable for the movement of the arms and for the independent
travelling of the equipment.
Electro-hydraulic controls in the two position, complementary to each other; the ones on
the cage are used for the work movements of the arms, while on the ground, it is possible to
travel with the tracks, the placement of the stabilizers and, if enabled, the movements of the
arm for the emergency recovery of people.
1.3. DIRECTIVE AND RULES
2006/42/CE Directive indicates the conditions to deliver the machine in EU market.
The machine supplied by Palazzani Industrie is a machine complying one of the ma-
chines category listed in the Directive attachment IV.
To comply with the conformity of the machine to the Directive dispositions, Palazza-
ni fulfils the risks analysis to verify the respect of safety and health essential subjects
indicated in the Directive, further than performing the tests and check required in the
applied rules, before delivering the machine.
The manufacture technical report is issued conforming with attachment VII of Directive
2006/42/CE and it is available for the inspecting institutes under justified request, as
required by the law dispositions in force.

Pag. 2OM1202_US
Palazzani Industrie provides, therefore, to supply the machine to the market, complete
of:• CE Mark
• CE Declaration of conformity
• Instructions and warning manual
1.4. LIFE CYCLES
In applying the UNI EN 280: 2015 standard, for the calculation of the fatigue stress, a
“heavy duty” application was considered, which translates into a life span of 100,000
load cycles (for example a duration of 10 years, considering 50 working weeks per year,
for 40 hours per week and for 5 load cycles per hour).
1.5. SPECIAL USE
In case the machine is needed for special works, or to be used in different conditions in
respect to point 1.1, a written approval as authorization by Palazzani Industrie is requi-
red. If there is a need to alter the effect of the stability, strength and performance of the
platform, written approval by Palazzani Industrie is required.

Pag. 3OM1202_US
1.6. DIMENSIONS AND PERFORMANCES
Machine in transfer position
Min. height 6ft 6in (1990 mm)
Lenght 21ft 10in (6650 mm)
Width (without basket) 3ft 3in/4ft 3in (980/1300 mm)
Total weight 10251 lb (4650 kg)
Max pressure on the ground of tracks 79.49 psf (3.88 kN/m2)
Max. working height 98ft 5in (30 m)
Max. cage floor height 91ft 10in (28 m)
Max. outreach 42ft 8in (13 m)
Max cage working load 510lb (230 kg)
Max. horizontal pull 400 N
Aerial cage dimensions ( A x B ) 5ft 11in x 2ft 4in x 3ft 7in
(1.8 x 0.7 x h 1.1 m)
Min steering radius 14ft 10in (4533 mm)
Max. selfpropelling speed 0.75mi/h (1,2 km/h)
Superable slope with outrigger 44 %
Superable slope with tracks 42 %
Turntable slewing E330° (360° continuous optional)
Cage rotation 90° + 80°
Hydr. system working pressure with diesel engine 2900.75psi (200 bar)
Hydr. system working pressure with el. motor 2538.16psi (175 bar)
Max. admitted wind speed 27.96mi/h (45 km/h)
Max. admitted chassis slope 2°
Technical data - times DIESEL
Stabilizing legs lifting (to floor touch) 25 sec.
Stabilizing legs lowering 30 sec.
Boom lifting (completely retracted) 50 sec.
Boom lowering (completely extended) 50 sec.
Telescopic boom extension 100 sec.
Telescopic boom return 50 sec.
Jib lifting 50 sec.
Jib lowering 55 sec.
Right-left turning (1 turn) 180 sec.
Transfer speed:
32ft 9.7in (10 m) slow 70 sec.
32ft 9.7in (10 m) fast 25 sec.

Pag. 4OM1202_US
Times are considered with empty cage, worm oil and max joystick activation.
A 10% tolerance on this value is acceptable. Times and dimensions are indicative and
Palazzani SpA may change the value for internal causes.
Main mechanic components
Tracks type: MESSERSI’TIPO RTU 22V/L
Brakes: negative and automatic, with hydraulic releasing
Cage leveling reductor: RE242 T2S 31.3 MD20
Turntable rotation motorgearbox: RE211NS7,2 MD40
Main hydraulic components
Diesel engine pump PLP 20.8/20.4 D/FS
El.motor pump PLP 10.2,5 DO
Turntable slewing device HYDR. DRIVE ARM30/168/F
Proportional electrodistributor BOSH REXROTH
Filters INLET WITH FULL CAPACITY
Filtering 25 micron
Oils: hydraulic system BP ENERGOL HLP HM 46
gearbox IP PONTIAX FZG85W/90
diesel engine See manufacturer book
Grase IPAUTO GREASE MP
Hydraulic oil tank 65 liters
!WARNING
For filling-up, it is recommended to use the above specified oil types
exclusively - in case of oils with corresponding characteristics, it is advi-
sable to make a complete change.
Main electric components
Electric motor 1.1 kW - 110V
Generator (optional) 5 kW 120V a.c.
Battery N° 1 70 Ah
Battery charger 12V - 15A - 115/230V
Ground control documents attached
Engine diesel atmospheric
Brand KUBOTA D722-E4B EPA
Fuel diesel
Rpm 3000 rpm.
Fuel tank 35 liters

Pag. 5OM1202_US
Noise lowering solutions original cover made with phonoabsorbing panel
Net power 14 kW a 3000 rpm
Phonometric tests (Directive 2000/14/CE)
Measured sound power level LwA = 95 dB
Guaranteed sound power level LwA = 96 dB
Vibrations
Operator hand/arm < 2,5 m/sec2of A(8)
Operator body < 1,25 m/sec2of A(8)
Gas emissions (exhaust gas)
In compliance with UE regulation 2016/1628 of the European parliament and of the
council.
Acceptance tests
Before shipment, the machine was tested in accordance with the provisions of the cur-
rent EN 280: 2015 standard.

Pag. 6OM1202_US
1.7. DIMENSIONS
g 1.1

Pag. 7OM1202_US
Max loading on a stabiliser 6393lb (KN 29)
g 1.2

Pag. 8OM1202_US
1.8. WORKING AREA
g 1.3

Pag. 9OM1202_US
g 1.3a

Pag. 10OM1202_US
g 1.4

Pag. 11OM1202_US
1.9. MAIN GROUPS OF THE PLATFORM
1) Stabilizers
2) chassis
3) tracks or wheels
4) main electrical box
5) turret
6) telescopic boom extension
7) jib
8) cage
9) cage control panel
Fig. 1.8
1
4
2
79
8
6
5
3
1

Pag. 11OM2016_US
