Panamax M10-HT-PRO User manual

M10-HT-PRO
LOOKING FOR CRYSTAL CLEAR PICTURE AND SOUND?
M10-HT-PRO
www.panamax.com
The M10-HT-PRO’s Power Cleaning and Linear Filtration
eliminates common symptoms of contaminated power (including loss
of detail, pops, hisses, hums and visual artifacts) and allows yourA/V
equipment to perform up to its full capability.
1
2The M10-HT-PRO senses sustained voltages that are high enough
to cause damage to your components, and shuts the power down
before damage can occur.
3The M10-HT-PRO is designed to provide noise isolation between 3
isolated outlet banks so that any noise created by anA/V component
can not contaminate the power going to equipment plugged into
another outlet bank.
Improves Picture and Sound Quality
Monitors Incoming Line Voltage
Reduces Cross-Contamination Between Components
•Telephone Line Protection
Protects equipment from electrical surges that
travel over Telephone lines.
•12 Volt Trigger
Allows source equipment to activate or
deactivate the delayed outlets on the
M10-HT-PRO.
•AVM (Automatic Voltage Monitoring)
Protects against prolonged over voltages by
disconnecting power to equipment.
•10 Outlets
4 digital-ultrasonic noise filtered outlets,
3 Linear Filtration outlets, 3 Linear Filtration
outlets with sequenced activation.
•Coax/Sat Protection
Protects equipment from electrical surges that
travel over Cable, Satellite, andAntenna lines.
•Premium Filtration
Improves Picture and Sound. Provides clean
power by filtering out noise common to
household power.
• 3 Isolated Outlet Banks
Isolating outlet banks from one another
prevents noise contamination between
components.
•Surge Protection
Exclusive Protect or Disconnect™ circuitry.
In the event of a catastophic surge such as
lightning, it completely disconnectsAC power
to connected equipment
•Hi Def Ready
Hi-Def Designed to work with your High
Definition system.
HOME THEATER POWER MANAGEMENT

M10-HT-PRO FEATURES
1. Power Cord
6 foot power cord with
right angle plug.
5. Digital-ultrasonic noise filtered outlets
Four outlets with digital-ultrasonic noise filtration. 6. In/Out Cable Connectors
For cable, satellite, or antenna.
3. Linear Filtration with Delay
Outlets
Three outlets with Linear
Filtration and delayed activation.
2. Trigger Bypass/Input Switch
7. Power Switch 9. Power Status LED 10. Extreme Over voltage
Indicator LED
8. 12V Trigger Input
for Delayed Outlets In/Out Telephone Connectors
M10-HT-PRO SPECIFICATIONS
UPC’S, QUANTITIES, WEIGHTS & MEASUREMENTS FOR ORDERING & SHIPPING
General________________________________________________________________
Dimensions:.........................................................................23.5 in. L x 3.75 in. W x 3.5 in H
Weight:.......................................................................................................................... 5 lbs.
AC Power_______________________________________________________________
Thermal Fusing:...............................................................................................................Yes
Line Voltage:..............................................................................................120VAC, 50/60Hz
Initial Clamping Level:....................................................................... 200V Peak, 141V RMS
Overvoltage shutoff:....................................................................................................... 137V
UL1449 Suppression Rating:......................................................................................... 330V
Protection Modes:............................................................................................................ L-N
Maximum Current Rating:................................................................................................15A
Energy Dissipation:.............................................................................................. 575 Joules
Peak Impulse Current:...................................................................................... 21,000Amps
EMI/RFI Noise Filtration:................................................................. 53 dB (100kHz - 1 MHz)
Response Time:.............................................................................................................. < 1n
DC Trigger Input__________________________________________________________
Jacks............................................................................................... 3.5mm mono mini-plug
Voltage and Polarity........................................................................3 - 24V DC, bidirectional
Current Requirement....................................................................4.6 mA@3V, 58 mA @24V
Telco Protection ________________________________________________________
Clamping Level:............................................................................................................ 600V
Capacitance:....................................................................................................30pf (approx.)
Suppression Modes:................................................................................................. Metallic
Wires Protected:...................................................................................... 2 wire, 1 pair (3,4)
Connectors:................................................................................................................. RJ-11
Universal Coaxial Protection ______________________________________________
HD Ready:....................................................................................................................... Yes
Shielded:...........................................................................................................................Yes
Clamping Level:............................................................................................................... 90V
Frequency Range:...................................................................................... 5MHz - 2200 GHz
Insertion Loss:.............................................................................................................< 0.1 dB
Connections:........................................................................................................... Female “F”
Bi-Directional:.....................................................................................................................Yes
MODEL M10-HT-PRO MASTER CARTON
UNIT CARTON
Dimensions Weight Dimensions Weight UPC Qty Dimensions Weight UPC
23.5” x 3.75” x 3.5” 5 lbs 28.5” x 8.5” x 5” 6 Lbs 0 50616 00828 0 4 31.25” x 10.25” x 16.5” 28 Lbs 5 00 50616 00828 5
1690 Corporate Circle, Petaluma, CA. 94954 800-472-5555 or 707-283-5900 Fax [phone] www.panamax.com
© 2007 Panamax, Inc. Panamax, MAX, and the Panamax logo are registered US trademarks of Panamax
Design and specifications subject to change without notice due to product improvement.
L581 REVA 5/07
4. Linear Filtration Outlets
Three outlets with Linear
Filtration.
