Panasonic CS-XE12PKUA Installation and user guide

Split System Submittal Data
Indoor: CS-XE12PKUA Outdoor: CU-XE12PKUA
Wall Mounted Air Conditioners
Approval:
Date:
Construction:
Unit#:
Drawing#:
Job Name:
Location:
Engineer:
Submitted to:
Submitted by:
Reference:
General Data
Power (V/P/Hz) 230/208/1/60
Circuit Ampacity (A) 15
Fuse Size, Max.(A) 20
Compressor DC Twin Rotary
No. Used 1
Output Power (W) 700
Outdoor Unit
Fan Type Propeller
Motor Type DC Motor ( 8 poles )
Output Power (W) 40
Airflow (CFM) 1555
Coil Type Aluminum (Blue Coated)
Fin Type - Pipe Type Corrugated Fin
Rows - F.P.I. 18
Face Area (sq.ft.) 5.99
Indoor Unit
Fan type Cross Flow
No. Speeds 5
RPM (High) 1350
Motor Output (w) 40
CFM (QLo/Lo/Me/Hi/SHi) 170/240/390/530/550
Indoor Sound Rating (Hi) (dB-A) 44
Coil Type Aluminum Fin & Copper Tube
Fin Type - Pipe Type Slit Plate - Inner Rifled
Rows - F.P.I 21
Face Area (sq.ft) 2.45
Drain Connection Size (in.) 3/4
Refrigerant R410A
Lbs. - R410a (Outdoor Unit) 2.54
Control Electronic Expansion Valve
Connection Flare
Line Length, Max (ft.) 66
Lift Difference, Max (ft.) 49
Line Size (in. O.D. Discharge) 1/4”
Line Size (in. O.D. Suction) 1/2”
Dimensions (HxWxD)
Indoor Unit (Crated) (in.) 11-7/8”x37-13/16”x14-3/8”
Indoor Unit (Uncrated) (in.) 11-5/8”x34-9/32”x10-1/16”
Outdoor Unit (Crated (in.) 29-11/32”x41-5/16”x18-1/8”
Outdoor Unit (Uncrated) (in.) 27-3/8”x34-15/32”x12-5/8”
Weight
Net, Indoor (lbs.) 24
Performance Data @ ARI Standard Conditions (230/208V)
Cooling
Total Capacity (BTU/H) 11,500 (2,800-14,000)
Sensible Capacity (BTU/H) 10,120
Latent Capacity (BTU/H) 1,380
SEER 25.5
Dehumidification (Pints/H) 2.3
Amps (A) 4.2/3.8
Power Inputs (W) 800 (150-1,050)
Outdoor Sound Rating (dB-A) 49
Heating
Total Capacity (BTU/H) 13,800 (3,000-23,000) (Max at 5F
12,500)
HSPF 12.0
Amps (A) 5.8/5.2
Power Inputs (W) 1,150 (150-2,100)
Outdoor Sound Rating (dB-A) 49
Features
Wireless Remote Controller Standard
Wired Remote Controller ( CZ-
RD516C )
Optional
Controls Microprocessor
Remote Control LCD Wireless Type
Temperature Control IC Thermostat
Air Louver, Horizontal Manual
Air Louver, Vertical Automatic
Power Failure Automatic Restart Built-In
Self-Diagnosis Built-In
Air Filter Washable, One-touch
Operating Range Indoor Air Intake Temp Outdoor Air Intake Temp
Cooling (Max) 90F DB/74F WB 115F DB/79F WB
Cooling (Min) 60F DB/52F WB 0F DB/-F WB
Heating (Max) 86F DB/-F WB 75F DB/64F WB
Heating (Min) 60F DB/-F WB 0F DB/-2.2F WB
Shipping, Indoor (lbs.) 26
Net, Outdoor (lbs.) 97
Shipping, Outdoor (lbs.) 108

Panasonic North America
Air Conditioning Division
1690 Roberts Blvd., NW, Suite 110
Kennesaw, GA 30144
http://www.panasonic.com/aircon
13
5. Dimensions
5.1 Indoor Unit
Indoor Dimensions
Outdoor Dimensions
13
5. Dimensions
5.1 Indoor Unit
14
5.2 Outdoor Unit
