Panasonic AVCCAM AG-AC90 User manual

Featuring a Wide-Angle/High-Powered Zoom Lens and
High-Sensitivity BSI Type 3MOS Sensors, This Stylish AVCCAM
Includes the Smooth Operation of Triple Manual Rings.
Panasonic’s new AG-AC90 AVCCAM combines the high image quality, advanced functions and easy
operation that professionals demand in a stylish, easy-to-handle design.
Its zoom lens extends from 29.8 mm (35 mm equivalent) wide angle to 12x optical zoom, with a high
speed, F1.5 brightness. BSI (backside illumination) type 3MOS Image Sensors exhibit high sensitivity,
Full-HD resolution and a high S/N ratio. And the AVCHD recorder section supports both PS mode, for
Full-HD progressive image production, and pro-use PH mode. They give you the field of view, the image
quality, and the file/video formats you need for news gathering and image production. Other professional
operating features include Triple Manual Rings (focus, zoom and iris) that approach the versatility and feel
of the interchangeable lenses, XLR Microphone/Audio Inputs, and remote terminals to provide the system
expandability that professional applications require.
