Panasonic AG-CVF15G User manual

Operating Instructions/Bedienungsanleitung/
Mode d’emploi/Istruzioni per l’uso/
Instrucciones de funcionamiento/
取扱説明書
Electronic HD Color View Finder
Elektronischer HD-Farbe-Sucher
Viseur électronique HD couleur
HD colore mirino elettronico
HD color visor electrónico
HD カラービューファインダー
Model No. AG-CVF15G
Before operating this product, please read the instructions carefully and save this
manual for future use.
Bitte lesen Sie diese Bedienungsanleitung vor der Inbetriebnahme dieses Produkts
aufmerksam durch, und bewahren Sie sie für späteres Nachschlagen auf.
Avant d’utiliser l’appareil, lire attentivement ce mode d’emploi, et le conserver à
des fins de référence ultérieure.
Prima di far funzionare questo prodotto, leggere attentamente le istruzioni e
conservare questo manuale per riferimenti futuri.
Antes de utilizar este producto, lea cuidadosamente las instrucciones y guarde este
manual por si tiene que utilizarlo en el futuro.
このたびは、パナソニック製品をお買い上げいただき、まことにありがとうございます。
■󲁢取扱説明書をよくお読みのうえ、正しく安全にお使いください。
■󲁢ご使用前に「安全上のご注意」（ J-2 ～ J-3 ページ）を必ずお読みください。
■󲁢󲁢保証書は「お買い上げ日・販売店名」などの記入を確かめ、取扱説明書とともに大切に保
管してください。
保証書別添付
製造番号は、品質管理上重要なものです。製品本体と保証書の製造番号をお確かめください。
ENGLISHDEUTSCHFRANÇAISITALIANOESPAÑOL
日本語
SS1112KT1037 -FJ
Printed in Japan VQT4U61-1

E-1
For General
WARNING:
•Toreducetheriskofre,donotexposethisequipmenttorainormoisture.
•Toreducetheriskofre,keepthisequipmentawayfromallliquids.
Useandstoreonlyinlocationswhicharenotexposedtotheriskofdrippingorsplashing
liquids,anddonotplaceanyliquidcontainersontopoftheequipment.
CAUTION:
Donotremovepanelcoversbyunscrewingthem.
Nouserserviceablepartsinside.
Referservicingtoqualiedservicepersonnel.
CAUTION:
•Donotpointtheeyepiecedirectlyatthesun.
indicatessafetyinformation.
AEEE Yönetmeliğine Uygundur.
AEEE Complies with Directive of Turkey.
Theratingplateisontheundersideoftheunit.
Manufactured by: Panasonic Corporation, Osaka, Japan
Importer’s name and address of pursuant to EU rules:
Panasonic Marketing Europe GmbH
Panasonic Testing Centre
Winsbergring 15, 22525 Hamburg, Germany
Read this rst!

E-2
ENGLISH
For USA
Thisdevicecomplieswithpart15oftheFCCRules.Operationissubjecttothefollowingtwo
conditions:
(1)Thisdevicemaynotcauseharmfulinterference,and(2)thisdevicemustacceptany
interferencereceived,includinginterferencethatmaycauseundesiredoperation.
FCC Note:
ThisequipmenthasbeentestedandfoundtocomplywiththelimitsforaclassBdigital
device,pursuanttoPart15oftheFCCRules.Theselimitsaredesignedtoprovidereasonable
protectionagainstharmfulinterferenceinaresidentialinstallation.Thisequipmentgenerates,
uses,andcanradiateradiofrequencyenergyand,ifnotinstalledandusedinaccordance
withtheinstructionmanual,maycauseharmfulinterferencetoradiocommunications.
However,thereisnoguaranteethatinterferencewillnotoccurinaparticularinstallation.If
thisequipmentdoescauseharmfulinterferencetoradioortelevisionreception,whichcanbe
determinedbyturningtheequipmentoffandon,theuserisencouragedtotrytocorrectthe
interferencebyoneormoreofthefollowingmeasures:
•Reorientorrelocatethereceivingantenna.
•Increasetheseparationbetweentheequipmentandreceiver.
•Connecttheequipmentintoanoutletonacircuitdifferentfromthattowhichthereceiveris
connected.
•Consultthedealeroranexperiencedradio/TVtechnicianforhelp.
•Theusermayndthebooklet“SomethingAboutInterference”availablefromFCClocal
regionalofceshelpful.
Warning:
ToassurecontinuedFCCemissionlimitcompliance,theusermustuseonlyshieldedinterface
cableswhenconnectingtoexternalunits.Also,anyunauthorizedchangesormodicationsto
thisequipmentcouldvoidtheuser’sauthoritytooperateit.
For Canada
NOTIFICATION (Canada)
ThisclassBdigitalapparatuscomplieswithCanadianICES-003.
indicatessafetyinformation.
Read this rst!
(continued)

E-3
EMC NOTICE FOR THE PURCHASER/USER OF THE APPARATUS
1. Applicable standards and operating environment
The apparatus is compliant with:
• standardsEN55103-1andEN55103-2,and
• electromagneticenvironmentsE1,E2,E3andE4.
2. Pre-requisite conditions to achieving compliance with the above standards
<1> Peripheral equipment to be connected to the apparatus and special connecting
cables
• Thepurchaser/userisurgedtouseonlyequipmentwhichhasbeenrecommendedbyusas
peripheralequipmenttobeconnectedtotheapparatus.
• Thepurchaser/userisurgedtouseonlytheconnectingcablesdescribedbelow.
<2>
For the connecting cables, use shielded cables which suit the intended purpose
of the apparatus.
• Videosignalconnectingcables
Usedoubleshieldedcoaxialcables,whicharedesignedfor75-ohmtypehigh-frequency
applications,forSDI(SerialDigitalInterface).
Coaxialcables,whicharedesignedfor75-ohmtypehigh-frequencyapplications,are
recommendedforanalogvideosignals.
• Audiosignalconnectingcables
IfyourapparatussupportsAES/EBUserialdigitalaudiosignals,usecablesdesignedfor
AES/EBU.
Useshieldedcables,whichprovidequalityperformanceforhigh-frequencytransmission
applications,foranalogaudiosignals.
• Otherconnectingcables
Usedoubleshieldedcables,whichprovidequalityperformanceforhigh-frequency
applications,asconnectingcablesforIEEE1394orUSB.
• WhenconnectingtotheHDMIsignalterminal,usemultilayershieldedcables,whichprovide
qualityperformanceforhigh-frequencyapplications.
• WhenconnectingtotheDVIsignalterminal,useacablewithaferritecore.
• Ifyourapparatusissuppliedwithferritecore(s),theymustbeattachedoncable(s)following
instructionsinthismanual.
3. Performance level
Theperformanceleveloftheapparatusisequivalenttoorbetterthantheperformancelevelrequired
bythesestandards.
However,theapparatusmaybeadverselyaffectedbyinterferenceifitisbeingusedinanEMC
environment,suchasanareawherestrongelectromagneticeldsaregenerated(bythepresence
ofsignaltransmissiontowers,cellularphones,etc.).Inordertominimizetheadverseeffectsofthe
interferenceontheapparatusincaseslikethis,itisrecommendedthatthefollowingstepsbetaken
withtheapparatusbeingaffectedandwithitsoperatingenvironment:
1.Placetheapparatusatadistancefromthesourceoftheinterference.
2.Changethedirectionoftheapparatus.
3.Changetheconnectionmethodusedfortheapparatus.
4.Connecttheapparatustoanotherpoweroutletwherethepowerisnotsharedbyany
otherappliances.
Read this rst!
(continued)

E-4
ENGLISH
Table of contents
Note concerning illustrations in these instructions
•Theillustrationsshowingtheviewnderitself,camerarecorderandotherproductsmaydifferfromthe
actualproducts.
References
•Referencesareshownas(Page00).
Read this rst! ............................................................................................................................... E-1
Operating precautions .................................................................................................................. E-5
Accessory ...................................................................................................................................... E-5
Features.......................................................................................................................................... E-5
Parts and their functions .............................................................................................................. E-6
Frontpanel................................................................................................................................... E-6
Rearpanel................................................................................................................................... E-8
LCDscreenindicators................................................................................................................. E-9
Attaching and adjusting the viewnder .................................................................................... E-10
Attachingtheviewnder............................................................................................................. E-10
Adjustingtheviewnder’sleft-rightposition............................................................................... E-11
Adjustingtheviewnder’sfront-backposition
(foracamerafeaturingafront-backpositionadjustmentslider)............................................... E-11
Detachingtheviewnder........................................................................................................... E-12
Flippinguptheeyepieceunit..................................................................................................... E-13
Adjustingtheangleoftheviewnder......................................................................................... E-13
Flippinguptheviewnderbarrelunit......................................................................................... E-14
Diopteradjustment..................................................................................................................... E-14
Screenadjustment..................................................................................................................... E-15
Removing the protective lter .................................................................................................... E-16
Maintenance ................................................................................................................................. E-16
Attaching the microphone .......................................................................................................... E-17
Appearance .................................................................................................................................. E-18
Specications .............................................................................................................................. E-19

E-5
Compatible camera recorders
ThisviewndersupportstheAG-HPX600andAJ-HPXseriesofcamerarecorders.
Pleasecontactthedealersforothercompatiblemodels.
Dependingonthemodel,viewnderoutputmaybesettoblackandwhiteimageasaninitialsetting.
Forhowtoswitchtheoutputtoacolorimage,refertotheoperatinginstructionsforeachcamerarecorder.
Concerning a monitor with a liquid crystal display
•WhenthesameimagesorcharactersareleftdisplayedforprolongedperiodsoftimeonanLCDmonitor,
imageburn-inmayoccuronthescreen.However,thescreenwillreverttonormaloncethepowerhas
beenturnedoffandkeptturnedoffforseveralhours.
•TheratioofeffectivepixelsusedfortheLCDmonitoriscontrolledtothehighaccuracyofmorethan
99.99%,whichmeansthatlessthan0.01%ofthepixelsmaybemissingorpermanentlylighted.Thisis
notindicativeofanymalfunctioninganddoesnothaveanyadverseeffectontherecordedimages.
•CondensationmayformontheLCDmonitorinlocationswherethetemperatureuctuatessignicantly.
Ifcondensationdoesform,wipeitoffusingasoftdrycloth.
•Iftheviewnderunithasbecomecold,theimagesdisplayedontheLCDmonitorwillbeslightlydarker
thanusualimmediatelyafterthepoweristurnedon.Thenormalbrightnesswillberestoredoncethe
temperatureinsiderises.
Accessory
Thefollowingaccessoryisattachedtotheviewnder.
•Eyecup
Features
•Focusingisnoweasierthankstotheuseofahigh-denitioncolorLCDmonitor.
•Inadditiontousingtheregulareyepieceforshooting,theeyepieceunitcannowbeippeduptoenable
shootingwhileviewingtheLCDmonitoroverthemirror.
•Theviewnderbarrelunitcanbeippedup,andoperationssuchascheckingouttheplaybackimagescan
beperformedwhiledirectlyviewingtheLCDmonitorwithitslargescreen.
•ThisviewndercanreplaceanexistingHDviewnder.
•TheviewndercanbeusedwiththeAG-HPX600andAJ-HPXseries.
Operating precautions

E-6
ENGLISH
Front panel
B.LIGHT
HIGH
NOR ON OFF
MOMENT
LOW
HIGH
OFF
LOW
ZEBRA
PEAKING CHROMA CONTRAST BRIGHT
TALLY
   
  
 

 





1 PEAKING control
Adjuststheoutlinesoftheimagesintheviewndertomakefocusingeasier.Thesettingofthiscontrol
hasnoeffectontheoutputsignalofthecamera.Theamountoftheadjustmentisincreasedwhenthe
controlisrotatedclockwise.
2 CHROMA control
Adjuststhechromaofthecolorfortheimageintheviewnder.Thesettingofthiscontrolhasnoeffect
ontheoutputsignalofthecamera.Thecolorsbecomedarkerwhenthecontrolisrotatedclockwise.
3 CONTRAST control
Adjuststhecontrastofthescreeninsidetheviewnder.Thesettingofthiscontrolhasnoeffectonthe
outputsignalofthecamera.Thecontrastbecomesstrongerwhenthecontrolisrotatedclockwise.
4 BRIGHT (Brightness) control
Adjuststhebrightnessofthescreeninsidetheviewnder.Thesettingofthiscontrol hasnoeffecton
theoutputsignalofthecamera.Theimagesbecomebrighterwhenthecontrolisrotatedclockwise.
5 B.LIGHT switch
AdjuststhebrightnessoftheLCDmonitorbacklight.
HIGH : Thebacklightismadebrighterthannormal.
NOR : Thebacklightissettothenormalbrightness.
LOW : Thebacklightismadedarkerthannormal.
6 ZEBRA switch
Displaysazebrapatterninsidetheviewnder.
ON : Displaysazebrapattern.
OFF : Nozebrapatternisdisplayed.
MOMENT : WhentheswitchissettoMOMENT,thezebrapatternisdisplayedforabout5seconds,
andthenitiscleared.
TheswitchdoesnotstayattheMOMENTpositionbutreturnsinsteadtotheOFFposition
(becauseitisaspring-backswitch.)
Thedetailsofthedisplay,suchasthetypeofzebrapattern,willdifferdependingonthecameraused
withtheviewnder.
Refertotheinstructionmanualofthecamerafordetails.
Parts and their functions

E-7
7 TALLY switch
Adjuststhebrightnessofthefronttallylamp.
HIGH : Makesthefronttallylampbrighter.
OFF : Turnsthetallylampoff.
LOW : Makesthefronttallylampdimmer.
8 Microphone holder
Enablesanoptionalmicrophonetobeattached.(PageE-17)
9 Front tally lamp
LightswhenthecameraisshootingandtheTALLYswitchissettoHIGHorLOW.
Also,blinkswhileawarningisgiven.
ThebrightnessofthefronttallylampiscontrolledbythesettingoftheTALLYswitch(HIGHorLOW).
 Connecting cable
ConnectedtotheVFconnectoronthecamera.
 Slide stopper
Preventstheviewnderfrombecomingdetachedfromthecamerawhenitisattachedandslidtothe
leftorright.
 Slide rail
Sliderailforinstallingtothecameraunit.
 Eye cup
(Accessory)Installedontheviewnderitself.
 Diopter adjuster ring
Adjuststhediopterwhenthisringisrotatedsothattheimageisseenatitsclearest.
 Eyepiece unit
 Viewnder barrel unit
Canbeippeduporrotateddependingonhowthecameraistobeused.
 Viewnder barrel unit release lever
Releasesthelock,causingtheviewnderbarrelunittoipup.
 Mirror
 LCD monitor
Parts and their functions
(continued)

E-8
ENGLISH
Parts and their functions
(continued)
Rear panel
PIC.SIZE
AUTO
FULL

ON
OFF



PIC.SIZE (PICTURE SIZE) switch
SetsthesizeoftheimagetobedisplayedontheLCDmonitor.
AUTO : Whenviewingthescreenthroughtheeyepieceunitorippinguptheeyepieceunitand
viewingthescreenoverthemirror,theimagesaredisplayedinaslightlysmallersize(approx.
83%ofthefull-screensize).Atallothertimes,theyareimagesatthefull-screensize.
Whenimagesarebeingdisplayedinthesmallersize,the[Greentally],[TALLY/REC],[!]and
[BATT]indicatorsaredisplayedatthetopandbottomofthescreen.
FULL : Imagesarealwaysshownasfull-screendisplays.
Whenimagesareshownasfull-screendisplays,the[Greentally],[TALLY/REC],[!]and[BATT]
indicatorsarenotdisplayed.
Note
WhendirectlyviewingtheLCDmonitorwiththeviewnderbarrelunitippeduporwhen
rotatingtheeyepieceunittothesubjectsidetoviewtheimages,imagesaredisplayedatthe
full-screensizeregardlessofthePIC.SIZEswitchsetting.
Protective lter
Thisiswheretheprotectivelter(43mm[1-11/16inches]diameter)isinstalled.(PageE-16)
Eyepiece unit release lever
Releasesthelock,causingtheeyepieceunittoipup.
Back tally lamp
Lightsduringshooting,andblinksduringwarnings.
ThebacktallylampishiddenwhentheleverissettoOFF.

E-9
Parts and their functions
(continued)
LCD screen indicators
ThescreenshownbelowappearswhenthePIC.SIZEswitchissettoAUTO.
TheindicatorsarenotdisplayedwhentheswitchissettoFULL.
Theerrordisplay5isdisplayedwhenanerroroccursintheviewnder,regardlessofthePIC.SIZEswitch
setting.
Note
Whatisdisplayedbytheindicatorsonthescreendependsonthecamerausedincombination
withtheviewnder.Fordetails,refertotheoperatinginstructionsofthecamera.
TALLY/REC
HEATER ERROR
BATT

 
 
1 Green tally indicator
Lightsupgreenwhenthegreentallysignalisreceived.
Theconditionsunderwhichthisindicatorlightswilldifferdependingonthecamerasettings.
2 TALLY/REC indicator
Lightsupredwhilerecordingisunderwayorwhentheredtallysignalisreceived.
Itblinksredwhentroublehasoccurred.
Theconditionsunderwhichthisindicatorlightsandblinkswilldifferdependingonthecamerasettings.
3 ! indicator
Theconditionsunderwhichthe!indicatorlightscanbesetusingthe!LEDitemofthemenuofthe
cameraunit.
Usethisindicatortoavoidmakingoperatingerrorsduringvariousoperations,forinstance.
•ThisindicatorisnotsupportedbytheAG-HPX600.
4 BATT indicator
Indicatesthestatusofthebatteryinthecamera.Theconditionsunderwhichthisindicatorlightsand
blinkswilldifferdependingonthecamerasettings.
5 Error display
Displayedwhenanerroroccursintheviewnder.Iftheproblemisnotresolvedbyturningoffpowerto
thecamera,stopusingtheviewnderandconsultyourdealer.
HEATER ERROR : Displayedwhenanerroroccursintheoperationoftheheaterinsidethe
viewnder.
SENSOR ERROR : Displayedwhenanerroroccursintheoperationofthetemperaturesensorinthe
viewnder.

E-10
ENGLISH
Attaching the viewnder
1ConrmthatthePOWERswitchofthecamerais“OFF”.
2ConnecttheplugoftheconnectingcabletotheVFconnectoronthecamera.
Note
WhenconnectingtheplugoftheconnectingcabletotheVFconnectoronthecamera,push
itrmlyinalltheway.
Viewnder left-right
position anchoring ring
Loosen the ring.
3Loosentheviewnderleft-rightpositionanchoringringofthecamera.
4Whilepullinguptheslidestopper,slidetheviewnderinthedirectionofthearrow,
andattachit.
Afterattachingtheviewnder,checkthatthestopperisinplace.
Slide stopper Tighten the ring.
5Tightentheviewnderleft-rightpositionanchoringringofthecamera.
Attaching and adjusting the viewnder

E-11
Adjusting the viewnder’s left-right position
1Loosentheviewnderleft-rightpositionanchoringring.
2Slidetheviewndertotheleftorright,andadjustittoapositionthatallowseasy
viewing.
Viewnder left-right
position anchoring ring Tighten the ring.
3Tightentheviewnderleft-rightpositionanchoringring.
Adjusting the viewnder’s front-back position
(for a camera featuring a front-back position adjustment slider)
1Loosentheviewnderfront-backpositionanchoringlever.
2Slidetheviewndertothefrontorback,andadjustittoapositionthatallowseasy
viewing.
Viewnder front-back
position anchoring lever
Loosen the viewnder front-back
position anchoring lever.
Loosen the viewnder front-back
position anchoring lever.
Front-back position
adjustment slider
3Tightentheviewnderfront-backpositionanchoringlever.
Attaching and adjusting the viewnder
(continued)

E-12
ENGLISH
Detaching the viewnder
1ConrmthatthePOWERswitchofthecamerais“OFF”.
2Loosentheviewnderleft-rightpositionanchoringringofthecamera.
3Whilepullinguptheslidestopper,slidetheviewnderinthedirectionofthearrow,
andremoveit.
Slide stopper Loosen the ring.
4Releasetheviewndercableandmiccablefromthecableclamps,anddisconnect
thecables.
Attaching and adjusting the viewnder
(continued)

E-13
Attaching and adjusting the viewnder
(continued)
Flipping up the eyepiece unit
Whenshootingwithyoureyesawayfromtheeyepiece,itiseasiertoseetheentirescreeniftheeyepiece
isippedup.
Pushtheeyepieceunitreleaselevertoreleasethelock,andipuptheeyepieceunit.
Eyepiece unit release lever
Adjusting the angle of the viewnder
Theangleoftheviewnderbarrelunitcanbeadjustedinarangefrom0degreetoabout300degreesas
showninthegurebelow.Adjustittotheanglethatmakesviewingtheeasiest.
Rotated about
300 degrees
•Toviewtheimagesfromthesubjectside,rotatetheviewnderbarrelunittothesubjectside,andipup
theeyepieceunit.Theimagesareautomaticallyippedverticallyorhorizontallysothattheywillappear
rightsideup.

E-14
ENGLISH
Flipping up the viewnder barrel unit
Slidetheviewnderbarrelunitreleaseleverinthedirectionofthearrowtoreleasethelock,andipupthe
viewnderbarrelunittoperformoperationswhiledirectlyviewingtheLCDmonitor.
Viewnder barrel unit release lever
•Byippinguptheviewnderbarrelunit,imageswillbeautomaticallyippedhorizontallysothatthe
imagesaredisplayedwiththecorrecthorizontalorientation.Atsuchtimes,imagesaredisplayedatthe
full-screensizeregardlessofthePIC.SIZEswitchsetting.
The[Greentally],[TALLY/REC],[!]and[BATT]indicatorsarenotdisplayed.
Note
Ifthereisanydirtonthemirror,removeitreferringto“Maintenance”.(PageE-16)
Diopter adjustment
1SetthePOWERswitchofthecamerato“ON”.Apicturewillappearintheviewnder.
2Turnthediopteradjusterringtoadjustthedioptersothattheviewnderpicturecan
beclearlyseen.
Diopter adjuster ring
• Diopteradjustmentrange:–3.7Dto+1.1D
Attaching and adjusting the viewnder
(continued)

E-15
Screen adjustment
Adjusttheconditionoftheviewnderscreen.(PageE-6)
Contour : AdjustthePEAKINGcontrol.
Chroma : AdjusttheCHROMAcontrol.
Contrast : AdjusttheCONTRASTcontrol.
Brightness : AdjusttheBRIGHTcontrol.
B.LIGHT
HIGH
NOR ON OFF
MOMENT
LOW
HIGH
OFF
LOW
ZEBRA
PEAKING CHROMA CONTRAST BRIGHT
TALLY
PEAKING control
CHROMA control
CONTRAST control
BRIGHT control
1SetthePOWERswitchofthecamerato“ON”.
2SettheOUTPUTswitchofthecamerato“BARS”.
3AdjustthebrightnessandcontrastoftheimagebyturningtheBRIGHTand
CONTRASTcontrolsontheviewnder,andthechromaoftheimagebythe
CHROMAcontrol.
TurningthePEAKINGcontrolmakesthepictureappearsharper,anditalso
facilitatesfocusing.
Attaching and adjusting the viewnder
(continued)

E-16
ENGLISH
Theprotectivelter(43mm[1-11/16inches]diameter)overtheeyepieceunitcanberemoved.
1Removetheeyecup.
Eye cup
Protective lter
1
2
2Rotatetheprotectivelter
counterclockwise,andremoveit.
Remounting the eyepiece
1Rotatetheprotectivelterclockwise,andremountit.
2Attachtheeyecup.
Note
Donotleavetheeyepieceoutdoorspointingatthesun.Heatfromthesunlightmaydamagethe
partsinside.
Maintenance
WhenthereisdustordirtontheLCDmonitorormirror,ipuptheviewnderbarrelunit,andblowthedust
ordirtawaywithablower,etc.
Ifanydirtisstillleft,wipeitawayusingasoftcloth.
Removing the protective lter

E-17
TheAG-MC200GXLRmicrophone(optionalaccessory)canbeattached.
1Openthemicrophoneholder.
Viewnder
Microphone holder
2Attachthemicrophone.
3PlugthemicrophoneconnectorcableintotheMICINjack.
•Whenguidingthemicrophoneconnectorcable,usethecableclamponthecameraunittoxthe
cable.
MIC IN jack
Cable clamp
Attaching the microphone

E-18
ENGLISH
Unit:mm(inch)
249 (9-13/16)
78 (3-1/16) 227 (8-15/16)
128 (5-1/32)
Appearance

E-19
Power supply:
Power consumption:
DC ( ) 12 V (supplied by camera)
5.7 W
indicates safety information.
Display panel:
87.63 mm (3.45-inch) wide LCD color monitor (approx. 920,000 dots)
Image system:
1080/50i, 1080/59.94i (switched automatically)
External adjustment controls:
Controls
  PEAKING
CHROMA
CONTRAST
BRIGHT
Switches
B.LIGHT (HIGH, NOR, LOW)
ZEBRA (ON, OFF, MOMENT)
TALLY (HIGH, OFF, LOW)
PIC.SIZE (AUTO, FULL)
Display lamps:
Front tally lamp, back tally lamp (set to ON or OFF using a lever)
LCD indicators:
Green tally, TALLY/REC, !, BATT
Ambient operating temperature:
0 °C to 40 °C (32 °F to 104 °F)
Ambient operating humidity:
10% to 85% (no condensation)
Storage temperature:
–20 °C to 60 °C (–4 °F to 140 °F)
External dimensions (W  H  D):
249 mm  78 mm  227 mm
(9-13/16 inches  3-1/16 inches  8-15/16 inches)
Weight: Approx. 650 g (1.43 lb)
Specications
