Panasonic ET-D3QW300 User manual

Thank you for purchasing this Panasonic product.
■To ensure correct use of this lens, please read the operating instructions supplied
with the lens and the projector carefully.
■Before using this product, be sure to read “Read this rst!” (Page 3).
■Please save this manual for future use.
Commercial Use
Model No. ET-D3QW300
ET-D3QS400
ET-D3QT500
ET-D3QT600
ET-D3QT700
ET-D3QT800
DPQX1392ZA/X1
Zoom lens
Operating Instructions
ENGLISH
FRANÇAIS
日本語
ET-D3QW300 ET-D3QS400
ET-D3QT500
ET-D3QT700 ET-D3QT800
ET-D3QT600

2-ENGLISH
Read this rst! ......................................................................................3
Before Use.............................................................................................4
Preparation............................................................................................4
Before replacing the projection lens........................................................4
Attaching and Detaching the Lens ..........................................................4
Peripheral focus adjustment function ......................................................5
Lens calibration .......................................................................................6
Projection relationships.......................................................................7
Lens shift ranges..................................................................................8
Specications .......................................................................................9
Dimensions .........................................................................................10
Projected image size and Projection distance.......Appendix / Annexe / 付録 1
The "Appendix" can be found after the Japanese language section ( 日本語 ).
█ Contents

ENGLISH-3
Read this rst! Always follow these precautions
WARNING:
Do not look at or place your skin into the light emitted from the lens while the
projector is being used.
Doing so can cause burns or loss of sight.
zStrong light is emitted from the projector’s lens. Do not look at or place your hands
directly into this light.
zTurn off the power when moving away from the projection lens or projector.
Do not project an image with the lens cover attached.
zDoing so can cause re.
CAUTION:
Before replacing the projection lens, be sure to turn off the power and
disconnect the power plug from the wall outlet.
zUnexpected projection of light may cause injury to eyes.
zReplacing the projection lens without removing the power plug may result in electric
shock.
Do not stand in front of the lens while the projector is being used.
Doing so can cause damage and burns to clothing.
zStrong light is emitted from the projector’s lens.
Do not place objects in front of the lens while the projector is being used.
Doing so can cause re, damage to the object, or malfunction of the lens and
projector.
zStrong light is emitted from the projector’s lens.
Do not open the desiccant bag. Do not eat the contents.
Inadvertently ingesting desiccant could be harmful.
zIf the desiccant gets into your eyes or mouth, immediately rinse with plenty of water
and seek medical attention.
zKeep desiccant out of the reach of children.

4-ENGLISH
This zoom lens is a projection lens equipped with an EEPROM*1 and stepping motor.
*1 EEPROM: Electrically erasable programmable read-only memory
■Supported projectors
PT-RQ50K
Note
zSome of the alphabet letters at the end of projector model numbers may be omitted in this
manual.
zModels other than the above may also be supported. Refer to the operating instructions for
your projector or the Panasonic website (https://panasonic.net/cns/projector/).
■Supplied Accessories
Make sure that the following has been provided.
Part name Appearance
Lens cover
1 each for front and rear
zThe product is delivered
with lens covers attached.
zThe shape and size of the
lens covers are different for
each product.
Before Use
Preparation
Before replacing the projection lens
Return the projection lens to the home position before replacing or removing it.
For details on how to return the lens to the home position, refer to the operating
instructions of the projector.
Attention
zMake sure that the projector power supply is switched off before attaching or detaching the
projection lens.
zAfter removing the projection lens, store it safely away from vibration or impacts.
z Do not touch the electrical contacts of the projection lens with your ngers. Dust and dirt on
the contacts may cause contact malfunctions, while static electricity may damage the unit.
zDo not touch the surface of the lens with bare hands. Finger prints and dirt on the surface
of the lens will be magnied by the lens and lower the quality of the projected image. Place
the supplied lens cover on the zoom lens when the projector is not in use.
zThe lens is made of glass. The lens could be damaged if brought into contact with or
rubbed against hard objects. Handle the lens carefully.
zUse a clean, soft and dry cloth to wipe away dust and dirt from the projection lens.
Do not use uffy cloths containing oil, water or dust for cleaning. The lens is easily
damaged, so do not apply excessive pressure when wiping it.
Attaching and Detaching the Lens
For details on attaching and detaching the projection lens, refer to the operating
instructions of the projector.

ENGLISH-5
Preparation (continued)
Peripheral focus adjustment function
When you change the size of the projected image, the focal balance between the center
and peripheral areas of the screen may shift. This shift in balance tends to increase
proportionally with smaller throw ratios.
The ET-D3QW300 / ET-D3QS400 / ET-D3QT500 is equipped with a peripheral focus
adjustment function to correct the shift in focal balance between the center and
peripheral areas of the screen.
1) Loosen the lock screw by
turning it counterclockwise.
2) Turn the lens barrel tip or
peripheral focus adjustment
ring in the direction of the
arrow to match the projection
distance displayed on the lens
to the actual distance from the
lens to the screen.
3) Tighten the lock screw by
turning it clockwise.
4) Operate the projector to align
the focus of the center of the
projected image.
Note
zThe projection distances displayed on the lens are approximate guides.
The illustrations in this procedure depict
attachment of the ET-D3QW300 onto the
PT-RQ50K.
zThe structure of the peripheral focus
adjustment part differs depending on the
projection lens type.
Peripheral focus adjustment ring
Lock screw
■Adjusting the focus

6-ENGLISH
Lens calibration
Perform lens calibration after attaching the lens.
The illustrations in this procedure depict
use of the ET-D3QW300 as an example.
1) Press the <MENU> button.
2) Use the ▲ and ▼ buttons to
select [PROJECTOR SETUP],
and press the <ENTER>
button.
zThe [PROJECTOR SETUP] screen
appears.
3) Use the ▲ and ▼ buttons to
select [LENS], and press the
<ENTER> button.
zThe [LENS] screen appears.
4) Use the ▲ and ▼ buttons to
select [LENS CALIBRATION],
and press the <ENTER>
button.
zThe [LENS CALIBRATION] screen
appears.
5) Use the ▲ and ▼ buttons to
select [SHIFT/FOCUS/ZOOM],
and press the <ENTER>
button.
zThe conrmation screen appears.
6) Use the and buttons to
select [OK], and press the
<ENTER> button.
zLens calibration starts.
zThe projection lens moves to the
home position after adjustment range
calibration is complete.
1/2
PROJECTOR SETUP
PROJECTOR ID ALL
PROJECTION METHOD
LENS
OPERATION SETTING NORMAL
LIGHT OUTPUT 100.0%
BRIGHTNESS CONTROL AUTO
NO SIGNAL SETTING
LAST MEMORY
LAST USED
INITIAL STARTUP
STARTUP INPUT SELECT
OFF
DATE AND TIME
SCHEDULE
MULTI PROJECTOR SYNC
MENU SELECT
ENTER
SUB MENU
SUB MENU
MENU SELECT
ENTER
LENS
LENS INFORMATION SETTING
LENS MEMORY
LENS HOME POSITION
ACTIVE FOCUS OPTIMIZER
LENS CALIBRATION
EXECUTE
MENU SELECT
ENTER
LENS CALIBRATION : ET-D3QW300
SHIFT/FOCUS/ZOOM
SHIFT/FOCUS
ZOOM
LENS CALIBRATION : ET-D3QW300
OK
Proceed LENS CALIBRATION,
and return to HOME POSITION.
EXECUTE
CHANGE
ENTER
CANCEL
Note
zIf lens calibration is not performed, the available zoom range will be narrowed.
Preparation (continued)

ENGLISH-7
Projection relationships
The dimensional relationship between the screen and the projector is shown below.
■Dimensional relationship diagram
Note
zThis diagram assumes that the size and position of the projected image will be adjusted so
that the image lls the entire screen.
zThis illustration is not drawn to scale.
L Projection distance
LW Minimum distance
LT Maximum distance
L1 Lens protrusion dimension
SH Projected image height
SW Projected image width
SD Projected image size
zDimension for L1 (approximate values) (Unit: m)
ET-D3QW300 ET-D3QS400 ET-D3QT500 ET-D3QT600 ET-D3QT700 ET-D3QT800
0.246 0.232 0.208 0.149 0.221 0.267
Note
zThe illustrations of projectors in this manual are for informational purposes only and do not
represent a specic projector model. Congurations may vary with the model.
Attention
zTo prevent obstruction of the intake and exhaust vents, install the projector with a
clearance at least 500 mm (1 ft. 7 in.) from walls and objects.
If you are installing the projector in a sealed space, be sure to provide additional air
conditioning equipment and ventilation equipment. Insufcient ventilation will result in an
accumulation of heat and may activate the projector's protection circuit.
zAvoid setting up in places which are subject to sudden temperature changes, such as near
an air conditioner or lighting equipment (studio lamps, etc.).
■Dimensional relationship
For details on the projection distance (L), refer to “Projected image size and Projection
distance” and “Projection distance formulas” in the Appendix.
SD
L (LW/LT)
L1
L1
L (LW/LT)
SW SH
SH
SW
投写画面
スクリーン
スクリーン
Projected image
Screen
Screen

8-ENGLISH
After moving the lens to the home position according to “Lens calibration” on page 6,
you can use the lens shift adjustment function on the projector to adjust the position of
the projected image within the respective lens shift ranges based on the optical screen
center position (standard projection position). The optical screen center position is the
screen position using the optical center of the projector as the base.
Perform lens shift adjustment within the ranges shown in the following illustrations.
Moving the lens outside of the adjustment ranges may alter the focus. This occurs due
to limitations in lens movement that are intended to protect the optical components.
The following illustrations depict lens shift ranges for oor installations of the projector.
ET-D3QW300
0.4V
0.14H0.14H
0.4V
Standard
projection position
Projected image
width H
Projected
height V
Optical center
ET-D3QS400 / ET-D3QT500
0.45V
0.16H0.16H
0.45V
Projected
height V
Projected image
width H
Standard
projection position
Optical center
ET-D3QT600
0.08H0.08H
0.25V 0.25V
Projected image
width H
Projected
height V
Standard
projection position
Optical center
Lens shift ranges

ENGLISH-9
Lens shift ranges (continued)
ET-D3QT700 / ET-D3QT800
0.1H0.1H
0.3V 0.3V
Projected image
width H
Projected
height V
Standard
projection position
Optical center
Note
zThe home position of the projector a point of origin position for the lens shift (i.e., vertical and
horizontal positions of the lens) based on the results of lens calibration. It is not the optical
center position of the screen.
Specications
Check the specications of each projection lens, and use the appropriate lens for your
intended use.
Model No. ET-D3QW300 ET-D3QS400 ET-D3QT500
F value 2.5 2.5 2.5
Focal Length (f) 35.2 mm (1-3/8") -
53.7 mm (2-1/8")
45.3 mm (1-25/32") -
65.6 mm (2-19/32")
61.4 mm (2-13/32") -
105.2 mm (4-5/32")
Dimensions
Width 187 mm (7-3/8") 187 mm (7-3/8") 198 mm (7-25/32")
Height 192 mm (7-9/16") 192 mm (7-9/16") 203 mm (8")
Depth 466 mm (18-11/32") 450 mm (17-23/32") 420 mm (16-17/32")
Net Weight 9.3 kg (20.50 lb) 8.5 kg (18.74 lb) 9.6 kg (21.16 lb)
Model No. ET-D3QT600 ET-D3QT700 ET-D3QT800
F value 2.5 2.5 2.5
Focal Length (f) 85.0 mm (3-11/32") -
121.6 mm (4-25/32")
122.8 mm (4-27/32") -
172.3 mm (6-25/32")
156.5 mm (6-5/32") -
243.1 mm (9-9/16")
Dimensions
Width 187 mm (7-3/8") 187 mm (7-3/8") 187 mm (7-3/8")
Height 192 mm (7-9/16") 192 mm (7-9/16") 192 mm (7-9/16")
Depth 370 mm (14-9/16") 442 mm (17-13/32") 486 mm (19-1/8")
Net Weight 6.4 kg (14.11 lb) 7.3 kg (16.09 lb) 8.0 kg (17.64 lb)

10-ENGLISH
Dimensions
■ET-D3QW300
(Unit: mm)
Ø155 (6-3/32")
466 (18-11/32")
187 (7-3/8")
192 (7-9/16")
Ø155 (6-3/32")
■ET-D3QS400
(Unit: mm)
450 (17-23/32")
192 (7-9/16")
Ø139 (5-15/32")
187 (7-3/8")
Ø155 (6-3/32")
■ET-D3QT500
(Unit: mm)
Ø155 (6-3/32")
420 (16-17/32")
Ø178 (7")
203 (8")
198 (7-25/32")

ENGLISH-11
Dimensions (continued)
■ET-D3QT600
(Unit: mm)
Ø155 (6-3/32")
Ø139 (5-15/32")
370 (14-9/16")
192 (7-9/16")
187 (7-3/8")
■ET-D3QT700
(Unit: mm)
Ø139 (5-15/32")
192 (7-9/16")
187 (7-3/8")
Ø155 (6-3/32")
442 (17-13/32")
■ET-D3QT800
(Unit: mm)
Ø144 (5-21/32")
Ø155 (6-3/32")
486 (19-1/8")
187 (7-3/8")
192 (7-9/16")

Disposal of Old Equipment
Only for European Union and countries with recycling systems
This symbol on the products, packaging, and/or accompanying documents means that
used electrical and electronic products must not be mixed with general household waste.
For proper treatment, recovery and recycling of old products, please take them to
applicable collection points in accordance with your national legislation.
By disposing of them correctly, you will help to save valuable resources and prevent any
potential negative effects on human health and the environment.
For more information about collection and recycling, please contact your local municipality.
Penalties may be applicable for incorrect disposal of this waste, in accordance with national legislation.
Information on Disposal in other Countries outside the European Union
This symbol is only valid in the European Union.
If you wish to discard this product, please contact your local authorities or dealer and ask for the correct
method of disposal.
Information for users in the European Union
Importer’s name and address within the European Union
Panasonic Marketing Europe GmbH
Panasonic Testing Centre
Winsbergring 15, 22525 Hamburg, Germany
Product Information (for Turkey only)
AEEE Yönetmeliğine Uygundur.
Eski Ekipman ve Bataryaların İşlenmesi.
Sadece geri dönüşüm sistemleri olan Avrupa Birliği ve ülkeleri için geçerlidir.
Ürünler, ambalaj ve/veya ekli belgeler üzerindeki bu semboller kullanılmış elektrik ve
elektronik ürünlerin genel ev atığı ile karıştırılmaması gerektiğini ifade eder.
Eski ürünlerin toplanması ve geri kazanılması için bu atıklar lütfen yasayla belirlenmiş olan
uygun toplama merkezlerine teslim ediniz.
Bu atıkların doğru işlenmesiyle, değerli kaynakların korunmasına ve insan sağlığı ve
çevreye olası negatif etkilerinin engellenmesine yardımcı olabilirsiniz.
Atıkların toplanması ve geri dönüşümü için detaylı bilgi için lütfen bağlı olduğunuz yerel
yönetimlerle iletişime geçiniz.
Atıkların atılmasıyla ilgili yanlış uygulamalar yasayla belirlenmiş olan cezalara sebebiyet verebilir.
Environment care information for users in China
This symbol is only valid in China.
Panasonic System Solutions Company of North America
Two Riverfront Plaza, Newark, NJ 07102
TEL: (877) 803 - 8492
Panasonic Canada Inc.
5770 Ambler Drive, Mississauga, Ontario L4W 2T3
TEL: (905) 624 - 5010
Panasonic Corporation
Web Site : https://panasonic.net/cns/projector/
© Panasonic Corporation 2019
HS1119AM0 -PS
Printed in Japan

1
Appendix / Annexe / 付録
Appendix / Annexe / 付録
■Projected image size and Projection distance
■Taille de l'image projetée et istance de projection
■投写画面サイズと投写距離
zWhen the screen aspect ratio is 17:9
zLorsque le rapport d’ aspect de l'écran est 17:9
zアスペクト比 17:9
（Unit / Unités / 単位 : m）
Lens model / Modèle d’objectif
/ 投写レンズ品番 ET-D3QW300 ET-D3QS400 ET-D3QT500
Throw ratio / Rapport de projection
/ スローレシオ 1.11 - 1.70:1 1.43 - 2.09:1 2.00 - 3.41:1
SD SH SW LW LT LW LT LW LT
2.54 (100") 1.188 2.245 2.42 3.77 3.13 4.64 4.64 7.80
3.05 (120") 1.426 2.694 2.93 4.55 3.79 5.59 5.51 9.31
3.81 (150") 1.783 3.367 3.69 5.71 4.77 7.02 6.81 11.57
5.08 (200") 2.377 4.490 4.95 7.65 6.40 9.40 8.97 15.33
6.35 (250") 2.971 5.612 6.22 9.60 8.03 11.78 11.14 19.09
7.62 (300") 3.565 6.734 7.49 11.54 9.66 14.17 13.31 22.85
8.89 (350") 4.160 7.857 8.76 13.48 11.29 16.55 15.47 26.62
10.16 (400") 4.754 8.979 10.03 15.42 12.92 18.93 17.64 30.38
12.70 (500") 5.942 11.224 12.56 19.31 16.18 23.69 21.97 37.90
15.24 (600") 7.131 13.469 15.10 23.19 19.44 28.45 26.31 45.43
17.78 (700") 8.319 15.714 17.63 27.07 22.70 33.21 30.64 52.95
20.32 (800") 9.507 17.959 20.17 30.96 25.97 37.98 34.97 60.48
22.86 (900") 10.696 20.203 22.70 34.84 29.23 42.74 39.31 68.00
25.40 (1000") 11.884 22.448 25.24 38.73 32.49 47.50 43.64 75.53
27.94 (1100") 13.073 24.693 27.77 42.61 35.75 52.26 47.97 83.05
30.48 (1200") 14.261 26.938 30.31 46.49 39.01 57.02 52.31 90.58
33.02 (1300") 15.450 29.183 32.84 50.38 42.27 61.79 56.64 98.10
35.56 (1400") 16.638 31.427 35.38 54.26 45.53 66.55 60.97 105.63
38.10 (1500") 17.827 33.672 37.91 58.15 48.80 71.31 65.31 113.16
Lens model / Modèle d’objectif
/ 投写レンズ品番 ET-D3QT600 ET-D3QT700 ET-D3QT800
Throw ratio / Rapport de projection
/ スローレシオ 2.69 - 3.88:1 3.89 - 5.47:1 4.97 - 7.76:1
SD SH SW LW LT LW LT LW LT
2.54 (100") 1.188 2.245 5.92 8.57 8.57 12.09 10.97 17.22
3.05 (120") 1.426 2.694 7.15 10.34 10.34 14.59 13.23 20.75
3.81 (150") 1.783 3.367 8.99 12.99 12.99 18.33 16.62 26.05
5.08 (200") 2.377 4.490 12.06 17.42 17.42 24.57 22.27 34.88
6.35 (250") 2.971 5.612 15.14 21.85 21.85 30.81 27.92 43.71
7.62 (300") 3.565 6.734 18.21 26.28 26.28 37.04 33.57 52.54
8.89 (350") 4.160 7.857 21.28 30.71 30.71 43.28 39.23 61.37
10.16 (400") 4.754 8.979 24.35 35.14 35.14 49.52 44.88 70.20
12.70 (500") 5.942 11.224 30.49 44.00 43.99 62.00 56.18 87.85
15.24 (600") 7.131 13.469 36.64 52.85 52.85 74.47 67.48 105.51
17.78 (700") 8.319 15.714 42.78 61.71 61.71 86.95 78.78 123.17
20.32 (800") 9.507 17.959 48.92 70.57 70.57 99.43 90.09 140.83
22.86 (900") 10.696 20.203 55.07 79.42 79.42 111.90 101.39 158.49
25.40 (1000") 11.884 22.448 61.21 88.28 88.28 124.38 112.69 176.15
27.94 (1100") 13.073 24.693 67.36 97.14 97.14 136.86 123.99 193.81
30.48 (1200") 14.261 26.938 73.50 106.00 106.00 149.33 135.30 211.47
33.02 (1300") 15.450 29.183 79.64 114.85 114.85 161.81 146.60 229.13
35.56 (1400") 16.638 31.427 85.79 123.71 123.71 174.29 157.90 246.79
38.10 (1500") 17.827 33.672 91.93 132.57 132.57 186.76 169.20 264.44

2Appendix / Annexe / 付録
Appendix / Annexe / 付録（continued / suite / つづき）
zWhen the screen aspect ratio is 16:10
zLorsque le rapport d’ aspect de l'écran est 16:10
zアスペクト比 16:10
（Unit / Unités / 単位 : m）
Lens model / Modèle d’objectif
/ 投写レンズ品番 ET-D3QW300 ET-D3QS400 ET-D3QT500
Throw ratio / Rapport de projection
/ スローレシオ 1.32 - 2.02:1 1.70 - 2.48:1 2.36 - 4.03:1
SD SH SW LW LT LW LT LW LT
2.54 (100") 1.346 2.154 2.76 4.30 3.58 5.29 5.23 8.83
3.05 (120") 1.615 2.585 3.34 5.18 4.32 6.37 6.22 10.54
3.81 (150") 2.019 3.231 4.21 6.51 5.43 8.00 7.69 13.10
5.08 (200") 2.692 4.308 5.65 8.71 7.28 10.70 10.15 17.38
6.35 (250") 3.365 5.385 7.09 10.92 9.14 13.41 12.62 21.65
7.62 (300") 4.039 6.462 8.53 13.12 10.99 16.11 15.08 25.93
8.89 (350") 4.712 7.539 9.97 15.33 12.84 18.82 17.54 30.20
10.16 (400") 5.385 8.616 11.41 17.54 14.70 21.52 20.00 34.48
12.70 (500") 6.731 10.770 14.29 21.95 18.40 26.93 24.93 43.03
15.24 (600") 8.077 12.923 17.17 26.36 22.11 32.34 29.85 51.58
17.78 (700") 9.423 15.077 20.05 30.78 25.81 37.75 34.77 60.13
20.32 (800") 10.770 17.231 22.93 35.19 29.52 43.16 39.70 68.68
22.86 (900") 12.116 19.385 25.81 39.60 33.23 48.58 44.62 77.23
25.40 (1000") 13.462 21.539 28.69 44.02 36.93 53.99 49.54 85.78
27.94 (1100") 14.808 23.693 31.57 48.43 40.64 59.40 54.47 94.33
30.48 (1200") 16.154 25.847 34.45 52.84 44.34 64.81 59.39 102.88
33.02 (1300") 17.501 28.001 37.33 57.26 48.05 70.22 64.31 111.43
35.56 (1400") 18.847 30.155 40.21 61.67 51.75 75.63 69.24 119.98
38.10 (1500") 20.193 32.309 43.09 66.08 55.46 81.04 74.16 128.53
Lens model / Modèle d’objectif
/ 投写レンズ品番 ET-D3QT600 ET-D3QT700 ET-D3QT800
Throw ratio / Rapport de projection
/ スローレシオ 3.19 - 4.60:1 4.61 - 6.49:1 5.89 - 9.21:1
SD SH SW LW LT LW LT LW LT
2.54 (100") 1.346 2.154 6.76 9.77 9.77 13.79 12.51 19.62
3.05 (120") 1.615 2.585 8.15 11.79 11.78 16.63 15.08 23.64
3.81 (150") 2.019 3.231 10.25 14.80 14.80 20.88 18.93 29.66
5.08 (200") 2.692 4.308 13.74 19.84 19.84 27.97 25.35 39.69
6.35 (250") 3.365 5.385 17.23 24.87 24.87 35.05 31.77 49.72
7.62 (300") 4.039 6.462 20.72 29.90 29.90 42.14 38.19 59.75
8.89 (350") 4.712 7.539 24.21 34.93 34.93 49.23 44.61 69.79
10.16 (400") 5.385 8.616 27.70 39.96 39.96 56.32 51.03 79.82
12.70 (500") 6.731 10.770 34.68 50.03 50.03 70.50 63.88 99.88
15.24 (600") 8.077 12.923 41.66 60.09 60.09 84.67 76.72 119.95
17.78 (700") 9.423 15.077 48.64 70.16 70.15 98.85 89.56 140.01
20.32 (800") 10.770 17.231 55.62 80.22 80.22 113.02 102.40 160.08
22.86 (900") 12.116 19.385 62.60 90.28 90.28 127.20 115.24 180.14
25.40 (1000") 13.462 21.539 69.58 100.35 100.35 141.38 128.09 200.20
27.94 (1100") 14.808 23.693 76.56 110.41 110.41 155.55 140.93 220.27
30.48 (1200") 16.154 25.847 83.54 120.47 120.47 169.73 153.77 240.33
33.02 (1300") 17.501 28.001 90.52 130.54 130.54 183.91 166.61 260.40
35.56 (1400") 18.847 30.155 97.50 140.60 140.60 198.08 179.45 280.46
38.10 (1500") 20.193 32.309 104.48 150.67 150.67 212.26 192.30 300.53

3
Appendix / Annexe / 付録
Appendix / Annexe / 付録（continued / suite / つづき）
zWhen the screen aspect ratio is 16:9
zLorsque le rapport d’ aspect de l'écran est 16:9
zアスペクト比 16:9
（Unit / Unités / 単位 : m）
Lens model / Modèle d’objectif
/ 投写レンズ品番 ET-D3QW300 ET-D3QS400 ET-D3QT500
Throw ratio / Rapport de projection
/ スローレシオ 1.18 - 1.81:1 1.52 - 2.23:1 2.13 - 3.63:1
SD SH SW LW LT LW LT LW LT
2.54 (100") 1.245 2.214 2.55 3.97 3.30 4.88 4.86 8.19
3.05 (120") 1.494 2.657 3.08 4.78 3.99 5.89 5.77 9.77
3.81 (150") 1.868 3.321 3.88 6.01 5.02 7.39 7.14 12.14
5.08 (200") 2.491 4.428 5.21 8.05 6.73 9.89 9.42 16.10
6.35 (250") 3.113 5.535 6.55 10.09 8.44 12.39 11.69 20.05
7.62 (300") 3.736 6.641 7.88 12.13 10.16 14.89 13.97 24.00
8.89 (350") 4.358 7.748 9.21 14.17 11.87 17.40 16.25 27.96
10.16 (400") 4.981 8.855 10.54 16.21 13.59 19.90 18.52 31.91
12.70 (500") 6.226 11.069 13.21 20.30 17.01 24.90 23.08 39.82
15.24 (600") 7.472 13.283 15.87 24.38 20.44 29.91 27.63 47.73
17.78 (700") 8.717 15.497 18.54 28.46 23.87 34.91 32.19 55.64
20.32 (800") 9.962 17.710 21.20 32.54 27.30 39.92 36.74 63.55
22.86 (900") 11.207 19.924 23.87 36.63 30.72 44.92 41.30 71.46
25.40 (1000") 12.453 22.138 26.53 40.71 34.15 49.93 45.85 79.37
27.94 (1100") 13.698 24.352 29.19 44.79 37.58 54.93 50.41 87.28
30.48 (1200") 14.943 26.566 31.86 48.87 41.01 59.94 54.96 95.19
33.02 (1300") 16.188 28.779 34.52 52.95 44.44 64.94 59.51 103.10
35.56 (1400") 17.434 30.993 37.19 57.04 47.86 69.95 64.07 111.01
38.10 (1500") 18.679 33.207 39.85 61.12 51.29 74.95 68.62 118.92
Lens model / Modèle d’objectif
/ 投写レンズ品番 ET-D3QT600 ET-D3QT700 ET-D3QT800
Throw ratio / Rapport de projection
/ スローレシオ 2.87 - 4.13:1 4.14 - 5.83:1 5.30 - 8.28:1
SD SH SW LW LT LW LT LW LT
2.54 (100") 1.245 2.214 6.23 9.02 9.02 12.73 11.55 18.12
3.05 (120") 1.494 2.657 7.52 10.88 10.88 15.35 13.92 21.83
3.81 (150") 1.868 3.321 9.46 13.67 13.67 19.28 17.49 27.40
5.08 (200") 2.491 4.428 12.69 18.33 18.33 25.84 23.43 36.68
6.35 (250") 3.113 5.535 15.92 22.98 22.98 32.40 29.36 45.96
7.62 (300") 3.736 6.641 19.15 27.64 27.64 38.95 35.30 55.24
8.89 (350") 4.358 7.748 22.38 32.29 32.29 45.51 41.24 64.52
10.16 (400") 4.981 8.855 25.60 36.95 36.94 52.07 47.18 73.80
12.70 (500") 6.226 11.069 32.06 46.25 46.25 65.18 59.06 92.36
15.24 (600") 7.472 13.283 38.52 55.56 55.56 78.29 70.94 110.92
17.78 (700") 8.717 15.497 44.98 64.87 64.87 91.41 82.82 129.48
20.32 (800") 9.962 17.710 51.43 74.18 74.18 104.52 94.70 148.04
22.86 (900") 11.207 19.924 57.89 83.49 83.49 117.63 106.58 166.60
25.40 (1000") 12.453 22.138 64.35 92.80 92.80 130.75 118.46 185.16
27.94 (1100") 13.698 24.352 70.80 102.11 102.11 143.86 130.34 203.72
30.48 (1200") 14.943 26.566 77.26 111.42 111.42 156.97 142.22 222.28
33.02 (1300") 16.188 28.779 83.72 120.73 120.73 170.09 154.10 240.84
35.56 (1400") 17.434 30.993 90.17 130.04 130.04 183.20 165.97 259.40
38.10 (1500") 18.679 33.207 96.63 139.35 139.35 196.31 177.85 277.96

4Appendix / Annexe / 付録
Appendix / Annexe / 付録（continued / suite / つづき）
zWhen the screen aspect ratio is 4:3
zLorsque le rapport d’ aspect de l'écran est 4:3
zアスペクト比 4:3 （Unit / Unités / 単位 : m）
Lens model / Modèle d’objectif
/ 投写レンズ品番 ET-D3QW300 ET-D3QS400 ET-D3QT500
Throw ratio / Rapport de projection
/ スローレシオ 1.58 - 2.43:1 2.04 - 2.98:1 2.82 - 4.83:1
SD SH SW LW LT LW LT LW LT
2.54 (100") 1.524 2.032 3.15 4.88 4.07 6.00 5.88 9.96
3.05 (120") 1.829 2.438 3.80 5.88 4.91 7.23 7.00 11.89
3.81 (150") 2.286 3.048 4.78 7.38 6.17 9.07 8.67 14.80
5.08 (200") 3.048 4.064 6.41 9.88 8.26 12.13 11.45 19.64
6.35 (250") 3.810 5.080 8.04 12.38 10.36 15.19 14.24 24.48
7.62 (300") 4.572 6.096 9.67 14.87 12.46 18.26 17.03 29.32
8.89 (350") 5.334 7.112 11.30 17.37 14.56 21.32 19.82 34.16
10.16 (400") 6.096 8.128 12.93 19.87 16.65 24.38 22.60 39.00
12.70 (500") 7.620 10.160 16.19 24.87 20.85 30.51 28.18 48.68
15.24 (600") 9.144 12.192 19.45 29.86 25.04 36.63 33.75 58.35
17.78 (700") 10.668 14.224 22.71 34.86 29.24 42.76 39.32 68.03
20.32 (800") 12.192 16.256 25.97 39.85 33.44 48.88 44.90 77.71
22.86 (900") 13.716 18.288 29.23 44.85 37.63 55.01 50.47 87.39
25.40 (1000") 15.240 20.320 32.49 49.85 41.83 61.13 56.05 97.07
27.94 (1100") 16.764 22.352 35.76 54.84 46.02 67.26 61.62 106.75
30.48 (1200") 18.288 24.384 39.02 59.84 50.22 73.38 67.19 116.43
33.02 (1300") 19.812 26.416 42.28 64.83 54.41 79.51 72.77 126.11
35.56 (1400") 21.336 28.448 45.54 69.83 58.61 85.63 78.34 135.79
38.10 (1500") 22.860 30.480 48.80 74.82 62.80 91.76 83.92 145.47
Lens model / Modèle d’objectif
/ 投写レンズ品番 ET-D3QT600 ET-D3QT700 ET-D3QT800
Throw ratio / Rapport de projection
/ スローレシオ 3.84 - 5.53:1 5.54 - 7.80:1 7.06 - 11.06:1
SD SH SW LW LT LW LT LW LT
2.54 (100") 1.524 2.032 7.68 11.10 11.10 15.66 14.15 22.27
3.05 (120") 1.829 2.438 9.26 13.38 13.38 18.87 17.06 26.82
3.81 (150") 2.286 3.048 11.63 16.80 16.80 23.69 21.42 33.63
5.08 (200") 3.048 4.064 15.58 22.49 22.49 31.71 28.69 44.99
6.35 (250") 3.810 5.080 19.53 28.19 28.19 39.74 35.96 56.35
7.62 (300") 4.572 6.096 23.48 33.89 33.89 47.76 43.23 67.70
8.89 (350") 5.334 7.112 27.43 39.58 39.58 55.78 50.50 79.06
10.16 (400") 6.096 8.128 31.39 45.28 45.28 63.81 57.77 90.42
12.70 (500") 7.620 10.160 39.29 56.67 56.67 79.86 72.30 113.13
15.24 (600") 9.144 12.192 47.19 68.07 68.07 95.91 86.84 135.85
17.78 (700") 10.668 14.224 55.09 79.46 79.46 111.95 101.38 158.56
20.32 (800") 12.192 16.256 63.00 90.85 90.85 128.00 115.92 181.28
22.86 (900") 13.716 18.288 70.90 102.25 102.25 144.05 130.46 203.99
25.40 (1000") 15.240 20.320 78.80 113.64 113.64 160.10 145.00 226.70
27.94 (1100") 16.764 22.352 86.70 125.03 125.03 176.15 159.53 249.42
30.48 (1200") 18.288 24.384 94.60 136.43 136.42 192.20 174.07 272.13
33.02 (1300") 19.812 26.416 102.51 147.82 147.82 208.25 188.61 294.85
35.56 (1400") 21.336 28.448 110.41 159.21 159.21 224.29 203.15 317.56
38.10 (1500") 22.860 30.480 118.31 170.60 170.60 240.34 217.69 340.28

5
Appendix / Annexe / 付録
Appendix / Annexe / 付録（continued / suite / つづき）
Note
zA ±5 % error in listed projection distances may occur.
In addition, when [KEYSTONE] is used, distance is corrected to become smaller than the specied screen size.
zThe throw ratio is based on the value during projection with the projected image size of 5.08 m (200").
zThe periods used in the numbers in the tables are decimal points.
Remarque
zUne erreur de ±5 % dans des distances de projection énumérées peut se produire.
En outre, lorsque [CORRECTION DE TRAPÈZE] est utilisé, la distance est corrigée pour devenir inférieure à
la taille d’écran spéciée.
zLe rapport de projection est basé sur la valeur en cours de projection avec une taille de l’image projetée de
5,08 m (200").
zLes points utilisés dans les nombres dans les tableaux sont des points décimaux.
お知らせ
z記載の投写距離は± 5％以下の範囲内で誤差が発生します。
また、［台形補正］使用時は、所定の画面サイズよりも小さくなる方向で補正されます。
zスローレシオは、投写画面サイズ 200 型投写時の値を基準にしています。
Setting-up dimensions which are not given in the above table can be calculated using the formulas below.
Check the projected image size SD (m) and use the following formula to determine projection distance (L).
La configuration des dimensions qui ne sont pas données dans le tableau ci-dessus peut être calculée à
l’aide des formules suivantes. Vérifiez la taille de l’image projetée SD (m) et utilisez la formule suivante
pour déterminer la distance de projection (L).
上記の表以外の投写寸法は次の計算式で求めることができます。画面対角サイズ SD（m）をご確認のうえ、
それぞれの計算式で投写距離（L）を求めてください。

6Appendix / Annexe / 付録
Appendix / Annexe / 付録（continued / suite / つづき）
zProjection distance formulas
zFormules de distance de projection
z投写距離計算式
The dimensions of the following table contain a slight error.
Periods are used to represent decimal points in the calculation formulas in the following table.
Les dimensions du tableau suivant peuvent présenter un léger écart.
Les points sont utilisés pour indiquer les décimales dans les formules de calcul dans le tableau suivant.
次の表内の寸法は若干の誤差があります。
（Unit / Unités / 単位 : m）
L
LW LT
ET-D3QW300 When the screen aspect ratio is 17:9
Lorsque le rapport d’ aspect de l'écran est 17:9
画面アスペクト比 17:9 のとき
=0.9981 ×SD - 0.1156 =1.5291 ×SD - 0.1143
When the screen aspect ratio is 16:10
Lorsque le rapport d’ aspect de l'écran est 16:10
画面アスペクト比 16:10 のとき
=1.1341 ×SD - 0.1156 =1.7374 ×SD - 0.1143
When the screen aspect ratio is 16:9
Lorsque le rapport d’ aspect de l'écran est 16:9
画面アスペクト比 16:9 のとき
=1.0490 ×SD - 0.1156 =1.6072 ×SD - 0.1143
When the screen aspect ratio is 4:3
Lorsque le rapport d’ aspect de l'écran est 4:3
画面アスペクト比 4:3 のとき
=1.2839 ×SD - 0.1156 =1.9669 ×SD - 0.1143
ET-D3QS400 When the screen aspect ratio is 17:9
Lorsque le rapport d’ aspect de l'écran est 17:9
画面アスペクト比 17:9 のとき
=1.2841 ×SD - 0.1267 =1.8748 ×SD - 0.1207
When the screen aspect ratio is 16:10
Lorsque le rapport d’ aspect de l'écran est 16:10
画面アスペクト比 16:10 のとき
=1.4590 ×SD - 0.1267 =2.1302 ×SD - 0.1207
When the screen aspect ratio is 16:9
Lorsque le rapport d’ aspect de l'écran est 16:9
画面アスペクト比 16:9 のとき
=1.3496 ×SD - 0.1267 =1.9705 ×SD - 0.1207
When the screen aspect ratio is 4:3
Lorsque le rapport d’ aspect de l'écran est 4:3
画面アスペクト比 4:3 のとき
=1.6517 ×SD - 0.1267 =2.4115 ×SD - 0.1207
ET-D3QT500 When the screen aspect ratio is 17:9
Lorsque le rapport d’ aspect de l'écran est 17:9
画面アスペクト比 17:9 のとき
=1.7060 ×SD + 0.3072 =2.9627 ×SD + 0.2772
When the screen aspect ratio is 16:10
Lorsque le rapport d’ aspect de l'écran est 16:10
画面アスペクト比 16:10 のとき
=1.9384 ×SD + 0.3072 =3.3663 ×SD + 0.2772
When the screen aspect ratio is 16:9
Lorsque le rapport d’ aspect de l'écran est 16:9
画面アスペクト比 16:9 のとき
=1.7931 ×SD + 0.3072 =3.1139 ×SD + 0.2772
When the screen aspect ratio is 4:3
Lorsque le rapport d’ aspect de l'écran est 4:3
画面アスペクト比 4:3 のとき
=2.1944 ×SD + 0.3072 =3.8109 ×SD + 0.2772

7
Appendix / Annexe / 付録
Appendix / Annexe / 付録（continued / suite / つづき）
（Unit / Unités / 単位 : m）
L
LW LT
ET-D3QT600 When the screen aspect ratio is 17:9
Lorsque le rapport d’ aspect de l'écran est 17:9
画面アスペクト比 17:9 のとき
=2.4187 ×SD - 0.2235 =3.4871 ×SD - 0.2915
When the screen aspect ratio is 16:10
Lorsque le rapport d’ aspect de l'écran est 16:10
画面アスペクト比 16:10 のとき
=2.7482 ×SD - 0.2235 =3.9621 ×SD - 0.2915
When the screen aspect ratio is 16:9
Lorsque le rapport d’ aspect de l'écran est 16:9
画面アスペクト比 16:9 のとき
=2.5421 ×SD - 0.2235 =3.6651 ×SD - 0.2915
When the screen aspect ratio is 4:3
Lorsque le rapport d’ aspect de l'écran est 4:3
画面アスペクト比 4:3 のとき
=3.1111 ×SD - 0.2235 =4.4855 ×SD - 0.2915
ET-D3QT700 When the screen aspect ratio is 17:9
Lorsque le rapport d’ aspect de l'écran est 17:9
画面アスペクト比 17:9 のとき
=3.4871 ×SD - 0.2923 =4.9121 ×SD - 0.3863
When the screen aspect ratio is 16:10
Lorsque le rapport d’ aspect de l'écran est 16:10
画面アスペクト比 16:10 のとき
=3.9621 ×SD - 0.2923 =5.5812 ×SD - 0.3863
When the screen aspect ratio is 16:9
Lorsque le rapport d’ aspect de l'écran est 16:9
画面アスペクト比 16:9 のとき
=3.6651 ×SD - 0.2923 =5.1627 ×SD - 0.3863
When the screen aspect ratio is 4:3
Lorsque le rapport d’ aspect de l'écran est 4:3
画面アスペクト比 4:3 のとき
=4.4855 ×SD - 0.2923 =6.3184 ×SD - 0.3863
ET-D3QT800 When the screen aspect ratio is 17:9
Lorsque le rapport d’ aspect de l'écran est 17:9
画面アスペクト比 17:9 のとき
=4.4498 ×SD - 0.3333 =6.9524 ×SD - 0.4407
When the screen aspect ratio is 16:10
Lorsque le rapport d’ aspect de l'écran est 16:10
画面アスペクト比 16:10 のとき
=5.0559 ×SD - 0.3333 =7.8994 ×SD - 0.4407
When the screen aspect ratio is 16:9
Lorsque le rapport d’ aspect de l'écran est 16:9
画面アスペクト比 16:9 のとき
=4.6768 ×SD - 0.3333 =7.3071 ×SD - 0.4407
When the screen aspect ratio is 4:3
Lorsque le rapport d’ aspect de l'écran est 4:3
画面アスペクト比 4:3 のとき
=5.7237 ×SD - 0.3333 =8.9427 ×SD - 0.4407

Panasonic System Solutions Company of North America
Two Riverfront Plaza, Newark, NJ 07102
TEL: (877) 803 - 8492
Panasonic Canada Inc.
5770 Ambler Drive, Mississauga, Ontario L4W 2T3
TEL: (905) 624 - 5010
Panasonic Corporation
Web Site : https://panasonic.net/cns/projector/
パナソニック株式会社 コネクティッドソリューションズ社
© Panasonic Corporation 2019
〒 571-8503 大阪府門真市松葉町２番 15 号 電話 [phone]
HS1119AM0 -PS
Printed in Japan
