Panasonic Corporation 2015 Unauthorized copying and distribution is a violation of law.
H-FS14140
Component Repair
Service Training Manual Ver.1.2
-S -K -KA

TABLE OF CONTENTS
1.1. Introduction
1.2. Important Notice
1.2.1. Distinction Method of Mode [-K] and Mode [-KA]
1.2.2. Distinction Method of Production Area
2 Ex
p
loded View
2.1. Lens Unit
2.2. Cam Barrel
3 Replacement Parts List
4 Service Fixture & Tools
4.1. Fixture and Tools
4.2. Clean Box
5 Maintenance
5.1. Dust / Dirt on the outer casing part(s)
5.2. Dust / Dirt on the Lens Glasses (Lens Cleaning)
5.2.2. Cleanin
g
p
rocedures of inside surface of the Lens
6 Disassembly and Assembly Instructions
6.1. Disassembly Instructions
6.1.1. Disassembly Flow Chart
6.1.2. Disassembly Procedure
6.2. Assembly Instructions
6.1.1. Assembly Flow Chart
6.1.2. Assembly Procedure
7 Adjustment
7.1. Matrix Chart for Re
p
laced Part and Necessar
y
Ad
j
ustment
7.2. Matrix Chart for Cleaning Portion and Necessary Adjustment
7.3. Flow Chart for Adjustment
7.4. Procedure for Adjustment
7.4.1. Service Fixture & Tools
7.4.2. Pre-setting
7.4.3. Projector / General-Purpose Camera / Repair Lens setting
7.4.4. 1st Lens Frame Adjustment
7.4.5. Electrical Adjustment
7.4.6. Procedure for Visual Checking (RP Chart)
7.4.7. Gluing
7.4.8. Procedure for Visual Checking (RP Chart)
8 Revision History
・ ・ ・ ・ ・ ・ ・ ・ ・ ・
・ ・ ・ ・ ・ ・ ・ ・ ・ ・
・ ・ ・ ・ ・ ・ ・ ・ ・ ・
・ ・ ・ ・ ・ ・ ・ ・ ・ ・
・ ・ ・ ・ ・ ・ ・ ・ ・ ・
・ ・ ・ ・ ・ ・ ・ ・ ・ ・
・ ・ ・ ・ ・ ・ ・ ・ ・ ・
・ ・ ・ ・ ・ ・ ・ ・ ・ ・
・ ・ ・ ・ ・ ・ ・ ・ ・ ・
・ ・ ・ ・ ・ ・ ・ ・ ・ ・
・ ・ ・ ・ ・ ・ ・ ・ ・ ・
14
・ ・ ・ ・ ・ ・ ・ ・ ・ ・
・ ・ ・ ・ ・ ・ ・ ・ ・ ・
・ ・ ・ ・ ・ ・ ・ ・ ・ ・
・ ・ ・ ・ ・ ・ ・ ・ ・ ・
・ ・ ・ ・ ・ ・ ・ ・ ・ ・
・ ・ ・ ・ ・ ・ ・ ・ ・ ・
・ ・ ・ ・ ・ ・ ・ ・ ・ ・
・ ・ ・ ・ ・ ・ ・ ・ ・ ・
・ ・ ・ ・ ・ ・ ・ ・ ・ ・
・ ・ ・ ・ ・ ・ ・ ・ ・ ・
・ ・ ・ ・ ・ ・ ・ ・ ・ ・
・ ・ ・ ・ ・ ・ ・ ・ ・ ・
・ ・ ・ ・ ・ ・ ・ ・ ・ ・
・ ・ ・ ・ ・ ・ ・ ・ ・ ・
・ ・ ・ ・ ・ ・ ・ ・ ・ ・
・ ・ ・ ・ ・ ・ ・ ・ ・ ・
・ ・ ・ ・ ・ ・ ・ ・ ・ ・
・ ・ ・ ・ ・ ・ ・ ・ ・ ・
・ ・ ・ ・ ・ ・ ・ ・ ・ ・
・ ・ ・ ・ ・ ・ ・ ・ ・ ・
18
18
20
25
19
20
21
21
22
23
23
25
18
26
8
8
8
・ ・ ・ ・ ・ ・ ・ ・ ・ ・
5.2.1. Cleaning procedures of outside surface of the Lens 7
7
・ ・ ・ ・ ・ ・ ・ ・ ・ ・
・ ・ ・ ・ ・ ・ ・ ・ ・ ・ 9
13
13
・ ・ ・ ・ ・ ・ ・ ・ ・ ・
・ ・ ・ ・ ・ ・ ・ ・ ・ ・
・ ・ ・ ・ ・ ・ ・ ・ ・ ・
7
7
7
6
6
6
4
5
1
1
3
PAGE
1 Service Navigation 1
1
3
・ ・ ・ ・ ・ ・ ・ ・ ・ ・ 2

1
1 Service Navigation
1.1. Introduction
This manual contains technical information, which allow service personnel's to understand and service this model.
Please place orders using the parts list and not the drawing reference numbers.
1.2. Important Notice
This manual is written for Micro Four Thirds Lens H-FS14140.
As you may know, lens hates dust, soil, sand, fingerprint. So that, you have to repair (disassembly / assembly)
with close attention. Or you have received customer complaint.
・
Use in the clean room / clean box. (At least class 10000)
This repair method isn't the exact same as factory production line. So please obey description in this manual, definitely.
Especially,
・
Disassembly / assembly order
・
Screw torque
・
Screw order
1.2.1. Distinction Method of Model [-K] and Model [-KA]
MODEL [-K] MODEL [-KA]
Character of 14 - 140 is Orange.
Character of 14 - 140 is White.

1.2.2. Distinction Method of Production Area
Made in Japan Made in China
"Made in Japan" with printing "Made in Japan" No printing
-K H-FS14140GKK AP-INBD →H-FS14140K9K PAVCX
-KA H-FS14140KKA AP-INBD
E
PP
GK
Made in Japan
Model No. Supplier Name
-S H-FS14140E-S AP-INBD →
-K H-FS14140E-K
-KA H-FS14140EKA AP-INBD
-S H-FS14140PPS AP-INBD
-K H-FS14140PPK AP-INBD
-KA H-FS14140PKA AP-INBD
-S H-FS14140GKS
Made in China
Model No. Supplier Name
H-FS14140E9S PAVCX
AP-INBD →H-FS14140E9K PAVCX
→H-FS14140P9S PAVCX
→H-FS14140P9K PAVCX
AP-INBD →H-FS14140K9S PAVCX
2
2

3
2 Exploded View
2.1. LENS UNIT
220
226
229
228
227
230
CAM BARREL

4
2.2. CAM BARREL
221
222
223
225
224

3 Replacement Parts List
Definition of Parts Supplier
・All parts are supplied from PAVCX.
227, 228 VMS8326 ZOOM DRIVE PIN 2
B212 VHD2298 SCREW 1
B213, B214 VHD2246 SCREW 2
B208 - B210 VHD2299 SCREW 3
B211 VHD1868 SCREW 1
B200 - B204,
B215 - B217 VHD2096 SCREW 8
B205 - B207 VHD2296 SCREW 1
229 VXP3917 RING MOUNT BASE UNIT 1 (-S)
230 VEB0914B-A MAIN P.C.B. 1
229 SXQ0391 RING MOUNT BASE UNIT 1 (-K, -KA)
225 5DE2HFS14140Z 5TH LENS FRAME2 UNIT 1
226 VMC2238 WAVE WASHER 1
223 3DE3HFS14140Z-H 3RD LENS FRAME3 UNIT 1
224 1DG1HFS14140Z CAM BARREL1 UNIT 1
221 VZT1160 DIRECT FRAME SHADING SHEET 1
222 2DE3HFS14140Z 2ND LENS FRAME2 UNIT 1
213 VXQ2372-A L MOUNT UNIT 1
220 1HR2HFS14140Z-H 1ST LENS HOLDER 1
212 K0ZZ00000642 OIS SWITCH 1 (-S)
212 K0ZZ00000641 OIS SWITCH 1 (-K, -KA)
210 VYC1120 DECORATION RING 1
211 VMG2090 DUST PROOF RING 1
208 DVYE1105Z REAR FRAME UNIT 1 (-K, -KA)
204 - 207 VMG1855 FLOATING RUBBER 4
208 DVYE1106Z REAR FRAME UNIT 1 (-S)
202 DVOR1092Z SHADING FRAME 1
203 VEJ2336-A LENS MOUNT CONTACT UNIT 1
Ref.No. Part No. Part Name & Description Pcs Remarks
201 VDW2635 FILTER RING 1
2
5

4 Service Fixture & Tools
4.1. Fixture and Tools
The following Fixture and Tools are used for checking and servicing this unit.
4.2. Clean Box
The repair quality is considered, and it is recommended working in the environment of satisfied clean level
less than class 10,000 (Federal Standard 209D).
Rp-Chart (L-size) Rp-Chart (M-size)
SUKZ000034 SUKZ000035
Lens Projector for Adjustment Lens Adaptor Projector Chart Lens Control Adaptor
SUKZ000030 SUKZ000031 SUKZ000032 SUKZ000033
Reference Camera / Lens
RFKZ0422 DMC-GM5 / H-FS12032
Lens Cleaning Kit Torque Driver Screw Driver Blower
VFK1900BK RFKZ0542 VFK1390
＊Use bit (for adjustment)：
T4 Torx type
＊Only supplied 10 set/box.
Glove Cloth Collimeter
6

5 Maintenance
5.1. Dust / Dirt on the outer casing part(s)
1. Blow off the dust first, then sweep out the dust from narrower spaces with soft cleaning brush.
2. Wipe up the outer casing part with the dry fuzz-free cloth.
5.2. Dust / Dirt on the Lens Glasses (Lens Cleaning)
5.2.1. Cleaning procedures of outside surface of the Lens
1. Blow off the dust on the Lens glass surface with the Blower, gently. (Do not blow strongly.)
2. Wipe out the dirt on the Lens glass surface with Lens Cleaning Kit (VFK1900BK) if necessary.
(Consult the instruction sheet which is included in the Lens Cleaning Kit in details.)
5.2.1. Cleaning procedures of inside surface of the Lens
1. When removing the each above unit, it has to be proceed inside of satisfied clean level.
(Less than class 10,000 (Federal Standard 209D))
As for clean box, refer to the "4.2. Clean Box", in details.
【Cleaning Instruction】
Wipe the Lens surface with
cleaning sheet starting
from centre towards to
outside in a circular motion.
1st Lens Holder
2nd Lens Frame2 Unit 3rd Lens Frame3 Unit
5th Lens Frame2 Unit
7

6 Disassembly and Assembly Instructions
6.1. Disassembly Instructions
6.1.1 Disassembly Flow Chart
Lens Unit
3 Shading Frame
4 L Mount Unit
5Rear Frame Unit
OIS Switch
6Lens Mount Contact Unit Lens P.C.B. Unit
Floating Rubber
7Zoom Drive Pin
Ring Mount Base Unit
8Wave Washer
1 Decoration Ring
2Filter Ring
Dust Proof Ring
12 3rd Lens Frame3 Unit
13 5th Lens Frame2 Unit
Come Barrel
9 1st Lens Holder
10 Direct Frame Shading Sheet
11 2nd Lens Frame2 Unit
Attention
If you do the disassemble procedure after this,
it requires the disassembly of No.1 and No.2.
(For adjustment after assembly)
8

9
Important：
It must be performed inside of satisfied clean level.
(Satisfied clean level: Less than class 10,000
(Federal Standard 209D))
2. Remove the L Mount Unit.
6.1.2. Disassembly Procedure
6.1.2.3. Removal of the Shading Frame
1. Remove 2 screws (B) and the Shading Frame.
6.1.2.1. Removal of the Decoration Ring
1. Decoration Ring is sticked on the Filter Ring.
2. Put the sheet so that the lens glass is fullty covered.
3. Insert the small flat blade screwdriver to Gap
(between the Decoration Ring and lens glass), and
peel off the Decoration Ring gently.
6.1.2.4. Removal of the L Mount Unit
1. Remove 1 screw (C) and 3 screws (D).
6.1.2.2. Removal of the Filter Ring and
the Dust Proof Ring
1. Remove 3 screws (A) and the Filter Ring.
2. Remove the Dust Proof Ring.
Dust Proof Ring

10
6.1.2.5. Removal of the Rear Frame Unit and
6.1.2.6. Removal of the Lens P.C.B. Unit and
3. Remove the Hook of the OIS Switch.
1. Remove 2 screws (G) and Zoom Drive Pin.
the OIS Switch
the Lens Mount Contact Unit
1. Remove 3 screws (E) and disconnect 1 connector.
1. Disconnect 4 connectors.
2. Remove the Rear Frame Unit.
2. Remove the Lens P.C.B. Unit and
the Lens Mount Connect Unit.
3. Disconnect a connector of the Lens P.C.B. Unit and
remove the Lens Mount Connect Unit.
6.1.2.7. Removal of the Zoom Drive Pin and
the Ring Mount Base Unit

11
1. Remove the 2nd Lens Frame2 Unit.
6.1.2.9. Removal of the 1st Lens Holder and
the Cam Barrel
1. Rotate the Cam Barrel clockwise when you watch
it from back.
6.1.2.11. Removal of the 2nd Lens Frame2 Unit
2. Remove 3 screws (F) and Ring Mount Base Unit.
6.1.2.10. Removal of the Direct Frame
Shading Sheet
1. Direct Frame Shading Sheet is sticked on the Cam Barrel.
2. Put the sheet so that the lens glass is fullty covered.
3. Insert the small flat blade screwdriver to Gap
(between the Direct Frame Shading Sheet and the 2nd
Lens Frame2 Unit), and peel off the Direct Frame
Shading Sheet gently.
6.1.2.8. Removal of the Wave Washer
1. Remove the Wave Washer.
Direct Frame Shading Sheet
2nd lens frame2 unit

12
6.1.2.12. Removal of the 3rd Lens Frame3 Unit
1. Remove the 3rd Lens Frame3 Unit.
6.1.2.13. Removal of the 5th Lens Frame2 Unit
1. Remove the 5th Lens Frame2 Unit.
3rd lens frame3 unit
5th lens frame2 unit
Cam Barrel Unit

6.2. Assembly Instruction
s
6.2.1 Assembly Flow Chart
15th Lens Frame2 Unit
Come Barrel
2 3rd Lens Frame3 Unit
3 2nd Lens Frame2 Unit
4Direct Frame Shading Sheet
5 1st Lens Holder
6 Wave Washer
7Zoom Drive Pin
Ring Mount Base Unit
8Lens Mount Contact Unit Lens P.C.B. Unit
Floating Rubber
9Rear Frame Unit
OIS Switch
10 L Mount Unit
13 Decoration Ring
Lens Unit
11 Shading Frame
12 Dust Proof Ring
Filter Ring
Attention
If you made the assembly of the No.5 from No.1,
it will requre adjustment before assembling the No.12 and No.13.
13

Im
p
ortant：
When tightening the screw, use a torque driver
(RFKZ0542) by ordering the screwing order with
specified torque described in each step.
1. Install the 3rd Lens Frame3 Unit.
1. To put the Direct Frame Shading Sheet so that a Gap
between the 2nd Lens Frame Unit and the Cam Barrel
is hidden.
6.2.2.2. Installation of the 3rd Lens Frame3 Unit
6.2.2.3. Removal of the 2nd Lens Frame Unit
1. Install the 2nd Lens Frame Unit after aligning
6.2.2.4. Installation of the Direct Frame
Shading Sheet
6.2.2. Assembly Procedure
1. Install the 5th Lens Frame2 Unit after aligning
phase mark (Δ).
6.2.2.1. Installation of the 5th Lens Frame2 Unit
2. Installation notice：
Do not forget to insert each FPC to each FPC slit.
phase mark (Δ).
3rd Lens Frame3 Unit
FPC Slit
Insert
Insert
5th Lens Frame2 Unit
Phase mark (∆)
2nd Lens Frame Unit
Phase mark (∆)
Direct Frame Shading Sheet
14

1. Align phase mark (Δ) and rotate the Cam Barrel Unit 4. Tighten 2 screws (G) in numerical order by using the torque driver with specified torque.
clockwise when you watch it from back.
6.2.2.5. Installation of the 1st Lens Holder and
the Cam Barrel
6.2.2.7. Installation of the Ring Mount Base
Screw Order ① → ② → ③
Torque 10 ± 1 N ・cm
6.2.2.8. Installation of the Lens P.C.B. Unit and
the Lens Mount Contact Unit
1. Connect FPC of Lens Mount Connect Unit to connector.
3. Install the Zoom Drive Pin.
6.2.2.6. Installation of the Wave Washer
1. Install the Wave Washer.
Torque 10 ± 1 N ・cm
Screw Order ① → ②
Unit and the Zoom Drive Pin
1. Install the Ring Mount Base.
2. Tighten 3 screws (F) in numerical order
by using the torque driver with specified torque.
2. Installation the Lens P.C.B. Unit and
the Lens Mount Connect Unit.
3. Connect FPCs to 4 connectors of the Lens P.C.B. Unit.
15

6.2.2.9. Removal of the OIS Switch and
the Rear Frame Unit
1. Hook the upperside hook.
6.2.2.10. Installation of the L Mount Unit
Screw Order ① → ② → ③
Torque 8 ± 1 N ・cm
Then, push the underside hook into.
2. Install the Rear Frame Unit.
3. Connect FPC to a connector of the Lens P.C.B. Unit.
4. Tighten 3 screws (E) in numerical order
by using the torque driver with specified torque.
1. Install the L Mount Unit.
2. Tighten 1 screw (C) and 3 screws (D) in numerical
order by using the torque driver with specified torque.
Screw Order ① → ② → ③ → ④
Torque：screw (D) 20 ± 1.2 N ・cm
Torque：screw (C) 8 ± 1 N ・cm
16

Screw Order ① → ② → ③
Torque 10 ± 1 N ・cm
6.2.2.12. Installation of the Dust Proof Ring an
d
the Filter Ring.
1. Install the Dust Proof Ring.
2. Install the Filter Ring.
3. Tighten 2 screws (A) in numerical order
by using the torque driver with specified torque.
1. Install the Shading Frame.
6.2.2.11. Installation of the Shading Frame
2. Tighten 2 screws (B) in numerical order
by using the torque driver with specified torque.
Screw Order ① → ②
Torque 10 ± 1 N ・cm
・Double-stick tape sticks to the Decoration Ring of
therepair part.
Please remove the old double-stick tape from
the Lens Unit.
2. After installing the Decoration Ring use a soft cloth to
Press it into place.
6.2.2.13. Installation of the Decoration Ring
1. Please insert the dent of the Decoration Ring to
convex of the Filter Ring.
・Use new one, do not use the one which is removed.
17

7 Adjustment
7.1. Matrix Chart for Replaced Part and Necessary Adjustment
The relation between Replaced part and Necessary Adjustment is shown in the following table.
When concerned part is replaced, be sure to achieve the necessary adjustment(s).
*1 NOTE:
In the case of replacing a single part in the scratches or damage, the adjustment is not necessary.
7.2. Matrix Chart for Cleaning Portion and Necessary Adjustment
The relation Cleaning portion and Necessary Adjustment is shown in the following table.
When concerned part is replaced, be sure to achieve the necessary adjustment(s).
Replaced Part Necessary Adjustment
Electrical
Adjustment 1st Lens Frame Adjustment
DECORATION RING (*1) ○○
DUST PROOF RING (*1) ○○
FILTER RING (*1) ○○
SHADING FRAME - - - - - -
L MOUNT UNIT - - - - - -
OIS SWITCH - - - - - -
REAR FRAME UNIT - - - - - -
LENS MOUNT CONTACT UNIT - - - - - -
FLOATING RUBBER - - - - - -
LENS P.C.B. ◎- - -
ZOOM DRIVE PIN - - - - - -
RING MOUNT BASE UNIT - - - - - -
1ST LENS HOLDER ◎◎
WAVE WASHER - - - - - -
DIRECT FRAME SHADING SHEET ◎◎
2ND LENS FRAME2 UNIT ◎◎
3RD LENS FRAME3 UNIT ◎◎
5TH LENS FRAME2 UNIT ◎◎
CAM BARREL1 UNIT ◎◎
Inside surface of the Lens ◎◎
Cleaning Portion Necessary Adjustment
Electrical
Adjustment 1st Lens Frame Adjustment
Outside surface of the Lens - - - - - -
18
