Panasonic CQ-C1013H User manual

General
Power Supply DC 12V (11V - 16V),
Test Voltage 14.4V
Negative Ground
Tone Controls Bass ; ±12dB at 100Hz
Treble ; ±12dB at 10kHz
Current Consumption Less than 2.2A (CD play mode,
0.5W×4ch)
Maximum Power Output 45W×4ch (at 1kHz, Vol. Max.)
Suitable Speaker Impedance 4-8Ω
FM Stereo Radio
Frequency Range 87.5 - 108MHz
Usable Sensitivity 11.0dBf (1.25µV, 75Ω)
AM Radio
Frequency Range 531 - 1,602kHz
© 2005 Matsushita Electric Industrial Co., Ltd. All
rights reserved. Unauthorized copying and
distribution is a violation of law.
CQ-C1013H
Removable Front Panel CD Player /
Receiver
Usable Sensitivity 28dB/µV (25µV, S/N 20dB)
CD Player
Sampling Frequency 8 times oversampling
Pick-Up Type Astigma 3-beam
Light Source Semiconductor Laser
Wavelength 780nm
Frequency Response 20Hz to 20,000Hz (±1dB)
Signal to Noise Ratio 96dB
Dimensions** 178×50×155mm
Weight** 1.4kg
* Specifications and the design are subject to possible modification
without notice due to improvements.
** Dimensions and Weight shown are approximate.
AUTOMOTIVE AFTERMARKET
Specifications *
Order No. ACED051219C3

1 ABOUT LEAD FREE SOLDER (PbF) 2
2 FEATUERS 2
3 LASER PRODUCTS 2
4 REPLACEING THE FUSE 2
5 MAINTENANCE 3
6 NOTES 3
7 DIMENSIONS 3
8 WIRING CONNECTION 4
9 BLOCK DIAGRAM 5
10 TERMINALS DESCRIPTION 6
1 ABOUT LEAD FREE
SOLDER (PbF)
Distinction of PbF PCB:
PCBs (manufactured) using lead free solder will have a PbF
stamp on the PCB.
Caution :
• • •
• Pb free solder has a higher melting point than standard
solder; Typically the melting point is 50 - 70°F (30 -
40°C) higher. Please use a soldering iron with
temperature control and adjust it to 700 ± 20°F (370 ±
10°C). In case of using high temperature soldering iron,
please be careful not to heat too long.
• • •
• Pb free solder will tend to splash when heated too high
(about 1100°F/600°C)
• • •
• This lead free solder will be used for the products after
serial No. 1,000,001.
2 FEATUERS
• • •
• 18-FM, 6-AM presets with preset scan
• • •
• Digital servo for reliable CD playback.
• • •
• Removable face plate.
11 PACKAGE AND IC BLOCK DIAGRAM 8
12 REPLACEMENT PARTS LIST 12
13 EXPLODED VIEW (Unit) 16
14 CD PLAYER MECHANICAL PARTS LIST 17
15 EXPLODED VIEW (CD Deck) 18
16 WIRING DIAGRAM 19
17 SCHEMATIC DIAGRAM-1 23
18 SCHEMATIC DIAGRAM-2 25
19 SCHEMATIC DIAGRAM for printing with A4 size 27
3 LASER PRODUCTS
4 REPLACEING THE FUSE
Use fuses of the same specified rating (15A). Using different
substitutes or fuses with higher ratings, or connecting the
product directly without a fuse, could cause fire or damage to
the stereo unit.
CONTENTS
Page Page
2
CQ-C1013H

5 MAINTENANCE
Your products is designed and manufactured to ensure a
minimum of maintenance. Use a dry, a soft cloth for routine
exterior cleaning. Never use benzine, thinner or other solvents.
6 NOTES
[RADIO BLOCK]
Do not align the AM/FM package block. When the package
block is necessary, it will be supplied already aligned at the
factory.
[CD DECK BLOCK]
This model has no servo alignment points because
microcomputer controls the servo circuit.
7 DIMENSIONS
3
CQ-C1013H

8 WIRING CONNECTION
4
CQ-C1013H

9 BLOCK DIAGRAM
5
CQ-C1013H

IC601 : C2CBGF000215
Pin
No. Port Description I/O(V) FM(V) AM(V) CD(V)
1XIN 4. 5 MHz X’tal and
Connection I2.4 2.49 2.48
2TEST2 GND connection I 0 0 0
3VREG Bypass condenser
connected. O2.9 2.99 2.99
4VSSCPU GND connection - 0 0 0
5CDC_DAT
ACD changer data I0.01 0.01 0.01
6N.C. None - - - -
7CDC_CLK CD changer clock I 0 0.01 0.01
8CDC_REM
_OUT CD changer Remote out O0.01 0.01 0.01
9LCD_DO LCD data output I5.1 5.17 5.17
10 LCD_DI LCD data input O4.95 5.01 4.92
11 LCD_CLK LCD clock O 5 5.14 5.12
12 LCD_CE LCD chip enable
output O0.1 0.18 0.23
13 CD_DO CD data output I5.3 5.27 4.92
14 CD_DI CD data input O0.01 0.01 5.12
15 CD_CLK CD clock O 5 5.17 5.1
16 CD_CE CD chip enable O0.01 0.01 0.4
17 CD_LM+ CD eject O0.02 0.02 0.02
18 CD_LM- CD loading O0.01 0.01 5.15
19 CD_S/L CD 24PIN
connection O0.01 0 0
20 CD_WRQ CD WRQ connection I5.3 5.29 0.1
21 CD_INSW
1CD insert SW input I0.1 0.1 0.1
22 CD_SW2 CD MECHA SW2 I 5 5.14 5.13
23 CD_LIMI
T_SW CD limit SW I 0 0 5.26
24 CD_DRF CD DRF I 0 0 5.15
25 CD_RST CD reset O 5 5.17 5.14
26 CD_MUTE CD mute O 0 0 0
27 N.C. None - - - -
28 N.C. None - - - -
29 PANEL Panel detect I5.18 5.18 0
30 N.C. GND connection I 0 0 0
31 N.C. GND connection I 0 0 0
32 N.C. GND connection I 0 0 0
33 N.C. None - - - -
34 N.C. None - - - -
35 N.C. None - - - -
36 N.C. None - - - -
37 N.C. None - - - -
38 N.C. None - - - -
39 VDDPORT Power supply of
PORT - 5 5.17 0
40 VSSPORT GND of PORT - 0 0 0
41 N.C. None - - - -
42 N.C. None - - - -
43 N.C. None - - - -
44 N.C. None - - - -
45 N.C. None - - - -
46 N.C. None - - - -
47 N.C. None - - - -
48 N.C. None - - - -
49 PWR_CNT Power control O 5 5.15 5.14
50 AMP_CNT Amp stand-by O 5 5.15 5.13
51 AMP_MUT
EAmp mute O 5 5.15 5.15
52 N.C. None - - - -
53 SSC Tuner search
sensitivity change O0.06 0.06 0.06
54 N.C.(AF
_MUTE) None - - - -
55 I2C_DAT
AElectronic VOL data O 5 5.17 5.16
Pin
No. Port Description I/O(V) FM(V) AM(V) CD(V)
56 I2C_CLK Electronic VOL
clock O 5 5.17 5.16
57 ANT_CNT Motor antena
control O 5 5.17 5.17
58 POWER_L
ED Power LED O0.1 0.17 0.17
59 N.C. None - - - -
60 N.C. (
BZ_OUT
)
None - - - -
61 N.C. None - - - -
62 N.C. None - - - -
63 N.C. None - - - -
64 N.C. None - - - -
65 N.C. None - - - -
66 TEL_MUT
EExternal MUTE input I5.2 5.33 5.33
67 BATT Battery detection I5.2 5.33 5.33
68 MODE_B ROTARY B input I0.54 0.62 0.02
69 N.C.(RD
S_CLK) None - - - -
70 REM_IN Remocon data input I 5 5.12 5.11
71 MODE_A ROTARY A input I0.6 0.59 0.06
72 CDC_STB CD changer strobe
input I 0 0.62 0.06
73 NC None - - - -
74 MONO Compulsion MONO ON O0.03 0.03 0.03
75 AM_MODE AM change O 8 0.06 8.06
76 FM_MODE FM change O0.08 8.06 0.08
77 N.C. GND connection I 0 0 0
78 INIT_C Initial value C I 0 0 0
79 INIT_B Initial value B I2.5 5.15 5.14
80 INIT_A Initial value A I3.23 3.25 3.24
81 VSS GND connection - 0 0 0
82 N.C.(RD
S_DATA) None - - - -
83 ST FM stereo input I5.3 5.25 0.34
84 SD_FM/A
MSignal detection I3.2 3.51 0.32
85 N.C. GND connection I 0 0 0
86 RESET Reset Input IOFF OFF OFF
87 ACC Power supply I5.3 5.37 5.42
88 N.C. GND connection I 0 0 0
89 N.C. GND connection I 0 0 0
90 FM/AM_I
FC FM/AM IF input I1.4 1.45 1.45
91 N.C. GND connection I 0 0 0
92 SUBPD None O 2 2.09 1.39
93 VDDPLL Power supply of
PLL - 5 5.16 OFF
94 N.C. GND connection I 0 0 0
95 OSC_FM/
AM FM/AM osc input I1.4 1.36 1.43
96 VSSPLL GND connection - 0 0 0
97 N.C. None - - - -
98 EO1 PLL phase
comparison error
output
O 2 2.08 1.38
99 TEST1 GND connection I 0 0 0
100 XOUT 4. 5 MHz X’tal and
Connection O2.5 2.56 2.56
Note 1 :
Voltage measuerments are with respect to ground, with a
voltmeter (internal resistance : 10M ohms).
10 TERMINALS DESCRIPTION
10.1. Main Block
6
CQ-C1013H

10.2. Display Block
IC901 : YEAMLC75853NW
Pin No. Port Descriptions I/O
(V) (V)
1-27 SEG1-27 LCD segment O2.5
28-40 NC No connection - -
41-43 COM1-3 LCD common O2.5
44-49 KS1-6 Key data output O0.9
50-54 KI1-5 Key data input I 0
55 TEST (Connecting to ground) - 0
56 VDD +5V power supply -5.1
57 VDD1 Ground through capacitor -3.3
58 VDD2 Ground through capacitor -1.7
59 Vss Ground - 0
60 OSC CR oscillator -3.9
61 DO Key data output O4.4
62 CE Chip enable I 0
63 CLK LCD clock I 0
64 DI LCD data input I 0
7
CQ-C1013H

11.1. Main Block
11 PACKAGE AND IC BLOCK DIAGRAM
P50:J3CCBB000005
IC270 : C1EA00000042
8
CQ-C1013H

IC1 : C1BB00001089
9
CQ-C1013H

IC300 : C1BB00000543
IC701 : C0DAZHF00004
10
CQ-C1013H

IC2 : C1BB00001088
11
CQ-C1013H

Ref.
No. Part No. Part Name & Description Remarks
1. IC’s and Transistors
MAIN BLOCK [E-4C290]
IC1 C1BB00001089 IC T
IC2 C1BB00001088 IC T
IC270 C1EA00000042 IC T
IC300 C1BB00000543 IC T
IC601 C2CBGF000215 IC T
IC701 C0DAZHF00004 IC T
P50 J3CCBB000005 Tuner T
Q1 YEAN2SA1317T Transistor T
Q2 B1BCCF000013 Transistor T
Q50 B1GDCFEH0001 Transistor T
Q53 B1AAEC000002 Transistor T
Q54 B1GDCFEH0001 Transistor T
Q62 YEANKRA104M Transistor T
Q241 YEANKRC110S Transistor T
Q242 YEANKRC110S Transistor T
Q341 YEANKRC110S Transistor T
Q342 YEANKRC110S Transistor T
Q401 B1CAHF000003 Transistor T
Q630 YEANKRA104M Transistor T
Q701 YEANKRA104M Transistor T
Q702 B1GACFCJ0003 Transistor T
DISPLAY BLOCK [E-4C276]
IC901 YEAMLC75853NW LCD DRIVER IC
Q901 B1GDCFJJ0002 Transistor T
2. Diodes
MAIN BLOCK [E-4C290]
D604 B0ACCK000005 Diode T
D605 B0ACCK000005 Diode T
D610 B0AADL000002 Diode T
D706 B0BC6R700006 Diode T
D707 YEADSM5819A Diode T
D708 YEAD1N5404FT Diode T
D710 YEAD1N4005ST Silicon Diode T
D714 YEAD1N4005ST Silicon Diode T
DISPLAY BLOCK [E-4C276]
D900 B3AAB0000213 CHIP LED (WHITE) T
D902 MAZ80560ML Zener Diode T
D903 MAZ80560ML Zener Diode T
Ref.
No. Part No. Part Name & Description Remarks
D904 MAZ80560ML Zener Diode T
D905 MAZ80560ML Zener Diode T
D907 MAZ80560ML Zener Diode T
D919 B3AAB0000216 LED(RED) T
D920 B3AAB0000216 LED(RED) T
D921 B3AAB0000216 LED(RED) T
D922 B3AAB0000216 LED(RED) T
D923 B3AAB0000216 LED(RED) T
D924 B3AAB0000216 LED(RED) T
D925 B3AAB0000216 LED(RED) T
D926 B3AAB0000216 LED(RED) T
D927 B3AAB0000216 LED(RED) T
D928 B3AAB0000216 LED(RED) T
D929 B3AAB0000216 LED(RED) T
D930 B3AAB0000216 LED(RED) T
D931 B3AAB0000216 LED(RED) T
3. Capacitors
MAIN BLOCK [E-4C290]
C1 F2A1A330A352 Electrolytic 33pF 10WV T
C2 F1J1H103A733 Ceramic 0.01MFD 50WV T
C3 F1J1H104A036 Ceramic 0.1MFD 50WV T
C4 F1J1H104A036 Ceramic 0.1MFD 50WV T
C5 F1J1H102A733 Ceramic 1000pF 50WV T
C6 EEAFC0J560H Electrolytic 56PF 6.3WV T
C7 F1J1H103A733 Ceramic 0.01MFD 50WV T
C8 ECEA1AKA221IV Electrolytic 220PF 10WV T
C9 F1J1H104A036 Ceramic 0.1MFD 50WV T
C10 F2A0J101A049 Electrolytic 100pF 6.3WV T
C11 F1J1H104A036 Ceramic 0.1MFD 50WV T
C12 F1J1H470A732 Ceramic 47pF 50WV T
C13 F1J1H473A733 Ceramic 0.047MFD 50WV T
C14 F1J1H472A733 Ceramic 0.0047MFD 50WV T
C15 F2A1C100A041 Electrolytic 10pF 16WV T
C16 F1J1H224A784 Chip 0.22MFD 50WV T
C17 F1J1H470A732 Ceramic 47pF 50WV T
C18 F1J1H104A036 Ceramic 0.1MFD 50WV T
C19 F2A0J101A020 Electrolytic 100pF 6.3WV T
C20 F2A1A101A354 Electrolytic 100pF 10WV T
C21 F2A0J101A049 Electrolytic 100pF 6.3WV T
C22 F2A0J101A020 Electrolytic 100pF 6.3WV T
C23 F1J1H103A733 Ceramic 0.01MFD 50WV T
C24 F2A0J331A020 Electrolytic 330pF 6.3WV T
C25 F1J1H104A036 Ceramic 0.1MFD 50WV T
C26 F1J1H561A733 Ceramic 560pF 50WV T
C33 ECEA0JKS470IV Electrolytic 47PF 6.3WV T
C34 F1J1H104A036 Ceramic 0.1MFD 50WV T
C35 F1J1H473A733 Ceramic 0.047MFD 50WV T
C36 ECUV105K16AT Ceramic 1MFD 16WV T
C37 F1J1H104A036 Ceramic 0.1MFD 50WV T
C38 F1J1H104A036 Ceramic 0.1MFD 50WV T
C39 F2A0J101A049 Electrolytic 100pF 6.3WV T
C40 F1J1H104A036 Ceramic 0.1MFD 50WV T
C44 F1J1H103A733 Ceramic 0.01MFD 50WV T
C45 F2A1A101A354 Electrolytic 100pF 10WV T
C46 F2A0J101A049 Electrolytic 100pF 6.3WV T
C47 F1J1H103A733 Ceramic 0.01MFD 50WV T
C48 F1J1H221A733 Chip 220pF 50WV T
C49 F1J1H222A733 Chip 2200pF 50WV T
C50 F2A1A101A354 Electrolytic 100pF 10WV T
C51 F1J1H104A036 Ceramic 0.1MFD 50WV T
C52 F1J1H103A733 Ceramic 0.01MFD 50WV T
C54 F3F1D105A042 Ceramic 1MFD 20WV T
C61 F1J1H470A732 Ceramic 47pF 50WV T
C65 F1J1H104A036 Ceramic 0.1MFD 50WV T
C72 F2A1A101A354 Electrolytic 100pF 10WV T
C73 F1J1H103A733 Ceramic 0.01MFD 50WV T
C74 F1J1H273A733 Chip 0.027MFD 50WV T
12 REPLACEMENT PARTS LIST
12
CQ-C1013H

Ref.
No. Part No. Part Name & Description Remarks
C75 F1J1H273A733 Chip 0.027MFD 50WV T
C76 F1K1E223A069 Ceramic 0.022MFD 25WV T
C77 F1J1H123A733 Ceramic 0.012MFD 50WV T
C78 F1J1H682A733 Ceramic 6800pF 50WV T
C79 F2A1A101A354 Electrolytic 100pF 10WV T
C106 ECEA1AKA221IV Electrolytic 220PF 10WV T
C107 F1J1H103A733 Ceramic 0.01MFD 50WV T
C108 ECQV1H683JL2 Plastic Film 0.068MFD 50WV T
C209 D0GD473JA017 Chip 47k ohms 1/10W T
C215 F2A1C100A041 Electrolytic 10pF 16WV T
C216 F2A1H2R2A407 Electrolytic 2.2pF 50WV T
C217 F2A1H2R2A407 Electrolytic 2.2pF 50WV T
C218 F2A1H2R2A407 Electrolytic 2.2pF 50WV T
C219 F2A1H2R2A407 Electrolytic 2.2pF 50WV T
C220 F2A1H2R2A407 Electrolytic 2.2pF 50WV T
C221 F2A1H2R2A407 Electrolytic 2.2pF 50WV T
C249 F1J1H222A733 Chip 2200pF 50WV T
C250 F1J1H222A733 Chip 2200pF 50WV T
C271 ECQV1H224JL2 Plastic Film 0.22MFD 50WV T
C272 ECQV1H224JL2 Plastic Film 0.22MFD 50WV T
C290 ECUV105K16AT Ceramic 1MFD 16WV T
C291 ECUV105K16AT Ceramic 1MFD 16WV T
C294 ECUV105K16AT Ceramic 1MFD 16WV T
C295 ECUV105K16AT Ceramic 1MFD 16WV T
C320 F1J1H103A733 Ceramic 0.01MFD 50WV T
C349 F1J1H222A733 Chip 2200pF 50WV T
C350 F1J1H222A733 Chip 2200pF 50WV T
C371 ECQV1H224JL2 Plastic Film 0.22MFD 50WV T
C372 ECQV1H224JL2 Plastic Film 0.22MFD 50WV T
C380 F2A1H2R2A407 Electrolytic 2.2pF 50WV T
C600 F1J1H220A732 Chip 22pF 50WV T
C601 F1J1H220A732 Chip 22pF 50WV T
C602 F1J1H103A733 Ceramic 0.01MFD 50WV T
C603 ECA0JM102J Electrolytic 1000PF 6.3WV T
C605 ECUV105K16AT Ceramic 1MFD 16WV T
C607 F1J1H103A733 Ceramic 0.01MFD 50WV T
C608 F1K1H101A153 Ceramic 100pF 50WV T
C610 F1J1H103A733 Ceramic 0.01MFD 50WV T
C611 F1J1H102A733 Ceramic 1000pF 50WV T
C612 F1J1H104A036 Ceramic 0.1MFD 50WV T
C620 F1J1H103A733 Ceramic 0.01MFD 50WV T
C621 F1K1H103A116 Ceramic 0.01MFD 50WV T
C622 ECUV105K16AT Ceramic 1MFD 16WV T
C630 F2A1H2R2A407 Electrolytic 2.2pF 50WV T
C631 F2A1C100A041 Electrolytic 10pF 16WV T
C702 EEAFC1A820H Electrolytic 82PF 10WV T
C703 F1K1H103A116 Ceramic 0.01MFD 50WV T
C704 F1J1H103A733 Ceramic 0.01MFD 50WV T
C705 F1J1H103A733 Ceramic 0.01MFD 50WV T
C706 ECEA1CKA101IV Electrolytic 100PF 16WV T
C707 F1K1H103A116 Ceramic 0.01MFD 50WV T
C708 F2A1A101A354 Electrolytic 100pF 10WV T
C710 F1J1H104A036 Ceramic 0.1MFD 50WV T
C713 F1J1H103A733 Ceramic 0.01MFD 50WV T
C714 F1J1H103A733 Ceramic 0.01MFD 50WV T
C715 F1J1H103A733 Ceramic 0.01MFD 50WV T
C716 F1J1H104A036 Ceramic 0.1MFD 50WV T
C718 F1J1H104A036 Ceramic 0.1MFD 50WV T
C720 ECA1CPX222L Electrolytic 2200PF 16WV T
C721 F2A1H2R2A407 Electrolytic 2.2pF 50WV T
C722 F2A1H1R0A407 Electrolytic 1pF 50WV T
C727 F2A1A101A354 Electrolytic 100pF 10WV T
C802 ECEA1AKA221IV Electrolytic 220PF 10WV T
XL01 YEXL16M9X54A Ceramic Filter T
Z52 D4ZZ00000024 Surge Protector T
DISPLAY BLOCK [E-4C276]
C901 F1J1H103A733 Ceramic 0.01MFD 50WV T
C902 F1J1H103A733 Ceramic 0.01MFD 50WV T
C903 F1J1H821A733 Ceramic 820pF 50WV T
C908 F1J1H104A036 Ceramic 0.1MFD 50WV T
C909 F1J1H103A733 Ceramic 0.01MFD 50WV T
Ref.
No. Part No. Part Name & Description Remarks
CD INTERFACE BLOCK [E-4C288]
C1 F1J1H104A036 Ceramic 0.1MFD 50WV T
4. Resistors
MAIN BLOCK [E-4C290]
J4 D0GDR00JA017 Chip 0 ohms 1/10W T
J13 ERJ8GX0R00V Chip 0 ohms 1/8W T
J18 ERJ8GX0R00V Chip 0 ohms 1/8W T
J19 ERJ8GX0R00V Chip 0 ohms 1/8W T
J21 ERJ8GX0R00V Chip 0 ohms 1/8W T
J28 D0GDR00JA017 Chip 0 ohms 1/10W T
J29 D0GDR00JA017 Chip 0 ohms 1/10W T
J30 D0GDR00JA017 Chip 0 ohms 1/10W T
J31 D0GDR00JA017 Chip 0 ohms 1/10W T
J60 ERJ8GX0R00V Chip 0 ohms 1/8W T
J61 D0GDR00JA017 Chip 0 ohms 1/10W T
J62 D0GDR00JA017 Chip 0 ohms 1/10W T
J200 ERJ8GX0R00V Chip 0 ohms 1/8W T
J208 ERJ8GX0R00V Chip 0 ohms 1/8W T
J210 ERJ8GX0R00V Chip 0 ohms 1/8W T
J217 ERJ8GX0R00V Chip 0 ohms 1/8W T
J226 ERJ8GX0R00V Chip 0 ohms 1/8W T
J230 ERJ8GX0R00V Chip 0 ohms 1/8W T
J232 ERJ8GX0R00V Chip 0 ohms 1/8W T
J235 ERJ8GX0R00V Chip 0 ohms 1/8W T
J244 ERJ8GX0R00V Chip 0 ohms 1/8W T
J246 D0GDR00JA017 Chip 0 ohms 1/10W T
J247 ERJ8GX0R00V Chip 0 ohms 1/8W T
J248 ERJ8GX0R00V Chip 0 ohms 1/8W T
J260 D0GDR00JA017 Chip 0 ohms 1/10W T
J269 ERJ8GX0R00V Chip 0 ohms 1/8W T
J270 ERJ8GX0R00V Chip 0 ohms 1/8W T
J272 D0GDR00JA017 Chip 0 ohms 1/10W T
J273 ERJ8GX0R00V Chip 0 ohms 1/8W T
J274 ERJ8GX0R00V Chip 0 ohms 1/8W T
J276 ERJ8GX0R00V Chip 0 ohms 1/8W T
J277 D0GDR00JA017 Chip 0 ohms 1/10W T
J278 ERJ8GX0R00V Chip 0 ohms 1/8W T
J281 ERJ8GX0R00V Chip 0 ohms 1/8W T
J282 D0GDR00JA017 Chip 0 ohms 1/10W T
J283 ERJ8GX0R00V Chip 0 ohms 1/8W T
J284 ERJ8GX0R00V Chip 0 ohms 1/8W T
J285 ERJ8GX0R00V Chip 0 ohms 1/8W T
J286 ERJ8GX0R00V Chip 0 ohms 1/8W T
J287 D0GDR00JA017 Chip 0 ohms 1/10W T
J288 ERJ8GX0R00V Chip 0 ohms 1/8W T
J293 ERJ8GX0R00V Chip 0 ohms 1/8W T
J294 D0GDR00JA017 Chip 0 ohms 1/10W T
J295 D0GDR00JA017 Chip 0 ohms 1/10W T
J297 ERJ8GX0R00V Chip 0 ohms 1/8W T
J300 ERJ8GX0R00V Chip 0 ohms 1/8W T
J307 D0GDR00JA017 Chip 0 ohms 1/10W T
J308 D0GDR00JA017 Chip 0 ohms 1/10W T
J309 D0GDR00JA017 Chip 0 ohms 1/10W T
J312 D0GDR00JA017 Chip 0 ohms 1/10W T
J317 ERJ8GX0R00V Chip 0 ohms 1/8W T
J325 D0GDR00JA017 Chip 0 ohms 1/10W T
J331 ERJ8GX0R00V Chip 0 ohms 1/8W T
J332 ERJ8GX0R00V Chip 0 ohms 1/8W T
J333 ERJ8GX0R00V Chip 0 ohms 1/8W T
J334 ERJ8GX0R00V Chip 0 ohms 1/8W T
J335 ERJ8GX0R00V Chip 0 ohms 1/8W T
J336 ERJ8GX0R00V Chip 0 ohms 1/8W T
J337 ERJ8GX0R00V Chip 0 ohms 1/8W T
J340 D0GDR00JA017 Chip 0 ohms 1/10W T
J341 D0GDR00JA017 Chip 0 ohms 1/10W T
J342 ERJ8GX0R00V Chip 0 ohms 1/8W T
J343 ERJ8GX0R00V Chip 0 ohms 1/8W T
J344 ERJ8GX0R00V Chip 0 ohms 1/8W T
J345 ERJ8GX0R00V Chip 0 ohms 1/8W T
J346 D0GDR00JA017 Chip 0 ohms 1/10W T
13
CQ-C1013H

Ref.
No. Part No. Part Name & Description Remarks
J348 ERJ8GX0R00V Chip 0 ohms 1/8W T
J349 D0GDR00JA017 Chip 0 ohms 1/10W T
J350 ERJ8GX0R00V Chip 0 ohms 1/8W T
J351 ERJ8GX0R00V Chip 0 ohms 1/8W T
J352 ERJ8GX0R00V Chip 0 ohms 1/8W T
J400 D0GD221JA017 Chip 220 ohms 1/10W T
J401 D0GDR00JA017 Chip 0 ohms 1/10W T
J502 D0GDR00JA017 Chip 0 ohms 1/10W T
J601 ERJ8GX0R00V Chip 0 ohms 1/8W T
J602 D0GDR00JA017 Chip 0 ohms 1/10W T
J604 ERJ8GX0R00V Chip 0 ohms 1/8W T
J607 D0GDR00JA017 Chip 0 ohms 1/10W T
J610 ERJ8GX0R00V Chip 0 ohms 1/8W T
J611 D0GDR00JA017 Chip 0 ohms 1/10W T
J613 ERJ8GX0R00V Chip 0 ohms 1/8W T
J616 ERJ8GX0R00V Chip 0 ohms 1/8W T
J617 D0GDR00JA017 Chip 0 ohms 1/10W T
J618 D0GDR00JA017 Chip 0 ohms 1/10W T
J701 ERJ8GX0R00V Chip 0 ohms 1/8W T
J801 ERJ8GX0R00V Chip 0 ohms 1/8W T
J802 ERJ8GX0R00V Chip 0 ohms 1/8W T
J804 ERJ8GX0R00V Chip 0 ohms 1/8W T
J806 ERJ8GX0R00V Chip 0 ohms 1/8W T
J807 ERJ8GX0R00V Chip 0 ohms 1/8W T
J808 ERJ8GX0R00V Chip 0 ohms 1/8W T
J809 ERJ8GX0R00V Chip 0 ohms 1/8W T
J810 ERJ8GX0R00V Chip 0 ohms 1/8W T
J811 ERJ8GX0R00V Chip 0 ohms 1/8W T
J817 ERJ8GX0R00V Chip 0 ohms 1/8W T
J818 ERJ8GX0R00V Chip 0 ohms 1/8W T
J819 ERJ8GX0R00V Chip 0 ohms 1/8W T
J820 ERJ8GX0R00V Chip 0 ohms 1/8W T
R1 D0AE823JA131 Chip 82k ohms 1/4W T
R2 D0GD102JA017 Chip 1k ohms 1/10W T
R3 D0AE183JA131 Chip 18k ohms 1/4W T
R4 D0AE183JA131 Chip 18k ohms 1/4W T
R5 D0GD102JA017 Chip 1k ohms 1/10W T
R6 D0AE823JA131 Chip 82k ohms 1/4W T
R7 D0AE470JA131 Chip 47 ohms 1/4W T
R8 D0GD3R3JA052 Chip 3.3 ohms 1/10W T
R9 D0GD103JA017 Chip 10k ohms 1/10W T
R10 D0GD331JA017 Chip 330 ohms 1/10W T
R11 D0GD273JA017 Chip 27k ohms 1/10W T
R12 D0GD622JA017 Chip 6.2k ohms 1/10W T
R13 D0GDR00JA017 Chip 0 ohms 1/10W T
R21 D0GD820JA017 Chip 82 ohms 1/10W T
R22 D0GD681JA017 Chip 680 ohms 1/10W T
R23 D0GD681JA017 Chip 680 ohms 1/10W T
R24 D0GD123JA017 Chip 12k ohms 1/10W T
R25 D0GD122JA017 Chip 1.2k ohms 1/10W T
R26 D0GF820JA029 Chip 68k ohms 1/9W T
R36 D0GD272JA017 Chip 2.7k ohms 1/10W T
R40 D0AE103JA131 Chip 10k ohms 1/4W T
R41 D0GD622JA017 Chip 6.2k ohms 1/10W T
R42 D0GD333JA017 Chip 33k ohms 1/10W T
R43 D0GD333JA017 Chip 33k ohms 1/10W T
R48 D0AE223JA131 Chip 22k ohms 1/4W T
R49 D0AE103JA131 Chip 10k ohms 1/4W T
R50 D0GF223JA017 Chip 22k ohms 1/8W T
R51 D0GD682JA017 Chip 6.8k ohms 1/10W T
R52 D0AE223JA131 Chip 22k ohms 1/4W T
R53 ERJ6GEYJ685V Chip 68M ohms 1/10W T
R59 D0AZ102JA008 Chip 1k ohms 1/6W T
R60 ERJ8GEYJ5R6V Chip 5.6 ohms 1/8W T
R61 D0GDR00JA017 Chip 0 ohms 1/10W T
R62 D0GD101JA017 Chip 100 ohms 1/10W T
R66 D0GD393JA017 Chip 39k ohms 1/10W T
R67 D0GD123JA017 Chip 12k ohms 1/10W T
R68 D0GD123JA017 Chip 12k ohms 1/10W T
R69 D0GF221JA017 Chip 220 ohms 1/8W T
R70 D0GD102JA017 Chip 1k ohms 1/10W T
R102 D0GF511JA017 Chip 510 ohms 1/8W T
R103 D0GD512JA017 Chip 5k ohms 1/8W T
Ref.
No. Part No. Part Name & Description Remarks
R104 D0GD331JA017 Chip 330 ohms 1/10W T
R105 D0AZ100JA008 Chip 10 ohms 1/6W T
R208 D0AE102JA131 Chip 1k ohms 1/4W T
R209 D0AE102JA131 Chip 1k ohms 1/4W T
R241 D0GD103JA017 Chip 10k ohms 1/10W T
R242 D0GD103JA017 Chip 10k ohms 1/10W T
R261 D0GD181JA017 Chip 180 ohms 1/10W T
R262 D0GF181JA017 Chip 180 ohms 1/8W T
R271 D0GD561JA017 Chip 560 ohms 1/10w T
R272 D0GD561JA017 Chip 560 ohms 1/10w T
R280 ERD25TJ562T Carbon 5.6k ohms 1/4W T
R284 ERD25TJ562T Carbon 5.6k ohms 1/4W T
R341 D0GD103JA017 Chip 10k ohms 1/10W T
R342 D0GD103JA017 Chip 10k ohms 1/10W T
R361 D0GF181JA017 Chip 180 ohms 1/8W T
R362 D0GD181JA017 Chip 180 ohms 1/10W T
R371 D0GD561JA017 Chip 560 ohms 1/10w T
R372 D0GD561JA017 Chip 560 ohms 1/10w T
R601 D0GD473JA017 Chip 47k ohms 1/10W T
R602 D0GD473JA017 Chip 47k ohms 1/10W T
R604 D0GD473JA017 Chip 47k ohms 1/10W T
R606 D0AZ103JA008 Chip 10k ohms 1/6W T
R607 D0AZ103JA008 Chip 10k ohms 1/6W T
R608 D0GD104JA017 Chip 100k ohms 1/10W T
R609 D0AE102JA131 Chip 1k ohms 1/4W T
R610 D0AE102JA131 Chip 1k ohms 1/4W T
R611 D0AZ102JA008 Chip 1k ohms 1/6W T
R612 D0AE102JA131 Chip 1k ohms 1/4W T
R613 D0AZ102JA008 Chip 1k ohms 1/6W T
R616 D0AE102JA131 Chip 1k ohms 1/4W T
R618 D0GD103JA017 Chip 10k ohms 1/10W T
R619 D0GF102JA014 Chip 1k ohms 1/8W T
R622 D0AZ473JA008 Chip 47k ohms 1/6W T
R624 D0GF333JA017 Chip 3.3k ohms 1/9W T
R625 D0AZ102JA008 Chip 1k ohms 1/6W T
R626 D0GD473JA017 Chip 47k ohms 1/10W T
R627 D0GD473JA017 Chip 47k ohms 1/10W T
R628 D0GF473JA017 Chip 47k ohms 1/10W T
R629 D0GD473JA017 Chip 47k ohms 1/10W T
R630 D0GD271JA017 Chip 270 ohms 1/10W T
R634 D0AZ682JA008 Chip 6.8k ohms 1/6W T
R636 D0GD223JA017 Chip 22k ohms 1/10W T
R638 D0GD272JA017 Chip 2.7k ohms 1/10W T
R640 D1HB1024A031 Chip 1k ohms 1/16W T
R641 D1HB1024A031 Chip 1k ohms 1/16W T
R642 D1HB1024A031 Chip 1k ohms 1/16W T
R652 D0GD473JA017 Chip 47k ohms 1/10W T
R654 D0GF473JA017 Chip 47k ohms 1/10W T
R660 D0AZ102JA008 Chip 1k ohms 1/6W T
R661 D0GD102JA017 Chip 1k ohms 1/10W T
R662 D0AZ104JA008 Chip 100k ohms 1/6W T
R663 D0GD104JA017 Chip 100k ohms 1/10W T
R682 D0GD104JA017 Chip 100k ohms 1/10W T
R683 ERJ6GEYJ475V Chip 47M ohms 1/10W T
R701 D0GD473JA017 Chip 47k ohms 1/10W T
R702 D0GD153JA017 Chip 15k ohms 1/10W T
R703 D0AE102JA131 Chip 1k ohms 1/4W T
R705 D0GD333JA017 Chip 33k ohms 1/10W T
R706 D0GD473JA017 Chip 47k ohms 1/10W T
R709 D0GF332JA017 Chip 3.3k ohms 1/8W T
R710 D0GD332JA017 Chip 3.3k ohms 1/10W T
R711 ERDS2TJ823T Carbon8.2k ohms 1/4W T
R712 D0GD104JA017 Chip 100k ohms 1/10W T
R713 D0GF223JA017 Chip 22k ohms 1/8W T
R992 D0GD103JA017 Chip 10k ohms 1/10W T
R993 D0GD163JA017 Chip 16k ohms 1/10W T
DISPLAY BLOCK [E-4C276]
R901 D0GD272JA017 Chip 2.7k ohms 1/10W T
R902 D0GD683JA017 Chip 68k ohms 1/10W T
R903 D0GD102JA017 Chip 1k ohms 1/10W T
R904 D0GD102JA017 Chip 1k ohms 1/10W T
14
CQ-C1013H

Ref.
No. Part No. Part Name & Description Remarks
R905 D0GD102JA017 Chip 1k ohms 1/10W T
R906 D0GD122JA017 Chip 1.2k ohms 1/10W T
R908 D0GD681JA017 Chip 680 ohms 1/10W T
R909 D0GD102JA017 Chip 1k ohms 1/10W T
R910 D0GD4R7JA056 Chip 4.7 ohms 1/10W T
R921 D0GD561JA017 Chip 560 ohms 1/10w T
R922 D0GD821JA017 Chip 820 ohms 1/10W T
R923 D0GD561JA017 Chip 560 ohms 1/10w T
R924 D0GD561JA017 Chip 560 ohms 1/10w T
R925 D0GD241JA017 Chip 240 ohms 1/10W T
CD INTERFACE BLOCK [E-4C288]
J30 ERJ8GX0R00V Chip 0 ohms 1/8W T
J31 ERJ8GX0R00V Chip 0 ohms 1/8W T
J32 ERJ8GX0R00V Chip 0 ohms 1/8W T
J33 ERJ8GX0R00V Chip 0 ohms 1/8W T
J34 ERJ8GX0R00V Chip 0 ohms 1/8W T
J35 ERJ8GX0R00V Chip 0 ohms 1/8W T
J36 ERJ8GX0R00V Chip 0 ohms 1/8W T
J37 ERJ8GX0R00V Chip 0 ohms 1/8W T
5. Connectors
MAIN BLOCK [E-4C290]
CN601 YEAE012475A Connector T
CN602 K1KA22A00001 Connector T
CN700 K1FA116B0028 Connector T
DISPLAY BLOCK [E-4C276]
CN901 YEAE4CCN074 Connector T
CD INTERFACE BLOCK [E-4C288]
CN1 YEAE4CCN075 Connector T
CN2 YEAE4CCN057A Connector T
6. Electric Parts
SWITCHES
SW901 K0H1BA000445 Tack Swich T
SW902 K0H1BA000445 Tack Swich T
SW903 K0H1BA000445 Tack Swich T
SW904 K0H1BA000445 Tack Swich T
SW905 K0H1BA000445 Tack Swich T
SW906 K0H1BA000445 Tack Swich T
SW907 K0H1BA000445 Tack Swich T
SW908 K0H1BA000445 Tack Swich T
SW909 K0H1BA000445 Tack Swich T
SW910 K0H1BA000445 Tack Swich T
SW911 K0H1BA000445 Tack Swich T
SW912 K0H1BA000445 Tack Swich T
SW913 K0H1BA000445 Tack Swich T
SW914 K0H1BA000445 Tack Swich T
SW915 K0H1BA000445 Tack Swich T
SW919 K0H1BA000445 Tack Swich T
SW920 K0H1BA000445 Tack Swich T
SW921 K0H1BA000445 Tack Swich T
SW924 K0H1BA000445 Tack Swich T
COILS
L2 G0C221JA0044 Axil Coil T
L50 G0C150JA0044 Axil Coil T
L52 G0C8R2K00006 Axil Coil T
L61 G1CR56JA0036 Coil T
L801 G1C100J00001 Coil T
L700 YETQ024C065V Choke Coil T
L901 G1C101J00002 Coil T
CRYSTAL
XL601 YEXL4C0450XT Crystal T
Ref.
No. Part No. Part Name & Description Remarks
LCD
LCD901 L5ADCJB00003 LCD T
7. Accessories
PRINT
YFM284C541CA Operating Instructions T
YFM284C542CA Installation Instructions T
INSTALLATION PARTS
FX0214C384ZA Escape Case T
ZZCORD-1333U Power Connector T
ZZBISC1101U-J Screw Kit T
8. Mechanical Parts
MISCELLANEOUS
ANT1 YAA104C700ZA ANT Jack T(2C)
1YFA034C053CA Upper Cover T(4C)
2XTB26+5FFN Screw T(4C)
3YGFD044C002 CD Deck T(3C)
4XTW2+5FFN Screw T(3C)
5XTB3+8FFZ Screw T(3C)
6YEJT034C019N Screw(CUP TIGHT 3X12) T(3C)
7YJS064C002FN Screw T(2C)
8YFF014C055CA Heat Sink T(3C)
9YFA084C064CA Rear Plate T(2C)
11 YFX054C074CA Spring (HOOK) T(2C)
12 YEFX9991682B Release Hook T(2C)
13 YFC024C659YA ESC Holder(CD) T(2C)
14 YFX054C071CA Spring (PUSH BUTTON) T(2B)
15 XTN2+8GFZ Screw T(2B)
16 YFC024C658YA Escucheon Rear Cover T(1B)
17 YFX014C088ZA Back Light Assy T(1B)
18 YFV024C104ZA Sheet T(2B)
19 YFS014C065YA Rubber Gum T(2A)
20 FX0214C350XA LCD Bracket T(2A)
21 YFX054C072CA Spring (OPEN) T(1B)
22 YFE134C419ZA Button (RELEASE) T(1B)
23 YFE134C484ZD Button(PRESET) T(1B)
24 YFE134C486YA Button(EJ/DISP) T(1B)
25 YFE134C488YA Button(DM/REP) T(1B)
26 YFE134C490ZA Button(VOL) T(1B)
27 YFE134C485YA Button(BAND/SRC) T(2A)
28 YFC034C046CA ESC Printing T(2A)
29 YEFS02302 Dust Felt T(2B)
32 YFC054C079YA Trim Plate T(1A)
33 YFA054C045ZA Bottom Cover T(1C)
34 APCB288A0-TY CD Interface PCB Assy T(3B)/R
TL
35 AADK288C0-TY Deck Assy T(3C)/R
TL
36 AAPB290E0-TY MAIN PCB ASSY T(2B)/R
TL
37 APCB276F0-TY Display PCB Assy T(2B)/R
TL
38 ESCC1013H-TY ESC Unit Assy T(2A)/R
TL
39 YFE134C489ZA Button(SEL) T(2A)
40 YFX014C083ZA Panel Light(CD) T(1A)
41 YFE134C491YA Button (Push) T(2B)
15
CQ-C1013H

13 EXPLODED VIEW (Unit)
16
CQ-C1013H

Ref.
No. Part No. Part Name & Description Remarks
13032 01 36 FRAME (M2) N(E-4)
23032 01 37 TOP COVER (M2) N(A-4)
33032 01 15 DAMPER F N(E-3)
43032 01 16 DAMPER R N(D-4)
11 3032 05 508 CHASSIS RIVET ASS’Y(M2) N(B-2)
12 3032 05 504 CHASSIS PLTAE RIVET
ASS’Y(M) N(C-4)
13 3032 05 301 CLAMPER ASS’Y N(B-3)
14 3032 05 307 SPINDLE MOTOR (M) ASS’Y T(D-1)
15 3032 05 56 CLAMPER ARM M N(B-4)
16 3032 05 03 CHANGE GEAR SPRING N(D-4)
17 3032 05 05 CHANGE GEAR 2 N(D-4)
18 3032 05 06 FEED GEAR N(D-3)
19 3032 05 51 FEED RACK M N(B-1)
20 3032 05 53 CHANGE LOCK LEVER M N(D-3)
21 3032 05 57 FEED SW HOLDER (M) N(C-1)
22 3032 05 54 PU SHAFT HOLDER (M) N(B-1);
N(B-2)
23 3032 05 13 CLAMPER SUB SPRING N(B-3)
24 3032 05 58 FD SUB HOLDER M N(B-1)
25 3032 05 65 TOP PLATE (M2) N(B-2)
26 3032 05 19 SELECT LOCK ARM N(A-1)
27 3032 05 21 SLIDE HOOK N(C-4)
28 3032 05 55 PU SHAFT M N(B-1)
29 3032 05 59 CLAMPER ARM SPRING M N(B-4)
30 3032 05 26 SELECT LOCK ARM SPRING N(A-1)
31 3032 05 62 SUSPENSION SPRING MS N(B-3);
N(C-1);
N(C-4);
N(D-2)
32 3032 05 64 SELECT ARM R (M2) N(A-2)
33 3032 05 30 LINK PLATE N(A-2)
34 3032 05 36 LINK PLATE SPRING S N(A-2)
35 3032 05 23 CUSHION F N(A-1)
36 3032 05 24 CUSHION R N(B-4)
37 3032 05 63 FEED SPR PLATE M N(C-2)
38 3032 05 61 TRIGGER ARM M N(C-4)
43 3032 08 03 SELECT PLATE L N(A-1)
44 3032 08 04 SELECT PLATE R N(A-2)
45 3032 08 05 SELECT PIECE L N(A-1)
46 3032 08 06 SELECT PIECE R N(A-2)
61 6904 16 06 PICK UP RD-DAP005-TN T(B-1)
62 6418 04 07 DET SW ESE 22MH55 N(C-1)
72 3032 10 02 MODE SW T(A-1)
73 3032 10 51 LD WIRE MN N(B-3);
N(C-1)
Ref.
No. Part No. Part Name & Description Remarks
74 3032 10 40 SW WIRE MN N(A-1)
75 3032 10 39 SP WIRE MN N(D-2)
77 3032 10 13 WIRE CLAMPER M N(C-2);
N(C-3);
N(D-4);
N(E-3)
78 3032 10 28 WIRE TUBE SPM N(D-2)
79 3032 10 29 WIRE TUBE MSW N(A-1)
81 3032 11 301 ROLLER SHAFT ASS’Y N(E-2)
82 3032 11 501 LOADING GEAR PLATE RIVET
ASS’Y N(D-2)
83 3032 11 302 LOADING PLATE ASS’Y N(C-4)
84 3032 11 504 LOCK ARM RIVET ASS’Y (S) N(E-1)
85 3032 11 305 LOADING / FEED MOTOR ASS’Y
(MB) T(B-3)
86 3032 11 01 LOADING GEAR 1 N(D-4)
87 3032 11 02 LOADING GEAR 2 N(D-3)
88 3032 11 03 LOADING GEAR 3 N(D-3)
89 3032 11 04 LOADING GEAR 4 N(D-2)
90 3032 11 05 LOADING GEAR 5 N(D-2)
91 3032 11 06 LOADING GEAR 6 N(D-2)
92 3032 11 07 LOADING GEAR 7 N(D-3)
93 3032 11 11 ROLLER GUIDE N(D-1);
N(E-3)
94 3032 11 14 ROLLER GUIDE SPRING N(D-1);
N(E-1)
95 3032 11 16 DISC STOPPER ARM N(C-1)
96 3032 11 17 DISC STOP ARM SPRING N(D-2)
97 3032 11 18 LD GEAR BRACKET N(D-2)
98 3032 11 25 L SLIDE PLATE N(D-4)
99 3032 11 31 LOADING PLATE SPRING N(C-4)
100 3032 11 37 LDG ROLLER (N) T(D-1)
101 3032 11 43 COLLAR SCREW N(E-1)
111 9P04 20 031 TAPPING SCREW 2X3 N(A-3);
N(B-3);
N(B-4);
N(D-2);
N(E-4)
112 9P04 20 041 TAPPING SCREW 2X4 N(B-1);
N(B-2)
113 9B03 20 041 TAPPING BIND SCREW 2X4 N(D-2)
114 9C01 17 183 CAMERA SCREW 1.7X1.8 N(B-2)
115 9C01 20 203 CAMERA SCREW 2X2 N(C-3)
116 9C45 17 503 CAMERA TAPPING SCREW P3
M1.7X5 N(C-1)
121 9W01 30 170 PW 3.5X8X0.3 N(D-4)
122 9W05 13 060 HLW 1.85X5X0.13 N(D-1)
123 9W07 10 070 LUMILAR WASHER 3.1X6X0.1 N(D-1)
124 9E01 00 152 E RING S 1.5 N(D-4)
125 9W01 13 020 PW 2.1X4X0.13 N(D-3)
14 CD PLAYER MECHANICAL PARTS LIST
17
CQ-C1013H

15 EXPLODED VIEW (CD Deck)
18
CQ-C1013H

16.1. Main Block-1
16 WIRING DIAGRAM
[E-4C290][TOP VIEW]
CQ-C1103U/W/D/H/NE/NW
CQ-C1113NE/NW
CQ-C1123NE/NW MAIN PCB
19
CQ-C1013H

16.2. Main Block-2
[E-4C290][BOTTOM VIEW]
CQ-C1103U/W/NE/NW/D/H
CQ-C1113NE/NW
CQ-C1123NE/NW MAIN PCB
20
CQ-C1013H
