FOMA®P705iμ/PROSOLID μ
ISSUE DATE:
NAME:
PHONE NUMBER:
MAIL ADDRESS:
INSTRUCTION MANUAL
Easy Search/Contents/Precautions
Before Using the Handset
Voice/Videophone Calls
Phonebook
Sound/Screen/Light Settings
Security Settings
Camera
i-mode/i-motion/i-Channel
Mail
i-αppli
Osaifu-Keitai/ToruCa
Full Browser/PC Movie
Data Display/Edit/Management
Music&Video Channel/Music Playback
Other Convenient Functions
Character Entry
Network Services
PC Connection
Overseas Use
Appendix/External Devices
Troubleshooting
Index/Quick Manual
‘08.1

DoCoMo W-CDMA system
Thank you for selecting the “FOMA P705iµ/PROSOLID µ”.
Before or during use of the FOMA P705iµ/PROSOLID µ, make sure that you
read this manual and the separate manuals for other optional devices
thoroughly so that you can use the FOMA P705iµ/PROSOLID µ correctly.
If you feel any inconvenience in reading the manual, contact the DoCoMo
Information Center listed on the back page of this manual.
The FOMA P705iµ/PROSOLID µ is designed to be your close partner. Treat
it carefully at all times to ensure long-term performance.
●Because the FOMA phones use radio waves, they cannot be used in
places where radio waves do not reach, such as inside tunnels,
underground, or in buildings; or the outside where radio waves are weak
or out of the FOMA service area. They may not be used in the high-rise
buildings even when the antennas are unobstructed. You may also
experience interruption of calls even when using without moving while the
radio waves are strong enough for the three antennas to appear on the
display.
●Use the FOMA phone carefully to avoid disturbing other people when in
public, or in crowded or quiet places.
●Since the FOMA phones use radio waves as the medium of
telecommunication, calls may be tapped by the third party. However, the
W-CDMA system automatically supports tapping prevention, so your
conversation will be incomprehensible to the third party.
●The FOMA phones change your voice into digital signals and send them to
the other party. In places where the radio waves are weak, the digital
signals may not be converted correctly, and in such a case, the voice may
sound different from the actual original voice.
●The user hereby agrees that the user shall be solely responsible for the
result of the use of SSL. Neither DoCoMo nor the certifiers as listed herein
make any representation and warranty as for the security in the use of
SSL. In the event that the user shall sustain damage or loss due to the use
of SSL, neither DoCoMo nor the certifiers shall be responsible for any
such damage or loss.
Certifiers: VeriSign Japan K.K., Cybertrust, Inc., GlobalSign K.K.,
RSA Security Inc., and SECOM Trust Systems Co., Ltd.
●This FOMA phone supports FOMA Plus-Area and FOMA High-Speed
Area.
●The FOMA terminal can be used only via the FOMA network provided by
DoCoMo and in DoCoMo’s roaming area.
●It is recommended that you make separate notes of the information (such
as Phonebook entries, schedule events, text memos, record messages,
voice memos, movie memos) stored in the FOMA phone and keep them in
a safe place. Note that we cannot be held responsible for the unlikely
event of loss of the stored contents due to a malfunction, repair, change of
your model, or other mishandling of the FOMA phone.
●You are advised to save your important data files to the microSD memory
card. If you have a personal computer, you can transfer and save the
information such as Phonebook entries, mail messages, schedule events,
and others to the personal computer by using DoCoMo keitai datalink.
For Using This Manual
This FOMA phone supports Kisekae Tool (page 107). If you use
Kisekae Tool to change the design of the Menu display, some
menu configurations change according to the usage frequency
depending on the type of the menu. Further, some menu
numbers that are assigned to the menu items do not apply.
In that case, you cannot operate as described in this manual, so
you are advised to switch to the basic structure menu
(page 108), or reset menu settings (page 108).
You can download the latest information about this manual
from the following DoCoMo web site:
・User’s Manual (PDF file) Download
(
http://www.nttdocomo.co.jp/english/support/manual/index.html )
※The URL and the content of the web site might be modified
without notice.
Before using your FOMA phone

1
Easy Search/Contents/Precautions
Easy Search/ Contents/Precautions
In this manual, illustrations and symbols are used in the explanations
so that you can easily understand how to use the FOMA phone
correctly.
≥ The operating procedures and displays in this manual are described with the default
settings of the “SILVER” handset. However, the following settings are changed.
・ “Menu icon setting”: TGB-menu03
・ “Color theme setting”: Yellow
・ “Display setting” → “Stand-by display”: OFF
・ “Display setting” → “Clock” → “Position”: Pattern 2
In this manual, the contents are described with “Character size” set to “Standard”.
With PROSOLID μ , the default of “Character size” is “Large” or “Extra large”, so
switch the setting to “Standard” to have the same displays with this manual.
≥Unless otherwise specified, the descriptions of the operating procedures in this
manual start from the Stand-by display.
≥Operations are described in the method of “Scroll Selection” (see page 32).
≥Displays and illustrations described in this manual are for reference. The actual
ones might differ.
≥In this manual, “Osaifu-Keitai compatible i-αppli which supports the IC card
function” is described as “Osaifu-Keitai compatible i-αppli”.
≥Note that “FOMA P705iμ/PROSOLID μ” is referred to as “FOMA phone” in this
manual.
≥In the operating procedures of this manual, key operations are described with
simplified key icons.
≥The functions which use a microSD memory card are described in this manual;
however, you need to obtain a microSD memory card separately to make these
functions available. See page 294 for the microSD memory card.
Unless otherwise specified, this manual essentially describes the
operations and displays of the P705iμ. When you read this manual to
operate PROSOLID μ(P705iCL), keep the following in mind.
■Functions not available on PROSOLID μ
You cannot use the camera function and its related functions.
(Shooting still images/moving images, Bar Code Reader, Text Reader, etc.)
■mark used in this manual
With this mark, the supplemental descriptions are given to text where operations
or displays differ from those of P705iμ.
How to Read/Refer to This Manual
For Users Who Use PROSOLID μ
By the following search methods, you can find pages where your
desired functions and services are described:
How to Refer to This Manual
Search from the index when you know the names of functions or services.
Search from keywords for the functions you frequently use or the functions that
are convenient if you can know any.
Search from the tabs printed on the cover.
See the next page for details.
Search from the contents that categorize functions.
Search from here to use the main functions.
Search from the function list.
Quick Manual gives you a clear, brief description about basic functions. You can take
it when you go out. Further, Quick Manual “For Overseas Use” is attached, so refer
to it when you use the FOMA phone overseas.
From the Index
From Easy Search
From the Tabs
on the Cover
From the Contents 11 P.6
From the Main Functions 11 P.8
From the Function List 11 P.412
From Quick Manual 11 P.478
It is prohibited to copy all or part of this manual without permission.
The instructions contained in this manual may be changed without notice.

2
Easy Search/Contents/Precautions
How to search for “Alarm” is explained here as an example of search method.
Accessories. . . . . . . . . . . . . . . . . . .24
Action list . . . . . . . . . . . . . . . . .73, 288
Add desktop icon . . . . . . . . . . . . . . 114
Add to aphonebook entry . . . . . . . .84
Add to phonebook (Phone). . . . .80, 84
Add to phonebook (UIM) . . . . . .80, 84
Additional service . . . . . . . . . . . . . .393
Additional guidance. . . . . . . . . . . 394
Address link function . . . . . . . . . . .171
Alarm . . . . . . . . . . . . . . . . . . . . . . .346
Alarm setting. . . . . . . . . . . . . . . . . . 354
From the Index
11P.470
Search for a function or a
service name as shown on the
right.
Search for the function you
frequently use or that is
convenient if you can know any
as shown on the right.
Other things you can do
To reduce the battery consumption .............................. <Power Saver Mode> 104
To scan QR codesor bar codes...................................... <Bar Code Reader
> 149
To use the microSD memory card ...........................<microSD Memory Card> 294
To exchange information using infrared rays......... <Infrared DataExchange> 307
To listen to music.................................................................. <MUSIC Player> 329
To use the FOMA phone as an alarm clock .......................................<Alarm> 346
To use the FOMA phone as acalculator .....................................<Calculator> 360
To use the FOMA phone overseas ...........................<International Roaming> 402
To bring software programsup to date............................. <Software Update> 454
To bring security up to date ........................................... <Scanning Function> 460
Youcannot use Bar Code Reader.
Go to page 346
where “Alarm”
is explained.
From Easy Search
11P.4
Search for the function you
want to set in the order of
“Cover” →“First page of
Chapter” →“Description page”
as shown on the right.
Mail
i-αppli
Osaifu-Keitai/ToruCa
Full Browser/PC Movie
Data Display/Edit/Management
Music&Video Channel/Music Playback
Other Convenient Functions
Character Entry
Network Services
PC Connection
Overseas Use
Appendix/External Devices
Troubleshooting
Index/Quick Manual
Multitask . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .‹Multitask› 343
InformingYou of an IncomingCall/Mail Message by Voice
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ‹ReadingAloud› 344
TurningPower On/Off Automatically at a Specified Time
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ‹Auto Power ON/OFF› 346
UsingAlarm. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ‹Alarm› 346
UsingCalendar to Manage Schedule . . . . . . . . . . . ‹Schedule› 349
UsingToDo to Manage Schedule . . . . . . . . . . . . . . . . . . ‹ToDo› 353
From the Tabs on the
Cover
11Cover page

3
Easy Search/Contents/Precautions
346
Other Convenient Functions
You can set Alarm to alert you at the specified time with an alarm tone,
animation and illumination. You can store up to 12 alarms.
1
mStationeryAlarm
Highlight an alarm and press
l()
Do the followingoperations.
2
Press l().
+m-4-4
Alarm
UsingAlarm
<>
Item Operation/Explanation
(Alarm) Youcan set whether to validate or invalidate the alarm.
ON or OFF
(Time) Enter the time for soundingthe alarm.
pYoucannot set the same time as the time set for the stored
alarm.
(Tone) Select a type of alarm toneSelect a folder
Select an alarm tone.
(Volume) Use Boto adjust the volume.
pIf youset “Step”, the alarm tone issilent for about three
seconds, and then the volume stepsup every about three
seconds, from Level 1 through Level 6.
(Prefer manner
mode)
Youcan set the alarm tone which soundsat the specified time
during Manner Mode.
ON or OFF
ON
. . . . Soundsat the same volume as set for “Alarm volume”
on page 99.
OFF . . . Soundsat the volume set for thisfunction.
The icon appearson the desktop.
“”. . . . Displayed when an alarm isset for today (except the setting for past time).
“”. . . . Displayed when an alarm isset for tomorrow or onward only.
pIf youset “Alarm”of the stored schedule event/ToDo item to “OFF”, the iconsare
not displayed.
Function Menu while Alarm isdisplayed
Function menu Operation/Explanation
Edit Go to step 1 of “Using Alarm”on page 346.
Detail Youcan display the stored alarm contents.
Set thisYoucan validate the stored alarm.
YES
pYoucan validate also by pressing Oo().
Set all Youcan validate all the stored alarm.
YES
Release thisYoucan invalidate the stored alarm.
YES
pYoucan invalidate also by pressing Oo().
Release all Youcan invalidate all the stored alarm.
YES
Information
pDuring acall, the alarm tone soundsat the level set for “Volume”(earpiece
volume).
pWhen youset the power to automatically turn on and an alarm to sound, the
default alarm tone soundsif the alarm which isset with the UIM restrictionshas
been selected.
pTurn off the FOMA phone after setting “Auto power ON”to “OFF”when youare
near electronic devicesusing high-precision control or weak signals, or where the
use isprohibited such as in airplanesand hospitals.
When you set an alarm for “Alarm”, “Schedule”, and “ToDo”
Note: The page above is a sample.
Menu number
(See page 34)
Function name
You can find this in
Index.
Operating
procedure
(See page 32)
Reference display
(Characters and settings
are for reference.)
You can
search by
chapter.
Options and their
explanations
Items shown on the
display
(Some items cannot
be executed.)
Operation and
supplementary
explanation for
each item
Cautions or
references for
using each function
Operations related
to the function and
explanations for
supplementary
operations.
Chapter title

4
Easy Search/Contents/Precautions
Easy Search
To retrieve the operation for the desired function with simple words,
refer to the following:
To know convenient functions for making calls
To/Not to notify your phone number to the other party ........<Caller ID Notification> 46
To switch to a videophone call during a voice call ...<Switch to Videophone Call> 53
To change a volume level of the other party’s voice ....................... <Volume> 66
To put a call on hold during a call.................................................... <Holding> 67
To do the following when you cannot answer calls
To put an incoming call on hold before answering ......................... <On Hold> 67
To convey the message that you need to
refrain from talking on the phone .....................<Public Mode (Drive Mode)> 68
....................... <Public Mode (Power Off)> 69
To record voice/video messages.......................... <Record Message Setting> 70
To change melody or illumination
To adjust the ring volume........................................................ <Ring Volume> 67
To change ring tones according to callers......................<Add to Phonebook> 80
To change ring tones........................................................ <Select Ring Tone> 94
To know incoming calls by vibrator .................................................<Vibrator> 96
To silence the keypad sound................................................<Keypad Sound> 97
To activate Manner Mode...................................................... <Manner Mode> 98
To change colors/lighting patterns of Call indicator for incoming calls
.................................................................................................. <Illumination> 109
To change/know display settings
To know the meaning of marks (icons) on the display
..........................................................................................................<Display> 29
To change the menu display .................................................. <Simple Menu> 36
To change the Stand-by display (Wallpaper) ...................... <Display Setting> 101
To display a calendar on the Stand-by display..............................<Calendar> 101
To change the character size ...............................................<Character Size> 115
To make full use of mail
To send Deco-mail ...................................................................... <Deco-mail> 186
To send images ....................................................................... <Attachments> 191
To sort and save mail automatically ..............................................<Auto-sort> 210
To make full use of camera Not available
To change the shooting size...................................................... <Image Size> 145
To save to the microSD memory card .................<Storage Setting (Store In)> 146
To display shot images......................................................... <Picture Viewer> 273

5
Easy Search/Contents/Precautions
※ 1 This is a pay service.
※ 2 This is a pay service which is available on a subscription basis.
To use the FOMA phone with a sense of security
To lock the FOMA phone from away when it gets lost .... <Omakase Lock>※1123
To keep Phonebook entries from prying eyes.........................<Secret Mode> 127
To reject calls without a caller ID ..............................<Call Setting without ID> 129
To reject calls from the phone numbers not
in the Phonebook ............................................................ <Reject Unknown> 130
To separately store Phonebook and other data
files in preparation for their erasure.................... <Data Security Service>※2131
Other things you can do
To reduce the battery consumption .............................. <Power Saver Mode> 104
To scan QR codes or bar codes ...................................... <Bar Code Reader > 149
To use the microSD memory card ...........................<microSD Memory Card> 294
To exchange information using infrared rays......... <Infrared Data Exchange> 307
To listen to music.................................................................. <MUSIC Player> 329
To use the FOMA phone as an alarm clock .......................................<Alarm> 346
To use the FOMA phone as a calculator ..................................... <Calculator> 360
To use the FOMA phone overseas...........................<International Roaming> 402
To bring software programs up to date............................. <Software Update> 454
To bring security up to date ........................................... <Scanning Function> 460
You cannot use Bar Code Reader.
≥The operating procedures for frequently used functions are summarized in Quick
Manual. (See page 478)

6
Easy Search/Contents/Precautions
Contents
How to Read/Refer to This Manual ......1
Easy Search...........................................4
Contents.................................................6
Main Functions of FOMA P705i μ /
PROSOLID μ.............................................. 8
Making Full Use of FOMA P705i μ /
PROSOLID μ !......................................10
Safety Precautions.............................. 12
Notes on Handling .............................. 18
Intellectual Property Rights ............... 21
Accessories and Main Options .......... 24
Before Using the
Handset
25
Phone Parts and Functions, Simple Menu,
Guide, UIM (FOMA Card), Battery,
Charging, Power ON/OFF, Select Language,
Initial Setting, Caller ID Notification, etc.
Voice/Videophone
Calls
49
Making a Call/Videophone Call, Chaku-moji, WORLD
CALL, Hands-free, Receiving a Call/Videophone Call,
Volume, Ring Volume, Public Mode (Drive Mode),
Public Mode (Power Off), Record Message Setting,
Chara-den, etc.
Phonebook
79
Available Phonebooks,
Add to Phonebook (FOMA phone/UIM),
Group Setting, Search Phonebook,
No. of Phonebook, Two-touch Dial, Voice Dial,
Data Security Service, etc.
Sound/Screen/
Light Settings
93
Select Ring Tone, Vibrator, Manner Mode,
Display Setting, Backlight, Color Theme Setting,
Menu Icon Setting, Kisekae Tool, Feel Settings,
Illumination, Desktop Icon, Font, Character Size, etc.
Security Settings
119
Passwords, Releasing PIN Lock, Lock All,
Omakase Lock, Self Mode, Personal Data Lock,
Keypad Dial Lock, Secret Mode, Mail Security,
Call Setting without ID, Reject Unknown, etc.
Camera
133
Before Using Cameras, Still Image Shoot,
Moving Image Shoot, Settings for Shooting Images,
Setting Image Size/Image Quality,
Bar Code Reader, Text Reader
i-mode/i-motion/
i-Channel
155
What is i-mode?, iMenu, My Menu,
Change i-mode Password, Enter URL, Bookmark,
Screen Memo, Download, i-mode Settings,
SSL Certificate, Client Certificate, What is i-motion?,
What is i-Channel?, etc.
Mail
181
i-mode Mail, Deco-mail, Attachments,
Mail Auto-receive, Receive Option, Check New
Message, Inbox, Outbox, Draft, Message R/F,
Emergency Alert “Area Mail”, Chat Mail, SMS, Web
Mail, etc.
i-αppli
229
What is i-αppli?, i-αppli Download,
i-αppli Run, i-αppli Settings,
Starting i-αppli Automatically, i-αppli Stand-by
Display, i-αppli(microSD)
Osaifu-Keitai/
ToruCa
245
What is Osaifu-Keitai?, What is iC Transfer Service?,
Osaifu-Keitai Compatible i-αppli, What is ToruCa?,
Obtain ToruCa Files, ToruCa File List/Detailed
ToruCa File Display, ToruCa Settings, IC Card Lock

7
Easy Search/Contents/Precautions
Full Browser/PC
Movie
255
Full Browser, Full Browser Settings,
What is PC Movie?, Downloading PC Movies,
PC Movie Player
Data Display/Edit/
Management
269
Data Box, Picture Viewer, i-motion Player,
Chara-den, Melody Player,
Kisekae Tool, microSD Memory Card,
Infrared Data Exchange, iC Communication,
PDF Viewer, Document Viewer, etc.
Music&Video
Channel/Music
Playback
319
What is Music&Video Channel?, Setting Programs,
Playing Back/Operating Programs, Playing Back Music,
Saving Music Files, MUSIC Player, Playlist
Other Convenient
Functions
341
Multiaccess, Multitask, Reading Aloud, Alarm,
Schedule, ToDo, Own Number, Voice Memo,
Movie Memo, Voice Recorder, Call Data, Calculator,
Text Memo, UIM Operation, Reset Settings, Initialize,
etc.
Character Entry
365
Character Entry, Mode 1 (5-touch),
Common Phrases, Cut/Copy/Paste, Own Dictionary,
Download Dictionary, Mode 2 (2-touch),
Mode 3 (NIKO-touch), etc.
Network Services
375
Check New Messages, Voice Mail, Call Waiting,
Call Forwarding, Nuisance Call Blocking,
Caller ID Request, Dual Network, Service Numbers,
Remote Control, Multi Number, 2in1, OFFICEED, etc.
PC Connection
395
Available Data Communication, Before Using,
Preparation Flow for Data Communication,
AT Command, CD-ROM, DoCoMo Keitai Datalink
Overseas Use
401
Outline of International Roaming (WORLD WING),
Available Services, Confirmation for Using,
Making a Call from the Country You Stay,
Receiving a Call, Set Roaming Guidance,
Network Services, etc.
Appendix/
External Devices/
Troubleshooting
411
Function List, Options and Related Equipment,
Troubleshooting, Error Messages, Warranty and Maintenance
Services, Software Update, Scanning Function, Specifications,
Number of Savable/Storable/Protectable Items, SAR, Export
Administration Regulations, etc.
Index/Quick
Manual
469
Index, Quick Manual, Quick Manual “For Overseas
Use”

8
Easy Search/Contents/Precautions
FOMA (Freedom Of Mobile multimedia Access) is the name of the
DoCoMo service based on the W-CDMA format, authorized as one of
the world’s standards for third-generation mobile telecommunication
systems (IMT-2000).
Main Functions of FOMA P705iμ/
PROSOLID
μ
Remarkable i-mode!
i-mode is an online service that enables you to get useful information from i-mode
menu sites (programs) or i-mode web pages. This service also enables you to
send or receive mail messages with ease.
◆ i-mode mail/Deco-mail/Decomail-pictograph 11P.182, P.186, P.270
Besides mail text, you can attach up to 2 Mbytes of files or 10 files (JPEG, ToruCa,
PDF, etc.) in total. The FOMA phone supports Deco-mail/Decomail-pictographs,
so you can change the character color, character size, and background color of
mail text, and insert images and moving pictographs.
◆Mega i-αppli 11P.230
By downloading i-αppli programs from sites, you can enjoy playing games or have
stock price information or weather forecasts updated automatically. As the large
capacity mega i-αppli is supported, you can enjoy playing high-resolution 3D
games and full-length role playing games.
◆High-Speed Area Supported 11P.396
FOMA High-Speed Area is supported so that high speed communication is
available with download speed of up to 3.6 Mbps and upload speed of up to 384
kbps.
◆International Roaming 11P.402
You can use your FOMA phone, phone number, and mail address overseas as
they are. (Supported in 3G area)
Voice calls, videophone calls, i-mode, i-mode mail, SMS, and network services are
available.
◆Chaku-uta Full®/Uta-hodai/Music&Video Channel※/Video Clips
11P.176, P.320, P.327, P.329
This FOMA phone supports Chaku-uta Full®that enables you to download a whole
music file and Uta-hodai that enables you to enjoy listening music as much as you
like at a flat rate.
This FOMA phone also supports Music&Video Channel that, just by setting up
beforehand, automatically downloads music programs in the night. You can watch
programs containing moving images on your P705iμ/PROSOLID μ. Further, this
FOMA phone supports up to 10 Mbytes of i-motion movies, so it also supports
Video Clip that enables you to enjoy a whole music clip file.
≥“Chaku-uta Full” is a registered trademark of Sony Music Entertainment Inc.
※This is a pay service which is available on a subscription basis.
◆Osaifu-Keitai/ToruCa 11P.246, P.248
By downloading Osaifu-Keitai compatible i-αppli, you can replenish electronic
money from a site into the IC card in the FOMA phone and check your account for
the balance and usage details. In addition, the “ DCMX ” i-αppli program that
provides the DoCoMo credit service is pre-installed. Further, “ iC transfer service ” is
supported so that you can easily move data from the existing IC card to a new one
when you replace your FOMA phone such as at the time of phone model change.
ToruCa is an electronic card that you can obtain from scanning devices or sites
and can easily exchange using mail or infrared data exchange.
◆Kisekae Tool 11P.107, P.293
By downloading the displays of your favorite characters from an i-mode site, you
can change the Stand-by display or Menu display at a time.
◆Image Stabilizer 11P.146
You can shoot still images with less blur by the camera.
Not available
