INSTRUCTION MANUAL

Preface
Thank you for selecting the "P-05D".
For proper use, read this manual before and when you use the
P-05D.
Notes on Using this Mobile Phone
• This mobile phone is compatible with W-CDMA, GSM/GPRS and
wireless LAN systems.
• Because this mobile phone uses radio waves, you cannot use
it in places where the radio waves do not reach such as inside
tunnels, basements and buildings, where the radio waves are
weak even outdoors, or out of FOMA service area. You might
not be able to operate this mobile phone even when you are
in a place with a fine view such as on upper floors of a high-
rise building or apartment. Note that you may experience
interruption of calls even when the four-bar antenna mark is
displayed indicating a strong radio wave and you are not
moving.
• Since this mobile phone uses radio waves as the medium of
telecommunication, calls may be tapped by a third party.
However, the W-CDMA and GSM/GPRS systems automatically
support tapping prevention, so your conversation will be
incomprehensible to the third party, because it is recognized
as mere noise.
• The mobile phones change your voice into digital signals and
send them to the other party. In places where the radio waves
are weak, the digital signals may not be converted correctly,
and in such a case, the voice may sound different from the
actual one.
• This mobile phone supports FOMA Plus-Area and FOMA High-
Speed Area.
• You are advised that you make separate notes of information
stored in this mobile phone and keep them in a safe place. Note
that we cannot be held responsible for the unlikely event of loss
of the stored content due to a malfunction, repair, change of
your model, or other mishandling of this mobile phone.
• You are advised to save your important data on the microSD
card.
1

• As with PC applications, some applications you have installed
in this mobile phone may pose problems: unstable operations
of your mobile phone, unauthorized distribution and use of
your location and personal information stored in the mobile
phone. Therefore, you need to thoroughly check the source
and behaviors of intended applications before use.
SIM Unlock
This mobile phone supports SIM unlocking. You can use
another operator's SIM card once you unlock the SIM.
• Contact a docomo Shop for SIM unlocking.
• You will be charged a SIM unlocking fee separately.
• When you use another operator's SIM card, available services
and functions are limited. Note that we provide no warranty of
operations with other operator's SIM cards.
• For details of SIM unlocking, refer to DOCOMO website.
2

Basic Package/Samples
QP-05D (with warranty) QQuick Start Guide
(in Japanese)
QAC Adapter Cable P01 (with warranty)
<AC adapter>
Basic Package
<microUSB cable>
Sample
Qdocomo mini UIM card Eject Tool
(with manual)
QOriginal Jacket (Two pieces provided)
(with manual)
QmicroSD card Reader/Writer
Cable (with manual)
• For other optional items, Z P.242
3

Descriptions of Operating Procedures
The operating procedures of the P-05D are described in the
following manuals.
■ "Quick Start Guide" (in Japanese only)
(supplied with this mobile phone)
Describes operating procedures of basic functions.
■ [Instruction Manual] (in Japanese only)
(installed in your mobile phone)
Describes detailed information of functions and operating
procedures.
Home screen W [App List] W [Instruction Manual]
• Before using Instruction Manual for the first time, install the
application from Android Market.
■ "Instruction Manual" (PDF)
Describes detailed information of functions and operating
procedures.
Download from DOCOMO website:
http://www.nttdocomo.co.jp/english/support/trouble/manual/
download/index.html
* Note that the URL and published contents may be modified
without notice.
Information
• It is prohibited to copy all or part of this manual without
permission.
• The information contained in this manual may be changed
without notice.
• Operating procedures when ["Fit Home"] is set as the home
application are explained in this manual. If you change the
home application, some operating steps may differ from those
described in this manual.
• Screenshots and illustrations shown in this manual are for
reference. The actual ones may differ.
• Keys are simplified for explaining operating procedures in this
manual.
4

Handling Precautions for this Mobile
Phone
• This mobile phone is not compatible with i-mode site
(program) and i-αppli.
• This mobile phone is designed to perform communication
automatically for some features such as data synchronization,
check for the latest software version and maintaining a
connection with the server. Communication of a massive
amount of data such as application download and video
watching will cost expensive packet communication fee, so we
strongly recommend subscription to the flat-rate packet
service.
• You cannot use a microSD card by inserting it into the mobile
phone. You can use a microSD card by using the microSD card
reader/writer cable (sample) (Z P.47).
• Public mode (drive mode) is not available for this mobile
phone.
• Operation sounds such as shutter sound of the camera, etc.
are emitted from this mobile phone even in Silent mode in
which phone ringtone, touch tones and notification ringtone
are muted.
• To confirm your phone number (My Profile), Z P.116
• To confirm the software version of your mobile phone, Z
P.161
• New features may be added to this mobile phone and
operation method is subject to change due to future operating
system (OS) upgrading. For the latest information on
additional features and change of operation method, see
DOCOMO website.
• OS upgrading may disable applications used in the old OS
version or pose unwanted failure.
• For services provided by Google, Inc., read Google Terms of
Service. For other web services, read the respective terms of
service.
• In the event of loss of your mobile phone, be sure to change
passwords for various service accounts from PC in order to
prevent others from accessing your accounts for Google
services such as Google Talk, Gmail and Android Market,
Facebook, Twitter, and/or mixi.
5

• Providers other than sp-mode, mopera U and business mopera
Internet are not supported.
• sp-mode subscription is required for using tethering.
• When tethering is enabled, sp-mode functions are not
available except Internet access and mail service.
• When an external device is connecting to the Internet by
tethering, applications (browser, games, etc.) may not work
correctly on the device in some situations.
• For details including usage fees, visit
http://www.nttdocomo.co.jp/english/.
6

Contents
Notes on Using this Mobile Phone. . . . . . . . . . . . . . . . . . . 1
SIM Unlock. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Basic Package/Samples. . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Descriptions of Operating Procedures. . . . . . . . . . . . . . . . 4
Handling Precautions for this Mobile Phone. . . . . . . . . . . 5
Precautions (ALWAYS FOLLOW THESE DIRECTIONS). . . 11
Handling Precautions. . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Waterproof/Dust-proof Performance. . . . . . . . . . . . . . . 34
Preliminary Check
42
Part Names and Functions. . . . . . . . . 42
docomo mini UIM card. . . . . . . . . . . 44
Storage Area of This Mobile Phone. . . 47
Charging. . . . . . . . . . . . . . . . . . . . . 49
Power On/Off. . . . . . . . . . . . . . . . . . 53
Basic Operations (How to Use Touch
Panel). . . . . . . . . . . . . . . . . . . . . . . 54
Screen Display/Icons. . . . . . . . . . . . 56
Character Entry. . . . . . . . . . . . . . . . 60
Home Screen. . . . . . . . . . . . . . . . . . 74
Application Screen. . . . . . . . . . . . . . 77
docomo Palette UI
85
Switching Home Application. . . . . . . 85
Home Screen. . . . . . . . . . . . . . . . . . 86
Application Screen. . . . . . . . . . . . . . 90
Home Application Settings. . . . . . . . 92
Initial Setting
93
Initial Setting. . . . . . . . . . . . . . . . . . 93
Changing Screen Display to English
. . . . . . . . . . . . . . . . . . . . . . . . . . . 95
Google Account. . . . . . . . . . . . . . . . 96
Setting Access Point. . . . . . . . . . . . . 97
Email Setting. . . . . . . . . . . . . . . . . 100
Wi-Fi. . . . . . . . . . . . . . . . . . . . . . . 102
Online Service Accounts. . . . . . . . . 105
Phone/Network
Services
106
Phone. . . . . . . . . . . . . . . . . . . . . . 106
Call Log. . . . . . . . . . . . . . . . . . . . . 112
Phonebook. . . . . . . . . . . . . . . . . . . 113
PhoneBookCopy. . . . . . . . . . . . . . . 118
Available Network Services. . . . . . . 120
7

Various Settings
129
Setting Menu. . . . . . . . . . . . . . . . . 129
Wireless & Networks. . . . . . . . . . . . 130
Call Settings. . . . . . . . . . . . . . . . . . 134
docomo Service. . . . . . . . . . . . . . . 137
Sound. . . . . . . . . . . . . . . . . . . . . . 138
Display. . . . . . . . . . . . . . . . . . . . . 140
Location & Security. . . . . . . . . . . . . 141
Applications. . . . . . . . . . . . . . . . . . 150
Accounts & Sync. . . . . . . . . . . . . . . 151
Privacy. . . . . . . . . . . . . . . . . . . . . 153
Storage. . . . . . . . . . . . . . . . . . . . . 156
Language & Keyboard. . . . . . . . . . . 157
Voice Input & Output. . . . . . . . . . . 158
Accessibility. . . . . . . . . . . . . . . . . . 159
Date & Time. . . . . . . . . . . . . . . . . 160
About Phone. . . . . . . . . . . . . . . . . 161
Mail/Internet
163
sp-mode Mail. . . . . . . . . . . . . . . . . 163
Message (SMS). . . . . . . . . . . . . . . 164
Email. . . . . . . . . . . . . . . . . . . . . . 167
Gmail. . . . . . . . . . . . . . . . . . . . . . 170
Early Warning "Area Mail". . . . . . . . 173
Google Talk. . . . . . . . . . . . . . . . . . 175
Web Browser. . . . . . . . . . . . . . . . . 178
File Management
183
filemanager. . . . . . . . . . . . . . . . . . 183
Bluetooth Communication. . . . . . . . 185
DLNA Device Connection. . . . . . . . . 189
VPN (Virtual Private Network) Connection
. . . . . . . . . . . . . . . . . . . . . . . . . . 190
External Device Connection. . . . . . . 192
8

Applications
194
Camera. . . . . . . . . . . . . . . . . . . . . 194
Picture Album. . . . . . . . . . . . . . . . 200
Media Player. . . . . . . . . . . . . . . . . 204
Disney Market. . . . . . . . . . . . . . . . 206
Android Market. . . . . . . . . . . . . . . . 207
Google Maps. . . . . . . . . . . . . . . . . 208
Osaifu-Keitai. . . . . . . . . . . . . . . . . 210
YouTube. . . . . . . . . . . . . . . . . . . . 214
Clock. . . . . . . . . . . . . . . . . . . . . . . 215
Calendar. . . . . . . . . . . . . . . . . . . . 217
Memo. . . . . . . . . . . . . . . . . . . . . . 220
Calculator. . . . . . . . . . . . . . . . . . . 221
ECONAVI. . . . . . . . . . . . . . . . . . . . 222
Barcode Reader. . . . . . . . . . . . . . . 223
Polaris Office. . . . . . . . . . . . . . . . . 226
iD appli. . . . . . . . . . . . . . . . . . . . . 228
Overseas Use
229
Overview of International Roaming
(WORLD WING). . . . . . . . . . . . . . . 229
Available Services. . . . . . . . . . . . . . 230
Confirmation before Use. . . . . . . . . 231
Settings for Overseas Use. . . . . . . . 234
Making/Receiving Calls in the Country You
Stay. . . . . . . . . . . . . . . . . . . . . . . 236
Configuring International Roaming
Settings. . . . . . . . . . . . . . . . . . . . . 239
Confirmation after Returning Home
. . . . . . . . . . . . . . . . . . . . . . . . . . 241
9

Appendix
242
Optional Items and Associated Equipment
. . . . . . . . . . . . . . . . . . . . . . . . . . 242
Troubleshooting (FAQ). . . . . . . . . . 243
Warranty and After-Sales Service. . . 252
Software Update. . . . . . . . . . . . . . 255
Main Specifications. . . . . . . . . . . . . 267
Specific Absorption Rate (SAR) of Mobile
Phones. . . . . . . . . . . . . . . . . . . . . 271
European RF Exposure Information
. . . . . . . . . . . . . . . . . . . . . . . . . . 273
Declaration of Conformity. . . . . . . . 274
FCC Notice. . . . . . . . . . . . . . . . . . . 275
FCC RF Exposure Information. . . . . 276
Important Safety Information. . . . . 278
Export Administration Regulations
. . . . . . . . . . . . . . . . . . . . . . . . . . 280
Intellectual Property Right. . . . . . . . 281
Index. . . . . . . . . . . . . . . . . . . . . . 286
10

Precautions (ALWAYS FOLLOW THESE
DIRECTIONS)
■Before using the mobile phone, read these safety
precautions carefully so that you can use it correctly. After
reading the precautions, keep them in a safe place.
■Be sure to observe these safety precautions to prevent you
or those around you from inflicting injury and to avoid
unnecessary damage to the property.
■The symbols below indicate the levels of danger or damage
that can be caused if the particular precautions are not
observed and equipments are not used properly.
Danger
This symbol indicates that incorrect
handling poses an imminent risk of
causing death or serious injury.
Warning
This symbol indicates that incorrect
handling poses a potential risk of
causing death or serious injury.
Caution
This symbol indicates that incorrect
handling poses a risk of causing an
injury or damage to property.
■The following symbols show specific directions:
Don’t
Denotes actions prohibited to do.
Do not
disassemble
Denotes not to disassemble the units.
Not wet
hands
Denotes not to touch with wet hands.
Avoid
Water
Denotes not to use where the equipment may get wet,
and avoid get it wet.
11

Do
Denotes mandatory instructions (matters that must be
complied with).
Pull the
power plug
out
Denotes to pull the power plug out of an outlet.
■"Precautions" are divided into the following five sections:
General Precautions for this Mobile Phone, Adapters and docomo
mini UIM card. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P.12
Precautions for this Mobile Phone. . . . . . . . . . . . . . . . . . . P.15
Precautions for Adapters. . . . . . . . . . . . . . . . . . . . . . . . . P.19
Precautions for docomo mini UIM card. . . . . . . . . . . . . . . P.21
Notes on Using near Electronic Medical Equipment. . . . . . . P.21
General Precautions for this Mobile Phone,
Adapters and docomo mini UIM card
Danger
Don’t
Do not use, store, or leave the mobile phone or its
accessories in places with a high temperature (such
as near fire, near heating appliances, inside a
kotatsu or near other furniture with heating
elements, in places exposed to direct sunlight, or in
cars heated by the sun).
Fire, burns, or injury may result.
Don’t
Do not place the mobile phone or its accessories
inside cooking appliances such as microwave ovens
or high pressure containers.
Fire, burns, injury or electric shock may result.
Do not
disassemble
Do not attempt to disassemble or remodel the
mobile phone or its accessories.
Fire, burns, injury or electric shock may result.
12

Avoid
Water
Do not allow the mobile phone or its accessories to
get wet either from water, drinking water or pet
urine, etc.
Fire, burns, injury or electric shock may result.
For details about waterproof performance, see the
following:
Z P.34 "Waterproof/Dust-proof Performance"
Do
With your mobile phone, use the adapters specified
by NTT DOCOMO, INC.
Fire, burns, injury or electric shock may result.
Warning
Don’t
Do not throw the mobile phone or accessories, or
subject them to severe force or shocks.
Fire, burns, injury or electric shock may result.
Don’t
Do not allow electrically conductive foreign objects
(such as metal pieces or pencil leads) to come into
contact with connector terminal or earphone/
microphone terminal. Do not allow such objects to
enter into the mobile phone.
Fire, burns, injury or electric shock may result.
Don’t
Do not cover or wrap the mobile phone or its
accessories with a cushion, etc. while it is being
used or recharged.
Fire or burns may result.
Do
Before entering a gas station or other places where
flammable gases are generated, be absolutely sure
to turn off this mobile phone and stop charging if it
is being charged.
Otherwise, the flammable gases may ignite.
Use the Osaifu-Keitai with the mobile phone turned off
when you are near a gas station. (When Osaifu-Keitai
lock is set, release the lock, and then turn off the power.)
13

Do
If odor, overheat, discoloration, deformation, or
malfunction is detected during use, battery charge,
or storage, immediately follow the instructions
below:
• Pull the power plug out of the outlet or cigarette
lighter socket.
• Turn off the power of this mobile phone.
Fire, burns, injury or electric shock may result.
Caution
Don’t
Do not place the mobile phone or accessories on
unstable locations such as wobbly tables or slanted
locations.
They may fall off and cause injury.
Don’t
Do not store in humid or dusty places, or in high
temperature environments.
Fire, burns or electric shock may result.
Do
If the mobile phone and its accessories are used by
a child, a guardian should explain how to operate
them correctly. During use, a guardian should also
check that they are being used as instructed.
Otherwise, injury may result.
Do
Keep out of the reach of small children.
Accidental swallowing or injury may result.
Do
Take special care when you use this mobile
phone for a long time with the adapter connected.
If you play applications (game) and so on for a
prolonged period of time while charging, the
temperature of this mobile phone or adapter may rise.
If you keep direct contact with high-temperature parts,
redness, itching, a rash or low-temperature skin burns
may result depending on the state of your physical
condition or constitution.
14

Precautions for this Mobile Phone
■The type of internal battery for this mobile phone is
described below:
Description Type
Li-ion 00 Lithium-ion battery
Danger
Don’t
Do not throw the mobile phone into fire.
Otherwise, the internal battery may ignite, burst or
overheat and its electrolyte may leak.
Don’t
Do not pierce it with nails, hit it with a hammer, or
step on it.
Otherwise, the internal battery may ignite, burst or
overheat and its electrolyte may leak.
Do
If the internal battery fluid or other material gets
into your eyes, do not rub them. Flush your eyes
with clean water and seek medical attention
immediately.
Otherwise, the loss of eyesight may result.
Warning
Don’t
Do not allow liquids such as water, or foreign
materials such as metal pieces or flammable
materials to get into the docomo mini UIM card.
Fire, burns, injury or electric shock may result.
15

Do
Turn off this mobile phone in places where use is
prohibited such as in airplanes and hospitals.
Otherwise, the electronic devices and electronic medical
equipment in those places may be adversely affected. If
the Auto power ON function is set, deactivate the
setting, then turn off the power.
For use inside medical facilities, make sure that you
comply with their regulations.
Engaging in any prohibited acts such as using the mobile
phone in an airplane is punishable by law.
However, if use of the mobile phones in an airplane is
permitted provided that radio wave transmission is
turned off, you may do so in accordance with
instructions of each airline.
Do
Because this mobile phone uses the earpiece also as
the speaker, if the speaker is set to "ON" and sound
is produced, such as when making a call or when a
ringtone sounds, a loud volume might be produced
directly into your ear. Always separate the mobile
phone from your ear.
Further, when you play games or play back music
etc. with the earphone/microphone etc. connected,
adjust the sound volume to moderate volume.
The excessive sound volume impairs your hearing.
Further, accidents may result due to the hardness of
hearing of surrounding sound.
Do
For those with weak heart conditions, the vibrator
and ring volume must be adjusted carefully.
Otherwise, the functions may adversely affect your
heart.
Do
If you are using an electronic medical device or
other type of device, check with its manufacturer or
vendor regarding the influence of radio waves upon
the device.
The mobile phone may adversely affect the device.
16

Do
Turn off this mobile phone when near electronic
devices using high-precision control or weak
signals.
The mobile phone may cause the electronic devices to
malfunction and have other adverse effects.
* Electronic devices that may be affected:
Hearing aids, implanted cardiac pacemakers, implanted
defibrillators, other electronic medical equipment, fire
alarms, automatic doors and other automatically
controlled devices. If you use an implanted cardiac
pacemaker, implanted defibrillator or any other
electronic medical equipment, consult the manufacturer
or retailer of the device for advice regarding possible
effects from the radio waves.
Do
If the display part or camera lens is broken, be
careful about broken glasses or the exposed interior
of this mobile phone.
The inside of the display and the surface of the camera
lens use an anti-impact resin, and the glass and lens are
constructed so that they do not scatter easily. However,
if you touch the damaged or exposed parts by mistake,
you may injure yourself.
Do
Immediately stop using the mobile phone and keep
it away from fire if the internal battery leaks or
emits an odor.
The leaked battery fluid may ignite, causing fire or burst.
Caution
Don’t
Do not use this mobile phone if it has been
damaged.
Fire, burns, injury or electric shock may result.
Don’t
When using the motion sensor, ensure that you
check around you for safety, securely take hold of
your mobile phone, and do not swing more than
necessitated.
Otherwise, injury or other accidents may result.
17

Don’t
If you accidentally damage the display part and
the substance inside leaks out, keep your face,
hands and skin away from it.
Otherwise, you may impair your eyesight or damage
your skin.
If this substance should get into your eyes or mouth,
immediately rinse them with clean water, and then seek
medical attention.
If it should adhere to your skin or clothing, immediately
wipe it off with alcohol or similar liquid, and then rinse
the affected area with soap and water.
Don’t
Do not dispose of the mobile phone with other
waste.
The internal battery may catch fire or damage the
environment. Take the unneeded mobile phone to a
handling counter such as a docomo Shop or dispose of
it in accordance with local waste disposal regulations.
Do
Before using the mobile phone inside a car, check
with its manufacturer or dealer whether the radio
waves will have any adverse effects.
In some vehicle models, the radio waves may adversely
affect the electronic devices inside the vehicle. Such
cases are rare. However, if this happens, stop using the
mobile phone immediately.
Do
Itching, rash or eczema may be caused depending
on your physical conditions or predisposition. If an
abnormality occurs, stop using the mobile phone
immediately, and then seek medical attention.
For material of each part, Z
P.23 "List of materials used"
Do
View the display in a sufficiently light place keeping
a certain distance from your eyes.
Otherwise, your eyesight may become impaired.
18

Do
If the electrolyte fluid or other material inside the
internal battery has leaked out, do not allow it to
come into contact with the skin on your face, hands
or any other part of your body.
Contact may result in loss of sight or skin problems.
If you get the fluid or other material in your eyes or
mouth, or on skin or clothing, immediately wash the
affected areas with clean water.
If you get it in your eyes or mouth, immediately seek
medical attention after rinsing.
Precautions for Adapters
Danger
Don’t
Do not connect microUSB cables other than the
supplied one to AC adapter.
Fire, burns or electric shock may result.
Warning
Don’t
Do not use the adapter cord if it has been damaged.
Fire, burns or electric shock may result.
Don’t
Do not use the AC adapter cable in humid places
such as a bathroom.
Fire, burns or electric shock may result.
Don’t
The DC adapter is for use only in a negative (-)
grounded vehicle. Do not use it in a positive (+)
grounded vehicle.
Fire, burns or electric shock may result.
Don’t
If a thunderstorm is nearby, do not touch the
adapter.
Otherwise, you may receive an electric shock.
Don’t
Do not place heavy objects on the adapter cord.
Fire, burns or electric shock may result.
19
