Panasonic RC-CF30 User manual

Troubleshooting guide
Specifications
Dear Customer
Thank you for purchasing this product.
For optimum performance and safety, please read these instructions thoroughly before
connecting, operating or adjusting this product.
Keep this manual for future reference.
WARNING:
To reduce the risk of fire, electric shock or product damage,
• Do not expose this unit to rain, moisture, dripping or splashing.
• Do not place objects filled with liquids, such as vases, on this unit.
• Use only the recommended accessories.
• Do not remove covers.
• Do not repair this unit by yourself. Refer servicing to qualified service personnel.
Product identification marking
LocationProduct
BottomMain unit
BottomAC adaptor
–If you see this symbol–
Disposal of old Equipment and Batteries
Only for European Union and countries with recycle systems
The mains plug is the disconnecting device.
Install this unit so that the mains plug can be unplugged from the socket outlet
immediately.
Operating Instructions
Clock Radio
Model No.
RC-CF30GN-K
Panasonic Corporation
Web Site: http://www.panasonic.com En
ADJ
Z
F
CLOC
RQT0A54-L
Factory reset
CAUTION!
To reduce the risk of fire, electric shock or product damage,
• Do not install or place this unit in a bookcase, built-in cabinet or in another
confined space. Ensure this unit is well ventilated.
• Do not obstruct this unit’s ventilation openings with newspapers, tablecloths,
curtains, and similar items.
• Do not place sources of naked flames, such as lighted candles, on this unit.
CAUTION!
This unit is intended for use in moderate climates.
This unit may receive radio interference caused by mobile telephones during use.
If such interference occurs, please increase separation between this unit and the mobile
telephone.
Factory reset
Operating Instructions
Clock Radio
Model No.
RC-CF30
Panasonic Corporation
Web Site: http://www.panasonic.com En
ADJ
Z
F
CLOC
RQT0A54-L
Specifications
Specifications
•iPod nano 7th generation
•iPod touch 5th generation
•iPhone 5
•iPhone 5C
•iPhone 5S
•iPhone 6
•iPhone 6 Plus
Compatibility depends on the software version of your iPod or iPhone.
“Made for iPod” and “Made for iPhone” mean that an electronic accessory has
been designed to connect specifically to iPod, or iPhone, respectively, and has
been certified by the developer to meet Apple performance standards.
Apple is not responsible for the operation of this device or its compliance with
safety and regulatory standards.
iPhone, iPod nano and iPod touch are trademarks of Apple Inc.,
registered in the U.S. and other countries.
Compatible iPod and iPhone
Placement
Set the unit up on an even surface away from direct sunlight, high temperatures,
high humidity, and excessive vibration. These conditions can damage the cabinet
and other components, thereby shortening the unit’s service life.
Place it at least 15 cm away from wall surfaces to avoid distortion and unwanted
acoustical effects.
Do not place heavy items on the unit.
Voltage
Do not use high voltage power sources. This can overload the unit and cause a fire.
Do not use a DC power source. Check the source carefully when setting the unit up
on a ship or other places where DC is used.
AC adaptor protection
Ensure the AC adaptor is connected correctly and not damaged. Poor connection
and lead damage can cause fire or electric shock. Do not pull, bend, or place heavy
items on the lead.
Grasp the plug firmly when unplugging the adaptor. Pulling the AC adaptor can
cause electric shock.
Do not handle the plug with wet hands. This can cause electric shock.
Foreign matter
Do not let metal objects fall inside the unit. This can cause electric shock or
malfunction.
Do not let liquids get into the unit. This can cause electric shock or malfunction. If
this occurs, immediately disconnect the unit from the power supply and contact your
dealer.
Do not spray insecticides onto or into the unit. They contain flammable gases which
can ignite if sprayed into the unit.
Service
Do not attempt to repair this unit by yourself. If sound is interrupted, indicators fail to
light, smoke appears, or any other problem that is not covered in these instructions
occurs, disconnect the AC adaptor and contact your dealer or an authorised
service centre. Electric shock or damage to the unit can occur if the unit is repaired,
disassembled or reconstructed by unqualified persons.
Extend operating life by disconnecting the unit from the power source if it is not to
be used for a long time.
Safety precautions
Please check and identify the supplied accessories.
1 AC adaptor
For others (not supplied)
1 AM loop antenna
Supplied accessories
Troubleshooting guide
The back-up battery (CR2032) saves the clock and alarm settings in the event of a
power interruption.
Bottom view
1 Keep the AC adaptor connected to the household mains socket when
unscrewing the screw on the cover of the battery holder using a screwdriver.
2 Open the cover of the battery holder.
3
Insert a new battery with the (+) side facing up.
4
Close the cover of the battery holder and secure it with the screw.
Replacing the battery
The service life of this battery is approximately 1 month if AC power is down.
When the battery is weak, the battery-weak indicator will blink constantly on the
display.
Note:
•Do not heat or expose to flame.
•Do not leave the battery(ies) in an automobile exposed to direct sunlight for a long
period of time with doors and windows closed.
•Remove the battery if the clock radio is not going to be used for a long period of
time. Store in a cool, dark place.
CAUTION
• Danger of explosion if battery is incorrectly replaced. Replace only with the
type recommended by the manufacturer.
• When disposing of the batteries, please contact your local authorities or dealer
and ask for the correct method of disposal.
Warning
Keep the Button-Type battery out of the reach of children. Never put Button-
Type battery in mouth. If swallowed call your doctor.
Insert with poles aligned.
Do not touch the terminals ( + and - ) with metal objects.
Warning
Risk of fire, explosion and burns. Do not recharge, disassemble, heat above
100 C or incinerate.
Memory backup
Troubleshooting guide
Before requesting service, make the following checks. If you are in doubt about
some of the check points, or if the solutions indicated do not solve the problem,
consult your dealer for instructions.
Clock
Clock cannot be synchronised to iPod or iPhone’s time.
•Make sure the iPod or iPhone is securely connected and turned on.
•Update your iPod or iPhone with the latest software.
Daylight saving time does not work.
•Make sure the clock has been set correctly.
•Press and hold [ ] in clock mode to activate daylight saving time.
Alarm
The iPod, radio or buzzer alarm does not sound at the preset time.
•Check that “ALARM 1” or “ALARM 2” has been correctly activated.
The iPod or radio alarm is activated but there is no sound at the preset time.
•Check the alarm’s volume setting.
iPod or iPhone
The iPod or iPhone cannot be operated with this unit.
•Make sure the iPod or iPhone has been securely connected and turned on.
•Update your iPod or iPhone with the latest software.
There is no sound from the iPod or iPhone.
•Make sure the iPod or iPhone has been securely connected.
•Adjust the volume.
The iPod or iPhone does not charge.
•Check the connections. Turn off and remove the iPod or iPhone from the dock
connector. Reinsert and turn it on again.
Radio
A noise or sound distortion is heard.
•Distance the unit away from any television, personal computer or device easily
influenced by magnetism.
A low hum is heard during AM broadcast.
•Separate the antenna from other cables and cords.
o
Specifications
Safety precautions
Troubleshooting guide
Specifications
Compatible iPod and iPhone
Specifications
AMPLIFIER SECTION
RMS Output Power (Mono)
2.6 W (3 ), 1 KHz, 10% THD
Front channel
TUNER SECTION
FM 10 stations
AM 10 stations
Preset memory
Frequency modulation (FM) 87.50 MHz to 108.00 MHz (50 KHz step)Frequency rangeAntenna terminals 75 (unbalanced)
Amplitude modulation (AM)
Frequency range
522 kHz to 1629 kHz (9 kHz step)
520 kHz to 1630 kHz (10 kHz step)
SPEAKER SECTION
1 way, 1 speaker system
Type Impedance 3Speaker unit(s) 40 mm cone typeFull range
GENERAL
AC 100 to 240 V, 50/60 HzPower supply (AC adaptor) 5 VDC Output
Power consumption (with iPod or iPhone charging) 11 W
Main unit 123 mm x 92 mm x 105 mmDimension (W x H x D)
Mass
Main unit 0.357 Kg (approximate)
AC adaptor 0.095 Kg (approximate)
0 C to + 35 COperating temperature range 20% to 80% RH (no condensation)Operating humidity range
Power consumption in standby mode:
Main unit 0.3 W (approximate)
AC adaptor 0.3 W (approximate)
Note:
1)Specifications are subject to change without notice.
Mass and dimensions are approximate.
2)Total harmonic distortion is measured by the digital spectrum analyser.
oo
1. The product is warranted for 12 months from the date of purchase. Subject to the conditions of this warranty Panasonic or its
Authorised Service Centre will perform necessary service on the product without charge for parts or labour, if in the opinion of
Panasonic, the product is found to be faulty within the warranty period.
2. This warranty only applies to Panasonic products purchased in Australia and sold by Panasonic Australia or its Authorised
Distributors or Dealers and only where the products are used and serviced within Australia or it's territories. Warranty cover only
applies to service carried out by a Panasonic Authorised Service Centre and only if valid proof of purchase is presented when
warranty service is requested.
3. This warranty only applies if the product has been installed and used in accordance with the manufacturer’s recommendations (as
noted in the operating instructions) under normal use and reasonable care (in the opinion of Panasonic). The warranty covers normal
domestic use only and does not cover damage, malfunction or failure resulting from use of incorrect voltages, incorrect installation,
accident, misuse, neglect, build-up of dirt or dust, abuse, maladjustment of customer controls, mains supply problems, thunderstorm
activity, infestation by insects or vermin, tampering or repair by unauthorised persons (including unauthorised alterations),
introduction of sand, humidity or liquids, commercial use such as hotel, office, restaurant, or other business or rental use of the
product, exposure to abnormally corrosive conditions or any foreign object or matter having entered the product.
5. Some products may be supplied with Ethernet connection hardware. The warranty is limited on such products and will not cover
6. To claim warranty service, when required, you should:
7. The warranties hereby conferred do not extend to, and exclude, any costs associated with the installation, de-installation or
re-installation of a product, including costs related to the mounting, de-mounting or remounting of any screen, (and any other
ancillary activities), delivery, handling, freighting, transportation or insurance of the product or any part thereof or replacement of and
do not extend to, and exclude, any damage or loss occurring by reason of, during, associated with, or related to such installation,
de-installation, re-installation or transit.
Panasonic Authorised Service Centres are located in major metropolitan areas and most regional centres of Australia, however,
coverage will vary dependant on product. For advice on exact Authorised Service Centre locations for your product, please telephone
our Customer Care Centre on 132600 or visit our website and use the Service Centre Locator.
In addition to your rights under this warranty, Panasonic products come with consumer guarantees that cannot be excluded under the
Australian Consumer Law. If there is a major failure with the product, you can reject the product and elect to have a refund or to have
the product replaced or if you wish you may elect to keep the goods and be compensated for the drop in value of the goods. You are
also entitled to have the product repaired or replaced if the product fails to be of acceptable quality and the failure does not amount to a
major failure.
If there is a major failure in regard to the product which cannot be remedied then you must notify us within a reasonable period by
contacting the Panasonic Customer Care Centre. If the failure in the product is not a major failure then Panasonic may choose to repair
or replace the product and will do so in a reasonable period of time from receiving notice from you.
If you require assistance regarding warranty conditions or any other enquiries, please visit the
Panasonic Australia
website www.panasonic.com.au or contact by phone on 132 600
If phoning in, please ensure you have your operating instructions available.
(a) Internet and or DLNA connection / setup related problems
(b) Access fees and or charges incurred for internet connection
(c) The use of incompatible software or software not specifically stipulated in the product operations manual;
and
(d) Any indirect or consequential costs associated with the incorrect use or misuse of the hardware, its connection to the internet or
any other device.
4. This warranty does not cover the following items unless the fault or defect existed at the time of purchase:
scsiDelbadroceRroyar-ulB,DVD)e()s(traPtenibaC)a(
(b) Video or Audio Tapes (f) Video / Audio Heads from wear and tear in normal use
(c) SD cards or USB devices (g) Information stored on Hard Disk Drive, USB stick or SD card
(d) User replaceable Batteries (h) DTV reception issues caused by TV Aerial / Cabling / Wall socket(s)
etc
Telephone Panasonic’s Customer Care Centre on 132600 or visit our website referred to below and use the Service Centre
Locator for the name/address of the nearest Authorised Service Centre.
Send or take the product to a Panasonic Authorised Service Centre together with your proof of purchase receipt as a proof of
purchase date. Please note that freight and insurance to and / or from your nearest Authorised Service Centre must be arranged
by you.
Note that home or pick-up/delivery service is available for the following products in the major metropolitan areas of Australia or the
normal operating areas of the nearest Authorised Service Centres:
Plasma/LCD televisions / displays (screen size greater than 103 cm)
THIS WARRANTY CARD AND THE PURCHASE DOCKET (OR SIMILAR PROOF OF PURCHASE)
SHOULD BE RETAINED BY THE CUSTOMER AT ALL TIMES
Panasonic Australia Pty. Limited
ACN 001 592 187 ABN 83 001 592 187
1 Innovation Road, Macquarie Park NSW 2113
PRO-031-F11 Issue: 4.0 01-01-2011
Specifications
Panasonic Warranty
Memory backup
In standby mode, press [ ] and [VOL ], “dEF” will show on LCD.
Factory reset is done.
Limited Warranty (FOR AUSTRALIA ONLY)
1 CR2032 Lithium button-type
backup battery
(Battery is already
installed in the unit.)
Lightning is a trademark of Apple Inc..
GN
Before using the first time
Remove the insulation sheet
．
Inserting the battery
When there is no battery, the
battery weak indicator will be
displayed until a battery is
inserted.
Compatibility depends on the software version. Update your iPhone / iPod to the
latest software before using it with this unit.
Please be aware that Panasonic accepts no responsibility for the loss of data
and / or information.
These symbols are only valid in the European Union
and countries with recycle systems.
If you wish to discard this product, please contact your local
authorities or dealer and ask for the correct method of disposal.

Rear v iew
To household
mains socket FM indoor antenna
AM loop antenna
1 Connect the AM antenna.
Stand the antenna up on its base.
2 Connect the AC adaptor.
•Do not use an AC adaptor from other equipment.
•Do not use any other AC adaptors except the supplied one.
•The unit is in the standby condition when the AC adaptor is connected. The
primary circuit is always “live” as long as the AC adaptor is connected to an
electrical outlet.
1 [SNO O Z E / D IMME R]
To stop the alarm for 9 minutes.
To adjust the display panel’s brightness (High (default), Medium or Low).
2 [O FF ] ALARM O FF
To turn off the alarm.
3 [] ALARM 1, [ ] ALARM 2
To activate either alarm 1 or alarm 2 function.
To display alarm 1 or alarm 2 setting.
4 [] SLE E P
To activate sleep function.
To activate daylight saving time (summer time) in clock mode.
5 [ / –, AD J ] , [ + / AD J ]
To adjust clock, radio and alarm settings.
To skip to previous or next track.
To backward or forward search through a track.
6 [ PRE SE T]
To perform automatic presetting or to view preset channels in radio mode.
7[ CLO CK SE T]
Press and hold to set clock.
8
[ V O L + ] , [ V O L –]
To adjust the volume.
9
[ ]
To start music playback from an iPod or iPhone and to pause during playback.
[ SO U RCE ]
To select clock, “IPOD”, “RADIO FM” or “RADIO AM” mode.
O v erv iew of controls
Making the connections
To clean this unit, w ipe w ith a soft, dry cloth.
•Never use alcohol, paint thinner or benzine to clean this unit.
•Before using chemically treated cloth, read the instructions that came with the
cloth carefully.
Maintenance
/ ll
ZZ
10
ADJ
Z
Z
OFF
CLOCK S E T P R E S E T
1
2
3
4
5
6
7
[ D E CO LE D ]
The deco LED will turn on when iPod or iPhone is docked.
Press & hold [SNOOZ E/DIMMER] to turn off or turn on the deco LED.
The clock is displayed once the main unit is connected to the household mains
socket.
Reset the clock regularly to maintain accuracy (monthly accuracy +/– 60 seconds).
1 Press and hold [CLOCK SET] for 2 seconds.
2 Press [ /– , ADJ ] or [ +/ , ADJ ] to select the day.
3 Press [CLOCK SET] again to confir.
4 Repeat steps 2 and 3 to set the hour and minute.
Example:
To change the clock display
In clock mode, press and hold [ ] and [VOL – ] at the same time for
2 seconds to select between a 12-hour or 24-hour display.
For 12-hour display:
AM : “PM” is not displayed.
PM : “PM” is displayed.
Daylight saving time ( summer time)
In clock mode, press and hold [ ] to activate or cancel daylight saving time
(summer time) function.
“DST” is displayed when the function is activated.
Sy nchronising clock w ith iPod or iPhone time
This function allows you to set the clock’s time to be the same time as your iPod or
iPhone’s time ( see “Compatible iPod or iPhone”).
Auto Sy nc clock w hile an iPod or iPhone is docked onto the main unit.
Note:
•Compatibility depends on the software version of your iPod or iPhone.
1 Pull out the iPod or iPhone
support.
Adjust the support according
to the height of your iPod or
iPhone.
2 Connecting an iPod or
iPhone.
Hold the main unit when
connecting or disconnecting
the iPod or iPhone.
iPod
(not included)
Note:
When docking an iPod touch or iPhone for the first time, a message will be
displayed on your iPod touch or iPhone if the Memory Loader application has not
been installed ( see “Using the Memory Loader application”).
Charging an iPod or iPhone
The iPod or iPhone charges automatically when connected to the main unit.
•See iPod or iPhone display to check its charging status.
•If the iPod or iPhone is not being used for an extended period of time after
charging has completed, disconnect it from the main unit, as the battery will be
depleted naturally. (Once fully charged, additional charging will not occur.)
Play ing an iPod or iPhone
1 Place an iPod or iPhone in the dock and turn it on.
2 Press [SOURCE] to select “IPOD”.
3 Press [ ] once to start music playback from the iPod or iPhone. Press
again to pause playback.
4 Press [ /– , ADJ ] or [+/ , ADJ ] to skip to the previous or next track.
5 Press and hold [ /– , ADJ ] or [+/ ,ADJ ] to backward or forward
search through a track.
Note:
•If the iPod or iPhone automatically shuffles or skip a track;
– Turn off its “Shake” feature (if there is any).
•For iPod or iPhone operation details, refer to iPod or iPhone’s User Guide.
Setting the clock
U sing an iPod or iPhone
Gently pull out
the iPod or iPhone
support
ADJ
Z
Z
OFF
CLOCKS E T PR E S E T
Remove the
adaptor for
using
iPhone 6 Plus
Manual tuning
1 Press [SOURCE] to select “RADIO FM” or “RADIO AM”.
2 Press [ /– , ADJ ] or [+/ , ADJ ] to select the desired frequency.
To tune automatically
Press and hold [ /– , ADJ ] or [+/ , ADJ ] until the frequency starts changing
rapidly. Automatic tuning stops when it finds a station or when [ /– , ADJ ] or
[+/ , ADJ ] is pressed again.
Note:
For better reception, extend and change the direction of the FM or AM antenna.
Memory preset
You may store your favourite channels in 10 FM or 10 AM preset channels.
Preparation
Press [SOURCE] to select “RADIO FM” or “RADIO AM”.
Automatic presetting ( AP)
Press and hold [SOURCE] until “AP” is displayed.
Note:
•Automatic presetting begins from the current frequency.
•Only the first 10 stations detected will be stored.
•“AP” will blink continuously until all 10 channels have been set.
Manual presetting
1 Press [ /– , ADJ ] or [+/ , ADJ ] to select the desired frequency.
2 Press and hold [PRESET] for 2 seconds to display the preset number.
3 Press [ /– , ADJ ] or [+/ , ADJ ] to select a preset number.
4 Press [PRESET] again to confir.
Tuning in to a preset channel
Press [PRESET] to switch between preset channels.
E x cept for Australia and N. Z .
AM allocation setting
This system can also receive AM broadcasts allocated in 10 kHz steps.
1 Press [ SO U RCE ] to select “ RAD IO AM” .
2 Press and hold [ ] .
After a few seconds the display changes to a flashing display of the current
minimum frequency. Release the button when the minimum frequency changes.
•To return to the original step, repeat the above steps.
•After changing the setting, previously preset frequency will be cleared.
This main unit is designed to operate withthe Memory Loader application which can
be downloaded from the App Store (search for MemoryLoader).
If you have not already downloaded the free Memory Loader application, you will
see the following message on your iPod touch or iPhone display:
Application Not Installed
This accessory requires an
application you do not have
installed. Would you like to install it
from the App store?
This message is a reminder for you to download the application in order to enjoy the
enhanced features of this main unit. However, your iPod touch and iPhone will work
properly with this main unit even without the Memory Loader application installed.
Memory loader is only compatible with iPod touch and iPhone running IOS 6.0
or later.
Once the Memory Loader application is installed into your iPod touch or iPhone,
the following functions can be easily accessible and controlled directly through the
application’s platform.
Alarm
•Adjust alarm 1 and alarm 2 settings easily.
•You may select any combination of days for the alarm to sound.
•You can choose your desired snooze settings from a choice of 1 to 30 minutes.
Radio
•Preset 10 FM or 10 AM channels by scrolling through your desired frequencies
by using the selector.
Events
•You can be alerted of dates stored on your iPod touch or iPhone contacts (if the
alarm is set to sound on that day).
Nap
•You can set a short nap timer or countdown on your iPod touch or iPhone.
Daylight saving time ( DST)
•Activate or deactivate the daylight saving time function with one simple step.
For more information, visit: www.memoryloader.com
U sing the Memory Loader application
U sing the radio
You can set two different alarm times. Before setting the alarm, make sure to set the
clock ( see “Setting the clock”).
Setting the alarm
1 Press and hold [ ] or [ ] until the hour display blinks.
2
Within 10 seconds, press [ /– , ADJ ] or [+/ ,ADJ ] to set the hour.
3 Press [ ] or [ ] to confir.
4 Repeat steps 2 and 3 to set the minutes.
5 Press [ /– , ADJ ] or [+/ ,ADJ ] to select the days of the week:
MON-SUN (everyday) MON-FRI (weekdays)
SAT-SUN (weekend)
6 Press [ ] or [ ] to confir.
7 Press [ /– , ADJ ] or [+/ ,ADJ ] to select the desired alarm mode:
“IPOD”, “RADIO” or “BUZ Z ER”.
8 Press [ ] or [ ] to confir.
“IPOD” selection: Continue with steps 9 and 10.
“RADIO” selection: Continue from steps 11 to 16.
Setting iPod alarm
9 Press [ /– , ADJ ] or [+/ , ADJ ] to adjust the volume level.
10 Press [ ] or [ ] to confir the setting.
Note:
•The buzzer will sound if no iPod or iPhone is detected at the set alarm time.
•Music will be played from the iPod or iPhone’s library when the alarm sounds.
Setting radio alarm
11 Press [ /– , ADJ ] or [+/ ,ADJ ] to adjust the volume level.
12 Press [ ] or [ ] to confir.
13 Press [ /– , ADJ ] or [+/ ,ADJ ] to select “FM” or “AM”.
14 Press [ ] or [ ] to confir.
15 Press [ /– , ADJ ] or [+/ , ADJ ] to select the desired preset channel.
16 Press [ ] or [ ] to confir the setting.
Note:
•Alarm will function only when powered by AC power.
•To activate or display the alarm setting, press [ ] or [ ] once.
•Press [ ] or [ ] again to deactivate the alarm function.
Turning off the alarm
Press [ O FF ] to turn off the alarm.
The alarm will sound at the same time on the next day.
Note:
If the alarm is not turned off, it will sound continuously for 59 minutes before turning
off by itself.
Snoozi ng the alarm
Press [ SNO O Z E ] w hen the alarm sounds to stop it for a few minutes.
The alarm will sound again after 9 minutes.
Tip:
For iPod touch and iPhone users, use the Memory Loader application to unlock
custom alarm settings ( see “Using the Memory Loader application”).
This function enables you to turn off the unit automatically after the set time (only in
iPod and radio mode).
1 Press [ ] to activate the timer.
2 Press [ ] again to select your desired time (in minutes).
OFF (default) 30 60 90 120
Note:
Press [ ] once to check the remaining time.
U sing the alarm
U sing the sleep timer
Click!

Click!
