9.1. Main Block
IC600 : C2CBKYY000239
Pin
No. Port Description I/O (V)
1 NC Remote control signal input I 0
2 VOL.LVL
(NC) No Connection - -
3 NC No Connection - -
4 NC No Connection - -
5 NC No Connection - -
6 BYTE - I 0
7 CNVSS - I 0
8 NC No Connection - -
9 NC No Connection - -
10 /RESET System reset H:RESET OFF I 3.2
11 XOUT Main clock output O 2.7
12 VSS Ground I 0
13 XIN Main clock input I 2.0
14 VCC1 Power Supply I 3.3
15 /NMI - I 3.3
16 ACC.DET Power Supply ACC Detection H
FACC ON I 3.4
17 BAT.DET Power Supply +B Detection H:
BATT ON I 3.4
18 RMC IN Remote control signal state input I 0
19 IE. BUS. IN - I 3.4
20 ILRST Abnormal reset flag to Nabis
microcomputer L: Normal O 0
21 ACC.DET.O
UT ACC ON fixation signal to Nabis
microcomputer H: ACC ON O 3.3
22 NC No Connection - -
23 SYS.LATCH Data fixation signal output to system
power supply IC O 3.3
24 SYS.DATA Data signaling output to system
power supply IC O 3.3
25 SYS.CLK Clock pulse output to system power
supply IC O 3.3
26 BEEP BEEP Output O 0
27 IE. BUS.IN IE Bus Input I 3.4
28 IE. BUS.OUT IE Bus Output O 0
29 DVD.TX DVD4.5U start-stop data signaling
output O 0
30 DVD.RX DVD4.5U start-stop data signaling
input O 0
31 SYS.STBY System power supply start control O 3.3
32 SYS.STBY2 System power supply internal
regulator change signal H: External
5V
O 3.3
33 NAVI.RX Data output for Nabis
microcomputer communication O 3.4
34 NAVI.TX Data input for Nabis microcomputer
communication I 3.4
35 NC No Connection - -
36 /DVD.RESET
(NC) No Connection - -
37 WDT.ON Customer engineer control with
built-in RESET IC WDT H: WDT ON O 3.3
38 WDT.CLK Release signal with built-in RESET
IC WDT O 3.3
39 /ILL.DET Vehicle ILL-SW detection H: ILL-SW I 3.3
40 NC No Connection - -
41 NC No Connection - -
42 NC No Connection - -
43 LED.CNT2
(NC) No Connection - -
44 LED.CNT1 Insertion entrance LED control
signal output 1 H:LED ON O 3.3
45 EVOL2 Speech output attenuator control 2 O 0
Pin
No. Port Description I/O (V)
46 EVOL1 Speech output attenuator control 1 O 0
47 ATTP0 (NC) No Connection - -
48 NAVI MUTE External monitor speech output
control H:MUTE ON O 0
49 STBY (NC) No Connection - -
50 DAC.MUTE Nabis voice guide MUTE control
H:MUTE ON O 3.2
51 S.MUTE.CA
NSEL (NC) No Connection - -
52 NMUTE MUTE to power amplifier H: MUTE
ON O 3.3
53 /AUDIO.RST Reset signal of RESET IC H:
RESET OFF O 3.3
54 AUDIO.NMI Soft NM I-signal to RESET IC H:
ACC ON O 3.3
55 ACC.ON AC C power supply ON fixation
signal H: When set operates O 3.3
56 ADPG Set distinction since 1S/2S H: since
2S I 0
57 TEST Test mode signal detection H: TEST
signal OFF I 3.3
58 PKB Parking brake signal detection H:
Brake ON I 3.3
59 TMC.RST Reset output port for external RDS
TMC equipment L: RESET O 0
60 CVCC2 Power-supply voltage I 3.3
61 NAVI DISP NAVI display notification output
signal O 3.3
62 VSS Ground I 0
63 NC No Connection - -
64 NC No Connection - -
65 NC No Connection - -
66 NC No Connection - -
67 NC No Connection - -
68 NC No Connection - -
69 NC Input for ACC voltage detection I 1.5
70 THM Input for ambient temperature
detection with thermistor I 1.4
71 VD.DOWN Chroma IC: For 12C-BUS
transmission timing detection I 3.3
72 /DVD.MUTE DVD MUTE trigger input I 3.4
73 OPEN.KEY Lid OPEN state detection H: OPEN I 0
74 NC No Connection - -
75 NC No Connection - -
76 SPD CNT - - -
77 MAX (NC) No Connection - -
78 NC No Connection - -
79 NC No Connection - -
80 NC No Connection - -
81 ACONT2
(NC) No Connection - -
82 ACONT1
(NC) No Connection - -
83 RGB.MUTE
(NC) No Connection - -
84 NC No Connection - -
85 VCONT2
(NC) No Connection - -
86 VCONT1
(NC) No Connection - -
87 NC No Connection - -
88 NC No Connection - -
89 NC No Connection - -
90 NC No Connection - -
91 CHROMA.C
K (NC) No Connection - -
9 TERMINALS DESCRIPTION
5
CN-D105H
