Panasonic CQ-VW120W User manual

Installation Instructions
CAMERA IN
SIDE BRAKE
ACC
BATTERY 15A
Power Connector/
전원 커넥터
Radio Antenna Connector (RADIO ANT IN)/
무선 안테나 커넥터
(RADIO ANT IN)
Pre-Out Connector (front)/
프리아웃 커넥터 (프런트)
Pre-Out Connector (rear)/
프리아웃 커넥터 (리어)
Camera Input Terminal (CAMERA IN)/
카메라 입력 단자
(CAMERA IN)
Reverse Lead/리버스 리드선
(Violet/white stripe)
(자색/백색 줄무늬)
Navi Mute Lead/
내비 뮤트 리드선
(Orange)
(오렌지색)
External Remote Control Lead/
외부 리모컨 리드선
(Brown/black stripe)(갈색/흑색 줄)
Side Brake (Parking Brake) Connection Lead
사이드 브레이크 (주차 브레이크) 접속 리드선
(Bright green)(밝은 녹색)
External Amplifier Control Power Lead/
외부 앰프 컨트롤 전원 리드선
(Blue/white stripe)(청색/백색 줄무늬)
Power Lead/전원 리드선
(Red)(적색)
(Yellow)(황색)
Battery Lead/배터리 리드선
Ground Lead/접지 리드선
(Black)(검정)
(R)(우)
(Red)(적색)
(L)(좌)
(White)(백색)
(Yellow) (황색)
RGB Connector/
RGB 커넥터
Motor Antenna Relay Control Lead/
모터 안테나 중계 컨트롤 리드선
(Blue)(청색)
Electrical Connections / 전기 접속
CQ-VW120W
*Fuse (15 A) Refer fuse replacement to your nearest authorized
Panasonic Service Center. Do not try fuse replacement by yourself.
*퓨즈(15 A)
퓨즈 교환은 가까운 파나소닉 서비스센터에 의뢰해
주십시오. 절대로 고객 자신이 퓨즈를 교환하지 마십시오.
Front Right + (Gray)
Front Right – (Gray/black stripe)
우측 전면 + (회색)
우측 전면 – (회색/검정 줄무늬)
Front Left + (White)
Front Left – (White/black stripe)
좌측 전면 + (백색)
좌측 전면 – (백색/검정 줄무늬)
Rear Right + (Violet)
Rear Right – (Violet/black stripe)
우측 후부 + (자색)
우측 후부 – (자색/검정 줄무늬)
Rear Left + (Green)
Rear Left – (Green/black stripe)
좌측 후부 + (녹색)
좌측 후부 – (녹색/검정 줄무늬)
Model: CQ-VW120W
TEXT

1
2CQ-VW120W
English
Safety Information
CAUTION:
• PLEASE FOLLOW THE LAWS AND REGULATIONS
OF YOUR STATE, PROVINCE OR COUNTRY FOR
INSTALLATION OF THE UNIT.
• TO REDUCE THE RISK OF FIRE OR ELECTRIC
SHOCK OR PRODUCT DAMAGE, DO NOT EXPOSE
THIS APPLIANCE TO RAIN, SPLASHING, DRIP-
PING OR MOISTURE.

2
3
CQ-VW120W
English
Contents
Safety Information................................................2
Installation ............................................................4
Electrical Connections ........................................8

3
4CQ-VW120W
English
Installation
Preparation Dashboard Installation
¡Before installation, check the radio operation with
antenna and speakers.
¡Disconnect the cable from the negative (–) battery ter-
minal (see caution below).
¡The unit should be installed in a horizontal position
with the front end up at a convenient angle, but not
more than 30°.
Installation Opening
The unit can be installed in any dashboard having an
opening as shown below. The dashboard should be 4.5
mm – 6 mm thick in order to be able to support the unit.
Installation Precautions
This product should be installed by a professional
installer, if possible.
In case of difficulty, please consult your nearest author-
ized Panasonic Service Centre.
1. This system is to be used only in a 12 V DC battery
system (car) with negative ground.
2. Follow the electrical connections carefully (a page 8-
12). Failure to do so may result in damage to the unit.
3. Connect the power lead after all other connections are
made.
4. Be sure to connect the battery lead (yellow) to the pos-
itive terminal (+) of the battery or fuse block (BAT) ter-
minal.
5. Insulate all exposed wires to prevent short circuiting.
6. Secure all loose wires after installing the unit.
7. Please carefully read the operating and installation
instructions of the respective equipment before con-
necting it to this unit.
0 – 30°
182 mm
111.6 mm
Caution
¡Do not disconnect the battery terminals of a car with
trip or navigational computer since all user settings
stored in memory will be lost. Instead take extra
care with installing the unit to prevent shorts.
Caution
¡Please follow the laws and regulations of your
province or country for installation of the unit.
¡When bending the mounting tab of the mounting
collar with a screwdriver, be careful not to injure
your hands and fingers.
¡We strongly recommend you to wear gloves for
installation work to protect yourself from injuries.

4
5
CQ-VW120W
English
<YFX994C134ZA>
Lock Cancel Plate
e2
❏Transportation Bracket Removal
Be sure to remove the transportation brackets before
use (installation). Use round head screws (5 mmøx 8
mm) for installation. (apage 7)
Be careful not to lose these screws.
Round Head Screw (5 mmøx 8 mm)
Transportation Bracket
❏Installation Hardware
(For Installation)
Note:
¡The number in parenthesis underneath each accessory
part name is the part number for maintenance and
service.
¡Accessories and their parts numbers are subject to
modification without prior notice due to improvements.
¡Mounting Collar wis mounted on the main unit at
shipment.
¡Use the supplied screws for installation exclusively. In
case of losing any of them, please order the specific
screw.
Qty.DiagramItemNo.
Trim Plate
<YFC054C091ZA>
q1
Mounting Collar
<YFX214C437ZA>
w1
<ZZBISVD6505>
Round Head Screw
(5 mmø x 8 mm)
t2
Flat-Head Screw
(5 mmø x 8 mm)
y6
<YEJV014C002N>
Mounting Bolt (5 mmø)
r1
❏Before Installation
Caution
¡Do not press the panel forcefully.
¡Do not scratch the panel with fingernails or any hard
objects.
¡Do not bump the front panel.
aFailure to observe the above may damage or
break the glass on the surface of the touch panel.
❏Installation Hardware
(For Wiring)
Qty.DiagramItemNo.
<YAJ024C130CA>
Power Connector
u1
Conversion Cable for AV IN
<YEAERA33000K>
i1

5
6CQ-VW120W
English
Installation (continued)
❏Mounting Procedures (A) (When using Mounting Collar w)
Mounting and removing the Main Unit
Note:
¡The car model, installation conditions and combination
of the units used may impose some restrictions on
opening and closing the monitor as well as on the
angle and position to which the monitor can be adjust-
ed.
IMPORTANT
When this unit is installed in dashboard, ensure that there
is sufficient air flow around the unit to prevent damage
from overheating. Do not block any ventilation holes on
the unit.
q
w
e
r
t
Insert the Mounting Collar winto the dash-
board, and bend the mounting tabs out with
a screwdriver.
Establish the rear connection of the unit.
After fixing Power Connector u, fix the rear
of the unit to the car body by either method
(a) or (b).
Insert the unit into Mounting Collar w.
Secure the clamp plate of Mounting Collar w
to the hook.
Insert Trim Plate q.
After installation reconnect the negative (–)
battery terminal.
Snapping point
q
w
e
t
(a) Using the Rear Support Strap (option) (b) Using the Rubber Cushion (option)
Fire wall of car
3 mmø
Tapping Screw
(5 mmø x 16 mm)
(option, XTT5+16AFN)
Rear Support Strap
(option, YEFG044C002)
rMounting Bolt
(5 mmø)
To the unit
To the unit
rMounting Bolt
(5 mmø)
Rear Support
Bracket
(Provided on
the Car)
Rubber Bushing
(option)
Hex. Nut (5 mmø)
(option, YEJN99023)
Method for Fixing the Rear of the Unit
r

6
7
CQ-VW120W
English
❏Mounting Procedures (B)
(When not using Mounting Collar w)
Use the brackets supplied with your car when mounting
this unit. The bracket shape and mounting method vary
with car manufacturers, car types and manufacturing
year. Please consult your nearest dealer or installer.
❏Removing Procedures
qRemove the trim plate q.
wLock release.
qInsert the lock cancel plate euntil you hear a
click.
wPull the unit out.
ePull the unit out with both hands.
q
w
Note:
¡Use pliers to bend the fingers
on the bracket vertically.
Select mounting screws according to the hole
positions and hole shape of the bracket.
tRound Head Screw
(5 mmø x 8 mm)
Note:
¡Reuse the two round head screws removed
from the transportation brackets. (apage 5)
yFlat-Head Screw
(5 mmø x 8 mm)

7
8CQ-VW120W
English
CAMERA IN
Electrical Connections
Caution
¡This unit is designed for use in a car having a 12 V negative ground battery system.
¡Be sure to insulate any exposed wires from the car chassis. Bundle all cables and keep cable terminals free from
any metal parts.
¡Note that if your car has a driving computer or a navigation computer, disconnecting the cable from the battery
may clear the memory.
¡Run the cords avoiding the spots where the temperature can be extremely high.
Radio Antenna Connector
(RADIO ANT IN)
Pre-Out Connector (front)
To an external amplifier.
Pre-Out Connector (rear)
To an external amplifier.
Camera Input Terminal (CAMERA IN)
Connect a rear view camera. (apage 11)
(Orange)
(Yellow)
Navi Mute Lead
Connect to the Navi Mute Lead of the Panasonic car
navigation system. (available in future)
Fuse (15 A) Refer fuse replacement to your nearest
authorized Panasonic Service Centre. Do not try fuse
replacement by yourself.
CQ-VW120W (Rear)
(R)(Red) (L)(White)
RGB Connector
To the Panasonic Car Navigation
System (available in future).

8
9
CQ-VW120W
English
SIDE BRAKE
ACC
BATTERY 15A
Note:
¡To prevent from damage to the unit, be sure to follow the wiring diagrams below.
¡Be sure to fully plug in the connectors. Secure them with clamps and tapes.
¡All other installation methods require the use of dedicated metal fittings. Consult with a qualified servicing engineer or
your dealer if other methods are required.
: This book refers to connections to the Panasonic car navigation system that will come onto the market in the
future. Descriptions regarding the car navigation system are boxed with a dotted line.
u Power Connector
Motor Antenna Relay Control Lead (Blue)
(To motor antenna) (Max. 100 mA)
This lead is not intended for use with a switch actuated power
antenna.
External Remote Control Lead (Brown/black stripe)
External Amplifier Control Power Lead (Blue/white stripe)
To an external amplifier.
Side Brake (Parking Brake) Connection Lead (Bright green)
Be sure to wire the side brake (parking brake) for safety and pre-
venting accidents. (apage 10)
Reverse Lead (Violet/white stripe)
When connecting the rear view camera, use the reverse
lead. (apage 11)
Battery Lead (Yellow)
To the car battery, continuous +12 V DC.
Power Lead (Red)
To ACC power, +12 V DC.
Front Right + (Gray)
Front Right – (Gray/black stripe)
Front Left + (White)
Front Left – (White/black stripe)
Rear Right + (Violet)
Rear Right – (Violet/black stripe)
Rear Left + (Green)
Rear Left – (Green/black stripe)
Speaker connections
• Do not connect more than one speaker to one set of
speaker leads (except for connecting to a tweeter).
Use of speakers which do not match the speci-
fications can cause burning, smoking or dam-
age of the speakers.
• Do not use a 3-wire type speaker system having a
common earth lead.
Ground Lead (Black)
To a clean, bare metallic part of the car chassis

9
10 CQ-VW120W
English
Electrical Connections (continued)
—
+
SIDE BRAKE
The side brake (parking brake) switch position varies with car model.
For details on the exact location of the side brake (parking brake) switch
in your car, contact your dealer.
qAttach a Clip Connector to the end of the side brake
(parking brake) connection lead.
wThe Clip Connector is connected to the power
source side lead of the side brake (parking brake)
lever.
Connecting the Side Brake (Parking Brake) Connection Lead
Hand brake Foot brake
Side Brake (Parking Brake) Connection
Lead (Bright green)
When the side brake (parking brake) lever is
engaged, the unit is grounded by the chassis.
Side brake (parking brake) switch
Car chassis
Battery
Brake light
Clip Connector
(From car accessories stores)
Side Brake (Parking Brake) Connection Lead
(Bright green)
Comes up to this point.
Power source side lead
Caution
¡For safety, be sure to ask your nearest professional installer to do this connection.

10
11
CQ-VW120W
English
CAMERA IN
P
N
D
2
L
R
P a
n
a
s
o
n
i
c
Connecting the Reverse Lead
If using an optional rear view camera, the reverse lead must
be connected.
Connect the reverse lead (violet/white stripe) to the positive (+)
lead of the reverse lamp (the lamp with a clear lens that lights
when the transmission gear is shifted into the reverse position).
Note:
¡Connect the reverse lead after cutting the terminal at the end.
¡Use a Reverse Extension Cord (option) if needed.
Connection with Rear View Camera
Rear View Camera
(CY-RC50KW) (option)
(Video)
(Yellow)
RCA Cord (option)
Rear View Camera
Control Unit (option)
CQ-VW120W (Rear)
uPower Connector
Reverse lamp
Clip connector
(From car accessories stores) Battery
Car chassis
Transmission gear
Reverse Lead
(Violet/white stripe)
Camera Input
Camera Input Terminal (CAMERA IN) (Yellow)
Check the reverse lamp.
Take it out of the back
of the tail lamp mount.
Note:
¡Refer to the operating instructions for the connected devices, in addition.

11
12 CQ-VW120W
English
Electrical Connections (continued)
INTELLIGENT SYSTEM
BS G-CODE
POWER
Example:
Connection with VCR or Camcorder (AV IN)
CQ-VW120W
(Front)
(R)
(Red)
(L)
(White)
(Video)
(Yellow)
VCR
Camcorder
(R) (Red) (L) (White)
(Video) (Yellow) RCA Cord (option)
Video Output
Audio Left
Audio Right
Note:
¡Refer to the operating instructions for the connected devices, in addition.
¡Please observe what shapes the connectors of the connecting devices are and where each of them is connected to in
order to establish a proper connection.
Connection with USB Device or iPod
Note:
¡Refer to the operating instructions for the connected devices, in addition.
¡Please observe what shapes the connectors of the connecting devices are and where each of them is connected to in
order to establish a proper connection.
¡For video browsing of the iPod/iPhone, please use the optional Direct Cable for iPod with Video (CA-LDC100X) for
connection with AV1 IN connector of this unit.
Note:
¡Be sure to use the Conversion Cable for AV IN that is supplied with this
product when an external device is connected to the AV IN terminal.
Failure to observe this results in an audio or video output error.
¡Only the pin jack of the supplied Conversion Cable for AV IN or a pin
jack that has the same electrode arrangement can be connected to the
AV IN terminal. (See Fig. 1.)
¡Use of the supplied Conversion Cable for AV IN or an audio pin jack that
has the same electrode arrangement also allows users to enjoy only
music. In this case, the screen background becomes black.
Conversion Cable
for AV IN
Direct Cable for iPod with Video (Cable 1)
(CA-LDC100X, option)
USB connection cable
(supplied with USB device or iPod/iPhone)
AV IN
Audio (L)
<Fig. 1>
Video
Ground
Audio (R)
USB device or iPod/iPhone
CQ-VW120W
(Front)
Dock connector
USB connector
AV IN
USB

12
13
CQ-VW120W
English

26 CQ-VW120W
Memorandum

27
CQ-VW120W

YFM294C155CA PTW1208-0 Printed in China
Installation Instructions
Web Site : http://panasonic.net
