Panasonic DMR-EZ48VP User manual

©2008 Matsushita Electric Industrial Co., Ltd. All
rights reserved. Unauthorized copying and
distribution is a violation of law.
Model No.DMR-EZ48VP
DMR-EZ48VPC
DMR-EZ485VP
Vol. 1
Colour
(K).......................Black Type
DVD Recorder
ORDER NO.CHM0802005CE
B24

15 Parts and Exploded Views
15.1. Exploded Views
15.1.1. Casing Parts & Mechanism Section1
112
DMR-EZ48VP / DMR-EZ48VPC / DMR-EZ485VP

15.1.2. Casing Parts & Mechanism Section 2
113
DMR-EZ48VP / DMR-EZ48VPC / DMR-EZ485VP

15.1.3. VHS Mechanism Section
114
DMR-EZ48VP / DMR-EZ48VPC / DMR-EZ485VP

15.1.4. Packing & Accessories Section
115
DMR-EZ48VP / DMR-EZ48VPC / DMR-EZ485VP

Notes:
*Important safety notice:
Components identified by mark have special
characteristics important for safety.
Furthermore, special parts which have purposes of fire-
retardant (resistors), high-quality sound (capacitors), low-
noise (resistors), etc. are used.
When replacing any of components, be sure to use only
manufactures specified parts shown in the parts list.
*Warning: This product uses a laser diode. Refer to caution
statements.
*Capacity values are in microfarads (µF) unless specified
otherwise, P=Pico-farads (pF), F=Farads (F).
*Resistance values are in ohms, unless specified otherwise,
1K=1,000 (OHM), 1M=1,000k (OHM).
*The marking (RTL) indicates the retention time is limited
for this item. After the discontinuation of this assembly in
production, it will no longer be available.
* (IA), (IB)”, marks in Remarks indicate languages of
instruction manuals. [(IA): English, (IB): Canadian French]
*All parts are supplied by PAVCSG.
Ref.
No.
Part No. Part Name &
Description
Pcs Remarks
QVEP06G41A MAIN P.C.B. 1 (RTL)
C2001 ECJ1VC1H330J 50V 33P 1
C2002 ECJ1VB0J105K 6.3V 1U 1
C2003 ECJ1VF1A105Z 10V 1U 1
C2051 F1J0J106A014 6.3V 10U 1
C2052 F1J0J106A014 6.3V 10U 1
C2053 F2A1C1000021 16V 10U 1
C2054 ECJ1VB1H392K 50V 3900P 1
C2055 ECJ1VF1C104Z 16V 0.1U 1
C2099 F1H1H681A799 50V 0.68U 1
C2501 ECJ1VF1C104Z 16V 0.1U 1
C2502 F2A0J101A825 6.3V 100U 1
C2504 ECJ1VB1E223K 25V 0.022U 1
C2505 ECJ1VB1E223K 25V 0.022U 1
C2506 ECJ1VB1A224K 10V 0.22U 1
C2507 ECJ1VB1H102K 50V 1000P 1
C2508 ECJ1VB1H182K 50V 1800P 1
C2509 F2A1C220B100 16V 22U 1
C2510 F1H1C104A090 16V 0.1U 1
C2511 F1H1C104A090 16V 0.1U 1
C2512 F1H1C104A090 16V 0.1U 1
C2513 ECJ1VF1A105Z 10V 1U 1
C2515 ECJ1VB1H103K 50V 0.01U 1
C2518 ECJ1VB1H103K 50V 0.01U 1
C2519 ECJ1VB1H103K 50V 0.01U 1
C2551 ECJ1VB1C473K 16V 0.047U 1
C2552 ECJ1VB1C683K 16V 0.068U 1
C2561 ECJ1VB1C683K 16V 0.068U 1
C2562 ECJ1VB1C473K 16V 0.047U 1
C2571 F2A1C2210095 16V 220U 1
C3001 ECJ1VC1H151J 50V 150P 1
C3002 F1H1C104A090 16V 0.1U 1
C3003 F1H1C104A090 16V 0.1U 1
C3004 F2A1C100B099 16V 10U 1
C3005 F1H1H220A799 50V 22P 1
C3006 F1H1C104A090 16V 0.1U 1
C3007 ECJ1VB1H103K 50V 0.01U 1
C3008 F2A1H4R7B033 50V 4.7U 1
C3009 ECJ1VB0J105K 6.3V 1U 1
C3010 ECJ1VB0J105K 6.3V 1U 1
Ref.
No.
Part No. Part Name &
Description
Pcs Remarks
C3011 F1H1C104A090 16V 0.1U 1
C3012 F2A0J470A824 6.3V 47U 1
C3013 F2A1C100B099 16V 10U 1
C3014 F1H1C104A090 16V 0.1U 1
C3015 ECJ1VB0J105K 6.3V 1U 1
C3016 F1H1C104A090 16V 0.1U 1
C3017 F1H1C104A090 16V 0.1U 1
C3019 F1H1C104A090 16V 0.1U 1
C3020 F2A1H3R3B032 50V 3.3U 1
C3021 F2A1V100A824 35V 10U 1
C3023 ECJ1VB1H103K 50V 0.01U 1
C3024 ECJ1VC1H331J 50V 330P 1
C3025 ECJ1VB1H103K 50V 0.01U 1
C3028 F2A1H4R7B033 50V 4.7U 1
C3029 F2A1HR47B032 50V 47U 1
C3030 ECJ1VB1E223K 25V 0.022U 1
C3031 ECJ1VB1C333K 16V 0.033U 1
C3032 F2A1H4R7B033 50V 4.7U 1
C3033 F1H1C104A090 16V 0.1U 1
C3034 F2A1H2R2B032 50V 2.2U 1
C3035 F1H1H472A798 50V 4700P 1
C3036 F2A0J470A824 6.3V 47U 1
C3037 F1H1C104A090 16V 0.1U 1
C3038 ECJ1VC1H040C 50V 4P 1
C3039 F2A1H1R0B032 50V 1U 1
C3040 ECJ1VB1H103K 50V 0.01U 1
C3041 ECJ1VB1H103K 50V 0.01U 1
C3044 F1H1C104A090 16V 0.1U 1
C3048 ECJ1VB1H103K 50V 0.01U 1
C3050 F1H1C104A090 16V 0.1U 1
C3053 F1H1C104A090 16V 0.1U 1
C3074 F1H1C104A090 16V 0.1U 1
C3701 F1H1C104A090 16V 0.1U 1
C3703 F1H1C104A090 16V 0.1U 1
C3705 F2A0J102A833 6.3V 1000U 1
C3706 F1H1C104A090 16V 0.1U 1
C3707 F2A1V470A831 35V 47U 1
C3708 F1H1C104A090 16V 0.1U 1
C3709 F2A1V470A831 35V 47U 1
C3710 ECJ1VB0J105K 6.3V 1U 1
C3711 ECJ1VB0J105K 6.3V 1U 1
C3712 ECJ1VF1C104Z 16V 0.1U 1
C3713 ECJ1VB0J105K 6.3V 1U 1
C3714 ECJ1VB1H103K 50V 0.01U 1
C3715 ECJ1VB0J105K 6.3V 1U 1
C3716 ECJ1VB0J105K 6.3V 1U 1
C3717 F2A1H1R0B040 50V 1U 1
C3718 F2A1H1R0B040 50V 1U 1
C3721 F2A1C100B110 16V 10U 1
C3722 ECJ1VB0J105K 6.3V 1U 1
C3724 ECJ1VB0J105K 6.3V 1U 1
C3725 ECJ1VB0J105K 6.3V 1U 1
C3726 ECJ1VB0J105K 6.3V 1U 1
C3727 ECJ1VF1H103Z 50V 0.01U 1
C3728 ECJ1VF1C104Z 16V 0.1U 1
C3729 ECJ1VB0J105K 6.3V 1U 1
C3730 ECJ1VF1C104Z 16V 0.1U 1
C3731 F1H1C104A090 16V 0.1U 1
C3733 F2A0J102A833 6.3V 1000U 1
C3734 F2A0J102A833 6.3V 1000U 1
C3735 ECJ1VF1H103Z 50V 0.01U 1
C3736 F2A0J471A832 6.3V 470U 1
C3737 F2A0J471A832 6.3V 470U 1
C3738 F2A0J102A833 6.3V 1000U 1
C3739 ECJ1VF1C104Z 16V 0.1U 1
C3740 ECJ1VF1H103Z 50V 0.01U 1
C3741 ECJ1VF1C104Z 16V 0.1U 1
C3742 ECJ1VF1C104Z 16V 0.1U 1
C4001 ECQB1H333JF3 50V 0.033U 1
C4004 ECJ1VB1H182K 50V 1800P 1
C4005 F2A0J220A878 6.3V 22U 1
15.2. Replacement Parts List
116
DMR-EZ48VP / DMR-EZ48VPC / DMR-EZ485VP

Ref.
No.
Part No. Part Name &
Description
Pcs Remarks
C4006 F2A1H4R7B033 50V 4.7U 1
C4007 ECJ1VB1H182K 50V 1800P 1
C4008 F2A1H3R3B032 50V 3.3U 1
C4009 F2A0J330A824 6.3V 33U 1
C4011 ECJ1VB1H103K 50V 0.01U 1
C4012 F2A1H4R7B033 50V 4.7U 1
C4013 ECJ1VB1H103K 50V 0.01U 1
C4017 F2A1C100B099 16V 10U 1
C4019 F2A1C100B099 16V 10U 1
C4081 ECJ1VB1E223K 25V 0.022U 1
C4082 ECJ1VB1H471K 50V 470P 1
C4083 F2A0J470A824 6.3V 47U 1
C4084 ECJ1VB1H182K 50V 1800P 1
C4501 ECQB1H473JF3 50V 0.047U 1
C4502 F2A1C100B099 16V 10U 1
C4503 F2A1C100B099 16V 10U 1
C4504 F2A1C100B099 16V 10U 1
C4505 F2A0J330A824 6.3V 33U 1
C4506 F2A1C100B099 16V 10U 1
C4507 F2A0J220A878 6.3V 22U 1
C4508 ECJ1VB1C333K 16V 0.033U 1
C4509 ECJ1VB1H103K 50V 0.01U 1
C4510 ECJ1VB1H103K 50V 0.01U 1
C4511 F1H1C104A090 16V 0.1U 1
C4512 ECJ1VB1A224K 10V 0.22U 1
C4513 F2A0J220A878 6.3V 22U 1
C4514 F2A1C100B099 16V 10U 1
C4515 F2A0J330A824 6.3V 33U 1
C4516 F2A1C100B099 16V 10U 1
C4517 F2A0J220A878 6.3V 22U 1
C4518 ECJ1VB1H103K 50V 0.01U 1
C4519 ECJ1VF1C104Z 16V 0.1U 1
C4520 F2A0J220A878 6.3V 22U 1
C4521 F2A1C100B099 16V 10U 1
C4522 ECQB1H473JF3 50V 0.047U 1
C4523 F2A1C220B100 16V 22U 1
C4524 F1H1C104A090 16V 0.1U 1
C4525 F2A1C101B102 16V 100U 1
C4526 F2A1C100B099 16V 10U 1
C4527 F2A1C100B099 16V 10U 1
C4528 F2A1C100B099 16V 10U 1
C4529 F2A1C100B099 16V 10U 1
C4530 F2A1C100B099 16V 10U 1
C4531 F2A1C100B099 16V 10U 1
C4532 F2A1C100B099 16V 10U 1
C4533 ECJ1VB1C105K 16V 1U 1
C4534 ECQB1H153JF3 50V 0.015U 1
C4535 ECQB1H153JF3 50V 0.015U 1
C4536 ECJ1VB1C105K 16V 1U 1
C4537 ECJ2VC1H560G 50V 56P 1
C4538 ECJ1VB1H103K 50V 0.01U 1
C4539 ECJ1VB1C105K 16V 1U 1
C4540 ECJ1VB1C105K 16V 1U 1
C4801 F1H1C104A090 16V 0.1U 1
C4802 ECQV1H104JL3 50V 0.1U 1
C4803 F2A1C471B112 16V 470U 1
C4805 F1H1C104A090 16V 0.1U 1
C4806 F2A1C100B110 16V 10U 1
C4807 F2A1C100B110 16V 10U 1
C4811 F2A1H1R0B040 50V 1U 1
C4812 F2A1H1R0B040 50V 1U 1
C4813 F2A1H1R0B040 50V 1U 1
C4814 ECJ1VC1H101J 50V 100P 1
C4815 F2A1H1R0B040 50V 1U 1
C4816 F2A1H1R0B040 50V 1U 1
C4817 ECJ1VB1C105K 16V 1U 1
C4818 ECJ1VB1C105K 16V 1U 1
C4819 F2A1H1R0B040 50V 1U 1
C4820 F2A1H1R0B040 50V 1U 1
C4821 F2A1E470B030 25V 47U 1
C4822 F2A1E470B030 25V 47U 1
C4823 ECJ1VC1H102J 50V 1000P 1
C4824 ECJ1VC1H102J 50V 1000P 1
Ref.
No.
Part No. Part Name &
Description
Pcs Remarks
C4825 F2A1H4R7B040 50V 4.7U 1
C4828 F2A1E470B030 25V 47U 1
C4829 ECJ1VC1H102J 50V 1000P 1
C4830 ECJ1VC1H102J 50V 1000P 1
C4831 F2A1H4R7B040 50V 4.7U 1
C4832 F2A1C100B110 16V 10U 1
C4833 F2A1E470B030 25V 47U 1
C4834 F2A1C100B110 16V 10U 1
C4835 F2A1E470B030 25V 47U 1
C4836 F2A0J470A831 6.3V 47U 1
C4837 ECJ1VF1C104Z 16V 0.1U 1
C4838 F2A1E470B030 25V 47U 1
C4840 ECJ1VB0J105K 6.3V 1U 1
C4841 ECJ1VC1H101J 50V 100P 1
C5001 ECJ1VB1H103K 50V 0.01U 1
C5002 ECJ1VB1H103K 50V 0.01U 1
C5003 ECJ1VB1H103K 50V 0.01U 1
C5004 ECJ1VB1H103K 50V 0.01U 1
C5005 F1H1C104A090 16V 0.1U 1
C5006 F2A0J101A825 6.3V 100U 1
C5007 ECJ1VF1C104Z 16V 0.1U 1
C5008 ECJ1VB0J105K 6.3V 1U 1
C6001 ECJ1VC1H180J 50V 18P 1
C6002 ECJ1VC1H180J 50V 18P 1
C6005 F2A1H3R3B032 50V 3.3U 1
C6008 ECJ1VC1H471J 50V 470P 1
C6009 ECJ1VB1H103K 50V 0.01U 1
C6010 ECJ1VC1H120J 50V 12P 1
C6011 ECJ1VC1H120J 50V 12P 1
C6012 ECJ1VF1C104Z 16V 0.1U 1
C6014 ECJ1VB1H102K 50V 1000P 1
C6015 ECJ1VB1C333K 16V 0.033U 1
C6016 ECJ1VB1H102K 50V 1000P 1
C6019 ECJ1VF1C104Z 16V 0.1U 1
C6020 ECJ1VB1H102K 50V 1000P 1
C6100 ECJ1VF1C104Z 16V 0.1U 1
C6101 ECJ1VB1H103K 50V 0.01U 1
C6102 ECJ1VF1A105Z 10V 1U 1
C6103 ECJ1VC1H561J 50V 560P 1
C6104 ECJ1VB1H103K 50V 0.01U 1
C6308 ECJ1VB0J105K 6.3V 1U 1
C7501 ECJ1VB1H103K 50V 0.01U 1
C7502 ECJ1VB1H103K 50V 0.01U 1
C7503 ECJ1VB1H103K 50V 0.01U 1
C7505 F2A0J470A831 6.3V 47U 1
C7508 ECJ1VF1C104Z 16V 0.1U 1
C7509 ECJ1VF1C104Z 16V 0.1U 1
C7510 ECJ1VC1H180J 50V 18P 1
C7511 F1H1H150A799 50V 15P 1
C7512 ECJ1VF1C104Z 16V 0.1U 1
C7513 ECJ1VB1H103K 50V 0.01U 1
C7514 ECJ1VF1C104Z 16V 0.1U 1
C7515 ECJ1VF1A105Z 10V 1U 1
C7520 F1H1A105A028 10V 1U 1
D1501 B3EA00000072 LED 1
D2001 B0AACK000004 DIODE 1
D2002 B0AACK000004 DIODE 1
D2502 MAZ4160NMF DIODE 1
D3001 MAZ4056NHF DIODE 1
D4501 B0AACK000004 DIODE 1
D4502 MAZ4056NHF DIODE 1
D4802 B0AACK000004 DIODE 1
D7502 B0AACK000004 DIODE 1
D7506 B0AACK000004 DIODE 1
DP7501 A2BD00000176 DISPLAY TUBE 1
IC1511 B3NAA0000117 IC 1
IC1512 B3NAA0000117 IC 1
IC2001 C0CBCDC00052 IC 1
IC2501 C1AB00001767 IC 1
IC3001 C1AB00002083 IC 1
117
DMR-EZ48VP / DMR-EZ48VPC / DMR-EZ485VP

Ref.
No.
Part No. Part Name &
Description
Pcs Remarks
IC3702 C1AB00002748 IC 1
IC4501 AN3656NFBPBV IC 1
IC4801 C0CBCDC00037 IC 1
IC4803 B3ZAZ0000016 IC 1
IC6001 C2CBHF000474 IC 1
IC6301 C0CBCDC00052 IC 1
IC7501 MN67789TA IC 1
IC7504 C0EBK0000206 IC 1
J1 VEE0U97-1 WIRE 1
JK3902 K1U717B00005 JACK,AV OUT 1
JK3903 K1U718B00003 JACK,AV IN/OUT 1
K3010 ERJ3GEY0R00V 1/10W 0 1
K4002 ERJ3GEY0R00V 1/10W 0 1
K4506 ERJ3GEY0R00V 1/10W 0 1
L3002 G0C271JA0019 COIL 1
L3003 G0C270JA0019 COIL 27UH 1
L3004 G0C680JA0019 COIL 68UH 1
L3005 G0C270JA0019 COIL 27UH 1
L3006 G1C120JA0036 COIL 12UH 1
L3701 G0C220JA0019 COIL 22UH 1
L3702 G0C220JA0019 COIL 22UH 1
L4061 G0C221KA0065 COIL 220UH 1
L4501 G0C1R2J00004 COIL 1.2UH 1
L4502 G0C391JA0019 COIL 390UH 1
L4503 G0C101JA0019 COIL 100UH 1
L5001 G0C680JA0019 COIL 68UH 1
L6102 G0C1R5JA0019 COIL 1.5UH 1
LB3701 J0JCC0000103 COIL 1
LB3702 J0JCC0000103 COIL 1
LB3703 J0JCC0000103 COIL 1
LB3704 J0JCC0000103 COIL 1
P1531 K1KA02A00375 CONNECTOR(2P) 1
P2501 K1MN07A00019 CONNECTOR(7P) 1
P2571 K1KA08A00355 CONNECTOR(8P) 1
P3001 K1MN09A00022 CONNECTOR(9P) 1
P3901 K1KB15AA0032 CONNECTOR(15P) 1
P3902 K1KB19AA0032 CONNECTOR(19P) 1
P4001 K1KB02A00035 CONNECTOR(2P) 1
P4002 K1MN06A00033 CONNECTOR(6P) 1
P6001 K1KB07AA0032 CONNECTOR(7P) 1
P6002 K1KB19AA0032 CONNECTOR(19P) 1
P6003 K1KB19AA0032 CONNECTOR(19P) 1
PS6001 K1KB12B00047 CONNECTOR(12P) 1
Q1501 PNA2602M01VT TRANSISTOR 1
Q1502 PNA2602M01VT TRANSISTOR 1
Q3001 B1ABDF000026 TRANSISTOR 1
Q3003 B1AAGD000016 TRANSISTOR 1
Q3004 B1ABDF000026 TRANSISTOR 1
Q4001 2SD114900L TRANSISTOR 1
Q4002 B1ABDF000026 TRANSISTOR 1
Q4081 2SD0602ARL TRANSISTOR 1
Q4084 2SB0710A0L TRANSISTOR 1
Q4501 2SB0710A0L TRANSISTOR 1
Q4502 B1AAGD000016 TRANSISTOR 1
Q4801 B1ABDF000026 TRANSISTOR 1
Q4802 B1ABDF000026 TRANSISTOR 1
Q4803 B1ABDF000026 TRANSISTOR 1
Q4804 B1ABDF000026 TRANSISTOR 1
QR4001 B1GDCFJJ0037 TRANSISTOR 1
QR4082 B1GBCFNN0041 TRANSISTOR 1
QR4501 B1GBCFJJ0040 TRANSISTOR 1
QR4502 B1GDCFNN0024 TRANSISTOR 1
QR4503 UNR5216J0L TRANSISTOR 1
QR4504 UNR5216J0L TRANSISTOR 1
Ref.
No.
Part No. Part Name &
Description
Pcs Remarks
QR4801 B1GBCFJJ0040 TRANSISTOR 1
QR4802 B1GDCFJJ0037 TRANSISTOR 1
QR4803 UNR5216J0L TRANSISTOR 1
QR4804 UNR5216J0L TRANSISTOR 1
QR4805 B1GDCFNN0024 TRANSISTOR 1
QR4808 B1GBCFJJ0040 TRANSISTOR 1
QR7504 B1GBCFJJ0040 TRANSISTOR 1
R1501 ERJ3GEYJ273V 1/10W 27K 1
R1502 ERJ3GEYJ273V 1/10W 27K 1
R1503 ERDS2TJ151T 1/4W 150 1
R1511 ERJ3GEYJ273V 1/10W 27K 1
R1512 ERJ3GEYJ273V 1/10W 27K 1
R1513 ERJ6GEYJ121V 1/8W 120 1
R2001 ERJ3GEYJ392V 1/10W 3.9K 1
R2002 ERJ3GEYJ105V 1/10W 1M 1
R2099 ERJ3GEYJ682V 1/10W 6.8K 1
R2501 ERJ6GEYJ1R2V 1/8W 1.2 1
R2502 ERJ6GEYJ1R5V 1/8W 1.5 1
R2503 ERDS2TJ822T 1/4W 8.2K 1
R2514 ERJ3GEYJ221V 1/10W 220 1
R2515 ERJ3GEYJ221V 1/10W 220 1
R2516 ERJ3GEYJ221V 1/10W 220 1
R2520 ERJ3GEYJ183V 1/10W 18K 1
R2521 ERJ3GEYJ102V 1/10W 1K 1
R2551 ERJ3GEYJ103V 1/10W 10K 1
R2552 ERJ3GEYJ103V 1/10W 10K 1
R2561 ERJ3GEYJ102V 1/10W 1K 1
R2562 ERJ3GEYJ473V 1/10W 47K 1
R2563 ERJ3GEYJ102V 1/10W 1K 1
R2564 ERJ3GEYJ101V 1/10W 100 1
R2565 ERJ3GEYJ101V 1/10W 100 1
R3001 ERJ3GEYJ152V 1/10W 1.5K 1
R3002 ERJ3GEYJ622V 1/10W 6.2K 1
R3003 ERDS2TJ471T 1/4W 470 1
R3009 ERJ3GEYJ153V 1/10W 15K 1
R3013 ERJ3GEYJ103V 1/10W 10K 1
R3014 ERJ3GEYJ102V 1/10W 1K 1
R3017 ERJ3GEYJ102V 1/10W 1K 1
R3021 ERJ3GEYJ222V 1/10W 2.2K 1
R3022 ERJ3GEYJ332V 1/10W 3.3K 1
R3023 ERJ3GEYJ152V 1/10W 1.5K 1
R3030 ERJ3GEYJ685V 1/10W 6.8M 1
R3031 ERJ3GEYJ331V 1/10W 330 1
R3032 ERJ3GEYJ392V 1/10W 3.9K 1
R3035 ERJ3GEYJ222V 1/10W 2.2K 1
R3046 ERJ3GEYJ103V 1/10W 10K 1
R3047 ERJ3GEYJ103V 1/10W 10K 1
R3701 ERJ3GEYF750V 1/10W 75 1
R3704 ERJ3GEYJ221V 1/10W 220 1
R3705 ERJ3GEYJ221V 1/10W 220 1
R3707 ERJ3GEYJ563V 1/10W 56K 1
R3709 ERJ3GEYJ103V 1/10W 10K 1
R3711 ERJ3GEYJ103V 1/10W 10K 1
R3720 ERJ3GEYF750V 1/10W 75 1
R3721 ERJ3GEYJ750V 1/10W 75 1
R3722 ERJ3GEYF750V 1/10W 75 1
R3723 ERJ3GEYF750V 1/10W 75 1
R3724 ERJ3GEYF750V 1/10W 75 1
R3728 ERJ3GEYJ471V 1/10W 470 1
R3729 ERJ3GEYJ471V 1/10W 470 1
R3730 ERJ3GEYJ471V 1/10W 470 1
R3731 ERJ3GEYJ750V 1/10W 75 1
R3732 ERJ3GEYJ103V 1/10W 10K 1
R3733 ERJ3GEYJ750V 1/10W 75 1
R3734 ERJ3GEYJ102V 1/10W 1K 1
R3735 ERJ3GEYF750V 1/10W 75 1
R3736 ERJ3GEYF750V 1/10W 75 1
R4001 ERJ3GEYJ102V 1/10W 1K 1
R4003 ERJ3GEYJ153V 1/10W 15K 1
R4004 ERJ3GEYJ271V 1/10W 270 1
R4005 ERJ3GEYJ102V 1/10W 1K 1
R4006 ERJ3GEYJ153V 1/10W 15K 1
118
DMR-EZ48VP / DMR-EZ48VPC / DMR-EZ485VP

Ref.
No.
Part No. Part Name &
Description
Pcs Remarks
R4007 ERJ3GEYJ103V 1/10W 10K 1
R4008 ERJ3GEYJ334V 1/10W 330K 1
R4009 ERJ3GEY0R00V 1/10W 0 1
R4011 ERJ3GEYJ153V 1/10W 15K 1
R4012 ERJ3GEYJ223V 1/10W 22K 1
R4081 ERJ3GEYJ103V 1/10W 10K 1
R4082 ERJ3GEYJ332V 1/10W 3.3K 1
R4086 ERJ3GEYJ222V 1/10W 2.2K 1
R4087 ERJ3GEYJ222V 1/10W 2.2K 1
R4500 ERJ3GEYJ102V 1/10W 1K 1
R4501 ERJ3GEYJ563V 1/10W 56K 1
R4502 ERJ3GEYJ682V 1/10W 6.8K 1
R4503 ERJ3GEYJ102V 1/10W 1K 1
R4504 ERDS2TJ821T 1/4W 820 1
R4505 ERJ3GEYJ682V 1/10W 6.8K 1
R4506 ERJ3GEYJ102V 1/10W 1K 1
R4507 ERJ3GEYJ472V 1/10W 4.7K 1
R4508 ERJ3GEYJ472V 1/10W 4.7K 1
R4509 ERJ3GEYJ473V 1/10W 47K 1
R4510 ERJ3GEYJ473V 1/10W 47K 1
R4513 ERJ3GEYJ472V 1/10W 4.7K 1
R4514 ERJ3GEYJ473V 1/10W 47K 1
R4515 ERJ3GEYJ563V 1/10W 56K 1
R4516 ERJ3GEYJ473V 1/10W 47K 1
R4520 ERJ3GEYJ472V 1/10W 4.7K 1
R4521 ERJ3GEYJ511V 1/10W 510 1
R4522 ERJ3GEYJ511V 1/10W 510 1
R4525 ERJ3GEYJ102V 1/10W 1K 1
R4526 ERJ3GEYJ243V 1/10W 24K 1
R4527 ERJ3GEYJ682V 1/10W 6.8K 1
R4529 ERJ3GEYJ681V 1/10W 680 1
R4534 ERJ3GEYJ124V 1/10W 120K 1
R4538 ERJ3GEYJ393V 1/10W 39K 1
R4539 ERJ3GEYJ102V 1/10W 1K 1
R4540 ERJ3GEYJ102V 1/10W 1K 1
R4801 D0HB821ZA002 1/16W 820 1
R4802 D0HB821ZA002 1/16W 820 1
R4803 D0HB822ZA002 1/16W 8.2K 1
R4804 D0HB822ZA002 1/16W 8.2K 1
R4805 D0HB153ZA002 1/10W 15K 1
R4806 D0HB153ZA002 1/10W 15K 1
R4809 ERJ3GEYJ123V 1/10W 12K 1
R4810 ERJ3GEYJ123V 1/10W 12K 1
R4811 ERJ3GEYJ133V 1/10W 13K 1
R4812 ERJ3GEYJ133V 1/10W 13K 1
R4813 ERJ3GEYJ133V 1/10W 13K 1
R4814 ERJ3GEYJ133V 1/10W 13K 1
R4815 ERJ3GEYJ133V 1/10W 13K 1
R4816 ERJ3GEYJ133V 1/10W 13K 1
R4817 D0HB103ZA002 1/10W 10K 1
R4818 ERJ3GEYJ103V 1/10W 10K 1
R4819 ERJ3GEYJ473V 1/10W 47K 1
R4820 ERJ3GEYJ681V 1/10W 680 1
R4821 ERJ3GEYJ821V 1/10W 820 1
R4822 ERJ3GEYJ821V 1/10W 820 1
R4823 ERJ3GEYJ681V 1/10W 680 1
R4824 D0HB103ZA002 1/10W 10K 1
R4825 D0HB392ZA002 1/16W 3.9K 1
R4826 D0HB392ZA002 1/16W 3.9K 1
R4827 ERJ3GEYJ123V 1/10W 12K 1
R4828 ERJ3GEYJ123V 1/10W 12K 1
R4829 D0HB392ZA002 1/16W 3.9K 1
R4830 ERJ3GEYJ681V 1/10W 680 1
R4831 ERJ3GEYJ681V 1/10W 680 1
R4832 D0HB392ZA002 1/16W 3.9K 1
R4833 ERJ3GEYJ471V 1/10W 470 1
R4834 ERJ3GEYJ133V 1/10W 13K 1
R4835 ERJ3GEY0R00V 1/10W 0 1
R4836 ERJ3GEYJ133V 1/10W 13K 1
R4837 ERJ3GEYJ221V 1/10W 220 1
R4838 ERJ3GEYJ123V 1/10W 12K 1
R4839 ERJ3GEYJ113V 1/10W 11K 1
R4840 ERJ3GEYJ113V 1/10W 11K 1
Ref.
No.
Part No. Part Name &
Description
Pcs Remarks
R4841 ERJ3GEYJ123V 1/10W 12K 1
R4842 ERJ3GEYJ221V 1/10W 220 1
R4843 ERJ3GEYJ681V 1/10W 680 1
R4844 ERJ3GEYJ473V 1/10W 47K 1
R4845 ERJ3GEYJ821V 1/10W 820 1
R4846 ERJ3GEYJ821V 1/10W 820 1
R4847 ERJ3GEYJ681V 1/10W 680 1
R4848 ERJ3GEYJ473V 1/10W 47K 1
R4849 ERJ3GEYJ473V 1/10W 47K 1
R4850 ERJ3GEYJ222V 1/10W 2.2K 1
R4851 ERJ3GEYJ221V 1/10W 220 1
R4852 ERJ3GEYJ221V 1/10W 220 1
R4859 D0HB103ZA002 1/10W 10K 1
R4860 D0HB103ZA002 1/10W 10K 1
R6001 ERJ3GEYJ102V 1/10W 1K 1
R6002 ERJ3GEYJ102V 1/10W 1K 1
R6004 ERJ3GEYJ103V 1/10W 10K 1
R6006 ERJ3GEYJ183V 1/10W 18K 1
R6008 ERJ3GEYJ222V 1/10W 2.2K 1
R6012 ERJ3GEYJ221V 1/10W 220 1
R6013 ERJ3GEYJ221V 1/10W 220 1
R6017 ERJ3GEYJ222V 1/10W 2.2K 1
R6020 ERJ3GEYJ221V 1/10W 220 1
R6022 ERJ3GEYJ221V 1/10W 220 1
R6023 ERJ3GEYJ221V 1/10W 220 1
R6024 ERJ3GEYJ221V 1/10W 220 1
R6026 ERJ3GEYJ103V 1/10W 10K 1
R6027 ERJ3GEYJ103V 1/10W 10K 1
R6028 ERJ3GEYJ103V 1/10W 10K 1
R6029 ERJ3GEYJ221V 1/10W 220 1
R6101 ERJ3GEYJ105V 1/10W 1M 1
R6102 ERJ3GEYJ471V 1/10W 470 1
R6103 ERJ3GEYJ181V 1/10W 180 1
R6201 ERJ3GEYJ473V 1/10W 47K 1
R7501 ERJ3GEYJ101V 1/10W 100 1
R7502 ERJ3GEYJ104V 1/10W 100K 1
R7503 ERJ3GEYJ101V 1/10W 100 1
R7504 ERJ3GEYJ221V 1/10W 220 1
R7505 ERJ3GEYJ101V 1/10W 100 1
R7506 ERJ3GEYJ101V 1/10W 100 1
R7507 ERJ3GEYJ101V 1/10W 100 1
R7508 ERJ3GEYJ101V 1/10W 100 1
R7509 ERJ3GEYJ101V 1/10W 100 1
R7510 ERJ3GEYF823V 1/10W 82K 1
R7511 ERJ3GEYJ101V 1/10W 100 1
R7512 ERJ3GEYJ101V 1/10W 100 1
R7513 ERJ3GEYJ101V 1/10W 100 1
R7514 ERJ3GEYJ101V 1/10W 100 1
R7515 ERJ3GEYJ101V 1/10W 100 1
R7516 ERJ3GEYJ472V 1/10W 4.7K 1
R7517 ERJ3GEYJ274V 1/10W 270K 1
R7518 ERJ3GEYJ822V 1/10W 8.2K 1
R7519 ERJ3GEYJ822V 1/10W 8.2K 1
R7520 ERJ3GEYJ822V 1/10W 8.2K 1
R7521 ERJ3GEYJ473V 1/10W 47K 1
R7522 ERJ3GEYJ103V 1/10W 10K 1
R7523 ERJ3GEYJ221V 1/10W 220 1
R7524 ERJ3GEY0R00V 1/10W 0 1
R7525 ERJ3GEY0R00V 1/10W 0 1
R7526 ERJ3GEYJ223V 1/10W 22K 1
R7528 ERJ3GEYJ101V 1/10W 100 1
R7529 ERJ3GEYJ101V 1/10W 100 1
R7530 ERJ3GEYJ101V 1/10W 100 1
R7534 ERJ3GEYJ101V 1/10W 100 1
R7535 ERJ3GEYJ101V 1/10W 100 1
R7536 ERJ3GEYJ101V 1/10W 100 1
R7538 ERJ3GEYJ101V 1/10W 100 1
R7539 ERJ3GEYJ101V 1/10W 100 1
R7542 ERJ3GEYJ101V 1/10W 100 1
R7547 ERJ3GEYF753V 1/10W 75K 1
R7548 ERJ3GEYJ101V 1/10W 100 1
R7549 ERJ3GEYJ102V 1/10W 1K 1
R7550 ERJ3GEYJ332V 1/10W 3.3K 1
119
DMR-EZ48VP / DMR-EZ48VPC / DMR-EZ485VP

Ref.
No.
Part No. Part Name &
Description
Pcs Remarks
R7551 ERJ3GEYJ182V 1/10W 1.8K 1
R7552 ERJ3GEYJ101V 1/10W 100 1
R7553 ERJ3GEYJ101V 1/10W 100 1
S1531 K0C111A00006 SWITCH,SAFETY TAB 1
S1532 K0ZZ00000598 SWITCH,MODE 1
T4081 G2A472C00003 TRANSFORMER 1
W701 ERJ3GEY0R00V 1/10W 0 1
W702 ERJ3GEY0R00V 1/10W 0 1
W703 ERJ3GEY0R00V 1/10W 0 1
W704 ERJ8GEY0R00V 1/4W 0 1
W705 ERJ8GEY0R00V 1/4W 0 1
W706 ERJ3GEY0R00V 1/10W 0 1
W707 ERJ3GEY0R00V 1/10W 0 1
W708 ERJ8GEY0R00V 1/4W 0 1
W709 ERJ8GEY0R00V 1/4W 0 1
W710 ERJ8GEY0R00V 1/4W 0 1
W711 ERJ8GEY0R00V 1/4W 0 1
W712 ERJ8GEY0R00V 1/4W 0 1
W713 ERJ8GEY0R00V 1/4W 0 1
W714 ERJ8GEY0R00V 1/4W 0 1
W715 ERJ8GEY0R00V 1/4W 0 1
W716 ERJ8GEY0R00V 1/4W 0 1
W717 ERJ6GEY0R00V 1/8W 0 1
W718 ERJ8GEY0R00V 1/4W 0 1
W719 ERJ8GEY0R00V 1/4W 0 1
W720 ERJ8GEY0R00V 1/4W 0 1
W721 ERJ3GEY0R00V 1/10W 0 1
W722 ERJ8GEY0R00V 1/4W 0 1
W723 ERJ8GEY0R00V 1/4W 0 1
W724 ERJ8GEY0R00V 1/4W 0 1
W725 ERJ6GEY0R00V 1/8W 0 1
W726 ERJ8GEY0R00V 1/4W 0 1
W727 ERJ8GEY0R00V 1/4W 0 1
W728 ERJ8GEY0R00V 1/4W 0 1
W729 ERJ8GEY0R00V 1/4W 0 1
W730 ERJ8GEY0R00V 1/4W 0 1
W731 ERJ6GEY0R00V 1/8W 0 1
W732 ERJ6GEY0R00V 1/8W 0 1
W733 ERJ6GEY0R00V 1/8W 0 1
W734 ERJ6GEY0R00V 1/8W 0 1
W735 ERJ3GEY0R00V 1/10W 0 1
W736 ERJ3GEY0R00V 1/10W 0 1
W737 ERJ6GEY0R00V 1/8W 0 1
W738 ERJ3GEY0R00V 1/10W 0 1
W739 ERJ3GEY0R00V 1/10W 0 1
W740 ERJ3GEY0R00V 1/10W 0 1
W741 ERJ6GEY0R00V 1/8W 0 1
W742 ERJ6GEY0R00V 1/8W 0 1
W743 ERJ3GEY0R00V 1/10W 0 1
W744 ERJ6GEY0R00V 1/8W 0 1
W745 ERJ3GEY0R00V 1/10W 0 1
W746 ERJ3GEY0R00V 1/10W 0 1
W747 ERJ3GEY0R00V 1/10W 0 1
W748 ERJ3GEY0R00V 1/10W 0 1
W749 ERJ6GEY0R00V 1/8W 0 1
W750 ERJ3GEY0R00V 1/10W 0 1
W751 ERJ6GEY0R00V 1/8W 0 1
W752 ERJ8GEY0R00V 1/4W 0 1
W753 ERJ3GEY0R00V 1/10W 0 1
W754 ERJ6GEY0R00V 1/8W 0 1
W755 ERJ3GEY0R00V 1/10W 0 1
W756 ERJ3GEY0R00V 1/10W 0 1
W757 ERJ3GEY0R00V 1/10W 0 1
W758 ERJ3GEY0R00V 1/10W 0 1
W759 ERJ3GEY0R00V 1/10W 0 1
W760 ERJ3GEY0R00V 1/10W 0 1
W761 ERJ6GEY0R00V 1/8W 0 1
W762 ERJ3GEY0R00V 1/10W 0 1
W763 ERJ6GEY0R00V 1/8W 0 1
W764 ERJ3GEY0R00V 1/10W 0 1
Ref.
No.
Part No. Part Name &
Description
Pcs Remarks
W765 ERJ3GEY0R00V 1/10W 0 1
W766 ERJ6GEY0R00V 1/8W 0 1
W767 ERJ3GEY0R00V 1/10W 0 1
W768 ERJ6GEY0R00V 1/8W 0 1
W769 ERJ6GEY0R00V 1/8W 0 1
W770 ERJ3GEY0R00V 1/10W 0 1
W771 ERJ6GEY0R00V 1/8W 0 1
W772 ERJ3GEY0R00V 1/10W 0 1
W773 ERJ3GEY0R00V 1/10W 0 1
W774 ERJ3GEY0R00V 1/10W 0 1
W775 ERJ6GEY0R00V 1/8W 0 1
W776 ERJ3GEY0R00V 1/10W 0 1
W777 ERJ6GEY0R00V 1/8W 0 1
W778 ERJ3GEY0R00V 1/10W 0 1
W779 ERJ3GEY0R00V 1/10W 0 1
W780 ERJ3GEY0R00V 1/10W 0 1
W781 ERJ3GEY0R00V 1/10W 0 1
W782 ERJ3GEY0R00V 1/10W 0 1
W783 ERJ3GEY0R00V 1/10W 0 1
W784 ERJ3GEY0R00V 1/10W 0 1
W785 ERJ3GEY0R00V 1/10W 0 1
W786 ERJ3GEY0R00V 1/10W 0 1
W787 ERJ3GEY0R00V 1/10W 0 1
W788 ERJ3GEY0R00V 1/10W 0 1
W789 ERJ3GEY0R00V 1/10W 0 1
X3002 H0D357400067 OSCILLATOR 1
X6001 H0A120500008 CRYSTAL OSCILLATOR 1
X7501 H0D100500016 CRYSTAL OSCILLATOR 1
ZB1501 VMD5470 SPACER 1
ZB1502 VMD5470 SPACER 1
ZB7501 RMN0870 HOLDER 1
ZB7502 RMN0871 HOLDER 1
ZJ3001 K9ZZ00001279 EARTH PLATE 1
QVEP04927A FRONT(L)P.C.B. 1 (RTL)
C3801 ECJ1VF1H103Z 50V 0.01U 1
C3802 ECJ1VF1C104Z 16V 0.1U 1
C7701 ECJ1VF1C104Z 16V 0.1U 1
IC7701 PNA4618M13VT IC 1
JK3802 K1AB107A0008 JACK,S VIDEO IN 1
JK4600 K2HA307A0009 JACK,AV IN 1
LB3301 J0JCC0000103 COIL 1
LB3302 J0JCC0000103 COIL 1
LB3303 J0JCC0000103 COIL 1
LB4301 J0JCC0000103 COIL 1
LB4302 J0JCC0000103 COIL 1
PP4601 K1KA12B00136 CONNECTOR(12P) 1
R3801 ERJ3GEYJ750V 1/10W 75 1
R3802 ERJ3GEYJ750V 1/10W 75 1
R3803 ERJ3GEYJ750V 1/10W 75 1
R3804 ERJ3GEYJ102V 1/10W 1K 1
R7701 ERJ3GEYJ123V 1/10W 12K 1
R7702 ERJ3GEYJ153V 1/10W 15K 1
R7703 ERJ3GEYJ221V 1/10W 220 1
S7701 EVQ11G07K SWITCH,POWER 1
S7702 EVQ11G07K SWITCH,EJECT 1
QVEP07B04A FRONT(R)P.C.B. 1 (RTL)
D27501 B3AAA0000752 DIODE 1
D27503 B3ACA0000273 DIODE 1
D27505 B3ADA0000173 DIODE 1
120
DMR-EZ48VP / DMR-EZ48VPC / DMR-EZ485VP

Ref.
No.
Part No. Part Name &
Description
Pcs Remarks
PP27501 K1KA10B00196 CONNECTOR(10P) 1
QR27501 B1GBCFJJ0040 TRANSISTOR 1
QR27503 B1GBCFJJ0040 TRANSISTOR 1
QR27505 B1GBCFJJ0040 TRANSISTOR 1
R27501 ERJ3GEYJ271V 1/10W 270 1
R27502 ERJ3GEYJ152V 1/10W 1.5K 1
R27503 ERJ3GEYJ391V 1/10W 390 1
R27505 ERJ3GEYJ391V 1/10W 390 1
R27508 ERJ3GEYJ152V 1/10W 1.5K 1
R27509 ERJ3GEYJ152V 1/10W 1.5K 1
R27516 ERJ3GEYJ272V 1/10W 2.7K 1
R27517 ERJ3GEYJ222V 1/10W 2.2K 1
R27532 ERJ3GEYJ222V 1/10W 2.2K 1
S27501 EVQ11G07K SWITCH,OPEN/CLOSE 1
S27502 EVQ11G07K SWITCH,CH DOWN 1
S27503 EVQ11G07K SWITCH,STOP 1
S27504 EVQ11G07K SWITCH,CH UP 1
S27505 EVQ11G07K SWITCH,PLAY 1
S27506 EVQ11G07K SWITCH,REC 1
S27507 EVQ11G07K SWITCH,D2V 1
S27508 EVQ11G07K SWITCH,V2D 1
S27509 EVQ11G07K SWITCH,DRIVE
SELECT
1
S27510 EVQ11G07K SWITCH,RESET 1
QVEP73153A DV/SD/USB P.C.B. 1 (RTL)
C66801 ECJ1VB0J105K 6.3V 1U 1
C66803 ECJ1VB0J105K 6.3V 1U 1
C66804 ECJ1VC1H471J 50V 470P 1
C66805 F1H1C104A090 16V 0.1U 1
C66806 F1H1C104A090 16V 0.1U 1
C66807 F1H1C104A090 16V 0.1U 1
C66808 F1H1C104A090 16V 0.1U 1
C66809 F1J0J106A013 6.3V 10U 1
C66810 F1H1C104A090 16V 0.1U 1
C66811 F1H1C104A090 16V 0.1U 1
C66812 F1H1H150A799 50V 15P 1
C66813 F1H1C104A090 16V 0.1U 1
C66814 ECJ1VC1H270J 50V 27P 1
C66815 F1H1C104A090 16V 0.1U 1
C66816 F1H1C104A090 16V 0.1U 1
C66817 F1H1C104A090 16V 0.1U 1
C66818 F1H1C104A090 16V 0.1U 1
C66819 F1H1C104A090 16V 0.1U 1
C66820 F1H1C104A090 16V 0.1U 1
C66821 F1H1C104A090 16V 0.1U 1
C66823 F1J0J106A014 6.3V 10U 1
C66826 F1H1A225A051 10V 22U 1
C66828 F1H1C104A090 16V 0.1U 1
C66829 F1H1C104A090 16V 0.1U 1
D66801 B0ECKP000002 DIODE 1
IC66801 C0DBGGF00001 IC 1
IC66802 C1CB00002799 IC 1
IC66803 C0DBZHE00024 IC 1
LB66801 ERJ3GEY0R00V 1/10W 0 1
LB66802 J0JGC0000020 COIL 1
P66801 K1KA06AA0231 CONNECTOR(6P) 1
P66802 K1MN07AA0003 CONNECTOR(7P) 1
P66803 K1FY104B0006 CONNECTOR(4P) 1
P66804 K1FY104B0011 USB CONNECTOR 1
P66805 K1NA09E00099 SD CARD CONNECTOR 1
R66801 ERJ3RBD123V 1/16W 12K 1
R66802 ERJ3GEYJ105V 1/10W 1M 1
R66803 ERJ3GEY0R00V 1/10W 0 1
Ref.
No.
Part No. Part Name &
Description
Pcs Remarks
R66804 ERJ3GEYJ104V 1/10W 100K 1
R66805 ERJ3GEYJ103V 1/10W 10K 1
R66806 ERJ3GEYJ330V 1/10W 33 1
R66807 ERJ3GEYJ103V 1/10W 10K 1
R66808 ERJ3GEYJ330V 1/10W 33 1
R66809 ERJ3GEY0R00V 1/10W 0 1
R66810 ERJ3GEY0R00V 1/10W 0 1
R66811 ERJ3GEYJ330V 1/10W 33 1
R66812 ERJ3GEYJ330V 1/10W 33 1
R66813 ERJ3GEYJ330V 1/10W 33 1
R66814 ERJ3GEYJ103V 1/10W 10K 1
R66815 ERJ3GEYJ104V 1/10W 100K 1
R66816 ERJ3GEYJ330V 1/10W 33 1
R66817 ERJ3GEYJ473V 1/10W 47K 1
R66818 ERJ3GEY0R00V 1/10W 0 1
X66801 H0J240500042 CRYSTAL OSCILLATOR 1
QVEP09150A DIGITAL I/F P.C.B. 1 (RTL)(P)
QVEP09150B DIGITAL I/F P.C.B. 1 (RTL)(PC)
C1101 ECQU2A224MLC 0.22U 1
C1104 ECQU2A683MLC 0.068U 1
C1105 F1B2G1020002 1000P 1
C1106 F1B2G1020002 1000P 1
C1107 F2B2E2210011 250V 220U 1
C1108 F1B2G1020002 1000P 1
C1120 F2A1E1010103 25V 0.01U 1
C1121 F1B3A332A008 3300P 1
C1122 ECJ1VB1H102K 50V 1000P 1
C1123 ECJ1VC1H101J 50V 100P 1
C1124 F1H1H222A798 50V 2200P 1
C1200 ECJ1VB1A224K 10V 0.22U 1
C1201 ECJ1VB1C473K 16V 0.047U 1
C1240 F2A1C1520021 16V 1500U 1
C1241 F2A1C1520021 16V 1500U 1
C1242 F2A1C1020095 16V 1000U 1
C1260 F2A1C4710079 16V 470U 1
C1261 F1H1C105A095 16V 1U 1
C1262 F1H1C104A090 16V 0.1U 1
C1263 F1H1C104A090 16V 0.1U 1
C1264 ECJ1VC1H270J 50V 27P 1
C1266 ECJ1VB1H103K 50V 0.01U 1
C1268 F2A1A6810022 10V 680U 1
C1270 F2A1A1010072 10V 100U 1
C1280 F2A1A1010072 10V 100U 1
C1281 F1H1A105A028 10V 1U 1
C1282 F2A1A1010072 10V 100U 1
C1283 ECJ1VB1C333K 16V 0.033U 1
C1290 F1H1A105A028 10V 1U 1
C1291 F2A1A1010072 10V 100U 1
C1292 F2A1A1010072 10V 100U 1
C1300 F2A1C4710079 16V 470U 1
C1301 F1H1C105A095 16V 1U 1
C1302 F1H1C104A090 16V 0.1U 1
C1303 F1H1C104A090 16V 0.1U 1
C1304 ECJ1VC1H270J 50V 27P 1
C1306 ECJ1VB1H103K 50V 0.01U 1
C1308 F2A1A6810022 10V 680U 1
C1310 F2A1A1010072 10V 100U 1
C1340 F1H1A105A028 10V 1U 1
C1341 F2A1A1010072 10V 100U 1
C1342 ECJ1VB1C333K 16V 0.033U 1
C1343 F2A1A1010072 10V 100U 1
C7301 F2A0J220A878 6.3V 22U 1
C7302 F2A1H4R7B033 50V 4.7U 1
C7304 F2A0J220A878 6.3V 22U 1
C7305 F2A1H4R7B033 50V 4.7U 1
C7306 F2A1H4R7B033 50V 4.7U 1
C7308 ECJ1VB1C473K 16V 0.047U 1
C7310 F2A0J470A824 6.3V 47U 1
C7311 ECJ1VB1H103K 50V 0.01U 1
C7312 F1H1C104A090 16V 0.1U 1
121
DMR-EZ48VP / DMR-EZ48VPC / DMR-EZ485VP

Ref.
No.
Part No. Part Name &
Description
Pcs Remarks
C7313 F2A1C100B099 16V 10U 1
C7314 F2A1H2R2B032 50V 2.2U 1
C7316 ECJ1VB0J105K 6.3V 1U 1
C7317 ECJ1VB0J105K 6.3V 1U 1
C7318 ECJ1VB0J105K 6.3V 1U 1
C7319 ECJ1VB0J105K 6.3V 1U 1
C7320 F1H1C104A090 16V 0.1U 1
C7321 ECJ1VB0J105K 6.3V 1U 1
C7322 F2A1H2R2B032 50V 2.2U 1
C7802 ECJ1VB1A105K 10V 1U 1
C7807 ECJ1VB0J105K 6.3V 1U 1
C7823 F2A0J470A824 6.3V 47U 1
C7824 F2A0J470A824 6.3V 47U 1
C7826 F2A0J470A824 6.3V 47U 1
C7827 F2A1H1R0B032 50V 1U 1
C7829 ECJ1VB1H103K 50V 0.01U 1
C7830 F2A0J470A824 6.3V 47U 1
C7831 F1H1C104A090 16V 0.1U 1
C7835 ECJ1VB1H103K 50V 0.01U 1
C7836 ECJ1VB1H103K 50V 0.01U 1
C7838 ECJ1VB1H103K 50V 0.01U 1
C7839 ECJ1VB1H103K 50V 0.01U 1
C7901 F2A1C221B111 16V 220U 1
C7902 ECQB1H392KF3 50V 3900P 1
C7903 F2A1V470A831 35V 47U 1
C7904 F2A1C221B111 16V 220U 1
C7905 F2A1H100B040 50V 10U 1
C7906 F2A1H100B040 50V 10U 1
C31001 F1H1A105A028 10V 1U 1
C31002 F1H1A105A028 10V 1U 1
C31004 ECJ1VB0J105K 6.3V 1U 1
C31005 F2A1A1010072 10V 100U 1
C31006 ECJ1VB1H103K 50V 0.01U 1
C31007 ECJ1VB1H103K 50V 0.01U 1
C37103 ECJ1VC1H101J 50V 100P 1
C37104 ECJ1VC1H101J 50V 100P 1
C37105 ECJ1VC1H101J 50V 100P 1
C37108 ECJ1VB1H103K 50V 0.01U 1
C37109 ECJ1VB1H103K 50V 0.01U 1
C37591 F2A1C220B110 16V 22U 1
D1101 B0EDKT000009 DIODE 1
D1120 B0AADM000003 DIODE 1
D1121 B0BC01600013 DIODE 1
D1122 B0AACK000004 DIODE 1
D1123 B0BC01200019 DIODE 1
D1124 MAZ73000BC DIODE 1
D1240 B0JBSG000047 DIODE 1
D1260 B0JCPE000038 DIODE 1
D1291 B0JCPE000038 DIODE 1
D1300 B0JCPE000038 DIODE 1
D7801 B0BA03000015 DIODE 1
D7901 B0AACK000004 DIODE 1
D7902 B0BA03600021 DIODE 1
D7903 MAZ4120NHF DIODE 1
D7904 B0AADM000003 DIODE 1
D7905 B0AADM000003 DIODE 1
D7906 MAZ4100NMF DIODE 1
D7907 B0HAMP000067 DIODE 1
D31001 B0ECKP000002 DIODE 1
D31002 B0ECKP000002 DIODE 1
DZ1101 J0LV00000001 SERGE ABSORBER 1 (PC)
DZ1101 J0LY00000045 SERGE ABSORBER 1 (P)
F1101 K5D202BK0005 FUSE 1
FL7301 J0B4504AA026 FILTER 1
IC1120 C0DACZH00035 IC 1
IC1200 C0DAEMZ00001 IC 1
IC1260 C0DBAZZ00132 IC 1
IC1280 C0DAEYH00002 IC 1
Ref.
No.
Part No. Part Name &
Description
Pcs Remarks
IC1290 C0DBEKG00003 IC 1
IC1300 C0DBAZZ00132 IC 1
IC1340 C0DAEYH00002 IC 1
IC7301 C1AB00002666 IC 1
IC7801 C0CBCDC00052 IC 1
IC31001 C0DBGHF00001 IC 1
IC31002 C0CBCBD00048 IC 1
IC37591 C0ABBA000168 IC 1
L1101 G0B123E00001 COIL 1
L1102 G0B123E00001 COIL 1
L1240 G0A100H00025 COIL 10UH 1
L1250 G0A100HA0023 COIL 10UH 1
L1260 G0A100HA0023 COIL 10UH 1
L1261 G0A100K00003 COIL 1
L1262 G0A100H00025 COIL 10UH 1
L1300 G0A100HA0023 COIL 10UH 1
L1301 G0A100K00003 COIL 1
L1302 G0A100H00025 COIL 10UH 1
L37103 G0A100HA0023 COIL 10UH 1
L45001 G0C220JA0021 COIL 22UH 1
LB1101 J0JKB0000003 COIL 1
LB1102 J0JKB0000003 COIL 1
LB1103 ERJ6GEY0R00V 1/8W 0 1
LB1104 J0JGC0000020 COIL 1
LB1105 J0JGC0000020 COIL 1
LB1120 ERJ3GEY0R00V 1/10W 0 1
LB1260 J0JHC0000048 FILTER 1
LB1300 J0JHC0000048 FILTER 1
LB7801 J0JCC0000103 COIL 1
LB7802 J0JCC0000103 COIL 1
LB7803 J0JHC0000032 COIL 1
LB7804 J0JCC0000103 COIL 1
LB7805 J0JCC0000103 COIL 1
LB7806 J0JHC0000032 COIL 1
LB7807 J0JCC0000103 COIL 1
LB7808 ERJ3GEY0R00V 1/10W 0 1
LB7809 J0JHC0000032 COIL 1
LB7810 J0JCC0000103 COIL 1
LB7811 J0JCC0000103 COIL 1
LB7812 ERJ3GEY0R00V 1/10W 0 1
LB7813 ERJ3GEY0R00V 1/10W 0 1
LB7814 J0JHC0000032 COIL 1
LB7815 ERJ3GEY0R00V 1/10W 0 1
LB7816 ERJ3GEY0R00V 1/10W 0 1
LB37101 J0JKB0000012 COIL 1
LB37103 J0JGC0000020 COIL 1
P1101 K2AB2B000007 AC INLET 1
P1200 K1KA04AA0180 CONNECTOR(4P) 1
P31901 K1KA15A00118 CONNECTOR(15P) 1
P31902 K1KA19A00007 CONNECTOR(19P) 1
P31903 K1KA19A00007 CONNECTOR(19P) 1
P31904 K1KA19A00007 CONNECTOR(19P) 1
P31905 K1KA07A00083 CONNECTOR(7P) 1
P31906 K1KB10B00053 CONNECTOR(10P) 1
P37101 K1KY64A00001 CONNECTOR(64P) 1
P37599 K1KA03AA0180 CONNECTOR(3P) 1
Q1200 B3PBA0000454 TRANSISTOR 1
Q1260 B1DHED000008 TRANSISTOR 1
Q1300 B1DHED000008 TRANSISTOR 1
Q7801 2SB1218K0L TRANSISTOR 1
Q7802 2SD1819K0L TRANSISTOR 1
Q7901 B1BABK000001 TRANSISTOR 1
Q7902 2SB0710A0L TRANSISTOR 1
Q37591 B1ABMF000020 TRANSISTOR 1
QR7801 UNR5112J0L TRANSISTOR 1
QR7901 B1GBCFJJ0040 TRANSISTOR 1
R1120 ERJ6GEYJ100V 1/8W 10 1
122
DMR-EZ48VP / DMR-EZ48VPC / DMR-EZ485VP

Ref.
No.
Part No. Part Name &
Description
Pcs Remarks
R1121 ERJ6GEYJ100V 1/8W 10 1
R1122 ERDS2TJ221T 1/4W 220 1
R1123 ERJ3GEYJ103V 1/10W 10K 1
R1124 ERJ3GEYJ103V 1/10W 10K 1
R1125 ERX2SZJR10E 2W 10 1
R1126 ERJ3RBD153V 1/16W 15K 1
R1127 ERJ3RBD102V 1/16W 1K 1
R1128 ERJ3RBD182V 1/16W 1.8K 1
R1129 ERJ3RBD682V 1/16W 6.8K 1
R1200 ERJ3GEYJ102V 1/10W 1K 1
R1201 ERJ3GEYJ271V 1/10W 270 1
R1203 ERJ3GEYJ222V 1/10W 2.2K 1
R1204 ERJ3GEYJ103V 1/10W 10K 1
R1206 ERJ3RBD272V 1/16W 2.7K 1
R1207 ERJ3GEY0R00V 1/10W 0 1
R1208 ERJ3RBD561V 1/16W 560 1
R1209 ERJ3RBD103V 1/16W 10K 1
R1260 ERJ3GEYJ333V 1/10W 33K 1
R1261 D1BFR033A010 1/2W 0.033 1
R1262 ERJ3RBD681V 1/16W 680 1
R1263 ERJ3RBD133V 1/16W 13K 1
R1264 ERJ3RBD362V 1/16W 3.6K 1
R1280 ERJ3RBD102V 1/16W 1K 1
R1281 ERJ3RBD223V 1/16W 22K 1
R1282 ERJ3RBD113V 1/16W 11K 1
R1290 ERJ3RBD362V 1/16W 3.6K 1
R1291 ERJ3RBD683V 1/16W 68K 1
R1292 ERJ3RBD243V 1/16W 24K 1
R1300 ERJ3GEYJ333V 1/10W 33K 1
R1301 D1BFR0270001 1/2W 0.027 1
R1302 ERJ3RBD821V 1/16W 820 1
R1303 ERJ3RBD103V 1/16W 10K 1
R1304 ERJ3RBD472V 1/16W 4.7K 1
R1340 ERJ3RBD102V 1/16W 1K 1
R1341 ERJ3RBD393V 1/16W 39K 1
R1342 ERJ3RBD113V 1/16W 11K 1
R7301 ERJ3GEYJ101V 1/10W 100 1
R7302 ERJ3GEYJ101V 1/10W 100 1
R7304 ERJ3GEY0R00V 1/10W 0 1
R7305 ERJ3GEY0R00V 1/10W 0 1
R7306 ERJ3GEYJ472V 1/10W 4.7K 1
R7307 ERJ3GEYJ102V 1/10W 1K 1
R7308 ERJ3GEY0R00V 1/10W 0 1
R7801 ERJ3GEYJ681V 1/10W 680 1
R7802 ERJ3GEYJ104V 1/10W 100K 1
R7803 ERDS2TJ102T 1/4W 1K 1
R7804 ERJ3GEY0R00V 1/10W 0 1
R7805 ERJ3GEY0R00V 1/10W 0 1
R7901 ERJ3GEYJ472V 1/10W 4.7K 1
R7902 ERJ3GEYJ562V 1/10W 5.6K 1
R7903 ERJ3GEYJ472V 1/10W 4.7K 1
R7904 ERJ3GEYJ470V 1/10W 47 1
R7905 ERJ3GEYJ473V 1/10W 47K 1
R7906 ERJ3GEYJ473V 1/10W 47K 1
R7907 ERDS2TJ1R0T 1/4W 1.0 1
R7908 ERDS2TJ331T 1/4W 330 1
R37503 ERJ3GEYJ473V 1/10W 47K 1
R37504 ERJ3GEYJ473V 1/10W 47K 1
R37594 ERJ3GEYJ303V 1/10W 30K 1
R37595 ERJ3GEYJ821V 1/10W 820 1
R37596 ERJ3GEYJ153V 1/10W 15K 1
T1101 G4D2A0000292 TRANSFORMER 1
T7901 G4D1A0000115 TRANSFORMER 1
TU7801 ENG56E02G1F TUNER,VHF/UHF 1
VA1101 ERZVA5V471 VARISTOR 1
VA1102 ERZVA5V471 VARISTOR 1
W300 ERJ3GEY0R00V 1/10W 0 1
W301 ERJ3GEY0R00V 1/10W 0 1
W302 ERJ3GEY0R00V 1/10W 0 1
Ref.
No.
Part No. Part Name &
Description
Pcs Remarks
W303 ERJ3GEY0R00V 1/10W 0 1
W304 ERJ3GEY0R00V 1/10W 0 1
W305 ERJ3GEY0R00V 1/10W 0 1
W306 ERJ3GEY0R00V 1/10W 0 1
W307 ERJ3GEY0R00V 1/10W 0 1
W308 ERJ3GEY0R00V 1/10W 0 1
W309 ERJ3GEY0R00V 1/10W 0 1
W310 ERJ3GEY0R00V 1/10W 0 1
W311 ERJ3GEY0R00V 1/10W 0 1
W312 ERJ3GEY0R00V 1/10W 0 1
W313 ERJ3GEY0R00V 1/10W 0 1
W314 ERJ3GEY0R00V 1/10W 0 1
W315 ERJ3GEY0R00V 1/10W 0 1
W316 ERJ3GEY0R00V 1/10W 0 1
W317 ERJ3GEY0R00V 1/10W 0 1
W318 ERJ3GEY0R00V 1/10W 0 1
W319 ERJ3GEY0R00V 1/10W 0 1
ZA1101 EYF52BCY FUSE HOLDER 1
ZA1102 EYF52BCY FUSE HOLDER 1
ZA1120 VSC5713-A EARTH PLATE 1
ZA1121 XYN3+J8FJ SCREW 1
ZA1240 VSC5984 HEAT SINK 1
ZA1241 XYN3+J8FJ SCREW 1
ZA1280 VSC5839-A HEAT SINK 1
ZA1281 XYN3+J8FJ SCREW 1
ZA1340 VSC5836-A EARTH PLATE 1
ZA1341 XYN3+J8FJ SCREW 1
ZJ37001 K9ZZ00001279 EARTH PLATE 1
ZJ37002 K9ZZ00001279 EARTH PLATE 1
ZJ37003 K9ZZ00001279 EARTH PLATE 1
ZJ37004 K9ZZ00001279 EARTH PLATE 1
ZA37005 K9ZZ00001279 EARTH PLATE 1
QCASING/ACCESSORY/P
ACKING
1 VEP04927A FRONT(L)P.C.B. 1 (RTL)
2 VEP06G41A MAIN P.C.B. 1 (RTL)
3 VEP07B04A FRONT(R)P.C.B. 1 (RTL)
4 VEP09150A DIGITAL I/F P.C.B. 1 (RTL)
(EZ48VP/EZ485
V)
4 VEP09150B DIGITAL I/F P.C.B. 1 (RTL)
(EZ48VPC)
5 VEP73153A DV/SD/USB P.C.B. 1 (RTL)
6 RFKB79180C DIGITAL P.C.B. 1 (RTL)
7 L6FALCCH0002 FAN MOTOR 1
8 RGR0374A-E1 REAR PANEL 1 (EZ48VP)
8 RGR0374A-F1 REAR PANEL 1 (EZ48VPC)
8 RGR0374A-G REAR PANEL 1 (EZ485V)
9 RHD26054 SCREW 1
10 RHD30111-3 SCREW 15
11 RHD30119-L SCREW 9
12 RHD30148 SCREW 1
13 RHDC0023 SCREW 3
14 RKA0137-K FOOT RUBBER 2
15 RKA0178-X FOOT 2
16 RMA2044-1 DVD ANGLE 1
17 RMA2060 REAR ANGLE 1
18 RMC0708-1 EARTH SPRING 1
19 RMC0741 EARTH PLATE(T) 1
20 RMN0885 SPACER 1
21 RMX0354 MECHA SPACER(F) 1
22 RMX0355 MECHA SPACER(R) 1
23 RMX0390 PCB SUPPORT 2
24 RMX0398 FFC SPACER 1
25 RMX0411 PCB SUPPORT 1
26 RMZ0891 INSULATION SHEET 1
27 RHD26045-J SCREW 3
28 RYP1418-K FRONT PANEL ASS Y
1
1 (EZ48V)
123
DMR-EZ48VP / DMR-EZ48VPC / DMR-EZ485VP

Ref.
No.
Part No. Part Name &
Description
Pcs Remarks
28 RYP1418D-K FRONT PANEL ASS Y
1
1 (EZ485V)
28-1 RGU2475-S DUBBING BUTTON 1
28-2 RGU2563-K OPERATION BUTTON 1
28-3 RKF0799-K BLINDER PANEL 1
28-4 RKF0800-K TRAY DOOR 1
28-5 RKF0801-K1 DOOR 1
28-6 RKW0781B-Q DUB WINDOW 1
28-7 RMB0870 TRAY DOOR SPRING 1
28-8 RMC0689 EARTH SPRING(T) 1
28-9 RMC0744 EARTH PLATE 1
28-11 VMB2521-J BLINDER SPRING 1
29 VEE1D23 WIRE WITH
CONNECTOR
1
30 VEE1E19 WIRE WITH
CONNECTOR
1
31 RHD30113-1K SCREW 4
32 RHD30119-L SCREW 3
33 RKM0572-K TOP COVER 1
34 VWJ1935 FFC(7P) 1
35 VWJ2003 FFC 1
36 VWJ2004 FFC 1
37 XSN3+4FJ SCREW 2
38 XTV26+6FFJ SCREW 1
39 RHD30111-3 SCREW 1
40 VHD1092-1 SCREW 1
41 VKC0295 HOLDER 3
42 VWJ1933-2 FFC(40P) 1
101 VEG1697KIT RDD CYLINDER ASS Y 1
101-1 VMD5464 FPC HOLDER 1
102 VEM0800T CAPSTAN MOTOR 1
103 L1AG00000011 FE HEAD ASS Y 1
104 VDB1431 TENSION ARM BOSH 1
105 VDG1686 INTERMEDIATE GEAR 1
106 VDG1685 MAIN CAM GEAR 1
107 VDG1512 IDLER GEAR 2
108 VDG1514 CHANGE GEAR 1
109 VDR0372A REEL TABLE 2
110 VDV0391 CAPSTAN BELT 1
111 VEM0797 LOADING MOTOR 1
112 VMB3550A CHANGING GEAR
SPRING
1
113 VMD4987 WORM SHAFT HOLDER 1
114 VMD5466 OPENER PIECE 1
115 VMD4253 LED PRISM 1
116 VML3934 MAIN LEVER 1
117 VML3933 PINCH CHARGE ARM 1
118 VML3632 IDLER ARM 1
119 VMX3092 P4 CAP 1
120 VXA7105 S SHAFT HOLDER 1
121 VXA7106 T SHAFT HOLDER 1
122 L1AE00000044 AC HEAD ASS Y 1
122-1 VHD1066-2 SCREW 2
122-2 VHD1185 SCREW 1
124 VXL3107 S LOADING ARM 1
125 VXL3108 T LOADING ARM 1
126 VXL3109-7 PINCH ARM 1
127 VXL3110 P5 ARM 1
128 VXL3111-1 TENSION ARM 1
129 VXL3252 S BRAKE ARM 1
130 VXL3343 T BRAKE ARM 1
130-1 VMB3548 T BRAKE SPRING 1
131 VXL3124 CHANGING LEVER 1
132 VXP2133 CENTER CLUTH 1
133 VXP2168 TORQUE CLUTCH 1
134 VMA0L25 TOP PLATE 1
135 VMD5468 SIDE PLATE(L) 1
136 VMD5469 SIDE PLATE(R) 1
137 VXA8265 CASSETTE HOLDER
ASS Y
1
138 VXL3160 MAIN SHAFT 1
139 VDG1684 SECTOR GEAR 1
141 VML3706 OPENER LEVER 1
142 VHD1044-1 SCREW 1
Ref.
No.
Part No. Part Name &
Description
Pcs Remarks
143 XYN3+C4FJ SCREW 1
144 XTN26+7JFJ SCREW 3
145 XTV26+5FFJ SCREW 2
146 XTV26+8FFJ SCREW 2
148 VHD1117-1 SCREW 3
149 VMX2208 WASHER 1
150 VMX3196 WASHER 1
151 VMX2699 WASHER 1
152 VMX3196 WASHER 1
A1 K2CB2CB00018 AC CORD 1
A2 K2KA6BA00004 AV CORD 1
A3 K2KZ2BA00001 RF COAXIAL CABLE 1
A4 N2QAYB000197 REMOTE CONTROL
ASS Y
1
A4-1 100300037800 BATTERY COVER 1
A5 RPQF0220-2 ACCESSORY BOX 1 (EZ48V)
A5 RPQF0254 ACCESSORY BOX 1 (EZ485V)
A6 RPFC0031-B POLYETHYLENE BAG 1
A7 RQT9056-P OPERATING
INSTRUCTIONS
1 (IA)
A7 RQT9057-C OPERATING
INSTRUCTIONS
1 (EZ48VPC)(IB)
A8 K1HA19DA0007 HDMI CABLE 1 (EZ485V)
PC1 RPG8415-1 PACKING CASE 1 (EZ48VP)
PC1 RPG8416-1 PACKING CASE 1 (EZ48VPC)
PC1 RPG8545 PACKING CASE 1 (EZ485V)
PC2 RPN2036A CUSHION(A) 1
PC3 RPN2036B CUSHION(B) 1
PC4 RPF0459 POLYETHYLENE BAG 1
PC5 RPN1994 FRONT PAD 1
124
DMR-EZ48VP / DMR-EZ48VPC / DMR-EZ485VP
