Panasonic ER-CSF1 User manual

Safety precautions
Follow these instructions.
To prevent accidents, injuries or damage to
property, please follow the instructions below.
■The following chart indicates the
degree of damage caused by
improper operation.
WARNING
Indicates potential
hazard that could
result in serious
injury or death.
CAUTION
Indicates potential
hazard that could
result in minor injury
or property damage.
WARNING
►Preventing accidents
• Do not place within reach of
children or infants. Do not let them
use it.
- Putting parts or accessories in the
mouth may cause an accident or injury.
CAUTION
►Protecting the skin
• Do not use excessive pressure to
apply the system outer foil to your
lip or other part of your face.
• Do not apply the system outer foil
directly to blemishes or injured skin.
• Do not touch the blade section
(metallic section) of the inner blade.
- Doing so may cause injury to skin or
hand.
• Do not use this appliance for hair on
head or any other part of the body.
- Doing so may damage the foil
causing injury to skin or reduce the
life of the system outer foil.
• Check the system outer foil for
cracks or deformations before use.
- Failure to do so may cause injury to
the skin.
• Do not forcefully press the system
outer foil.
Also, do not touch the system
outer foil with ngers or nails
when in use.
- Doing so may damage the foil
causing injury to skin or reduce the
life of the system outer foil.
►Note the following precautions
• Do not share with your family or
other people.
- Doing so may result in infection or
inammation.
Important information
• Apply the lubrication oil after each
cleaning for it will keep the movement
of the blade smooth and maintain a
comfortable shave.
• Note the following precautions to avoid
malfunction or deformation.
• Do not bring the system outer foil into
contact with hard objects.
• Do not drop or hit against other objects.
• Store the appliance in a place with
low humidity after use.
• Be sure to place the protective cap on the
head when carrying around or storing.
Parts identication
(Fig. 1)
AHead
1Protective cap
2System outer foil
3Foil frame
4System outer foil release buttons
5Outer foil section
6Inner blades
7Foil frame release button
How to use
• Clean the appliance after use.
1 Mount the head to the main body
until it clicks.
2 Turn on the power.
Note
• The use time after a full charge is as
follows.
ER-CBL1: 50 minutes
ER-CBN1: 40 minutes
(Based on dry using at 20 °C – 30 °C)
The operating time may differ
depending on the frequency of use and
the operating method.
Quick charge (ER‑CBL1 only)
Even though the battery runs out, you can
use for 5 minutes after 3-minute charge.
(This will differ depending on usage.)
Removing and mounting
the head (Fig. 2)
• Make sure that the main body is turned off.
Remove the head while pushing the
head release button (a).
▪Stand the head when it is removed.
Mount the head to the main body until
it clicks.
Shaving (Fig. 3)
Apply the whole system outer foil
perpendicularly against the skin and
shave by slowly gliding the appliance over
the face against the grain of the beard.
• The beard under the chin and around
the throat can be shaved better by
stretching the skin to raise the beard.
• To prevent damaging the system outer
foil, do not shave with only a part of the
system outer foil.
Maintenance
• Make sure that the main body is turned off.
• Lubricate after cleaning and store the
head with the protective cap attached.
How to clean
►With water
1
Apply some hand soap and some water
to the system outer foil. (Fig. 4‑ 1 )
2 Turn on the power and turn off the
power after 20 seconds.
3 Remove the head and the outer foil
section.
4 Rinse them with running water.
(Fig. 4‑2)
5 Shake up and down several times to
remove the water.
▪Be careful not to hit the appliance on
the sink or any other object while
draining the water.
6 Wipe off the water with a dry cloth
and dry it well.
▪Allow the head to dry in the shade,
avoid direct sunlight.
▪Do not dry the appliance with a dryer
or a fan heater.
Notes
• Do not wipe with thinner, benzine,
alcohol etc. Doing so may cause
malfunction, cracking or discoloring of
the parts.
►With the cleaning brush
1. Remove the outer foil section and the
inner blades.
2. Brush off any hair trimmings from the
head and the outer foil section. (Fig. 5)
▪
Clean the inner blades using the brush
by moving it in direction as illustrated.
▪Do not move the brush
perpendicularly against the blades as
it will damage the inner blades and
affect their sharpness.
Operating Instructions
(Household use) Shaver Head
Model No. ER-CSF1









 
12
3 4



 
5
6 76
ER-CSF1_US_PR.indd 1 2022/02/21 15:08:45

Removing and mounting the
outer foil and the inner blades
Outer foil section (Fig. 6‑1)
Remove the frame by pushing the
frame release button (b).
Align as illustrated, securely attach
the outer foil section to the head until
it clicks.
System outer foil (Fig. 6‑2)
• Do not throw away the foil frame.
Press the system outer foil release
buttons (c) and pull down the system
outer foil.
• Do not press the system outer foil
release buttons with excessive force.
Doing so may bend the system outer
foil, preventing complete attachment
to the foil frame.
Align as illustrated, securely attach
the system outer foil to the foil frame
until it clicks.
Inner blades (Fig. 6‑3)
Remove the inner blades one at a time.
Insert the inner blades one at a time.
Replacement parts
System outer foil: once every year
Inner blades: once every two years
Replacement part is available at your
dealer or Service Center.
System outer foil and inner
blades
WES9013
System outer foil WES9087
Inner blades WES9068
Lubrication oil WES003P
Lubrication
1
Apply one drop of lubrication oil to
each of the system outer foils. (Fig. 7)
2 Turn on the power and allow to run
it for approximately 5 seconds.
3 Turn off the power and wipe off any
excess lubrication oil from the
system outer foil with a soft cloth.
Troubleshooting
Problem Action
The appliance
has become
blunt.
Operating
time is short.
Appliance
stopped
functioning.
Until problems are
solved, please follow
each procedure as
follows;
1. Charge the
appliance.
2. Clean the blade
and apply
lubrication oil.
3. Replace the blade.
Makes a loud
sound.
Clean the blade and
apply lubrication oil.
Conrmthattheblade
is properly attached.
The odor is
getting
stronger.
This can be
improved by
cleaning every time
after shaving.
Shavingsyout
in all directions.
This can be
improved by
cleaning every time
after shaving.
Clean the inner
blades with the
brush when shavings
are adhering to the
inner blades.
System outer
foil gets hot.
Apply lubrication oil.
Replace the system
outer foil if it is
damaged or deformed.
If the problems still cannot be resolved,
contact your dealer or a service center
authorized by Panasonic for repair.
Personal Care & Beauty Care Products
FOR USA ONLY
30‑Day Quality
Satisfaction Guarantee
Ifyouaredissatisedwithany
Panasonic Personal Care & Beauty
Care Products for any reason, simply
return it to the place of purchase with a
dated proof of purchase, in the original
packaging, with all accessories, parts
and instructions, within 30 days of the
date of purchase, for a full refund, or
call Panasonic at 1-800-338-0552.
Abuse or misapplication of this product
voids the guarantee.
PRODUCT REGISTRATION
(U.S. customers only)
Go to www.panasonic.com/register and
register your product now to receive
thesebenets:
Safety Notication
We contact our customers in case of recall
Owner Verication
Proof of purchase in case of product
theft or loss
Efcient Warranty Service
In case there is a problem with your product
Special Offers and Promotions from
Panasonic
FOR YOUR CONVENIENCE, WE HAVE
ESTABLISHED A TOLL‑FREE (IN USA
ONLY) NATIONAL ACCESSORY
PURCHASE HOTLINE AT 1‑800‑332‑5368.
