Panasonic ER389X User manual

Operating Instructions
Rechargeable Beard/Moustache Trimmer
Model No. ER389X
English����������������������������������������������� 3
Português���������������������������������������� 17
Español�������������������������������������������� 31

2

3
English
Operating Instructions
Rechargeable Beard/Moustache Trimmer
Model No. ER389X
Thank you for purchasing this Panasonic product.
Before operating this unit, please read these instructions
completely and save them for future use.
Contents
Safety precautions.............................4
Intendeduse�������������������������������������������������9
Partsidentication�������������������������������������10
Charge��������������������������������������������������������� 11
Use��������������������������������������������������������������� 11
Care��������������������������������������������������������������12
Troubleshooting�����������������������������������������13
Frequentlyaskedquestions����������������������14
Bladelife������������������������������������������������������14
Batterylife���������������������������������������������������15
Removingthebuilt-inrechargeablebattery ���15
Specications���������������������������������������������16

4
English
Safety precautions
To reduce the risk of injury, loss of life, electric shock, fire, and damage
to property, always observe the following safety precautions.
Explanation of symbols
The following symbols are used to classify and describe the level of
hazard, injury, and property damage caused when the denotation is
disregarded and improper use is performed.
DANGER Denotes a potential hazard
that will result in serious
injury or death.
WARNING Denotes a potential hazard
that could result in serious
injury or death.
CAUTION Denotes a hazard that could
result in minor injury.
The following symbols are used to classify and describe the type of
instructions to be observed.
This symbol is used to alert users to a specific operating
procedure that must not be performed.
This symbol is used to alert users to a specific operating
procedure that must be followed in order to operate the unit
safely.

5
English
WARNING
Do not connect or disconnect the power plug to a
household outlet with a wet hand.
-Doing so may cause electric shock or injury.
Never use the appliance if the AC adaptor is damaged
or if the power plug fits loosely in a household outlet.
Do not damage or modify, or forcefully bend, pull, or
twist the cord.
Also, do not place anything heavy on or pinch the cord.
-Doing so may cause electric shock or fire due to a short circuit.
Do not use in a way exceeding the rating of the
household outlet or the wiring.
-Exceeding the rating by connecting too many plugs to one
household outlet may cause fire due to overheating.
Do not modify or repair.
-Doing so may cause fire, electric shock, or injury.
Contact an authorized service center for repair (battery
change, etc.).
Never disassemble except when disposing of the
product.
-Doing so may cause fire, electric shock, or injury.
This product has a built-in rechargeable battery.
Do not throw into flame or heat.
-Doing so may cause fluid leak, overheating, or explosion.
Do not immerse the main body or the AC adaptor in
water or wash it with water.
Do not place the main body or the AC adaptor over or
near water filled sink or bathtub.
Keep the appliance dry.
-Doing so may cause electric shock or fire due to a short circuit.
Do not use anything other than the supplied AC
adaptor. Also, do not charge any other product with the
supplied AC adaptor.
-Doing so may cause burn or fire due to a short circuit.

6
English
WARNING
Do not store within the reach of children or infants. Do
not let them use it.
-Putting the blade, and/or oil container in the mouth may cause
accidents and injury.
Always ensure the appliance is operated on an electric
power source matched to the rated voltage indicated on
the AC adaptor.
Fully insert the power plug.
-Failure to do so may cause fire or electric shock.
Immediately stop using and remove the power plug if
there is an abnormality or malfunction.
-Failure to do so may cause fire, electric shock, or injury.
<Abnormality or malfunction cases>
•The main unit or AC adaptor is deformed or
abnormally hot.
•The main unit or AC adaptor smells of burning.
•There is abnormal sound during use or charging of the
main unit or AC adaptor.
-Immediately request inspection or repair at an authorized
service center.
Always unplug the power plug from a household outlet
when cleaning.
-Failure to do so may cause electric shock or injury.
Regularly clean the power plug and the charging plug
to prevent dust from accumulating.
-Failure to do so may cause fire due to insulation failure caused
by humidity.
Disconnect the power plug and wipe with a dry cloth.
If the oil is consumed accidentally, do not induce
vomiting, drink a large amount of water, and contact a
physician.
If the oil comes into contact with eyes, immediately
wash thoroughly with running water, and contact a
physician.
-Failure to do so may result in physical problems.

7
English
WARNING
This appliance is not intended for use by persons
(including children) with reduced physical, sensory or
mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or
instruction concerning use of the appliance by a person
responsible for their safety. Children should be
supervised to ensure that they do not play with the
appliance.
-Failure to do so may cause an accident or injury.
If the supply cord is damaged, it must be replaced by
the manufacturer, its service agent, or similarly
qualified persons in order to avoid a hazard.
-Failure to do so may cause an accident or injury.
CAUTION
Do not use the trimmer for any purpose other than
trimming.
Do not directly apply the blades on ears or rough skin
(such as swellings, injuries or blemishes).
Do not press the blade against the skin. Also, do not
directly apply the blade on pimples or wounds.
-Doing so may cause skin injury.
Do not allow pins or trash to adhere to the power plug
or the charging plug.
-Doing so may cause electric shock or fire due to a short circuit.
Do not drop or subject to shock.
-Doing so may cause injury.
Do not wrap the cord around the AC adaptor when
storing.
-Doing so may cause the wire in the cord to break with the
load, and may cause fire due to a short circuit.
Check that the blades are not damaged or deformed
before use.
-Failure to do so may cause skin injury.

8
English
CAUTION
Disconnect the power plug from the household outlet
when not charging.
-Failure to do so may cause electric shock or fire due to
electrical leakage resulting from insulation deterioration.
Disconnect the power plug by holding onto it instead of
the cord.
-Failure to do so may cause electric shock or fire due to a short
circuit.
►Disposal of the rechargeable battery
DANGER
The rechargeable battery is exclusively for use with this
trimmer. Do not use the battery with other products.
Do not charge the battery after it has been removed
from the product.
•Do not throw into fire or apply heat.
•Do not solder, disassemble or modify the battery.
•Do not let the positive and negative terminals of the
battery get in contact with each other through metallic
objects.
•Do not carry or store the battery together with metallic
jewellery such as necklaces and hairpins.
•Never peel off the tube.
-Doing so may cause fluid leak, overheating, or explosion.
WARNING
After removing the rechargeable battery, do not keep it
within the reach of children and infants.
-The battery will harm the body if accidentally swallowed.
If this happens, consult a physician immediately.

9
English
WARNING
If the battery fluid leaks out, take the following
procedures. Do not touch the battery with your bare
hands.
-The battery fluid may cause blindness if it comes in contact
with your eyes.
Do not rub your eyes. Wash immediately with clean water and
consult a physician.
-The battery fluid may cause inflammation or injury if it comes
in contact with the skin or clothes.
Wash it off thoroughly with clean water and consult a
physician.
Intended use
►Notes
• The appliance should not be used on animals.
• Before and after each use, apply oil at the places marked with arrows.
(See page 13.)
• The trimmer may become warm during use and charging. However,
this is not a malfunction.
• Clean the housing only with a soft cloth slightly dampened with tap
water or soapy tap water. Do not use thinner, benzine, alcohol or
other chemicals.
• Store the trimmer in a place with low humidity after use.
• Before using an attachment, check that it has been installed correctly.
Failure to do so may cause hair to be cut too short.

10
English
Parts identification
A Comb attachment
B Blade block
1 Stationary blade
2 Moving blade
3 Cleaning lever
4 Mounting hook
C Main body
5 Height adjustment
switch
6 Lock button
7 Trimming position mark
8 Appliance socket
9 Power switch
[0•charge/1]
D AC adaptor
(RE9-74/RE9-75)
: Charging plug
; Cord
< Power plug
Accessory
E Oil
6
5
4
3
2
1
3 mm
  

 











11
English
Charge
This trimmer can be used for approximately 45 minutes after charging
for 8 hours. A 12 hours charge will fully charge the battery, and the
trimmer can be used for approximately 65 minutes.
• The operating time may be shorter when using the trimmer for the
first time, or if it has not been used for more than 6 months. In this
case, charge the battery for 16 hours or longer.
• Recommended ambient temperature for charging is 0 – 40 °C.
Battery performance may decrease under extremely low or high
temperatures, and the battery may not be charged properly.
1. Place the trimmer on the AC adaptor.
2. Insert the power plug into a
household outlet.
• The power switch should be set to the
“0•charge” (off) position during charging.
• When charging is completed, remove the
power plug from the household outlet. 2
1
Use
We recommend using the trimmer in an ambient temperature range of
0 - 40 °C. The trimmer may not operate in temperatures outside the
recommended temperature range.
Using the comb attachment
If you wish to maintain a consistent beard length, within a range of
3 mm to 18 mm, use the provided comb attachment.
1. Place the comb attachment over the
blade.
2. Press the lock button, located on the
height adjustment switch, and slide it
up or down to your preferred position.
3. Release the lock button, then the
position will be set.
2
1

12
English
• The trimming position mark indicates the trimming heights as follows.
Trimming position mark Trimming height (approx.)
1 3 mm
2 6 mm
3 9 mm
4 12 mm
5 15 mm
6 18 mm
►Trimming without a comb attachment
Trimming without a comb attachment will trim hair length to approx. 0.5 mm.
Care
Removing and mounting the blade
Removing the blade
Hold the trimmer with the switch facing
upward and push the blade with your
thumb while catching the blade in your
other hand.
Mounting the blade
Fit the mounting hook into the
blade mounting on the trimmer
and then push in until you hear a
click.
Cleaning the blade
Use a brush to clean the blade.
Clean the trimmer and the blade after each use.
Brush the hairs out from between the
stationary blade and the moving blade
while pressing down on the cleaning lever
to raise the moving blade.

13
English
Lubrication
• Apply the oil to the trimmer before and after each use.
Apply a drop of the oil to each
indicated point.
Failure to apply the oil may cause
the following problems due to
rust, wear or burn out.
-The clipper has become blunt.
-Shorter operating time.
-Louder sound.
Cleaning the AC adaptor
Use a brush to clean hair trimmings and dust in the charging plug or in
the hole on the bottom surface.
Troubleshooting
Problem Action
The trimmer has become
blunt.
Charge the trimmer.
(See page 11.)
Clean the blade and apply oil.
(See pages 12 and 13.)
Replace the blade.
(See page 12.)
Trimmer stopped functioning.
Operating time is short even
after charging.
Charge the battery for
approximately 16 hours
continuously to rejuvenate it.
If few uses remain even after
charging, the battery has reached
the end of its life. (Fluid may be
leaking due to degradation at the
end of battery life.)

14
English
Problem Action
The trimmer cannot be
charged.
Push the main body into the AC
adaptor all the way.
Charge within the recommended
charging temperature of 0 °C to
40 °C.
Clean the charging plug if it is dirty
or there is any foreign material on it.
Trimmer can be used for only
about 10 minutes even after
charging.
Have the battery replaced by an
authorized service center.
Makes a loud sound. Confirm that the blade is properly
attached.
If the problem persists, please contact our customer service lines (see
back page). Or try our website: www.panasonic.com
Frequently asked questions
Question Answer
Will the battery be exhausted
after a long period of disuse?
When the appliance is not used for
6 months or more, the battery will
weaken (leak battery fluid, etc.).
Fully charge the battery once
every 6 months.
Can the battery be charged
before every use?
Yes, but it is recommended that
you charge the battery when it is
empty. The life of the battery will
vary depending upon usage and
storage conditions.
Blade life
Blade life varies according to the frequency and period of use of the
trimmer.
For example, the blade life is approximately 3 years when using the
trimmer for 5 minutes 20 times a month. Replace the blades if cutting
efficiency reduces substantially especially with proper maintenance.

15
English
Battery life
Battery life will vary according to the frequency and period of use. If the
battery is charged once every 2 weeks, the service life will be
approximately 3 years.
If the operating time is significantly shorter even after a full charge, the
battery has reached the end of its life.
Removing the built-in rechargeable battery
Remove the built-in rechargeable battery before disposing the
trimmer.
Please make sure that the battery is disposed of at an officially
designated location if there is one.
This figure must only be used when disposing the trimmer, and must
not be used to repair it. If you dismantle the trimmer yourself, it may
cause malfunction.
• Remove the trimmer from the AC adaptor.
• Slide the power switch to turn on the power and then keep the power
on until the battery is completely discharged.
• Perform steps 1 to 2 and lift the battery, and then remove it.
• Please take care not to short-circuit the battery.



16
English
For environmental protection and recycling of materials
This trimmer contains a Nickel-Metal Hydride battery.
Please make sure that the battery is disposed of at an officially
assigned location, if there is one in your country.
Specifications
Power source See the name plate on the product.
Motor voltage 1.2 V
Charging time Approx. 8 hours

17
Português
Instruções de operação
Recarregável aparador de bigode e barba
Modelo no. ER389X
ObrigadoporadquiriresteprodutoPanasonic.
Antesdeutilizaresteaparelho,leiaestasinstruções
completamenteeguarde-asparafuturasconsultas�
Índice
Precauções de segurança ...............18
Utilizaçãoprevista��������������������������������������23
Identicaçãodaspeças�����������������������������24
Carregar�������������������������������������������������������25
Uso���������������������������������������������������������������25
Cuidado�������������������������������������������������������26
Resoluçãodeproblemas���������������������������27
Perguntasfrequentes���������������������������������28
Tempodevidadalâmina���������������������������28
Vidadabateria��������������������������������������������29
Remoçãodabateriarecarregável
incorporada�������������������������������������������������29
Especicações��������������������������������������������30

18
Português
Precauçõesdesegurança
Parareduziroriscodeferimentos,morte,choqueeléctrico,incêndioedanos
materiais,respeitesempreasprecauçõesdesegurançaapresentadasem
seguida.
Explicaçãodossímbolos
Ossímbolosseguintessãoutilizadosparaclassicaredescreveronívelde
perigo,ferimentosedanosmateriaiscausadosquandoasinstruçõesnãosão
respeitadaseoaparelhoéutilizadoincorretamente.
PERIGO Indicaumperigopotencial
queresultaráemferimentos
gravesoumorte.
ADVERTÊNCIA
Indicaumperigopotencial
quepoderáresultarem
ferimentosgravesoumorte.
CUIDADO Indicaumperigoquepoderá
resultaremferimentos
menores.
Ossímbolosseguintessãoutilizadosparaclassicaredescreverotipode
instruçõesarespeitar.
Estesímboloalertaosusuáriosparaumprocedimentode
funcionamentoespecícoquenãodeveserrealizado.
Estesímboloalertaosusuáriosparaumprocedimentode
funcionamentoespecícoquetemdeserseguidoparautilizaro
aparelhoemsegurança.

19
Português
ADVERTÊNCIA
Nãoliguenemdesligueoconectordealimentaçãodatomada
elétricacomumamãomolhada�
- Casocontrário,poderáocorrerumchoqueeléctricoouferimentos.
NuncautilizeoaparelhoseotransformadordeCAestiver
danicadoouseoconectordealimentaçãoencaixarcom
folganatomadaelétrica�
Nãodaniqueoumodiquenemdobre,puxeoutorçacom
forçaocabo�
Alémdisso,nãocoloquenadapesadoemcimadocabonem
ocomprima�
- Casocontrário,poderáocorrerumchoqueeléctricoouincêndio
devidoaumcurto-circuito.
Nãoutilizeoaparelhodeformaqueexcedaapotência
nominaldatomadaelétricaoudainstalaçãoelétrica�
- Excederapotêncianominalaoligarmuitosconectoresàtomada
elétricapoderácausarumincêndiodevidoasobreaquecimento.
Nãomodiquenemrepareoaparelhopelosseusprópriosmeios�
- Casocontrário,poderáocorrerumincêndio,choqueeléctricoou
ferimentos.
Contateumcentrodeassistênciaautorizadopararepararoaparelho
(substituiçãodabateria,etc.).
Nuncadesmonteoaparelho,exceptoquandoprocederàsua
eliminação�
- Casocontrário,poderáocorrerumincêndio,choqueeléctricoouferimentos.
Esteprodutopossuiumabateriarecarregávelincorporada�
Nãooatireparachamasououtrasfontesdecalor�
- Casocontrário,poderáocorrersobreaquecimento,igniçãoouexplosão.
NãomergulheocorpoprincipalouotransformadordeCAem
águanemolavecomágua�
NãocoloqueocorpoprincipalouotransformadordeCA
sobreoupertodolavatóriooubanheiracheiosdeágua�
Mantenhaoaparelhoseco�
- Casocontrário,poderáocorrerumchoqueeléctricoouincêndio
devidoaumcurto-circuito.

20
Português
ADVERTÊNCIA
Nãoutilizequalqueroutrotransformadoralémdo
transformadordeCAincluído�Alémdisso,nãocarregue
qualqueroutroaparelhocomotransformadordeCAincluído�
- Casocontrário,poderãoocorrerqueimadurasouumincêndiodevido
aumcurto-circuito.
Nãooguardeaoalcancedecriançasoubebês�Nãoosdeixe
utilizaroaparelho�
- Aplicaralâminae/ouorecipientedeóleonabocapoderácausar
acidenteseferimentos.
Certique-sesempredequeoaparelhoéutilizadonuma
fontedealimentaçãoquecorrespondaàtensãonominal
indicadanotransformadordeCA�
Insiracompletamenteoconectordealimentação�
- Senãoozer,poderáocorrerumincêndioouchoqueeléctrico.
Pareimediatamentedeutilizaroaparelhoeremovaoconector
dealimentaçãoseocorrerumaanormalidadeoufalha�
- Senãoozer,poderáocorrerumincêndio,choqueeléctricoou
ferimentos.
<Casosdeanormalidadeouavaria>
•AunidadeprincipalouotransformadordeCAestá
deformadoouanormalmentequente�
•AunidadeprincipalouotransformadordeCAcheiraaqueimado�
•Éemitidoumsomanormalduranteautilizaçãoou
carregamentodaunidadeprincipalouapartirdo
transformadordeCA�
- Soliciteimediatamenteainspeçãooureparaçãonumcentrode
assistênciaautorizado.
Desliguesempreoconectordealimentaçãodatomada
elétricaquandolimparoaparelho�
- Senãoozer,poderáocorrerumchoqueeléctricoouferimentos.
Limpeperiodicamenteoconectordecarregamentoeo
conectordealimentaçãoparaimpediroacúmulodepó�
- Senãoozer,poderáocorrerumincêndiodevidoaumafalhade
isolamentocausadaporumidade.
Desligueoconectordealimentaçãoelimpecomumpanoseco.
