Panasonic ES-LS9A-K820 User manual

Operating Instructions
(Household use) Rechargeable Shaver
Model No. ES‑LS9A
English��������������������������������������������� 3
Русский ����������������������������������������� 31
Українська ������������������������������������ 61
Қазақша����������������������������������������� 91

2

3
English
Thank you for purchasing this Panasonic product.
Before operating this unit, please read these instructions completely and save them for future use�
Operating Instructions
(Household use) Rechargeable Shaver
Model No. ES‑LS9A
Safety precautions..................... 4
Important information �������������������������9
Parts identication ���������������������������� 11
Preparation�����������������������������������������12
How to use �����������������������������������������14
Cleaning thoroughly��������������������������17
Replacing the system outer foil �������19
Replacing the cleaning liquid�����������20
When the LOW/STATUS lamp glows ���21
FAQ �����������������������������������������������������22
Troubleshooting ��������������������������������22
Battery life������������������������������������������28
Removing the built-in rechargeable
battery�������������������������������������������������28
Specications ������������������������������������29
Contents

4
English
Safety precautions
Make sure to follow these instructions.
To prevent accidents, injuries or damage to property,
please follow the instructions below.
■The following chart indicates the degree of
damage caused by improper operation�
DANGER
Indicates a potential hazard that
will result in serious injury or death.
WARNING
Indicates a potential hazard that
could result in serious injury or
death.
CAUTION
Indicates a potential hazard that
could result in minor injury or
property damage.
■ The symbols are classied and explained as
follows�
This symbol indicates prohibition.
This symbol indicates requirement that must be
followed.
WARNING
►This product
This product has a built-in rechargeable
battery. Do not throw into re, apply heat, or
charge, use, or leave in a high temperature
environment�
‑ Doing so may cause overheating, ignition, or
explosion.
Do not modify or repair�
‑ Doing so may cause re, electric shock, or
injury.
Contact an authorized service centre for repair
(replacement of battery etc).
Never disassemble except when disposing of
the product�
‑
Doing so may cause re, electric shock, or injury.

5
English
WARNING
►In case of an abnormality or malfunction
Immediately stop using and remove the AC
adaptor if there is an abnormality or
malfunction�
‑ Failure to do so may cause re, electric shock,
or injury.
<Abnormality or malfunction cases>
•The main unit, self-cleaning recharger, AC
adaptor or cord is deformed or abnormally hot�
•The main unit, self-cleaning recharger,
adaptor or cord smells of burning�
•There is an abnormal sound during use or
charging of the main unit or self-cleaning
recharger�
‑ Immediately request inspection or repair at an
authorized service centre.
►Power supply
Do not connect or disconnect the adaptor to
a household outlet with a wet hand�
‑ Doing so may cause electric shock or injury.
Do not immerse the AC adaptor and the self-
cleaning recharger in water or wash with water�
Do not place the AC adaptor and the self-
cleaning recharger over or near water lled
sink or bathtub�
Never use the appliance if the AC adaptor is
damaged or if the power plug ts loosely in a
household outlet�
Do not damage the cord or the power plug�
•Do not deface, modify, forcefully bend or
pull the cord or the power plug� Also, do
not place anything heavy on, twist or pinch
the cord�
‑ Doing so may cause electric shock or re due
to a short circuit.
Do not use in a way that would exceed the
rating of the household outlet or the wiring�
‑ Exceeding the rating by connecting too many
plugs to one household outlet may cause re
due to overheating.
Do not use anything other than the supplied
AC adaptor and the self-cleaning recharger
for any purpose�
Also, do not use any other product with the
supplied AC adaptor and the self-cleaning
recharger� (See page 11�)
‑ Doing so may cause burn or re due to a short
circuit.
Fully insert the power plug�
‑
Failure to do so may cause re or electric shock.

6
English
WARNING
Disconnect the AC adaptor when cleaning the
main body with water�
‑
Failure to do so may cause electric shock or injury.
Regularly clean the power plug and the
appliance plug to prevent dust from
accumulating�
‑ Failure to do so may cause re due to insulation
failure caused by humidity.
►Preventing accidents
Persons using an implanted medical electronic
device, such as a pacemaker, should not allow
this unit to touch the skin where the medical
electronic device is implanted�
‑ Doing so may cause an accident or illness.
Do not place within reach of children or
infants� Do not let them use it�
‑ Putting parts or accessories in the mouth may
cause an accident or injury.
Do not use or store the self-cleaning
recharger on top of other electrical devices�
‑ Doing so may cause electric shock due to liquid
spill or re due to a short circuit.
If detergent or oil is consumed accidentally,
do not induce vomiting, drink a large amount
of water and contact a physician�
If detergent or oil comes into contact with
eyes, wash immediately and thoroughly with
running water and contact a physician�
‑ Failure to follow these instructions may result in
physical problems.
If detergent contacts skin, wash immediately
and thoroughly with soap�
If you experience skin irritation anywhere on
the body, stop using immediately and contact
a physician�
‑ Failure to follow these instructions may result in
physical injury or injury to the skin.
►Note the following precautions
This appliance is not intended for use by
persons (including children) with reduced
physical, sensory or mental capabilities, or
lack of experience and knowledge, unless
they have been given supervision or
instruction concerning use of the appliance
by a person responsible for their safety�
Children should be supervised to ensure that
they do not play with the appliance�
‑ Failure to do so may cause an accident or
injury.

7
English
WARNING
The supply cord cannot be replaced� If the
cord is damaged, the AC adaptor should be
scrapped�
‑ Failure to do so may cause an accident or
injury.
CAUTION
►Protecting the skin
Do not use excessive pressure to apply the
system outer foil to your lip or other part of
your face�
Do not apply the system outer foil directly to
blemishes or injured skin�
‑ Doing so may cause injury to skin.
Do not forcefully press the system outer foil�
Also, do not touch the system outer foil with
ngers or nails when in use.
Do not use this product for hair on head or
any other part of the body�
‑ Doing so may cause injury to skin or reduce the
life of the system outer foil.
Do not remove the shaver from the self-
cleaning recharger while using the “AUTO”
mode or “Dry/Charge” mode�
‑ Doing so may cause burn due to high
temperatures around the system outer foil.
Check the system outer foil for cracks or
deformations before use�
‑ Failure to do so may cause injury to the skin.
►Note the following precautions
Do not allow metal objects or trash to adhere
to the power plug or the appliance plug�
‑ Doing so may cause electric shock or re due
to a short circuit.
Do not share your shaver with your family or
other people�
‑ Doing so may result in infection or inammation.
Do not use detergent for any purpose other
than washing the system outer foil�
‑ Using it with other products may cause
discoloration or cracking.
Disconnect the adaptor from the household
outlet when not charging�
‑ Failure to do so may cause electric shock or re
due to electrical leakage resulting from
insulation deterioration.
Use caution when opening detergent as
spout is sharp�
‑ Failure to do so may cause injury.

8
English
Handling of the removed battery when disposing
DANGER
•The rechargeable battery is exclusively for
use with this appliance� Do not use the
battery with other products�
•Do not charge the battery after it has been
removed from the product�
•Do not throw into re or apply heat.
•Do not hit, disassemble, modify, or puncture
with a nail�
•Do not let the positive and negative
terminals of the battery get in contact with
each other through metallic objects�
•Do not carry or store the battery together
with metallic jewellery such as necklaces
and hairpins�
•Do not use or leave the battery where it will
be exposed to high temperatures, such as
under direct sunlight or near other sources
of heat�
•Never peel off the tube�
‑ Doing so may cause overheating, ignition, or
explosion.
WARNING
After removing the rechargeable battery, do
not keep it within reach of children and infants�
‑ The battery will harm the body if accidentally
swallowed.
If this happens, consult a physician immediately.
If the battery uid leaks out and comes in
contact with the eyes, do not rub the eyes,
and thoroughly rinse with clean water, such
as tap water�
‑ Failure to do so may cause eye injury.
Consult a physician immediately.
CAUTION
If the battery uid leaks out and comes in
contact with the skin or clothes, rinse off with
clean water, such as tap water�
‑ Failure to do so may cause inammation.

9
English
Important information
• This WET/DRY shaver can be used for wet shaving
using shaving lather or for dry shaving. You can use
this watertight shaver in the shower and clean with
water. The following symbol means suitable for use in
a bath or shower.
• Treat yourself to wet lather shaves for at least three
weeks and notice the difference. Your Panasonic
WET/DRY shaver requires a little time to get used to
because your skin and beard need about a month to
adjust to any new shaving method.
• If you clean the shaver with water, do not use salt
water or hot water. Do not soak the shaver in water for
a long period of time.
• The following symbol indicates that a specic
detachable power supply unit is required for
connecting the electrical appliance to the supply
mains. The type reference of power supply unit is
marked near the symbol.
• Charge the appliance correctly according to these
Operating Instructions. (See page 12 “Charging the
shaver”.)
• This appliance contains battery that is only
replaceable by skilled persons. Please contact an
authorized service centre for the details of repair.
Note the following precautions
►When using
• Do not bring the system outer foil into contact with
hard objects.
Doing so may damage the system outer foil as it is
very thin and deforms easily.
• Do not drop or hit against other objects.
Doing so may cause injury.
►About detergent
• Do not leave the detergent in location of high
temperatures.
Doing so may cause deterioration.
• Immediately wipe up any cleaning liquid that has been
spilt.
Prolonged contact may cause discoloration of leather
products or wooden oors.
►When storing
• Store the shaver in a place with low humidity after
use.
Failure to do so may cause malfunction due to
condensation or rust.
• Be sure to place the protective cap on the shaver
when carrying around or storing.
Failure to do so may cause injury to skin or reduce the
life of the system outer foil.
►When cleaning
• Do not dry the main unit with a dryer or a fan heater.
Doing so may cause malfunction or deformation of the
parts.

10
English
• Do not leave the shaver exposed to direct sunlight
with the foil frame detached.
Doing so may deteriorate the waterproof rubber and
degrade waterproof function, which may cause to
malfunction.

11
English
Parts identication









a
e b
c
d





Back







  








AMain body
1Protective cap
2System outer foil
3Foil frame
4Smooth rollers
• They help to glide
over the skin more
easily.
5Foil frame release
buttons
6Power switch
7Lamp display
a. Battery capacity
lamp
b. Clean lamp ( )
c. Switch lock lamp ( )
d. Charge status lamp
()
e. Foil/blade check
lamp ( )
Appliance socket
Outer foil section
System outer foil
release buttons
Trimmer
Trimmer handle
Main body rear
terminals
BSelf-cleaning recharger
(RC9-23)
Charging terminals
Cleaning liquid unit
removal button
Intake port
Self‑cleaning
recharger socket
Lock release lever
 Cleaning liquid lter
Cleaning liquid unit
STATUS lamp
LOW lamp
CLEAN lamp
DRY lamp
SELECT button
CAC adaptor (RE7-87)
Adaptor
Power plug
Cord
Appliance plug
Accessories
DTravel case
ECleaning brush
FOil
GSpecial detergent
(Detergent)
There may be water
droplets inside the self‑
cleaning recharger at the
time of purchase, but
there is no problem
regarding the hygiene.
They are remains after
the factory inspection.

12
English
Preparation
Charging the shaver
• Turn the shaver off.
• Wipe off any water droplets on the main body rear
terminals.
1 Insert the appliance plug
into the self-cleaning
recharger�
2 Remove the protective cap
while pressing the side of
the cap and insert the
shaver into the self-
cleaning recharger�
• Slowly insert the shaver into
the self‑cleaning recharger
taking care not to damage the
system outer foil.
3
1
2
3 Plug the adaptor into a household outlet�
• Check that the charge status lamp ( ) is glowing.
• Charging is completed after approx. 1 hour.
4 Disconnect the adaptor after charging is
completed�
Quick charge
Even though the battery runs out, you can shave
once after 3‑minute charge.
(This will differ depending on usage.)
While charging After charging is
completed
glows.
The number of the battery
capacity lamp will increase
as charging progresses.
“100%” appears and then
turns off after 5 seconds.
Notes
• When charging the shaver for the rst time or when it
has not been in use for more than 6 months, the
charging time may change or the charge status lamp
() may not glow for a few minutes. It will eventually
glow if kept connected.
• Recommended ambient temperature for charging is
10 °C – 35 °C. It may take longer to charge, or the
charge status lamp ( ) will blink quickly and the
battery may fail to charge properly in extremely high
or low temperatures.
• The shaver can be used for approximately 2 weeks
with a full charge.
(Based on one 3‑minute dry‑shave usage per day in
an ambient temperature range of 20 °C – 30 °C.)
The number of usable days varies depending on the
following conditions.
‑ Beard thickness
‑ Pressure applied to the skin
‑
Usage frequency of the sonic vibration cleaning mode

13
English
• If there is noise from the radio or other sources while
using or charging the appliance, move to a different
location to use the appliance.
Charging without the self-cleaning recharger
• Turn the shaver off.
• Wipe off any water droplets on the appliance socket.
1 Insert the appliance plug
into the shaver�
2 Plug the adaptor into a
household outlet�
3
Disconnect the adaptor
after charging is completed�
1
2
Note
You cannot operate the shaver while charging.
Preparing the cleaning liquid
Cleaning can start right after the usage by preparing in
advance.
(See page 16.)
• Remove the AC adaptor from the self‑cleaning recharger.
1
Press the cleaning
liquid unit removal
button ( 1 ) and
remove the cleaning
liquid unit ( 2 ) on a
hard, at surface.


• When the self‑cleaning recharger is lifted, or on
the soft surface such as carpets, the lock release
lever will not t in the recharger properly. In that
case, the cleaning liquid unit cannot be removed.
2 Pour tap water (1)
and detergent (2)
into the cleaning
liquid unit�
• Be careful not to let the
water rise above the
maximum water line (
a ).
• Pour the entire packet
of detergent.
 

3 Slowly insert the
cleaning liquid unit
into the self-
cleaning recharger
until it clicks�

14
English
Notes
• To replace the cleaning liquid, see page 20.
• Only use self‑cleaning recharger detergent for
Panasonic shavers.
Not doing so may cause malfunction or failure.
• Do not tilt the self‑cleaning recharger.
Doing so may cause spill or the number of days that
cleaning liquid can be used reduce.
• You can use the cleaning liquid for approximately
30 days if used once per day.
(This will differ depending on beard thickness and the
ambient temperature.)
How to use
This appliance has a smart lock function, so the power
switch is automatically locked to prevent accidental
operation when not shaving.
►Unlocking the power switch
The power switch is automatically
unlocked when the main body is grasped.
• The lamps glow and then turn off after
approximately 6 seconds.
►Locking the power switch
All the lamps turn off when
releasing the main body.
The lamps glow and the
power switch is
automatically locked after
1 minute.
• The switch lock lamp
() will light up for
6 seconds and turn off.
• The sensor may respond and the power switch may
be unlocked when an electrical device or metal object
is brought closer. This is not abnormal.
Shaving beard
1 Press and shave�
• The “shaving sensor”, which
automatically adjusts the power
depending on the beard thickness,
will operate.
It will shave with high power on areas
where the beard is heavy, and reduce
the power on areas where the beard
is thin, to reduce burden on the skin.

15
English
Tips for better shaving
Apply the whole system outer foil
perpendicularly against the skin
and shave by slowly gliding the
shaver over the face against the
grain of the beard.
• The beard under the chin and
around the throat can be shaved
better by stretching the skin so
the beard will stand.
• To prevent damaging the system
outer foil, do not shave with only
a part of the system outer foil.
2 Press when nished.
When the battery capacity is low
“5%” appears.
The appliance beeps twice after switched
off.
• You can shave 1 to 2 times after “5%”
appears. (This will differ depending on
usage.)
Notes
• The appliance may not operate in an ambient
temperature lower than approximately 5 °C.
• The shaving sensor may not respond depending on
the type and quantity of the shaving gel. This is not
abnormal.
• Depending on the beard thickness or the amount of
beard trimmings in the shaver head, the shaving
sensor may not react and the driving sound may not
change. This is not abnormal.
• To prevent erroneous operation, place your ngers on
the nger rest while using the shaver.
• The sonic vibration cleaning mode is activated when
the power switch is pressed for more than 2 seconds
while the shaver is not operating. (See page 17.)
You cannot shave in this mode.
►Using the trimmer
1.Slide the trimmer handle up to
the “ ” position so that the
trimmer stands upright.
2.Press and use.
Press and hold the top knob ( a )
and slide the trimmer handle
down to lower the trimmer.

Tips for better usage
Apply the trimmer edge perpendicular to skin gently
and move downward slowly.

16
English
Trimming sideburns Pre‑shave of long beards
►Switching the shaver head
You can change the pivot action.
“”
The shaver head is moved to
prevent missed spots.
“ ”
You can lock the shaver head.
Cleaning, drying, charging
We recommend cleaning the shaver after each use.
1 Insert the shaver into the
self-cleaning recharger
and plug the adaptor into
a household outlet� (See
page 12�)
• Check that the charge status
lamp ( ) is glowing.
• When the LOW lamp or the
STATUS lamp lights up, see
page 21.
1
2
1
2 Press �
The CLEAN lamp and the DRY lamp glow, and the
“AUTO” mode will start after approximately 6 seconds.
• It is not possible to change the mode after the
“AUTO” mode has started.
Clean
10 min
Dry
80 min*
Charge
0 to 60 min
*When the ambient temperature of the self‑cleaning
recharger is low (approx. 15 °C or lower), the
drying process will take up to 170 min.
3 Remove the adaptor after the selected
mode is completed�

17
English
Clean the shaver with water or with the
cleaning brush once per month. (See
pages 17 to 19.)
The main unit neck section (a), trimmer,
system outer foil gaps, etc. cannot be
cleaned with the self‑cleaning recharger.

Changing the mode of self-cleaning recharger
The “Charge” mode starts when attaching the shaver,
and the mode can be changed by pressing the
SELECT button.
Charge mode
(Charge)
AUTO mode
(Clean/Dry/
Charge)
Dry/Charge
mode
(Dry/Charge)
Notes
• Do not press the cleaning liquid unit removal button
during cleaning as the cleaning liquid may spill
causing a malfunction.
• The drying time may increase in an ambient temperature
approximately 15 °C or lower.
The Clean or Dry function may not operate under
extreme low temperatures (approximately 0 °C or lower).
• A lubricant constituent is included in the detergent, so
smooth shave is maintained without applying oil.
Cleaning thoroughly
Cleaning with water
• Turn the shaver off and disconnect the AC adaptor.
1 Apply some hand soap and
some water to the system
outer foil�
2 Press for more than
2 seconds to activate the
sonic vibration cleaning
mode�
• Splashing of foam is
suppressed.
• The lamps blink alternately.
• After about 20 seconds, it will be automatically
turned off, or you can turn it off by pressing the
power switch.
3 Remove the outer foil
section and clean with
running water�
• See page 19 for removing
the outer foil section.
• Splashing is reduced by rinsing the shaver in sonic
vibration cleaning mode.

18
English
• After rinsing with water, shake the shaver up and
down for a few times to remove excess moisture and
then wipe off any drops of water with a dry cloth.
4 Attach the outer foil
section and dry with the
self-cleaning recharger�
1.Insert the shaver into the
self‑cleaning recharger and
plug the adaptor into a
household outlet.
• Check that the charge status
lamp ( ) is glowing.
2.Press twice.
The DRY lamp glows, and the “Dry/Charge”
mode will start after approximately 6 seconds.
• It is possible to change to the “AUTO” mode
even after the “Dry/Charge” mode has started.
Dry
180 min
Charge
0 to 60 min
3.Remove the adaptor after the selected mode is
completed.
5 Lubricate the shaver�
It will keep the movement of the
blades smooth and maintain a
comfort shave.
1.Apply one drop of oil to each of
the system outer foils.
2.Raise the trimmer and apply a drop of oil.
1
2
1
3.Switch the shaver on, and run it for approximately
ve seconds.
4.Switch off the shaver, and wipe off any excess oil
from the system outer foil with a soft cloth.
►Drying the shaver without the self-cleaning recharger
Dry in a shade and apply oil.
Notes
• Do not use any kitchen or bathroom detergents other
than hand soap.
Doing so may cause malfunction.
• Be careful not to hit the main body on the sink or any
other object while draining the water. Failure to do so
may cause malfunction.
• Do not wipe with thinners, benzine, alcohol etc.
Doing so may cause malfunction, cracking or
discoloration of the parts.
Wipe with diluted soapy water.
• Do not use the self‑cleaning recharger while droplets or
soap remain on the shaver.
Doing so may change the concentration level or
composition of the cleaning liquid in the cleaning liquid
unit, which may degrade cleaning, sterilization,
lubrication and drying performance. This may also cause
cleaning liquid to spill from the self‑cleaning recharger.

19
English
Cleaning with the brush
Remove the outer foil section.
(See this page.)
Clean the system outer foil in the areas
indicated by the circles every time you
use the shaver. Otherwise, abnormal
sound may be generated.
►Cleaning with the long brush
Clean the foil frame, system
outer foil, the main body
and the trimmer using the
long brush.
Replacing the system outer foil
appears on the lamp display once every 18 months.
(Based on one 3‑minute shave use per day)
We recommend checking the system outer foil when it
appears.
Press the power switch for more than 30 seconds to
turn off .
Even if is not turned off right after the replacement, it
will automatically turn off within approximately 7 uses.
system outer foil once every 18 months
►Removing the outer foil section
Press the foil frame release buttons and
lift the outer foil section upwards.
►Attaching the outer foil section
After turning the foil frame mark ( ) to the
front, securely attach the outer foil section
to the shaver until it clicks.
►Replacing the system outer foil
1.Press the system outer foil release
buttons and pull down the system
outer foil.
• Do not press the system outer foil
release buttons with excessive
force.
Doing so may bend the system outer foil, preventing
complete attachment to the foil frame.
2.
Align the foil frame mark ( ) and the system outer foil
mark ( ) and securely attach together until it clicks.
Note
Do not throw away the foil frame.

20
English
Replacing the cleaning liquid
If the STATUS lamp glows for 5 seconds when the
SELECT button is pressed, the cleaning liquid needs to
be replaced.
• Even if the STATUS lamp does not light up, replace
the cleaning liquid after 6 months have passed.
1 Remove the AC adaptor and
remove the cleaning liquid unit�
(See page 13�)
2 Wash away the old cleaning
liquid�
• It can be drained as sewage.
1
3 Rinse the cleaning liquid unit�
• Pour water as illustrated while tilting the
cleaning liquid unit and shaking it gently.
• You can clean with the cleaning liquid
lter removed.
After washing, be sure to attach the
cleaning liquid lter.
4 Gently wipe off any beard
trimmings attached to the
inside of the cleaning tray
(a) with a cloth or tissue
paper dampened with water�
• Clean the corners and uneven
parts of the cleaning tray with a
cotton swab dampened with water.

5 Prepare the new cleaning liquid�
(See page 13�)
The symbol on the left means “Do not
wash the self‑cleaning recharger with
water”.
Notes
• The cleaning liquid will decrease every time it is used,
but do not add detergent and water except when
replacing the cleaning liquid.
Doing so may deteriorate the cleaning function.
• Do not wash the self‑cleaning recharger unit with water.
• Do not wipe with thinners, benzine, alcohol etc.
Doing so may cause malfunction, or cracking or
discoloration of the parts.
Wipe with diluted soapy water.
►When the water does not drain from the cleaning tray
• Do not tilt the self‑cleaning recharger to pour out
water. Doing so may cause the cleaning liquid in the
cleaning liquid unit to spill or cause the self‑cleaning
recharger to malfunction.
