Panasonic ES4036 User manual

Operating Instructions
AC/Rechargeable Shaver
Model No.
ES4036
Before operating this unit, please read these instructions completely.
P00-35.ES4036(Asia)  2008.2.29 11:00  ページ1

2
1
A
B
C
G
H
D
E
F
3
2
J
˛I
˛N
˛M
charge
status
K
˛L
P00-35.ES4036(Asia)  2008.2.29 11:00  ページ2

3
6
7
4
5
P00-35.ES4036(Asia)  2008.2.29 11:00  ページ3

Index
ENGLISH Page 5
22
30
14
4
ab
i
fe
g
c
d
h
j
8 9
10
(A) (B)
P00-35.ES4036(Asia)  2008.2.29 11:00  ページ4

5
Safety Instructions
To ensure proper operation of the appliance, please carefully read all
information contained in these Safety Instructions.
All information in this section is provided to instruct you in the correct
and safe operation of this appliance so that you can avoid injuries to
yourself and others as well as damage to property.
Safety warnings, cautions and precaution symbols are distinguished
as follows.
ALWAYS FOLLOW THESE IMPORTANT SAFETY PRECAUTIONS!
WARNING:This message indicates potentially hazardous actions
and situations, which, if not avoided, could result in
death or serious injury.
CAUTION: This message indicates potentially hazardous actions
and situations, which, if not avoided, could result in
personal injury or property damage.
Safety Precautions Symbols
A circle and slash symbolizes prohibited actions and
behaviors
A solid circle denotes mandatory actions and
instructions to be followed for safe operation
After reading these safety instructions, ensure they are kept in a
place allowing easy viewing at all times by the appliance user.
WARNING!
CAlways turn off the power switch and unplug
the power cord/adaptor from the power outlet
before cleaning and maintenance.
Never plug in or unplug the appliance when
hands are wet.
Failure to disconnect the plug can result in electric
shock or personal injury.
Unplug!
CAlways ensure the appliance is operated on an
electric power souce matched to its rated
voltage.
Failure to do so can result in fire or electric shock.
Mandatory!
P00-35.ES4036(Asia)  2008.2.29 11:00  ページ5

6
WARNING!
CRegularly clean the cord connector, which
plugs into the appliance, to keep it free of dust
and foreign objects such as pins, etc.
Failure to do so could result in deterioration of the
electrical insulation and cause fire.
Mandatory!
CNever operate the appliance if the cord or
adaptor are damaged or overly hot, or if the
plug fits loosely in the power outlet.
Doing so could result in short-circuiting, electric
shock or fire.
CDo not modify the cord or damage it in any way
such as by bending, twisting or pulling on it
unnecessarily.
Doing so could result in electric shock or fire.
CDo not clean with water when the shaver is
connected to the power cord.
Doing so could result in electric shock.
Prohibited!
CDo not attempt to modify, repair, or in any way
dismantle the appliance, other than when
discarding it at the end of its useful life.
Doing so could result in fire, electric shock or
mechanical malfunction.
For repairs and servicing, please consult the place
of purchase or a customer service center
designated by the manufacture.
Do not
dismantle!
C Do not allow the power cord to be immersed in,
splashed with, or rinsed under water.
Doing so could result in electric shock or short-
circuiting.
Avoid water
contact!
P00-35.ES4036(Asia)  2008.2.29 11:00  ページ6

7
CAUTION!
CBefore use, always make sure that the outer
foil has not become damaged or misshapen.
Failure to do so can cause damage to skin.
CDry the shaver completely before charging it.
Failure to do so could result in short-circuiting,
electric shock or fire.
CGrip the plug when disconnecting the power
cord from a receptacle; tugging on the cord
may damage it.
CDo not use other AC adaptors or power cords
to supply power to the appliance. Also, do not
use the included power cord to supply power
to other electrical products.
Doing so may result in electric shock, short-circuit,
or fire.
CAlways use your shaver for its intended use,
as described in this manual.
Failure to do so can cause personal injury or
mechanical malfunction.
CDo not allow the appliance to used by, on, or
near children.
Doing so could result in burns, electric shock or fire.
Mandatory!
CDo not apply excessive pressure to the outer
foil.
Doing so may break the foil, resulting in scratching
of the skin.
CWhen cleaning the shaver or changing the
blades, be sure to set the power switch off.
Failure to do so may result in injury.
Prohibited!
P00-35.ES4036(Asia)  2008.2.29 11:00  ページ7

8
CAUTION!
CDo not use under the following circumstances.
APeople with sensitive skin or skin which is
easily irritated.
AAllergic constitution
AIf there are pimples or bumps on the skin:
Doing so can cause damage to skin.
Prohibited!
NOTICE
CDo not leave the appliance in places where it
will be exposed to high temperatures or direct
contact with sunlight.
Doing so can cause mechanical malfunction.
CDo not wipe any part of the shaver with
thinner, benzine or alcohol.
Clean it by using a cloth dampened with soapy water.
CDo not leave the shaver in direct sunlight to
dry with the outer foil removed.
Doing so may cause deterioration of the
waterproof seal, which could result in malfunction.
CWash the shaver in tap water. Do not use salt
water or boiling water. Also, do not use
cleaning products that are designed for toilets,
bathrooms or kitchen appliances. Do not
submerge the shaver for a long time.
CDo not charge the shaver where the
temperature is below 0°C (32° F) or above 40°C
(104°F), where it will be exposed to direct
sunlight or a heat source, or where there is a
lot of moisture.
CUse only the included shaver power cord RE7-
22 to charge the ES4036 shaver.
CDry the shaver completely before charging it.
P00-35.ES4036(Asia)  2008.2.29 11:00  ページ8

9
NOTICE
C Keep the power cord away from water and handle
it only with dry hands. Do not use an extension
cord to connect the power cord to an outlet.
CThe shaver may not immediately begin to
charge after being placed into the power cord
after use. Allow the shaver to sit in the power
cord for a few minutes and check again to
make sure that it is being charged.
CStore the power cord in a dry area where it will
be protected from damage.
CThe outer foil is very thin. If handled
improperly, it can be easily damaged. To avoid
personal injury, do not use the shaver if it has
a damaged foil or inner blade.
CDo not take the housing apart as this can affect
the watertight construction.
C
Do not pull, twist, or severely bend the power cord.
CDo not wrap the power cord tightly around the
appliance.
P00-35.ES4036(Asia)  2008.2.29 11:00  ページ9

Usi
(see
Slide
the t
Plac
your
trim
Cle
(see
The f
shav
hand
wate
For c
reco
shav
soap
shav
vent
oping
perfo
With
som
Turn
wate
After
shav
Rem
Wa
sho
nec
sha
bef
10
Parts identification
(see fig. 1)
Protective cap
Outer foil
Outer foil release buttons
Foil frame
Inner blades
Foil frame release buttons
!On/Off switch
"Charge status lamp
#Trimmer
$Trimmer handle
%Adaptor
&Power cord
'Cleaning brush
(Travel pouch
Charging and cordless
shaving
(see fig. 2)
When charging the shaver for the first
time or when it has not been in use
for more than 6 months, charge it for
the activation for at least 8 hours
before use.
Connect the power cord to the
shaver, and plug the adaptor to an
AC outlet.
It will adjust automatically to the AC
voltages which are indicated on the
charging adaptor nameplate.
In some areas, a special plug adap-
tor may be required.
The charge status lamp will glow
when the shaver is being charged. It
will flash when the charging is com-
pleted.
You can fully charge the shaver in 1
hour if it seems to be losing speed.
A full charge will supply enough
power for approx. 12 shaves (3 min-
utes per shave for a normal beard).
Cord shaving
Connect the shaver to the power
cord and plug the adaptor to the AC
outlet, then turn the shaver on.
If the shaver does not run, charge it
for approx. 1 minute.
Using your shaver
Depress the switch lock button and
slide the On/Off switch upward to turn
the shaver on. Hold the shaver at a
right angle (90°) to your skin (see fig.
3). Start out shaving by applying gen-
tle pressure to your face. Stretch your
skin with your free hand and move the
shaver back and forth in the direction
of your beard. You may gently
increase the amount of pressure as
your skin becomes accustomed to this
shaver. Applying excessive pressure
does not provide a closer shave, or
may cause injury of your skin, espe-
cially to the earlier user.
10
