Panasonic ES8046-A3 User manual

1 SCHEMATIC DIAGRAM 2
2 DISASSEMBLY INSTRUCTIONS 3
3 ASSEMBLY INSTRUCTIONS 5
©2005 Matsushita Electric Works, Ltd. All rights
reserved. Unauthorized copying and distribution is a
violation of law.
ES8046-A3
ES8047-A3
4 TROUBLESHOOTING GUIDE 7
5 EXPLODED VIEW & REPLACEMENT PARTS LIST 9
AC/Rechargeable Shaver
SPECIFICATIONS
Power source
A
C 100-240V, 50-60Hz (Automatic voltage conversion)
Power consumption
A
pprox. 7W ( at AC drive)
Motor voltage 3.6V DC
Charging time 1 Hour
Shaves per charge 14 times (3 minutes shave)
Measurement (H)15.3 x (W)6.2 x (D)4.6 cm
Weight 180g
Supplied accessories Soft case
Cleaning brush
Charging stand
CONTENTS
Page Page
ORDER NO. SD0506A39C3

1 SCHEMATIC DIAGRAM
1.1. ES8046
1.2. ES8047
2
ES8046-A3 / ES8047-A3

Follow the procedure below to disassemble the main unit.
1. Remove the cap, the outer foil with foil frame and the
inner blade.
2. To remove the trimmer driving bar or the slit blade
driving bar, press bars outward.
3. Loosen a screw and remove the bottom cover. Set the
pivot action selector to "LOCK". Slide the rear panel and
remove it with care of pivot action selector.
4. Remove the both side of housing clips.
Loosen four screws and remove housing B.
Take out the lock lever shaft.
5. Slide the trimmer handle up to open the trimmer and
unhook 2 locations on both side by inserting the slit with
something like a slotted-head screw driver.
2 DISASSEMBLY INSTRUCTIONS
3
ES8046-A3 / ES8047-A3

6. Remove trimmer and trimmer handle.
7. Move gently the linear motor assembly down and
unhook it and remove the float springs from housing A.
8. Pull up the battery and chassis block from the linear
motor side first. Then, slide it upward and take it out
from the housing A.
NOTE:
Do not pull the battery and chassis block forcefully
due to connecting the linear motor by the lead wires.
9. Take out the battery from the chassis.
10. Unsolder the lead wires from the module.
4
ES8046-A3 / ES8047-A3

1. Solder the lead wires with the module.
NOTE:
Make sure of the color of lead wires.
2. Make sure that the lead wires set in position. Install (+)
terminal of battery into the terminal plate at the linear motor
side and firmly set the battery sliding the direction of arrow.
NOTE:
Fix the lead wires with the adhesive tape.
3. When inserting the battery and module assembly into the
housing A, confirm if the module does not get any damage
or deformation.
4. In case of trimmer is removed;
Make sure if the bosses of handle arm insert into the holes
of trimmer. Align the bosses of housing with the holes of
trimmer, and hook the trimmer. Then, slide the trimmer up
and hook the both sides of trimmer handle.
NOTE:
Confirm its operation or smooth movement of trimmer.
5. Set the linear motor assembly on the housing A and sliding
it upward to hook. Confirm that the lead wire tube fits to the
housing A firmly and no foreign substance sticking around.
Attach the head block to housing A with care of the
direction. And attach the rock lever shaft to housing B.
6. When putting the housing A and the housing B together,
make sure if the waterproof seal must be fitted properly and
no foreign substance sticking around.
3 ASSEMBLY INSTRUCTIONS
NOTE: When reassembling, replace the new waterproof rubber.
Make sure whether there is NO foreign substance sticking around a part covered with waterproof seal.
5
ES8046-A3 / ES8047-A3
