Panasonic KX-FLM551 Operating and installation instructions

This document is a text description of the control panel
layout for the product listed below.
“PDF” files of the complete operating instructions are
available from the Customer Support section of
www.Panasonic.com.
If you need the operating instructions in an alternate
format, please request it from Customer Support.
Multi-Function Laser Fax
Model Number KX-FLM551
Finding the Controls
The control panel of the unit is divided into three equal parts: left, middle and right.
Left part:
This part contains the telephone keypad laid out in the conventional telephone arrangement with a “nib”
on the 5 button. Below the keypad are four circular buttons in a horizontal row: from left to right,
REDIAL, HANDSET MUTE, FLASH and MONITOR. The REDIAL button is also the PAUSE button.
Middle part:
At the top middle part of the panel is a smooth surface. This is the display. Immediately below the display
is the ONE-TOUCH LABEL CARD, which has three rectangular buttons each, in a vertical row at both
ends. Below this card are three circular buttons in a horizontal row: from left to right, HELP,
DIRECTORY PROGRAM and MENU. Below these buttons are two more circular buttons: the left one is
the CALLER ID PRINT button and the right one is the CALLER ID SEARCH button. Immediately
below the CALLER ID PRINT button is the NAME and TELEPHONE NUMBER button. To the right of
these buttons is the JOG DIAL, a large circular dial that clicks as it rotates. Each click indicates one jog
step.
Right part:
Just to the right of the display, the half-moon shaped button is the AUTO ANSWER button. To the right
of this button is the COPY ZOOM button, this can be pressed in up and down positions which are PLUS
or MINUS keys respectively. These are also the VOLUME control increase and decrease keys. Below this
button are three small buttons in a horizontal row: from left to right, COLLATE, RESOLUTION and

QUICK SCAN START. Immediately below these buttons is a button marked with an indented page icon.
This is the COPY START button. Below this is a button marked with an indented triangle. This is the
STOP button. To the right below the COPY START button, there is a button with a “nib”, marked with an
indented diamond. This is the FAX START button, which is also the SET button.
PFQW1627ZA October 2, 2001
September 24, 2002 Revised
