Panasonic SC-XH385GA User manual

© Panasonic Corporation 2014
Unauthorized copying and distribution is a violation of law.
ORDER NO.AD1404025CE
DVD Home Theater Sound System
Model No. SC-XH385GA
SC-XH385GS
SA-XH385GA
SA-XH385GS
Color: (K)...........Black Type
Notes: Please refer to the original service manual for:
• Speaker system SB-HFS4810/HC4010 Order No:AD1403015CE
SB-HW6010 Order No:AD1404027CE
SB-HFS4810
SB-HC4010
SB-HW6010
SA-XH385
Remote
Control

2
TABLE OF CONTENTS
PAGE
1 Safety Precautions ------------------------------------------------3
1.1. General Guidelines ------------------------------------------3
1.2. Leakage Current Cold Check ------------------------------3
1.3. Leakage Current Hot Check (See Figure 1.) ----------3
1.4. Protection Circuitry -------------------------------------------3
2 Warning ---------------------------------------------------------------4
2.1. Prevention of Electrostatic Discharge (ESD)
to Electrostatically Sensitive (ES) Devices ------------4
2.2. Caution for AC Cord (For the Saudi Arabia,
Kuwait and Africa) --------------------------------------------5
2.3. Precaution of Laser Diode ---------------------------------6
2.4. Static Electricity Protection Measures ------------------7
2.5. Ground for Electrostatic Breakdown
Prevention ------------------------------------------------------7
3 Service Navigation ------------------------------------------------8
3.1. Service Information ------------------------------------------8
3.2. How to Update Firmware -----------------------------------8
4 Specifications ----------------------------------------------------- 10
4.1. Others (Licences) -------------------------------------------11
5 Location of Controls and Components ------------------- 12
6 Installation Instructions ---------------------------------------- 14
6.1. Speaker Connections -------------------------------------- 14
6.2. Connection to a TV ----------------------------------------- 14
6.3. FM Antenna Connection ---------------------------------- 14
7 Operating Instruction ------------------------------------------- 15
7.1. Take out the Disc from Drive Unit when the
Disc cannot be ejected by the OPEN/CLOSE
button ---------------------------------------------------------- 15
8 Troubleshooting Guide ----------------------------------------- 16
8.1. About Operation of Set ----------------------------------- 16
8.2. About Circuit-------------------------------------------------- 17
9 Wiring Connection and Voltage Data ---------------------- 21
10 Disassembly and Assembly Instructions --------------- 23
11 Replacement Parts List and Exploded View ----------- 27
11.1. Replacement Parts List ---------------------------------- 27
11.2. Casing Parts & Mechanism Section ------------------ 28
11.3. Packing & Accessories Section ------------------------ 29

3
1 Safety Precautions
1.1. General Guidelines
1. IMPORTANT SAFETY NOTICE
There are special components used in this equipment which are important for safety. These parts are marked by in the
Exploded Views and Replacement Parts List. It is essential that these critical parts should be replaced with manufacturer’s
specified parts to prevent X-RADIATION, shock, fire, or other hazards. Do not modify the original design without permission
of manufacturer.
2. An Isolation Transformer should always be used during the servicing of AC Adaptor whose chassis is not isolated from
the AC power line. Use a transformer of adequate power rating as this protects the technician from accidents resulting in
personal injury from electrical shocks. It will also protect AC Adaptor from being damaged by accidental shorting that may
occur during servicing.
3. When servicing, observe the original lead dress. If a short circuit is found, replace all parts which have been overheated or
damaged by the short circuit.
4. After servicing, see to it that all the protective devices such as insulation barriers, insulation papers shields are properly
installed.
5. After servicing, make the following leakage current checks to prevent the customer from being exposed to shock hazards.
1.2. Leakage Current Cold Check
1. Unplug the AC cord and connect a jumper between the two prongs on the plug.
2. Measure the resistance value, with an ohmmeter, between the jumpered AC plug and each exposed metallic cabinet part on the
equipment such as screwheads, connectors, control shafts, etc. When the exposed metallic part has a return path to the chassis,
the reading should be between 1MΩand 5.2MΩ. When the exposed metal does not have a return path to the chassis, the
reading must be infinity.
1.3. Leakage Current Hot Check (See Figure 1.)
1. Plug the AC cord directly into the AC outlet. Do not use an isolation transformer for this check.
2. Connect a 1.5kΩ, 10W resistor, in parallel with a 0.15μF capacitor, between each exposed metallic part on the set and a
good earth ground, as shown in Figure 1.
3. Use an AC voltmeter, with 1 kΩ/V or more sensitivity, to measure the potential across the resistor.
4. Check each exposed metallic part, and measure the voltage at each point.
5. Reverse the AC plug in the AC outlet and repeat each of the above measurements.
6. The potential at any point should not exceed 0.75V RMS. A leakage current tester (Simpson Model 229 or equivalent) may
be used to make the hot checks, leakage current must not exceed 1/2 mA. In case a measurement is outside of the limits
specified, there is a possibility of a shock hazard, and the equipment should be repaired and rechecked before it is returned
to the customer.
1.4. Protection Circuitry
The protection circuitry may have operated if either of the following conditions are noticed:
• No sound is heard when the power is turned on.
• Sound stops during a performance.
The function of this circuitry is to prevent circuitry damage if, for example, the positive and negative speaker connection wires
are “shorted”, or if speaker systems with an impedance less than the indicated rated impedance of the amplifier are used.
If this occurs, follow the procedure outlines below:
1. Turn off the power.
2. Determine the cause of the problem and correct it.
3. Turn on the power once again after one minute.
Note:
When the protection circuitry functions, the unit will not operate unless the power is first turned off and then on again.
Figure. 1

4
2 Warning
2.1. Prevention of Electrostatic Discharge (ESD) to Electrostatically
Sensitive (ES) Devices
Some semiconductor (solid state) devices can be damaged easily by static electricity. Such components commonly are called
Electrostatically Sensitive (ES) Devices.
Examples of typical ES devices are IC(integrated circuits)and some field-effect transistors and
semiconductor “chip” components.
The following techniques should be used to help reduce the incidence of component damage caused by electrostatic
discharge(ESD).
1. Immediately before handling any semiconductor component or semiconductor-equipped assembly, drain off any ESD
on your body by touching a known earth ground. Alternatively, obtain and wear a commercially available discharging
ESD wrist strap, which should be removed for potential shock reasons prior to applying power to the unit under test.
2. After removing an electrical assembly equipped with ES devices, place the assembly on a conductive surface such as
aluminum foil, to prevent electrostatic charge buildup or exposure of the assembly.
3. Use only a grounded-tip soldering iron to solder or unsolder ES devices.
4. Use only an antistatic solder removal device. Some solder removal devices not classified as "antistatic (ESD protected)"
can generate electrical charge sufficient to damage ES devices.
5. Do not use freon-propelled chemicals. These can generate electrical charges sufficient to damage ES devices.
6. Do not remove a replacement ES device from its protective package until immediately before you are ready to install it.
(Most replacement ES devices are packaged with leads electrically shorted together by conductive foam, aluminum foil
or comparable conductive material).
7. Immediately before removing the protective material from the leads of a replacement ES device, touch the protective
material to the chassis or circuit assembly into which the device will be installed.
CAUTION :
Be sure no power is applied to the chassis or circuit, and observe all other safety precautions.
8. Minimize bodily motions when handling unpackaged replacement ES devices. (Otherwise harmless motion such as the
brushing together of your clothes fabric or the lifting of your foot from a carpeted floor can generate static electricity (ESD)
sufficient to damage an ES device).

5
2.2. Caution for AC Cord
(For the Saudi Arabia, Kuwait
and Africa)
2.2.1. Information for Your Safety
IMPORTANT
Your attention is drawn to the fact that recording of
prerecorded tapes or discs or other published or broadcast
material may infringe copyright laws.
WARNING
To reduce the risk of fire or shock hazard, do not expose
this equipment to rain or moisture.
CAUTION
To reduce the risk of fire or shock hazard and annoying
interference, use the recommended accessories only.
FOR YOUR SAFETY
DO NOT REMOVE THE OUTER COVER
To prevent electric shock, do not remove the cover. No
user serviceable parts inside. Refer servicing to qualified
service personnel.
2.2.2. Caution for AC Mains Lead
For your safety, please read the following text carefully.
This appliance is supplied with a moulded three-pin mains
plug for your safety and convenience.
A 5-ampere fuse is fitted in this plug.
Should the fuse need to be replaced please ensure that the
replacement fuse has a rating of 5 amperes and it is
approved by ASTA or BSI to BS1362.
Check for the ASTA mark or the BSI mark on the body of the
fuse.
If the plug contains a removable fuse cover you must ensure
that it is refitted after the fuse is replaced.
If you lose the fuse cover, the plug must not be used until a
replacement cover is obtained.
A replacement fuse cover can be purchased from your local
Panasonic Dealer.
If the fitted moulded plug is unsuitable for the socket outlet in
your home then the fuse should be removed and the plug cut
off and disposed of safety.
There is a danger of severe electrical shock if the cut off plug
is inserted into any 13-ampere socket.
If a new plug is to be fitted please observe the wiring code as
shown below.
If in any doubt, please consult a qualified electrician.
2.2.2.1. Important
The wires in this mains lead are coloured in accordance with
the following code:
Blue Neutral
Brown Live
As the colours of the wires in the mains lead of this
appliancemay not correspond with the coloured markings
identifying the terminals in your plug, proceed as follows:
The wire which is coloured BLUE must be connected to
the terminal in the plug which is marked with the letter N or
coloured BLACK.
The wire which is coloured BROWN must be connected to
the terminal in the plug which is marked with the letter L or
coloured RED.
Under no circumstances should either of these wires be
connected to the earth terminal of the three pin plug, marked
with the letter E or the Earth Symbol.
Earth Symbol
2.2.2.2. Before Use
Remove the Connector Cover as follows:
2.2.2.3. How to Replace the Fuse
1. Remove the Fuse Cover with a screwdriver.
2. Replace the Fuse and attach the Fuse cover.

6
2.3. Precaution of Laser Diode
CAUTION :
This product utilizes a laser diode with the unit turned “on”, invisible laser radiation is emitted from the pick-up lens. Wave
length:770 to 800 nm (CDs)/645 to 660 nm (DVDs) Maximum output radiation power from pick-up:100 μW/VDE Laser
radiation from the pick-up lens is safety level, but be sure the followings:
1. Do not disassemble the optical pick-up unit, since radiation from exposed laser diode is dangerous.
2. Do not adjust the variable resistor on the pick-up unit, it was already adjusted.
3. Do not look at the focus lens using optical instruments.
4. Recommend not to look at pick-up lens for a long time.
CAUTION INVISIBLE LASER RADIATION WHEN OPEN
DO NOT STARE INTO BEAM.
DANGER INVISIBLE LASER RADIATION WHEN OPEN
AVOID DIRECT EXPOSURE TO THE BEAM.
Back of unit
Caution !
This unit utilizes a laser. Use of controls or adjustments or
performance of procedures other than those specified herein may
result in hazardous radiation exposure.

7
2.4. Static Electricity Protection Measures
• The laser diode in the traverse unit (optical pick-up) may break down due to potential difference caused by static electricity
of clothes or human body.
So, be careful of electrostatic breakdown during repair of the traverse unit (optical pick-up).
2.5. Ground for Electrostatic Breakdown Prevention
• As for parts that use optical pick-up (laser diode), the optical pick-up is destroyed by the static electricity of the working
environment.
Repair in the working environment that is grounded.
2.5.1. Work table grounding
• Put a conductive material (sheet) or steel sheet on the area where the traverse unit (optical pick-up) is placed, and ground
the sheet.
2.5.2. Human body grounding
• Use the anti-static wrist strap to discharge the static electricity from your body.
2.5.3. When exchanging the Drive
• Before remove the ESD prevention bag, make sure to use the anti-static wrist strap to discharge the static electricity when
replace the Drive.
Note:
The ESD prevention bag is used to replace the original short-circuit point.
It can be removed while placing the Drive.

8
The firmware of the DVD Theater may be renewed to improve the quality including operational performance and playability.
Make sure to refer the following procedure when performing version-up.
Step 1 Check the software version currently installed in your DVD Theater.
1. Open the disc tray.
2. Press the number button [6] on the remote control four times, then the software version number will appear.
Step 2 Download and depress the latest software.
1.The latest firmware required for version-up can be downloaded from “Support Information
from NWBG/VDBG-PAVC” web-site in “TSN system”.
Click file name to download.
2.Decompress the downloaded file.
Click file to decompress.(Total:1file)
The decompressed file will be named as below.(Confirm the model No.)
File Name: PANASONIC_HTSXXX.BIN
(300W Model: PANASONIC_HTS105.bin; 1000W Model: PANASONIC_HTS333.bin)
Step 3 Burn all files to a blank CD-R disc or USB memory device by the writing software.
Use only CD-R or USB memory device.
(Burning method to CD-R disc is not image data writing but normal data writing.)
Step 4 Playback the CD-R disc or USB memory device by the DVD Theater.
3 Service Navigation
3.1. Service Information
This service manual contains technical information, which allow service personnels to understand and service this model.
Please place orders with the part numbers in the parts list, not the numbers in the exploded views. If the circuit is changed or
modified, the information will be followed by service manual to be controlled with original service manual.
Note:
The replacement parts of this model is supplied as block unit.
Please use Troubleshooting Guide for your reference of the repair.
3.2. How to Update Firmware
Current Firmware Version
Firmware Version Information Screen

9
Set the CD-R disc or USB memory device into the DVD Theater and playback it.
Step 5 Software update is completed.
When the message of recommending the
“Software Update” appears on the display
monitor, select the Left cursor button: [Yes] or
the Right cursor buttons :[No] and press the
[OK] button with the remote control.
If you choose the Left cursor buttons:
[Yes], the DVD Theater is automatically
updated.

10
4 Specifications
GENERAL
Power consumption Approx. 76 W
Power consumption in
standby mode
Approx. 0.5 W
Power supply AC 220 V to 240 V, 50 Hz/60 Hz
Dimensions (W
M
H
M
D) 430 mm M 55 mm M 322 mm
Mass Approx. 2.6 kg
Operating temperature
range
0QC to 40 QC
Operating humidity
range
35 % to 80 % RH
(no condensation)
LASER Specification Class 1 LASER Product
Wave length: 785 nm (CDs)/
655 nm (DVDs)
Laser power: No hazardous
radiation is emitted with the
safety protection
AMPLIFIER SECTION
RMS TTL POWER
OUTPUT
1000 W
1 kHz, 30 % total harmonic distortion
FRONT:
CENTRE:
SURROUND:
167 W per ch (4 j)
167 W (4 j)
167 W per ch (4 j)
63 Hz, 30 % total harmonic distortion
SUBWOOFER: 167 W (4 j)
Audio Input AUX M1
Digital Audio Input Optical M1
Sampling frequency:
32 kHz, 44.1 kHz, 48 kHz
Audio Format:
PCM, Dolby Digital, DTS®
* This unit supports “HDMI CEC” function.
MM
TERMINAL SECTION
USB slot USB2.0
1 system
Mic jack Mono, 6.3 mm jack (2 systems)
Bluetooth®SECTION
Bluetooth®Version 4.0
Class 2
2.4 GHz Band FH-SS
Supported Profile:
A2DP/AVRCP
Supported Codec:
SBC/AAC
FM TUNER SECTION
Frequency range 87.50 MHz to 108.00 MHz
(50 kHz step)
Antenna terminals 1 with Antenna Cable (1.2 m)
VIDEO SECTION
Signal system PAL/NTSC
Video output Output level:
1.0 Vp-p (75 j)
Output connector:
Pin jack (1 system)
HDMI AV output* Output connector:
Type A (19 pin) 1 system
pThe impedance of all the speakers is 4 j.
Specifications are subject to change without notice.
MM
pWith certain recording states and folder structures, the play
order may differ or playback may not be possible.
MM
File format
File format Extension Reference
Xvid
“.AVI”, “.avi”
p The video file and
subtitles text file are
inside the same folder,
and the file names are
the same except for
the file extensions.
p Some Xvid files may not
be played back correctly,
depending on the video
resolution, frame rate
condition, subtitle format
and so on.
[Except\South\East\Asia]
Subtitles text file
“.SRT”, “.srt”,
“.SUB”, “.sub”,
“.TXT”, “.txt”
FLV “.FLV”, “.flv” Some FLV/MOV files may
not be played back
correctly, depending on
the video resolution, frame
rate condition and so on.
MOV “.MOV”, “.mov”
JPEG “.JPG”, “.jpg”,
“.jpeg”
p MOTION JPEG and
Progressive JPEG are
not supported.
p You may not be able to
play back the file if you
have edited the folder
structure or the file name
on a PC or other device.
MP3 “.MP3”, “.mp3”
This unit supports ID3
tags, but only titles, artist
names and album
names can be displayed.
SPEAKER SECTION
Woofer
CONE TYPE
(cm)
Full range
CONE TYPE
(cm)
Super
tweeter
Piezo type
MM
Front L6.5 M1
Centre L6.5 M2
Surround L6.5 M1
Subwoofer 20 LL
MM
Dimensions
(W (mm)
M
H (mm)
M
D (mm))
Mass
(Approx. kg)
MM
Front 270 M1181 M270 2.7
Centre 304 M87 M77 0.7
Surround 270 M1181 M270 2.7
Subwoofer 232 M416 M319 6.3

11
4.1. Others (Licenses)
Manufactured under license from Dolby Laboratories.
Dolby, Pro Logic, and the double-D symbol are trademarks of Dolby
Laboratories.
For DTS patents, see http://patents.dts.com. Manufactured under
license from DTS Licensing Limited. DTS, the Symbol, & DTS and
the Symbol together are registered trademarks, and DTS
2.0+Digital Out is a trademark of DTS, Inc. © DTS, Inc. All Rights
Reserved.
This item incorporates copy protection technology that is protected
by U.S. patents and other intellectual property rights of Rovi
Corporation. Reverse engineering and disassembly are prohibited.
HDMI, the HDMI Logo, and High-Definition Multimedia Interface are
trademarks or registered trademarks of HDMI Licensing LLC in the
United States and other countries.
MPEG Layer-3 audio coding technology licensed from Fraunhofer
IIS and Thomson.
“DVD Logo” is a trademark of DVD Format/Logo Licensing
Corporation.
The Bluetooth®word mark and logos are owned by the Bluetooth
SIG, Inc. and any use of such marks by Panasonic Corporation is
under license.
Other trademarks and trade names are those of their respective
owners.

12
5 Location of Controls and Components
モヷ
リワヱヶヵ
モヶュリヰ
ンユヵヶンワ
ヵヰヱチヮユワヶ ヮユワヶ
ヱヨヮ
ヴロヰヸヴンュ ョンモヮユ
ュヷュ
ヴユヵヶヱ
ヶヴャ
ンモュリヰ ヮヶヵユ
ヤモワヤユロ
Ľ
ヴヰヶワュ
ヮリヤ ユヤラヰ
ユヹヵノリワ
6
1
2
3
4
5
9
10 141211
7 8 3
1815 1716 19 21
20
22
13

13
1[
¦
]
Turn the unit on and off
[
¦
TV]
Turn the TV on and off
[AV, INPUT]
Switch the input select of TV
2[]/[
L
PAIRING] (Bluetooth)
Select Bluetooth®/
Enable pairing (>11)
[DVD], [USB], [RADIO], [EXT-IN]
Select an audio or video source
[SETUP]
Show Setup menu (>15)
[AUDIO]
Change the audio channel number or
soundtrack language, etc.
[MUTE]
Mute the sound
p“MUtE” flashes on the unit’s display, while
the function is on.
pTo cancel, press the button again or adjust
the volume.
pMuting is cancelled if the unit is turned off.
[TV VOL
K L
]
Adjust the volume of TV
[VOL
K L
]
Adjust the volume of the main unit
3[

/

] (Play/Pause)
Start or pause playback
[
w
] (Stop)
Stops playback and remembers the resume
point (>10)
[

] / [

] (Skip)
Skip to the title, chapter or track
[

] / [

] (Search)
Start fast reverse or fast forward
4[TOPMENU]
Show Top Menu
[MENU]/[PGM]
Show Menu /
Register radio broadcasts (>12) /
Set the playback order of music tracks
Press [,,,] to select the item.
Press [0] to [9] to specify the order.
To cancel: Press [CANCEL].
Press [,,,] to select “PLAY”.
To clear the whole program:
Press [,,,] to select “CLEAR”.
Press [OK].

¦
¦
¦
L
KL
KL

w


[

,

,

,

]
Move the highlight for selection
[OK]
Confirm the selection
[OPTION]
Show Option menu (>14)
[RETURN ]
Return to previous screen
5 [SOUND]/[MIC]
Set the sound effects (>13) /
Adjust the microphone volume (>13)
[SRD]/[ECHO]
Set the surround effects (>14) /
Add the echo effect for the audio of
microphone (>13)
[SLOW]
Start slow motion playback
[FRAME]
Play video frame-by-frame
6Select title numbers, etc./Enter numbers
[CANCEL]: Cancel
7Open or close the disc tray (>10)
8Adjust the volume of the main unit
9 Standby/on switch (
¦
/I)
Press to switch the unit from on to standby
mode or vice versa. In standby mode, the unit
is still consuming a small amount of power.
10 Disc tray
11 Display
Unit’s display list (>21)
12 Remote control signal sensor
Distance: Within approx. 7 m.
Angle: Approx. 20 G up and down, 30 G left and right
13 Connect microphones (>13)
14 USB port (>10)
15 AC IN terminal
16 Speaker terminals
17 Cooling fan
18 VIDEO OUT terminal
19 AUX terminal
20 DIGITAL AUDIO IN terminal
21 HDMI AV OUT (ARC) terminal
22 FM radio antenna terminal
/
/

14
TV
LR
AUDIO OUT VIDEO IN OPTICAL OUT
or
6 Installation Instructions
Turn off all equipment before connection and read the appropriate operating instructions.
Do not connect the AC power supply cord until all other connections are completed.
6.1. Speaker Connections
Connect the speaker cables to the terminals of the same color.
6.2. Connection to a TV
HDMI
6.3. FM Antenna Connection
Affix this end of the antenna to a wall or
pillar where the reception is best.
Step 2
When the HDMI terminal of
your TV does not support ARC,
* ARC is an abbreviation of Audio Return
Channel, also known as HDMI ARC.
This feature allows a home theatre
system to receive and play audio from
the TV through a single HDMI cable
without additional wiring.
Audio Cable (Not supplied)
If you use an optional HDMI cable,
use the ARC* compatible High Speed
HDMI cables.
Non-HDMI-compliant cables cannot
be utilized. It is recommended that you
use Panasonic’s HDMI cable. When
outputting 1080p signal, please use
HDMI cables 5.0 meters or less.
Video Cable
(Not supplied)
Step 1
If the HDMI terminal of your TV supports ARC, skip Step 2.
HDMI Cable
or
TV
OPTICAL OUT
LR
AUDIO OUT VIDEO IN
or
or
Optical Digital
Audio Cable
(Not supplied)

15
7 Operating Instruction
7.1. Take out the Disc from the Drive Unit when the Disc cannot be ejected
by the OPEN/CLOSE button
7.1.1. When the Disc Eject can not be done.
1. Turn off the power and pull out the AC cord.
2. Put the unit upside down so that the bottom can be seen.
3. Insert the paper clip into the slot and slide the gear in the direction of the arrow to eject the tray slightly.
4. Put the unit upward, and pull out the tray.
Paper clip
Slot

16
8 Troubleshooting Guide
8.1. About Operation of Set
w
The images from this unit do not appear on
the TV.
Picture is distorted.
Jittering occurs.
¾The “Resolution” setting is incorrect or the
“TV System” setting of the unit and that of the
TV do not match.
LRestore the default settings following the
steps described in “To return all settings to
the factory preset.”. (>left)
¾PAL discs cannot be correctly viewed on an
NTSC TV.
¾If irregular colouring occurs on your TV, turn
the TV off for about 30 minutes.
If it persists, move the speakers further away
from the TV.
w
No sound.
Low volume.
Distorted sound.
Cannot hear the desired audio type.
¾Depending on the connected equipment, the
sound may be distorted if this unit is
connected with an HDMI cable.
¾The multi-channel audio from a device
connected to the TV is not output in it’s
original multi-channel form.
LIf the device has an optical audio output
terminal, connect the device to this unit’s
DIGITAL AUDIO IN terminal. (>7)
No sound from the TV.
¾If there is no sound from the equipment
connected to this unit’s DIGITAL AUDIO IN
terminal, please make sure that the optical
audio output of the equipment is set to PCM.
Sound
Disc cannot be played.
¾The disc is dirty. (>3)
Alternative subtitles cannot be selected.
¾You may not be able to use the Option menu
to change the subtitles on some discs. Use
the disc’s menus to make changes.
Pairing cannot be done.
¾Check the Bluetooth®device condition.
The device cannot be connected.
¾Try pairing the device again.
¾This system might be connected to a different
device. Disconnect the other device and try
pairing the device again.
The device is connected but audio cannot be
heard through this system.
¾For some built-in Bluetooth®devices, you
have to set the audio output to “Panasonic
XH” manually. Read the operating instructions
for the device for details.
The sound is interrupted.
¾The communication range is 10 m. Bring the
Bluetooth®device closer to the main unit.
¾Other devices that use the 2.4 GHz frequency
band (wireless router, microwaves, cordless
phones, etc.) are interfering. Bring the
Bluetooth®device closer to the main unit and
distance it from the other devices.
Playback
Bluetooth®
Distorted sound or noise is heard.
¾Adjust the position of the antenna.
A beat sound is heard.
¾Try to keep a certain amount of distance
between the antenna and the TV.
Error Disc
¾You inserted an incompatible disc.
¾The disc may be upside down.
This operation is not available.
¾Some operations are unsupported by the unit.
This list only contains displays that are difficult to read.
Radio
Messages on the screen
Unit’s display list
Display Reading Display Reading
OFF OPEN
LOAD MUTE
STOP SETUP
DISC USB
AUX OPT (Optical)
ERASE UPD (Update)
DONE
No DISC,
No PLAY,
No READ,
UNSUPPORT
ERR (Error)
BLUETOOTH
w
To return to the factory defaults.
¾Select “Restore” in “Default” in the Setup
menu. (>17)
To return all settings to the factory preset.
¾Reset the unit as follows:
Turn the unit on.
Press [] to open the disc tray.
Press and hold [w] and [/] on the main
unit at the same time for more than
5 seconds.
You have forgotten your ratings password.
You want to cancel the ratings level.
¾The ratings level returns to the factory defaults.
LRestore the default settings following the
steps described in “To return all settings to
the factory preset.”. (>above)
This unit does not recognize the USB
connection correctly.
¾Disconnect and re-connect the USB cable. If
it still does not recognize the connection, turn
this unit off and on again.
¾USB devices may not be recognized by this
unit when connected using the following :
La USB hub
La USB extension cable
¾If you connect USB HDD to this unit, use the
USB cable that is supplied with the HDD.
General operation

17
8.2. About Circuit
VOLTAGE DATA (measurement value)
*2
13.2V
211.2V
3GND
4GND
55V
65V
7GND
8GND
9GND
10 34V
11 34V
12 34V
*2
CHECK POINT LOCATION
*1
Symptom - 1 No Power
Check the AC cord.
(cutting or damage…etc)
Check the Power supply
P.C.B. Is the Fuse(F501) *1
break?
Check the Digital P.C.B.
connector (XP751) *2 voltage.
Exchange the Digital P.C.B.
Exchange the AC cord.
Exchange the Fuse.
Exchange the Power Supply P.C.B.
NG
OK
NG
NG
OK
OK
Before the syptom check remove the power cable and reinsert it after 10 sec. If the unit is still NG, please refer to
below syptoms.
1
1
12
12

18
Symptom - 2 No LED display /Keys do not work
Check the Digital P.C.B.
connector (XS4)*3
voltage.
Check the FFC cable *4
connecting Digital P.C.B. and
Front panel P.C.B.
Exchange the Front panel P.C.B.
Exchange the Digital P.C.B.
Exchange the FFC cable.
OK
OK
NG
NG
*3
CHECK POINT LOCATION
*4
VOLTAGE DATA (measurement value)
*3
13.3V 13 3.1V
23.3V 14 3.3V
3GND 15 5V
40V 16 5V
50V 17 11.1V
60V 18 GND
7GND 19 0V
83.3V 20 GND
9GND 21 0V
10 3.3V 22 GND
11 1.2V 23 2.6V
12 0.5V 24 3.3V
1
1
24
24

19
Symptom - 3 Can not OPEN or CLOSE
Check the OPEN/ CLOSE
SW.(Break or click
feeling…etc)
Check the connector (XP135*5/
XP136*6) voltage on the Digital
P.C.B.
Exchange the mechanism
Check the symptom -1
OK
NG
NG
OK
Exchange the Mechanism unit.
CHECK POINT LOCATION
*5 *6
VOLTAGE DATA (measurement value)
*5
11.3V
23.4V
33.3V
4GND
52.5V
62.4V
1
1
6
6
*6
1GND
23.3V
1
1
2
2

20
Symptom - 4 No picture, No sound
CHECK POINT LOCATION VOLTAGE DATA (measurement value)
*5
11.3V
23.4V
33.3V
4GND
52.5V
62.4V
1
1
6
6
Ch k th
Ch k
3
Check the
Disc tray Operation.
(OPEN and COLSE) NG
OK
Check symptom -3,
afterwards check
symptom -4.
Check the Operation
and FL display.
1. DISC TOC read
2. Track No. and
playback time
NG
Check the connector
(XP135*5) voltage on
the Digital P.C.B. after
pulling a drive cable. NG
OK
OK
and FL display
.
1. DISC TOC read
2. Track No. and
playback time.
OK
NG
(XP135 5) voltage on
the Digital P.C.B. after
pulling a drive cable. NG
Exchange the
Digital P.C.B.
Exchange the
Digital P.C.B.
Exchange the
Mechanism unit.
NG
Check the Digital P.C.B.
output terminal
waveform.
Exchange the
Digital P.C.B.
Exchange the
Digital P.C.B.
Exchange the
Mechanism unit.
No problem
Exchange the
Digital P.C.B.
OK
*5
