Home network "DLNA"
Get started
Information
You can share the contents (Photo, Video, Music etc.) stored in DLNA Certified media
server with your home network system.
•Please confirm Network connection and Network menu settings before
use this function.
This TV is a DLNA Certified TM product.
DLNA (Digital Living Network Alliance) is a standard that makes DLNA Certified
digital electronics easier and more convenient to use on a home network. To learn
more, visit www.dlna.org. It allows you to share photos, videos and music stored in
the DLNA Certified media server (for example, PC with Windows 7 installed, etc.)
connected to your home network, and enjoy the contents on the TV screen.
•Media server
Store photos, videos or music into the DLNA Certified media server, and then you
can enjoy them on the TV.
To use a PC as a media server
Prepare the PC with Windows 7 or ensure the server software is installed on the
PC. "Windows 7" is the server software that has been tested for compatibility with
this TV (as of January, 2011). Any other server software have not been tested with
this TV, therefore compatibility and performance cannot be assured.
,, Windows 7
The setup for homegroup settings of Windows 7 is required. For details, refer to the
help functions of Windows 7.
50

Home network "DLNA"
Connect to network
Network connections (1)
1. Contact your Broadband service provider
If you don't have Internet service from your local provider, please order a high-
speed Internet service at no less than the connection speed below. If you already
have this service, make sure that the connection speed exceeds the following:
•Required speed (effective): at least 1.5 Mbps for SD and 6 Mbps for HD picture
quality, respectively.
•Dial-up Internet service cannot be used for VIERA Connect.
2. Select wired or wireless connection
If the Cable/DSL modem is close to the TV and you have only one TV set, you may
choose a wired connection.
If the Cable/DSL modem is far from the TV and/or you have more TVs in the
house, you may want to use a wireless network.
51

Home network "DLNA"
Connect to network
Network connections (2)
3. Connecting to the Internet
A. Wireless connection
If you are using the network for connecting various pieces of equipment and want
to connect the TV, you could also use a Wireless LAN and Access point to connect
the TV to the Internet.
TV USB Wireless LAN Access
(Wireless LAN Adapter) Adapter point
- Hub, Router
- Modem
- DLNA Certified media server
(for example, PC, etc.)
To use only DLNA features, you can operate the features without Broadband
network environment.
You can just connect the TV directly to the equipment with a LAN cross cable.
52

Home network "DLNA"
Connect to network
Network connections (3)
B. Wired connection (Directly connected)
If you are not using the network for connecting anything else but the TV, you can
just connect the TV directly to the Cable/DSL Ethernet modem with LAN cable.
TV
ETHERNET LAN cable Modem
53

Home network "DLNA"
Connect to network
Network connections (4)
C. Wired connection (Using Router)
If you are using the network for connecting various pieces of equipment and want
to connect the TV, you should use a router to connect the TV to the Internet with
LAN straight cable.
TV
ETHERNET LAN cable - Hub, Router
- Modem
- DLNA Certified media server
(for example, PC, etc.)
To use only DLNA features, you can operate the features without Broadband
network environment.
You can just connect the TV directly to the equipment with a LAN cross cable.
54

Home network "DLNA"
Network settings
Setting menu
This menu is used for connecting to a Broadband environment.
1, Display the and select
[M E N U I _:_:_ >
Select _:: !:_ using _ /_ from menu bar and press
2, Select the options and set
:_::: ,i:_/_ :::_:o_! _,_/:t_:_:: _, :_; _ _:::/
55

Home network "DLNA"
Network settings
Connection test
•Connection test
Check that the all Network settings, and then start i:@s:_
_:::1:::_Select _:::: _:::: using _ /_ and press
(It takes a while to cancel the test,)
_:_ Displayed Connection test screen
• Check mark appears at front of each check item's box when check has
been finished successfully,
_) Complete Connection test
Success Completion screen is displayed,
Error Follow the directions on screen to complete the setting,
If you perform the Proxy settings, check the Proxy address and the Proxy port
number,
56

Home network "DLNA"
Network settings
Network connection
•Network connection
_ Select _ _ using _/V
_ Select Network type (Ethernet cable/Wireless (WiFi)) with
57

Home network "DLNA"
Network settings
Wireless network settings
•Wireless network settings
([_ Select with _/V and press
(5) Display and select access point.
Or select connection method (below) with color key and follow the
directions on screen to complete the setting.
WPS (push button):
You can connect to the access point by pressing a connection button.
WPS (PIN):
Set the PiN code that is displayed on the TV on the access point.
Manual settings:
Manually set SSID, security type, and encryption type to match the settings
of the access point to which to connect.
Search again:
Search again an available wireless network within the range.
* Wi-Fi Protected Setup is an easy setting of the Wi-Fi Alliance's certification.
* For more details on setting of an access point, please refer to operating manual
for the access point.
* When connecting by 11n (5 GHz), select "AES" as the encryption type for the
wireless LAN.
58

Home network "DLNA"
Network settings
IP address/DNS settings
•IP address/DNS settings
I_,_ Select using _/V and press
(_ Displayed
@} Select i:j_ /©i_S using _ /_ and select
Automatic with _ /_-_
@} Each IP address is acquired automatically
If you are using a Broadband router, IP automatic acquisition in DHCP can be
used under normal circumstances. If you are not sure, check with the person
who installed the equipment, or check the instructions for each device.
•Manual setting
,/._ On _ above, Select /©i_:i:_
using _/V and select Manual with _ /
(_ Select the item
@} Check the specifications of the Broadband router and enter each IP address.
Or Enter each IP address as specified by the provider.
59

Home network "DLNA"
Network settings
Proxy settings
•Proxy settings
Set only if specified by the provider. It is not required for normal household use.
(_ Select using _/_ and press
,,.2>Select using _/V and press
(.3J Select the item and press
_:_>Enter address or port number and press
This is the address of the relay server that is connected to the target server instead
of the browser and sends data to the browser. Setting is only required if specified
by the provider.
This number is specified by the provider together with the Proxy address.
60

Home network "DLNA"
Network settings
Network link (1)
•Network link
I:_) Select using _/V and press
(_, Displayed
@) Select the item and set
•Edit the name of this TV
Sets your favorite name for this TV. This name will be displayed on the screen of
the other Network compatible equipment.
q) Select :::_:::,:!_ using _/V and press
_"}}_zjEnter name and press
IEnabling DLNA remote control
Select using _/_ and switches Disable or
Enable with _ /
•Volume setting in DMR operation
Select using _/V and switches Disable
or Enable with <_ /
• Available only when Enable is selected in above.
61

Home network "DLNA"
Network settings
Network link (2)
•Enabling Network remote control
(network device such as a smartphone.)
Select ,:,:_ :_:_i using _/V and switches Disable or
Enable with _ /
62

Home network "DLNA"
Network settings
Software update
•Software update
Q) Select using _/V and press
(5) Press OK to start the Software update screen
(_) Follow directions on the screen
• Make sure to set before the update starts,
63

Home network "DLNA"
Network settings
New software notice
•New software notice
Displays new software update information when TV is turned on.
(_) Select using _/V
(2' Switches Off or On with <,_/
64

Home network "DLNA"
Network settings
Network status
•Network status
Displayed Current settings and status screen.
(_) Select using _/V and press
(_) Display i_::__ screen
* Displayed items differ depending on the type of network connection.
65

Home network "DLNA"
Photos
Viewing Photos
1. Display VIERA TOOLS
JVIERA TOOLS J VIERA TOOLS
2. Display
Select DLNA using _ /_ and press
3. Select server (Available DLNA servers are displayed).
Select desired server using _ /_ from DLNA server list and press
4, Select photo (Thumbnail and Contents type are displayed ).
Select desired content using _ /V from file list and press
5, View
Follow the Navigation and guide to operate.
*Displayed navigation and guide will be different depending on data type.
66

Home network "DLNA"
Photos
Photo view
•Thumbnail view
Display
IINFOI Information panel (File name, Date, and Size etc.)
*Information differs depending on selected data.
• Playback screen
I INFO I ......Display/hide Guide and Banner
Photo status: Shows current photo status
/or
Navigation Guide: Shows available functions.
* In DMR mode, Slideshow is not available.
* In DMR mode, OK/Next/Prev. are not available.
67

Home network "DLNA"
Photos
Options menu
In Photo view, some optional menus are available pressing IOPTION Ibutton.
1, Display
_IOPTIONI
2. Select the item
Select the desired menu using _ /V and press
*Ava ilable menus are displayed on (::, ,::::: depe nding on data
condition and situation,
