Service Manual
Colour LCD Television
TX-L37G10E
TX-LF37G10
TX-L32G10E
TX-LF32G10
TX-L32G10L
LH89 Chassis
Specifications
(Informations in brackets [ ] refers to model 32”)
Power Source: 220-240V AC, 50/60Hz
Power Consumption 145W [123W]
Stand-by Power Consumption: 0.3W (Without monitor out recording)
15W (With monitor out recording)
Aerial Impedance: 75Ωunbalanced, Coaxial Type
Receiving System: PAL-I/H, B/G, D/K,
SECAM B/G, D/K, L/L’
PAL-525/60 (AV only)
DVB-T Digital terrestrial services
DVB-C Digital cable services
M.NTSC (AV only)
NTSC (AV only)
Receiving Channels: VHF E2-E12 VHF H1-H2 (ITALY)
VHF A-H (ITALY) VHF A-J (IRELAND)
VHF R3-R5 VHF R1-R2
UHF E21-E69 VHF R6-R12
CATV S1-S10 (M1-M10) CATV (S01-S05)
CATV S21-S41 (Hyperband) CATV S11-S20 (U1-U10)
Aerial Input: VHF/UHF
Operating Conditions: Temperature: 0°C ÷35°C
Humidity: 20% ÷ 80% RH (non condensing)
Scanning format: 480i(60Hz), 480p(60Hz), 576i(50Hz), 576p(50Hz), 720p(60Hz), 720p(50Hz), 1.080i(60Hz),
1.080i(50Hz), 1.080p(60Hz), 1.080p(50Hz), 1080p(24Hz)
PC signals: VGA, SVGA, WVGA, XGA, SXGA, WXGA (compressed)
Horizontal scanning frequency 31 – 69 kHz
Vertical scanning frequency 59 – 86 Hz
ORDER No. PCZ0903027CE
REVISION 2
© Panasonic Corporation 2008.
Unauthorized copying and
distribution is a violation of law.

Intermediate Frequency:
Video/Audio
Video 38,9MHz, 33,9MHz
Audio 33,4MHz (B/G), 33,16MHz (A2)
33,05MHz (NICAM B/G, D/K, L)
32,4MHz (D/K), 32,66MHz (CZ STEREO)
40,4MHz (L’), 39,75MHz (L’NICAM)
32,9 (I), 32,35 (I NICAM)
Colour 34,47MHz (PAL)
34,5MHz, 34,65MHz (SECAM)
38,3MHz, 38,15MHz (SECAM L’)
Terminals:
AV1 IN Video (21 pin) 1V p-p 75Ω
Audio (21 pin) 500mV rms 10kΩ
RGB (21 pin) 0,7V p-p 75Ω
AV1 OUT Video (21 pin) 1V p-p 75Ω
Audio (21 pin) 500mV rms 1kΩ
AV2 IN Video (21 pin) 1V p-p 75Ω
Audio (21 pin) 500mV rms 10kΩ
RGB (21 pin) 0,7V p-p 75Ω
S-video IN (21-pin) Y: 1V p-p 75Ω
C:0,3V p-p 75Ω
AV2 OUT Video (21 pin) 1V p-p 75Ω
Audio (21 pin) 500mV rms 1kΩ
AV3 IN S-Video IN (4-pin) Y: 1V p-p 75Ω
C:0,286 p-p 75Ω
Audio (RCAx2) 500mV rms 10kΩ(used for HDMI4, AV3 - AUDIO)
Video (RCAx1) 1V p-p 75Ω
HDMI1, HDMI2, HDMI3, HDMI4 Type A Connector HDMITM (Version 1.3a with x.v. Color TM)
This TV supports “HDAVI Control 4” function.
COMPONENT Video (RCAx3) Y:1V p-p 75Ω(including synchronization)
Pb, Pr: ±0,35V p-p 75Ω
AUDIO IN Audio (RCAx2) 500mV rms 10kΩ(used for HDMI1, COMPONENT-AUDIO)
AUDIO OUT Audio (RCAx2) 500mV rms 1kΩ(high impedance)
DIGITAL AUDIO OUT PCM / Dolby digital, Fiber optic
CARD SLOT SD CARD slot x1
PC HIGH-DENSITY D_SUB 15PIN R,G,B: 700mV p-p 75Ω
HD,VD/TTL Level 2-5V p-p (high impedance)
LCD screen: L5EDD9T00010 [L5EDD8T00005]
1920 x 1080 XGA, 16:9
Visible Diagonal 940mm [800mm]
Audio Output: 20W (2x10W), 10% THD
Headphones: 3,5mm, 8ΩImpedance
Accessories supplied : Remote Control 2 x R6 (UM3) Batteries
Dimensions:
Height: Width: Depth:
Including TV stand 611mm 894mm 287mm
[541mm 777mm 217mm]
TV set only 568mm 894mm 99mm
[501mm 777mm 95mm]
Mass:
Including TV stand 17.5kg [13.5kg]
TV set only 15.0kg [12.0kg]
Specifications are subject to change without notice.
Mass and dimensions shown are approximate.
This service information is designed for experienced repair technicians only and is not designed for use by the general public. It does not
contain warnings or cautions to advise non-technical individuals of potencial dangers in attempting to service a product. Products
powered by electricity should be serviced or repaired only by experienced professional technicians. Any attempt to service or repair the
product or products deal within this service information by anyone else could result in serious injury or death.
Warning
2

CONTENTS
SAFETY PRECAUTIONS ........................................... 4
GENERAL GUIDE LINES...................................... 4
TOUCH – CURRENT CHECK............................... 4
PREVENTION OF ELECTROSTATIC DISCHARGE
(ESD) TO ELECTROSTATICALLY SENSITIVE (ES)
DEVICES .................................................................... 5
ABOUT LEAD FREE SOLDER (PBF)......................... 6
SUGGESTED PB FREE SOLDER........................ 6
APPLICABLE SIGNALS.............................................. 7
SERVICE HINTS ........................................................ 8
CHASSIS BOARD LAYOUT ....................................... 9
LOCATION OF LEAD WIRING………………………….9
SETTING INSPECTION............................................ 10
SELF-CHECK ........................................................... 11
SERVICE MODE FUNCTION ................................... 14
SERVICE .................................................................. 15
OPTION BYTES DESCRIPTION .............................. 16
ADJUSTMENT METHOD.......................................... 17
WIRING DIAGRAM ................................................... 18
BLOCK DIAGRAMS.................................................. 19
PARTS LOCATION................................................... 22
REPLACEMENT PARTS LIST.................................. 24
SCHEMATIC DIAGRAMS ......................................... 41
A-BOARD (1 OF 27) SCHEMATIC DIAGRAM .... 42
G-BOARD SCHEMATIC DIAGRAM………………69
V-BOARD SCHEMATIC DIAGRAM………………70
CONDUCTOR VIEWS………………………………….71
POWER LED BLINKING CHART ............................. 13
3

Safety Precautions
General Guide Lines
1. When servicing, observe the original lead dress. If a short circuit is found, replace all parts which have been overheated
or damaged by the short circuit.
2. After servicing, see to it that all the protective devices such as insulation barriers, insulation papers shields are properly
installed.
3. After servicing, make the following touch current checks to prevent the customer from being exposed to shock hazards.
4. Always ensure panel TKP0E16001 is correctly replaced before returning to customer (see Fig.1).
Touch-Current Check
1. Plug the AC cord directly into the AC outlet. Do not use an isolation transformer for this check.
2. Connect a measuring network for touch currents between each exposed metallic part on the set and a good earth
ground such as a water pipe, as shown in Fig. 2.
3. Use Leakage Current Tester (Simpson 228 or equivalent) to measure the potential across the measuring network.
4. Check each exposed metallic part, and measure the voltage at each point.
5. Reserve the AC plug in the AC outlet and repeat each of the above measure.
6. The potential at any point (TOUCH CURRENT) expressed as voltage U1 and U2, does not exceed the following values:
For a. c.: U1 = 35 V (peak) and U2 = 0.35 V (peak);
For d. c.: U1 = 1.0 V,
Note:
The limit value of U2 = 0.35 V (peak) for a. c. and U1 = 1.0 V for d. c. correspond to the values 0.7 mA (peak) a. c. and
2.0 mA d. c.
The limit value U1 = 35 V (peak) for a. c. correspond to the value 70 mA (peak) a. c. for frequencies greater than 100
kHz.
7. In case a measurement is out of the limits specified, there is a possibility of a shock hazard, and the equipment should
be repaired and rechecked before it is returned to the customer.
Fig. 2
4
TO
APPLIANCES
EXPOSED
METAL PARTS
Resistance values in ohms (Ω)
V
R0=500
Ω
RS=1500
Ω
CS=0.22
μ
F
10k
Ω
0.022
μ
F
COLD
WATER PIPE
(EARTH GROUND)
V: Voltmetr or oscilloscope
(r.m.s. or peak reading)
Measuring network for TOUCH CURRENTS
Input resistance: ≥ 1M
Ω
Input capacitance: ≤ 200pF
Frequency range: 15Hz to 1MHz and d.c.respectively
NOTE – Appropriate measures should be taken to obtain the correct value in case of non-sinusoidal waveforms
U2(V)
Fig. 1

Prevention of Electrostatic Discharge (ESD) to Electrostatically
Sensitive (ES) Devices
Some semiconductor (solid state) devices can be damaged easily by static electricity. Such components commonly are
called Electrostatically Sensitive (ES) Devices. Examples of typical ES devices are integrated circuits and some field-effect
transistors and semiconductor "chip" components. The following techniques should be used to help reduce the incidence of
component damage caused by electrostatic discharge (ESD).
1. Immediately before handling any semiconductor component or semiconductor-equipped assembly, drain off any ESD on
your body by touching a known earth ground. Alternatively, obtain and wear a commercially available discharging ESD
wrist strap, which should be removed for potential shock reasons prior to applying power to the unit under test.
2. After removing an electrical assembly equipped with ES devices, place the assembly on a conductive surface such as
aluminum foil, to prevent electrostatic charge build up or exposure of the assembly.
3. Use only a grounded-tip soldering iron to solder or unsolder ES devices.
4. Use only an anti-static solder removal device. Some solder removal devices not classified as "anti-static (ESD
protected)" can generate electrical charge sufficient to damage ES devices.
5. Do not use freon-propelled chemicals. These can generate electrical charges sufficient to damage ES devices.
6. Do not remove a replacement ES device from its protective package until immediately before you are ready to install it.
(Most replacement ES devices are packaged with leads electrically shorted together by conductive foam, aluminum foil
or comparable conductive material).
7. Immediately before removing the protective material from the leads of a replacement ES device, touch the protective
material to the chassis or circuit assembly into which the device will be installed.
Caution
Be sure no power is applied to the chassis or circuit, and observe all other safety precautions.
8. Minimize bodily motions when handling unpackaged replacement ES devices. (Otherwise harmless motion such as the
brushing together of your clothes fabric or the lifting of your foot from a carpeted floor can generate static electricity
(ESD) sufficient to damage an ES device).
There are special components used in this equipment which are important for safety.
These parts are marked by in schematic diagrams, exploded views and replacement parts list. It is essential that
these critical parts should be replaced with manufacturer’s specified parts to prevent shock, fire, or other hazards. Do
not modify the original design without permission of manufacturer.
IMPORTANT SAFETY NOTICE
5

About lead free solder (PbF)
Note: Lead is listed as (Pb) in the periodic table of elements.
In the information below, Pb will refer to Lead solder, and PbF will refer to Lead Free Solder.
The Lead Free Solder used in our manufacturing process and discussed below is (Sn+Ag+Cu).
That is Tin (Sn), Silver (Ag) and Copper (Cu) although other types are available.
This model uses Pb Free solder in it’s manufacture due to environmental conservation issues. For service and repair work,
we’d suggest the use of Pb free solder as well, although Pb solder may be used.
PCBs manufactured using lead free solder will have the PbF within a leaf Symbol
stamped on the back of PCB.
Caution
•Pb free solder has a higher melting point than standard solder. Typically the melting point is 50 ~ 70 °F (30~40°C)
higher. Please use a high temperature soldering iron and set it to 700 ± 20 °F (370 ± 10 °C).
•Pb free solder will tend to splash when heated too high (about 1100 °F or 600 °C).
If you must use Pb solder, please completely remove all of the Pb free solder on the pins or solder area before
applying Pb solder. If this is not practical, be sure to heat the Pb free solder until it melts, before applying Pb solder.
•After applying PbF solder to double layered boards, please check the component side for excess solder which may
flow onto the opposite side. (see Fig.3)
Suggested Pb free solder
There are several kinds of Pb free solder available for purchase. This product uses Sn+Ag+Cu (tin, silver, copper) solder.
However, Sn+Cu (tin, copper), Sn+Zn+Bi (tin, zinc, bismuth) solder can also be used. (see Fig.4)
Fig.3
Fig.4
6

Applicable Signals
Applicable input signal for PC is basically compatible to VESA standard timing.
Signal name Horizontal frequency (kHz) Vertical frequency (Hz)
640 ×400 @70 Hz 31.47 70.07
640 ×480 @60 Hz 31.47 59.94
640 ×480 @75 Hz 37.50 75.00
800 ×600 @60 Hz 37.88 60.32
800 ×600 @75 Hz 46.88 75.00
800 ×600 @85 Hz 53.67 85.06
852 ×480 @60Hz 31.44 59.89
1,024 ×768 @60Hz 48.36 60.00
1,024 ×768 @70Hz 56.48 70.07
1,024 ×768 @75Hz 60.02 75.03
1,024 ×768 @85Hz 68.68 85.00
1,280 ×768 @60Hz 47.70 60.00
1,280 ×1,024 @60Hz 63.98 60.02
1,366 ×768 @60Hz 48.39 60.04
Macintosh 13“ (640 ×480) 35.00 66.67
Macintosh 16“ (832 ×624) 49.73 74.55
Macintosh 21“ (1,152 ×870) 68.68 75.06
Applicable input signal for PC is basically compatible to HDMI standard timing.
Signal name Horizontal frequency (kHz) Vertical frequency (Hz)
640 ×480 @60 Hz 31.47 60.00
750 (720) / 60p 45.00 60.00
1,125 (1,080) / 60p 67.50 60.00
Note:
•Signals other than above may not be displayed properly.
•The above signals are reformatted for optimal viewing on your display.
•PC signal is magnified or compressed for display, so that it may not be possible to show fine detail
with sufficient clarity.
7
Signal name COMPONENT HDMI
525 (480) / 60i * *
525 (480) / 60p * *
625 (576) / 50i * *
625 (576) / 50p * *
750 (720) / 60p * *
750 (720) / 50p * *
1,125 (1,080) / 60i * *
1,125 (1,080) / 50i * *
1,125 (1,080) / 60p *
1,125 (1,080) / 50p *
1,125 (1,080) / 24p *
PC (from D-sub 15P)
Component (Y, Pb, Pr), HDMI
PC (from HDMI terminal)

Service Hints
How to remove the back cover
Remove the 19 fixing screws. (see Fig.5)
How to remove the Pedestal assembly
Lay the main unit face down. (see Fig.6)
Remove the 4 fixing screws and the pedestal assembly. (see Fig.7)
8
Fig.5
SCREWS SCREWS
Fig.6
Fig.7
SCREWS

Chassis Board Layout
Location of Lead Wiring
To find the Part Number of required wire in Replacement Parts List click on the wire name in red box.
Board Name Function
A-Board AV Terminal, HDMI, AV Switch, Sound Processor, TV tuner, PC,SD Card,
OFDM, ZWEI, GENX, EEPROM, ADV, Peaks AVC, Speaker out
G-Board Side AV Terminal
V-Board Remote Receiver, R&G LED, Timer Rec LED, C.A.T.S., SD LED
P-Unit Main Input, Power Supply, Inverter
P-UNIT
G-BOARD
V-BOARD
A-BOARD
9
A20-P4
A01
P4
SPL
V10
LVDS
P6
K01
A10
P1
A04
LVDS (32’’)
(37’’)
A-K/SP/V
G04
TU2901
A12
A03
P2
A11
A20
SPR
P5
(32’’+37’’)
(32’’) A12-SP (37’’)
A10-V10 (37’’)
A01-K01
(37’’)

Setting Inspection
Voltage Confirmation
Confirm the following voltages:
A board
Description Test point Position Voltage
5VS TP2765 A03(pin 23) 5V±2%
P17V TP2777 A03 (pin 12,13) 17V±2%
SUB_F_12V TP2764 A03 (pin 16,17,19 12V±2%
INV_ON TP2759 A20 (pin3) 2,85±2%
10

Self Check
Self-check is used to automatically check the bus lines and hexadecimal code of the TV set. To enter Self-Check mode, keep
pressing the down (-/v) button on the TV set and press the STATUS button on the remote control. To exit Self Check,
switch off the TV set at the power button.
ADV O.K.
ADAV O.K.
TUN O.K.
GENX O.K..
MEM1 O.K.
MEM2 O.K.
AVSW O.K.
OFDM O.K.
TEMP O.K.
VIF O.K.
ZWEI O.K.
PEAKS-SOFT 1.205
PEAKS-EEP 01.00.0006
GenX-SOFT 1.00.00
GenX-EEP 1.03.37
GenX-ROMCORR 1.00.00
ZWEI-SOFT 30000101
SUM 7BC1
MODEL ID 06
03103100
00000010
EDID 222b1b0bfb
TX-L37G10E
TX-L32G10E
37FHD Panasonic 2009LCD
Self Check Com
p
lete
32FHD Panasonic 2009LCD
Self Check Com
p
lete
ADV O.K.
ADAV O.K.
TUN O.K.
GENX O.K..
MEM1 O.K.
MEM2 O.K.
AVSW O.K.
OFDM O.K.
TEMP O.K.
VIF O.K.
ZWEI O.K.
PEAKS-SOFT 1.205
PEAKS-EEP 01.00.0007
GenX-SOFT 1.00.00
GenX-EEP 1.03.37
GenX-ROMCORR 1.00.00
ZWEI-SOFT 30000101
SUM 77FD
MODEL ID 06
03103100
00000004
EDID 222b1b0bfb
11
ADV O.K.
ADAV O.K.
TUN O.K.
GENX O.K..
MEM1 O.K.
MEM2 O.K.
AVSW O.K.
OFDM O.K.
TEMP O.K.
VIF O.K.
ZWEI O.K.
PEAKS-SOFT 1.205
PEAKS-EEP 01.00.0006
GenX-SOFT 1.00.00
GenX-EEP 1.03.37
GenX-ROMCORR 1.00.00
ZWEI-SOFT 30000101
SUM 7BC1
MODEL ID 06
03103100
00000010
EDID 222b1b0bfb
TX-LF37G10 37FHD Panasonic 2009LCD
Self Check Com
p
lete
TX-LF32G10 32FHD Panasonic 2009LCD
Self Check Com
p
lete
ADV O.K.
ADAV O.K.
TUN O.K.
GENX O.K..
MEM1 O.K.
MEM2 O.K.
AVSW O.K.
OFDM O.K.
TEMP O.K.
VIF O.K.
ZWEI O.K.
PEAKS-SOFT 1.205
PEAKS-EEP 01.00.0007
GenX-SOFT 1.00.00
GenX-EEP 1.03.37
GenX-ROMCORR 1.00.00
ZWEI-SOFT 30000101
SUM 77FD
MODEL ID 06
03103100
00000004
EDID 222b1b0bfb

Display Ref. No. Description P.C.B.
ADV IC4510 A/D CONVERTER A-Board
ADAV IC4510 A/D CONVERTER A-Board
TUN TU2901 TUNER A-Board
GENX IC1100 MICROPROCESSOR A-Board
MEM1 IC1101 EEPROM /GenX/ A-Board
MEM2 IC8502 EEPROM /Peaks-AVC/ A-Board
AVSW IC3001 AUDIO VIDEO SWITCH A-Board
OFDM IC8301 COFDM DEMODULATOR A-Board
TEMP IC2750 TEMP SENSOR A-Board
VIF TU2901 TUNER A-Board
ZWEI IC4200 ZWEI A-Board
If the CCU
p
orts have been checked and found to be incorrect or not located then " - - " will a
pp
ear in
p
lace of "O.K.".
12
TX-L32G10L 32FHD Panasonic 2009LCD
Self Check Com
p
lete
ADV O.K.
ADAV O.K.
TUN O.K.
GENX O.K..
MEM1 O.K.
MEM2 O.K.
AVSW O.K.
OFDM O.K.
TEMP O.K.
VIF O.K.
ZWEI O.K.
PEAKS-SOFT 1.205
PEAKS-EEP 01.00.0015
GenX-SOFT 1.00.00
GenX-EEP 1.03.37
GenX-ROMCORR 1.00.00
ZWEI-SOFT 30000101
SUM 78EB
MODEL ID 06
030A3100
00000004
EDID 222b1b0bfb

4 sec
Once
Power LED blinking timing chart
1. Subject
Information of LED Flashing timing chart.
2. Contents
When abnormality has occurred the unit, the protection circuit operates and reset to the stand by mode. At this time, the
defective block can be identified by number of blinking of the Power LED on the front panel of the unit.
Blinking
times Blinking timing Contents Check point
1 INVERTER_SOS
A BOARD,
P UNIT
2 FAN_SOS A BOARD
3 SOS A BOARD
4 SUB_F_12V
A BOARD
P UNIT
5 MAIN_9V A BOARD
6 SUB_5V A BOARD
V BOARD
7 SUB_3.3V A BOARD
8 MAIN_3.3V A BOARD
V BOARD
9 SOUND_SOS
A BOARD
10 ZWEI_SOS A BOARD
13 Emergency SOS A BOARD
14 AUDIO_PWM_SOS A BOARD
13
No Light
Light

Service Mode Function
MPU controls the functions switching for each IICs through IIC bus in this chassis. The following setting and adjustment can
be adjusted by remote control in Service Menu
How to enter SERVICE
While pressing (-/v) button on the TV unit, press on the remote control for 3 times within 2 seconds.
Note:
To exit from Service mode, press the exit button on remote control.
14
0

SERVICE
S e r
v
i c e 1
216
15
SERVICE
ADJUST
WB-ADJ
OPTION
SRV-TOOL
Peaks SOFT 0.501 OPTION 1 1c
Peaks EEP 00.01.1120 OPTION 2 ef
LSI DATA 0.00.0a OPTION 3 01
STBY SOFT 1.00.00 Model ID 06
STBY EEP 1.03.37 03033100
STBY ROMCOR 1.00.00 00000004
ZWEI SOFT 30000101
RB Cnt 000
INV Cnt 0000
ADJUST DYNAMIC
CONTRAST
YMAX
1,2:MAIN SELECT
3,4:SUB SELECT
9 :PICTURE MENU SELECT
YELLOW:AUTO ADJUST
VOL:ADJUST
OK :WRITE
000
ADJUST DYNAMIC
COLOR
1,2:MAIN SELECT
3,4:SUB SELECT
9 :PICTURE MENU SELECT
VOL:ADJUST
OK :WRITE
5D
1,2:MAIN SELECT
3,4:SUB SELECT
9 :PICTURE MENU SELECT
VOL:ADJUST
OK :WRITE
ADJUST DYNAMIC
SUB-BRT
1,2:MAIN SELECT
3,4:SUB SELECT
9 :PICTURE MENU SELECT
VOL:ADJUST
OK :WRITE
C00
A
DJUST DYNAMIC
BACKLGT
1,2:MAIN SELECT
3,4:SUB SELECT
9 :PICTURE MENU SELECT
VOL:ADJUST
OK :WRITE
4DE
A
DJUST DYNAMIC
H-POS
1,2:MAIN SELECT
3,4:SUB SELECT
9 :PICTURE MENU SELECT
VOL:ADJUST
OK :WRITE
0
A
DJUST DYNAMIC
H-AMP
1,2:MAIN SELECT
3,4:SUB SELECT
9 :PICTURE MENU SELECT
VOL:ADJUST
OK :WRITE
0
ADJUST DYNAMIC
V-POS
1,2:MAIN SELECT
3,4:SUB SELECT
9 :PICTURE MENU SELECT
VOL:ADJUST
OK :WRITE
0
A
DJUST DYNAMIC
V-AMP
1,2:MAIN SELECT
3,4:SUB SELECT
9 :PICTURE MENU SELECT
VOL:ADJUST
OK :WRITE
0
WB-ADJ DYNAMIC
R-GAIN
COLOR TEMP NORMAL
1,2:MAIN SELECT
3,4:SUB SELECT
7 :COLOR TEMP SELECT
9 :PICTURE MENU SELECT
VOL:ADJUST
OK :WRITE
FC
WB-ADJ DYNAMIC
G-GAIN
COLOR TEMP NORMAL
1,2:MAIN SELECT
3,4:SUB SELECT
7 :COLOR TEMP SELECT
9 :PICTURE MENU SELECT
VOL:ADJUST
OK :WRITE
FF
WB-ADJ DYNAMIC
B-GAIN
COLOR TEMP NORMAL
1,2:MAIN SELECT
3,4:SUB SELECT
7 :COLOR TEMP SELECT
9 :PICTURE MENU SELECT
VOL:ADJUST
OK :WRITE
DA
WB-ADJ DYNAMIC
R-CENT
COLOR TEMP NORMAL
1,2:MAIN SELECT
3,4:SUB SELECT
7 :COLOR TEMP SELECT
9 :PICTURE MENU SELECT
VOL:ADJUST
OK :WRITE
80
WB-
A
DJ DYNAMIC
G-CENT
COLOR TEMP NORMAL
1,2:MAIN SELECT
3,4:SUB SELECT
7 :COLOR TEMP SELECT
9 :PICTURE MENU SELECT
VOL:ADJUST
OK :WRITE
WB-
A
DJ DYNAMIC
B-CENT
COLOR TEMP NORMAL
1,2:MAIN SELECT
3,4:SUB SELECT
7 :COLOR TEMP SELECT
9 :PICTURE MENU SELECT
VOL:ADJUST
OK :WRITE
80
OPTION DYNAMIC
Boot
1,2:MAIN SELECT
3,4:SUB SELECT
9 :PICTURE MENU SELECT
VOL:ADJUST
ROM
OPTION DYNAMIC
STBY-SET
1,2:MAIN SELECT
3,4:SUB SELECT
9 :PICTURE MENU SELECT
OK :POWER OFF
00
OPTION DYNAMIC
Emergency
1,2:MAIN SELECT
3,4:SUB SELECT
9 :PICTURE MENU SELECT
VOL:ADJUST
ON
OPTION DYNAMIC
Y/C Delay
1,2:MAIN SELECT
3,4:SUB SELECT
9 :PICTURE MENU SELECT
VOL:ADJUST
OK :WRITE
OPTION DYNAMIC
OPT 1
1,2:MAIN SELECT
3,4:SUB SELECT
5,6:BIT SELECT
9 :PICTURE MENU SELECT
VOL:ADJUST
OK :WRITE
00011100
OPTION DYNAMIC
OPT 2
1,2:MAIN SELECT
3,4:SUB SELECT
5,6:BIT SELECT
9 :PICTURE MENU SELECT
VOL:ADJUST
OK :WRITE
11101111
OPTION DYNAMIC
OPT 3
1,2:MAIN SELECT
3,4:SUB SELECT
5,6:BIT SELECT
9 :PICTURE MENU SELECT
VOL:ADJUST
OK :WRITE
00000001
SRV-TOOL DYNAMIC
1,2:MAIN SELECT
9 :PICTURE MENU SELECT
OK :ENTER
00
1
2
3
4
1
1
1
2
2
2
3 3 3
3
3
3 3
3
3
3
3
3
3
3
3
3 3 3
4
4
4
4
4
4
4 44
4
4 4
4
4
4
4 4
4
80
Key Command
•Press the 3/4 button to change the adjustment values or function.
•Press the 1/2 button to step up/down through the functions and adjustments
•Press the numerical button VOLUME (+/-) to change of each option item.
•Press the OK button after each adjustment has been made to store the required values.
A
DJUST DYNAMIC
TINT 00

Option Bytes Description
OPTION1
b0 ATP Search speed Slow (1) / Fast (0)
b1 TEXT Ch Refresh ON (1) / OFF (0)
b2 ID-1 ON (1) / OFF (0)
b3 Macrovision Auto-judge ON (1) / OFF (0)
b4 Surround enable low bit ON (1) / OFF (0)
b5 Surround enable high bit ON (1) / OFF (0)
b6 Pre Emphasis ON (1) / OFF (0)
b7 TINT_Component_HDMI ON (1) / OFF (0)
OPTION2
b0 Adjust gain enable ON (1) / OFF (0)
b1 A2 BG enable (5,5MHz) ON (1) / OFF (0)
b2 A2 DK1 enable (6,26MHz) ON (1) / OFF (0)
b3 A2 DK3 enable (5,742MHz) ON (1) / OFF (0)
b4 NICAM scan ON (1) / OFF (0)
b5 NICAM BG enable (5,5MHz) ON (1) / OFF (0)
b6 NICAM I enable (6,0MHz) ON (1) / OFF (0)
b7 NICAM DK enable (6,5MHz) ON (1) / OFF (0)
OPTION3
b0 NICAM priority (ASIA/M.E) ON (1) / OFF (0)
b1 NICAM priority (K/UK) ON (1) / OFF (0)
b2 NICAM priority (China) ON (1) / OFF (0)
b3 NICAM priority (NZ/INDN) ON (1) / OFF (0)
b4 NICAM priority (AUS) ON (1) / OFF (0)
b5 NICAM priority (E.Evropa) ON (1) / OFF (0)
b6 NICAM priority (Special) ON (1) / OFF (0)
b7 Not use Not use
OPTION4
b0 All country DVB-S enable ON (1) / OFF (0)
b1 All country DVB-C enable ON (1) / OFF (0)
16

Adjustment Method
Sub-Contrast/White Balance Adjustment
Instrument Name Connect to Remarks
1. Remote controller
2. LCD WB meter (Minolta CA-210 or equivalent)
3. Comunication jig
4. Computer for external control
Correlation can be also taken by
CS-1000A or equivalent
Procedure Remarks
Subcontrast adjustment
1. Receive PAL colour bar (100% white) RF signal.
2. Enter “Contrast” adj. In SERVICE mode.
3. Start adjusting by using Yellow Key.
4. If the adjustment finished normally, the letter of Contrast will change from red
to black.
White Balance adjustment
1. Procedure basically performs checking using the production software and
make automatic adjustment using external computer.
2. It adjusts in the mode of: Colour balance Normal
Viewing Mode Dynamic
TX-L32/37G10E
TX-LF32/37G10 TX-L32G10L
Normal Normal
Highlight x: 0,2860 ±0,010 x: 0,2860 ±0,010
y: 0,3060 ±0,010 y: 0,3110 ±0,010
Normal
Lowlight x: 0,2860 ±0,010 x:0,2840 ±0,010
y: 0,3090 ±0,010 y: 0,3120 ±0,010
Let the panel standfor more than 3
hours at more than 20 °C.
Basically perform adjustment in the
ambient environment of room
temperature more than 20 °C.
The aging time is more than20 min
at above room temperature.
Applied signal
100% full colour bar
0,7V p-p white peak
85% modulation
100% WHITE
50% GRAY
17

Wiring diagram
PC
JK3001
YUV,AUDIO IN,
AUDIO OUT
JK3100
CI SLOT
JK8401
HDMI1
JK4501
SD SLOT
JK8302
SERVICE
CN0100
A-BOARD
AV1 JK3002
AV2 JK3003
HDMI2
JK4500
HDMI3
JK4700
HDMI4
JK4502
TU2901
A12
A01
SP
KEY
A04 A10
G-BOARD V-BOARD
V10
G04
AV3
JK3700
A03 A20
A11
D3015 DIGITAL
AUDIO OUT
LCD PANEL
18
P UNIT
P4
P2
P1 MAIN IN
P5 P6
SERVICE
CN4201

Video & Stereo Audio Block Diagram
JK3002
AV1_V 20
AV1_VOUT 19
AV1_RED 15
AV1_GREEN 11
AV1_BLUE 7
AV1_L 6
AV1_LOUT 3
AV1_R 2
AV1_ROUT 1
AV1 21PIN SCART
JK3003
AV2_V 20
AV2_VOUT 19
AV2_RED/C 15
AV2_GREEN 11
AV2_BLUE 7
AV2_L 6
AV2_LOUT 3
AV2_R 2
AV2_ROUT 1
AV2 21PIN SCART
Y
PB
PR
L
R
L
Y,PB,PR
JK3100
AUDIO
IN
R
OUT
JK3001
PC
1
2
3
G-BOARD
A-BOARD
[EXCHANGE UNIT]
Y
C
R
L
V
R
L
JK3700
AV3_RIN
AV3_LIN
AV3_Y
AV3_C
HP_LOUT
HP_ROUT
G04
2 4 6 8 10 3 1
A04
2 4 6 8 10 3 1
AV3_V
IC3001
[C1AB00002855]
AVSW
79 CVBSIN6
44 CVBS/Y+COUT3
43 SAGCVBSOUT3
91 R3
89 G3
87 B3
62 L3IN
56 L1OUT
63 R3IN
55 R1OUT
19 G1
38 Y/Y+CVBSOUT4
37 SAGCVBSOUT4
11 R2
13 G2
15 B2
64 L4IN
54 L2OUT
65 R4IN
53 R2OUT
23 CVBSIN2
21 CIN1
95 CYIN1
93 PBIN1
YPBPR_Y
YPBPR_PB
97 PRIN1
YPBPR_PR
70 L7IN
71 R7IN
PC_LIN
PC_RIN
52 L3OUT
51 R3OUT
RCA_AUDIOOUT_L
RCA_AUDIOOUT_R
3RIN
1GIN
PC_R
PC_G
99 BIN
PC_B
69 R6IN
68 L6IN
81 CVBSIN5
83 YIN4
85 CIN4
AV3_RIN AV3_LIN
AV3_V
AV3_Y
AV3_C
HP_LOUT
HP_ROUT
IC4510
[C1AB00003045]
ADV
G/CY/CVBSout1 31
MAIN_Y/CVBS
B/PB/Cout1 33 MAIN_PB/C
R/PRout1 35 MAIN_PR
Q4516
Q4515
Q4514
CVBSout 46 RGB_CVBS Q4519
Q4517
R4out 49 AV_R
L4out 50 AV_L
L1IN 58 AUDIOOUT_L
R1IN 59 AUDIOOUT_R
L2IN 60 TV_L
R2IN 61 TV_R
TU2901
21
10
11
19
17
12
TUNER
VIDEO_OUT
AUDIO_OUT
SIF_OUT
MAIN_RF_CVBS
CVBSIN4 5AUXIN2L
AUXIN2R
SIF_IN1
SIF_IN2 A17
A18
A22
B22
A14
A12
A13
B10
A15
A21
B21
D22
D23
C22
C23
N23 PWM3A
N22 PWM3B
M22 PWM4B
SOY
AIN4
AIN6
AIN5
AIN9
H22
H23
HP_LOUT
HP_ROUT
M23 PWM4A
IC2301
[C1AB00002875]
AUDIO AMPLIFIER
PWM_Wo_L+ PWM_Wo_L-
PWM_Wo_R+ PWM_Wo_R-
5
7
12
14
30
25
21
34
A12
1 2 3 4
SP_L
SP_R
L+
L-
R+
R-
M20 SPDIF_OUT
D3015
Digital
Audio Out
JK4502
HDMI4
RXA_CN,CP,0N,0P,1N,1P,2N,2P
B5,A5,B4,A4
B3,A3,B2,A2
JK4500
HDMI2
RXB_CN,CP,0N,0P,1N,1P,2N,2P
D2,D1,E2,E1
F2,F1,G2,G1
JK4700
HDMI3
RXC_CN,CP,0N,0P,1N,1P,2N,2P
J2,J1,K2,K1
L2,L1,M2,M1
JK4501
HDMI1
RXD_CN,CP,0N,0P,1N,1P,2N,2P
P2,P1,R2,R1
T2,T1,U2,U1
IC8001
[MN2WS0053]
Peaks AVC
DIGITAL
VIDEO OUT
VI1_P0,P2-P19,P21-29,CLK2,EN,HSYNC, VSYNC, CLK,CKOUT
A6,B6,B5,C5,A4,E6,B4,C2,C1,D3,D2,E3,D1,E2,E1,F3,F2,
H5,H6,F1,G3,H3,A7,B7,K6,K1,K2,J1,H1,A5,J2,C6,G1,H2
CVBSin1 17
DVB_CVBS DVB_CVBS E10 Analog video I/F
T21
U20
R21
U21
P20
DAUDI0
SRCK0
DMIX0
LRCK0
IECOUT0
E12
B12
A12
F12
F8
Audio I/F
JK8302
SD Card
Data SD Card I/F
IC4200
[MN85060]
ZWEI
B27,A27,B28,A28,B29,B30
C29,C30,D29,D30,E29,E30
LVDS I/F
E4,C4,D5,D6,F7,E7,C7,E8,B14,C14
E13,D13,F13,G5,D14,J5,F5,F4,J6,G2,J3
LOSD OUT
ZW_RX-AN,AP,BN,BP,CN,CP,DN, DP,EN,EP,CLKN,CLKP
LOSDOUT_0-15,CLKO,CLKI,HPO, VPO,HPI,HOLDI
J1,J2,K1,K2,L1,L2
M1,M2,N1,N2,P1,P2
LVDS-Rx
B1,A2,C5,C2,C1,D3,D2,D1,E2,E3,E1
F1,F3,A5,B5,F2,B3,F4,A4,A3,C4,B4
OSD
N26 M26 L26 K26 J26 H26 G26 F26 E26 D26 C26 B26
N25 M25 L25 K25 J25 H25
LVDS-Tx1 LVDS-Tx0
G25 F25 E25 D25 C25 B25
A11
11 12 13 14 16 17 19 20 21 22 23 24 27 28 29 30 32 33 35 36 37 38 39 40
TE1P
TE1M TD1P TD1M TCLK1P
TCLK1M
TC1P
TC1M
TB1P
TB1M
TA1P
TA1M TE0P
TE0M
TD0P
TD0M TC0P
TC0M
TB0P
TB0M
TA0P
TA0M
TCLK0P
TCLK0M
LCD PANEL
IC8301
[C1AB00003049]
FEO_COMBINED
DEMODULATOR
IFD2
IFD1
IFAGC
2IFAGC
57 IFD1
58 IFD2
FE_XIRQ
5
8
9
10
13
14
17
18
19
20
21
22
FE_PSYNC
FE_VAL
FE_CLK
FE_MDO0
FE_MDO1
FE_MDO2
FE_MDO3
FE_MDO4
FE_MDO5
FE_MDO6
FE_MDO7
IC8411
IC8410
IC8404
IC8405
IC8408
IC8409
CI SLOT
DATA
IC8580
FLASH MEM
JK8401
DATA
TS BUFFER
DATA
IC4201
IC4202
DDR2
IC8002
IC8003
DDR2
IC8502
EEPROM PL-AVC
IC4203
FLASH MEM
19

IC1100
GENX
24,39,62,64,68,88
STB3.3V
Power Supply Block Diagram
P UNIT
V-BOARD
A03
3 8
9
12
13 16 17 19
20
22 23
STB5V
P24V
P17V
SUB_F_12V
SUB_TNR_6V
5VS
D4001
SD LED
AI
SN2500
SUB5V
STB3.3V
SUB5V
STB3.3V
TIMER LED
D2510
R&G LED
D2500
Q2500 Q2501
REMOTE CONTROL
A01
4
STB5V
D3015
DIGITAL
AUDIO OUT
SUB3.3V 3
5VS
JK4501
+5V
18
HDMI1
JK4500
+5V 18
HDMI2
JK4700
+5V 18
HDMI3
JK4502
+5V 18
HDMI4
CN0100
STB5V 1
SERVICE
JK8302
SUB_SD
_3.3V
4
SD SLOT
JK8401
SUB_CI
_5V 17,18
CI SLOT
51,52
A11
1 2
3
4
42
43
PNL12V
TO LCD PANEL
P17V
Q5417
MAIN_SND_17V
IC2008
Regulator
4
Vin
5
Vout
SUB5V
AAVDD_3.3V
IC4511
Regulator
4
Vin
5
Vout
SUB5V
DVDDI0_3.3V
TVDD_3.3V
IC4513
Regulator
4
Vin
5
Vout
SUB3.3V
PVDD_1.8V
VAVDD_1.8V
CVDD_1.8V
IC4512
Regulator
6
Vin
1
Vout
SUB3.3V DVDD_1.8V
IC2902
Regulator
4
Vin
5
Vout
SUB_TNR_6V
TUNER5V
IC5441
Regulator
2
VDD
1
Vout
SUB9V
BT30V
IC5405
Regulator
1
Vin
3
Vout
SUB_TNR_6V
SUB5V
IC5409
Regulator
4,3
Vin
5
Vout
SUB_F_12V
SUB9V
IC5533
Regulator
5
Vout
SUB5V ZW_PL3.3V
IC5534
Regulator
5
Vin
1
Vout
SUB5V
ZW3.3V
L4211
ZW2.5V
L4209
ZW_IF3.3V
IC8403
Regulator
1
Vin
5
Vout
SUB5V
SUB_CI_5V
IC8302
Regulator
1
Vin
5
Vout
SUB3.3V
CVDD_1.2V
IC5600
DC/DC CONV
20
VCC
10
SUB_F_12V
SUB3.3V
IC5480
DC/DC CONV
24 11
SUB_F_12V
SUB9V
12
STB3.3V
13
STB5V
16
5VS
19
SUB5V
Peaks reset
V10
9
5
TUNER
TU2901
3
16
TUNER5V
BT30V
TUNER5V 5
KEY
IC8502
EEPROM PL-AVC
8
SUB3.3V
IC1101
EEPROM GENX
8
STB3.3V
IC5601
DC/DC CONV
20
VCC
4
SUB_F_12V
SUB1.2V
10
SUB1.8V
L8003
1.8_DDRI/F
IC8002
DDR SDRAM
A1,E1,M9,J9,R1,J1,A9,C1, C3,C7,C9,E9,G1,G3,G7,G9
1.8_DDRI/F
IC8003
DDR SDRAM
A1,E1,M9,J9,R1,J1,A9,C1, C3,C7,C9,E9,G1,G3,G7,G9
1.8_DDRI/F
IC5512
DC/DC CONV
20
VCC
4
SUB_F_12V
ZW1.2V
10
ZW1.8V
L4210
ZWDDR1.8V
IC4201
DDR SDRAM
A1,E1,M9,J9,R1,J1,A9,C1, C3,C7,C9,E9,G1,G3,G7,G9
ZWDDR1.8V
IC4202
DDR SDRAM
A1,E1,M9,J9,R1,J1,A9,C1, C3,C7,C9,E9,G1,G3,G7,G9
ZWDDR1.8V
IC4203
FLASH MEMORY
8
ZW3.3V
IC8408
Buffer
20
SUB3.3V
IC8409
Buffer
20
SUB3.3V
IC8410
Buffer
20
SUB3.3V
IC8411
Buffer
20
SUB3.3V
4
Vin
IC8580
FLASH MEMORY
29,43,53
SUB3.3V
IC8404
TS Buffer
20
SUB5V
IC8405
TS Buffer
20
SUB5V
IC2750
TEMP SENSOR
4,5
SUB3.3V
IC8004
Clock Gen
5,13,15
SUB_XO_3.3V
SUB3.3V
L8005
SUB_XO_3.3V
IC2301
Audio Amp
19,20,35,36
MAIN_SND_17V
IC4200
ZWEI
ZW1.2V
ZW1.8V
ZW3.3V
ZW_PL3.3V
IC4510
ADV
TVDD_3.3V
DVDD_1.8V
VAVDD_1.8V
PVDD_1.8V
AAVDD_3.3V
DVDDI0_3.3V
CVDD_1.8V
SUB3.3V
L8001
VDD3.3V
IC8001
Peaks AVC
SUB1.2V
SUB1.8V
SUB3.3V
VDD3.3V
IC1100
GENX
24,39,62,64,68,88
STB3.3V
IC3001
AVSW
4,6,18,22,24,36,82,86
SUB5V
45,80
SUB9V_VIDEO
SUB9V
R3112
SUB9V_VIDEO
A10
1
5
20
IC8301
Com. Dem
4,15,27,39,45,48
CVDD_1.2V
12,24,36,40,41,51,60
SUB3.3V
IC8401
Level Shifter
49
SUB3.3V
2,17,33
SUB5V
OVP_DET
SUB_F_12V
SUB_TNR_6V
P17V
SOS
ZW3.3V
SUB9V
SUB5V_CI
SUB3.3V
SUB_F_12V
Q LINK
D3339 D3048
STB5V
ZW2.5V
1.8_DDRI/F
5
SOS_SENSE
P17V
P2
P5 P6
TO LCD PANEL
RM2500
LED RECEIVER
P1
MAIN IN
