Panasonic BTS901YN - COLOR MONITOR User manual

erating
nstructions
Color Video Monitor
Model No. BT-S9SO1YN
Please read these instruchons completely. before operating this set.
TOBJOO20

Dear Panasonic Customer;
Welcome to our Panasonic family of customers. It is our desire that you have many years of enjoyment
from your new Color Video Monitor.
ee ——eE—E ee il
Customer’s Record
The serial number of this product may be found on its back cover. You should note the serial number of
this unit in the space provided and retain this book as a permanent record of your purchase to aid in
identification in the event of theft or loss.
Mode! number: BT-S901YN Serial number:
Note: This Color Video Monitor is designed to operate in the U.S.A., and in other countries where the —
broadcasting system and AC power are exactly the same as those in the U.S.A.
WARNING: To reduce the risk of fire or electric shock, do not expose this
appliance to rain or moisture.
\
The following cautions are attached to this color video monitor:
The lightning flash with arrowhead within a
triangle is intended to tell the user that parts
CAUTION inside the product present a risk of electric
shock to persons.
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
The exclamation point within a triangle is
intended to tell the user that important oper-
ating and servicing instructions are con-
tained in the paper work accompanying the
video monitor.
DO NOT REMOVE COVER {OR BACK).
NO USER-SERVICEABLE PAATS INSIDE
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL
f
WARNING: This equipment has been tested and found to comply with the limits for a Class A digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated in a commercial! environment. This
equipment generates, uses, and can radiate radio frequency energy and, if not installed and used
in accordance with the instruction manual, may cause harmful interference to radio communica-
tions. Operation of this equipment in a residential area is likely to cause harmful interference in
which case the user will be required to correct the interference at his own expense.
CAUTION: Any unauthorized changes or modifications to this equipment would void the users authority to
operate.

mF: |0)(-Me) mOre) alt=) a) ec
PECANS -stirsestowdoainepestnreateveisecnier cess auitarseusnc dau Deietosiata tenes:
2720 [4 2 Gene Re epee en De eR Cree Pe rE ORT eee nnn eo one
COMUO! LE OCANOMS: sissshc iateceke rive retee ies Yensainecuncsscissnentghivest eswdeaenne
ODGIANGNS sscpcqcxtreisittes esetien iiierectolativndicetiatieeieiendess
Video/Audio Terminals ........cccceceeeceeeee: eee
CGOPIMO CHONG: fists esieiccassconcatancaneersteceecanaveuntmardadilsaeanten ca gloaiaiees
SIO CHIGA MONG: aiccentaietenadsbeadeedicaricoatevtastiateee du ieend neta auendeneenst

Precautions
@ Do not attempt to disassemble the Color Video Monitor.
To prevent electric shock, do not remove screws or cover. There are no user-serviceable parts inside.
Refer servicing to qualified service personnel.
@ Location
Adequate ventilation is essential to prevent failure of the electrical components.
Avoid direct sunlight on the set. Do not mount above heat generating equipment or near high magnetic
fields.
© Do not use this Color Video Monitor beyond its temperature and humidity range.
(a) This unit is designed for indoor use. Ambient temperature must not exceed the range of 32°F ~
104°F (0°;C~+40°C).
(b) Avoid using this Color Video Monitor when the humidity is either above 80% or less than 20%.
(c) Do not block the ventilation slits onthe bottom, sides and rear panels. If rack mounted, allow
ventilation space or force cool the unit.
© The input power source is 120V 50Hz/60Hz AC.
© Do not remove the grounding pin on the AC power plug.
This Color Video Monitor is equipped with a three wire grounding-type power plug. This plug will only fit
a grounding-type power outlet.
This is a safety feature. If you are unable to insert the plug into the outlet, contact an electrician. Do not
defeat the purpose of the grounding plug.
Use a grounding-type
power outlet only.
Do not remove

@ Two selectable input signals (LINE A / LINE B)
@ Applicable of both Video and S-Video signals (Switch selectable at LINE A)
© NTSC-M System (American TV Standard 525 Line/60 Field)
© Underscan (Switch Selectable)
© Pulse Cross (Switch Selectable)
@ BLUE Only for monitor set up and balance with the SMPTE color bar signal.(Switch Selectable)
@ INT/EXT Sync (Switch Selectable)
@ Automatic Impedance Change for Video and Sync In/Out terminals (750hm or high)
© A compact designed attractive metal cabinet
@ Capable of rack-mounting with optional brackets
@ Virtually no magnetic/electrical interference
@® Controls
¢ Front; POWER/VOL Control LINE A / LINE B Change Switch
Underscan Switch Pulse Cross Switch
BLUE Only Switch INT/EXT SYNC Switch
V-HOLD Control CONTRAST Control
BRIGHT Control TINT Control
COLOR Control
* Rear: Impedance Change Switch (75Q or HI-Z, S-VIDEO)
VIDEO/S-VIDEO Switch (LINE A only)
* Behind Access Panel:
Aperture Control (Front)
® Input/Output
LINE A
S-VIDEO IN/OUT : 4P MINI DIN Type
VIDEO IN/OUT : BNC Type
AUDIO IN/OUT : RCA Phono Type
LINE B
VIDEO IN/OUT : BNC Type
AUDIO IN/OUT : RCA Phono Type
EXTERNAL SYNC IN/OUT : BNC Type

Oxeyaiiage) mm Meler-1i(e)at=
FRONT
at-$901 wn
@) iNT/EXT SYNC Switch
3) LINE A / LINE B Change
Switch
APERTURE Control
V-HOLD Control
(9) CONTRAST Control
(@ BRIGHT Control
di) TINT Control
(2 COLOR Control
(2) Power indicator
GQ) POWER/VOL Control
(@) Underscan Switch
(5) Pulse Cross Switch
(6) BLUE Only Switch
REAR
Color Video Manilor (h)
MODEL MO. 6T-S001TN
i
—
War 2
/4, iol Ata ied .
aa
en eel
Trae DEVICE COePUEd Writ ae
Model Number
INPUT/OUTPUT Terminals
DOQQQ0Q00DD0000000001
DOQQMDOODDD 0000000000
Serial Number
Note:
1.
The
circled
numbers
indicate
the
control
description
item
on
the
following
page.
2.
The
APERTURE
control
is
not
user
adjustable
and
should
only
be
adjusted
by
a
qualified
service
personnel.

Gd) POWER/VOL Control 1. Turn clockwise to turn the monitor on.
Turn counterclockwise to turn the monitor off.
2. Adjust this control for the appropriate audio level.
The Power Indicator will light when the monitor is turned on.
LINE A: Receives video signa! from the VIDEO IN terminal or S-
VIDEO signal from the S-VIDEO IN terminal, and audio sig-
nal from AUDIO IN terminal.
LINE B: Receives video and audio signals from the VIDEO IN and
afl me AUDIO IN terminals.
@) Underscan Switch Decreases the overall picture size to allow the corners to be seen.
(QO)
6) Pulse Cross Switch Receives cross pulse to allow vertical and horizontal syncs to be seen
) in the picture.
@ Power Indicator
@ LINEA / LINEB
Change Switch
z
© BLUE Only Switch Defeats the red and green signals. This feature is used for monitor
(ELUE) balancing with the SMPTE color bar signal. 7
@ INT/EXT SYNC Switch Set the INT/EXT SYNC Switch to EXT Position when connecting an
~ external composite sync signal to the monitor.
V-HOLD Control Adjust the V-Hold control if the picture rolls up or down.
(9) CONTRAST Control Adjust the contrast level for proper overall contrast.
There is a click position for normal level.
(@ BRIGHT Control
Adjust the brightness level for proper overall picture brightness.
There is a click position for normal level.
d) TINT Control Adjust the Tint control for proper chroma phase of flesh tones.
(2 COLOR Control Adjust the Color contro! to set the chroma (saturation) level.

Vato (loves NUlol(omm m=) aenllarclc
Terminal Board on Rear Cover
$-VIDEO _.
aa So ao
o a a 2
a cG
S-VIDEO IN/OUT Terminals”
3)
Impedance
Change
Switch
VIDEO
IN/OUT
Terminals
LINE
A
B) e
AUTO 75Q/HI-Z Terminals
© AUDIO © (5) AUDIO IN/OUT Terminals
viocoff | $-VIBEO
6] VIDEO/S-VIDEO Select Switch
ven
-[)
VIDEO
IN/OUT
Terminals
AUTO 75Q/HI-Z LINE B
Oe:
©
[9]
AUDIO
IN/OUT
Terminals
Terminals
EXT SYNC IN/OUT Terminals
5
AUTO 75Q/HI-Z
Signal Level and Terminal Impedance
Fema [ tee [_inpmsnce
sn
(0.7Vp-p)
= [=
ow [=f
Includes sync
signal.
(Does not include
sync signal.)
1 Vrms =0dB
at 400Hz
Negative vertical
and horizontal sync
EXT. SYNC

LINE A Terminals Available when LINE A / LINE B Change Switch on the front panel is
set to “LINE A”.
[2] S-VIDEO IN/OUT Connect S-VIDEO signal to {N terminal.
Terminals The same signal is available at the OUT terminal.
[3] Impedance Change Set this switch to 75Q for the S-ViIDEO termination or to HI-Z for
Switch bridge-connection to next unit.
[4] VIDEO IN/OUT Connect video signal to IN terminal.
Terminals The same signal is available at the OUT terminal.
[5} AUDIO IN/OUT Connect audio signal to IN terminal.
Terminals The same signal is available at the OUT terminal.
[6} VIDEO/S-VIDEO Select When the video signal is applied, set this switch to VIDEO position
Switch and when the S-VIDEO signal is applied, set this switch to S-VIDEO
position. |
LINE B Terminals Available when LINE A / LINE B Change Switch on the front panel is
set-to “LINE B”.
[8] VIDEO IN/OUT Connect video signal to IN terminal.
Terminals The same signal is available at the OUT terminal.
{9] AUDIO IN/OUT Connect audio signal to IN terminal.
Terminals The same signal is available at the OUT terminal.
EXT SYNC IN/OUT Connect an external composite sync signal to this terminal when a
Terminals non-composite video signal is applied to the video terminals ([4) or
(8).
Note: 1. The video and the external sync input/output terminals are equipped with “Automatic Termination
Switch”. If only input signal is applied, they are terminated by 75ohm, and if both input/output
signals applied, they are opened to high impedance.
2. It is possible to connect up to 10 monitors in series by looping through the S-VIDEO IN and
$-VIDEO OUT or the VIDEO IN and VIDEO OUT terminals. There may be a possibility of a
brightness reduction or interference if more than 10 units are connected. Please carefully confirm
that these problems do not exist with the units before connection.

OXeyalal=rerile) a kom
Video Camera
Video Disc
Sync Generator
or other Sync
Source
Specifications
Power Source:
Power Consumption:
Television System:
Dimensions (WX D X H):
Weight:
Picture Tube:
Speaker:
Speaker Output Level:
Operation Temperature Range:
Operation Humidity Range:
Option:
120V 50/60Hz AC
37 W
NTSC-M System (American TV Standard 525 Line/60
Field)
8 25/32" K 12 1/16" X 9”
(223 mm) X (321.5 mm) X (228.5 mm)
15.5 tbs. (7.0 kg)
9 inches, 90° deflection
2 1/2 inch round type, located on cabinet left
1.0W (at 10% distortion)
32°F ~104°F (0°C ~ +40°C)
20% ~ 80%
Rack Kit (TY-LK100)
Contents subject to change without notice.
